Owner’s Manual

REFRIGERATORFREEZER

Please read carefully the manual instruction and safety caution before operating your refrigerator and retain it for future reference

P/No : MFL67377022

www.lg.com

CONTENTS

IMPORTANT SAFETY INFORMATION ................

INSTALLATION ........................................................

INNER PARTS

...........................................................

OPERATIONS ..........................................................

Starting

Before Setting The Temperature

Door Alarm

Self Test

Lamp Auto Off Feature

Controls For Refrigerator Compartment

Fast Freezing

Child Lock

Hygiene Fresh (Optional)

Controls For Freezer Compartment

Ice Making

Defrosting

Vegetable Drawer

Deodorizer (Optional)

Green Ion Door Cooling (Optional)

SUGGESTIONS ON FOOD STORAGE ...............

CLEANING .................................................................

GENERAL INFORMATION ....................................

LAMP REPLACEMENT ...........................................

IMPORTANT WARNINGS .....................................

BEFORE CALLING FOR SERVICE

......................

EARTH/ GROUNDING CONSTRUCTION

(OPTIONAL)

..............................................................

IMPORTANT SAFETY INFORMATION

WARNING

Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

Do not damage the r

Do not use electrical appliances inside the food storage compartment of the appliance, unless they are of the type recommended by the manufacturer.

The refrigerant and insulation blowing gas used in the appliance require

special disposal procedures. When disposal, please consult with services agent or a similarly qualified person.

This appliance contains a small amount of isobutane refrigerant (R600a),

natural gas with high environmental compatibility, but it is also combustible.

When transporting and installing the appliance, care should be taken to ensure

that no parts of the refrigerating circuit are damaged. Refrigerant squirting out

of the pipes could ignite or cause an eye injury. if a leak is detected, avoid any

naked flames or potential sources of ignition and air the room in which the

appliance is standing for several minutes.

efrigerant circuit.

In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. The room must be

1 m in size for every 8g of R600a refrigerant inside the appliance. The amount

of refrigerant in your particular appliance is shown on the identification plate

inside the appliance. Never start up an appliance showing any signs of damage.

if in doubt, consult your dealer.

IMPORTANT SAFETY INFORMATION

BASIC SAFETY PRECAUTIONS

This guide contains many important safety messages. Always read and obey all safety messages.

This is the safety alert symbol. It alerts you to safety messages that inform you of hazard

that can hurt you or others or cause damage to the product. All safety messages will be

preceded by the safety alert symbol and the hazard signal word WARNING, or CAUTION. These words mean:

WARNING CAUTION

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

You will be hurt or seriously injured if you don't follow instructions.

It indicates an imminent hazardous situation which, if not avoided, may result in minor or moderate injury, or product damage.

WARNING

To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance.

1. When connecting the power

Do not use many power outlets.

A separate outlet should be used. Using several devices at one outlet may cause fire.

Do not allow the power plug to face upward or to be squeezed at the back of the refrigerator.

Water on the plug or plug damage can cause fire or electric shock.

Prevent the power cord from being squeezed or imprinted if the refrigerator is pushed in after the power plug is extracted during the installation.

It becomes the cause of fire or electric shock.

Make sure the mains cable is not bent or trapped under a heavy object. It may damage the cable and cause fire or electric shock.

IMPORTANT SAFETY INFORMATION

1. When connecting the power

Do not change the mains cable and do not change its length. It may damage the cable and cause fire

or electric shock.

If the mains cable is damaged it must be replaced by a service agent or a similarly qualified person in order to avoid hazard.

To unplug the refrigerator, pull

the end of the plug and not

the cable.

Extraction by the cord may

cause electric shock or short

circuit and fire.

o not pull out the cable or touch the power

plug with wet hands.

• It may cause electric

shock or injury.

Unplug the power plug when cleaning, handling or replacing the interior lamp of the refrigerator.

• It may cause electric shock or injury.

• When replacing the interior lamp

of the refrigerator, make sure that the rubber ring for preventing the electric spark within the socket is not taken off.

Remove water or dust from the plug and securely connect it to the socket.

Dust, water or looseness in connection may cause fire or electric shock.

After unplugging the appliance, wait for 5 minutes or longer before reconnecting the plug.

It may cause the

operation of the freezer

After

5minutes

to fail.

The appliance must be earthed.

Incorrect grounding

may cause breakdown or electric shock.

Ground

Wire

Copper

Flat

Be sure to use grounded exclusive proper

voltage consent for the power plug.

Be sure to use grounded extension consents

when extension consents are used.

may cause breakdown

It becomes the cause of fire.

When the power cord or the power plug is damaged or the holes of the outlet are loosed, do not use them.

It may cause electric shock or short circuit to make fire.

More than

30 inches

IMPORTANT SAFETY INFORMATION

2. When using the refrigerator

Do not place heavy or dangerous objects such the top of the appliance.

When opening or closing the door it may fall and cause injury, fire or electric shock.

Do not cling to the doors, door baskets, drawers or shelves.

These may cause the refrigerator to fall or lead to hand injuries. Especially, do not allow the children to do the above.

Prevent children from entering the product.

It may endanger the life of a child if the child enters the refrigerator.

Opening and closing the door of the refrigerator vigorously may cause the stored food in the refrigerator basket to fall by

shock and hurt the foot, so take precautions.

Deterioration of insulation of electric parts may cause short circuit or electric shock.

Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.

It may cause fire, electric shock

or injury by dropping down.

Do not use or store inflammable materials such as ether, benzene, alcohol, LP gas, spray or cosmetics near or in the refrigerator.

It may cause explosion or fire.

Do not store medicine or scientific materials in the appliance.

Storing materials with strict temperature limitations may cause deterioration of the materials or other unexpected reaction

and may be riskfull.

The Academic

Medicine

The Medicine

Benzene

Ether

Thinner

IMPORTANT SAFETY INFORMATION

2. When using the refrigerator

Do not use drier to dry the inside, nor light a candle to remove odor.

It may cause explosion or fire.

Do not use the combustible spray near the refrigerator.

It may cause fire.

In case of thunder and lightning, or not in use for a long period of time, detach the power plug.

There is a danger of

electric shock or fire.

Don't use heating devices close to the appliance.

It may cause fire.

Do not use the submerged refrigerator directly,

It may cause electric shock or fire.

kindly checked by the technician.

Do not spray water on the outside or inside of the refrigerator and do not clean it with solvents.

Deterioration of insulation of electric parts may cause electric shock or fire.

ThinnerThinner

When gas is leaked, do not touch the

refrigerator or the outlet and ventilate the room immediately.

- The explosion by spark may cause fire or burn.

- Because this refrigerator uses natural gas as the environtment-friendly refrigerant, even as small amount is combustible. When the gas is leaked by the severe damage during delivering, installing or using the refrigerator, any spark may cause fire or burn.

IMPORTANT SAFETY INFORMATION

2. When using the refrigerator

Only qualified technician should disassemble, repair or alter the refrigerator.

When disposing the refrigerator, remove the gasket from the doors and leave the shelves on their places.

Otherwise a child may be

locked inside.

Install the refrigerator on the solid and level floor.

The appliance should be installed on a plane surface to prevent

it from falling and causing injuries.

When any strange smell or smoke is detected from the refrigerator, disconnect the power plug immediately and

Down-block

office

Service

center

contact to the service center.

It may cause fire.

Do not use the refrigerator for non-domestic purpose (storing medicine or testing material, using at the ship, etc.).

It may cause an unexpected risk such as fire,

shock, deterioration of stored material or chemical reaction.

electric

What to do with your old refrigerator,

Your refrigerator contain liquid (refrigerant,

lubricant) made of recylable materials. All these materials must bes sent to a recycling

waste disposal site as they can be reused after a specific recycling process. Refrigerator Contact local authoritie.

Do not put hands or other things in the air holis, under the cover, into the holes at the back of the refrigerator

It may cause electric shock

or injury

Completely empty inside before taking out the container from the door.

IMPORTANT SAFETY INFORMATION

2. When using the refrigerator

Do not remove the cover on the back.

Place all the components in the right places

before connecting the power.

Do not use an Adapter on the back.

Never leave lit candles or incense on the fridge, at risk of causing fire or product damage.

CAUTION

Violating this direction may cause injury or damage house or furniture. Always be careful, please.

Do not touch food or containers at the freezer with wet hands.

It may cause frostbite

Do not put bottle into the freezer.

Frozen contents may break the bottle and cause injury.

To carry the refrigerator hold handles on the front bottom and rear top sides.

Otherwise, your hands may be slipped to cause injury.

Because the product is

heavy, carrying it alone may hurt people or accidents may occur.

Do not place the food in disorder inside the refrigerator.

The food may fall during opening and closing the door of the refrigerator and hurt people.

Do not put hands under the refrigerator.

The iron plate of the bottom may cause injury.

Please, be careful opening or closing the doors of the refrigerator. It may cause injuries to other people.

A hand or a foot can be caught between the door and case when

opening or closing the refrigerator child can

be hurt by a corner of

the door

IMPORTANT SAFETY INFORMATION

Do not put any living animal in the refrigerator.

It may cause the animal died.

Avoid the contact of oil or fat on the plastic parts. They may cause damage.

When the power cord is damaged, let a technician to replace

it to remove the danger of an accident.

Technician

Do not lean on the doors, Hinges may deregulate Themselves, harming

seal cooler and compromising performance.

Do not use products such as grinding sponge, brush, iron, or even special products to clean stainless steel, soap products such as alcohol, kerosene, gasoline, wax, or solvent, or strong chemicals such as chlorine, detergent, or

vinegar, for the purpose of gloss. These products may damage the protective lacquer, and they may cause risk or stain on the surface of the

Strong

Chemicals

for steelfor steel

ProductsProducts

refrigerator.

Do not apply oil in the door connection part in any circumstances. It may cause damage to the plastic parts.

oiloiloil

Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance

WARNING

Please do not use a dishwasher to clean the lower drawers; the high temperature may cause

damage to the baskets which make them unusable.

THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY.

WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY.

BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY

IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS.

INSTALLATION

1. Select a good location.

Place your refrigerator where it is easy to use.

2.Avoid placing the unit near heat sources,

direct sunlight or moisture.

3.To ensure proper air circulation around the

fridge - freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall.

4. To avoid vibrations, the unit must be level.

If required, adjust the leveling screws to compensate for unevenness of the floor. The front should be slightly higher than the rear to aid in door closing. Leveling screws can be turned easily by tipping the cabinet slightly. Turn the leveling screws clockwise( ) to raise the unit, counterclockwise( ) to lower it.

5. Don't install this appliance below 5°C. It may

cause the debasement of the refrigerator.

1. Clean your refrigerator thoroughly and wipe off all dust accumulated during shipping.

2. Install accessories such as ice cube box, etc.,

in their proper places. They are packed together to prevent possible damage during shipment.

3. Connect the power supply cord (or plug) to

the outlet. Don't double up with other appliances on the same outlet.

4. Prior to storing food, leave your refrigerator

on for 2 or 3 hours. Check the flow of cold air in the freezer compartment to ensure proper cooling. Your refrigerator is now ready for use.

INNER PARTS

INTERNAL CONTROLLER MODEL

FREEZER

COMPARTMENT

Lamp

Twisting Ice Serve

Type Ice Making

Freezer Temperature Control Dial

Shelf

REFRIGERATOR

COMPARTMENT

Temperature

Refrigerator

Control

Lamp

Shelves

(Optional)

Vegetable Drawer

NOTE

Freezer Door Rack

Egg Tray

MIN

Refrigerator Door Rack

Levelling Screw

- This guide covers several different models. The refrigerator you have purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves

supplied by manufactureris the most efficient usage for energy saving.

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

INNER PARTS

EXTERNAL CONTROLLER MODEL

FREEZER

COMPARTMENT

Lamp

Twisting Ice Serve

Type Ice Making

Freezer Temperature Control Dial

Shelf

REFRIGERATOR

COMPARTMENT

Deodorizer

(Optional)

Fresh Zone

(Optional)

Lamp

Shelves

(Optional)

Hygiene Fresh

(Optional)

Vegetable Drawer

- This guide covers several different models. The refrigerator you have

NOTE

Freezer Door Rack

Dairy Corner

REF. TEMP. CONTROL

MIN MAX

(Optional)

Egg Tray

Green Ion Door Cooling

Refrigerator Door Rack

Levelling Screw

purchased may have some or all of the features shown above.

- To keep a position of inner parts like as baskets, drawers and shelves

supplied by manufactureris the most efficient usage for energy saving.

SUGGESTION FOR ENERGY SAVING

- Please do not keep the door open for a long time, close door in the shortest time.

- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.

- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature

sensor.

- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.

Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause temperature to rise.

OPERATIONS

STARTING

When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods.

If operation is interrupted, wait 5 minutes before restarting.

BEFORE SETTING THE TEMPERATURE

●

The temperature of the refrigerator is kept constant regardless of changes in room temperature.

It is recommended that, once set, the temperature settings(the controls for the refrigerator and freezer compartments) not be changed unless necessary.

●

This refrigerator has one temperature control button for the refrigerator compartment and one

temperature control dial for the freezer compartment.

●

The default setting of the temperature control button for the refrigerator compartment is ‘3°C’.

●

The default setting of the temperature control dial for the freezer compartment is ' '.

●

This refrigerator has a temperature sensor in the refrigerator compartment. It will start and stop

the compressor automatically as needed.

DOOR ALARM

When the door of the refrigerator or the freezer is open for 1 minute, an alarm will sound three times.

It the door remains open, the alarm will repeat every 30 seconds.

SELF TEST

●

Your refrigerator contains a built in diagnostic capability. If it develops a malfunction in certain areas,

it will display an error code to assist the repair technician. While an error code is displayed, other control and display functions will not operate.

●

If an error code is displayed, contact a service center. Do not disconnect the power cord from

the outlet.

LAMP AUTO OFF FEATURE

When the door is open for 7 minutes or longer, the lamp inside goes off automatically to save energy

and prevent overheating. However, the alarm sound continues until the door is closed.

CONTROLS FOR REFRIGERATOR COMPARTMENT

FOR INTERNAL CONTROLLER MODEL

REF. TEMP. CONTROL

Ref. Temp Control Button

The default setting of the temperature control button for the refrigerator compartment is NORMAL.

To control the refrigerator temperature, press the REF. TEMP CONTROL button.

Whenever pressing the button, LED emitting the light. The temperature is set in 7 steps, from MIN to MAX.

cooling.(MIN = warmest, MAX = coldest temperature)

OPERATIONS

FOR EXTERNAL CONTROLLER MODEL

Display graphic can be different, depend on the type of your refrigerator.

Type a

●

Type b

●

Press 'REFRIGERATOR' button to control refrigerator temperature.

●

Whenever pressing the button, the LED emits light.

●

Press ‘HYGIENE FRESH’ button to operate hygiene motor (optional).

● The number showing up on the LED luminesce indicate the temperature of refrigerator compartment.

●

You can select the desired setting point seven steps, from '0 C' to '6oC'.

●

Type a

- Press

Press

Press button for 5 seconds, then hygiene filter replacement periode is RESET.

button, refrigerator temperature will be down each 1 C.

ⓑ

button, Hygiene Fresh motor will be on, power mode, off.

ⓐ

- The RESET icon will turn on if hygiene filter need to be changed, please contact service center.

●

Type b

- Press ⓐ button, refrigerator temperature will be down each 1 C.

ⓑ

Press

button, refrigerator temperature will be up each 1 C.

FAST FREEZING

●

The FAST FREEZING feature operates when the refrigerator first turn on. The compressor and circulating fan

operate at maximum cooling capacity to quickly lower the refrigerator temperature. It shuts off automatically.

●

If warm food is placed into the refrigerator, FAST FREEZING can be started with the button

on the control panel. FAST FREEZING will shut off when the temperature reaches

the proper level or it can be shut off manually by pressing the FAST FREEZING button.

CHILD LOCK (OPTIONAL)

●

CHILD LOCK

Press and hold the CHILD LOCK button

for 3 seconds to lock the child lock.

When it is locked, the Lock LED will be on

and the other button will not operate. To

unlock, press and hold the CHILD LOCK

button for 3 seconds again.

OPERATIONS

HYGIENE FRESH (OPTIONAL)

CAUTION

Before installing or using the product, make sure to read the owner's manual carefully to use the product accurately as intended. This HYGIENE FRESH filter has the antibacterial function of removing the virus or bacteria inside the refrigerator and the deodorizer function to remove the scent. The function has tested and has been certificated by authorized institutions

Life of the filter is about 1 to 2 years. (The life of the filter may vary by the environment of the

consumer.)

●

How to remove existing filter

When the RESET lamp is turned on, replace the filter.

When the “RESET” lamp is turned on, replace the

•

filter to maintain the performance of the HYGIENE FRESH filter.

To replace the filter, press the

•

button

to switch to OFF mode.

Hold the filter cover and rotate counterclockwise to

•

separate the cover. Pull out the HYGIENE FRESH

REF. TEMP. CONTROL

MIN MAX

filter inserted inside the filter cover.

Intertek

During use notify

time to RESET

When switched

over to OFF mode

●

How to install the new filter

Install the new filter.

•

Insert the new HYGIENE FRESH filter in the separated filter cover so that the hooks around the filter are visible.. (If the filter is inserted in reverse direction, it will not be assembled.)

•

Insert the filter cover to its original position and then turn clockwise by 30 degrees to lock the filter cover.

You can purchase the HYGIENE FRESH filter at the nearest distributor or the service center.

OPERATIONS

●

Set replacement timing (Initialization)

After the user replaces the filter, the user can set the time for the next replacement.

Close the refrigerator door and press the

•

button on the display panel on the front side of the he front side of the door for more than 5 seconds to check that the RESET lamp on the display panel is turned off.

●

Switch over to use mode

Switch over to use mode.

During use notify

time to RESET

When switched

over to OFF mode

To use the HYGIENE FRESH filter, press the

•

door and switch over to the AUTO or POWER mode. (Whenever you press the button, the HYGIENE FRESH filter will be switched to OFF

POWER OFF.)

OFF AUTO POWER OFF

CAUTION

When the user switches to AUTO or POWER mode, the LED around the filter is also turned on. Open the door to check whether the LED around the filter is also turned on. Do not put in your finger or alien particles inside the fan. It can be caused of an injury or malfunction.

CAUTION

Do not wash the HYGIENE FRESH filter by using water because It can be caused of malfunction.

•

If the user continuously use the filter after the time to RESET, It can be caused of malfunction.

•

This filter may not be effective for all types of bacteria and virus.

•

This is effective to remove the bacteria which is not on the food in the refrigerator.

•

button on the display panel on the front side of the

AUTO

You can purchase the HYGIENE FRESH filter at the nearest distributor or the service center.

OPERATIONS

CONTROLS FOR FREEZER COMPARTMENT

●

The higher number the control setting is, the lower the

FREEZER CONTROL

FREEZER MIN

NORMAL

3 7

FREEZER MAX

432

●

Setting the Freezer Knob at will satisfy 4 STAR. Setting the Freezer Knob at NORMAL will have sufficient freezing effect, so it is recommended to set the Knob at NORMAL.

ICE MAKING

Twisting Ice Serve Type

●

To make ice cubes, fill the ice tray with water and

insert in its position.

●

To remove ice cubes, hold the lever of the tray and pull turn gently. Then, ice cubes drop in to the ice cube box.

temperature of the freezer compartment becomes.

●

Since the temperature of the refrigerator and freezer compartments is controlled with a fixed amount of cooled air, the refrigerator compartment will be warmer if the freezer compartment

●

When the freezer compartment is not cold enough in winter,

set to be

adjust the control for the freezer to High

colder.

(4~7).

Ice Trays

NOTE

You can disassemble the Ice Maker to secure space in the freezer.

Ice Cube Box

• Twisting Ice Serve Type: Remove 1 and 2.

1. Ice Tray

2. Ice Cube Box.

WARNING

• Do not use anything other than water.

• Fill the water up to the marked line..

DEFROSTING

●

Defrosting takes place automatically.

●

The defrosted water flows down to the evaporating tray which located in the lower back side of the refrigerator and is evaporated automatically.

OPERATIONS

VEGETABLE DRAWER

Vegetable Partitioner

●

Fix the partitioner by inserting it at the rear side of vegetable box as shown in the figure.

How to use

●

Vegetable drawer can be used through the control of knob.

●

Check the position of knob prior to store the food.

●

Do not locate the knob on the middle point.

Partitioner

DEODORIZER (OPTIONAL)

●

Unpleasant odor of food in fresh food compartment is deodorized with no harm to you and the food.

How to use

• As Deodorizer is located in cooling air inlet for circulating air in fresh food compartment, there is

no need for any handling.

• Do not prick the cooling air inlet with a sharp tip because Deodorizer may be damaged.

• When storing food with a strong odor, wrap it or store it in a container with a lid because odor may be

passed on to other foods.

Re-Using of Deodorizer

• Used some length and the odor is strong,

Deodorizer can be revived and re-used.

• Separate Deodorizer in ceiling of refrigerator

compartment, using hair drier to remove moisture or malodor and oxidize under sunlight to decomposing malodor by ultraviolet.

GREEN ION DOOR COOLING

(OPTIONAL)

The anion coating in the duct cover purifies the air and helps stored foods remain fresh longer.

If water of foreign substances enter the cool air vent while cleaning, efficiency will be lowered. In addition, if gasket is damaged, efficiency may be lowered owing to the escape of cool air.

Cool air vent

SUGGESTIONS ON FOOD STORAGE

STORING FOOD

●

Store fresh food in the refrigerator compartment. How food is frozen and thawed is an

important factor in maintaining its freshness and flavor.

●

Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and melons.

●

Allow hot food to cool prior to storing. Placing hot food in the refrigerator could spoil other food, and lead to higher electric bills!

●

When storing the food, cover it with vinyl wrap or store in a container with a lid. This prevents moisture from evaporating, and helps food to keep its taste and nutrients.

●

Do not block air vents with food. Smooth circulation of chilled air keeps refrigerator temperatures

even.

●

Do not open the door frequently. Opening the door lets warm air enter the refrigerator, and cause temperatures to rise.

FREEZER COMPARTMENT

●

Do not store bottles in the freezer compartment - they may break when frozen.

●

Do not refreeze food that has been thawed. This causes loss of taste and nutrition.

●

When storing frozen food like ice cream for a long period, place it on the freezer shelf, not in the door rack.

● Loading for Freezing - It is recommended to load newly introduced foods on the following

position for freezing:

●

Freezer Door Basket, marked ( storage of frozen food (optional).

) is -12°C compartment, that is suitable for short term

REFRIGERATOR COMPARTMENT

●

Avoid placing moist food on deep interior refrigerator shelves, it could freeze upon direct contact with chilled air. To avoid this it is better to store food in the covered container.

●

It is desirable to store moist food (especially vegetable and fruit) in the vegetable storage compartment. If it is necessary to store on a shelf of the refrigerator, put it close to the door away from the back wall of the refrigerator to avoid being frozen by the cool circulating in the refrigerator.

●

Always clean food prior to refrigeration. Vegetables and fruits should be washed and wiped, and packed food should be wiped clean, to prevent adjacent food from spoiling.

●

When storing eggs in their storage rack, ensure that they are fresh, and always store them in a up-right position, which keeps them fresh longer.

CLEANING

It is important that your refrigerator be kept clean to prevent undesirable odors. Spilled food should be wipe up immediately, since it may acidify and stain plastic surfaces if allowed to settle.

Never use metallic scouring pads, brushes, coarse abrasive cleaners or strong alkaline solutions on any surface.

Before you clean, however, remember that damp objects will stick or adhere to extremely cold surfaces. Do not touch frozen surfaces with wet or damp hands.

EXTERIOR - Use a lukewarm solution of mild

soap or dish washable solution to clean the durable finish of your refrigerator. Wipe with a clean, damp cloth and then dry.

For products with a stainless steel exterior, use a clean sponge or soft cloth and a mild Detergent in warm water. Do not use abrasive or harsh cleaners. Dry thoroughly with a Soft cloth. Do not use appliance wax, bleach, or other products containing chlorine on stainless steel.

INTERIOR - Regular cleaning of the interior and

interior parts is recommended. Use a lukewarm solution of mild soap or dish washable solution to clean the durable finish of your refrigerator. Wipe with a clean, damp cloth and then dry.

INTERIOR PARTS - Wash compartment

shelves, door racks, storage trays and magnetic door seals etc. Use a lukewarm solution of mild soap or dish washable solution to clean the durable finish of your refrigerator. Wipe with a clean damp cloth and then dry.

WARNING

Always remove power cord from the wall outlet prior to cleaning in the vicinity of electrical parts(lamps, switches, controls, etc.). Wipe up excess moisture with a sponge or cloth to prevent water or liquid from getting into any electrical part and causing electric shock. Do not use flammable or toxic cleaning liquids.

• Caution for Cleaning Not in use : Surface

active agent, Car wax, Anticorrosive, All sorts of oil, Gasoline, Acids, Wax.

• Usable Detergent Vegetable dish washable

solution, Soapy water.

• When careless using, it can occur a color

change.

GENERAL INFORMATION

VACATION TIME

During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan to be away for an extended period, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation.

POWER FAILURE

Most power failures are corrected in an hour or two and will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off. During power failures of longer duration, place a block of dry ice on top of your frozen packages.

This appliance is intended to be used in household and similar applications such as:

- Staff kitchen areas in shops, offices and other working environments.

- Farm houses and by clients in hotels, motels and other residential type environments.

- Bed and breakfast type environments.

- Catering and similar non-retail applications.

IF YOU MOVE

Remove or securely fasten down all loose items inside the refrigerator. To avoid damaging the leveling screw(s), turn them all the way into the base.

ANTI-CONDENSATION PIPE

The outside wall of the refrigerator cabinet may sometimes get warm, especially just after installation. Don't be alarmed. This is due to the anticondensation pipe, which pumps hot refrigerant to prevent "sweating" on the outer cabinet wall.

Caution

Electrical Shock Hazard Before replacing a burned-out light bulb,

either unplug the refrigerator or turn off power at the circuit breaker or fuse box.

NOTE :Moving the control to the OFF position does not remove power to the light circuit.

LAMP REPLACEMENT

NOTE

● This product use LED lamp which not intend to be replaced by user, please contact

authorized service center for lamp replacement.

IMPORTANT WARNINGS

DO NOT USE AN EXTENSION CORD

If possible, connect the refrigerator to its own individual electrical outlet to prevent it and other appliances or household lights from causing an overload that could cause a power outage.

ACCESSIBILITY OF SUPPLY PLUG

The refrigerator-freezer should be so positioned that the supply plug is accessible for quick disconnection when accident happens.

SUPPLY CORD REPLACEMENT

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

VERY DANGEROUS ATTRACTION

An empty refrigerator can be a dangerous attraction to ch latches, lids or the entire door from your unused appliance, or take some other action to make it harmless.

ildren. Remove either gaskets,

ABOUT GROUNDING (EARTHING)

In the event of an electric short circuit, grounding (earthing) reduces the risk of electric shock by providing an escape wire for the electric current.

In order to prevent possible electric shock, this appliance must be grounded.

Improper use of the grounding plug can result in

an electric shock. Consult a qualified electrician or service person if the grounding instructions are not completely understood, or if you have doubts on whether the appliance is properly

grounded.

DO NOT MODIFY OR EXTEND THE POWER CORD LENGTH.

It will cause electric shock or fire.

This appliance must be grounded (earthed).

DON'T WAIT! DO IT NOW!

Do not store inflammable materials, explosives

or chemicals in the refrigerator.

WARNING

This appliance is not intended for use by person (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

DISPOSAL OF THE OLD APPLIANCE

This appliance contains fluid (refrigerant, lubricant) and is made of parts and materials which are reusable and/or recyclable.

All the important materials should be sent to the collection center of waste material and can be

reused after rework (recycling). For take back, please contact with the local agency.

BEFORE CALLING FOR SERVICE

SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE

POSSIBLE CAUSES FIRST :

PROBLEM POSSIBLE CAUSES

REFRIGERATOR DOES NOT OPERATE

REFRIGERATOR OR FREEZER COMPARTMENT TEMPERATURE TOO WARM

●

Has a house fuse blown or circuit breaker tripped?

●

Has the power cord plug been removed or loosened from the electrical wall outlet?

●

Temperature control not set on proper position.

●

Appliance is placed close to wall or heat source.

●

Warm weather-frequent door openings.

●

Door left open for a long time.

●

Large amount of foods are kept in the refrigerator.

ABNORMAL NOISE(S)

REFRIGERATOR HAS ODOR

DEW FORMS ON THE CABINET SURFACE

●

Refrigerator is installed in a weak or uneven place, or leveling screw needs adjusting.

●

Unnecessary objects placed in the back side of the refrigerator.

●

Foods with strong odors should be tightly covered or wrapped.

●

Interior needs cleaning.

●

Not unusual during periods of high humidity.

●

Door may have been left ajar.

DISPOSAL OF YOUR OLD APPLIANCE

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

+ 56 hidden pages
