LG GSB325NSQZ, GS-5164AEFZ1, GSL325PZYZ, GSP325PZCV, GS-B325PVQZ User Manual

...
SXS REFRIGERATOR
Please read this manual carefully before operating your set and retain it for future reference.
POLSKI
P/No. : MFL67683081
www.lg.com
(In the UK Only)
Electrical Connections
Important
The wires in this mains lead are coloured in accordance with the following code:
GREEN AND YELLOW:EARTH
BLUE:NEUTRAL
BROWN:LIVE
This appliance must be earthed
Green and Yellow (Ear th)
Brown(Live)
Blue(Neutral)
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol( ) or coloured Green or Green and Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured Red.
If a 13 amp(BS 1363) plug is used, t a 13 amp BS 1362 fuse.
Fuse
Cord grip
2
