LG FLATRON L2013P Specifications
FLATRON L2013P
TM
FLATRON L2013P
20.1” TFT COLOR LCD MONITOR
FLATRON L2010P
FLATRON L2010P
FLATRON L2010P
◗ 20.1" Diagonal Viewable Image
◗ Maximum (Native) Resolution 1600 x 1200
◗ 178/178 Degree Ultra Wide Viewing Angle
◗ Space Saving Slim Bezel Design
◗ LightView(Pre-set Brightness Control) Function
◗ Portrait/Landscape Pivoting Display, Height Adjustable Stand
◗ Digital (DVI-D) and Standard Analog VGA Inputs
◗ TCO'03 Low Emission Compliant
FLATRON L2013P
FLATRON L20103P
FLATRON L2013P
FLATRON L20103P
FLATRON L2013P
FLATRON L2013P
FLATRON L2013P
FLATRON L2013P
EPA POLLUTION PREVENTER
FLATRON L2013P
A slim look with all the features you need. In addition to a sleek profile, the
FLATRON L2013P TFT-LCD has both digital (DVI-D) and standard analog
20.1” TFT COLOR LCD MONITOR
VGA input. Plus convenient LightView pre-set brightness control function,
up to 1600 x 1200 resolution, 40
FLATRON L2013P
DISPLAY SIZE AND TYPE 20.1" TFT Color LCD (20.1" VIS)
DISPLAY AREA 16.1" x 12.1"
DISPLAY COLORS 16.7 million
PIXEL PITCH 0.255 mm x 0.255 mm pixel
SURFACE TREATMENT Hard coating 3H, anti-glare
ELECTRONIC INTERFACE LVDS
BACKLIGHTING 6 CCFL lamps
NATIVE RESOLUTION (MAX.RES.) 1600 x 1200
BRIGHTNESS 250 cd/m
CONTRAST RATIO 400:1 (typical)
RESPONSE TIME 16 ms (typical)
VIEWING ANGLE H: 178º , V: 178º S-IPS Technology
HORIZONTAL SCANNING FREQUENCIES 28~92 kHz (autoscanning)
VERTICAL SCANNING FREQUENCIES 56~85 Hz (autoscanning)
AUTO SYNC SUPPORT 640 x 350 ~ 1600 x 1200
www.LGusa.com
2
(typical)
remarkable viewing experience. The FLATRON L2013P from LG.
Simply the best.
0:1 contrast, fine pixel pitch for a
CONTROL TYPE On-screen display of adjustments
INPUT SIGNALS RGB analog (0.7V pp) and DVI-D
INPUT TERMINALS 15-pin D-sub, DVI-D
SYNC SIGNALLING Separate, digital signal
VESA PLUG AND PLAY LEVEL DDC2B
DIGITAL ON-SCREEN CONTROLS Brightness, Contrast, Color: (9300K,6500K), user (RGB)
Horiz/Vert position , Clock, Phase, Language,
Zoom, Image size , OSD transparency, OSD lock, LightView Menu
Front Panel Controls Power, LightView, Auto Adjust, Source, Menu, Left/Right/Up/Down, Select
POWER REQUIREMENTS 90~264 VAC (47~63 Hz)
DPMS POWER CONSUMPTION On: 60W / Suspend: 5W / Off: 3W / Cut Off: 0W
TILT/SWIVEL/HEIGHT ADJUSTMENT Tilt: 5~20º Swivel 350
VESA WALL/SPECIAL MOUNTING TYPE Standard VESA, 100mm x 100mm Screw Spacing
DIMENSIONS WITH BASE (WXDXH) 17.6" x 8.8" x 17.6" (446mm x 223mm x 446mm)
SHIPPING DIMENSIONS (WxDxH) 21.5" x 10.2" x 20.5" (546mm x 259mm x 521mm)
WEIGHT Net: 19.4 lbs.
SAFETY/REGULATORY UL, FCC-B, EPA Energy Star, MPR-II, CSA, TUV-GS, SEMCO, CE, TCO-03, ISO-9241-3, C-Tick, GOST
ACCESSORIES D-Sub15-pin cable, DVI-D 19-pin cable, Power cord,
0
Height Adjustment Range: 3.2" (80mm)
Colorific Software/Manual Disk
LGEUS WARRANTY 3 year limited warranty on parts, labor and backlights
UPC# 719192179875
LG ELECTRONICS U.S.A., INC.
HEADQUARTERS
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 ◗ Tel: (201) 816-2000, Fax: (201) 816-2188
© 2005 LG Electronics U.S.A., Inc. All other trademarks are the property of their respective owners. Design and specifications subject to change without notice.
The Energy Star emblem does not represent EPA endorsement of any product or service. Printed in USA, 1/05
