LG GTF7851PS, GTF7850BL User manual

ENGLISH

Owner’s Manual

REFRIGERATOR FREEZER

Please read carefully the manual instruction and safety caution before operating your refrigerator and retain it for future reference

www.lg.com

P/No. : MFL69844902

CONTENTS

IMPORTANT SAFETY INFORMATION ................

INSTALLATION ........................................................

INNER PARTS

...........................................................

OPERATIONS ..........................................................

Starting

Before Setting The Temperature

Door Alarm

Self Test

Controls For Refrigerator Compartment

Express Freeze

Lock

(Optional)

Wi-Fi (Optional)

Hygiene Fresh (Optional)

Controls For Freezer Compartment

Ice Making

Vegetable Drawer

Defrosting

Door Cooling

Deodorizer (Optional)

Water Dispenser

Home Bar

(Optional)

SUGGESTIONS ON FOOD STORAGE ...............

CLEANING

.................................................................

GENERAL INFORMATION ...................................

LAMP REPLACEMENT ..........................................

IMPORTANT WARNINGS .....................................

BEFORE CALLING FOR SERVICE

......................

EARTH (GROUNDING) CONSTRUCTION

(OPTIONAL)

SMART FUNCTION

SMART DIAGNOSIS

...............................................................

.................................................

IMPORTANT SAFETY INFORMATION

WARNING

Keep ventilation openings, in the appliance enclosure or in the built-in structure,

Do no the defrosting process, other than those recommended by the manufacturer.

Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage

compartment of the appliance, unless they are of the type recommended by the manufacturer.

The refrigerant and insulation blowing gas used in the appliance require special disposal procedures. When disposal,

please consult

This appliance contains a small amount of isobutane refrigerant

(R600a),natural gas with high environmental compatibility, but it is

t use mechanical device

clear of obstruction.

s or o

with services agent or a similarly qualified person.

ther means to accelerate

also combustible.When transporting and installing the appliance, care should be taken to ensurethat no parts of the refrigerating circuit are damaged. Refrigerant squirting outof the pipes could ignite or cause an eye injury. if a leak is detected, avoid anynaked

flames or potential sources of ignition and air the room in which

theappliance is standing for several minutes.

In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 21 m in size for every 8g of R600a

refrigerant inside the appliance. The amount of refrigerant in your

particular appliance is shown on the identification plate inside the

appliance. Never start up an appliance showing any signs of damage.

if in doubt, consult your dealer.

IMPORTANT SAFETY INFORMATION

• Using several devices at one outlet may cause fire.

• The electric leakage breaker may

damage food and the dispenser may be leaked.

Prevent the power cord from being squeezed or imprinted if the refrigerator is pushed in after the power plug is extracted during the installation.

It becomes the cause of fire or electric shock.

Do not allow the power plug to face upward or to be squeezed at the back of the refrigerator.

Water may be flown into or the plug may be damaged, which causes fire or electric shock.

Do not allow the power cord bent or pressed by the heavy object to be damaged.

It may damage the power cord to cause fire or electric shock.

BASIC SAFETY PRECAUTIONS

This guide contains many important safety messages. Always read and obey all safety messages.

This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word WARNING, or CAUTION. These words mean:

WARNING CAUTION

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

You can be killed or seriously injured if you don’t follow instructions.

Indicates an imminently hazardous situation which, if not avoided, may result in minor or moderate injury, or product damage only.

WARNING

To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance.

1. When connecting the power

Do not use many power outlets.

IMPORTANT SAFETY INFORMATION

Pull out the power plug not by grasping the cord but the plug of its end.

It may cause electric shock or short circuit to fire.

Do not extend or modify the length of the power plug.

It causes electric shock or fire by the electric damage of the power cord or others.

Do not pull out the cord or touch the power plug with wet hands.

It may cause electric shock or injury.

Make sure of grounding.

The incorrect grounding may cause breakdown and electric shock.

Ground

Wire

Copper

Flat

More than

30 inches

Unplug the power plug when cleaning, handling or replacing the interior lamp of the refrigerator.

• It may cause electric shock or injury.

Remove water or dust from the power plug and insert it with the ends of the pins securely connected.

Dust, water or unstable connection may fire or electric shock.

When the power cord or the power plug is damaged or the holes of the outlet are loosed, do not use them.

It may cause electric shock or short circuit to make fire.

Wait for 5 minutes or longer when reconnecting the plug.

It may cause the operation of the freezer to fail.

1. When connecting the power

Be sure to use grounded exclusive proper voltage consent for the power plug.

Be sure to use grounded extension consents when extension consents are used.

It becomes the cause of fire.

IMPORTANT SAFETY INFORMATION

2. When using the refrigerator

(For CENELEC countries) This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

* CENELEC countries: AT, BE, BG,

HR, CY, CZ, DK, EE, FI, MK, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH, TR, GB

(For IEC countries) This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children shall not play with the appliance.

Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator.

It may be dropped to cause injury, fire or electric shock when opening or closing the door.

Prevent children from entering the product.

It may endanger the life of a child if the child enters the refrigerator.

Opening and closing the door of the refrigerator vigorously may cause the stored food in the refrigerator basket to fall by shock and hurt the foot, so take precautions.

Do not install the refrigerator in the wet place or the place which water or rain splashes.

Deterioration of insulation of electric parts may cause electric leakage.

IMPORTANT SAFETY INFORMATION

Benzene



Ether

Thinner

2. When using the refrigerator

Do not cling to the door or the shelves of the door or the cool chamber.

It may make the refrigerator fallen down or damage the hands. Especially, do not allow the children to do the above.

Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.

It may cause fire, electric shock or injury by dropping down.

Do not use or store inflammable materials ether, benzene, alcohol, medicine, LP gas, spray or cosmetics near or in the refrigerator.

It may cause explosion or fire.

Do not use drier to dry the inside, nor light a candle to remove odor.

It may cause explosion or

fire.

Do not use the combustible spray near the refrigerator.

It may cause fire.

In case of thunder and lightning, or not in use for a long period

of time, detach the power

There is a danger of

electric shock or fire.

plug.

Do not store the medicine or the

academic

materials at the refrigerator.

When the material with the strict temperature control is stored, it may be deteriorated or it may

The Academic

make an unexpected reaction to cause any

Medicine

The Medicine

risk.

Tempered glass is applied at the front door (optional). It can be damaged by general impact.

Do not touch the broken part.

It may cause injury.

IMPORTANT SAFETY INFORMATION

2. When using the refrigerator

When gas is leaked, do not touch

the refrigerator or the air outlet and ventilate the room

immediately.

- The explosion by spark may cause fire or burn.

- Because this refrigerator uses

natural gas as the environtment- friendly refrigerant, even as small amount is combustible. When the gas is leaked by the severe damage during delivering, installing or using the refrigerator,

any spark may cause fire or burn.

Install in places away from the fire such as the place where flammable gas is leaked.

It may cause fire.

Use the submerged refrigerator after checking it.

It may cause electric shock or fire.

Do not spray water at the outside or the inside of the refrigerator or do not clean it with benzene or thinner.

Deterioration of insulation of electric parts may cause

ThinnerThinner

electric shock or fire.

Do not allow any person except the qualified engineer to disassemble, repair or alter the refrigerator.

It may cause injury, electric shock or fire.

When disposing the refrigerator, remove the packing materials from the door.

It may cause to lock out the child.

Install the refrigerator on the solid and level floor.

Installing it on the unstable place may cause death by falling down the refrigerator when opening or closing the door.

IMPORTANT SAFETY INFORMATION

ENGLISH

2. When using the refrigerator

Do not insert the hands or the metal stick into the exit of cool air, the cover, the bottom of the refrigerator, the heatproof grill (exhaust hole) at the backside.

It may cause electric shock or injury.

When any strange smell or smoke is detected from the refrigerator, disconnect the power plug immediately and contact to the

Down-block

service center.

office

Service

center

It may cause fire.

Do not use the refrigerator for nondomestic purpose (storing medicine or testing material, using at the ship, etc.).

It may cause an unexpected risk such as fire, electric shock, deterioration of stored material or chemical reaction.

What to do with your old refrigerator.

Your refrigerator contains liquids (refrigerant, lubricant) made of recyclable materials. Allthese materials must be sent to a recyclingwaste disposal site as they can be reused aftera specific recycling process. Contact localauthorities.

Do not remove the cover on the back.

Do not use an Adapter on the back.

Place all the components in the right

places before connecting the power.

Completely empty inside before

out the container from the

door

taking

Never leave lit candles or incense on the fridge, at risk of causing fire or product damage.

IMPORTANT SAFETY INFORMATION

Carry the refrigerator with the handle bar at the bottom of the front and the top of the rear.

Otherwise, your hands may be slipped to cause injury. Because the product is heavy, carrying it alone may hurt people or accidents may occur.

Do not put bottle in the freezer.

It may freeze the contents to break the bottle to cause injury.

Do not place the food in disorder inside the refrigerator.

The food may fall during opening and closing the door of the refrigerator and hurt people.

Do not insert the hands into the bottom of the refrigerator.

The iron plate of the bottom may cause injury.

Do not put any living animal in the refrigerator.

Do not apply oil in the door connection part in any circumstances. It may cause damage to the plastic parts.

oiloil

Do not lean on the doors. Hinges may deregulate themselves, harming seal cooler and compromising performance.

CAUTION

Violating this direction may cause injury or damage house or

furniture. Always be careful, please.

Do not touch food or containers at the freezer with wet hands.

It may cause frostbite.

Because opening or closing the door or the home bar of the refrigerator may cause injury to the person around it, be careful, please.

Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner.

Technician

Products

for steel

Strong

Chemicals

Water Tank

Water

Clean the water tank according to the instruction before using the Ice Maker.

IMPORTANT SAFETY INFORMATION

Do not use products such as grinding

sponge, brush, iron, or even special

products to clean stainless steel, soap products such as alcohol, kerosene, gasoline, wax, or solvent, or strong chemicals such as chlorine, detergent,

or vinegar, for the purpose of gloss. These products may damage the protective lacquer, and they may cause risk or stain on the surface of the refrigerator.

Avoid the contact of oil or fat on the plastic parts. They may cause damage.

When the power cord is damaged, let a technician to replace it to remove the danger of an accident.

Do not use the carbonated water. The gas pressure may cause leakage.

WARNING : fill with potable water

only.

Water Tank

Use only water. If any other liquid is used, the operation of the system may be deteriorated. If a problem occurs by using any liquid other than water, the manufacturer will not be

responsible.

Water Tank

Only water

Do not store excessive water bottle or side dish container,

etc. in the door basket. It will

make you put excessive force to take out the water bottle or side dish container from the basket, and it may damage the basket or it may cause injury of your hand hitting the surrounding structure.

WARNING

Please do not use a dishwasher to clean the lower drawers; the high temperature may cause damage to the baskets which make them unusable.

THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY.

WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY. IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS.

INSTALLATION

1. Select a good location. Place your refrigerator where it is easy to use.

2.Avoid placing the unit near heat sources, direct sunlight or moisture.

3. Air must circulate properly around your refrigerator to ensure efficient operation. If your refrigerator is placed in a recessed area

in the wall, allow at least 10 inches (25 cm) or greater clearance above the refrigerator and 2 inches (5 cm) or more from the wall. The refrigerator should be elevated 1 inch (2.5 cm) from the floor,

especially if the floor is carpeted.

To avoid vibrations, the unit must be level. If required, adjust the

leveling screws to compensate for unevenness of the floor. The

front should be slightly higher than the rear to aid in door closing. Leveling screws can be turned easily by tipping the cabinet slightly. Turn the leveling screws clockwise ( ) to raise the unit,

counterclockwise( ) to lower it.

Don't install this appliance below 5°C. It may cause the debasement

of the refrigerator.

Clean your refrigerator thoroughly and wipe off all dust accumulated during shipping.

Install accessories such as ice cube box, etc., in their proper places.

They are packed together to prevent possible damage during shipment.

Connect the power supply cord (or plug) to the outlet. Don't double

up with other appliances on the same outlet.

Prior to storing food, leave your refrigerator on for 2 or 3 hours. Check the flow of cold air in the freezer compartment to ensure

proper cooling.

Your refrigerator is now ready for use.

INNER PARTS

INTERNAL CONTROLLER MODEL TYPE A

FREEZER

COMPARTMENT

Lamp

Twisting Ice Serve

Type Ice Making

Shelf

REFRIGERATOR

COMPARTMENT

Lamp

Deodorizer

(Optional)

Door Cooling

Temperature

Refrigerator

Control

Shelves

(Optional)

Vegetable Drawer

NOTE

Smart Diagnosis

Freezer Temperature Control Dial

Freezer Door Rack

( )

Freezer Door Rack

Refrigerator Door Rack

Egg Tray

Refrigerator Door Rack

(Optional)

Levelling Screw

- This guide covers several different models. The refrigerator you have purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves supplied by manufactureris the most efficient usage for energy saving.

Optional)

(

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

INNER PARTS

INTERNAL CONTROLLER MODEL TYPE B

FREEZER

COMPARTMENT

Lamp

Twisting Ice Serve

Type Ice Making

REFRIGERATOR COMPARTMENT

Temperature

Hygiene Fresh

Vegetable Drawer

Shelf

Lamp

Deodorizer

(Optional)

Fresh Zone

Door Cooling

Refrigerator

Control

Shelves

(Optional)

Smart Diagnosis

Freezer Temperature Control Dial

Freezer Door Rack

(Optional)

( )

Freezer Door Rack

Refrigerator Door Rack

Door Cooling

Egg Tray

Refrigerator Door Rack

Levelling Screw

- This guide covers several different models. The refrigerator you have

NOTE

purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves

supplied by manufactureris the most efficient usage for energy saving.

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

INNER PARTS

EXTERNAL CONTROLLER MODEL

FREEZER

COMPARTMENT

Lamp

Twisting Ice Serve

Type Ice Making

REFRIGERATOR COMPARTMENT

Shelf

Lamp

Deodorizer

(Optional)

Fresh Zone

Door Cooling

Smart Diagnosis

Freezer Temperature Control Dial

Freezer Door Rack

(Optional)

( )

Freezer Door Rack

Refrigerator Door Rack

Door Cooling

Egg Tray

Shelves

(Optional)

Hygiene Fresh

(Optional)

Vegetable Drawer

NOTE

- This guide covers several different models. The refrigerator you have purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves

supplied by manufactureris the most efficient usage for energy saving.

Refrigerator Door Rack

Levelling Screw

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

INNER PARTS

DISPENSER MODEL

FREEZER

COMPAR

TMENT

Lamp

Shelf

Twisting Ice Serve

Type Ice Making

REFRIGERATOR COMPARTMENT

Lamp

Deodorizer

(Optional)

Fresh Zone

Door Cooling

Shelves

(Optional)

Hygiene Fresh

(Optional)

Vegetable Drawer

NOTE

Smart Diagnosis

- This guide covers several different models. The refrigerator you have purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves

supplied by manufactureris the most efficient usage for energy saving.

eezer Temperature

Fr Control Dia

Freezer Door Rack

( )

Freezer Door Rack

Wat

Egg Tray

Refrigerator Door Rack

Levelling Screw

(Optional)

er Tank

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

INNER PARTS

DOOR IN DOOR MODEL

Deodorizer

(Optional)

Smart Diagnosis

( )

Door Cooling

(Optional)

NOTE

- This guide covers several different models. The refrigerator you have purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves

supplied by manufactureris the most efficient usage for energy saving.

Home Bar

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

OPERATIONS

STARTING

When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods.

If operation is interrupted, wait 5 minutes before restarting.

BEFORE SETTING THE TEMPERATURE

●

The temperature of the refrigerator is kept constant regardless of changes in room temperature.

It is recommended that, once set, the temperature settings(the controls for the refrigerator and freezer compartments) not be changed unless necessary.

●

This refrigerator has one temperature control button for the refrigerator compartment and one

temperature control dial for the freezer compartment.

●

The default setting of the temperature control button for the refrigerator compartment is ‘3°C’.

(for external controller model),

●

The default setting of the temperature control dial for the freezer compartment is '3'.

●

This refrigerator has a temperature sensor in the refrigerator compartment. It will start and stop

the compressor automatically as needed.

DOOR ALARM

When the door of the refrigerator or the freezer is open for 1 minute, an alarm will sound three times.

It the door remains open, the alarm will repeat every 30 seconds.

SELF TEST

●

Your refrigerator contains a built in diagnostic capability. If it develops a malfunction in certain areas,

it will display an error code to assist the repair technician. While an error code is displayed, other control and display functions will not operate.

●

If an error code is displayed, contact a service center. Do not disconnect the power cord from

the outlet.

CONTROLS FOR REFRIGERATOR COMPARTMENT

FOR INTERNAL CONTROLLER MODEL

The default setting of the temperature control button for the refrigerator compartment is NORMAL.

To control the refrigerator temperature, press the REF. TEMP CONTROL button.

Whenever pressing the button, LED emitting the light. The temperature is set in 7 steps, from Cold to Coldest

cooling.

OPERATIONS

FOR EXTERNAL CONTROLLER MODEL

Display graphic can be different, depend on the type of your refrigerator.

●

Touch

'Fridge' button to control refrigerator temperature.

●

Whenever the button, the LED emits light.

●

Touch

● The number showing up on the LED luminesce indicate the temperature of refrigerator compartment.

●

You can select the desired setting point seven steps, from '0 C' to '6oC'.

touching

‘Hygiene Fresh’ button to operate hygiene motor (optional).

Touch

button, Fridge temperature will be down each 1 C.

ⓐ

button, Hygiene Fresh motor will be on, power mode, off .

ⓑ

(optional)

EXPRESS FREEZE

●

The Express Freeze

when the refrigerator first turn on. The compressor and circulating fan operate at maximum cooling capacity to quickly lower the refrigerator temperature. It shuts off automatically.

●

If warm food is placed into the refrigerator, Express Freeze can be started with the button

on the control panel. Express Freeze will shut off when the temperature reaches

the proper level or it can be shut off manually by the Express Freeze button.

eature operates

touching

LOCK (OPTIONAL)

●

LOCK

Touch

and hold the Lock button for 3 seconds to lock the Lock. When it is locked, the Lock LED will be on and the other button will not operate. To

touch

unlock, and hold the Lock button for 3 seconds again.

OPERATIONS

(OPTIONAL)

Wi-Fi

This sets the refrigerator to connect to your home's Wi-Fi network.

HYGIENE FRESH (OPTIONAL)

CAUTION

Before installing or using the product, make sure to read the owner's manual carefully to use the product accurately as intended. This HYGIENE FRESH filter has the antibacterial function of removing the virus or bacteria inside the refrigerator and the deodorizer function to remove the scent. The function has tested and has been certificated by authorized institutions

●

Switch over to use mode

Switch over to use mode.

Intertek

To use the HYGIENE FRESH filter,

•

of the door and switch over to the AUTO or POWER mode.

(Whenever you press the button, the HYGIENE FRESH filter will be switched to AUTO

OFF .)

AUTO

AUTO POWER OFF AUTO

CAUTION

When the user switches to AUTO or POWER mode, the LED around the filter is also turned on. Open

door to check whether the LED around the filter is also turned on. Do not put in your finger or alien

the

particles inside the fan. It can be caused of an injury or malfunction.

CAUTION

Do not wash the HYGIENE FRESH filter by using water because It can be caused of malfunction.

•

This filter may not be effective for all types of bacteria and virus.

•

This is effective to remove the bacteria which is not on the food in the refrigerator.

•

touch

the

button on the display panel on the front side

POWER

OPERATIONS

CONTROLS FOR FREEZER COMPARTMENT

5 3

To lower the temperature in the freezer, turn the knob

To raise the temperature in the freezer, turn the knob

●

When the freezer compartment is not cold enough in

( 6 ~ ).

●

Knob is for quick freezing in the freezer compartment. continuously or the

refrigerator compartment can be warmer. When the quick

right and set to a higher number.

left and set to a smaller number.

winter, adjust the control for the freezer to High

The refrigerator can be operated

freezing is finished,

please return to set the Knob at Normal.

●

Setting the Freezer Knob at will satisfy

. Setting the Freezer Knob at NORMAL will have

sufficient freezing effect, so it is recommended to set the Knob at NORMAL.

●

Refrigerator temperature would be warmer when the Freezer temperature set to be colder

ICE MAKING

Twisting Ice Serve Type

●

To make ice cubes, fill the ice tray with water and

insert in its position.

●

To remove ice cubes, hold the lever of the tray and

pull turn gently. Then, ice cubes drop in to the ice cube box.

Ice Trays

You can disassemble the Ice Maker to

NOTE

• Twisting Ice Serve Type:

secure space in the freezer.

Remove 1 and 2

1. Ice Tray

2. Ice Cube Box.

WARNING

• Do not use anything other than water.

• Fill the water up to the marked line..

Ice Cube Box

OPERATIONS

VEGETABLE DRAWER

How to use

●

Vegetable drawer can be used through the control of knob.

●

Check the position of knob prior to store the food.

●

Do not locate the knob on the middle point.

DEFROSTING

●

Defrosting takes place automatically.

●

The defrosted water flows down to the evaporating tray which located in the lower back side of the refrigerator and is evaporated automatically.

DOOR COOLING

(OPTIONAL)

The anion coating in the duct cover purifies the air and helps stored foods remain fresh longer.

If water of foreign substances enter the cool air vent while cleaning, efficiency will be lowered. In addition, if gasket is damaged, efficiency may be lowered owing to the escape of cool air.

DEODORIZER (OPTIONAL)

●

Unpleasant odor of food in fresh food compartment is deodorized with no harm to you and the food.

How to use

• As Deodorizer is located in cooling air inlet for circulating air in fresh food compartment, there is

no need for any handling.

• Do not prick the cooling air inlet with a sharp tip because Deodorizer may be damaged.

• When storing food with a strong odor, wrap it or store it in a container with a lid because odor may be

passed on to other foods.

Re-Using of Deodorizer

• Used some length and the odor is strong,

Deodorizer can be revived and re-used.

• Separate Deodorizer in ceiling of refrigerator

compartment, using hair drier to remove moisture or malodor and oxidize under sunlight to decomposing malodor by ultraviolet.

REF. TEMP. CONTROL

MIN MAX

OPERATIONS

WATER DISPENSER (OPTIONAL)

●

Put water after the water tank being in position. Necessarilly separate the water tank to

NOTE

clean it or not use it.

●

When the water tank is not position after filling it with water, water can leak out by the valve pushed.

●

Putting water in the water tank

1. Open the cover cap and pour water into the water tank.

2. Close the cover cap.

3. The water tank is optional removable part

which can be applied to enlarge the storage capacity.

You can store food, drinks after removing the water tank cover.

Caution

Do not use anything other than water including. Hot water needs to be cooled before being put

in the water tank.

Cover Cap

WATER

PUSH

●

Drinking

1. Press the dispenser pad with cup.

2. The water is released when the dispenser pad is pressed. The pad returns to its original position when the cup is removed and the water stops its flow.

HOME BAR

How to use Home Bar

(OPTIONAL)

Press the button at the top left side of Home Bar until “click” sounds. You can use various storage spaces inside Home Bar to systematically store food. Do not use the button to close Home Bar. Store food that is frequently taken out and used. You don’t have to open the door and it saves electricity. LED lamp is turned on for easy taking out of the contents when Home Bar is open. Do not hang on Home Bar for safety reasons.

How to disassemble Home Bar basket

Press until “click” sounds

1. If you lightly lift and take out the basket, the basket is hooked into the grooves at the left and right side of the drawer.

How to assemble Home Bar basket

1. Place the basket on the guide and push in to be hooked into the wide groove.

2. At this time, hold the both ends of the basket, lift with force to separate one side, and separate the other side.

2. At this time, hold both ends of the basket, insert one side with force, and assemble the other side.

Caution

How to disassemble Home Bar cover

Please follow the guidelines. Otherwise, it may be damaged.

Lift Home Bar cover upward and pull to separate and take out.

Caution

Before the disassembly, take out all food to empty inside the refrigerator.

SUGGESTIONS ON FOOD STORAGE

STORING FOOD

●

Store fresh food in the refrigerator compartment. How food is frozen and thawed is an

important factor in maintaining its freshness and flavor.

●

Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and melons.

●

Allow hot food to cool prior to storing. Placing hot food in the refrigerator could spoil other food, and lead to higher electric bills!

●

When storing the food, cover it with vinyl wrap or store in a container with a lid. This prevents moisture from evaporating, and helps food to keep its taste and nutrients.

●

Do not block air vents with food. Smooth circulation of chilled air keeps refrigerator temperatures

even.

●

Do not open the door frequently. Opening the door lets warm air enter the refrigerator, and cause temperatures to rise.

FREEZER COMPARTMENT

●

Do not store bottles in the freezer compartment - they may break when frozen.

●

Do not refreeze food that has been thawed. This causes loss of taste and nutrition.

●

When storing frozen food like ice cream for a long period, place it on the freezer shelf, not in the door rack.

●

Loading for Freezing - It is recommended to load newly introduced foods on the following position for freezing:

Newly Introduced Food

●

Freezer Door Basket, marked ( storage of frozen food (optional).

) is -12°C compartment, that is suitable for short term

REFRIGERATOR COMPARTMENT

●

Avoid placing moist food on deep interior refrigerator shelves, it could freeze upon direct contact with chilled air. To avoid this it is better to store food in the covered container.

●

It is desirable to store moist food (especially vegetable and fruit) in the vegetable storage compartment. If it is necessary to store on a shelf of the refrigerator, put it close to the door away from the back wall of the refrigerator to avoid being frozen by the cool circulating in the refrigerator.

●

Always clean food prior to refrigeration. Vegetables and fruits should be washed and wiped, and packed food should be wiped clean, to prevent adjacent food from spoiling.

●

When storing eggs in their storage rack, ensure that they are fresh, and always store them in a up-right position, which keeps them fresh longer.

CLEANING

It is important that your refrigerator be kept clean to prevent undesirable odors. Spilled food should be wipe up immediately, since it may acidify and stain plastic surfaces if allowed to settle.

Never use metallic scouring pads, brushes, coarse abrasive cleaners or strong alkaline solutions on any surface.

Before you clean, however, remember that damp objects will stick or adhere to extremely cold surfaces. Do not touch frozen surfaces with wet or damp hands.

EXTERIOR - Use a lukewarm solution of mild

soap or dish washable solution to clean the durable finish of your refrigerator. Wipe with a clean, damp cloth and then dry.

For products with a stainless steel exterior, use a clean sponge or soft cloth and a mild Detergent in warm water. Do not use abrasive or harsh cleaners. Dry thoroughly with a Soft cloth. Do not use appliance wax, bleach, or other products containing chlorine on stainless steel.

INTERIOR - Regular cleaning of the interior and

interior parts is recommended. Use a lukewarm solution of mild soap or dish washable solution to clean the durable finish of your refrigerator. Wipe with a clean, damp cloth and then dry.

INTERIOR PARTS - Wash compartment shelves,

door racks, storage trays and magnetic door seals etc. Use a lukewarm solution of mild soap or dish washable solution to clean the inner lining of your refrigerator. Wipe with a clean damp cloth and then dry.

WARNING

Always remove power cord from the wall outlet prior to cleaning in the vicinity of electrical parts(lamps, switches, controls, etc.). Wipe up excess moisture with a sponge or cloth to prevent water or liquid from getting into any electrical part and causing electric shock. Do not use flammable or toxic cleaning liquids.

• Do not use : Surface

active agents, Car wax, Anticorrosive, or any kind of oil, Gasoline, Acids, Wax.

• Only use dish washable

solution, and soapy water when cleaning.

• Using harsh cleaning chemicals will cause the

external finishes to change colour.

CLEANING

WATER DISPENSER

(OPTIONAL)

Grille -

Wipe with a wet cloth, and dry with a dry cloth.

Water Tank -

1. Putting the Water Is not necessary to remove the water tank in order to supply

it (it could be filled like shows fig. 1 pulling the tank gate).

NOTE

- Before closing door, close the cap and clamp tightly.

- Do not use liquids containing sugar or carbonated drinks like soda

2. Disassembly Lift the water tank, gripping a side and bottom of water tank.

NOTE

When disassemble Water Tank, use all water

3. Assembly If by some cause removes the water tank, place again the water

tank on its original position. Verify that the valve assembly

correctly in the hole of the door (fig. 3,4). Once assembled push

down and check the tank position with line.

Water Tank -

1. Remove the tank cover.

inside dispenser first.

3. Clean the inside and outside of the cap with diswashing detergent and rinse throughly under running water. Dry the water with a cloth.

WATER

PUSH

2. Clean the inside and outside of the water tank with diswashing detergent and rinse throughly under running water. Dry the water with a cloth.

Caution

1. Use lukewarm water when cleaning.

2. Do not use anything other than water. If it is used with soft drinks,put water in the water tank and discharge three or four cups of water shortly.

GENERAL INFORMATION

VACATION TIME

During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan to be away for an extended period, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation.

POWER FAILURE

Most power failures are corrected in an hour or two and will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off. During power failures of longer duration, place a block of dry ice on top of your frozen packages.

IF YOU MOVE

Remove or securely fasten down all loose items inside the refrigerator. To avoid damaging the leveling screw(s), turn them all the way into the base.

This appliance is intended to be used in household and similar applications such as:

- Staff kitchen areas in shops, offices and other working environments.

- Farm houses and by clients in hotels, motels and other residential type environments.

- Bed and breakfast type environments.

- Catering and similar non-retail applications.

ANTI-CONDENSATION PIPE

The outside wall of the refrigerator cabinet may sometimes get warm, especially just after installation. Don't be alarmed. This is due to the anticondensation pipe, which pumps hot refrigerant to prevent "sweating" on the outer cabinet wall.

LAMP REPLACEMENT

NOTE

● This product applies LED Lamp which can not be replaced by the user.

Please contact authorized service centre for the lamp replacement.

IMPORTANT WARNINGS

DO NOT USE AN EXTENSION CORD

If possible, connect the refrigerator to its own individual electrical outlet to prevent it and other appliances or household lights from causing an overload that could cause a power outage.

ACCESSIBILITY OF SUPPLY PLUG

The refrigerator-freezer should be so positioned that the supply plug is accessible for quick disconnection when accident happens.

SUPPLY CORD REPLACEMENT

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

VERY DANGEROUS ATTRACTION

An empty refrigerator can be a dangerous attraction to ch latches, lids or the entire door from your unused appliance, or take some other action to make it harmless.

ildren. Remove either gaskets,

ABOUT GROUNDING (EARTHING)

In the event of an electric short circuit, grounding (earthing) reduces the risk of electric shock by providing an escape wire for the electric current.

In order to prevent possible electric shock, this appliance must be grounded.

Improper use of the grounding plug can result in

an electric shock. Consult a qualified electrician or service person if the grounding instructions are not completely understood, or if you have doubts on whether the appliance is properly

grounded.

DO NOT MODIFY OR EXTEND THE POWER CORD LENGTH.

It will cause electric shock or fire.

This appliance must be grounded (earthed).

DON'T WAIT! DO IT NOW!

Do not store inflammable materials, explosives

or chemicals in the refrigerator.

Do not store explosive substances such as aerosol cans with a flammable propellant in this

appliance.

DISPOSAL OF THE OLD APPLIANCE

This appliance contains fluid (refrigerant, lubricant) and is made of parts and materials which are

reusable and/or recyclable.

All the important materials should be sent to the collection center of waste material and can be

reused

r rework (recycling). For take back, please contact with the local agency.

afte

BEFORE CALLING FOR SERVICE

SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE

POSSIBLE CAUSES FIRST :

PROBLEM POSSIBLE CAUSES

REFRIGERATOR DOES NOT OPERATE

REFRIGERATOR OR FREEZER COMPARTMENT TEMPERATURE TOO WARM

●

Has a house fuse blown or circuit breaker tripped?

●

Has the power cord plug been removed or loosened from the electrical wall outlet?

●

Temperature control not set on proper position.

●

Appliance is placed close to wall or heat source.

●

Warm weather-frequent door openings.

●

Door left open for a long time.

●

Large amount of foods are kept in the refrigerator.

ABNORMAL NOISE(S)

REFRIGERATOR HAS ODOR

DEW FORMS ON THE CABINET SURFACE

●

Refrigerator is installed in a weak or uneven place, or leveling screw needs adjusting.

●

Unnecessary objects placed in the back side of the refrigerator.

●

Foods with strong odors should be tightly covered or wrapped.

●

Interior needs cleaning.

●

Not unusual during periods of high humidity.

●

Door may have been left ajar.

DISPOSAL OF YOUR OLD APPLIANCE

1. This crossed-out wheeled bin symbol indicates that waste electrical and electronic products (WEEE) should be disposed of separately from the municipal waste stream.

2. Old electrical products can contain hazardous substances so correct disposal of your old appliance will help prevent potential negative consequences for the environment and

human health. Your old appliance may contain reusable parts that could be used to repair other products, and other valuable materials that can be recycled to conserve limited resources.

3. You can take your appliance either to the shop where you purchased the product, or contact your local government waste office for details of your nearest authorised WEEE collection point. For the most up to date information for your country please see www.lg.com/global/recycling

EARTH (GROUNDING) CONSTRUCTION (OPTIONAL)

It is recommended to install the earth wire to prevent electric shock in case of electricity leakage.

How to connect the earth wire:

• Connect the earth wire's metal ring end to the earth screw

on the back of the refrigerator.

• Peel off the cable sheath/insulation at the other end of the earth wire. Attach the peeled wire

to a metal screw/nail and then drive it through the wall or ground.

Do not connect the earth wire to the following locations.

• Gas pipe

It could produce sparks which lead to fire and explosion.

• Telephone earth wire and lightning rod

It is dangerous during lightning.

• Water pipe and water tap

The earth wire connection will not work when the middle of the water pipe is made of plastic. If it is connected to a metal water pipe, it could cause someone to be electrocuted.

When installing the product in a humid or wet location, you must install the earth wire.

Ex) • Unfloored or dirt floored room (Room with dirt and no floor), concrete floor

• Location where it can get wet such as near the sink

• Location where water can leak or is humid such as basement

• Other wet or humid location

Especially, for locations where it always get wet such as near the restaurant sink, you are obligated by the law to install a circuit breaker in addition to the earth wire.

After consulting with your retailer or electric construction company, you must do the earth wire construction (Type 3 earth construction). Please note that earth construction could incur extra fees.

SMART FUNCTION

(OPTIONAL)

Using Smart ThinQ Application

Installing Smart ThinQ

Search for the LG Smart ThinQ application from the Google Play Store or Apple App Store on a smart phone. Follow instructions to download and install the application.

Wi-Fi Function

• For appliances with the or logo

Communicate with the appliance from a smart phone using the convenient smart features.

Firmware Update

Keep the appliance performance updated.

Smart Diagnosis™

If you use the Smart Diagnosis function, you will be provided with the useful information such as a correct way of using the appliance based on the pattern of use.

Settings

Allows you to set various options on the refrigerator and in the application.

NOTE

• To verify the Wi-Fi connection, check that Wi-Fi icon on the control panel is lit.

• LG Smart ThinQ is not responsible for any

network connection problems or any faults, malfunctions, or errors caused by network connection.

• The machine supports 2.4 GHz Wi-Fi networks

only.

• If the appliance is having trouble connecting

to the Wi-Fi network, it may be too far from the router. Purchase a Wi-Fi repeater (range extender) to improve the Wi-Fi signal strength.

• The Wi-Fi connection may not connect or may

be interrupted because of the home network environment.

• The network connection may not work properly

depending on the internet service provider.

• The surrounding wireless environment can

make the wireless network service run slowly.

• The application is subject to change for appliance improvement purposes without notice to users.

• Functions may vary by model.

Open Source Software Notice Information

To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http:// opensource.lge.com.

In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.

LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the product.

Smart Diagnosis™ Using a Smart Phone

• For appliances with the or logo

Use this function if you need an accurate diagnosis by an LG Electronics customer information centre when the appliance malfunctions or fails.

Smart Diagnosis™ can not be activated unless the appliance is connected to power. If the appliance is unable to turn on, then troubleshooting must be done without using Smart Diagnosis™.

SMART DIAGNOSIS

(Only for applied models)

FOR INTERNAL CONTROLLER MODEL

Smart diagnosis function is...

Use the function to contact the service center and receive precise diagnosis when the refrigerator malfunctions or fails. Use it only to connect to the consultant and do not use it in normal times.

How to use the function

First, call to the LG service center. Only use the Smart Diagnosis feature when instructed to do so by the LG call center agent.

Open the refrige

s the ref

Pres button or

If the buzzer sounds 4 times, open the Freezer

(upper) door and place the phone near the speaker hole.

Check if the speaking side(microphone) of the telephone is toward the speaker hole.

4. Do not take away the telephone while data is being transmitted.

During the data transmission for smart diagnosis, wait with the telephone placed near the speaker hole at the top right side.

ator (lower) door.

igerator temperature control

or 3sec

re.f

w CAUTION

The transmission sound may be irritating. Do not take away the telephone until the sound stops for good diagnosis.

5. After the completion of the data transmission,

listen to the explanation of the consultant about the result of the smart diagnosis.

When the data transmission is completed, along with the display of the data transmission completion, the refrigerator will be automatically turned off and on a few seconds later.

Listen to the explanation of the consultant about the result of the analyzed diagnosis and follow the instructions.

NOTE

• Position the phone so that its microphone is aligned with the speaker hole.

• The Smart Diagnosis™ sound is generated after around three seconds.

• Do not take the phone off the speaker hole while the data is transmitted.

• Hold the phone to the upper right speaker hole and wait while the data is transmitted.

• The data transfer sound may be harsh to the ear while the Smart Diagnosis™ data is being transmitted, but do not take the phone off the speaker hole for accurate diagnosis until the data transfer sound has stopped.

• When the data transfer is complete, the transfer completion message is displayed and the control panel is automatically turned off and then on again after a few seconds. After the customer information centre explains the diagnosis result.

• The Smart Diagnosis™ function depends on the local call quality.

• The communication performance will improve and you can transmit a better signal if you use a land line home phone.

• If the Smart Diagnosis™ data transfer is poor due to poor call quality, you may not receive the best Smart Diagnosis™ service.

SMART DIAGNOSIS (Only for applied models)

FOR EXTERNAL CONTROLLER MODEL

Smart diagnosis function is...

Use the function to contact the service center and receive precise diagnosis when the refrigerator malfunctions or fails. Use it only to connect to the consultant and do not use it in normal times.

How to use the function

First, call to the LG service center. Only use the Smart Diagnosis feature when instructed to do so by the LG call center agent.

1. Close all refrigerator doors, and touch

and hold display lock button to make it locked state.

If the display is already in locked state,

touch

and hold lock button to reset the lock and

touch

and hold the lock button again to make it

locked state.

Caution

■

If it passes 5 minutes in locked state, smart

diagnosis function will not be activated, so be careful.

Touch

2. and hold fridge temperature button for 3 seconds or longer. (All display screens will be turned off, and in a while, 3 will be displayed on the fridge temperature display part.)

3. Open all refrigerator compartment and freezer compartment doors, and place the telephone near the speaker hole at the top right side.

Check if the speaking side(microphone) of the telephone is toward the speaker hole.

4. Do not take away the telephone while data is being transmitted.

During the data transmission for smart

diagnosis, wait with the telephone placed near the speaker hole at the top right side.

The remaining time for data transmission is

displayed on the display screen.

Caution

■

The transmission sound may be irritating.

Do not take away the telephone until the sound stops for good diagnosis.

5. After the completion of the data transmission, listen to the explanation of the consultant about the result of the smart diagnosis.

When the data transmission is completed,

along with the display of the data transmission completion, the refrigerator will be automatically turned off and on a few seconds later. Listen to the explanation of the consultant about the result of the analyzed diagnosis and follow the instructions.

NOTE

• Position the phone so that its microphone is aligned with the speaker hole.

• The Smart Diagnosis™ sound is generated after around three seconds.

• Do not take the phone off the speaker hole while the data is transmitted.

• Hold the phone to the upper right speaker hole and wait while the data is transmitted.

• The Smart Diagnosis™ function depends on the local call quality.

• The communication performance will improve and you can transmit a better signal if you use a land line home phone.

• If the Smart Diagnosis™ data transfer is poor due to poor call quality, you may not receive the best Smart Diagnosis™ service.

MEMO

LG GTF7851PS, GTF7850BL User manual

Specifications and Main Features

Frequently Asked Questions

User Manual
