ASSEMBLING AND PREPARING 3
Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.
ENGLISH
CD(Owner's Manual) / |
D-SUB Cable |
DVI-D Cable |
Card |
|
(This cable is not included in all |
|
|
countries.) |
|
|
or |
Power Cord |
AC-DC Adapter |
AC-DC adapter |
(Depending on the country) |
(Depending on the country) |
Stand Body |
Stand Body |
Stand Base |
( E2342V /E2442V ) |
( E2742V ) |
|
CAUTION
yyDo not use any unapproved accessories to ensure the safety and product life span.
yyAny damages or injuries by using unapproved accessories are not covered by the warranty.
NOTE
yyThe accessories supplied with your product may vary depending on the model.
yyProduct specifications or contents in this manual may be changed without prior notice due to upgrade of product functions.
4 ASSEMBLING AND PREPARING
ENGLISH
Indicator
On: Turned on
Off: Turned off
(Power Button)
(See p.12)
/
DC-IN
Connection panel (See p.10)
|
|
ASSEMBLING AND PREPARING 5 |
|
Setting up the Monitor set |
E2742V |
|
|
Attaching the Stand |
Use two screw to assemble the Stand Body and |
||
back cover, attach the stand base and then |
|||
1 Place the Monitor set with the screen side |
tighten the screw to the right with a Coin. |
||
|
|
||
down on a flat and cushioned surface. |
|
|
|
CAUTION |
|
|
|
Lay a foam mat or soft protective cloth |
|
|
|
on the surface to protect the screen from |
|
|
|
damage. |
|
|
|
|
Stand Body |
|
|
2 E2342V/E2442V |
|
2 |
|
|
|
||
Attach the Stand body and then attach the Stand |
|
|
|
Base,then tighten the screw to the right with a |
Stand |
|
|
Coin. |
3 |
||
|
Stand Body
2
Stand |
3 |
|
ENGLISH
ENGLISH
6 ASSEMBLING AND PREPARING
Detaching the Stand |
E2742V |
1 Place the Monitor set with the screen side |
Turn the screw to the left with a Coin, and then |
pull out the Stand Base from the Stand Body. |
|
down on a flat and cushioned surface. |
Remove 2 screws and pull out the Stand Body |
|
|
|
from the Monitor set. |
2 E2342V/E2442V |
|
Turn the screw to the left with a Coin, and then |
|
pull out the Stand Base from the Stand Body, |
|
then pull out the Stand Body from the Monitor |
|
set . |
|
Stand Body 3
2
Stand Body
Stand |
1 |
|
3 |
||
|
||
2 |
|
Stand
CAUTION
y This illustration depicts the general model of connection. Your monitor may differ from the items shown in the picture.
y Do not carry the product upside down holding only the stand base. The product may fall and get damaged or injure your foot.
ASSEMBLING AND PREPARING 7
Mounting on a table
1Lift and tilt the Monitor set into its upright position on a table.
Leave a 10 cm (minimum) space from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
3Press (Power) button on the bottom switch panel to turn the power on.
CAUTION
Unplug the power cord before moving the Monitor to another location. Otherwise electric shock may occur.
Using the cable holder
ENGLISH
2 Connect the AC-DC adapter and Power Cord
to wall outlet |
/ |
Cable holder
or
/
DC-I
N
ENGLISH
8 ASSEMBLING AND PREPARING
WARNING
Using the Kensington security system
When you adjust the angle, do not hold the bottom of the Monitor set frame as shown on the following illustration, as may injure your fingers.
Do not touch or press the screen when adjusting the angle of the monitor.
Do not hold this set like below picture. Monitor screen can detach from stand base and injure your body.
NOTE
Tilt from +20 to -5 degrees up or down to adjust the angle of the Monitor set to suit your view.
- 5 20
The Kensington security system connector is located at the back of the Monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com.
Connect the Kensington security system cable between the Monitor set and a table.
NOTE
The Kensington security system is optional. You can obtain it from most electronics stores.
Front Rear
ASSEMBLING AND PREPARING 9
Mounting on a wall
For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.
10 cm
10 cm
10 cm
10 cm
If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set.
When you install the Monitor set using a wall mounting interface (optional parts), attach it carefully so it will not drop.
1Please, Use the screw and wall mount interface in accordance with VESA Standards.
2If you use screw longer than standard, the monitor might be damaged internally.
3If you use improper screw, the product might be damaged and drop from mounted position. In
this case, LG Electronics is not responsible for it.
4 VESA compatible.
5 Please use VESA standard as below. yy784.8 mm (30.9 inch) and under
*Wall Mount Pad Thickness : 2.6 mm * Screw : Φ 4.0 mm x Pitch 0.7 mm x Length 10 mm
yy787.4 mm (31.0 inch) and above
*Please use VESA standard wall mount pad and screws.
Model |
E2342V |
|
E2442V |
|
|
E2742V |
|
|
|
|
|
|
|
ENGLISH |
VESA (A x B) |
75 x 75 |
100 x 100 |
|
Standard screw |
M4 |
|
|
Number of screws |
4 |
|
|
CAUTION
yyDisconnect the power cord first, and then move or install the Monitor set. Otherwise electric shock may occur.
yyIf you install the Monitor set on a ceiling or slanted wall, it may fall and result in severe injury.
yyUse only an authorized LG wall mount and contact the local dealer or qualified personnel.
yyDo not over tighten the screws as this may cause damage to the Monitor set and void your warranty.
yyUse only screws and wall mounts that meet the VESA standard. Any damages or injuries by misuse or using an improper
accessory are not covered by the warranty.
NOTE
yyUse the screws that are listed on the VESA standard screw specifications.
yyThe wall mount kit will include an installation manual and necessary parts.
yyThe wall mount bracket is optional. You can obtain additional accessories from your local dealer.
yyThe length of screws may differ depending on the wall mount. Be sure to use the proper length.
yyFor more information, refer to the instructions supplied with the wall mount.
