Please read this manual carefully before operating
your set and retain it for future reference.
P/NO.:MFL67783522
www.lg.com
Introduction
Connection
Registration
Important Safety Instruction
Identification of Parts
Installation
Connection
4
5
9
10
10
Operation
CARE AND
MAINTENANCE
Control panel
• Temperature control
• Express freeze
• “Lock” (Optional)
• ECO MODE(Optional)
• Self-test
Removal and installation of detachable glass shelf
Removal and installation of drawer in refrigeration
comparment
Removal and installation of drawer
in freezing comparment
Ice preparation
Foodstuff storage
Energy-Saving Method
Cleaning
General
Refrigerator operation features
12
13
13
14
14
14
15
15
16
16
17
17
17
18
18
Trouble Shooting
SMART DIAGNOSIS(Option)
Trouble Shooting
Disposal of your old appliance
SMART DIAGNOSIS(Optional)
3
19
20
21
Registration
The model and serial number are found on
the rear ofthis unit. This number is unique
to this unit and notavailable to others.
You should record requestedinformation
here and retain this guide as a
permanent record of your purchase.
Staple your receipt here.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
:
:
:
:
:
:
Important Safety Instruction
This is the safety alert symbol. It alerts you to
safety messages that inform you of hazards that
can kill or hurtyou or others or cause damage to
the product. All safety messages will be preceded
by the safety alert symbol and the hazard signal
word DANGER, WARNING, or CAUTION.
These words mean:
WARNING!
You can be killed or seriously injured if you
don’t follow instructions.
CAUTION!
Indicates an imminently hazardous situation
which,minor or moderate injury, or product
damage only.
WARNING!
• Before it is used,this refrigerator must be
properly installed and located in accordance
with the installation instructions in this
document.
• All safety messages will identify the hazard,
tell you how to reduce the chance of injury,
and tell you what can happen if the
instructions are not followed.
• To reduce the risk of fire, electric shock, or
injury to persons when using your product,
basic safety precautions should be followed,
including the following. Read all instructions
before using this appliance.
•
If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order
to avoid a hazard.
Introduction
When connecting the power:
The dedicated outlet
should be used.
Using several devices at one
outlet may cause fire.
The electric leakage breaker
may damage food and the dispenser
may be leaked.
Water may be flown into or
the plugmay be damaged,
which causes fire or electric
shock.
Do not allow the power cord bent or pressed
by the heavy object to be
damaged.
NO
It may damage the power
cord to cause fire or
electric shock.
Do not extend or modify the length of the
power plug.
It causes electric shock or fire
NO
by the electric damage of the
power cord orothers.
Do not pull out the cord or touch the
power plug with wet hands.
It may cause electric shock
or injury.
Remove water or dust from the power plug
and insert it with the ends of the pins
securely connected.
Dust, water or unstable
connection may fire or
electric shock.
Make sure of grounding.
Consult a qualified electrician or service
person if the grounding instructions are
not completely understood, or if you have
doubts on whether the appliance is properly
grounded or not.
The incorrect grounding
may cause breakdown
and electric shock.
4
Copper flat
Ground wire
More than
30 inches
Introduction
When the power cord or the power plug is
damaged or the holes of the outlet are
loosed, donot use them.
It may cause electric shock or
short circuitto make fire.
When using the fridge-freezer:
Do not place the heavy object or the
dangerous object (container with liquid)
on the fridge-freezer.
It may be dropped to cause
injury, fire or electric shock
when opening or closing the
door.
Do not cling to the door or the shelves
of the door or the home bar of the
freezer or the cool chamber.
It may make the fridge-freezer
NO
fallen down or damage the
hands. Especially,do not allow
the children to do theabove.
Do not install the fridge-freezer
in the wet place orthe place
which water or rain
NO
splashes.
Deterioration of insulation of
electric parts may cause electric
leakage.
Do not use or store inflammable materials
ether,benzene, alcohol, medicine, LP gas,
spray or cosmetics near
or in the fridge-freezer.
It may cause explosion
or fire.
Do not put any living animal
NO
in the fridge-freezer.
Do not place the lit candle with in the
fridge-freezer to deodorize.
Do not use drier to dry the
NO
inside, nor light a candle to
remove odor.
It may cause explosion or fire.
Do not store the medicine or the academic
materials at the fridge-freezer.
When the material with the strict temperature
control is stored, it may be deteriorated or
it may make an unexpected
reaction to cause any risk.
NO
Use the submerged fridge-freezer after
checking it.
It may cause electric shock
or fire.
When gas is leaked, do not touch the
fridge-freezer or the outlet and ventilate
the room immediately.
The explosion by spark
may cause fire or burn.
Because this fridge-freezer
uses natural gas
(isobutene, R600a) as
the environment-friendlyrefrigerant, even a
small amount(80~90g) is combustible.
When the gas is leaked by the
severe damage during delivering, installing or
using thefridge-freezer, any spark may cause
fire or burn.
Do not spray water at the outside or the
inside of the fridge-freezer or do not clean
it with benzene or thinner.
Deterioration of insulation of
electric parts may cause
electric shock or fire.
NO
Thinner
5
Carry the fridge-freezer with the handle
bar at the bottom of the front
and the top of the rear.
Otherwise, your hands
may be slipped to cause
injury.
Introduction
Because opening or closing the door
of the fridge-freezer may cause
injury to the person around it,
becareful, please.
Opening or closing the
NO
door may cause feet or
hands to be caught in the
chink in door or the child to
be get hurt by the corner.
When any strange smell or smoke is
detected from the fridge-freezer,
disconnect the power plug immediately
and contact to the service center.
It may cause fire.
Service center
Do not allow any person except the
qualified engineer to disassemble,
repair or alter the
fridge-freezer.
NO
It may cause injury,
electric shock orfire.
Install the fridge-freezer on the solid
and level floor.
Installing it on the unstable
place may cause death by
falling down the
fridge-freezer when opening
or closing the door.
Do not insert the hands or the metal stick
into the exit of cool air, the cover, the
bottom of the fridge-freezer,
the heatproof grill
(exhaust hole) at
NO
the backside.
It may cause electric
shock or injury.
Avoid the heating devices. Install in
places away from the fire such as the
place where flammable gas is leaked.
It may cause fire.
NO
Do not insert the hands into the bottom
of the fridge-freezer.
The iron plate of the bottom
may cause injury.
Do not use the fridge-freezer for
non-domestic purpose (storing medicine
or testing material, using at the ship, etc.).
It may cause an unexpected
risk such as fire, electric shock,
NO
deterioration of stored material
or chemical reaction.
Do not touch food or containers at the
freezer with wet hands.
It may cause frostbite.
6
NO
Introduction
CAUTION!
Violating this direction may cause injury or
damage house or furniture.
Always be careful, please.
When you want to dispose the
fridge-freezer,contact to the
down-block office.
When you want to dispose
the large living waste such
Down-block
office
as electric home appliance
and furniture,you’d better
contact the local down-block
office.
Do not touch food or containers at
the freezer with wet hands.
It may cause frostbite.
NO
Wait for 5 minutes or longer when
reconnecting the plug.
It may cause the operation
NO
of the freezer to fail.
After
5 minutes
Pull out the power plug not by grasping
the cord but the plug of itsend.
It may cause electric shock or
shortcircuit to fire.
Do not use the combustible spray near
the fridge-freezer.
Do not store explosive
NO
substances such as
aerosol cans with a
flammable propellant in
this appliance.
It may cause fire.
Unplug the power plug when cleaning,
handling or replacing the interior lamp of
the fridge-freezer.
It may cause electric
shock or injury.
When replacing the
interior lamp of the
fridge-freezer, make sure
that therubber ring for preventing the
electric spark within the socket is not taken off.
In case of thunder and
lightning, or not in use for
along period of time, detach
thepower plug.
There is a danger of electric
shockor fire.
Do not place flower vase, cup, cosmetics,
medicine or any container with water on
the fridge-freezer.
It may cause fire, electric
shock or injury by dropping
down.
NO
Upon opening or closing of the door,
unstable objects may overturn, fall, and
result in injury.
It may cause fire, electric
NO
shock or injury by dropping
down.
The power outlet should be easily
accessible for the event of necessary
quick disconnection.
When one door of the refrigerator is
closed abruptly, another door may open,
since the refrigerator compartments are
connected by air ducts.
7
Introduction
CAUTION!
This appliance is intended to be used in
household and similar applications such
as staff kitchen areas in shops, offices
and other working environments; farm
houses and by clients in hotels, motels
and other residential type environments;
bed and breakfast type environments;
catering and similar non-retail
applications.
CAUTION!
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
WARNING!
Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
WARNING!
The refrigerant and insulation blowing gas
used in the appliance require special disposal
procedures. When disposal, please consult
with service agent or a similarly qualified
person.
WARNING!
Do not use mechanical devices or other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
WARNING!
Do not damage the refrigerant circuit.
WARNING!
Do not use electrical appliances inside the
food storage compartments of the appliance,
unless the yare of the type recommended by
the manufacturer.
This appliance contains a small amount
of isobutane refrigerant (R600a), natural
gas with high environmental compatibility,
but it is also combustible. When
transporting and installing the appliance,
care should be taken to ensure that no
parts of the refrigerating circuit are
damaged. Refrigerant squirting out of the
pipes could ignite or cause an eye injury.
If a leak is detected, avoid any naked
flames or potential sources of ignition and
air the room in which the appliance is
standing for several minutes.
In order to avoid the creation of a flammable
gas air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which
the appliance may be sited depends on the
amount of refrigerant used. The room must be
2
1m in size for every 8g of R600a refrigerant
inside the appliance. The amount of
refrigerant in your particular appliance is
shown on the identification plate inside the
appliance.
Never start up an appliance showing any
signs of damage. If in doubt, consult your
dealer.
8
Introduction
Identification of Parts
Utility Corner
(not in all models)
(not in all models)
Removable glass
shelf (2 or 3)
refrigeration system
Vitamin Plus system
(not in all models)
vegetables and fruits
freezing compartment
Height-adjustable foot
Display
Lamp
Multi-flow
Drawer for
Ice tray
Drawers of
Egg tray
Door baskets
(4 or 5)
Door basket for
2L bottles
NOTE
Parts,features,and options vary by model.Your model may not include every option.
9
INSTALLATION
• Install the limit stops to the upper corners
on the rear wall of the refrigerator as shown
in Fig.1. The stops are supplied in the door
basket inside the refrigeration compartment;
• Choose the suitable place. Locate the
refrigerator in a place convenient for its
use;
• The refrigerator is not a built-in appliance.
Free space not less than 5 cm should be
provided from above, from its rear and side
faces for air circulation and reduction of
power consumption. Fig.2;
• Do not install the refrigerator near heat
sources and in a zone exposed to direct
sunlight or high humidity;
• Make sure that electrical voltage indicated
in the manual meets the parameters of
your mains;
• Do not remove the round stickers on the
rear side of the refrigerator.
They have a decorative function closing
the fabrication holes;
• To exclude vibration, check the refrigerator
installation using a level. If necessary, turn
the adjustable feet to compensate irregularity
of the floor.
To ensure better closing of the door, the
refrigerator should be slightly inclined
backwards. To turn the adjustable feet,
slightly incline the refrigerator.
To raise the front part of the refrigerator,
turn the adjustable feet counter-clockwise
( )to lower it – turn them clockwise( );
Connection
• Before use, carefully wash the refrigerator;
• Install the removable parts, such as ice tray,
etc. to the appropriate places.
It is necessary to prevent possible damages
during transportation;
• Insert the power cord plug to the power
outlet. Do not power other electric appliance
from the same outlet.
CONNECTION
After first installation of the refrigerator, let it
work for 2-3 hours for stabilization of the
operating temperature inside and only then
fill the refrigerator with fresh or frozen
foodstuffs. After disconnection of the
refrigerator from the mains, wait at least 5
minutes to switch on it again. Now, the
refrigerator is ready for service.
Lamp Replacement
•
If LED lamp is damaged,it should be replaced
by the service center in stead of on your own.
• To ensure proper air circulation around the
fridge -freezer, please maintain sufficient
space on both the sides as well as top and
maintain at least 2 inches (5cm) from the
rear wall.
10
Connection
forward backward
Figure 1. Installation of limit stops
Figure 2. Installation of refrigerator to wall
NOTE
The limit stops are located in the door basket of the
refrigeration compartment.
They should be installed to get higher operational efficiency
of the refrigerator.
11
CONTROL PANEL
External light-emitting-diode
(LED) display
Operation
Temperature control in
freezing compartment
Express freeze
Internal display
Express freeze Temperature control in
freezing compartment
Temperature control in
refrigeration compartment
LED display lock button
Temperature control
in refrigeration compartment
Economy mode
12
Operation
TEMPERATURE CONTROL
The initial temperature in the refrigeration
and freezing compartments is 3 °C and -20 °C,
respectively.
If you wish, you can change it pushing the
temperature control button of the appropriate
compartment.
External LED display
Internal LED display
EXPRESS FREEZE
It is used, if it is necessary to expressly freeze
foodstuffs.
Push once the "express freeze"
button (on the external display) or
"express freeze" button (on the internal display).
The "EXPRESS FREEZE" lamp will light up and
express freezing will be started. Express freeze
takes about 24 hours.
Upon completion of this operation, the
refrigerator automatically goes to the previous
state (earlier set temperature mode).
If you wish to stop the express freeze operation,
push again once the
"express freeze" button
(on the external display) or once the
"express freeze" button (on the internal display).
The lamp will extinguish, the express freeze
operation will be stopped, and the refrigerator
will return to the previous state
(previous temperature mode).
External LED display
БЫСТР. ЗАМОР.
NOTE
Temperature indicated on the LED display
is a target value, since actual temperature
inside the refrigerator varies depending on
intensity of exposure to external factors,
such as temperature of placed foodstuffs
and door opening frequency.
After switching on, the refrigerator reaches
the set mode for 2-3 days.
Internal LED display
13
Operation
ECO MODE (Optional )
It activates the power saving mode, which is
convenient in the event of your long departure.
It allows you to reduce power consumption.
Push once the "Economy mode" button
(on the internal display).
The lamp will light up (ECO MODE).
Repeated pushing of the button
deactivates this function.
Internal LED display
NOTE
When the "ECO MODE" is activated,
other buttons are inoperative. Push the
"ECO MODE" button to return the
appliance to the previous temperature
mode.
NOTE
For power saving, the external display is
switched to the energy conservation
mode – backlighting of all indicators
except for "LOCK" extinguishes.
"LOCK" (Optional)
• When the "LOCK" button is activated, other
buttons are inoperative;
• To lock/unlock the refrigerator display, push
the "LOCK" button and hold it for 3 seconds.
Lock Unlock Unlock
NOTE
In the event of power cutoff, the mode
settings are kept.
SELF-TEST
The display has a self-test function.
If the refrigerator has a failure, the buttons
become inoperative and the indicator shows
the error code. In this case, do not switch
off power and immediately contact the local
service center.
If you switch off the refrigerator, a service
engineer may need much time to find the
faulty element.
14
Operation
REMOVAL AND INSTALLATION OF
DETACHABLE GLASS SHELF
To remove a shelf from the refrigerator, first
slightly raise it (1) and then pull (2). Improper
removal may result in damage of internal
parts in the refrigerator.
To install a shelf to the refrigerator, proceed
in the same way: first raise the front edge of
the shelf (3) and then push it to the
refrigerator (4). Improper installation may
result in damage of internal parts in the
refrigerator.
REMOVAL AND INSTALLATION OF
DRAWER IN REFRIGERATION
COMPARTMENT
To remove the lower drawer from the
refrigeration compartment, proceed as follows:
• Remove the lower basket from the door
raising the basket;
• Pull the drawer all the way out raising it by
the front part and pulling;
• Raise the drawer cover by the front part
and pull to remove it;
1
• To install the drawer back, proceed in the
reverse sequence.
CAUTION!
At that, you should take care to exclude slant.
Improper removal and installation may result
in damage of internal parts in the refrigerator.
15
NOTE
The guarantee does not cover mechanical
damages (cracks, shears, dents, traces of
enclosure opening, etc.) caused by
violation of the refrigerator storage,
transportation, operation, and
maintenance rules, application of
excessive force.
REMOVAL AND INSTALLATION OF
DRAWERS IN FREEZING
COMPARTMENT
When a large quantity of foodstuffs is stored
in the freezing compartment, you can remove
the middle drawer from the appliance and
store foodstuffs immediately on foodstuffs
placed to the lower drawer.
To remove any drawer of the freezing
compartment, proceed as follows:
1. Pull the drawer all the way out;
2. Raise it by the front part and pull.
Operation
2
1
3
CAUTION!
Do not apply excessive force to remove the
drawers and shelves – this may result in
damage of the refrigerator.
ICE PREPARATION
Fill the ice tray with water and place it to
the freezing compartment.
2
1
To install any drawer back to the freezing
compartment, proceed in the reverse
sequence:
1. Place the drawer onto the guides at
an angle 45°;
2. Lower the front part of the drawer in
parallel to the guides;
3. Push the drawer all the way in.
At that, you should take care to exclude
slant.
If ice cubes are required as soon as possible,
activate the "Express Freeze" function.
To remove ice cubes, hold the tray on ends
and slightly bend it.
WARNING
Fill with potable water only.
To easily remove cubes, water the tray in
advance.
16
CARE AND MAINTENANCE
FOODSTUFF STORAGE
• Do not store food which goes bad easily at
low temperature, such as banana, and melon.
• Allow hot food to cool prior to storing.
Placing hot food in the fridge-freezer could
spoil other food, and lead to higher electric bills.
• When storing the food, use a container
with a lid. This prevents moisture from
evaporating, and helps food to keep its
taste and nutrients.
• Do not block air vents with food.
Smooth circulation of cold air keeps
fridge-freezer temperature even.
• Do not open the door frequently. Opening
the door lets warm air enter the fridge-freezer,
and cause temperature to rise.
• To adjust the temperature control easily,
do not store food near the temperature
control dial.
• Never keep too many foods in door rack,
as this may stop the door from fully closing.
• Do not store bottles in the freezer
compartment - they may break when frozen.
• Do not refreeze food that has been thawed.
This causes loss of taste and nutrition.
• If it is necessary to quickly freeze fresh
foodstuffs, place them to the lower drawer
of the freezing compartment and push
the "Express Freeze" button;
• Frozen foodstuffs should be stored packed
(in polyethylene film, aluminum foil, etc.) in
the freezing compartment;
• Volume of the upper drawer in the freezing
compartment is the "two stars" section.
Temperature inside this section does not
rise above -12°C. This should be taken into
account for storage of foodstuffs.
Energy-Saving Method(optional)
• Install the fridge in a shady,cool and
well-ventilated place.
• Do not open and close the door frequently
if not necessary.
• Please do not keep the door open for a
long time, close door in the shortest time
Allow hot food to cool prior to storing.
•
• Too much food are not advised to be put in.
Enough space should be kept for cool air
circulating freely.
•
Do not set the temperature of refrigerator
lower than needed.
Do not put the food near the temperature
sensor.
•
Food need’t store is not advised to be put in.
•
Place the deep-frozen food for thawing
intorefrigerator; they can be used for cooling
the refrigerator.
（Applicabe to some models only
•
Do not block air vents with food.
）
（ Applicabe to some models only）
CLEANING
1. Before cleaning, make sure that power
supply is switched off;
2. Outside and inside, the refrigerator should
be washed with a clean napkin wetted in
warm water with a liquid detergent.
Then wipe dry with a dry napkin;
3. After cleaning, make sure that the power
cord is not damaged.
Then tightly insert the plug to the power
outlet.
CAUTION!
1.
It is prohibited to use abrasive materials,
gasoline, benzene, solvents, hydrochloride,
hot water, hard brushes, etc., which may
damage the refrigerator surface.
2. For products with a stainless steel exterior,
use a clean sponge or soft cloth and a
mildDetergent in warm water.
Do not use abrasive or harsh cleaners.
Dry thoroughly with a Soft cloth.
Do not use appliance wax, bleach, or other
products containing chlorine on stainless
steel.
VITAMIN PLUS (OPTIONAL)
It contains anti-oxydant that is able to avoid
oxidation process in order to make the fruits
and vegetables fresh for longer time.
This part contains anti-oxydant substance that
should not be eaten.Opening and closing the
door too much often can reduce its lifetime.
17
CARE AND MAINTENANCE
GENERAL
Electric power failure.
• An interruption in electric power supply for
1-2 hours will not harm the stored foodstuffs.
Try to less frequently open and close the
refrigerator door during this period.
DURING MOVE:
• Remove all foodstuffs and other objects
from the refrigerator. Firmly secure the
internal detachable parts
(shelves, drawers, door baskets);
• To avoid damage of the floor and adjustable
feet of the refrigerator, turn them
counter-clockwise before transportation;
• The refrigerator should be firmly secured in
the truck to prevent its hits and falling
inside the truck during transportation;
• The refrigerator should be transported in
vertical position in a covered vehicle.
The original package should not be
damaged during transportation;
• During loading and unloading, the
refrigerator should be protected against hits.
BEFORE SWITCHING ON:
• If the refrigerator is transported in cold
season, unpack the refrigerator in a warm
room and do not switch on it for at least
12 hours.
CAUTION!
Do not move or incline the refrigerator during
its operation.
Noise may occur in the compressor.
This feature does not affect operability of
the compressor.
REFRIGERATOR OPERATION
FEATURES
Cracking noise may be heard due to thermal
deformations of the refrigerator components.
Typical sounds from activation of the
thermostatic controller and compressor are
normal sounds occurring during operation of
electric equipment in the appliance.
The refrigerant circulating inside the
refrigeration system may calmly gurgle,
even if the compressor is idle.
Do not worry, this is absolutely normal.
The following sounds may be heard during
operation of the refrigerator:
- Clicks from actuation of the temperature
sensor/switch;
- Murmur of the refrigerant circulating in tubes
of the refrigeration system;
- Slight cracking noise from thermal
deformations of materials.
These sounds are not associated with any
defect and they have a functional aspect.
ANTI-CONDENSATION TUBE:
• The anti-condensation tube is laid inside
the enclosure around the front face of the
refrigerator to exclude moisture
condensation;
• The refrigerator may greatly heat up in
these places, especially immediately after
switching on for the first time or at high
ambient temperature.
Anti-condensation tube
18
Trouble Shooting
Before calling for service, check this list.
It may save you both time and expense.
This list includes common occurrences that are not the result of defective workmanship
or materials in this appliance.
Problem Possible Causes
Fridge-Freezerdoes
not operate
Fridge or Freezer
Compartment
Temperature too warm
Vibration or Rattling
or Abnormal Noise
Frost or IceCrystals
on frozenFood
Moisture
forms on Cabinet Surface
• Power plug may be unplugged from the electricoutlet.
Plug it in securely.
• House fuse has blown or circuit breaker hastripped.
Check and/or replace fuse and reset circuit breaker.
• Power cut.
Check house lights.
• Temperature control not set on proper position.
Refer to Temperature Control section.
• Appliance is placed close to heat source.
• Warm weather-frequent door openings.
• Door left open for a long time.
• Package holding door open or blocking air
duct in freezer compartment.
• The floor on which the fridge-freezer is installed may
be uneven or the fridge-freezer may beunstable.
Make it even by rotating the leveling screw.
• Unnecessary objects placed in the back side of
the fridge-freezer.
Door may have been left ajar or package holding
•
door open.
• Too frequent or too long door openings.
• Frost within package is normal.
• This phenomenon is likely to occur in a wet space.
Wipe it with a dry towel.
Moisture collects inside • Too frequent or too long door openings.
• In humid weather, air carries moisture into
fridge when doors are opened.
19
Problem Possible Causes
Fridge has odor
Door not closing properly
Interior light does
not work
Trouble Shooting
• • Foods with strong odors should be tightly
covered or wrapped.
Check for spoiled food.
• Interior needs cleaning.
Refer to CLEANING section
• Food package is keeping door open.
Move packages that keep door from closing.
• Fridge-freezer is not level.
Adjust the leveling screws.
• The floor on which the fridge-freezer is installed
may be uneven or the fridge-freezer may be unstable.
Slightly raise the front side with the leveling screw.
• No power at outlet.
• Light lamp needs replacing.
Refer to the Lamp Replacement section
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached
to a product it means the product is covered by the
European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed
of separately from the municipal waste stream via
designated collection facilities appointed by the
government or the local authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of your
old appliance, please contact your city office, waste
disposal service or the shop where you purchased the
product.
.
20
SMART DIAGNOSIS(Option)
SMART DIAGNOSIS(Optional)
SMART DIAGNOSIS
Should you experience any problems with
your refrigerator, it has the capability of
transmitting data via your telephone to the LG
service center. This gives you the capability of
speaking directly to our trained specialists. The
specialist records the data transmitted from
your machine and uses it to analyze the issue,
providing a fast and effective diagnosis.
If you experience problems with your
refrigerator, call the phone No. of LG
Customer Information Center. Only use
the Smart Diagnosis feature when instructed
to do so by the LG call center agent. The
transmission sounds that you will hear are
normal and sound similar to a fax machine.
Smart Diagnosis cannot be activated unless
your refrigerator is connected to power. If
your refrigerator is unable to turn on, then
troubleshooting must be done without using
Smart Diagnosis.
Using Smart Diagnosis
First, call the phone No. of LG Customer
Information Center. Only use the Smart
Diagnosis feature when instructed to do so
by the LG call center agent.
Lock the display. (Option)
1
To lock the display, press and hold the
Lock button for three seconds. (If the
display has been locked for over five
minutes, you must deactivate the lock
and then reactivate it.)
Hold the mouthpiece of your phone in
3
front of the speaker that is located on the
right hinge of the refrigerator door, when
instructed to do so by the call center.
Press and hold the Freezer Temperature
4
button for three seconds while continuing
to hold your phone to the speaker.
After you hear three beeps, release the
5
Freezer Temperature button.
Keep the phone in place until the tone
6
transmission has finished. This takes about
15 seconds, and the display will count
down the time. Once the countdown is
over and the tones have stopped, resume
your conversation with the specialist, who
will then be able to assist you in using the
information transmitted for analysis.
NOTE
For best results, do not move the phone
while the tones are being transmitted.
If the call center agent is not able to get
an accurate recording of the data, you
may be asked to try again.
Open the refrigerator door.
2
Lock Unlock Unlock
NOTE
Call quality differences by region may
affect the function.
Use the home telephone for better
communication performance, resulting
in better service.
Bad call quality may result in poor data
transmission from your phone to the
machine, which could cause Smart
Diagnosis to not work properly.
21
23
Loading...
