SIMPLE MANUAL
MFL71379811
Micro Hi-Fi
ENGLISH DEUTSCH FRANÇAIS
NEDERLANDS
SLOVENŠČINA
Audio
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
CM2460DAB
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
1908_Rev01
ITALIANO ESPAÑOL
ΕΛΛΗΝΙΚΑ
PORTUGUÊS
www.lg.com
CM2460-CB.AWEULLZ_SIM_ENG_MFL71379811.indd 1 2019-08-20 10:38:20
Front Panel
(Power)
a 1/!
Switches the unit ON or OFF.
F
b
Selects the function or input source.
c Y/U
a
f
g
d ecb
ji
k
TUNING - / +
- Selects the radio stations.
- Scans DAB+ stations by pressing and holding.
d T
e R
h
Remote sensor
f
Display window
g
Volume Knob
h
i
Disc tray
j
k
(Skip/Search)
- Searches backward or forward.
- Skips to the previous/next track/le.
(Play/Pause)
- Starts or pauses playback.
- Selects Stereo/Mono.
Opens or closes the disc tray.
Adjusts volume of speaker.
USB
Plays the audio les by connecting the USB device.
PORT. IN
Connects to a Portable device.
Rear Panel
DAB+/FM ANTENNA
a
SPEAKERS (L/R) terminals
b
POWER IN
c
a
b
Controller App
Download the Music Flow Bluetooth App to your
device.
CM2460-CB.AWEULLZ_SIM_ENG_MFL71379811.indd 2 2019-08-20 10:38:22
c
LG Sound Sync (Wireless)
For more information, download the online owner’s
manual. http://www.lg.com
Speaker Connection
(R03)
(R03)
Additional Information
Specifications
Power Requirements
Power Consumption
Dimensions (W x H x D)
Black
Refer to the main label on
the unit.
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Approx. 230 mm x 126 mm
x 253 mm
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
Red
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
MICRO HI-FI SYSTEM is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
Bus Power Supply (USB)
Amplier
(Total RMS output power)
5 V 0 500 mA
100 W
Design and specications are subject to change without
notice.
CM2460-CB.AWEULLZ_SIM_ENG_MFL71379811.indd 3 2019-08-20 10:38:23
