OWNER’S MANUAL
FREEZER
Please read this owner's manual thoroughly before
operating and keep it handy for reference at all times.
F-2004SQ
GR-224SQ
GR-204SQ
P/No. : EBAX00097B
www.lg.com
3
Introduction
Installation
Operation
Suggestion on
food storage
Care and
Maintenance
Trouble Shooting
Table of Contents
Important safety Instruction
Disposal of the old appliance &
packing of new appliance
Identification of Parts
Location
Electrical Connection
Starting
Storing food
Making Ice
Defrosting
Cleaning
General Information
Tips for saving Energy
Trouble Shooting
4
6
7
8
9
10
10
11
12
13
14
15
8
Important Safety Instruction
Introduction
4
This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on the
power cord. Always grip plug firmly and pull straight
out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer compartment,
particularly when hands are damp or wet. Skin may
adhere to these extremely cold surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer.
Never damage, severely bend, pull out, or twist the
power cord because power cord damage may cause a
fire or electronic shock. Never place glass products in the
freezer because they may be broken when their inner
contents are frozen.
If possible, connect the fridge-freezer to its own
individual electrical outlet to prevent it and other
appliances or household lights from causing an overload.
The appliance is suitable for storing the frozen goods.
It is restricted for household use. If it is used for
industrial or commercial purpose, observe the related
regulations firmly. If using other purpose or misuse, the
manufacturer is not responsible for the damages of
occasion.
Ignoring the recommendations for environmental use
will make your appliance consume higher energy.
Precaution
Don't use an
extension cord
5
Introduction
Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not
easily climb inside.
The supply plug of the refrigerator-freezer should be
placed in easy accessible position for quick disconnection
in emergency.
Accessibility of
Supply Plug
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Supply Cord
Replacement
In the event of an electric short circuit, grounding
(earthing) reduces the risk of electric shock by providing
an escape wire for the electric current. In order to
prevent possible electric shock, this appliance must be
grounded. Improper use of the grounding plug can result
in an electric shock.
Consult a qualified electrician or service person if the
grounding instructions are not completely understood, or
if you have doubts on whether the appliance is properly
grounded.
Grounding
(Earthing)
ww
Danger
Important Safety Instruction
Introduction
The old appliance whose life has expired should be
destroyed in order to make it safe prior to disposal. Take
out power plugs, separate connection wires and remove
or destroy all springs, latches or bolting, to prevent
children from being trapped during play.
For environmental protection, old refrigerators should be
disposed off by a professional disposition agency. If you
have any question, please consult with the local sale
agency or local authority.
Disposal of the old
appliance
All packing materials used for this appliance are
environment-friendly.
Matters concerning material are as follows:
PE : Polyethylene – Foil or pocket for packing
PS : Formed objects made of foamed CFC-FREE
polystyrene
PP : Strapping tape made of polypropylene
Disposal of
packing of new
appliance
This appliance contains fluid (refrigerant, lubricant) and is
made of parts and materials which are reusable and/or
recyclable.
All the important materials should be sent to the
collection center of waste material and can be reused
after rework (recycling). For take back, please contact
with the local agency.
Take back offer
1. When this crossed-out wheeled bin symbol is attached
o a product it means the product is covered by the
European Directive 2002/96/EC.
2. All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed by
the government or the local authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of your
old appliance, please contact your city office, waste
disposal service or the shop where you purchased the
product.
Disposal of your
old appliance
•
Information of fluorinated greenhouse gases
used as refrigerant of this refrigerator.
Disposal of the old appliance
& packing of new appliance
6
Chemical name Composition of Gases Total GWP (kg CO2-eq)
R-134a 100% HFC-134a 1300
7
Introduction
Identification of Parts
Note
This is a basic model.The shape of refrigerator is
subject to change.
Temperature
Display
Ice scraper
Ice Tray
Magnetic
Gasket
Freezer Drawer
Leveling
Screws
Installation
8
This appliance is suitable for using at ambient
temperature between +16°C and +38°C. If the ambient
temperature drops below +16°C, it is possible that the
freezing foods in the freezer compartment are thawed
because the temperature of the freezer gets warm.
We recommend that the refrigerator be installed at a dry
and well ventilated place. Make sure that the appliance is
not exposed to direct sunlight or placed in vicinity of a
heat source such as stove, heaters, radiator.
To ensure proper air circulation around the fridgefreezer, please maintain sufficient space on both the
sides as well As top and maintain at least 2 inches (5 cm)
from the rear wall.
Location
This appliance should be connected to the mains AC
220~240V , 50 Hz. You must connect this appliance only
to the power socket with grounding complying with the
related regulations and only an approved expert should
install this appliance.
Electrical connection
Note
Place on a flat and firm flooring. If the floor is not
even, adjust the feet by using the leveling screw at
the front edge of the cabinet.
If the front is slightly higher than the rear, the door
can close more easily.
9
Operation
Starting
Before switching it on, leave the appliance standing for
at least 2 hours, so that the circulation of the refrigerant
stabilizes and no operating problems occur.
When the appliance powers on, the initial state displayed
on LED is "-18°C".
•
Button K1 (Defrost):
Press button K1 for three seconds the first time, indicator
"-", "°C", "h" shut off, compressor stop running and the
value displayed on LED is"OF". Press button K1 for the
second time , indicator "-", "°C", "h" display normally,
compressor running normally and LED displays the initial
state.
•
Button K2 (Quick freezing):
Press butoon K2 for the first time, indicator "-", "°C"shut
off, indicator "h" light on and initial freezing time displayed
is"3h". Press button K2 for the second time the freezing
time displayed is "2h". Press button K2 for the third time
the freezing time displayed is "1h". The compressor will ren
from 1hour to 3 hours according to the freezing time
displayed on LED. Press button K2 for the fourth time, the
indicators will recover the state before quick freeze.
•
Button K3 (Temperature regulation):
Press button K3 continuously, the provided temperature
displayed will be from -14°C to -27°C circularly.
Function of
electronic control
°C
h
Suggestions on food storage
10
Storing food
Making Ice
Opening the door often or keeping the door opened a
long time, increases the inside temperature. This causes
the storage life and flavor of the foods to reduce, and
increases the energy consumption.
To make ice cubes, fill ice tray 3/4
full with water and place it on
the bottom of the freezer
compartment.
To remove ice cubes, hold the ice tray at its ends and
twist gently.
Make sure foods that are not frozen do not touch the
frozen foods. The frozen foods may melt.
The packing materials suitable for refrigerating the foods
are
- Polyethylene bags, Plastic foil, freezing containers.
The suitable wrapping materials are
- Rubber band, Plastic clips, attaching tape, string. Before
sealing, get rid of air from packing bags and foil.The
remained air makes the storing foods dry.
You can freeze foods quickly when packing is level. Do
not store bottles in freezer compartment. They may
break when frozen.
Note
Do not touch deep-frozen foods with wet hands.
You could get chilblains on your hands.
To remove ice cubes easily, run water on the tray
before twisting.
Tips
11
Care and Maintenance
Note
Never place electrical devices in the refrigerator
for defrost. Take care when using defrosting sprays
for assisting defrosting. These sprays include
substances containing explosive gas, or harmful for
synthesis or human health.
Tips
It is helpful to place a saucepan with hot water inside
of the freezing room in order to assist defrost.
Defrosting
Defrosting the fridge compartment
When the freezer is working, frost is formed at the rear
wall of the fridge compartment and melts automatically
when the compressor stops.
Defrosting the freezer compartment
Humidity forms frost or ice in the freezer compartment
while the appliance is working or when the freezer door
is opened. The thick ice and frost decrease cool air and
increase the energy consumption.
Defrost Ice Layer
If the freezer compartment is heavily iced, defrost as
follows.
- Remove the frozen food, wrap in newspaper and store
in a cool place.
- Leave the door open, and wipe out water with a
sponge.
- Dry the freezer compartment thoroughly, turn on the
appliance, and replace frozen foods.
Care and Maintenance
12
ww
Warning
Cleaning
Always remove plugs or Switch off supply before
cleaning.
Do not use sharp objects (such as knife, screwdriver)
which could break refrigerant circuit resulting in
environmental and health risks.
Never use steam cleaner or steam pressure cleaner since
hot steam may damage refrigerator surface and electrical
devices. Never use sand, abrasive detergent, acid or
chemical solvent.
• The freezer compartment should be cleaned at least
once a month.
• The most appropriate time for cleaning of the freezer
compartment is a time after defrosting.
• Clean refrigerator including inside devices with clothes
or lukewarm water. You may use commercial
detergent for tableware.
• Frequently clean the water drain inlet on the inside rear
side of refrigerator. Clean the drain inlet using objects
like a toothpick so that the drain inlet is not clogged.
Care should be taken so that cleaning water does not
overflows in the drain tub.
Regularly clean the heat exchanger on the rear side of
refrigerator using a smooth brush so that accumulations
of dusts and residues. Do not disrupt expansion from the
inside and cause increased energy consumption.
Any damage to the heat exchanger or other events
leading to the exposure of the refrigerant to the
environment, should be avoided because of
potential environment and health risks.
13
Care and Maintenance
Going away
General Information
When you plan to be away for an extended period,
remove all food, disconnect the power cord, clean the
interior thoroughly, and leave the door OPEN to prevent
odor formation.
Power failure
Anti-condensation
pipe
Most power failures are corrected in an hour or two and
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings while
the power is OFF. During power failures of longer
duration, place a block of dry ice on top of your frozen
packages.
If you move
Remove all items inside the refrigerator or securely fasten
all loose items. To avoid damaging the leveling screw,
turn them all the way into the base.
• The Anti-condensation pipe is
installed around the front side
of fridge-freezer to prevent
dewing.
• Especially after installation or
when ambient temperature is
high, the fridge-freezer may feel
hot, which is quite normal.
Anti - Condensation
Pipe
Care and Maintenance
14
Tips for saving Energy
- After moving the appliance, allow 2 hours to turn
on again.
- Do not place the appliance near radiator, stove, and
heat sources. If ambient temperature is high, the
compressor will run longer.
- Place the appliance on a cool and well ventilated
room. Do not expose to direct sunlight.
- Do not keep the door opened too long.
- Do not place warm food and beverages in
appliance. Please cool down first otherwise the
steam from hot foodstuffs would contribute to the
icing up of the evaporator unit; and the cooling
period should be as short as possible, for health and
hygiene reasons.
- Do not set the temperature of appliance lower than
needed.
- Place the deep-frozen foods for thawing into the
fridge.
They can be used for cooling the fridge.
- Replace magnetic door gasket of the door if it is not
properly functioning.
15
Trouble Shooting
Fridge-Freezer
does not operate
Before calling for service, check this list.
It may save you both time and expense.
This list includes common occurrences that are not the
result of defective workmanship or materials in this
appliance.
• Power plug may be unplugged from the electric
outlet.
Plug it in securely.
• House fuse has blown or circuit breaker has
tripped.
Check and/or replace fuse and reset circuit breaker.
• Power cut.
Check house lights.
Vibration or
Rattling or
Abnormal Noise
• The floor on which the fridge-freezer is installed
may be uneven or the fridge-freezer may be
unstable.
Make it even by rotating the leveling screw.
• Unnecessary objects placed in the back side of the
fridge-freezer.
Temperature of
foods inside
refrigerator is not
cold enough
• Too frequent or too long door openings.
There is a heat source near Fridge-Freezer.
A large quantity of food was placed inside the
fridge compartment.
The temperature
inside the
refrigerator is too
cold
• The electronic controller is setting to extremely
low figure.
Problem
Possible Causes
Trouble Shooting
16
Fridge has odor
• Foods with strong odors should be tightly covered
or wrapped
• Check for spoiled food
• Interior needs cleaning
• Refer to "Cleaning Section"
Moisture forms on
cabinet surface
• This phenomenon is likely to occur in a wet space.
Wipe it with a dry towel
Problem
Possible Causes
Loading...
