Owner’s Manual
REFRIGERATORFREEZER
Please read this manual carefully before operating
your set and retain it for future reference
G*-B352C***
G*-B392C***
BZ03
P/NO : MFL63747335
001
www.lg.com
003
Page 2
IMPORTANT SAFETY INFORMATION ................ 3
CONTENTS
INSTALLATION .......................................................... 9
INNER PARTS ..................................................... 10
OPERATIONS .................................................... 11
Starting
Controls
Controls For Freezer Compartment
Ice making
Fresh zone
Vegetable Drawer
Defrosting
Deodorizer (optional)
For Refrigerator Compartment
SUGGESTIONS ON FOOD STORAGE .............. 14
CLEANING ................................................................
15
GENERAL INFORMATION ................................... 15
LAMP REPLACEMENT .......................................... 16
I
MPORTANT WARNINGS ..................................... 17
BEFORE CALLING FOR SERVICE ..................... 18
• The working life of this set is 7 years since the date of
delivery to consumer.
2
Page 3
IMPOR TANT SAFETY INFORMATION
BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages. Always read and obey all safety
messages.
This is the safety alert symbol. It alerts you to safety messages that inform you of hazard
that can kill or hurt you or others or cause damage to the product. All safety messages will be
preceded by the safety alert symbol and the hazard signal word DANGER, WARNING, or
CAUTION. These words mean:
DANGER
WARNING
CAUTION
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell
you what can happen if the instructions are not followed.
You will be killed or seriously injured if you don't follow instructions.
You will be killed or seriously injured if you don't follow instructions.
indicates an imminently hazardous situation which, if not avoided, may
result in minor or moderate injury, or product damage only.
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety
precautions should be followed, including the following.
Read all instructions before using this appliance.
1. When connecting the power
The dedicated outlet should be used.
• Using several devices at
one outlet may cause fire.
• The electric leakage
breaker may damage food
and the dispenser may be
leaked.
Do not allow the power plug to face upward
or to be squeezed at
the back of the
refrigerator.
Water may be flown into
or the plug may be
damaged, which causes
fire or electric shock.
Do not allow the power cord bent or pressed
by the heavy object to
be damaged.
It may damage the power
cord to cause fire or
electric shock.
Do not extend or modify the length of the
power plug.
It causes electric shock or
fire by the electric damage of
the power cord or others.
3
Page 4
IMPORTANT SAFETY INFORMATION
1. When connecting the power
Unplug the power plug when cleaning,
handling or replacing the interior lamp of the
refrigerator.
• It may cause electric shock or injury.
• When replacing the interior lamp
of the refrigerator, make sure
that the rubber ring for
preventing the electric spark
within the socket is not taken off.
Remove water or dust from the power plug
and insert it with the ends of the pins
securely connected.
Dust, water or unsta
ble
connection may fire or
electric shock.
When the power cord or the power plug is
damaged or the holes of
the outlet are loosed, do
not use them.
It may cause electric shock or
short circuit to make fire.
o not pull out the cord or touch the power
D
plug with wet hands.
• It may cause electric
shock or injury.
Make sure of grounding.
The incorrect grounding
may cause breakdown
and electric shock.
Ground
Wire
Copper
Flat
More than
30 inches
2. When using the refrigerator
Do not place the heavy object or the
dangerous object
(container with liquid) on
the refrigerator.
It may be dropped to cause
injury, fire or electric shock when
opening or closing the door.
Do not cling to the door or the shelves of the
door or the home bar of the freezer or the
cool chamber.
It may make the refrigerator
fallen down or damage the
hands. Especially, do not
allow the children to do the
above.
4
Page 5
IMPOR TANT SAFETY INFORMATION
2. When using the refrigerator
Do not install the refrigerator in the wet
place or the place which
water or rain splashes.
Deterioration of insulation of
electric parts may cause
electric leakage.
Do not place the lit candle within the
refrigerator to deodorize.
It may cause explosion or fire.
Do not use the combustible spray near the
refrigerator.
It may cause fire.
Do not use or store inflammable materials
ether, benzene, alcohol, medicine, LP gas,
spray or cosmetics
near or in the
refrigerator.
It may cause explosion
or fire.
Benzene
Do not store the medicine or the academic
materials at the refrigerator.
When the material with
the strict temperature
control is stored, it may be
deteriorated or it may
make an unexpected
reaction to cause any risk.
The Academic
Medicine
The Medicine
Avoid the heating devices.
It may cause fire.
Ether
Thinner
Do not place flower vase, cup, cosmetics,
medicine or any container
with water on the
refrigerator.
It may cause fire, electric shock
or injury by dropping down.
Use the submerged refrigerator after
checking it.
It may cause electric
shock or fire.
5
Page 6
IMPORTANT SAFETY INFORMATION
2. When using the refrigerator
Do not spray water at the outside or the
inside of the refrigerator or do not clean it
with benzene or
thinner.
Deterioration of insulation of
electric parts may cause
electric shock or fire.
ThinnerThinner
Do not allow any person except the qualified
engineer to disassemble, repair or alter the
refrigerator.
It may cause injury,
electric shock or fire.
When disposing the refrigerator, remove the
packing materials from
the door.
It may cause to lock
child.
out the
When any strange smell or smoke is
detected from the refrigerator, disconnect
the power plug
immediately and
Service
center
contact to the
service center.
It may cause fire.
Do not use the refrigerator for non-domestic
purpose (storing medicine or testing
material, using at the ship, etc.).
It may cause an unexpected
risk such as fire,
shock, deterioration of
stored material or chemical
reaction.
electric
Install the refrigerator on the solid and level
floor.
Installing it on the unstable
place may cause death by
falling down the refrigerator
when opening or closing the
door.
6
Page 7
IMPORTANT SAFETY INFORMATION
2. When using the refrigerator
Do not insert the hands or the metal stick
into the exit of cool air, the cover, the bottom
of the refrigerator, the heatproof grill
(exhaust hole) at the
backside.
It may cause electric
shock or injury.
When you want to dispose the refrigerator,
contact to the down-block office.
When you want to dispose
the large living waste such
as electric home appliance
and furniture, you'd better
contact the local downblock office.
Down-block
office
CAUTION
Violating this direction may cause injury or damage house or furniture. Always be careful, please.
Do not touch food or containers at the
freezer with wet
hands.
It may cause frostbite
Wait for 5 minutes or longer when
reconnecting the plug.
It may cause the operation
of the freezer to fail.
Do not put bottle in the freezer.
It may freeze the contents to
break the bottle to cause
injury.
After
5minutes
Pull out the power plug not by grasping the
cord but the plug of its
end.
It may cause electric shock or
short circuit to fire.
7
Page 8
IMPORTANT SAFETY INFORMATION
CAUTION
Violating this direction may cause injury or damage house or furniture. Always be careful, please.
Do not install the refrigerator in the wet
place or the place which water or rain
splashes.
Deterioration of insulation of
electric parts may cause
electric leakage.
Carry the refrigerator with the handle bar at
the bottom of the front and the top of the
rear.
Otherwise, your hands
may be slipped to cause
injury.
Do not put any living animal in the
refrigerator.
Do not insert the hands into the bottom of
the refrigerator.
The iron plate of the bottom
may cause injury.
Because opening or closing the door of the
refrigerator may cause injury to the person
around it, be careful, please.
Opening or closing the
door may cause feet or
hands to be caught in
the chink
child to be get hurt by
the corner.
in door or the
8
Page 9
9
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE
LATEST IN TECHNOLOGY.
WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE
AND RELIABILITY.
BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY
IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND
MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS.
INSTALLATION
.
1. Select a good location.
Place your refrigerator where it is easy to
use.
2.Avoid placing the unit near heat sources,
direct sunlight or moisture.
3.To ensure proper air circulation around the
fridge - freezer, please maintain sufficient
space on both the sides as well as top and
maintain at least 2 inches (5 cm) from the
rear wall.
4.To avoid vibrations, the unit must be level.
If required, adjust the leveling screws to
compensate for unevenness of the floor.
The front should be slightly higher than the
rear to aid in door closing.
Leveling screws can be turned easily by
tipping the cabinet slightly.
Turn the leveling screws clockwise( ) to
raise the unit, counterclockwise( ) to
lower it.
5. Don't install this appliance below 5°C. It may
cause the debasement of the refrigerator.
NEXT
1. Clean your refrigerator thoroughly and wipe
off all dust accumulated during shipping.
2. Install accessories such as ice cube box, etc.,
in their proper places. They are packed
together to prevent possible damage during
shipment.
Connect the power supply cord (or plug) to
3.
the outlet. Don't double up with other
appliances on the same outlet.
Prior to storing food, leave your refrigerator
4.
on for 2 or 3 hours.
Check the flow of cold air in the freezer
compartment to ensure proper cooling.
Your refrigerator is now ready for use.
Page 10
INNER PARTS
FREEZER
COMPARTMENT
Freezer Temperature
Control Dial
Shelf
Twisting Ice Serve
REFRIGERATOR
COMPARTMENT
Deodorizer (Optional)
Fresh Zone
Refrigerator Temperature
Electronic Control
Vitamin Kit (Optional)
Vegetable Drawer
NOTE
To keep a position of inner parts like as baskets, drawers and shelves supplied by manufacturer
is the most efficient usage for energy saving.
Lamp
Shelves
●
This guide covers several different models. The refrigerator you have
purchased may have some or all of the features shown above.
Freezer Door Rack
Egg Storage Rack
Refrigerator
Door Rack
Leveling Screw
Suggestion for energy saving
- Please do not keep the door open for a long time, close door in the shortest time.
- Too much food are not advised to be put in. Enough space should be kept for cool air circulating freely.
- Do not set the temperature of refrigerator lower than needed. Do not put the food near the temperature
sensor.
- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and
lead to higher electric bills.
- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer temperature even.
- Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer, and cause
temperature to rise.
10
Page 11
OPERATIONS
STARTING
When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures
prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.
CONTROLS FOR REFRIGERATOR COMPARTEMENT
REF. TEMP. CONTROL
MIN MAX
Ref. Temp Control Button
(COLDEST)
CONTROLS FOR FREEZER COMPARTMENT
• FREEZER CONTROL- 1, 2, 3, 4, 5, 6, 7, 8
Setting at "8", the freezer compartment becomes colder.
But the refrigerator compartment becomes warmer because less cold air
flows into the refrigerator compartment.
• In cold weather the unit operates less and the freezer compartment
has a tendency to warm up.
For colder freezer, turn the FREEZER CONTROL to "7"~"8".
• If you take a lot of foods in the freezer or open its door frequently its temperature is apt to be somewhat
higher. In this case, set the FREEZER CONTROL dial between 7 and 8 to cool it. Return the FREEZER
CONTROL dial to the original position to cut down the consumption
.
• In hot weather or to put much foods in the refrigerator compartment, the refrigerator compartment has
a tendency to warm up. For colder refrigerator, turn the FREEZER CONTROL to "2"~"4" to direct more
cold air into the refrigerator compartment, and the REFRIGERATOR TEMP. CONTROL to "MAX" or "0".
Setting at "7"~"8" of the FREEZER CONTROL, the refrigerator compartment will not be cold enough.
Setting the Freezer Knob at will satisfy 4 STAR. Setting the Freezer Knob at NORMAL will
•
have sufficient freezing effect, so it is recommended to set the Knob at NORMAL.
The default setting of the temperature control button for
the refrigerator compartment is NORMAL .
To control the refrigerator temperature, press the REF.
TEMP CONTROL button.
When the button is pressed, the LEDs light.
The temperature is set in 5 steps, from MIN to MAX.
cooling.(MIN = warmest, MAX = coldest temperature)
11
Page 12
ICE MAKING (OPTIONAL)
To remove ice cubes, hold the lever of the tray
and pull turn gently. Then, ice cubes drop int to
the ice cube box.
To make ice cubes, fill the ice tray with water
and insert in its position.
Twisting Ice Serve Type
General Type
To make ice cubes, fill the ice tray with water and
place it on the ice cube box. Then insert the ice
cube box in the freezer compartment.
To remove ice cubes, hold the tray at its end
and twist gently.
Choose the type of ice Making you have.
Ice Trays
Ice Cube Box
Ice Trays
Ice Cube Box
OPERATIONS
ICE MAKING
Twisting Ice Serve Type
To make ice cubes, fill the ice tray with water
and insert in its position.
To remove ice cubes, hold the lever of the tray
and pull turn gently. Then, ice cubes drop into
the ice cube box.
FRESH ZONE
●
When the door is opened, the warmer air doesn't influence
in the fresh zone. So you can keep food fresher in it.
VEGETABLE DRAWER
MAGIC CRISPERS
Magic Crispers provide fresher-tasting fruit and vegetables
by letting you easily keep humidity inside the vegetable
drawer.
A lattice on the underside of the cover to efficiently hold or
release moisture.
Sealing structure keep the humidity.
Ice Trays
Ice Cube Box
Absorb Release
moisture moisture
Overly Humid
humid deficiency
VITAMIN KIT (OPTIONAL)
M
I
N
A
T
I
K
V
I
T
It contains anti-oxydant that is able to avoid
oxidation process in order to make the fruits and
vegetables fresh for longer time.
This part contains anti-oxydant substance that do not to eat.
Opening and closing the door too much often can reduce its lifetime.
12
T
V
I
I
K
T
A
N
I
M
Page 13
OPERATIONS
DEFROSTING
●
Defrosting takes place automatically.
●
The defrosted water flows down to the evaporating tray which located in
the lower back side of the refrigerator and is evaporated automatically.
DEODORIZER (OPTIONAL)
Unpleasant odor of food in fresh food
●
compartment is deodorized with no harm to
you and the food.
How to use
• As Deodorizer is located in cooling air inlet for circulating air in fresh food compartment, there is
no need for any handling.
• Do not prick the cooling air inlet with a sharp tip because Deodorizer may be damaged.
• When storing food with a strong odor, wrap it or store it in a container with a lid because odor may be
passed on to other foods.
Re-Using of Deodorizer
• Used some length and the odor is strong,
Deodorizer can be revived and re-used.
• Separate Deodorizer in ceiling of refrigerator
compartment, using hair drier to remove
moisture or malodor and oxidize under sunlight
to decomposing malodor by ultraviolet.
13
Page 14
SUGGESTIONS ON FOOD STORAGE
STORING FOOD
●
Store fresh food in the refrigerator compartment. How food is frozen and thawed is an
important factor in maintaining its freshness and flavor.
●
Do not store food which goes bad easily at low temperatures, such as bananas, pineapples,
and melons.
●
Allow hot food to cool prior to storing. Placing hot food in the refrigerator could spoil other
food, and lead to higher electric bills!
●
When storing the food, cover it with vinyl wrap or store in a container with a lid. This prevents
moisture from evaporating, and helps food to keep its taste and nutrients.
●
Do not block air vents with food. Smooth circulation of chilled air keeps refrigerator temperatures
even.
●
Do not open the door frequently. Opening the door lets warm air enter the refrigerator, and
cause temperatures to rise.
FREEZER COMPARTMENT
●
Do not store bottles in the freezer compartment - they may break when frozen.
●
Do not refreeze food that has been thawed. This causes loss of taste and nutrition.
●
When storing frozen food like ice cream for a long period, place it on the freezer shelf, not in
the door rack.
●
It is recomended to load food at least 15mm against freezer wall, it will keep good air
circulation in the freezer compartment.
● Loading for Freezing - It is recommended to load newly introduced foods on the following
position for freezing:
Newly Introduced Food
●
Freezer Door Basket, marked (
storage of frozen food (optional).
) is -12°C compartment, that is suitable for short term
REFRIGERATOR COMPARTMENT
●
Avoid placing moist food on deep interior refrigerator
shelves, it could freeze upon direct contact with chilled
air. To avoid this it is better to store food in the covered
container.
●
It is desirable to store moist food (especially vegetable
and fruit) in the vegetable storage compartment. If it is
necessary to store on a shelf of the refrigerator, put it
close to the door away from the back wall of the
refrigerator to avoid being frozen by the cool circulating in the refrigerator.
●
Always clean food prior to refrigeration. Vegetables and fruits should be washed and wiped,
and packed food should be wiped clean, to prevent adjacent food from spoiling.
●
When storing eggs in their storage rack, ensure that they are fresh, and always store them
in a up-right position, which keeps them fresh longer.
14
Page 15
CLEANING
It is important that your refrigerator be kept clean to
prevent undesirable odors. Spilled food should be
wipe up immediately, since it may acidify and stain
plastic surfaces if allowed to settle.
Never use metallic scouring pads, brushes, coarse
abrasive cleaners or strong alkaline solutions on
any surface.
Before you clean, however, remember that damp
objects will stick or adhere to extremely cold
surfaces. Do not touch frozen surfaces with wet or
damp hands.
EXTERIOR - Use a lukewarm solution of mild soap
or dish washable solution to clean the durable
finish of your refrigerator. Wipe with a clean, damp
cloth and then dry.
INTERIOR - Regular cleaning of the interior and
interior parts is recommended. Use a lukewarm
solution of mild soap or dish washable solution to
clean the durable finish of your refrigerator. Wipe
with a clean, damp cloth and then dry.
GENERAL INFORMATION
VACATION TIME
During average length vacations, you will probably
find it best to leave the refrigerator in operation.
Place freezable items in freezer for longer life.
When you plan to be away for an extended period,
remove all food, disconnect the power cord, clean
the interior thoroughly, and leave each door OPEN
to prevent odor formation.
POWER FAILURE
Most power failures are corrected in an hour or two
and will not affect your refrigerator temperatures.
However, you should minimize the number of door
openings while the power is off. During power
failures of longer duration, place a block of dry ice on
top of your frozen packages.
IF YOU MOVE
Remove or securely fasten down all loose items
inside the refrigerator.
To avoid damaging the leveling screw(s), turn them
all the way into the base.
INTERIOR PARTS - Wash compartment shelves,
door racks, storage trays and magnetic door seals
etc. Use a lukewarm solution of mild soap or dish
washable solution to clean the durable finish of
your refrigerator. Wipe with a clean, damp cloth
and then dry.
WARNING
Always remove power cord from the wall outlet
prior to cleaning in the vicinity of electrical
parts(lamps, switches, controls, etc.).
Wipe up excess moisture with a sponge or
cloth to prevent water or liquid from getting into
any electrical part and causing electric shock.
Do not use flammable or toxic cleaning liquids.
• Caution for Cleaning Not in use : Surface
active agent, Car wax, Anticorrosive, All sorts
of oil, Gasoline, Acids, Wax.
• Usable Detergent Vegetable dish washable
solution, Soapy water
• When careless using, it can occur a color
change.
ANTI-CONDENSATION PIPE
The outside wall of the refrigerator cabinet may
sometimes get warm,
especially just after
installation.
Don't be alarmed.
This is due to the anticondensation pipe, which
pumps hot refrigerant to
prevent "sweating" on the
outer cabinet wall.
Electrical Shock Hazard
Before replacing a burned-out light bulb,
either unplug the refrigerator or turn off
power at the circuit breaker or fuse box.
NOTE :Moving the control to the OFF position
does not remove power to the light circuit.
15
Anti - Condensation
Caution
Page 16
LAMP REPLACEMENT
REFRIGERATOR LAMP
1. Unplug the power cord from the outlet.
2. Remove refrigerator shelves.
3. To remove the lamp cover insert
under hole of the lamp cover and pull it out forwards
4. Turn the lamp counterclockwise.
5. Assemble in reverse order of diassembly. Replacement bulb must be the same
specification as original.
type driver at the corner of
16
Page 17
IMPORTANT WARNINGS
DO NOT USE AN EXTENSION CORD
If possible, connect the refrigerator to its own In the event of an electric short circuit, grounding
individual electrical outlet to prevent it and other (earthing) reduces the risk of electric shock by
appliances or household lights from causing an providing an escape wire for the electric current.
overload that could cause a power outage.
ACCESSIBILITY OF SUPPLY PLUG
The refrigerator-freezer should be so positioned that
the supply plug is accessible for quick disconnection
when accident happens.
ABOUT GROUNDING (EARTHING)
In order to prevent possible electric shock, this
appliance must be grounded.
Improper use of the grounding plug can result in
an electric shock. Consult a qualified electrician
or service person if the grounding instructions
are not completely understood, or if you have
doubts on whether the appliance is properly
SUPPLY CORD REPLACEMENT
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
VERY DANGEROUS ATTRACTION
An empty refrigerator can be a dangerous
attraction to ch
latches, lids or the entire door from your
unused appliance, or take some other action
to make it harmless.
ildren. Remove either gaskets,
DO NOT MODIFY OR EXTEND THE
POWER CORD LENGTH
It will cause electric shock
or fire.
This appliance must be grounded (earthed).
.
DON'T WAIT! DO IT NOW!
Do not store inflammable materials, explosives
or chemicals in the refrigerator.
WARNING
This appliance is not intended for use by person (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
DISPOSAL OF THE OLD APPLIANCE
This appliance contains fluid (refrigerant, lubricant) and is made of parts and materials which are
reusable and/or recyclable.
All the important materials should be sent to the collection center of waste material and can be
reused after rework (recycling). For take back, please contact with the local agency.
“The equipment complies with requirements of the Technical Regulation, in terms of restrictions
for the use of certain dangerous substances in electrical and electronic equipment.”
19
17
Page 18
BEFORE CALLING FOR SERVICE
SERVICE CALLS CAN OFTEN BE AVOIDED!
IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE
CAUSES FIRST :
PROBLEM POSSIBLE CAUSES
REFRIGERATOR DOES
NOT OPERATE
REFRIGERATOR OR FREEZER
COMPARTMENT TEMPERATURE
TOO WARM
●
Has a house fuse blown or circuit breaker tripped?
●
Has the power cord plug been removed or loosened
from the electrical wall outlet?
●
Temperature control not set on proper position.
●
Appliance is placed close to wall or heat source.
●
Warm weather-frequent door openings.
●
Door left open for a long time.
●
Large amount of foods are kept in the refrigerator.
ABNORMAL NOISE(S)
●
Refrigerator is installed in a weak or uneven place, or
leveling screw needs adjusting.
●
Unnecessary objects placed in the back side of the
refrigerator.
REFRIGERATOR
HAS ODOR
DEW FORMS ON THE
CABINET SURFACE
●
Foods with strong odors should be tightly covered or
wrapped.
●
Interior needs cleaning.
●
Not unusual during periods of high humidity.
●
Door may have been left ajar.
DISPOSAL OF YOUR OLD APPLIANCE
1. When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from
the municipal waste stream via designated collection facilities appointed by
the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please
contact your city office, waste disposal service or the shop where you
purchased the product.
• Information of fluorinated greenhouse gases
used as refrigerant of this refrigerator.
Chemical Name
R-134a
Composition of Gases
100% HFC-134a
Total GWP (kg CO2-eq)
1300
18
Loading...
