LG LGAX310 User Manual

Important Safety Precautions

Read these instructions. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

WARNING! Violation of the instructions may cause serious injury or death.

1. Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

2. Never place your phone in a microwave oven as it will cause the battery to explode.

3. Never store your phone in temperatures less than

-4°F or greater than 122°F.

4. Do not dispose of your battery by fire or with hazardous or flammable materials.

5. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is deployed, you may be seriously injured.

6. Do not use a hand-held phone while driving.

7. Do not use the phone in areas where its use is prohibited. (For example: aircraft)

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 1

Important Safety Precautions

1. Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

2. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. This could cause a fire.

3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the phone.

4. Do not use your phone in high explosive areas as the phone may generate sparks.

5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause electric shock or fire.

7. Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

8. Do not disassemble the phone.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 2

Important Safety Precautions

1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

2. Do not hold or let the antenna come in contact with your body during a call.

3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

4. Store the battery out of reach of children.

5. Be careful that children do not swallow any parts (such as rubber plugs, earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury or death.

6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

7. Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

8. Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

9. Your service provider programs one or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 3

Table of Contents

Important Safety Precautions

Table of Contents 4

Welcome 9

Technical Details 10

Important Information 10

FCC Part 15 Class B Compliance 10

Technical Details 10

FCC RF Exposure Information 12

Bodily Contact During Operation 12

Vehicle-Mounted the External Antenna 13

FCC Notice and Cautions 13

Caution 14

Part 15.19 statement 14

Part 15.21 statement 14

Part 15.105 statement 15

Phone Overview 16

Menus Overview 18

Getting Started with Your Phone 21

The Battery 21

Installing the Battery 21

Removing the Battery 21

Charging the Battery 22

Battery Charge Level 22

Turning the Phone On and Off 23

Turning the Phone On 23

Turning the Phone Off 23

Signal Strength 23

Screen Icons 24

Making Calls 24

Correcting Dialing Mistakes 25

Receiving Calls 25

Quick Access to Convenient Features 26

Lock Mode 26

Mute Function 26

Quick Volume Adjustments 26

Call Waiting 26

Caller ID 27

Speed Dialing 27

Entering and Editing Information 28

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 4

Table of Contents

Text Input 28

Key Functions 28

Contacts in Your Phone’s Memory 29

The Basics of Storing Contacts Entries 29

Phone Numbers With Pauses 29

Storing a Number with Pause or Wait 30

Adding Pause or Wait to an Existing Number 30

Searching Your Phone’s Memory 31

Scrolling Through Your Contacts 31

Contacts Options 31

Making a Call From Your Phone’s Memory 32

Phone Menus 34

Messaging 34

1. New Text Message 34

2. New Picture Message 36

3. Inbox 38

4. Sent 39

5. Drafts 40

6. Voicemail 41

7. Templates 41

8. Settings 41

9. Delete All 44

Alltel Shop 44

1. Launch 45

Alltel Web 45

1. Launch 45

Multimedia 48

1. Take Photo 48

2. Record Voice 49

3. Images 49

4. Audios 50

5. Shuffle 51

Contacts 52

1. New Contact 52

2. Contact List 52

3. Groups 53

4. Speed Dials 53

5. My Name Card 54

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 5

Table of Contents

Recent Calls 54

1. Missed Calls 54

2. Received Calls 55

3. Dialed Calls 55

4. All Calls 55

5. Call Timer 55

6. Data 55

7. Data Counter 56

Bluetooth 56

1. Paired Devices 57

2. Power 57

3. My Visibility 58

4. My Bluetooth Name 58

5. My Bluetooth Info 58

Tools 59

1. Voice Command 59

1.1 Start Command 59

1.1.1 Call <Name> or <Number> 59

1.1.2 Voicemail 59

1.1.3 Missed Calls 59

1.1.4 Messages 59

1.1.5 Time & Date 59

1.1.6 Help 60

1.2 Command Mode 60

1.3 Announce Alert 60

1.4 Train Word 60

1.5 Best Match 60

2. My Menu 61

3. Alarm Clock 61

4. Calendar 62

5. Ez Tip Calc 62

6. Notepad 63

7. Calculator 63

8. World Clock 64

9. Stopwatch 64

0. Unit Converter 64

Settings 65

1. Sound 65

1.1 Ringers 65

1.2 Volume 65

1.3 Message Alerts 65

1.4 Alert Type 66

1.5 Service Alerts 66

1.6 Power On/Off Tone 66

1.7 Flip Tone 67

2. Display 67

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 6

Table of Contents

2.1 Wallpaper 67

2.2 Banner 68

2.3 Backlight 68

2.4 Menu Style 68

2.5 Languages 68

2.6 Clocks & Calendar 69

2.7 Font Settings 69

2.8 Phone Dial Search 69

3. Security 70

3.1 Lock Phone 70

3.2 Restrictions 70

3.3 Emergency #s 71

3.4 Change Lock Code 71

3.5 Reset Default 72

4. Call Settings 72

4.1 Answer Options 72

4.2 Auto Retry 72

4.3 One-Touch Dial 73

4.4 Voice Privacy 73

4.5 Voice Clarity 73

4.6 Airplane Mode 74

4.7 TTY Mode 74

5. PC Connection 74

6. Alltel Shop & Web 75

6.1 Alltel Info 75

6.2 Web Settings 75

7. S y s tem 75

7.1 Network 75

7.1.1 System Select 75

7.1.2 Set NAM 76

7.1.3 Auto NAM 76

7.1.4 Serving System 76

7.2 Location 76

8. Memory 77

9. Phone Info 77

RealTone JukeBox 78

Alltel Navigation 78

Wallpaper Universe 78

Safety 79

TIA Safety Information 79

Exposure to Radio Frequency Signal 79

Antenna Care 79

Phone Operation 80

Tips on Efficient Operation 80

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 7

Table of Contents

Driving 80

Electronic Devices 80

Pacemakers 81

Persons with pacemakers: 81

Hearing Aids 81

Other Medical Devices 81

Health Care Facilities 82

Vehicles 82

Posted Facilities 82

Aircraft 82

Blasting Areas 82

Potentially Explosive Atmosphere 82

For Vehicles Equipped with an Air Bag 83

Safety Information 83

Charger and Adapter Safety 84

Battery Information and Care 85

Explosion, Shock, and Fire Hazards86

General Notice 86

Warning! Important safety information 88

Avoiding hearing damage 88

Using your phone safely 88

Avoiding hearing damage 89

Using headsets safely 89

FDA Consumer Update 89 10 Driver Safety Tips 100 Consumer Information on

SAR 103 FCC Hearing-Aid Compatibility

(HAC) Regulations for Wireless Devices 106

Accessories 110

Limited Warranty Statement 111

Index 115

Some content in this user guide may differ from your phone depending on the phone software. Features and specifications are subject to change without prior notice.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 8

Welcome

Thank you for choosing the AX310 cellular phone designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this compact phone offers:

●

Significantly enhanced voice clarity

●

Slim and sleek design with internal antenna (Internal antenna described as antenna throughout this user guide).

●

Large, easy-to-read, backlit LCD with status icons.

●

Paging, messaging, voice mail, and caller ID.

●

24-key keypad.

●

Speakerphone feature.

●

Menu-driven interface with prompts for easy operation and configuration.

●

Any key answer, auto answer, auto retry, one-touch and speed dialing with 99 memory locations.

●

Bilingual (English and Spanish)

capabilities.

●

Bluetooth®wireless technology.

Note

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 9

Technical Details

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your warranty.

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Technical Details

The AX310 is a dualmode phone that operates on among (Code Division Multiple Access CDMA) frequencies: cellular services a 800 MHz, (Personal Communication Services PCS) at

1.9 GHz.

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard handoff, and dynamic RF power control technologies combine to reduce call interruptions.

The Cellular and PCS CDMA networks consist of MSO

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 10

Technical Details

(Mobile Switching Office), BSC (Base Station Controller), BTS

(Base Station Transmission System), MS (Mobile Station).

CDMA Standard

Basic Air Interface

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000 ANSI TIA/EIA 553A

CDMA Dual Mode Air Interface

14.4kbps radio link protocol and interband operations IS-95 adapted for PCS frequency band cdma2000 1xRTT AirInterface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Cellular base station Cellular mobile station PCS personal station PCS base station Speech CODEC

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125

TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 TIA/EIA/IS-707-A

Speech CODEC Short message service Packet Data Position Determination Service (gpsOne) High Speed Packet Data

Network

Service

Performance

Designator

Description

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 11

Technical Details

* TSB-74: Protocol between an

IS-95A system and ANSI JSTD-008

1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. Highspeed data transmission is also possible.

The following table lists some major CDMA standards.

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic

energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 0.79 inches (2.0 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of

0.79 inches (2.0 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Thirdparty belt-clips, holsters, and similar accessories containing

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 12

Technical Details

metallic components should not be used. Avoid the use of accessories that cannot maintain

0.79 inches (2.0 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted the External Antenna

(Optional, if available.)

To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted the external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

FCC Notice and Cautions

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the

following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Use only the supplied antenna. Use of unauthorized antennas (or modifications to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations.

Don't use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 13

Technical Details

Caution

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin a minor burn may result. Contact your local dealer for a replacement antenna.

Part 15.19 statement

This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions:

(1) This device & its accessories

may not cause harmful interference.

(2) This device & its accessories

must accept any interference received, including interference that may cause undesired operation.

Part 15.21 statement

Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 14

Welcome

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. if this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 15

Phone Overview

1. Earpiece Lets you hear the caller.

2. LCD Screen Displays messages and indicator

icons. When the phone is turned on, Power Save mode automatically dims the screen and then darkens it if no keys are pressed.

3. Left Soft Key Use to access the Contacts list

from the standby screen, or the function immediately above it.

Speakerphone Key Use to turn Speaker On or Off.

5. SEND Key Use to place or answer calls.

6. Alphanumeric Keypad Use to enter numbers

and characters and select menu items.

Vibrate Mode Key

Use to set Normal/Vibrate Only mode from standby mode, press and hold for about 3 seconds.

8. Navigation Key Use to navigate through menus

and options. When in standby mode, use for quick access to Alltel Web, Ringers, My Menu and Alltel myapps.

9. Right Soft Key Use to access Messaging from

the standby screen, or the function immediately above it.

10 .

Menu/OK

Key Lets you access the phone's

main Menu and also selects the highlighted choice when navigating through a menu or function.

11. Voice Command When in standby mode, use

to start the Voice Command feature.

12 .

PWR/END Key Use to turn the power on/off

and to end a call. Also returns to standby mode.

13 . CLR Key Deletes single spaces or characters

with a quick press, but press and hold to delete text entered. Will also back you out of menus, one level at a time.

14 .

Lock Mode Key

Use to lock the phone when in standby mode, press and hold for about 3 seconds.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 16

Phone Overview

1. Earphone Jack Allows the use of a headset for

handsfree conversations.

2. Side Keys Use to adjust the ringer volume in

standby mode and the earpiece volume during a call.

3. Charger Port Connects the phone to the battery

charger or other available accessories.

4. Side Camera Key Use for quick access to Camera

function.

5. Camera Lens lets you take pictures and videos.

6. Speaker lets you hear the different ringers and

sounds.

Charging with PC USB

You can use your computer to charge your phone. Connect one end of a USB cable to the charging accessory port on your phone and the other end to a highpower USB port on your PC (commonly located on the front panel of the computer). When charging with Hub, charge the phone with Hub Power.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 17

Menus Overview

Messaging

1. New Text Message

2. New Picture Message

3. Inbox

4. Sent

5. Drafts

6. Voicemail

7. Templates

8. Settings

1. All Messages

2. Text Message

3. Picture Message

4. Edit Voicemail#

9. Delete All

1. Delete Inbox

2. Delete Sent

3. Delete Drafts

4. Delete All Messages

Alltel Shop

Alltel Web

Multimedia

1. Take Photo

2. Record Voice

3. Images

4. Audios

5. Shuffle

Contacts

1. New Contact

2. Contact List

3. Groups

4. Speed Dials

5. My Name Card

Menu Access

While in standby mode, press Menu to access the phone menus. There are two methods of accessing menus and submenus:

●

Use the navigation key to highlight and select. Or

●

Press the number key that corresponds with the menu (or submenu).

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 18

Menus Overview

Recent Calls

1. Missed Calls

2. Received Calls

3. Dialed Calls

4. All Calls

5. Call Timer

6. Data

7. Data Counter

Bluetooth

1. Paired Devices

2. Power

3. My Visibility

4. My Bluetooth Name

5. My Bluetooth Info

Tools

1. Voice Command

1. Start Command

2. Command Mode

3. Announce Alert

4. Train Word

5. Best Match

2. My Menu

3. Alarm Clock

4. Calendar

5. Ez Tip Calc

6. Notepad

7. Calculator

8. World Clock

9. Stopwatch

0. Unit Converter

Settings

1. Sound

1. Ringers

2. Volume

3. Message Alerts

4. Alert Type

5. Service Alerts

6. Power On/Off Tone

7. Flip Tone

2. Display

1. Wallpaper

2. Banner

3. Backlight

4. Menu Style

5. Languages

6. Clocks & Calendar

1. Main Screen

2. Front Screen

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 19

Menus Overview

7. Font Settings

8. Phone Dial Search

3. Security

1. Lock Phone

2. Restrictions

3. Emergency #s

4. Change Lock Code

5. Reset Default

4. Call Settings

1. Answer Options

2. Auto Retry

3. One-Touch Dial

4. Voice Privacy

5. Voice Clarity

6. Airplane Mode

7. TTY Mode

5. PC Connection

1. USB Modem

2. Bluetooth

3. Closed

6. Alltel Shop & Web

1. Alltel Info

2. Web Settings

7. S y s t e m

1. Network

2. Location

8. Memory

1. Reserved Memory

2. Multimedia

9. Phone Info.

1. My Number

2. ESN/MEID

3. Icon Glossary

4. Version

Alltel Navigation

RealTone JukeBox

Wallpaper Universe

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 20

Getting Started with Your Phone

The Battery

The phone comes with a rechargeable battery. The battery charge level is shown at the top of the LCD screen.

Installing the Battery

Remove the battery cover by pressing down below the LG logo and sliding the cover up. Align the battery with the terminals near the top of the phone, then snap the rest of the battery into place. Align the battery cover then slide it downward side until it clicks into place.

Removing the Battery

Turn the phone off. Slide the battery cover to upward to remove it. Use the opening near the bottom of the battery to lift the battery out.

Note

It is important to fully charge the battery before initial use of the phone.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 21

Charging the Battery

Use the charger provided with your phone:

Warning! Use only the charger provided with the phone. Using any charger other than the one included with the AX310 may damage your phone or battery.

1. Plug the end of the adapter into the phone’s charger port and the other end into an electrical outlet.

2. The charge time varies depending upon the battery level.

Battery Charge Level

The battery charge level is shown at the top right of the LCD screen. When the battery charge level becomes low, the low battery sensor alerts you in up to three ways: sounding an audible tone, blinking the battery icon, and displaying a warning message. If the battery charge level becomes exceedingly low, the phone automatically switches off and any function in progress is not saved.

Getting Started with Your Phone

Notice

Please make sure that the 'B' Side faces up before inserting a charger or data cable into the charger port of your phone.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 22

Getting Started with Your Phone

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source.

2. Press for about 3 seconds until the LCD screen lights up.

Turning the Phone Off

1. Press and hold until the display turns off.

Signal Strength

Call quality depends on the signal strength in your area. The signal strength is indicated on the screen as the number of bars next to the signal strength icon

-- the more bars, the better the signal strength. If the signal quality is poor, move to an open area. If you are in a building, the reception may be better near a window.

Note

The call quality may also be affected by the places where you are and weather/ambient conditions.

AX310_Eng_0817.qxd 8/17/09 4:17 PM Page 23

Getting Started with Your Phone

Screen Icons

To see the icon glossary, go to

Settings

Phone Info.

Icon Glossary

on your phone.

Making Calls

1. With the phone turned on, open the flip.

If the phone is locked, press the Left Soft Key Unlock, enter the Lock Code (by default, it is the last 4 digits of your phone number).

2. Enter the phone number (include the area code if needed).

3. Press .

4. Press to end the call.

Getting Started with Your Phone

Note

If Outgoing calls are restricted, you can only dial phone numbers saved in the Emergency Numbers or your Contact List. To turn off this function:

Menu -> Settings ->

Security -> Lock Code ->

Restrictions -> Lock Code -> -> Restrictions -> Calls ->

None

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 24

Getting Started with Your Phone

Correcting Dialing Mistakes

If you make a mistake while dialing a number, press while once to erase the last digit entered, or hold down while press digit go to the for at least 2 seconds to go back to standby mode.

Redialing Calls

1. Press twice to redial the number from the last call. The last 120 numbers calls (40 missed, 40 received and 40 dialed) are stored in the call history list and you can also select any of these to redial.

Receiving Calls

1. When the phone rings and/or vibrates, press to answer or open the flip (depending on your Answer Options).

2. Press to end the call.

Note

If you press (the side keys), while the phone is ringing, the ringing and/or vibration is muted for that call.

Tip

To change Answer Options:

Settings

Call Settings

Answer Options

Choose from the following options:

Flip Open/ Any Key/ SEND Key Only/ Auto Answer

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 25

Quick Access to Convenient Features

Lock Mode

Sets your phone to require a 4digit password in order to use the phone.

To quickly lock your phone press

for three seconds. To

unlock, press Left Soft Key Unlock, enter the Lock Code and press .

Mute Function

The Mute Function can be used during a phone call. To quickly activate Mute press Left Soft Key

Mute, then to cancel press

Left Soft Key Unmute.

Quick Volume Adjustments

Use the side keys to adjust the Master volume while in standby mode, and the earpiece volume during a phone call. The upper key increases the volume and the lower key decreases the volume.

Call Waiting

Your cellular service may offer call waiting. While a call is in progress, a beep indicates another incoming call. When call waiting is enabled, you may put the active call on hold while you answer the other incoming call.

Note

Until you change it, the default lock code/password is the last 4 digits of your phone number.

Note

Keypad Volume is adjusted through the Sound Volume menu:

Menu -

Settings -

Sound -

Volume -

Keypad -

Use

adjust volume and press .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 26

Quick Access to Convenient Features

Check with your cellular service provider for information about this function.

1. Press to answer a waiting call.

2. Press again to switch between calls.

Caller ID

Caller ID displays the phone number or name of the incoming call. If the caller’s identity is stored in Contacts, the name will appear along with the phone number. Check with your cellular provider for information about this function.

Speed Dialing

Speed dialing is a convenient feature that allows you to make phone calls quickly. A speed dial number can be assigned to a specific phone number. By pressing and holding down a

number key, your phone will recall the phone number associated from the Contact List and display it briefly while simultaneously dialing that phone number for you. Speed Dial Number 1 is set to Voicemail by default and is unchangeable.

Dialing Single Digit Speed Dials (from 2 to 9)

Press and hold the Speed Dial number.

OR Enter the Speed Dial number

and press .

Dialing Double Digit Speed Dials (from 10 to 99)

Press the first digit and then press and hold the key of the second digit.

OR Enter the first and second

digits and press .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 27

Entering and Editing Information

Text Input

You can customize and enter text in many of the functions in your phone. Including, but not limited to: the Banner, Calendar, Contacts and more. While entering text, the following are your options:

Key Functions

Left Soft Key: Press to scroll through the following text input modes:

T9 Word

: T9WORD/

T9Word/ T9word

Abc

: ABC/ Abc/ abc

12 3 Symbols

Shift Key: Press to change

capitalization modes: T9Word : T9Word -> T9WORD -> T9word

Abc : Abc -> ABC -> abc

Next: In T9 mode, press

to display other matching words.

Space: Press to complete a word and insert a space.

Clear: Press to delete a single space or character. Hold to delete the text entered.

Punctuation: When entering text or numbers, press to enter punctuation marks or some of available special characters.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 28

Contacts in Your Phone’s Memory

The Basics of Storing Contacts Entries

1. From standby mode enter the phone number you want to save (up to 48 digits).

2. Press Left Soft Key Save.

3. Select either Save New or Update Existing.

4. Use to highlight a Label and press .

Mobile 1/ Home/ Work

Mobile 2/ Fax

5. Enter a name for the phone number (up to 22 characters) and press . A confirmation message is displayed briefly.

Phone Numbers With Pauses

When you call automated systems, such as voice mail or credit billing numbers, you often have to enter a series of numbers to navigate through the system. Instead of entering these numbers by hand, you can store the numbers in your Contacts separated by special pause characters (W, P). There are two different types of pauses you can use when storing a number:

Wait (W)

The phone stops dialing until you press Left Soft Key

Release

to advance to the next

string of digits.

Pause (P)

The phone waits 2 seconds before sending the next string of digits.

Note

Use

Update Existing

to add another phone number to a contact already stored in memory.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 29

Contacts in Your Phone’s Memory

Storing a Number with Pause or Wait

1. Press

2. Press

Contacts

3. Press

New Contact

4. Enter a name (up to 22 characters) and enter a number.

5. While entering a number, press Right Soft Key

Options.

6. Press

Wa it

Pause

7. Enter additional number(s) then press

Save

Adding Pause or Wait to an Existing Number

1. Press the Right Soft Key7

Contacts

to display your

Contacts alphabetically.

2. Use to highlight the Contact entry to edit, then press View.

3. Press Left Soft Key

Edit

4. Use to highlight the number.

5. Press Right Soft Key

Options

6. Press

Wa it

Pause

7. Enter additional number(s), then press

Save

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 30

Contacts in Your Phone’s Memory

Searching Your Phone’s Memory

The AX310 phone is able to perform a dynamic search of the contents in your phone’s Contact List. A dynamic search compares entered letters on the Dialpad against the entries in your Contacts. A matching list is displayed in descending order. You can then select a number from the list to call or view.

Scrolling Through Your Contacts

1. Press

Contacts

to display your Contacts alphabetically.

2. Use to scroll through the list.

Searching by Letter

1. Press

Contacts

to display

your Contacts alphabetically.

2. Start entering the Contact name. The closest (alphabetical) match will be highlighted.

Contacts Options

1. Press

Contacts

2. Highlight a contact and press Right Soft Key

Options

3. Select an option (use then press , or press the corresponding number on the keypad):

Send Message

: Send a text message or picture message to the selected contact.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 31

Contacts in Your Phone’s Memory

Delete

: Delete the selected

entry in your Contacts.

Edit

: Edit the selected

contact information.

Delete Multiple

: Choose

Selective/ All

to delete multiple entries at one time.

Send via Bluetooth

: Send the contact (as a vCard) via

Bluetooth

Set Speed Dial/ Remove Speed Dial

: Set a speed dial or remove the speed dial.

Making a Call From Your Phone’s Memory

Once you have stored phone numbers in your Contacts, you can place calls to those numbers quickly and easily.

●

By pressing Send Key after searching for a phone number in your Contacts list.

●

By using Speed Dials.

From Contacts

1. Press

Contacts

to display

your Contacts.

2. Use to highlight the Contact entry, then press .

3. Use to highlight the phone number.

4. Press to place the call.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 32

Contacts in Your Phone’s Memory

From Call History

1. Press

2. Press

Recent Calls.

3. Use to highlight the type of recent call, then press .

Missed Calls/Received Calls/Dialed Calls/All Calls

4. Use to highlight the phone number.

5. Press to place the call.

Speed Dialing

For a single-digit Speed Dial, press and hold the digit or press the digit, then press . For a double-digit Speed Dial, press the first digit and hold the second digit or press the first and second digits, then press

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 33

Phone Menus

Messaging

The phone can store up to 435 messages (including a maximum of 100 SMS and 100 MMS in the Inbox). The information stored in the message is determined by phone model and service capability. Other limits such as available characters per message may exist, please check with your service provider for system features and capabilities.

1. New Text Message

Allows you to send text messages, pages (if supported by the recipient's network), and email transmissions.

The Basics of Sending a Text Message

1. Press , , .

2. Enter the recipient's address.

3. Press to access the text screen.

Type your message (text or e-mail).

5. Press Send.

A confirmation message is displayed.

Select Recipient(s) Using Options

1. Press , , .

2. Press Right Soft Key

Options

3. Use to highlight an option and press .

Contacts

To select a recipient

from your Contact List.

Recent Calls

To select a

recipient from your Recent Calls.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 34

Messaging

Recent Messages

Choose

Inbox/ Sent

to select a recipient

from your Recent Messages.

Groups

Select a recipient from

your Groups.

Cancel

Cancels the message.

4. Complete your message and send or save it.

Customize Your Text Message

Using Options

While you are composing the text of a message, you have various options to customize the text.

1. Press , , .

2. Enter the recipient's address.

3. Use or press to get to the text entry window.

4. Press Right Soft Key

Options

5. Use to highlight an option and press .

Add Graphic/ Animation/

Sound/ Templates

Signature

Text Format Alignment/ Font

Size/ Font Style/ Text Color/ Background

Save As Draft/Templates

Priority Level Normal

High

Callback # On

Off

Delivery Notice On

Off

Cancel

Cancels the message.

6. Complete your message and send or save it.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 35

Messaging

Message Icon Reference

Inbox

New/Unread Text/Picture Message

Opened/Read Text/Picture Message

New/Unread Notification Message

Opened/Read Notification Message

Priority High

MMS New/Read Priority High

Sent

Failed Text/Picture Message

Failed Multiple Text/Picture Messages

Sent Text Message

Drafts

Draft Text Message

Draft Picture Message

2. New Picture Message

Allows you send messages with Text, Image and Audio.

1. Press , , .

2. Enter the recipient's address, or press Right Soft Key

Options

to search recent contacts, and press to select the desired contact.

3. Press to access the message screen.

4. Type your message, then use

to access other fields.

5. With the highlight on


press Left Soft Key

Add

and press to select:

Image / Take Photo

6. Use to highlight a picture, then press Left Soft Key

Set

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 36

Messaging

7. With the highlight on Audio,

press Left Soft Key

Add,

and press to select a file (listed) or a file from

Audios

. Please note that files

from

Default

are not

supported.

8. Use to highlight a sound, then press Left Soft Key

Set

9. Use to highlight Subject, then enter subject.

10. Use Right Soft Key

Options.

* Options for the To: field

Contacts/ Recent Calls/ Recent Messages/ Groups/ Online Album/ Cancel

* Options for the Text field

Preview/ Add/ Go to/ Save As/ Priority Level/ Delivery Notice/ Remove/ Cancel

* Options for the Image field

Preview/ Add Slide/ Go to

Save As Draft/ Priority Level/ Delivery Notice/ Remove/ Cancel

* Options for the Audio field

Preview/ Add Slide/Go to

Save As Draft/Priority Level

Delivery Notice/ Remove/ Cancel

* Options for the Subject field

Preview/ Add/ Go to/ Save As

Priority Level/ Delivery

Notice/ Remove/ Cancel

12. Press

Send

to send.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 37

Messaging

3. Inbox

The phone can alert you in several ways when you receive a new message, including:

●

Displaying a notification message on the screen.

●

Displaying the message icon

on the status bar (It blinks when the message is urgent).

●

Ringing and/or Vibrating (depending on the Volume settings).

Received messages are displayed from newest to oldest.

Viewing Your Inbox

Up to 300 (100 SMS, 100 MMS and 100 MMS Notifications) messages can be stored in the Inbox.

1. Press , , .

2. Use to highlight an inbox message.

3. Press Left Soft Key

to reply, or Right Soft Key

Options

or press

Chat

to view the message.

The Options menu options available are:

For text messages:

View/ Change View Type/ Delete/ Forward/ Save Contact/ Lock/ Message Info/ Delete Multiple

For picture messages:

Delete/ Forward/ Save Contact/ Lock/ Message Info/ Delete Multiple

4. While viewing the message as a Chat conversation, press Left Soft Key

reply, or Right Soft Key

Options

to view additional

options.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 38

Messaging

View Last Message/ Delete Last Chat/ Delete All/ Save Contact/ Go to Website

4. Sent

Up to 100 sent messages (50 SMS and 50 MMS) can be stored in the Sent folder. Access the Sent message list to view contents of sent messages and verify whether the transmission was successful or not.

1. Press , , .

2. Use to highlight a sent message. Press Left Soft Key

Resend

to resend the

message to the recipient,

View

to view the message, or

Right Soft Key

Options

to access additional options.

Delete/ Forward/ Save Contact/ Lock/ Message Info/ Delete Multiple

3. While viewing the selected sent message, press Left Soft Key

Resend

to resend the message to the recipient, or Right Soft Key

Options

to access the following options:

Delete

Deletes the selected

message.

Forward

Forwards a received message to other destination address(es).

Note

The options available when viewing a picture message:

Play Again/ Delete/ Forward/ Save Contact/ Save Media/ Lock/ Go to Website/ Message Info

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 39

Messaging

Save Contact

Stores the underlined number, e-mail address, and numbers in the received message into your Contacts.

Save as Templates

Stores the message as a template for future messages.

Lock/Unlock

Locks or unlocks

the selected message.

Message Info

Shows the

message type priority and status.

5. Drafts

Displays saved messages and draft messages.

1. Press , , .

2. Use to highlight a Saved message. Options available are:

●

Press

Edit

●

Press Right Soft Key

Options

Delete

Deletes the selected

message from the Drafts folder.

Save Contact

Select

Save New

Update Existing

to store the phone number or e-mail address in the draft message into your Contacts or update an existing contact already stored in memory.

Lock/Unlock

Locks a message so that it is not erased if the Delete Drafts or Delete All Messages feature is used.

Delete Multiple

Select

Selective/ All

to delete multiple

messages at one time.

Note

The options available when viewing a picture message:

Play Again/ Delete/ Forward/ Save Contact/ Save Media/ Lock/ Go to Website/ Message Info

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 40

Messaging

6. Voicemail

Allows you to access new voice messages recorded in your voice mail box. Your phone will alert you when you receive a new voice message.

Checking Your Voicemail Box

1. Press , , .

2. Choose from the following options:

●

Press Left Soft Key Clear to clear the voicemail counter.

●

Press to listen to the message(s).

●

Press Right Soft Key

Exit

to return to the Messaging menu.

7. Templates

Allows you to display, edit, and add text phrases. These text strings allow you to reduce manual text input into messages.

1. Press , , .

2. Press Left Soft Key

New

to create a new template.

Enter text and press

Save

to save the template.

3. Use to highlight a template and press Right Soft Key

Options

, then

highlight an option and press

to select:

Delete/Edit

8. Settings

Allows you to configure Messaging settings.

1. Press , , .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 41

Messaging

2. Use to highlight

All

Messages

/ Text Message/

Picture Message/ Edit Voicemail #

then press .

3. Use to highlight one of

the submenus and press

to select it.

Message Settings Sub-Menu Descriptions

All Messages

1. Auto Save (Auto Save/ Prompt/ Do Not Save)

With this feature on, messages are automatically saved in Sent when transmitted.

2. Auto Delete (On/ Off)

With this feature on, read messages are automatically deleted when you exceed the storage limit.

3. Entry Mode

Allows you to select the default input method including

T9Word, Abc and 12 3 .

4. Signature (On/ Off/ Edit)

Allows you to make/edit a signature to automatically send with your messages.

5. Speed Messaging (On/ Off)

Allows you to send messages quickly to your Speed Dial contacts. Create a message and enter the text and content. Then, instead of entering a number or contact, press and hold down the Speed Dial number; the message will automatically be sent to that Speed Dial contact.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 42

Messaging

For example:

1. Assign the number 2 as a speed dial for one of your contacts.

2. Compose a new text or picture message. In the destination address window, hold down the number 2 key instead of entering the address, and the message will be automatically sent to that contact.

Text Message

1. Auto View (On/ Off)

When set to On, new messages will automatically display on your screen when they are received.

2. Auto Play (On/ Off)

Allows the display to automatically scroll down while viewing messages.

3. Callback # (On/ Off/ Edit)

With this feature on, you can input the callback number that will be automatically included when you send a message.

Picture Message

1. Auto Receive (On/ Off)

With this set to On, attached content will automatically download when a new picture message is received.

Edit Voicemail #

Allows you to manually enter the access number for Voicemail Service. This feature should only be used when a VMS (Voicemail Service) access number is not provided from the network.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 43

Alltel Shop

9. Delete All

Allows you to erase the messages stored in your Inbox, Sent, or Drafts message folders. You can also erase all messages at the same time.

1. Press , , .

2. Use to highlight an

option: Delete Inbox/ Delete

Sent/ Delete Drafts/ Delete All Messages then press .

3. Use to highlight

Ye s/ No

and press .

Alltel Shop

Alltel Shop allows you to do more than just talk on your phone. Alltel Shop is a technology and service that allows you to download and use applications on your phone. With Alltel Shop, it is quick and easy to personalize your phone to suit your lifestyle and tastes. Just download the applications that appeal to you. With a wide range of software available, from ringtones and wallpapers to games and productivity tools, you can be assured that you will find something useful, practical, or downright entertaining.

Downloading Applications

You can download applications and use Alltel Shop anywhere on the network, as long as your handset has a digital signal available. Most applications do not use a network connection while in use.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 44

Alltel Web

Incoming Calls

While downloading an application, incoming calls will automatically be sent to your voice mail, if available. If you do not have voice mail, downloading will not be interrupted by an incoming call, and the caller will receive a busy signal.

When using applications, an incoming call will automatically pause the application and allow you to answer the call. When you complete your call, you can resume using the application.

1. Launch

Opens the Alltel Shop, where you can access

my apps

download new ones.

1. Press , .

2. After a few seconds, you will see the downloaded applications list.

Alltel Web

The Alltel Web feature allows you to view Internet content. Accessibility and selections within this feature are dependent upon your service provider. For specific information on Alltel Web contact your service provider.

1. Launch

Allows you to initiate an Alltel Web session.

1. Press , .

2. After a few seconds, you will be directed to your home page.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 45

Alltel Web

Ending an Alltel Web Session

End an Alltel Web session by pressing .

Navigating Through the Browser

On-screen items may be presented in one of the following ways:

●

Numbered options

You can use your numeric keypad or you can select the items by moving the cursor and pressing the appropriate Soft Key(s).

●

Links embedded in content

You can select the options or the links by using the Soft Keys at the bottom of the display screen.

Scrolling

Use to scroll through the content if the current page does not fit on one screen. The currently selected item is indicated by a the highlighted text on the screen.

Fast Scrolling

Use the Side Volume Keys to quickly move the cursor up and down on the current screen.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 46

Alltel Web

Entering Text, Numbers, or Symbols

When prompted to enter text, the current text entry method appears above the Right Soft Key . Press the Right Soft Key to select another Text Entry mode:

abc/ ABC/ Sym/ 123/ Emoticons/ word/ WORD

Initiating a Phone Call From Alltel Web

You can make a phone call from Alltel Web if the site you are using supports the feature. Usually, this involves an embedded phone number that can be highlighted and called by pressing the . After you end the call, your phone returns to the screen from which you initiated the call.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 47

Multimedia

View, take, and exchange digital pictures right from your wireless phone.

1. Take Photo

1. Press , , .

2. Set the brightness using , zoom using and press Right Soft Key

Options

to change the following settings:

View Mode Fit to Screen/

Landscape

Resolution 1280X960/

640X 480/ 32 0X 240 / 17 6 X 14 4 / 16 0 X 12 0

Quality Fine/ Normal/

Economy

Zoom Brightness Night Mode On/ Off

Self Timer Off/ 3 Seconds/

5 Seconds/ 10 Seconds

White Balance Auto/ Sunny/

Cloudy/ Tungsten/ Fluorescent

Color Effects Color/ Sepia/

Mono/ Negative

Template On/ Off Shutter Sound None/ Sound

1/ Sound 2/ Sound 3/ Say Cheese

Multishot Off/ 3 shots/ 6 shots AlltelMyPics Remider Enable/

Disable

Auto-Save Enable/ Disable

3. Take a picture by pressing

Ta k e

4. Press Right Soft Key

Delete, Send

or Left Soft Key

Save

. If you choose to Save, you can choose to send the picture to AlltelMyPics.net.

The picture is stored in

Gallery

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 48

Multimedia

2. Record Voice

Allows you to add, listen to, and erase short verbal reminders.

1. Press , , .

2. Press

Record

to record a

new voice memo.

3. Talk into the microphone, then press

Stop

4. Once you've stopped the recording, press Right Soft Key

Options

to access

the following:

Rename/ Delete

Press Left Soft Key to save. The default memo title is the date and time of recording.

3. Images

Allows you to view the saved images on your phone. You can

also select images to customize your phone's Main Screen, Front Screen, or Picture ID.

1. Press , , .

2. Use to highlight

Images

Default

then press

3. Use to highlight an image. Once you have an image highlighted, you can:

●

Press Right Soft Key

Options

to access additional options. Then, use to highlight and select one of the following options:

For images saved in

Images

Set as/ Take Photo/ Delete/ Rename/ Lock/ List View/ Information/ Delete Multiple/ Sort by/

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 49

Multimedia

Send via Bluetooth/ Send to AllteMyPics.net

For images saved in

Default: Set as/ List View/

Information

●

Press

View

to view the

selected image.

●

Press Left Soft Key

Send

to send the selected image to somebody else. (This option is only available in My Images).

4. Audios

Allows you to access saved audio clips on your phone. You can also customize some phone sound settings using these menus.

1. Press , , .

2. Press Left Soft Key

Voice

to record an audio clip.

●

Press Left Soft Key

Audio

to return to the My

Audios list.

3. Press

Record

to begin

recording.

4. While recording, press Left Soft Key

Pause

to pause,

Stop

to stop

recording.

5. When you are finished recording, press Left Soft Key

Save to save the audio

clip,

Send to send the

audio clip to somebody else, or Right Soft Key

Options to

access additional options. Use

to highlight

Rename/

Delete and press .

-Or-

2. Use to highlight My

Audios

/ Default and press .

3. Use to highlight the audio clip.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 50

Multimedia

●

Press Left Soft Key

Send

to send the selected

audio clip to somebody else.

●

Press

Play

to play the

selected audio clip.

●

Press Right Soft Key

Options

to access

additional options. Use

to highlight an option

and press .

Options for audio files in

Audios

Record Voice/ Delete/ Rename/ Lock/ Information / Delete Multiple/ Sort By/ Send Via Bluetooth

Options for audio files in

Default: Set as/ Information

5. Shuffle

Allows you to set your ringtone and wallpaper to shuffle and

change after a selected period of time.

1. Press , , .

2. Use to highlight

Ringtone List/ Wallpaper List

then press .

3. Press Add to begin

adding ringtones or wallpapers to the Shuffle list.

4. Use to highlight the desired ringtones or wallpapers and press to select them.

5. Press Left Soft Key

Done

when you are finished selecting the ringtones or wallpapers you wish to add.

Press Right Soft Key Options and select Settings. From this menu you can configure the Shuffle preferences.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 51

Contacts

The Contacts Menu allows you to store names, phone numbers and other information in your phone’s memory. When you access your Contacts, the number in parentheses represents the number of entries you have stored (up to 1000).

1. New Contact

Allows you to add a new contact to your Contact List.

1. Press , , .

2. Enter the name, then press .

3. Highlight the field you wish to store the contact information in.

4. Enter the phone number or e-mail address.

5. Continue adding the desired contact information to the entry.

6. When you are finished entering the desired contact information, press

Save

to save the entry into your Contact List.

2. Contact List

Allows you to view your Contact List.

1. Press , , .

2. Choose from the following options:

●

Press to scroll through your Contacts alphabetically.

●

Press Right Soft Key

Options

to select

one of the following:

Note

Using this submenu, the number is saved as a new Contact. To save the number into an existing Contact, edit the Contact entry.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 52

Contacts

Send Message/ Delete/ Edit/ Delete Multiple/ Send via Bluetooth/ Set Speed Dial/ Remove Speed Dial

●

Press

View

to view the

contact's information.

●

Press Left Soft Key

New

to create a new

Contact.

3. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, or delete a whole group.

1. Press , , .

2. Choose from the following options:

●

Use to highlight a group, then press

View

to view the contacts in the selected group.

●

Press Left Soft Key

New

to add a new

group.

●

Use to highlight a group, then press Right Soft Key

Options

to choose from the following options:

Delete/ Send Message/ Rename Group/ Set Ringtone/ Delete All

4. Speed Dials

Allows you to view your Speed Dials list, designate new Speed Dials, or remove Speed Dial designations entered in your Contacts.

1. Press , , .

2. Use to highlight the desired Speed Dial location (or enter the Speed Dial digits), and press

Assign

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 53

Recent Calls

3. Use to highlight the Contact.

4. Use to choose a number, then press . A confirmation message is displayed.

5. My Name Card

Allows you to view and add to your personal Contact information that can be sent via Bluetooth

1. Press , , .

2. Use to highlight the feature you wish to edit, and press Left Soft Key

Edit

3. Edit the information as desired and press .

Recent Calls

The Recent Calls menu has lists of phone numbers and/or Contact entries for calls you missed, received or dialed. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

1. Missed Calls

Allows you to view the list of missed calls, up to 40 entries.

1. Press , , .

2. Use to highlight an entry.

Note

You cannot edit the Mobile 1 field, but you can add additional contact info.

To quickly view the list of Recent Calls, press from standby mode.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 54

Recent Calls

2. Received Calls

Allows you to view the list of incoming calls; up to 40 entries.

1. Press , , .

2. Use to highlight an entry.

3. Dialed Calls

Allows you to view the list of outgoing calls; up to 40 entries.

1. Press , , .

2. Use to highlight an entry.

4. All Calls

Allows you to view the list of missed, received and dialed of calls; up to 120 entries.

1. Press , , .

2. Use to highlight an entry.

5. Call Timer

Allows you to view the duration of selected calls.

1. Press , , .

2. Use to highlight a call

type, then press .

Last Call/ Home Calls / Roam Calls / All Calls

6. Data

Allows you to view the list of the most recent data calls.

1. Press , , .

2. Use to highlight a call,

then press

View

to view

the call details.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 55

Bluetooth

7. Data Counter

Allows you to view the amount of Received and Sent data.

1. Press , , .

2. Use to highlight a data call

list, then press .

Received Data/ Sent Data/ All Data

Bluetooth

The AX310 is compatible with devices that support the Bluetooth

headset and handsfree profile(s). You may create and store 20 pairings within the AX310 and connect to one device at a time. The approximate communication range for Bluetooth

wireless technology is up to 30 feet (10 meters).

Bluetooth QD ID B015228

Note

Read user guide of each Bluetooth

accessory that you are trying to pair with your phone because the instructions may be different.

The Bluetooth

features available on this handset may not be compatible with all Bluetooth

enabled devices. Your service provider or handset manufacturer cannot be held responsible for compatibility issues with devices not sold by the service provider or handset manufacturer.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 56

Bluetooth

1. Paired Devices

Pairing is the process that allows the handset to locate, establish and register 1-to-1 connection with the target device.

For pairing new Bluetooth

device

1. Press , , .

2. Follow the Bluetooth

accessory instructions to set the device to pairing mode.

3. Press Left Soft Key Search.

4. If Bluetooth

power is set to

off, you will be prompted to turn power on. Highlight Yes and press .

5. Select

New Search/Last

. The device will appear in the Add New Device menu once it has been located.

Highlight the device and press

Pair

6. If you attempt to pair a device that is part of the handset profile, your device will automatically attempt to pair using a "0000" passcode.

7. The handset will prompt you for your connection preferences. Highlight

Always

Ask

Always Connect

and

press .

Once connected, you will see the device listed in the Paired Devices menu.

2. Power

Allows you to set the Bluetooth

power On/Off.

1. Press , , .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 57

Bluetooth

2. Use to select a setting, then press .

On/ Off

3. My Visibility

Allows you to set the visibility of your

Bluetooth®device.

1. Press , , .

2. Use to select a setting, then press .

Visible/ Hidden

4. My Bluetooth Name

Allows you to edit the name/alias of your Bluetooth

device.

1. Press , , .

2. Hold down to clear the existing name.

3. Use the alphanumeric keypad to enter a new alias.

4. Press

Save

to save and

exit, or Right Soft Key

Cancel

to cancel editing.

5. My Bluetooth Info

Allows you to view information regarding the Bluetooth

functionality.

1. Press , , .

Note

If you turn on My Visibility, your device is able to be discovered by other in-range Bluetooth

devices.

Note

By default, your device’s Bluetooth

functionality is turned off.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 58

Tools

1. Voice Command

Allows you to make phone calls quickly and easily by voice. Your phone recalls the number from your Contacts, displays it briefly, and then dials it. This menu includes useful features for those who may be driving or blind. It delivers time information by voice and allows you to check missed calls, messages and voicemails.

1.1 Start Command

1. Press , , , .

1.1.1 Call <Name> or <Number>

1.Press ,,,,

2. Say the Contact name (and phone type, if applicable) or number.

1.1.2 Voicemail

Press , , , ,

1.1.3 Missed Calls

You can check missed alerts.

Press , ,

2. The handset will prompt you to dial each number. Say

Ye s

or Noto proceed.

1.1.4 Messages

Press , ,

1.1.5 Time & Date

Press , ,

Shortcut

When in standby mode, press to quickly and easily access Voice Command.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 59

Tools

1.1.6 Help

Allows you to check the information of Voice Control.

Press , ,

1.2 Command Mode

Allows you to set command mode to Normal or Speed (The Speed setting allows you to access and use the Voice Command functions more quickly with a faster non-verbal prompt).

1. Press , ,

2. Select options.

Normal/ Speed

1.3 Announce Alert

Allows you to customize Announce Alert. Announce Alert lets your hear more information about an incoming call or message instead of, or along with, your ringtone.

1. Press , ,

2. Select options.

Disable/ Announce/ Announce + Ring

1.4 Train Word

Allows your to train words for improved Voice Command responses.

1. Press , ,

2. Select options.

Voice Command/ Answer/ Digit Dial

1.5 Best Match

Allows you to choose whether the phone displays the 4 closest matches, or only the closest match, when using the Call <Name> function.

1. Press , ,

2. Select options.

1 Match/ 4 Matches

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 60

Tools

2. My Menu

Allows you quick access to your favorite menus or functions. A maximum of 12 items can be stored in My Menu.

1. Press , , .

Select the location for your menu (or function) by using

, then press .

3. Select the menu (or function) you wish to add to My Menu by using , then press

Set.

3. Alarm Clock

Allows you to set up to five alarms. At the alarm time, any set alarm can sound (depending on your Master Volume settings) the tone of your choice, and an alarm message will be displayed on the LCD screen.

1. Press , , .

2. Use to highlight the alarm you wish to set, then press to select it.

3. Press Left Soft Key

Set

set the alarm time.

4. Use to highlight Repeat (recurrence setting).

5. Press to select one of the following.

Once/ Daily/ Mon - Fri

Weekends

6. Use to highlight

Ringtones, press Left Soft Key

Set and select a folder.

My Audios/ Default

7. Use to highlight the ring tone and press the Left Soft Key

Set

, then press

Save

Shortcut

Access the My Menu items directly from the standby screen by pressing .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 61

Tools

4. Calendar

Allows you to store and access your agenda(s). Simply enter your appointments in the Calendar, and your phone will alert you with a reminder.

1. Press , , .

2. Use to highlight the scheduled day.

Moves to the previous day.

Moves to the next day.

Moves to the previous week.

Moves to the next week.

3. Press Left Soft Key

New

4. Use to highlight the field you wish to edit, then press Left Soft Key

Set

to edit

your schedule information:

●

Set Time●Subject

●

Reminder●Repeat

●

Repeat End ●Ringtone

5. Press

Save

5. Ez Tip Calc

Allows you to quickly and easily estimate the tip and total amount of a bill by inputting the bill amount before tip, the tip percentage, and dividing it by the number of people paying.

1. Press , , .

2. Enter values for all variable fields (Bill amount, Tip (%), Split) and the corresponding calculation fields (tip and total for each person) are updated automatically.

3. Press the Left Soft Key

Reset

for another calculation.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 62

Tools

6. Notepad

Allows you to add, read, edit, and erase notes.

1. Press , , .

2. Press Left Soft Key New

to write a new note.

3. Type the note, then press

Save

A confirmation message displays briefly, then displays your list of notes.

Options for a Notepad Entry

1. Access Notepad and highlight the entry.

2. To erase, press Right Soft Key

Options

●

Delete

●

Edit

●

Delete All

7. Calculator

Allows you to perform simple mathematical calculations.

1. Press , , .

2. Enter data.

●

Use keypad to enter numbers.

●

Use to enter decimals.

●

Use to switch the numbers entered to a negative value.

●

Press Left Soft Key Clear to erase the entry.

●

Press Right Soft Key Operator for additional calculating options.

●

Use Navigation Keys to enter functions.

●

Press to complete equation.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 63

Tools

8. World Clock

Allows you to determine the current time in another time zone or city.

1. Press , , .

2. Press Right Soft Key

Cities

to select a specific city and display the date/time in that location.

3. Press to select the highlighted city.

4. Use to scroll through all available cities on the map.

5. Press Left Soft Key

Set

DST

9. Stopwatch

Allows you to use your phone as a stopwatch.

1. Press , , .

2. Press Start to start, and press Stop to stop.

●

You can use the Lap function by pressing Right Soft Key

Lap

to record up to 20 laps and lap times.

3. Press Left Soft Key Reset

to reset.

0. Unit Converter

Allows you to convert units of measurement for Area, Length, Temperature, Mass, Volume and Velocity.

1. Press , , .

2. Select the unit of measurement you want to convert:

Area/ Length/ Temperature/ Mass/ Volume/ Velocity

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 64

Settings

1. Sound

Options to customize your phone's sounds:

1.1 Ringers

Allows you to assign ringtones for incoming calls.

1. Press , , , .

2. Select

All Calls/Caller ID

No Caller ID/ Restricted Calls

Shuffle/ Buy ringtones

3. Select

My Audios

Default

4. Use to highlight the ringtone.

5. Press

Play

to preview the

ringtone, and Left Soft Key

Set

to set as ringtone to

your phone.

1.2 Volume

Allows you to set various volume settings.

1. Press , , , .

2. Select

Master Volume

Keypad/ Earpiece/ Speaker

3. Use to adjust the volume of the ringer, then press to save the setting.

1.3 Message Alerts

Allows you to select the alert tone for new message notifications, and set the frequency of the Message Reminder.

1. Press , , , .

2. Select

Text Message/Picture

Message

Voicemail/All

Messages

Message Reminder.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 65

Settings

3. Use to select a file/ setting, then press .

1.4 Alert Type

Allows you to select the alert types.

1. Press , , , .

2. Use to highlight the alert you wish to edit.

Call Alert/ Message Alerts/ Schedule Alert/ Alarm Alert

3. Use to scroll through the alert types.

Ring Only/ Vibrate Only/ Ring & Vib

4. Press

Save

to save.

1.5 Service Alerts

Allows you to set the Service Alert preferences.

1. Press , , , .

2. Select an alert option.

3. Use to set

On/ Off

, then press . (for Low Battery option,

Announce/ Tone

)

1.5.1 Minute Beep

Alerts you 10 seconds before the end of every minute during a call.

1.5.2 Call Connect

Alerts you when the call is connected.

1.5.3 Back to Top

Alerts you when you scroll through the end of a menu list.

1.5.4 Low Battery

Alerts you when the battery charge level is low.

1.6 Power On/Off Tone

Allows you to set the phone to sound a tone when the phone is powered on and off.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 66

Settings

1. Press , , , .

2. Use to set to

On/ Off

then press .

1.7 Flip Tone

Allows you to set a flip tone that will play when you flip your phone open or closed.

1. Press , , , .

2. Use to set to

On/ Off

then press .

2. Display

Options to customize your phone's display screen.

2.1 Wallpaper

Allows you to choose the kind of background to be displayed on the phone.

1. Press , , , .

2. Select

Main Screen/Front

Screen

Shuffle/ Buy

Wallpaper,

then press .

2.1.1 Main Screen

Highlight an image from

Images

Default

, and press

View

to view the image, and Left

Soft Key

Set

to set it as the

wallpaper.

2.1.2 Front Screen

Highlight an image from

Images

Default

, and press

View

to view the image, and Left

Soft Key

Set

to set it as the

wallpaper.

2.1.3 Shuffle

Set Shuffle to Onor

Off

for the

Main Screen

Front Screen

and set the

Repeat

frequency.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 67

Settings

2.1.4 Buy Wallpaper

Allows you to buy wallpaper through Alltel application. Airtime charges may apply.

2.2 Banner

Allows you to enter a string of characters which display on the LCD screen.

1. Press , , , .

2. Use to scroll between

On/ Off

3. Use to highlight the text window.

4. Input text and press Left Soft Key

Abc

to change text

options,

Save

to save, or

Right Soft Key

Cancel

cancel editing your banner.

2.3 Backlight

Allows you to set the duration for illuminating the backlight.

1. Press , , , .

2. Choose a submenu, then press .

Display/ Keypad

3. Use to select a setting, then press .

2.4 Menu Style

Allows you to view the Menu as an Icon or List display.

1. Press , , , .

Select Icon or List and press

2.5 Languages

Allows you to use the bilingual feature according to your preference. Choose between English and Spanish.

1. Press , , , .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 68

Settings

2. Use to select

English

Spanish

, then press .

2.6 Clocks & Calendar

Allows you to select the type of clocks displayed on the main LCD or the external LCD.

1. Press , , , .

2. Choose a sub-menu and press .

Main Screen/Front Screen

3. Use to highlight an

option and press .

2.7 Font Settings

Allows you to select the type of font displayed on the phone text and dialpad.

1. Press , , , .

2. Choose a sub-menu and press

Font Type/ Dial Font Style/ Dial Font Size

3. Use to highlight an option, then press .

Options for Font Type

LG Gothic/ LG Secret/ LG Mint

Options for Dial Font Style

Magic/ Digital/ Basic

Options for Dial Font Size

Normal/Large

2.8 Phone Dial Search

When in standby mode, this function compares entered letters on the keypad against the entries in your Contacts. A matching list is displayed in descending order. You can then select a Contact Entry from the list to call or view.

1. Press , , , .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 69

Settings

2. Use to select a setting,

then press .

On/ Off

3. Security

The Security menu allows you to secure the phone electronically.

3.1 Lock Phone

Keeps your phone from unauthorized use. Once the phone is locked, it is in restricted mode until the lock code is entered. You can still receive phone calls and make emergency calls. You can modify the lock code by setting a New Lock code within the Security menu.

1. Press , , .

2. Enter the four-digit lock code and press .

The default lock code is commonly the last 4 digits of

your phone number.

3. Press

Lock Phone

4. Use to select an option,

then press .

Unlock

The phone remains unlocked by default, until it is locked manually.

Lock

The phone remains locked. When locked, you can receive incoming calls and make only emergency calls.

On Power Up

The phone is

locked when it is turned on.

3.2 Restrictions

Allows you to restrict Calls, Messaging, Camera or Data.

Note

You can receive the incoming calls from saved contacts on your phone, when Incoming Only is on.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 70

Settings

1. Press , , .

2. Enter the four-digit lock code and press .

3. Press

Restrictions.

4. Enter the four-digit lock code and press .

5. Use to select

Calls/

Messaging/ Camera/ Data

then press .

3.3 Emergency #s

Allows you to enter 3 emergency numbers. You can call these emergency numbers and 911, even when the phone is locked or restricted.

1. Press , , .

2. Enter the four-digit lock code and press .

3. Press

Emergency #s

4. Press to edit the emergency numbers.

5. When you are finished editing the number, press

Save

to save, or Right Soft Key

Cancel

to cancel editing.

3.4 Change Lock Code

Allows you to enter a new fourdigit lock code.

1. Press , , .

2. Enter the four-digit lock code and press .

3. Press

Change Lock

Code

4. Use to select an option, then press . Phone Only Allows you to change the lock code used to lock/unlock the phone. Call & Applications Allows

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 71

Settings

you to change the lock code that is used to access the Restrictions menu (Calls, Messaging, Camera and Data).

5. Enter a new 4-digit lock code and press .

6. For confirmation, it will ask you to enter the new lock code again.

3.5 Reset Default

Allows you to reset your phone to the factory default settings.

1. Press , , .

2. Enter the four-digit lock code and press .

3. Press

Reset Default

A message will pop up that says "Preference settings will be set to factory defaults. Press <OK> to continue." Press .

5. Use to highlight an

option and press .

Revert/

Cancel

4. Call Settings

The Call Settings menu allows you to designate how the phone handles both incoming and outgoing calls.

4.1 Answer Options

Allows you to determine how to answer an incoming call.

1. Press , , , .

2. Use to select a setting, then press .

Flip Open/Any Key/SEND Key Only

Auto Answer

4.2 Auto Retry

Allows you to set the length of time the phone waits before automatically redialing a number when the attempted call fails.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 72

Settings

1. Press , , , .

2. Use to select a setting, then press .

Off/ Every 10 Seconds

Every 30 Seconds/ Every 60 Seconds

4.3 One-Touch Dial

Allows you to initiate a speed dial call by pressing and holding the speed dial digit. If set to Off, Speed Dial numbers designated in your Contacts will not function.

1. Press , , , .

2. Use to select a setting, then press .

On/ Off

4.4 Voice Privacy

Allows you to set the voice privacy feature for CDMA calls as Enhanced or Standard. CDMA offers inherent voice privacy. Check with your service provider for availability.

1. Press , , , .

2. Use to select a setting, then press .

On/ Off

4.5 Voice Clarity

When this feature is enabled, it provides a better audio experience by controlling the dynamic range and volume of the sending and receiving voices across different environments and conditions.

1. Press , , , .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 73

Settings

2. Use to select a setting, then press .

On/ Off

4.6 Airplane Mode

Only allows you to use features on your phone that do not require wireless communications.

1. Press , , , .

2. Read the displayed message and press to continue.

3. Use to select a setting, then press .

On/ Off

4.7 TTY Mode

Allows you to attach a TTY (Teletype writer) device, enabling you to communicate with parties also using a TTY device. A phone with TTY support is able to translate typed characters to

voice. Voice can also be translated into characters and then displayed on the TTY.

1. Press , , , .

2. Read the displayed message and press to continue.

3. Use to select a setting, then press .

TTY Full/TTY + Talk/ TTY + Hear

TTY Off

5. PC Connection

Allows you to set the preferred connection type between your handset and your PC (when connected via a USB cable).

1. Press , , .

2. Use to select a setting, then press .

USB Modem/ Bluetooth/ Closed

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 74

Settings

6. Alltel Shop & Web

Allows you to set a settings and options related to the Alltel Shop & Web application.

1. Press , , .

6.1 Alltel Info

Allows you to decide whether or not your phone displays the Airtime Charges Warning message when you start Alltel Shop.

1. Press , , , .

2. Press

Ye s

or No.

6.2 Web Settings

Allows you to customize some of the browser notification settings.

1. Press , , , .

2. Select

Prompt

Alert Beep

•

Prompt

: At Start/ At End/

Both/ None

•

Alert Beep

: Mute/ 2 Beeps/

4 Beeps

7. S ys te m

The System menu allows you to designate specific system network settings.

7.1 Network

7.1.1 System Select

Allows you to set up the phone producer’s management environment. Leave this setting as the default unless you want to alter system selection as instructed by your service provider.

1. Press , , , , .

2. Use to highlight

Home Only/ Automatic A/ Automatic B

then press .

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 75

Settings

7.1.2 Set NAM

Allows you to select the phone’s NAM (Number Assignment Module) if the phone is registered with multiple service providers.

1. Press , , , , .

2. Use to highlight

NAM1

NAM2

, then press .

7.1.3 Auto NAM

Allows the phone to automatically switch between programmed telephone numbers corresponding to the service provider area.

1. Press , , , , .

2. Use to highlight

Off

, then press .

7.1.4 Serving System

Identifies the channel number of a system that is served as a SID Number. This information should only be used for technical support.

1. Press , , , , .

7.2 Location

Allows you to turn On or Off the Location function on your phone. If set to On, locationbased services are able to access your GPS (Global Positioning System) satellite-assisted location information.

1. Press , , , .

2. Use to highlight

setting,

then press .

Location On/ E911 Only

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 76

Settings

8. Memory

Allows you to check out the memory status of your phone.

1. Press , , .

2. Use to highlight

Reserved Memory/ Multimedia

, and press .

9. Phone Info

The Phone Info menu provides you with specific information pertaining to your handset.

1. Press , , .

2. Use to highlight an option and press , or press the corresponding number key.

My Number/ESN/MEID/ Icon Glossary/ Version

Note

GPS satellite signals are not always transmitted, especially under bad atmospheric and environmental conditions, indoors etc.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 77

RealTone JukeBox/ Alltel Navigation/ Wallpaper Universe

RealTone JukeBox

Allows you to download real music ringtones from your favorite artists.

1. Press , .

2. Access application and download ringtones.

Alltel Navigation

Alltel Navigation is an application downloadable from the Alltel Navigation menu. Now you can find the address of a great restaurant or the nearest ATM. Check movie times. Discover the latest hot spots. And know exactly how to get where you're going. Alltel Navigation puts all the advanced features of the latest GPS devices and system on your wireless device at a fraction of the price.

1. Press , .

2. Register your name, email and press to submit.

Wallpaper Universe

Allows you to access application and download wallpapers.

1. Press , .

2. Access application and download wallpapers.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 78

Safety

TIA Safety Information

The following is the complete TIA Safety Information for wireless handheld phones.

Exposure to Radio Frequency Signal

Your wireless handheld portable phone is a low power radio transmitter and receiver. When ON, it receives and sends out Radio Frequency (RF) signals.

In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:

ANSI C95.1 (1992) *

NCRP Report 86 (1986)

ICNIRP (1996)

* American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection.

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 79

Safety

could damage the phone and may violate FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.

Tips on Efficient Operation

For your phone to operate most efficiently:

Don’t touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in

the areas where you drive and always obey them. Also, if using your phone while driving, please observe the following:

●

Give full attention to driving -driving safely is your first responsibility;

●

Use hands-free operation, if available;

●

Pull off the road and park before making or answering a call if driving conditions or the law require it.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 80

Safety

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six (6) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Persons with pacemakers:

●

Should ALWAYS keep the phone more than six (6) inches from their pacemaker when the phone is turned ON;

●

Should not carry the phone in a breast pocket;

●

Should use the ear opposite the pacemaker to minimize the potential for interference;

●

Should turn the phone OFF immediately if there is any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 81

Safety

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 82

Safety

Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations); below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If

in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Safety Information

Please read and observe the following information for safe and proper use of your phone and to prevent damage. Also, keep the user guide in an accessible place at all times after reading it.

CCaa uuttii oonn!!

Violation of the instructions may cause minor or serious damage to the product.

●

Do not disassemble or open crush, bend or deform, puncture or shred.

●

Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 83

Safety

to fire, explosion or other hazard.

●

Only use the battery for the system for which it is specified.

●

Only use the battery with a charging system that has been qualified with the system per IEEE-Std-1725-2006. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

●

Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.

●

Replace the battery only with another battery that has been qualified with the system per this standard, IEEE-Std-1725-

2006. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

●

Promptly dispose of used batteries in accordance with local regulations.

●

Battery usage by children should be supervised.

●

Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

●

Improper battery use may result in a fire, explosion or other hazard.

●

The phone shall only be connected to USB products that bear the USB-IF logo or have completed the USB-IF compliance program.

Charger and Adapter Safety

●

The charger and adapter are intended for indoor use only.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 84

Safety

●

Insert the battery pack charger vertically into the wall power socket.

●

Use the correct adapter for your phone when using the battery pack charger abroad.

●

Only use the approved battery charger. Otherwise, you may cause serious damage to your phone.

Battery Information and Care

●

Please dispose of your battery properly or take it to your local wireless carrier for recycling.

●

The battery doesn't need to be empty before recharging.

●

Use only LG-approved chargers specific to your phone model since they are designed to maximize battery life.

●

Do not disassemble or shortcircuit the battery.

●

Keep the battery’s metal contacts clean.

●

Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.

●

Recharge the battery after long periods of non-use to maximize battery life.

●

Battery life will vary due to usage patterns and environmental conditions.

●

Use of extended backlighting, Browser, and data connectivity kits affect battery life and talk/standby times.

●

The self-protection function of the battery cuts the power of the phone when its operation is in an abnormal state. In this case, remove the battery from the phone, reinstall it, and turn the phone on.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 85

Safety

Explosion, Shock, and Fire Hazards

●

Do not put your phone in a place subject to excessive dust and keep the minimum required distance between the power cord and heat sources.

●

Unplug the power cord prior to cleaning your phone, and clean the power plug pin when it’s dirty.

●

When using the power plug, ensure that it’s firmly connected. If not, it may cause excessive heat or fire.

●

If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

●

Don’t short-circuit the battery. Metallic articles such as a coin, paperclip or pen in your pocket or bag may shortcircuit the + and – terminals of the battery (metal strips on the battery) upon moving. Short-circuit of the terminal may damage the battery and cause an explosion.

●

Do not disassemble or crush the battery. It may cause a fire.

General Notice

●

Using a damaged battery or placing a battery in your mouth may cause serious injury.

●

Do not place items containing magnetic components such as a credit card, phone card, bank book, or subway ticket near your phone. The magnetism of the phone may damage the data stored in the magnetic strip.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 86

Safety

●

Talking on your phone for a long period of time may reduce call quality due to heat generated during use.

●

When the phone is not used for a long period time, store it in a safe place with the power cord unplugged.

●

Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference to the phone.

●

Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna.

●

Do not immerse your phone in water. If this happens, turn it off immediately and remove the battery. If the phone does not work, take it to an LG Authorized Service Center.

●

Do not paint your phone.

●

The data saved in your phone might be deleted due to careless use, repair of the phone, or upgrade of the software. Please backup your important phone numbers. (Ring tones, text messages, voice messages, pictures, and videos could also be deleted.) The manufacturer is not liable for damage due to the loss of data.

●

When you use the phone in public places, set the ringtone to vibration so you don't disturb others.

●

Do not turn your phone on or off when putting it to your ear.

●

Use accessories, such as earphones and headsets, with caution. Ensure that cables are tucked away safely and do not touch the antenna unnecessarily.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 87

Safety

Warning! Important safety information

Avoiding hearing damage

Permanent hearing loss may occur if you use your phone and/or headset at a high volume. Set the volume to a safe level. You can adapt over time to a higher volume of sound that may sound normal but can be damaging to your hearing. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked. The louder the volume, the less time is required before your hearing could be affected. Hearing experts suggest that to protect your hearing:

●

Limit the amount of time you use your phone and/or headset at high volume.

●

Avoid turning up the volume to block out noisy surroundings.

●

Turn the volume down if you can’t hear people speaking near you.

For information about how to set a maximum volume limit on your phone, see the features guide for your phone.

Using your phone safely

Use of your phone while operating a vehicle is not recommended and is illegal in some areas. Be careful and attentive while driving. Stop using your phone if you find it disruptive or distracting while operating any type of vehicle or performing any other activity that requires your full attention.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 88

Safety

Avoiding hearing damage

Permanent hearing loss may occur if you use your headset at a high volume. Set the volume to a safe level. You can adapt over time to a higher volume of sound that may sound normal but can be damaging to your hearing. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked. The louder the volume, the less time is required before your hearing could be affected. Hearing experts suggest that to protect your hearing:

●

Limit the amount of time you use headset at high volume.

●

Avoid turning up the volume to block out noisy surroundings.

●

Turn the volume down if you can’t hear people speaking near you.

For information about how to set a maximum volume limit on your handset, please refer to the features guide for your handset.

Using headsets safely

Use of headsets to listen to music while operating a vehicle is not recommended and is illegal in some areas. Be careful and attentive while driving. Stop using this device if you find it disruptive or distracting while operating any type of vehicle or performing any other activity that requires your full attention.

FDA Consumer Update

The U.S. Food and Drug Administration’s Center for Devices and Radiological Health Consumer Update on Mobile Phones:

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 89

Safety

1. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of Radio Frequency (RF) energy in the microwave range while being used. They also emit very low levels of RF when in standby mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some

cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

2. What is the FDA's role concerning the safety of wireless phones?

Under the law, the FDA does not review the safety of radiationemitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit Radio Frequency (RF) energy at a level that is hazardous to the user. In such a case, the FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace, or recall the phones so that the hazard no longer exists.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 90

Safety

Although the existing scientific data do not justify FDA regulatory actions, the FDA has urged the wireless phone industry to take a number of steps, including the following:

●

Support needed research into possible biological effects of RF of the type emitted by wireless phones;

●

Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and

●

Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health.

The FDA belongs to an interagency working group of the federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:

●

National Institute for Occupational Safety and Health

●

Environmental Protection Agency

●

Occupational Safety and Health Administration

●

National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working group activities, as well.

The FDA shares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 91

Safety

with FCC safety guidelines that limit RF exposure. The FCC relies on the FDA and other health agencies for safety questions about wireless phones.

The FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.

3. What kinds of phones are the subject of this update?

The term “wireless phone” refers here to handheld wireless phones with built-in antennas, often called “cell”, “mobile”, or “PCS”

phones. These types of wireless phones can expose the user to measurable Radio Frequency (RF) energy because of the short distance between the phone and the user’s head.

These RF exposures are limited by FCC safety guidelines that were developed with the advice of the FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person's RF exposure decreases rapidly with increasing distance from the source. The so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures far below the FCC safety limits.

4. What are the results of the

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 92

Safety

research done already?

The research done thus far has produced conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of Radio Frequency (RF) energy exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer-causing chemicals so as to be predisposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours

per day. These conditions are not similar to the conditions under which people use wireless phones, so we do not know with certainty what the results of such studies mean for human health. Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any possible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about longterm exposures, since the average period of phone use in these studies was around three years.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 93

Safety

5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?

A combination of laboratory studies and epidemiological studies of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However, very large numbers of animals would be needed to provide reliable proof of a cancer promoting effect if one exists. Epidemiological studies can provide data that is directly applicable to human populations, but ten or more years follow-up may be needed to provide answers about some health effects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop — if they

do — may be many, many years. The interpretation of epidemiological studies is hampered by difficulties in measuring actual RF exposure during day-to-day use of wireless phones. Many factors affect this measurement, such as the angle at which the phone is held, or which model of phone is used.

6. What is the FDA doing to find out more about the possible health effects of wireless phone RF?

The FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to Radio Frequency (RF) energy.

The FDA has been a leading participant in the World Health

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 94

Safety

Organization International Electro Magnetic Fields (EMF) Project since its inception in

1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The project has also helped develop a series of public information documents on EMF issues.

The FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research And Development Agreement (CRADA) to do research on wireless phone safety. The FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIAfunded research is conducted through contracts with

independent investigators. The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.

7. How can I find out how much Radio Frequency energy exposure I can get by using my wireless phone?

All phones sold in the United States must comply with Federal Communications Commission (FCC) guidelines that limit Radio Frequency (RF) energy exposures. The FCC established these guidelines in consultation with the FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless phones is set at a Specific Absorption Rate (SAR)

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 95

Safety

of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have effects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website (

http://www.fcc.gov/oet/rfsafety)

gives directions for locating the FCC identification number on your phone so you can find your phone’s RF exposure level in the online listing.

8. What has the FDA done to measure the Radio Frequency energy coming from wireless phones?

The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical standard for measuring the Radio Frequency (RF) energy exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers. The standard, “Recommended Practice for Determining the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques”, sets forth the first consistent test methodology for measuring the rate at which RF is deposited in the heads of wireless phone users. The test method uses a tissue-simulating model of the human head.

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 96

Safety

Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.

9. What steps can I take to reduce my exposure to Radio Frequency energy from my wireless phone?

If there is a risk from these products — and at this point we do not know that there is — it is probably very small. But if you are concerned about avoiding even potential risks, you can take

a few simple steps to minimize your exposure to Radio Frequency (RF) energy. Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure. If you must conduct extended conversations by wireless phone every day, you could place more distance between your body and the source of the RF, since the exposure level drops off dramatically with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientific data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 97

Safety

described above to reduce your RF exposure from wireless phone use.

10. What about children using wireless phones?

The scientific evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to Radio Frequency (RF) energy, the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and increasing the distance between the user and the RF source will reduce RF exposure.

Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United

Kingdom distributed leaflets containing such a recommendation in December

2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.

11. What about wireless phone interference with medical equipment?

Radio Frequency (RF) energy from wireless phones can interact with some electronic devices. For this reason, the FDA helped develop a detailed test method to measure Electro Magnetic Interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless telephones. This test method is

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 98

Safety

now part of a standard sponsored by the Association for the Advancement of Medical Instrumentation (AAMI). The final draft, a joint effort by the FDA, medical device manufacturers, and many other groups, was completed in late

2000. This standard will allow manufacturers to ensure that cardiac pacemakers and defibrillators are safe from wireless phone EMI.

The FDA has tested hearing aids for interference from handheld wireless phones and helped develop a voluntary standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test methods and performance requirements for hearing aids and wireless phones so that no interference occurs when a person uses a

“compatible” phone and a “compatible” hearing aid at the same time. This standard was approved by the IEEE in 2000.

The FDA continues to monitor the use of wireless phones for possible interactions with other medical devices. Should harmful interference be found to occur, the FDA will conduct testing to assess the interference and work to resolve the problem.

12. Where can I find additional information?

For additional information, please refer to the following resources:

FDA web page on wireless phones (http://www.fda.gov/cellphones/)

Federal Communications Commission (FCC) RF Safety Program (http://www.fcc.gov/oet/rfsafety)

International Commission on

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 99

Safety

100

Safety

Non-lonizing Radiation Protection (http://www.icnirp.de)

World Health Organization (WHO) International EMF Project (http://www.who.int/emf)

National Radiological Protection Board (UK) (http://www.hpa.org.uk/radiation/)

10 Driver Safety Tips

Your wireless phone gives you the powerful ability to communicate by voice almost anywhere, anytime. An important responsibility accompanies the benefits of wireless phones, one that every user must uphold.

When operating a car, driving is your first responsibility. When using your wireless phone behind the wheel of a car, practice good common sense and remember the following tips:

1. Get to know your wireless phone and its features such as speed dial and redial. Carefully read your instruction manual and learn to take advantage of valuable features most phones offer, including automatic redial and memory. Also, work to memorize the phone keypad so you can use the speed dial function without taking your attention off the road.

2. When available, use a handsfree device. A number of hands-free wireless phone accessories are readily available today. Whether you choose an installed mounted device for your wireless phone or a speaker phone accessory, take advantage of these devices if available to you.

3. Make sure you place your wireless phone within easy

AX310_Eng_0817.qxd 8/17/09 4:18 PM Page 100

LG LGAX310 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
