LG L05A Users manual

Part 15.21 statement

"Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1)This device & its accessories may not cause harmful interference.

(2)This device & its accessories must accept any interference received, including interference that may cause undesired operation.

Body-worn Operation

This Mobile Broadband USB Modem, model L-05A, is approved for use in normal size laptop computers only (typically with 12" or larger display screens). To comply with FCC RF exposure requirements, this modem should not be used in configurations that cannot maintain at least

5mm (approximately 0.2 inches) from users and bystanders, and 12mm (approximately 0.47 inches) from the top of the USB modem.

This USB modem has been tested for compliance with FCC/IC RF exposure limits

in the laptop computer(s) configurations with horizontal and vertical USB slots and can be used in laptop computers with substantially similar physical dimensions, construction, and electrical and RF characteristics.

This USB modem must not be used with any other antenna or transmitter that has not been approved to operate in conjunction with this modem.

DOCOMO W-CDMA GSM/GPRS

System

Thank You for Purchasing the Data Commu- nication Device L-05A

Before or while using the L-05A, be sure to thoroughly read this manual and the individual manual for other operation devices to ensure its correct use. For further information, contact the "docomo Information Center" on the back of this manual. The L-05A is designed to be your close partner. Treat it carefully at all times to ensure longterm performance.

Before Using the FOMA Terminal

•Because the FOMA terminal uses radio waves, it may not function in locations where it is difficult for radio waves to penetrate, such as tunnels, underground passages and some buildings in areas where radio wave signals are weak or out of the service area. Even when you are on a higher floor of a tall building or condominium and nothing blocks your view outside, the FOMA terminal may not be able to receive or transmit signals. Also communication may be interrupted even when the Antenna Indication Lamp on the FOMA terminal lights green indicating a strong signal reception with 3 antenna indication bar.

•Use the FOMA terminal in ways that do not disturb others in public places, crowded locations, or quiet locations.

•The FOMA terminal communicates via radio waves by converting voices into digital signals. If you move into an area where signal reception is poor, the digital signals may not be accurately decoded and what you hear may differ slightly from what was actually said.

•DOCOMO is not responsible for any economic losses incurred through lost communication opportunities caused by external factors such as malfunction or failure of the FOMA terminal, or electrical outage.

•The FOMA terminal can be operated in FOMA Plus-Areas and FOMA HIGH-SPEED Areas.

•The FOMA terminal can be used only via the FOMA network provided by DOCOMO and DOCOMO's roaming area.

•This FOMA terminal does not support i-mode functions (i-mode mail, connection to official i-mode sites or i-αppli, etc.)

For Those Who Use the FOMA Terminal for the First Time

If this is the first time for you to use the FOMA terminal, it is recommended that you read this manual in the following order to learn basic operations.

1.Learning the precautions. . . . . . . . . . . . . . . . . . . . . . . P7

2.Learning the names of parts and functions of the FOMA terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P18

3.Inserting the FOMA terminal into a PC . . . . . . . . . . P24

4.Having the FOMA terminal recognized by your PC. . .P24

5.Setting up the FOMA terminal for communication. . . .P66

The latest version of this manual can be downloaded from the DOCOMO web site.

■The URL of PDF for Instruction Manual http://www.nttdocomo.co.jp/english/support/manual/ index.html

The URL and the information contained in the manual are subject to change without prior notice.

How to Read/Refer to This Manual

Contents

L-05A Manual is composed of L-05A Instruction Manual Connection Guide and L-05A INSTRUCTION MANUAL (included CD-ROM) (this manual) recorded in CD-ROM.

■ L-05A Instruction Manual Connection Guide

The following contents such as connection to computer, troubleshooting methods, specifications of L-05A are written.

•Contents/Precautions

•Before Using the FOMA Terminal

•Setting up

•Appendix/Troubleshooting

■ L-05A INSTRUCTION MANUAL (included CD-ROM) this manual

Besides the above contents described in L-05A Instruction Manual Connection Guide , the contents of configuring communication through special application are also written.

This manual is supplied with PDF. To view this manual, Adobe Reader (Version6.0 or later is recommended) is necessary.

•L-05A Connection Software

•DOCOMO Connection Manager

•Configuring Network Manually

•Overseas Use

How to Refer to This Manual

This manual offers you the following methods to easily find a page describing functions or services you want to know about.

From the Index		P141

Search from the index when you know the names of functions or services.

From the Tabs on the Cover		Front
		cover

Search functions or services from the index tabs printed on the front cover.

See next page for detailed descriptions

From the Contents		P5

Search from the contents that categorize functions.

From the Main Features		P6

Search from the features when you want to use specific functions.

Please understand that L-05A Manual refers to the L-05A as the FOMA Terminal .

This manual describes, some steps and screens may differ depending on your operating environment.

Reprinting all or parts of this manual is prohibited.

Information contained in this manual is subject to change without prior notice.

A way to find a destination page is explained with an example of installing L-05A connection software on Windows (including a driver).

From the Index

P141

Search or a function name or a service name as shown below.

From the

Index Tabs on the Front Cover

Front cover

Search for the function in the order of "Front cover"→ "Chapter title page"→ "Target page" as shown below.

P35

The page describing installation of L-05A connection software on Windows (including a driver)"

Displays a section title.

Useful Information or suggestions relating to an operation.

The above page is an example.

Screen images and illustrations contained in this manual are for reference only. They may differ from those seen for the actual product.

Explains Operation steps

A key screen for an operation step. This is an image of a screen seen on the PC. Numbers, settings or characters entered are for reference only.

Index: Searching each

chapter is available.

Contents

How to Read/Refer to This Manual 1 Contents 5 Features of the L-05A 6

Safety Precautions (ALWAYS FOLLOW THESE

PRECAUTIONS) 7

Handling and Care 12

Purchased Product and Accessories 15

	Before Using	Names of Parts and Functions
	the FOMA	Using FOMA Card
	the FOMA	Available Communications
	Terminal	Available Communications
	Terminal	Connecting FOMA Terminal with a PC
	17
	Setting Up	Setting Up
	31	Windows version
	31	Macintosh version
	L-05A	L-05A Connection Software
	Connection	Using Packet Communication
	Software	Using SMS
	Software	Using Phonebook
	49	Using Application Option
	DOCOMO	DOCOMO Connection Manager
	Connection	Windows version
	Manager	Macintosh version
	Manager
	77

	Configuring	Configuring Dial-up Network Manually
	Network	Conducting Communication
	Network	(Connecting Dial-up)
	Manually	(Connecting Dial-up)
	Manually
	89
		International Roaming Service
	Overseas	(WORLD WING)
	Overseas	Services Available Overseas
	Use	Confirming before Using Overseas
	111	Setting the Searching Method for
		Available Networks
		Configuring Network
		AT Commands
		AT Command List
	Appendix/	Troubleshooting
	Appendix/	Error Messages
	Trouble-	Warranty and After-Sales Service
	Trouble-	Software update
	shooting	Software update
	shooting	Main Specifications
	119	Export Controls of the Product and
		Accessories
		Intellectual Property Rights
		Index

Contents/Precautions 5

Features of the L-05A

FOMA (Freedom Of Mobile multimedia Access) is the name of a service provided by DOCOMO based on the W-CDMA system, which is certified as one of the global standards of 3rd generation mobile communication systems (IMT-2000).

■Correspondence with the FOMA HIGH-SPEED Area

You can enjoy high speed communication (Best effort system at a maximum of 7.2Mbps for receiving and 5.7Mbps for sending.

•The maximum speed of 7.2Mbps for receiving and 5.7Mbps for sending are theoretical values and they do not show the actual performance.

•Out of High-Speed area, the maximum communication speed for receiving and sending is 384kbps.

•The actual communication speed varies depending on surrounding communication conditions and network condition.

•DOCOMO offers Internet connection services, such as

mopera U . For details, visit the mopera U web site http://www.mopera.net/ (Japanese only)

The packet communication in FOMA HIGHSPEED area, the amount of send/receive data is expected to increase. Note that the communication fees may become high.

■International Roaming Service

Communications are available from a PC even in foreign countries that have adapted the W-CDMA (3G) network system or GPRS network. P112

If you subscribed to the FOMA service after September 1, 2005, a separate subscription is not required. However, if you unsubscribed to the FOMA service subscription or canceled the service, a separate subscription is required.

If you initially subscribed to the FOMA service before August 31, 2005, and have not subscribed to "WORLD WING", a separate subscription is required.

This service is not available with some billing plans.

■FOMA Card Interchangeability

The same FOMA card can be used in more than one FOMA terminal. P19

■SMS Feature

Allows you to send and receive SMS by using L-05A

Connection Software P54

6 Contents/Precautions

Safety Precautions (ALWAYS

FOLLOW THESE PRECAUTIONS)

■Before using your FOMA terminal, read these ″Safety Precautions″carefully so that you can use it properly. After reading the safety precautions, keep this manual in a safe place for later reference.

■These precautions are intended to protect you and others around you. Read and follow them carefully to avoid injury, damage to the product or damage to property.

■The signs below indicate the levels of danger or damage that may occur if the particular precautions are not observed .

This sign indicates that

incorrect handling has a DANGER high possibility of

causing death or serious injury.

This sign indicates that

WARNING incorrect handling poses a risk of causing death or

serious injury.

This sign indicates that

incorrect handling poses CAUTION a risk of causing injury or

damage to the product or property.

■The following symbols indicate special warnings regarding product usage.

Denotes things not to do (prohibition).

Denotes not to disassemble.

Notdisassembly

Denotes not to use where it could get

wet.

Not liquids

Denotes mandatory instructions (matters that must be complied with).

■"Safety Precautions" are explained in the following 4 sections.

General Precautions for the FOMA Terminal and FOMA Card ………………………………………………………………… 8 Precautions for the FOMA Terminal ……………………… 9 Precautions for the FOMA Card ………………………… 10 Notes on Using near Electronic Medical Equipment …… 11

Contents/Precautions 7

General Precautions for the FOMA

Terminal and FOMA Card

Do not use or leave the FOMA terminal and FOMA card in places with a high temperature such as in cars under the blazing sun.

Deformation, malfunction heating or the deterioration of performance may result. Also, part of the case could get heated, causing bare skin burns.

Do not disassemble Disassemble, remodel or solder the terminal and FOMA

card.

Notdisassembly

Fire, injury, electric shock or malfunction may result.

Do not let FOMA terminal and FOMA card get wet.

Not liquids

Contact with water or other liquids may cause heating, electric shock, fire, malfunction or injury. Take care not to use the terminal and FOMA card in areas where they could get wet.

8 Contents/Precautions

WARNING

Do not put the FOMA terminal or FOMA card in microwave ovens or other heating.

The FOMA terminal may over heat, smoke or catch fire, or its circuit parts may burst.

Do not throw the FOMA terminal or FOMA card, or subject them to severe shocks.

Malfunction or fire may result.

Be careful not to let electro conductive materials (metal pieces, pencil leads etc.) contact with the connector terminal. Also, make sure that these are not entered into the inside of the FOMA terminal.

Fire or other malfunctions may result from a short circuit.

Make sure you have the power of the computer which is connected with FOMA terminal switched off before you go near a flammable gas such as gasoline fumes.

Using the terminal in such an environment may result in a fire.

CAUTION

Do not place the FOMA terminal or FOMA card on unstable locations such as wobbly tables or slanted locations.

The FOMA terminal or FOMA card may fall, resulting in injury or malfunction.

Do not store the FOMA terminal or FOMA card in humid or dusty places, or in hot areas.

Malfunction may result.

If children use the FOMA terminal or FOMA card, a guardian should explain the precautions and correct operations. The guardian should also make sure that the instructions are followed during use.

Injury may result.

Keep out of reach of babies and infants.

Accidental swallowing or injury may result.

Precautions for the FOMA Terminal

WARNING

Do not put the FOMA terminal in the place where it could be affected by an expanded airbag, e.g. on the dashboard.

If the airbag expands, the FOMA terminal could hit you and others, causing accidents such as injury and the FOMA terminal could get malfunction or damaged.

Do not place the terminal in breast or inner pocket when electronic medical equipment is near by.

Using FOMA terminal closed to electronic medical equipment may result malfunction.

Do not allow liquids such as water, or foreign materials such as metal pieces or flammable materials to get into the FOMA card opening in the FOMA terminal.

Fire, electronic shock or malfunction may result.

Contents/Precautions 9

Turn off the FOMA terminal in places where use is prohibited such as airplanes or hospitals.

Electronic and electronic medical appliances may be adversely affected. For use inside medical facilities, make sure that you comply with their regulations.

Remove FOMA terminal from the USB port in places near high-precision electronic devices or devices using weak electronic signals.

The FOMA terminal may possibly cause these devices to malfunction.

Electronic devices that may be affected Hearing aids, implanted cardiac pacemakers, implanted defibrillators, other medical electronic devices, fire alarms, automatic doors and other automatically controlled devices.

If you are using an implanted cardiac pace maker, implanted defibrillator or any other electronic medical device, consult the manufacturer or retailer of the device for advice regarding possible effects from radio waves.

CAUTION

Electronic devices in some types of cars can be affected by use of the FOMA terminal.

For safety's sake, do not use the FOMA terminal inside such cars.

Itching, rash or eczema may be caused depending on your physical conditions or predisposition.

If an abnormality occurs, stop using the FOMA terminal immediately, and then seek medical attention.

Metal(chrome plating) is used to the following parts.

Parts that are used: USB connector

Precautions for the FOMA Card

CAUTION

Be careful when removing the FOMA card(IC portion).

Your hands or fingers may be injured.

10 Contents/Precautions

Notes on Using near Electronic Medical Equipment

■The description below meets ″Guideline on the Use of Radio-communication Equipment such as Cellular Telephones - Safeguards for Electronic Medical Equipment″ by the Electromagnetic Compatibility Conference.

WARNING

Be sure to adhere to the following regulations inside medical facilities.

●Keep the FOMA terminal out of operating rooms, intensive care units (ICUs) or coronary care units (CCUs).

●Turn off the PC in hospital wards.

●Turn off the PC in hospital lobbies and corridors if electrical medical devices could be nearby.

●If the medical facility has specific zones where use or possession of mobile terminals is prohibited, follow those regulations.

●If the function which automatically turns on the power is set, cancel the setting before turning off your PC.

Turn off the PC in crowded trains or other public places where implanted cardiac pacemaker or defibrillator wearers could be nearby.

Signals from the FOMA terminal may affect the operation of implanted cardiac pacemakers or defibrillators.

If you use an implanted cardiac pacemaker or implanted defibrillator, use the mobile terminal 22cm or more away from the implanted cardiac pacemaker or implanted defibrillator.

Operation of an implanted cardiac pacemaker or implanted defibrillator may be affected by radio waves.

Patients using electronic medical equipment other than implanted cardiac pacemakers or implanted defibrillators (using outside medical facilities for treatment at home, etc.) should check the influence of radio waves upon the equipment by consulting the manufacturer.

Operation of electronic medical equipment may be affected by radio waves.

Contents/Precautions 11

Handling and Care

General Usage Guidelines

■Keep the FOMA terminal away from water.

The FOMA terminal and FOMA card are not waterproof. Do not use the terminal in places with high humidity such as a bath or where rain may get it wet. If you carry the card close to your body, moisture from sweat may corrode the internal parts causing a malfunction. Note that malfunctions deemed to be caused by water are not covered by the warranty, and may be impossible to repair. Since these malfunctions are not under warranty, even when repair is possible, it will be done at the user's expense.

■Clean the FOMA terminal with a dry, soft cloth (Lens cleaning cloth).

If the FOMA terminal is wiped with alcohol, paint thinner, benzine or detergent, the printing may disappear or color may fade.

■Keep the connector contacts clean with a dry, soft cloth.

Dirty contacts can result in intermittent connections.

■Do not place the equipment near air conditioner outlets.

Condensation may form due to rapid changes in temperature, and this may corrode internal parts and cause malfunction.

■Do not place the FOMA terminal where excessive force will be applied to it.

If FOMA terminal is inserted to a full bag, or placed in a pocket and sat on, its internal PCBs may be damaged or malfunction. Such damage is not covered by warranty.

■Read the individual manual attached to the FOMA terminal.

FOMA Terminal

■Avoid using in extremely high or low temperatures.

The FOMA terminal should be used within a temperature range from 5 °C to 35 °C and a humidity range from 45 % to 85 %.

■FOMA terminal may affect fixed phones, televisions or radios in use nearby. Use as far as possible from such appliances.

■Keep a separate record of any information stored on the FOMA terminal and store the copies in a safe location.

DOCOMO assumes no responsibility for the loss of any of your data.

12 Contents/Precautions

■Remove the FOMA terminal from the PC when transporting.

Malfunction or damage may result.

■It is normal for the FOMA terminal to become warm during use. You can continue to use it even when it is warm.

■Take care not to drop the FOMA terminal when removing the FOMA terminal from the carrying case.

■When it is not in use, keep the FOMA terminal in its carrying case to keep the connector contacts clean.

Dirty contacts may result in intermittent connections.

■When putting the FOMA terminal in carrying case, keep it away from wet or high temperature place. Pay attention not to put excessive force on the FOMA terminal.

Transformation, tarnish, color staining may result.

FOMA Card

■Do not put excessive force on the FOMA card when inserting or removing it into the FOMA terminal.

■It is normal for the FOMA card to become warm during use. You can continue to use it even when it is warm.

■Always keep the IC portion of the FOMA card clean.

■Clean the FOMA card with a soft, dry cloth (Lens cleaning cloth).

■Be sure to keep a separate note of the information registered to the FOMA terminal.

DOCOMO is not responsible for any losses of registered information.

■Visit DOCOMO shop to return the FOMA card for the environmental purpose.

■Avoid extreme temperature.

■Do not scratch, touch carelessly or short circuit the IC portion.

Data loss or malfunction may result.

■Do not drop or give shock to the FOMA card .

Malfunction may result.

■Do not bend or put heavy things on the FOMA card.

Malfunction may result.

■Do not insert UIM into the FOMA terminal with labels or stickers attached on.

Contents/Precautions 13

CAUTION

■Do not use the modified FOMA terminal. Using modified FOMA terminal result in violating the law of Electromagnetic Compatibility.

FOMA terminal has been complied with technical standard of wireless equipment stipulated by law of Electromagnetic Compatibility. As for the proof, the technical standard compliance mark, is indicated in the inscription seal. If FOMA terminal is modified by turning the screw to the left to disassemble, technical standard compliance becomes invalid.

Please do not use FOMA terminal during the time when technical standard compliance is being invalid, since you are in violation of the law of Electromagnetic Compatibility.

14 Contents/Precautions

Purchased Product and Accessories

■L-05A Terminal (With Rear Cover L13, Warranty)	■L-05A CD-ROM
	•	L-05A Connection Software (For Windows/Macintosh
	•	DOCOMO Connection Manager (For Windows/Macintosh
	•	L-05A INSTRUCTION MANUAL PDF
