LG GR-L207-FLQ, GR-P207-FLQ User Manual

OWNER’S MANUAL

SXS REFRIGERATOR

Please read this manual carefully before operating your set and retain it for future reference.

P/N: MFL62880435

www.lg.com

Entry Important safety instruction Identification of parts

Where to install Door removal Door replacement Feed water pipe installation Height adjustment

Starting Adjusting the temperatures and functions

(Dispenser / Automatic ice maker) Refreshment center (Applicable to some models only) Shelf (Applicable to some models only) Wine holder (Applicable to some models only) Egg box (Applicable to some models only)

Location of foods Storing foods

How to dismantle parts General information Cleaning Trouble shooting

Table of contents

Introduction

Installation

Operation

Suggestion on

food storage

Care and

maintenance

3 3 5

9 10

10 11

12 13 18 19 19 19

22 24

24 25



This product is exclusive use at 230V/50Hz.



You should purchase transformer of more than 2.0KVA when you want to use it at the 110V area.



You can't use it anywhere except 50Hz area.

Introduction

Entry

The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information her e and r etain this guide as a permanent record of your purchase. Staple your r eceipt her e.

Date of purchase : Dealer purchased from : Dealer address : Dealer phone no. : Model no. : Serial no. :

Before it is used, this refrigerator must be properly installed and located in accordance with the installation instructions in this document.

Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull it straight out from the outlet.

When moving your appliance away from the wall, be careful not to roll over the power cord or to damage it in any way.

After your refrigerator is in operation, do not touch the cold surfaces in the freezer compartment

, particularly when your hands are damp or wet. Skin could adhere to

these extremely cold surfaces.

Unplug the power cord from the power outlet for cleaning or other requirements. Never touch it with wet hands because you can get an electric shock or be hurt.

Never damage, process, severely bend, pull out, or twist the power cord because damage the power cord may cause a fire or electric shock. You have doubts on whether the appliance is properly grounded.

Never place glass products in the freezer because they may be broken due to expansion when their contents are frozen.

Never allow your hands within the ice storage bin of the automatic ice maker. You could be hurt by the operation of the automatic ice maker.

The appliance is not intended for use by young children or infirm persons without supervision.

Young children should be supervised to ensure that they do not play with the appliance.

Never allow anyone to climb, sit, stand or hang on the refreshment center door. These actions may damage the refrigerator and even tip it over, causing severe personal injury.

If possible, connect the refrigerator to its own individual electrical outlet to prevent it and other appliances or household lights from causing an overload that could cause a power outage.

The refrigerator-freezer should be so positioned that the supply plug is accessible for quick disconnection when accident happens.

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

Do not modify or extend the Power Cord length.



It will cause electric shock or fire.

Important safety instruction

Don’t use an

extension cord

Accessibility of

Supply Plug

Supply Cord

Replacement

Warning

Introduction

This appliance contains a small amount of isobutane refrigerant (R600a), natural gas with high environmental compatibility, but it is also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or cause an eye injury. If a leak is detected, avoid any naked flames or potential sources of ignition and air the room in which the appliance is standing for several minutes.

In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be 1m2in size for every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identification plate inside the appliance. Never start up an appliance showing any signs of damage. If in doubt, consult your dealer.

Warning

Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

Do not damage the refrigerant circuit.

Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

The refrigerant and insulation blowing gas used in the appliance require special disposal procedures. When disposal, please consult with service agent or a similarly qualified person.

Introduction

Child entrapment

Warning

Don’t store

Warning

Grounding

(Earthing)

Warning

DANGER: Risk of child entrapment.

Before you dispose of your old refrigerator please remove doors but leave the shelves in place so that children cannot climb inside.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

this or any other appliance.

In the event of an electric short circuit, grounding (earthing) reduces the risk of electric shock by providing an escape wire for the electric current.

In order to prevent possible electric shock this appliance must be earthed. Improper

electrician or service engineer if the earthing instructions are not completely understood, or if you have doubts as to whether the appliance is properly earthed.

*Non dispenser model

Space plus

Door rack

Automatic

ice maker

Lamp

Shelf

Door rack

Drawer

Door rack

Lower cover

Freezer compartment

Refrigerator compartment

Milk product corner

Lamp

Shelf

Door rack

Shelf

Shelf (Folding or Normal)

Shelf

Door rack

Vegetable drawer

Door rack

Shelf

Conversion switch (Meats/Vegetables) (Optional)

NOTE

•

Parts, features, and options vary by model. Your model may not include every option.

*Dispenser model -Type1

Introduction

Space plus

Door rack

Automatic

ice maker

Lamp

Shelf

Door rack

Drawer

Door rack

Lower cover

Freezer compartment

Refrigerator compartment

Milk product corner

Lamp

Filter

Shelf

Door rack

Shelf

Shelf (Folding or Normal)

Shelf

Door rack

Vegetable drawer

Door rack

Shelf

Conversion switch (Meats/Vegetables) (Optional)

NOTE

•

Parts, features, and options vary by model. Your model may not include every option.

Introduction

*Dispenser model -Type2

Freezer compartment

Refrigerator compartment

Space plus

Door rack

Automatic

ice maker

Lamp

Shelf

Door rack

Drawer

Door rack

Lower cover

Milk product corner

Lamp

Filter

Shelf

Door rack

Shelf

Shelf (Folding or Normal) Guide Pitcher

Shelf

Door rack

Vegetable drawer

Door rack

Shelf

Conversion switch (Meats/Vegetables) (Optional)

NOTE

•

Parts, features, and options vary by model. Your model may not include every option.

Installation

Select a good

location

Where to Install

1. Place your appliance where it is easy to use.

2. Avoid placing the unit near heat sources, direct sunlight or moisture.

3. To ensure proper air circulation around the fridge freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall.

4. To avoid vibrations, the appliance must be leveled.

5. Don't install the appliance below 5°C. It may cause

affect the performance.

Disposal of the

old appliance

This appliance contains fluid (refrigerant, lubricant)and is made of parts and materials which are reusable and/or recyclable. All the important materials should be sent to the collection center of waste material and can be reused after rework (recycling). For take back, please contact with the local agency.

Installation

Warning

Remove lower

cover and

then feed water

tube

Remove the

freezer

compartment

door

Door removal

Electric Shock Hazard

Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury.

If your access door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally.

Remove the lower cover by lifting upward, and then pull up the feed water tube while pressing area shown in the gure to the right.

NOTE

•

If a tube end is deformed or abraded, cut the part away.

1) Removing the hinge cover by loosening the screws. Separate all connection wires except for the earth line after.

2) Remove the keeper by rotating it counter

)

clockwise ( hinge up (

and then lifting the upper

Upper hinge

Feed water tube

Hinge cover

Keeper

Connection wires

Earth line

Upper hinge

Lower cover

Remove the

refrigerator

door

NOTE

•

When removing the upper hinge, be careful that the door does not fall forwards .

3) Remove the freezer compartment door by lifting it upward. This time, the door should be lifted enough for the feed water pipe tube to be completely pulled out.

Lower hinge

NOTE

•

Move the refrigerator compartment door passing through the access door and lay it down, but be careful not to damage the feed water pipe tube.

1) Loosen the hinge cover screws and remove the cover. Remove connection wire, if any, except for the earth line.

Connection

wires

2) Remove keeper by rotating it clockwise (

)

Upper hinge

Keeper

and then remove the upper hinge by lifting it up ( ).

3) Remove the refrigerator compartment door by lifting it up.

Lower hinge
