LG CB630 User Manual [en, es]
Copyright © 2008 LG Electronics, Inc. ALL RIGHTS RESERVED.
All materials used herein, including but not limited to trademarks, service marks, and all other
commercially valuable rights, properties and products are owned by and proprietary to LG Electronics,
Inc. and may not be reproduced, republished, redistributed or disseminated, either in whole or in part,
without the express written permission of LGElectronics, Inc.
All other marks are proprietary to their respective owners. Features and specifications are subject to
change without prior notice.
Bluetooth QD ID B013856
1. WHAT THIS WARRANTY COVERS :
LG offers you a limited warranty that the
enclosed subscriber unit and its enclosed
accessories will be free from defects in material
and workmanship, according to the following
terms and conditions:
1. The limited warranty for the product extends
for TWELVE (12) MONTHS beginning on the
date of purchase of the product with valid
proof of purchase, or absent valid proof of
purchase, FIFTEEN (15) MONTHS from date
of manufacture as determined by the unit’s
manufacture date code.
2. The limited warranty extends only to the
original purchaser of the product and is not
assignable or transferable to any subsequent
purchaser/end user.
3. This warranty is good only to the original
purchaser of the product during the warranty
period as long as it is in the U.S, including
Alaska, Hawaii, U.S. Territories and Canada.
4. The external housing and cosmetic parts
shall be free of defects at the time of
shipment and, therefore, shall not be covered
under these limited warranty terms.
5. Upon request from LG, the consumer must
provide information to reasonably prove the
date of purchase.
6. The customer shall bear the cost of shipping
the product to the Customer Service
Department of LG. LG shall bear the cost of
shipping the product back to the consumer
after the completion of service under this
limited warranty.
2. WHAT THIS WARRANTY DOES NOT
COVER :
1. Defects or damages resulting from use of
the product in other than its normal and
customary manner.
2. Defects or damages from abnormal use,
abnormal conditions, improper storage,
exposure to moisture or dampness,
unauthorized modifications, unauthorized
connections, unauthorized repair, misuse,
neglect, abuse, accident, alteration,
improper installation, or other acts which
are not the fault of LG, including damage
caused by shipping, blown fuses, spills of
food or liquid.
3. Breakage or damage to antennas unless
caused directly by defects in material or
workmanship.
4. That the Customer Service Department
at LG was not notified by consumer of
the alleged defect or malfunction of the
product during the applicable limited
warranty period.
5. Products which have had the serial
number removed or made illegible.
6. This limited warranty is in lieu of all other
warranties, express or implied either in
fact or by operations of law, statutory or
otherwise, including, but not limited to any
implied warranty of marketability or fitness
for a particular use.
7. Damage resulting from use of non-LG
approved accessories.
LIMITED WARRANTY STATEMENT
8. All plastic surfaces and all other externally
exposed parts that are scratched or
damaged due to normal customer use.
9. Products operated outside published
maximum ratings.
10. Products used or obtained in a rental
program.
11. Consumables (such as fuses).
3. WHAT LG WILL DO:
LG will, at its sole option, either repair,
replace or refund the purchase price of
any unit that does not conform to this
limited warranty. LG may choose at its
option to use functionally equivalent
reconditioned, refurbished or new units or
parts or any units. In addition, LG will not
re-install or back-up any data, applications
or software that you have added to your
phone. It is therefore recommended that
you back-up any such data or information
prior to sending the unit to LG to avoid the
permanent loss of such information.
4. STATE LAW RIGHTS :
No other express warranty is applicable
to this product. THE DURATION OF ANY
IMPLIED WARRANTIES, INCLUDING
THE IMPLIED WARRANTY OF
MARKETABILITY, IS LIMITED TO THE
DURATION OF THE EXPRESS WARRANTY
HEREIN. LG INFOCOMM INC. SHALL NOT
BE LIABLE FOR THE LOSS OF THE USE
OF THE PRODUCT, INCONVENIENCE,
LOSS OR ANY OTHER DAMAGES, DIRECT
OR CONSEQUENTIAL, ARISING OUT
OF THE USE OF, OR INABILITY TO USE,
THIS PRODUCT OR FOR ANY BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY,
INCLUDING THE IMPLIED WARRANTY OF
MARKETABILITY APPLICABLE TO THIS
PRODUCT.
Some states do not allow the exclusive of
limitation of incidental or consequential
damages or limitations on how long an
implied warranty lasts; so these limitations
or exclusions may not apply to you. This
warranty gives you specific legal rights
and you may also have other rights which
vary from state to state.
5. HOW TO GET WARRANTY SERVICE :
To obtain warranty service, please call or
fax to the following telephone numbers
from anywhere in the continental United
States:
Tel. 1-800-793-8896 or Fax. 1-800-448-4026
Or visit www.lgeservice.com.
Correspondence may also be mailed to:
LG Electronics MobileComm U.S.A., Inc.
201 James Record Road Huntsville, AL
35824
DO NOT RETURN YOUR PRODUCT TO
THE ABOVE
ADDRESS. Please call or write for the
location of the LG authorized service
center nearest you and for the procedures
for obtaining warranty claims.
User Guide
CB630
For Your Safety. . . . . . . .. . . . . .. . . . . 5
Important Information ..............................5
Before You Start .......................................5
Your Phone . . . . . . . .. . . . . .. . . . . .. 10
Phone Components ................................10
Your Phone’s Features ............................11
Display Information ................................13
Getting Started. . . . .. . . . . .. . . . . .. 16
Installing the SmartChip ........................16
Charging the Battery ..............................17
Memory card slot ...................................18
Inserting the memory card .....................18
Removing the memory card ...................19
Turning Your Phone On and Off .............19
Access Codes .........................................19
General Functions. . . . .. . . . . .. . . . 20
Making a Call .........................................20
Adjusting the Volume .............................21
Answering a Call ....................................21
Entering Text ...........................................21
Selecting Functions and Options. . 25
Menu Tree . . . . . . . . . . . . . . . . . . . . . . 26
In-Call Menu. . . . .. . . . . .. . . . . .. . . 30
During a Call ...........................................30
Video Share Calling ................................31
Conference Calls ....................................34
TV & Video
. . . . .. . . . . .. . . . .. . . . . . 36
Mobile TV ...............................................36
Cellular Video .........................................41
Music Videos ..........................................42
Entertainment Videos ............................42
Sports Videos ..........................................42
Shop Videos ............................................ 42
Video Applications .................................42
Messaging. .. . . . . .. . . . . .. . . . . .. . 43
New Message ........................................43
Inbox ........................................................46
IM ............................................................47
Mobile Email ..........................................51
Drafts ......................................................52
Outbox .....................................................52
Sent .........................................................53
Voicemail ................................................53
Templates................................................53
Message Settings .................................. 54
Table of Contents
2
Recent Calls . . . . . . .. . . . . .. . . . . .. 56
Missed Calls ...........................................56
Dialed Calls .............................................56
Received Calls ........................................56
All Calls ...................................................56
Call Duration ........................................... 56
Data Counter .......................................... 57
MEdia Net . .. . . . . .. . . . . .. . . . . .. . 58
MEdia Net Home .................................... 58
Bookmarks ..............................................59
Saved Pages ...........................................59
Enter URL ................................................59
Recent Pages ..........................................59
Security ...................................................60
Browser Settings ....................................60
AT&T Mall .. . . . . .. . . . . .. . . . . .. . . 63
Shop Tones .............................................63
Shop Games ........................................... 63
Shop Graphics ........................................63
Shop Multimedia ....................................63
Shop Applications .................................. 63
Shop Videos ............................................ 63
MEdia Net Home .................................... 63
AT&T Music . . . . .. . . . . .. . . . . .. . . 64
Music Player ...........................................64
Shop Music .............................................70
MusicID ...................................................70
XM Radio ................................................71
Music Videos ..........................................71
The Buzz ..................................................71
Community .............................................. 72
Music Apps .............................................72
My Stuff . . . .. . . . . .. . . . . .. . . . . .. . 73
Games ..................................................... 73
Applications ............................................ 73
Audio & Ringtones ................................. 74
Pictures ...................................................74
Video ....................................................... 74
Tools ........................................................75
Camera & Recordings ............................80
Other Files ...............................................83
Memory Card ..........................................84
Address Book .. . . . . .. . . . . .. . . . .. 85
Contact List ............................................. 85
New Contact ........................................... 85
Caller Groups ..........................................85
3
Speed Dial List .......................................85
Copy All Contacts ...................................85
Delete All Contacts ................................86
Service Dial Numbers ............................86
My Business Card ..................................86
View Options ..........................................86
My Numbers ...........................................86
Settings . . . . . . .. . . . . .. . . . . .. . . . . 87
Audio & Ringtones ................................. 87
Display ....................................................88
Bluetooth ...............................................89
Date & Time ............................................90
Call .......................................................... 91
Security ...................................................95
Connection .............................................. 97
Flight Mode.............................................98
Software Update ....................................98
Check Memory ........................................ 99
Handset Information...............................99
Reset Settings ........................................99
Q&A. . . . . .. . . . . .. . . . .. . . . . .. . . . 101
Accessories . . . . .. . . . . .. . . . . .. . 103
Safety Guidelines . . . . .. . . . . .. . . 105
TIA Safety Information .........................105
Safety Information ................................108
FDA Consumer Update .........................112
10 Driver Safety Tips ............................121
Consumer Information on SAR (Specific
Absorption Rate) ...................................123
Glossary. . . . . . .. . . . . .. . . . . .. . . . 126
Index. . . . . . .. . . . . .. . . . . .. . . . . .. 128
Memo . . . .. . . . . .. . . . .. . . . . .. . . . 131
4
For Your Safety
Important Information
This user guide contains important
information on the use and operation
of this phone. Please read all the
information carefully for optimal
performance and to prevent any damage
to or misuse of the phone. Any changes
or modifications not expressly approved
in this user guide could void your
warranty for this equipment.
Before You Start
Safety Instructions
WARNING!
To reduce the possibility of
electric shock, do not expose your phone
to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from
heat.
Never store your phone in settings
that may expose it to temperatures less
than 32°F or greater than 104°F, such
as outside during extreme weather
conditions or in your car on a hot day.
Exposure to excessive cold or heat will
result in malfunction, damage and/or
catastrophic failure.
Be careful when using your phone near
other electronic devices.
RF emissions
from your mobile phone may affect
nearby in adequately shielded electronic
equipment. You should consult with
manufacturers of any personal medical
devices such as pacemakers and hearing
aides to determine if they are susceptible
to interference from your mobile phone.
Turn off your phone in a medical facility or
at a gas station. Never place your phone
in a microwave oven as this will cause
the battery to explode.
IMPORTANT!
Please read the TIA SAFETY
INFORMATION on page 105 before using
your phone.
Safety Information
Read these simple guidelines. Breaking
the rules may be dangerous or illegal.
Further detailed information is given in
this user guide.
]
Never use an unapproved battery since
this could damage the phone and/or
battery and could cause the battery to
explode.
5
6
]
Never place your phone in a microwave
oven as it will cause the battery to
explode.
]
Do not dispose of your battery by fire or
with hazardous or flammable materials.
]
Make sure that no sharp-edged items
come into contact with the battery.
There is a risk of this causing a fire.
]
Store the battery in a place out of reach
of children.
]
Be careful that children do not
swallow any parts such as rubber
plugs (earphone, connection parts
of the phone, etc.). This could cause
asphyxiation or suffocation.
]
Unplug the power cord and charger
during lightning storms to avoid electric
shock or fire.
]
When riding in a car, do not leave your
phone or set up the hands-free kit near
to the air bag. If wireless equipment is
improperly installed and the air bag is
activated, you may be seriously injured.
]
Do not use a hand-held phone while
driving.
]
Do not use the phone in areas where its
use is prohibited. (For example: aircraft).
]
Do not expose the battery charger or
adapter to direct sunlight or use it in
places with high humidity, such as a
bathroom.
]
Never store your phone in temperatures
less than- 4°F or greater than 122°F.
]
Do not use harsh chemicals(such as
alcohol, benzene, thinners, etc.) or
detergents to clean your phone. There
is a risk of this causing a fire.
]
Do not drop, strike, or shake your phone
severely. Such actions may harm the
internal circuit boards of the phone.
]
Do not use your phone in high explosive
areas as the phone may generate
sparks.
]
Do not damage the power cord by
bending, twisting, pulling, or heating.
Do not use the plug if it is loose as it
may cause a fire or electric shock.
]
Do not place any heavy items on the
power cord. Do not allow the power
cord to be crimped as it may cause fire
or electric shock.
For Your Safety
7
For Your Safety
]
Do not handle the phone with wet
hands while it is being charged. It may
cause an electric shock or seriously
damage your phone.
]
Do not disassemble the phone.
]
Do not place or answer calls while
charging the phone as it may shortcircuit the phone and/or cause electric
shock or fire.
]
Only use the batteries, antennas, and
chargers provided by LG. The warranty
will not be applied to products provided
by other suppliers.
]
Only authorized personnel should
service the phone and its accessories.
Faulty installation or service may
result in accidents and consequently
invalidate the warranty.
]
Do not hold or let the antenna come in
contact with your body during a call.
]
An emergency call can be made only
within a service area. For an emergency
call, make sure that you are within
a service area and that the phone is
turned on.
]
Use accessories, such as earphones
and headsets, with caution. Ensure that
cables are tucked away safely and do
not touch the antenna unnecessarily.
Memory card information and
care
]
Always insert/ remove the memory card
while the handset power is off. If you
remove it while the power is on, it may
be damaged.
]
If the damage cannot be fixed, format
the memory card.
]
The memory card cannot be used for
recording copyright- protected data.
]
Do not write forcefully on the memo
area.
]
Carry and store the memory card in
its case.
]
Do not allow the memory card to get
wet.
]
Do not leave the memory card in
extremely hot location.
]
Do not disassemble or modify the
memory card.
8
For Your Safety
FCC RF Exposure Information
WARNING!
Read this information before
operating the phone.
In August 1996, the Federal
Communications Commission (FCC)
of the United States, with its action
in Report and Order FCC 96-326,
adopted an updated safety standard
for human exposure to radio frequency
(RF) electromagnetic energy emitted
by FCC regulated transmitters. Those
guidelines are consistent with the safety
standard previously set by both U.S. and
international standards bodies.
The design of this phone complies
with the FCC guidelines and these
international standards.
CAUTION
Use only the supplied and approved
antenna. Use of unauthorized antennas
or modifications could impair call
quality, damage the phone, void your
warranty and/or result in violation of FCC
regulations. Do not use the phone with a
damaged antenna. If a damaged antenna
comes into contact with skin, a minor
burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical bodyworn operations with the back of the
phone kept 0.79 inches (2.0cm) between
the user’s body and the back of the
phone. To comply with FCC RF exposure
requirements, a minimum separation
distance of 0.79 inches(2.0cm) must be
maintained between the user s body and
the back of the phone. Third-party beltclips, holsters, and similar accessories
containing metallic components should
not be used. Body-worn accessories
that cannot maintain 0.79 inches(2.0cm)
separation distance between the user's
body and the back of the phone, and have
not been tested for typical body-worn
operations may not comply with FCC RF
exposure limits and should be avoided.
Vehicle Mounted External
Antenna (optional, if available)
A minimum separation distance of
8 inches (20cm) must be maintained
between the user/bystander and the
vehicle mounted external antenna to
satisfy FCC RF exposure requirements. For
more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply
with part 15 of FCC rules. Operation is
subject to the following two conditions:
(1) This device and its accessories
may not cause harmful interference,
and (2) this device and its accessories
must accept any interference received,
including interference that may cause
undesired operation.
Cautions for Battery
]
Do not disassemble.
]
Do not short-circuit.
]
Do not expose to high temperature:
60°C (140°F).]
]
Do not incinerate.
Battery Disposal
]
Please dispose of your battery properly
or bring to your local wireless carrier
for recycling.
]
Do not dispose in fire or with hazardous
or flammable materials.
Adapter (Charger) Cautions
]
Using the wrong battery charger could
damage your phone and void your
warranty.
]
The adapter or battery charger is
intended for indoor use only.
Do not expose the adapter or battery
charger to direct sunlight or use it in
places with high humidity, such as the
bathroom.
Avoid damage to your hearing
]
Damage to your hearing can occur
if you are exposed to loud sound for
long periods of time. We therefore
recommend that you do not turn on or
off the handset close to your ear. We
also recommend that music and call
volumes are set to a reasonable level.
]
If you are listening to music whilst
out and about, please ensure that the
volume is at a reasonable level so that
you are aware of your surroundings.
This is particularly imperative when
attempting to cross the street.
9
For Your Safety
10
Your Phone
Phone Components
1. Earpiece
5. Left soft key
4. Mobile TV key
3. Volume keys
2. Display screen
6. Send key
7. Alpha numeric keys
8. Power Connector
9. Navigation key
13. Right soft key
14. End /Power key
15. Confirmation key
11. Clear key
16. Microphone
10. Multi-task key
12. Camera key
11
Your Phone
Your Phone’s Features
1. Earpiece:
Lets you hear the caller and
automated prompts.
2. Display screen:
Displays phone status
icons, menu items, web information,
pictures and more in full color.
3. Volume keys:
These keys are used
to control the volume of ringtone in
standby mode and speaker volume
during a call.
4. Mobile TV key:
For further details, see
page 36 (Menu 1.1).
5, 13. Left soft key/Right soft key:
Each
of these keys perform the functions
indicated by the text on the display
immediately above them.
6. Send key:
You can dial a phone number
and answer incoming calls. Press this
key in standby mode to quickly access
the most recent incoming, outgoing and
missed calls.
7. Alpha numeric keys:
These keys are
used to dial a number in standby mode
and to enter numbers or characters in
edit mode.
8. Power Connector:
Insert charger.
9. Navigation key:
Use for quick access to
phone functions.
10. Multi-task key:
Multitask
simultaneously with voice and data
- browse the web, make calls, play
games, send and receive messages,
and listen to MP3s. All at once.
11. Clear key:
Allows you to delete the
characters entered or return to the
previous screen.
12. Camera key:
Press this key to use the
camera feature or to go directly to
camera mode.
14. End/Power key:
Allows you to power
the phone on or off, end calls, or
return to Standby Mode.
15. Confirmation key:
Short press will
launch the WAP browser. Allows you
to select and confirm menu options.
16. Microphone:
Can be muted during a
call for privacy.
12
Your Phone
Side view
Rear view
Advice to the customer
In order to allow better antenna
sensitivity LG suggests that you hold the
handset as depicted in the figure below.
Please do not cover the antenna area
with your hand during a call and using
a bluetooth connection. It may degrade
speech quality.
Multi-task key
Camera key
Press this key to use the
camera feature or to go
directly to camera mode.
USIM card socket
Camera
Battery terminals
Antenna
Display Information
13
Your Phone
Icon area
Soft key indications
Text and graphic
area
Area Description
First line Displays various icons.
Middle
lines
Displays messages,
instructions and any
information that you enter,
such as number to be dialed.
Last line
Shows the functions currently
assigned to the two soft keys.
Your Phone
14
On-Screen Icons
The table below describes various display
indicators or icons that appear on the
phone’s display screen.
Icon Description
Indicates the strength of the 3G
network signal.
Indicates the strength of the
network signal.
Indicates that GPRS service is
available. Indicates that the EDGE
service is available. Connection
to the EDGE service allows you
to transfer data at a speed of
200Kb/s(depending on network
availability). Check with your
operator for network coverage and
service availability.
Indicates that GPRS service is
available.
Indicates that Flight mode has been
activated.
Icon Description
Indicates the status of the battery
charge.
Indicates that a call is in progress.
Indicates that the alarm has been
set and is on.
Indicates the receipt of a message.
Indicates the receipt of a Voicemail.
Indicates that Ring has been set
for alert.
Indicates that Ring and vibration
has been set for alert.
Indicates that Ring after Vibration
has been set for alert.
Indicates that Silent has been set
for alert.
Indicates that the speakerphone
has been activated.
* The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by LG Electronics is under license. Other trademarks and trade
names are those of their respective owners. Bluetooth QD ID B013856
15
Your Phone
Icon Description
Indicates that the Bluetooth®
function has been activated.
Indicates that you can see TV.
Indicates that the connection to a
hands-free with Bluetooth has been
activated.
Indicates that the connection to a
stereo Bluetooth device has been
activated.
Indicates that the connection to a
hand-free & stereo with Bluetooth
has been activated.
Indicates that the Multitasking
function has been activated.
Indicates that the TTY has been set
and is on.
Indicates that the phone is
accessing the WAP or data service.
Indicates that data communication
is being initiated with connection to
Packet Switching.
16
Installing the SmartChip
When you subscribe to a cellular network,
you are provided with a plug-in SmartChip
loaded with your subscription details,
such as your PIN, any optional services
available and many others.
n Important!
The plug-in SmartChip and its contacts can be
easily damaged by scratches or bending, so be
careful when handling, inserting or removing the
card. Keep all SmartChips out of the reach of
small children.
1.
If necessary, switch off the phone by
holding down the
[END] key until
the power-off image appears.
2.
Remove the battery. To do so:
3.
Slide the SmartChip into the
SmartChip socket so that it locks the
card into place. Make sure that the
notched corner is at the bottom right
and the gold contacts of the card face
into the phone.
n Note
When you need to remove the SmartChip, slide
it, as shown, and take it out of the socket.
Getting Started
17
Getting Started
4. Insert the the battery into the battery
compartment as metal contacts meet in the
phone. Push down the top of the battery
until it snaps into place. Place the battery
cover to the phone as shown.
Charging the Battery
Use of unauthorized accessories could
damage your phone and void your
warranty.
To use the travel charger provided with
your phone:
1.
With the battery in position in the
phone, connect the lead from the
travel charger to the bottom left of the
phone. Check that the arrow on the
lead connector is facing towards the
front of the phone.
2.
Connect the travel charger to a
standard AC wall outlet. Only use the
travel charger that comes with the
package.
n Warning
The travel charger must be unplugged before you
remove the battery, otherwise, the phone could
be damaged.
18
Getting Started
3.
When the phone has been charged
fully, disconnect the travel charger
from the phone by pulling the
connector out.
n Note
] If your phone is powered on while charging,
you’ll see the bars on the battery indicator
icon cycle.
When the battery is fully charged, the bars on
the battery indicator icon will flash on and off.
If the battery fails to charge completely:
] After turning the phone on and off, please
attempt to recharge the battery.
] After detaching and reattaching the battery,
please attempt to recharge the battery.
Memory card slot
The INVISION supports the microSD™
memory card. The memory card can be
inserted into the side of the INVISION
device. You can use this card to save data
files such as MP3 songs.
n Note
Only use memory cards that have been approved
by the manufacturer. Some memory cards might
not be compliant with the handset.
Inserting the memory card
Insert the memory card into the slot until
the memory card is fully inserted into the
slot, as shown in the figure below:
n Note
The gold connectors must be face down and
inserted first into the memory card slot.
19
Getting Started
Removing the memory card
1.
Push the memory card down into
the slot with the tip of your finger to
engage the spring mechanism.
2.
Carefully pull the memory card out of
the slot.
Turning Your Phone On and
Off
1.
Hold down the [END] key until the
phone switches on.
2.
If the phone asks for a PIN, enter the
PIN and press the key.
The phone searches for your network and
after finding it goes to the idle screen.
From the idle screen, you can make or
receive a call.
n Note
The display language is preset to Automatic at
the factory. To change the language, use the
Languages menu option (Menu 9.2.6).
3.
When you wish to switch the phone
off, hold down the [END] key until
the power-off image displays.
Access Codes
You can use the access codes described
in this section to avoid unauthorized use
of your phone. The access codes can
be changed by using the
Change Codes
feature (Menu 9.6.5).
Security code (4 digits)
The security code protects your phone
from unauthorized use. The default
security code is set to ‘
0000
’ and the
security code is required to delete all
phone entries and to activate the Restore
Factory Settings menu. The security code
default setting can be modified from the
Security menu.
20
Making a Call
1.
Make sure your phone is powered on.
2.
Enter a phone number including the
area code. To edit a number on the
display screen, simply press the
key to erase one digit at a time.
] Press and hold the key to erase
the entire number.
3.
Press the [SEND] key to call the
number.
4.
When finished, press the [END]
key.
Making a Call by Send Key
1.
Press the [SEND] key, and the
most recent incoming, outgoing
and missed phone numbers will be
displayed.
2.
Select the desired number by using the
navigation key.
3.
Press the [SEND] key.
Making International Calls
1.
Press and hold the key and the
international access character ‘+’ will
appear.
2.
Enter the country code, area code, and
the phone number.
3.
Press the [SEND] key.
Ending a Call
When you have finished a call, press the
[END] key.
Making a Call From the Contacts
You can store names and phone numbers
dialed frequently in the SmartChip as
well as in the phone memory known as
the Contacts.
You can dial a number by simply selecting
a name in the contacts and pressing the
[SEND] key.
General Functions
21
Adjusting the Volume
During a call, if you want to adjust the
earpiece volume, use the side keys of
the phone.
In idle mode, you can adjust the ring
volume using the side keys.
Answering a Call
When you receive a call, the phone
rings and the phone icon appears on the
screen. If the caller can be identified, the
caller’s phone number (or name if stored
in your Address Book) is displayed.
1.
Press the [SEND] key or the left
soft key to answer an incoming call. If
Any Key
has been set as the Answer
Mode (Menu 9.5.4), any key press will
answer a call except for the [END]
key or the right soft key.
2.
End the call by pressing the [END]
key.
n Notice
You can answer a call while using the Address
Book or other menu features.
Vibrate Mode (Quick)
Vibrate Mode can be activated by
pressing and holding down the
[Star] key.
Signal Strength
If you are inside a building, being near a
window may give you better reception.
You can see the strength of your signal
by the signal indicator on your phone’s
display screen.
Entering Text
You can enter alphanumeric characters by
using the phone’s keypad. For example,
storing names in the Address Book,
writing a message, or creating scheduling
events in the calendar all require entering
text.
The following text input modes are
available on the phone.
General Functions
22
General Functions
T9 Mode
This mode allows you to enter words with
only one keystroke per letter. Each key
on the keypad has more than one letter.
The T9 mode automatically compares
your keystrokes with an internal linguistic
dictionary to determine the correct word,
thus requiring far fewer keystrokes than
the traditional ABC mode.
ABC Mode
This mode allows you to enter letters by
pressing the key labeled with the required
letter once, twice, three or four times
until the letter is displayed.
123 Mode (Numbers Mode)
Type numbers using one keystroke per
number. To change to 123 mode in a text
entry field, press key until 123 mode
is displayed.
A long press toggles between Abc and
T9 modes.
Symbol Mode
This mode allows you to enter special
characters.
n Note
You can select a different T9 language from the
Options menu. The default setting on the phone
is T9 disabled mode.
Changing the Text Input Mode
Change the text input mode by pressing
.
You can check the current text input mode
in the upper right corner of the screen.
Using the T9 Mode
The T9 predictive text input mode allows
you to enter words easily with a minimum
number of key presses. As you press
each key, the phone begins to display the
characters that it thinks you are typing
based on a built-in dictionary. As new
letters are added, the word changes to
reflect the most likely candidate from the
dictionary.
1.
When you are in the T9 predictive text
input mode, start entering a word by
23
General Functions
pressing keys to . Press one
key per letter.
] The word changes as letters are
typed - ignore what’s on the screen
until the word is typed completely.
] If the word is still incorrect after
typing completely, press the
[Star] key once or more to cycle
through the other word options.
] If the desired word is missing from
the word choices list, add it by using
the ABC mode.
2.
Enter the whole word before editing or
deleting any keystrokes.
3.
Complete each word with a space
by pressing the key or the right
navigation key.
To delete letters, press . Press and
hold down to erase the letters
continuously.
n Notice
To exit the text input mode without saving your
input, press the [END] key.
Using the ABC Mode
Use the keypad keys to enter your text.
1.
Press the key labeled with the required
letter:
] Once for the first letter
] Twice for the second letter
] And so on
2.
To insert a space, press the key
once. To delete letters, press the
key. Press and hold down the key
to erase the letters continuously.
n Note
Refer to the table below for more information on
the characters available using the keys.
24
General Functions
Using the 123 (Numbers) Mode
The 123 Mode enables you to enter
numbers in a text message (a telephone
number, for example) more quickly.
Press the keys corresponding to the
required digits before manually switching
back to the appropriate text entry mode.
Using the Symbol Mode
The Symbol Mode enables you to enter
various symbols or special characters.
To enter a symbol, press the [Star]
key. Use the navigation keys to select the
desired symbol and press the [OK] key.
T9 dictionary
The T9 dictionary is a feature that allows
the user to add any unique or personal
words to the T9 standard language
database. The T9 dictionary function can
be selected from the Text Entry Settings
sub menu under the Options soft key
menu. Within the T9 dictionary function,
the user can add, modify, delete or reset
personal words.
Key
Characters in the Order Display
Upper Case Lower Case
1 . , ' @ ? ! - : / 1 . , ' @ ? ! - : / 1
2 A B C 2 a b c 2
3 D E F 3 d e f 3
4 G H I 4 g h i 4
5 J K L 5 j k l 5
6 M N O 6 m n o 6
7 P Q R S 7 p q r s 7
8 T U V 8 t u v 8
9 W X Y Z 9 w x y z 9
0
Space Key,
0 (Long press)
Space Key,
0 (Long press)
25
Your phone offers a set of functions that allow you to customize the phone. These
functions are arranged in menus and sub-menus, accessed via the two soft keys
marked the left soft key and the right soft key. Each menu and sub-menu
allows you to view and alter the settings of a particular function.
Soft key functions vary depending on the model of the phone. The label on the bottom
of the display screen immediately above the soft keys indicates the current function.
Selecting Functions and Options
Press the left soft key
to access the available
Menu.
Press the right soft key
to access the Favorite
Menu .
Pressing this Key from standby mode
launches the browser. Pressing it within
menus confirms menu options.
26
1. TV & Video (see page 36)
1.1 Mobile TV
1.2 CV-Video
1.3 Music Videos
1.4 Entertainment Videos
1.5 Sports Videos
1.6 Shop Videos
1.7 Video Applications
2. Messaging (see page 43)
2.1 New Message
2.2 Inbox
2.3 IM
2.4 Mobile Email
2.5 Drafts
2.6 Outbox
2.7 Sent
2.8 Voicemail
2.9 Templates
2.9.1 Text Templates
2.9.2 Multimedia Templates
2.9.3 Signature
2.0 Message Settings
2.0.1 Text Message
2.0.2 Multimedia Message
2.0.3 Voicemail
2.0.4 Service Messages
3. Recent Calls (see page 56)
3.1 Missed Calls
3.2 Dialed Calls
3.3 Received Calls
3.4 All Calls
3.5 Call Duration
3.6 Data Counter
4. MEdia Net (see page 58)
4.1 MEdia Net Home
4.2 Bookmarks
4.3 Saved Pages
4.4 Enter URL
4.5 Recent Pages
4.6 Security
The following illustration shows the available menu structure and indicates the:
]
Number assigned to each menu option.
]
Page where you can find the feature description.
Menu Tree
Loading...
