LG GW910 User Guide

GW910 User Guide

- English

This document is the user guide for the GW910 Windows Phone

Smartphone. All rights for this document are reserved by LG Electronics.

Copying, modifying and distributing this document without the consent of

LG Electronics are prohibited.

Part 15.21 statement

" Change or Modifications that are not expressly approved by the manufacturer could void

the user's authority to operate the equipment. “

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful interference or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Part 15 Class B Compliance

This device and its accessories comply with part15 of FCC rules.

Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Body-worn Operation

This device has been tested for typical body-worn operations

with the distance of 0.79inches (2.0cm) from the user’s body.

To comply with FCC RF exposure requirements, a minimum separation distance

of 0.79inches(2.0cm) must be maintained from the user's body.

Additionally, Belt clips, holsters & other body-worn accessories may not contain

metallic components.

GW910TM Features

Phone Components

Hands-free Connector/

Charger/

Proximity Sensor

Turns off the LCD automati-

cally when in close proximity

to your face, during a call.

Touch Screen

Send Key

Opens the touchscreen

Dialpad and answers

incoming calls

Power/End Key

Hold down to power the phone On or Off.

Earpiece

Allows you to listen to the other party/caller.

Fingerprint Navigation sensor

Scrolls right and left or up and down to navigate menus.

End Key

Ends or rejects a call.

Back button

Returns to the previous menu

Stylus Connector Slot

Volume Keys

When the screen is idle:

Adjust the phone volumes

During a call:

Adjust the in-call earpiece

volumes

MicroSD Card Slot

Multitasking Key

Camera key

Activates the camera

GW910TM Features

External Camera Lens

Soft Reset Key

SIM card slot

Battery Terminals

How to hold your GW910

For better RF antenna reception, LG suggests that you hold the handset as depicted in the figure below.

Do not cover the RF antenna area with your hand during a call.

. This may degrade speech quality.

RF antenna

Touchscreen Guidelines

This product’s keys consist of touch keys displayed on the LCD screen. Be sure to read follow these Touchscreen Guidelines before using this product.

Make sure your hands are clean and dry.

In humid environments, remove any moisture from your fingers or the touch keys.

Touchscreen

It is unnecessary to press the touch keys hard for them to work. Do not subject the product to

severe impact, as this may damage the touch key sensors.

Use the tip of your finger to press precisely on the touch key you want, being careful not to tap

any other keys.

Touch keys may not work properly if a mobile phone case or plastic cover is covering them.

Keep metallic or other conductive materials away from the surface of the touchscreen. Contact

with them may result in errors.

This phone allows you to use a pen or stylus to select Menus. You can also use your finger to

select Menus.

The touchscreen may not function properly in hot and humid environments.

Getting Started

Installing the SIM Card and Battery

1. Installing the SIM card

Your SIM card contains your phone number, service details and contacts and must be inserted into your handset. If your SIM card is removed, your handset becomes unusable (except for emergency calls, depending on which Country you are in at the time) until a valid one is inserted. Always disconnect the charger and other accessories from your handset before inserting or removing your SIM card. Slide the SIM card into the SIM card holder. Make sure that the SIM card is properly inserted and the gold contact area on the card is facing downwards. To remove the SIM card, press down lightly and pull it gently outwards.

To remove the SIM card To insert the SIM card

Note

The metal contact of the SIM card can easily be damaged by scratches. Pay special attention to the SIM

card while handling. Follow the instructions supplied with the SIM card.

2. Installing the battery.

Remove the battery cover (as shown below). Align the metal contacts on the bottom edge of the battery compartment. Press the other end of the battery down until it clicks into place. Finally, place the battery cover on the phone as shown below.

Charging the Battery

Before connecting the charger to the phone, you must first check if the battery is installed.

Getting Started

Charging Mode

When you charge your phone, the phone’s LED next to the earpiece of your phone turns red.

When the phone is fully charged, the LED turns green.

Note

If the phone is off while charging, you can press the power key for approx. 2 seconds and it will turn on.

When the battery is completely discharged, the red LED blinks and you can’t turn on the phone at this

moment. As soon as the charged power reaches 1%(after a few minutes), the LED stops blinking and charging animation is displayed. Then you can power on the phone.

CAUTION!

• When you charge a fully discharged battery, it may take over a minute for the display to respond. This is not a malfunction but completely normal.

• Do not force the connector in, as this may damage the phone and/or the charger.

• If you use the charger out of your own country, use an attachment plug adaptor for the proper configuration.

• Do not remove your battery or the SIM card while charging.

• There is risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the manufacturer’s instructions.

WARNING

• Unplug the charger from the power source and the phone during lightning storms to avoid electric shock or fire.

• Make sure that no sharp-edged items such as animal teeth or nails come into contact with the battery. It may cause a fire.

Disconnecting the Charger

Disconnect the travel adapter from the phone as shown in the diagram below. Make sure you pull the plug, not the cord.

Getting Started

How to Use a MicroSD Memory Card (Optional)

The EXpo supports microSD cards of up to a 32GB capacity. For more information on microSD, please refer to the memory card instruction manual.

How to insert a microSD memory card

Lift the plastic cover which protects the microSD slot.

Insert the memory card into the slot with the metal contacts facing down. Do not force the memory card into the slot, if the card does not slide in easily, please check that the card is being inserted in the correct way or if there is a foreign object in the slot.

Once inserted, push the memory card until it clicks, meaning that the card has been correctly engaged.

Close the plastic slot protection.

Do not remove the memory card when reading and writing the memory card.

Attention:

Avoid using the microSD memory card when the battery is low.

When you save data to the card, wait for the operation to complete and remove the card.

The card is designed to fit easily into the slot.

Do not bend the card or force it into the slot.

Do not insert any memory cards other than microSD.

WARNING

• Do not insert or remove memory card when the phone is switched on, as this may damage memory card.

Power On the Device

Turn on/off the eXpo

Press and hold the power key on the top right of the phone for a few seconds to turn the eXpoTM on or off.

Getting Started

Go to sleep mode / Wake up from sleep mode

With the power on, press the power key once to go to sleep mode. To return from sleep mode, press the power key again.

Lock or unlock your phone

Press End key for about 3 seconds to lock the device. To unlock your phone, slide the button on the screen to left or right.

Calibrate the touch screen

When you’re turning on your phone for a first time, touch calibration screen will appear. Calibrating the device screen involves tapping, with the stylus, the center of a cross as it moves around the screen.

If your device does not accurately respond to screen taps, follow these steps to re-calibrate it:

Tap Start > Settings > System > Screen.

On the Alignment tab, tap calibration is completed, Align screen reappears. Click OK on upper right corner to return to the home screen.

Align Screen

button, and follow the instructions on the screen. After

Getting Started

Windows Default Today Screen

When turning on the phone, you can see ‘Windows Default’ today screen. On this screen, you can see important and recent information. You can also move to each function by selecting items on the screen.

Start:

Opens the MS Start menu.

• pictures:

• music:

• getting started:

• phone:

• voicemail:

• clock:

• text:

• calendar:

• favorites:

* Sliding open the qwerty keyboard will rotate the screen to landscape.

Shows the list of images and videos.

You can play the music directly.

Shows today’s date and current time.

You can see the missed call history.

You can see new voicemail.

Shows the current time and date (if highlighted).

You can see the unread message from Inbox account.

Link to Calendar

You can go bookmark directly.

LG Home Screen

LG home screen is specially designed to provide an easy-to-use smart phone experience.

There are 3 home screens available, drag the touchscreen from side to side to view them. You can easily

control most features of GW910 corresponding screens for quick access.

There are shortcut icons for some of the menus and functions at the bottom of the home screen, allowing you to access them directly from the home screen.

using LG Home. You can add favorite contacts and media to the

To set or change the Today screen (including the LG Home Screen and Windows Default), tap Start > Settings > Today > Items (tab) > LGIdles / Windows Default > OK (on the top right of the screen).

Getting Started

LG S-class UI Tutorial

The LG S-class UI Tutorial will be displayed if you set the LG home screen. This is the video tutorial showing you how to access and use the phone menus, such as Contacts and Messaging. It plays automatically every time you turn on the device, if the LG Home screen is set. If you want to see the movie again, tap the Quick Settings tab on the Home screen. See the next page for more information.

Taking a look at LG home screen

Tap to open the Wireless Manager

You can access various menus and

functions directly from the home

screen using the icons on the bottom of

the screen. Slide your finger to access

the other options. Press and hold an

icon to rearrange order.

Tap to open the Alarm menu.

Tap to open the

Quick Settings

menu.

Flight Mode:

communications.

Ringtone & Alerts:

right from the home screen. You can choose from

Normal, Vibrate All,Silent All, Outdoor or Automatic.

Theme & Wallpapers:

wallpaper.

LG S-Class UI Tutorial:

Set to ON to turn off the phone’s wireless

Change the notification setting

Change the phone theme or

Launches the tutorial.

Getting Started

* Sliding open the qwerty keyboard will display the options (on the left). These are

major functions that most use the slide-out keyboard.

Favorite Media & Contact

Drag the Home screen from side to side to reveal the Media and Contact Favorites screens. You can easily access the favorite Contacts or Multimedia files from these screens.

Press and hold the Add Contacts and Add Files buttons to add/edit items for the screen.

Indicators

The following are some of the status icons that you may see on your device. It may appears right-upper corner of the screen.

Icon Description

Remaining battery life

Battery is very low

Battery charging

Sound on

Sound off

Ringer in vibration mode

Maximum signal strength

No signal

No phone service

Searching for phone service

Voice call in progress

Calls are forwarded

Getting Started

Icon Description

Call on hold

Missed call or rejected call

Voice command

TTY

GPRS (General Packet Radio Services) available

EDGE (Enhanced Data Rates For Global Evolution) available

WCDMA or HSDPA available

New e-mail or text messages

New voice mail

There are more notifications. Tap the icon to view all.

SIM is not inserted. You can not use Network service without SIM.

Shows the list of running Applications by tapping this indicator.

Menu Tree

Tap Start and then to open the top menu. From here you can access the following menus and categories:

Communications, Multimedia, Applications

and

Settings

Communications

LG Contacts

Call History

Messaging

E-mail

Instant Messaging

Write New Message

Write New E-mail

RSS Reader

Multimedia

AppCenter

Mobile Web

Music

Mobile Video

Mobi4Biz

Music Player

Photo Album

My Multimedia

Podcasts

Games

Apps

FM Radio

Camera

Video

Menu Tree

Applications

Downloaded

Navigator

Mobile Banking

Pocket Express

Internet Explorer

Schedules

Alarm

Multitasking

Weather

Calculator

Tip calculator

Stopwatch

Sprite Backup

Tools

Settings

Phone Settings

Fingerprint Sensor

Touch Feedback

Sensors

XT9 in put

Screen Outputs

Homescreen Layout

TTY

Using the Start Menu

The Start menu, located at the top left corner of the Today screen, displays a list of programs. It allows you to open a screen and switch from one program to another. You can start a program by scrolling through the programs list and tap a program.

Scroll down with your finger to see more programs that are installed in your device. Tap and hold an item to move to the top.

Image Menu Description

Today Takes you to the Today screen. Phone Opens the dialing screen and keypad. Text Opens the Message menu (SMS/MMS). E-mail Opens the Email accounts screen. Calendar Opens the MS calendar Internet

Explorer Contacts Opens MS Contacts

Instant Messaging

AppCenter Link to an web site to download ring tones, graphics, and

Mobile Web Opens the Web portal. Camera Opens the Camera (and Camcorder) function.

Web Browser to access the Internet

Opens the AIM, MSN, and Yahoo Messenger client.

multimedia files.

Image Menu Description

Navigator The Navigator application on your device uses GPS positioning

technology and your carrier’s data network to provide you with driving directions and a host of other services.

Marketplace Link to (download) the Windows® Marketplace for Mobile

application. Settings Opens the phone’s Settings menu. Apps Opens the folder containing the pre-loaded apps, like Mobile

Banking and Mobi4Biz. Multimedia Opens the folder containing Multimedia applications, such as

FM Radio, Music Video, and Podcast. Tools Opens the folder that contains Tools, such as Task Manager,

Java, MobileZip and more. Games Opens the folder containing Games. LG Menu Opens the LG Menu. Music Opens the folder containing a variety of music apps.

Windows Live

Office Mobile

File Explorer File Explorer is a program for managing files on the phone and

Lets users sync their email from Windows Live Hotmail as well

as their Windows Live Contacts

Opens the folder containing the MS Office Mobile applications

Excel Mobile, PowerPoint Mobile, OneNote Mobile and Word

Mobile.

memory card

Image Menu Description

Help Opens up the help function, allowing you to access more

information about how to use your phone. Getting

Started Search

Phone

Pictures & Videos

Windows Media

Allows you to easily set up the most commonly used functions

on your phone.

Search Phone widget that will search your phone and its various

apps, including e-mail, calendar, contacts, messages, tasks, and

Word documents, to find results

Allows you to browse your phone folders for Pictures and Videos.

Opens Windows Media Player.

+ 60 hidden pages
