LG AX830 User Guide

Download

ENGLISH

Guárdelo para consultarlo en el futuro. Lea este manual cuidadosamente antes de utilizar su teléfono.

MANUAL DEL USUARIO

USER GUIDE

Please read this manual carefully before operating your mobile phone. Retain it for future reference.

ESPAÑOL

P/N : MMBB0267801(1.0)

Copyright ©2008 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners.

Important Safety Precautions

Read these instructions. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

WARNING! Violation of the instructions may cause serious injury or death.

1. Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

2. Never place your phone in a microwave oven as it will cause the battery to explode.

3. Never store your phone in temperatures less than

-4°F or greater than 122°F.

4. Do not dispose of your battery by fire or with hazardous or flammable materials.

5. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is deployed, you may be seriously injured.

6. Do not use a hand-held phone while driving.

7. Do not use the phone in areas where its use is prohibited. (For example: aircraft)

Important Safety Precautions

1. Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

2. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. This

Important Safety Precautions

could cause a fire.

3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the phone.

4. Do not use your phone in high explosive areas as the phone may generate sparks.

5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause electric shock or fire.

7. Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

8. Do not disassemble the phone.

1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

2. Do not hold or let the antenna come in contact with your body during a call.

3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

4. Store the battery out of reach of children.

5. Be careful that children do not swallow any parts (such as rubber plugs, earphone, connection parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury or death.

6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

7. Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

8. Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

9. Your service provider programs one or more emergency phone numbers, such as 911, that you can call under any circumstances, even when your phone is locked. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

Important Safety Precautions

Important Safety Precautions 1

Table of Contents 4

Welcome 9

Technical Details 10

FCC RF Exposure Information 12

Table of Contents

Bodily Contact During Operation 12

Vehicle-Mounted the External Antenna 13

FCC Notice and Cautions 13

Phone Overview 14

Touch Sensitive Soft Keys 15

Touch Screen Shortcut Menu 17

Menus Overview 18

Menu Access 21

Getting Started with Your Phone 22

The Battery 22

Installing the Battery 22

Removing the Battery 22

Charging the Battery 22

Battery Charge Level 23

Turning the Phone On and Off 23

Turning the Phone On 23

Turning the Phone Off 23

Signal Strength 24

Screen Icons 24

Making Calls 24

Correcting Dialing Mistakes 25

Redialing Calls 25

Receiving Calls 25

Quick Access to Convenient Features 26

Lock Mode 26

Mute Function 26

Volume Quick Adjustment 26

Call Waiting 26

Caller ID 27

Speed Dialing 27

Entering and Editing Information 28

Text Input 28

Contacts in Your Phone’s Memory 29

The Basics of Storing Contacts Entries 29

Phone Numbers With Pauses 29

Storing a Number with Pauses 30

Adding a Pause to an Existing Number 30

Searching Your Phone’s Memory 31

Accessing Options 31

Making a Call From Your Phone’s Memory 32

Using Phone Menus 34

Recent Calls 34

1. Missed Calls 34

2. Received Calls 35

3. Dialed Calls 35

4. Data 35

5. All Calls 35

6. Call Timer 35

7. Data Counter 36

Contacts 36

1. New Contact 36

2. Contact List 37

3. My Circle 37

4. Groups 38

5. Speed Dials 38

6. My Name Card 39

Table of Contents

Messaging 39

1. New Text Message 39

2. New Picture Message 42

3. Inbox 43

4. Sent 45

5. Drafts46

6. Voicemail 46

7. Quick-Text 47

8. Settings 47

9. Delete All 49

New Events Manager 50

Table of Contents

Axcess Web 50

1. Start Browser 50

2. Web Messages 52

3. Web Settings 53

Axcess Shop 53

1. Axcess Shop 54

2. Axcess Info 55

Music 56

Shuffle 56

Table of Contents

Multimedia 56

Take Photo 57

Image 58

Record Video 59

Video 60

Audio 61

Axcess TV 61

Tools 62

Voice Command 62

Alarm Clock 62

Calendar 63

World Clock 63

Calculator 64

Ez Tip Calc 64

Notepad 65

Unit Converter 65

Settings 66

Display 66

1. Wallpaper 66

2. Banner 66

3. Backlight 66

4. Languages 67

5. Clocks & Calendar 67

6. Font Settings 68

7. Color Scheme 68

Sound & Touch 69

1. Ringers 69

2. Volume 69

3. Message Alert 69

4. Alert Type 70

5. Service Alerts 70

6. Power On/Off Tones 71

7. Slide Tone 71

8. Touch Key Feedback 71

9. Touch Calibration 72

Bluetooth

1. Power 73

2. Add New 73

3. Paired Devices 74

4. Settings 74

4.1 Power 74

4.2 Visibility 75

4.3 Device Name 75

4.4 Device Info 75

USB Connection 76

Security 78

1. Lock Phone 78

2. Restrictions 78

3. Emergency #s 79

4. Change Lock Code 79

5. Reset Default 80

Call Settings 80

1. Answer Options 80

2. End Options 81

3. Auto Retry 81

4. One-Touch Dial 81

5. Voice Privacy 82

6. Auto Volume 82

7. Airplane Mode 82

8. TTY Mode 83

System 83

1. Network 83

2. Location 85

Phone Information 85

1. My Number 85

2. ESN/MEID 86

3. Icon Glossary 86

4. Version 86

5. Software Update 86

6. Memory 87

Safety 88

TIA Safety Information 88

Exposure to Radio Frequency Signal 88

Antenna Care 88

Phone Operation 89

Table of Contents

Tips on Efficient Operation 89

Driving 89

Electronic Devices 89

Pacemakers 89

Persons with pacemakers: 90

Hearing Aids 90

Other Medical Devices 90

Health Care Facilities 90

Vehicles 91

Table of Contents

Posted Facilities 91

Aircraft 91

Blasting Areas 91

Potentially Explosive Atmosphere91

For Vehicles Equipped with an Air Bag 92

Safety Information 92

Charger and Adapter Safety 92

Battery Information and Care 93

Explosion, Shock, and Fire Hazards 93

General Notice 94

Warning! Important safety information 96

Avoiding hearing damage 96

Using your phone safely 96

Avoiding hearing damage 97

Using headsets safely 97

FDA Consumer Update 98

10 Driver Safety Tips 108

Consumer Information on SAR 112

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices 115

Accessories 118

Limited Warranty Statement 119

Index 123

Thank you for choosing the

™

cellular phone designed

Glimmer to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this compact phone offers:

Music capability and microSD

™

card slot.

Significantly enhanced voice

clarity

Slim and sleek design with internal antenna (Internal antenna described as antenna throughout this user guide).

Large, easy-to-read, 9-line backlit LCD with status icons.

Paging, messaging, voice mail, and caller ID.

15-key keypad and Touch Screen.

Speakerphone feature.

Welcome

Menu-driven interface with prompts for easy operation and configuration.

Any key answer, auto answer, auto retry, one-touch and speed dialing with 99 memory locations.

Bilingual (English and Spanish) capabilities.

Bluetooth®wireless technology.

Note

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.

Welcome

Technical Details

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your warranty.

Technical Details

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Technical Details

The Glimmer™is an all digital phone that operates on both Code Division Multiple Access (CDMA) frequencies: Cellular services at 800 MHz and Personal Communication Services (PCS) at

1.9 GHz.

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard handoff, and dynamic RF power control technologies combine to reduce call interruptions.

The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), and MS (Mobile Station).

* TSB-74: Protocol between an IS-

95A system and ANSI J-STD008

Its battery life is twice as long as IS-95. High-speed data

transmission is also possible. The following tab lists some

major CDMA standards.

CDMA Standard

Basic Air Interface

Network

Service

1x EV-DO

Related interface

Designator

TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-96-B TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 TIA/EIA/IS-707-A

TIA/EIA/IS-856 TIA/EIA/IS-878

TIA/EIA/IS-866

TIA/EIA/IS-890

Description

CDMA Dual-Mode Air Interface

14.4kbps radio link protocol and interband operations IS-95 adapted for PCS frequency band CDMA2000 1xRTT Air Interface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Speech CODEC Short Message Service Packet Data Position Determination Service (gpsOne) High Speed Packet Data

CDMA2000 High Rate Packet Data Air Interface

1xEV-DO Inter-Operability Specification for CDMA2000 Access Network Interfaces

Recommended Minimum Performance Standards for CDMA2000 High Rate Packet Data Access Terminal Test Application Specification (TAS) for High Rate Packet Data Air Interface

Technical Details

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for

Technical Details

human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 0.79 inches (2.0 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of

0.79 inches (2.0 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Thirdparty belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot maintain

0.79 inches (2.0 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted the External Antenna

(Optional, if available.)

To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted the external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

FCC Notice and Cautions

Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Use only the supplied antenna. Use of unauthorized antennas (or modifications to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations.

Don't use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

Technical Details

Phone Overview

1.Earpiece Lets you hear the caller.

2. Slide Slide up to answer an incoming call and

slide it down to end the call.

3.LCD Screen Displays incoming calls, messages

and indicator icons as well as viewing a wide variety of content you select to view.

4.TALK Key Use to place or answer calls.

5.Alphanumeric Keypad Use to enter numbers

and characters and select menu items.

Lock Mode Key

standby mode press and hold for about 3 seconds).

Microphone

8.BACK Key Deletes single spaces or characters

with a quick press, but press and hold to delete entire words. Will also back you out of menus, one level at a time.

9.PWR/END Key Use to turn the power on/off

and to end a call. Also returns to standby mode.

10.

Axcess Search Key

games, and images with Free Axcess Search. Axcess Search puts the mobile web at your fingertips. Search for music, images, news, weather, stocks, mobile web links, and local services from the search box.

11.

Camera Lens

video. Keep it clean for optimal photo quality.

12.

Flash

Use to lock the phone (from

Lets callers hear you.

Find the latest ringtones,

Used to take photos and record

microSD™card slot

(accommodates optional

™

microSD

card up to

™

Insert microSD

4GB.)

card for external memory. Use LG-approved

™

card. To access

microSD

™

card slot

the microSD you must remove the battery cover located on the back of your phone.

Touch Sensitive Soft Keys

( , , , )

1. Make sure your hands are clean and dry. Remove moisture from the surface of your hands. Don't use the touch keys in a humid environment.

2. Touch key sensors are sensitive to your light touch. You don't need to press them forcefully to use them. Protect

1.HOLD Key Use to lock your phone

when the slide is closed. To unlock, press or slide up.

2.Earphone Jack Allows the use of a

headset to hear caller's voice.

3.Charger Port Connects the phone

to the battery charger or other available accessories.

4.Side Keys Use to adjust the ringer

volume in standby mode and the earpiece volume during a call.

5.Side Camera Key Use for quick

access to Camera functions.

your phone from severe impact because touch key sensors may become damaged from harsh use.

3. Use the tip of your finger to touch the center of a touch key. If you touch off-center it may activate the nearby function instead.

4. The touch sensor level can be adjusted to your preference.

Phone Overview

5. When both the outside LCD screen and touch key lights are off, touch keys are deactivated. Press the Unlock Key ( ) to turn on the Touch Screen and touch key lights.

6. If the slide is closed and the Touch Protection function is on, during calls the Touch Protection feature is

Phone Overview

automatically enabled.

7. Keep metal and other conductive material away from the surface of touch keys because contact may cause electronic interference.

WARNING

Do not put heavy objects on the Touch Screen.

Do not sit on your phone because it may damage the Touch Screen.

Do not drag or scratch your phone with any sharp materials.

Do not keep your phone in extreme conditions (places that are too humid, hot, or cold).

Keep chemicals away from your phone because they may change the cosmetic or functional features of your phone.

Warning! Do not sit on your phone or put heavy items on it as it may damage your phone.

The Touch Screen is a great way to interact with the

™

Glimmer

’s software. Take a little time to become accustomed to using it. If it doesn’t react as you expect, adjust the Touch Screen calibration.

TIP

Keep in mind that the smaller the text appears on the screen, the smaller the area of touch activation. Try zooming the screen in, if available, to increase the touch area.

Touch Screen Shortcut Menu

The Touch Screen Shortcut Menu allows instant access to menus with the quick touch of your fingertip. To use the Shortcut Menu:

1. Touch on the screen (located above the Touch Soft Keys) from standby mode. You may need to touch first if the screen is locked.

2. The Shortcut Menu will open. Touch any of the options for quick access to frequently used applications.

3. To close the Shortcut Menu, touch or the Key.

Touch Soft Keys

From standby mode, touch the Touch Screen with your finger.

Menu: Displays

a list of menus.

Phone Overview

Phone: Displays additional touch keys so you

can make a call without opening the slide. Dial manually using the numeric keys or automatically from Recent Calls and Contacts.

Message:

Displays the Messaging menu.

Contacts:

Displays your Contact List.

Menus Overview

Recent Calls

1. Missed Calls

2. Received Calls

3. Dialed Calls

4. Data

5. All Calls

6. Call Timer

1. Last Call

2. Home Calls

3. Roam Calls

4. All Calls

7. Data Counter

1. Received Data

2. Sent Data

3. All Data

Contacts

1. New Contact

2. Contact List

3. My Circle

4. Groups

5. Speed Dials

6. My Name Card

Messaging

1. New Text Message

2. New Picture Message

3. Inbox

4. Sent

5. Drafts

6. Voicemail

7. Quick-Text

8. Settings

1. All Messages

2. Text Message

3. Picture Message

4. Edit Voicemail#

9. Delete All

1. Delete Inbox

2. Delete Sent

3. Delete Drafts

4. Delete All Messages

New Events

Manager

Axcess Web

1. Start Browser

2. Web Messages

3. Web Settings

Axcess Shop

1. Axcess Shop

2. Settings

3. Help

4. Axcess Info

Music

1. All Songs

2. Playlists

3. Recently Played

4. Artists

5. Genres

6. Albums

Voice Command

Alarm Clock

Calendar

Shuffle

Take Photo


Record Video

Video

Audio

Axcess TV

World Clock

Menus Overview

Calculator

Ez Tip Calc

Notepad

Unit Converter

Menus Overview

Display

1. Wallpaper

2. Banner

3. Backlight

4. Languages

5. Clocks & Calendar

6. Font Settings

7. Color Scheme

Menus Overview

Sounds & Touch

1. Ringers

2. Volume

3. Message Alert

4. Alert Type

5. Service Alerts

6. Power On/Off Tones

7. Slide Tone

8. Touch Key Feedback

9. Touch Calibration

Bluetooth

1. Power

2. Add New

3. Paired Devices

4. Settings

USB Connection

1. USB Modem

2. USB Mass Storage

Security

1. Lock Phone

2. Restrictions

3. Emergency #s

4. Change Lock Code

5. Reset Default

Call Settings

1. Answer Options

2. End Options

3. Auto Retry

4. One-Touch Dial

5. Voice Privacy

6. Auto Volume

7. Airplane Mode

8. TTY Mode

System

1. Network

2. Location

Phone Information

1. My Number

2. ESN/MEID

3. Icon Glossary

4. Version

5. Software Update

6. Memory

Menu Access

Touch the MENU Touch Key to have access to phone menus. To access the MENU, unlock first by pressing down the unlock key on the left side of your phone. To go back to standby mode, touch or press at the bottom center of your phone.

Menus Overview

Getting Started with Your Phone

The Battery

Note

It is important to fully charge the battery before initial use of the phone.

Getting Start ed with Your Phone

The phone comes with a rechargeable battery. Keep the battery charged while not in use in order to maximize talk and standby time. The battery charge level is shown at the top of the LCD screen.

Installing the Battery

Insert the bottom of the battery into the opening on the back of the phone, then push the battery down until the latch clicks.

Removing the Battery

1. Turn off the phone, then push down on the battery cover button (located on the top of your phone).

2. While holding down the battery cover button, lift and remove the battery cover.

3. Lift the top of the battery out using the fingertip cutouts, then remove it.

Charging the Battery

To use the charger provided with your phone:

Warning! Use only the charger provided with the phone. Using any charger other than the one included with the Glimmer damage your phone or battery.

1. Plug the end of the adapter into the phone’s charger port and the other end into an electrical outlet.

2. The charge time varies depending upon the battery level.

™

may

Notice

Please make sure that the LG logo faces up before inserting a charger, data cable, etc into the charger port of your phone.

Battery Charge Level

The battery charge level is shown at the top right of the LCD screen. When the battery charge level becomes low, the low battery sensor alerts you in three ways: sounding an audible tone, blinking the battery icon, and displaying a warning message. If the battery charge level becomes exceedingly low, the phone automatically switches off and any function in progress is not saved.

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source.

2. Open the slide to reveal the keypad.

3. Press for about 3 seconds until the LCD screen lights up.

Turning the Phone Off

1. Open the slide to reveal the keypad.

2. Press and hold until the display turns off.

Getting Start ed with Your Phone

Getting Started with Your Phone

Signal Strength

Call quality depends on the signal strength in your area. The signal strength is indicated on the screen as the number of bars

Getting Start ed with Your Phone

next to the signal strength icon

. The more bars, the better the signal strength. If the signal quality is poor, move to an open area. If you are in a building, the reception may be better near a window.

Note

The call quality is also affected by the places where you are and weather conditions with radio frequency (RF) emission changes.

Screen Icons

To see the icon glossary, touch

-> -> ->

Glossary

on your phone.

Icon

Making Calls

1. Make sure the phone is turned on. If not, press for about 3 seconds.

2. Enter the phone number (include the area code if needed).

3. Press or touch .

lf the phone is locked, press the Unlock Key on the left side of your phone.

Note

If the phone is restricted, you can only dial phone numbers saved in the Emergency Numbers or your Contact List. To turn off this function: ->

Security -> Enter Lock Code. ->

2 Restrictions -> Enter Application

Lock Code. ->

1 Calls -> 4 None

Call

Settings ->

4. Press or touch to

END

end the call.

Correcting Dialing Mistakes

If you make a mistake while dialing a number, press or touch once to erase the last digit entered, or hold down or touch and hold for at least 2 seconds to go to standby mode.

Redialing Calls

1. Press twice to redial the last number you dialed. The last 150 numbers (dialing, incoming, missed) are stored in the call history list and you can also select any of these to redial.

Receiving Calls

1. When the phone rings or vibrates, press to answer.

Tip

Call Settings Menu allows you to choose answer options:

Open Slide/ Press Any Key/ Press Send Key only/ Auto Answer

Note

If you press or (the side keys), while the phone is ringing, the ringing or vibration is muted for that call.

2. Press to end the call.

Getting Start ed with Your Phone

Quick Access to Convenient Features

Lock Mode

Sets your phone to require a 4digit password in order to use the phone.

Quick Access to Convenient Features

Note

Until you change it, the default lock code/password is the last 4 digits of your phone number.

To quickly lock your phone press

for three seconds. To cancel, touch and enter the password.

Unlock

Mute Function

The Mute Function is used during a phone call. To quickly activate the Mute function, touch

and touch

Touch to mute and unmute.

Mute/Unmute

- or -

Volume Quick Adjustment

Use the side keys to adjust the ringer volume in standby mode, and the earpiece volume during a call. The upper key increases the volume and the lower key decreases the volume.

Note

Keypad Volume is adjusted through the Sounds Volume Menu. ( -

Volume ->Keypad).

>->

Sound & Touch

Call Waiting

Your cellular service may offer call waiting. While a call is in progress, two beeps indicate another incoming call. When call waiting is enabled, you may put

the active call on hold while you answer the other incoming call. Check with your cellular service provider for information about this function.

1. Press to receive a waiting call.

2. Press again to switch between calls.

Caller ID

Caller ID displays the phone number or name of the incoming call. If the caller’s identity is stored in Contacts, the name will appear along with the phone number. Check with your service provider to ensure they offer this feature.

Speed Dialing

Speed dialing is a convenient feature that allows you to make phone calls quickly. A number key can be assigned to a specific phone number. By pressing and holding down a number key, your phone will recall the phone number associated from the Contact List and display it briefly

while simultaneously dialing that phone number for you. Speed Dial Number 1 is set to Voice Mailbox by default and is unchangeable.

Dialing Single Digit Speed Dials (from 2 to 9)

Press and hold the Speed Dial number.

Enter the Speed Dial number and press .

Dialing Double Digit Speed Dials (from 10 to 99)

Press the first digit and then press and hold the key of the second digit.

Enter the first and second digits and press .

Quick Access to Convenient Features

Entering and Editing Information

Text Input

You can enter information using the Touch Screen or the keypad. Each has special key functions to help you with text entry.

Using the Touch Screen

Entering and Editing Information

When creating a Text, Picture or Video message using the outside LCD, the Touch Screen provides you with Touch Keys specific to the type of field. Refer to the example below:

When you touch the Touch Key the following dialing keypad is displayed.

Touch this key

Back

Touch this key to view the recent call history and simply touch a phone number to call it.

to go back to standby mode.

Options

Contacts in Your Phone’s Memory

The Basics of Storing Contacts Entries

1. From standby mode enter the phone number you want to save (up to 48 digits).

2. Touch .

Save

3. Touch

New Entry

on the pop-up screen.

4. Touch a Phone Label.

Mobile/Home/Work Pager/ Fax/ None

Note

Use phone number to a contact already stored in memory.

5. Enter a name for the phone number (up to 32 characters) and touch A confirmation message is displayed briefly.

and select either

Existing Entry

Save

Existing Entry

to add another

Phone Numbers With Pauses

When you call automated systems such as voice mail or credit billing numbers, you often have to enter a series of numbers to navigate through the system. Instead of entering these numbers by hand, you can store the numbers in your Contacts separated by special pause characters (W, P). There are two different types of pauses you can use when storing a number:

Wait (W)

The phone stops dialing until you select the next number.

Pause (P)

The phone waits 2 seconds before sending the next string of digits.

Release

to advance to

Contacts in Your Phone’s Memory

Storing a Number with Pauses

1. Touch .

2. Touch

3. Touch

Contacts in Your Phone’s Memory

4. Enter a name (up to 32 characters) and touch the number field to enter a number.

5. Touch and select or

6. Enter additional number(s) then touch

Contacts

1 New Contact

2 Pause

Save

Adding a Pause to an Existing Number

1 Wait

1. Touch . to display your Contacts alphabetically.

2. Scroll through the list and touch the Contact entry you wish to edit. Touch .

3. Touch

Edit

4. Touch the number.

5. Touch .

6. Touch

Wait

Pause

7. Enter additional number(s), then touch

8. Touch a Phone Label.

Mobile/ Home/ Work/ Pager/ Fax/ None

9. Touch

Save

Searching Your Phone’s Memory

The Glimmer™phone is able to perform a dynamic search of the contents in your phone’s memory. A dynamic search compares entered letters or numbers against the entries in your Contacts. A matching list is displayed in descending order. You can then select a number from the list to call or edit.

Scrolling Through Your Contacts

1. Touch to display your Contacts alphabetically.

2. Scroll through the list.

Searching by Letter

1. Touch to display your contacts alphabetically.

2. Press (or press repeatedly) the key on the alphanumeric

keypad that corresponds with the search letter.

Accessing Options

1. Touch .

2. Touch .

3. Touch the search criteria:

Send Message

message or picture message to the selected contact.

New Contact

contact to your Contact List.

Edit

: Edit the selected contact

information.

Delete

entry from your Contacts.

Delete Multiple

contact entries at one time.

Send Contact

contact(vCard) via

: Send a text

: Add a new

: Delete the selected

: Delete multiple

: Send a

Bluetooth

Contacts in Your Phone’s Memory

. In

Contacts in Your Phone’s Memory

case

Bluetooth

a notice pops up to turn

Bluetooth

on.

Set Speed Dial/ Remove Speed

Contacts in Your Phone’s Memory

: Add the selected number

Dial

to, or remove it from My Circle.

Set As My Circle/ Remove My

: Add the selected number

Circle

to, or remove it from My Circle.

Making a Call From Your Phone’s Memory

Once you have stored phone numbers in your Contacts, you can place calls to those numbers quickly and easily.

By highlighting a phone number in Contacts or Recent Calls, and pressing or

Call

touching

By using Speed Dialing.

power is not on,

From Contacts

1. Touch to display your Contacts.

2. Touch the Contact entry.

3. Touch the phone number.

4. Press or touch place the call.

From Recent Calls

1. Touch from standby mode.

2. Touch the type of recent call.

Call

From Recent Calls/ From Speed Dials/ From Contact List/ From Message Inbox

3. Touch the phone number.

4. Touch or press to

Call

place the call.

Speed Dialing

For a single-digit Speed Dial, press and hold the digit or press the digit, then press . For a double-digit Speed Dial, press the first digit and hold the second digit or press the first and second digits, then press

Contacts in Your Phone’s Memory

Using Phone Menus

Recent Calls

The Recent Calls Menu is a list of the last phone numbers or Contact entries for calls you placed, accepted, or missed. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

Using Phone Menus

Note

To view a quick list of all your recent calls, press from standby mode.

Shortcut

Touch on the touchpad to access the Recent Calls menu from standby mode. Make a call from the following options: From Recent Calls, From Speed Dials, From Contacts List or From Message Inbox.

TALK Key

1. Missed Calls

Allows you to view the list of missed calls; up to 50 entries.

1. Touch .

2. Touch .

1 Missed Calls

3. Touch

4. Touch the entry.

Press to place a call to the number.

Touch to select

Save/ Send Message/ View Timer/ Delete/ Delete

Multiple

Note

The Save Option will be displayed as Contacts if the selected number is already saved in your Contacts.

Press to return to standby mode.

Call/

2. Received Calls

Allows you to view the list of incoming calls; up to 50 entries.

1. Touch .

2. Touch .

2 Received Calls

3. Touch

4. Touch the entry.

3. Dialed Calls

Allows you to view the list of outgoing calls; up to 50 entries.

1. Touch .

2. Touch .

3 Dialed Calls

3. Touch

4. Touch the entry.

4. Data

Allows you to view the list of data calls; up to 50 entries.

1. Touch .

2. Touch .

3. Touch

4 Data

4. Touch the entry.

5. All Calls

Allows you to erase selected call list(s).

1. Touch .

2. Touch .

5 All Calls

3. Touch

4. The history of all calls is displayed.

6. Call Timer

Allows you to view the duration of selected calls.

1. Touch .

2. Touch .

6 Call Timer

3. Touch

4. Touch a call list.

Last Call/Home Calls/Roam

All Calls

Calls

Using Phone Menus

7. Data Counter

Allows you to view the list of received and transmitted data calls.

1. Touch .

2. Touch .

7 Data Counter

3. Touch

4. Touch a data call list.

Using Phone Menus

Received Data/Sent Data All Data

Contacts

The Contacts Menu allows you to store names, phone numbers and other information in your phone’s memory. When you access your Contacts, the number in parentheses represents the

number of entries you have stored (up to 500).

1. New Contact

Allows you to add a new contact to your Contact List.

Note

Using this submenu, the number is saved as a new Contact. To save the number into an existing Contact, edit the Contact entry.

1. Touch .

2. Touch .

3. Touch

1 New Contact

4. Enter the name.

5. Touch the Phone Number field , and enter the number.

6. Continue entering Contact

information by touching the corresponding field and entering the desired information.

2. Contact List

Allows you to view your Contact List.

1. Touch .

2. Touch .

2 Contact List

3. Touch

4. Touch a Contact entry.

5. Choose from the following

options:

Scroll through your Contacts alphabetically.

Touch to select one of the following:

Send Message/ New Contact/ Edit/ Delete/ Delete Multiple/ Send Contact/ Set(Remove) Speed Dial/ Set As(Remove) My Circle

Touch

New Contact

to store new contact information.

3. My Circle

Allows you to assign some of your Contacts as favorites, and quickly send them messages.

1. Touch .

2. Touch .

3 My Circle

3. Touch

4. Touch the My Circle location (or press the corresponding number key on the keypad).

5. Touch the Contact.

6. Touch the icon next to the

Using Phone Menus

phone number to switch between numbers, then touch

Select

A confirmation message is displayed.

4. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, or

Using Phone Menus

delete a whole group.

1. Touch .

2. Touch .

4 Groups

3. Touch

4. Choose from the following options:

Touch a group to view.

Touch a group, then touch

to choose from the

following options:

Send Message/ New Group/

Edit/ Delete/ Delete Multiple/ Send via Bluetooth

5. Speed Dials

Allows you to view your Speed Dials list, designate new Speed Dials, or remove Speed Dial designations entered in your Contacts.

1. Touch .

2. Touch .

5 Speed Dials

3. Touch

4. Touch the Speed Dial location (or press the corresponding number key on the keypad) and touch

5. Touch the Contact.

6. Touch the icon next to the phone number to switch between numbers, then touch

Select

Assign

A confirmation message is displayed.

6. My Name Card

Allows you to view all of your personal Contact information including name and phone numbers.

1. Touch .

2. Touch .

6 My Name Card

3. Touch

4. Touch

Edit

5. Touch the feature you want to edit.

6. Edit the information as necessary and touch

Note

You cannot edit your mobile phone number, but you can add an additional phone number.

Save

Messaging

The phone can store up to 540 messages. The Glimmer supports up to 160 characters. The information stored in the message is determined by phone model and service capability. Other limits such as available characters per message may exist, please check with your service provider for system features and capabilities.

Shortcut

From standby mode, touch .

1. New Text Message

Allows you to send text messages, pages, and e-mail transmissions. Each message will be formatted and sent according to the destination address.

™

Using Phone Menus

The Basics of Sending a Text Message

1. Touch .

2. Touch

Messaging

1. New Text Message

3. Touch the address field and enter the recipient's address.

4. Touch the Message tab to

Using Phone Menus

access the message screen.

Type your message (text or

5. e-mail).

6. Touch .

Send

A confirmation message is displayed.

Customizing the Text Message Using Options

1. Touch .

Messaging

2. Touch

1 New Text Message

3. Touch .

4. Touch the option(s) to

customize.

and

Contacts

from your Contact List.

Recent Calls

recipient from your Recent Calls.

Recent Messages

Inbox/Sent

from your Recent Messages.

Groups

your Groups.

General/Family/Friends

To select a recipient

To select a

Choose

to select a recipient

Select a recipient from

Colleagues/Business/School

Priority Level

High

your message.

Callback #

Edit

to set your callback number

callback number.

Delivery Notice

Enhanced/Normal

status of the Delivery Notice.

Cancel

message.

5. Complete and send the message.

Choose

Normal

to set the priority level of

Choose On/

Off

, or to edit your

Cancels editing your

Off

Choose

to set the

Text Options

While you are composing the text of a message you can insert customized text.

1. Touch .

2. Touch

Messaging

1 New Text Message

and

3. Touch the Message tab to access the message screen.

4. Touch .

5. Touch the option(s) to customize.

Add Graphic/Animation

Sound/Quick-Text/Signature

Text Format Alignment/ Font

Size/ Font Style/ Text Color/ Background

Note

Messages with advanced features cannot be sent to e-mail. If the text format is set, the message is sent in a form of photo message. Depending on the network, such enhanced messages may not be supported.

Message Icon Reference

Text Message Picture Message

Description Normal High Normal High

Sent

Fail

Pending

Cancel

Delivery Acknowledgement

Read

Incomplete

WAP Push Msg

Voice Msg

Draft

Single Address Multi-Address

Normal High Normal High

Using Phone Menus

Save As Draft/Quick-Text

Priority Level Normal

Callback # On/ Off/ Edit

Delivery Notice Enhanced

Normal

Cancel message

your message.

6. Complete your message and

Using Phone Menus

send or save it.

2. New Picture Message

Allows you to send messages with Text, Image/ Video, and Audio.

1. Touch .

Messaging

2. Touch

2 New Picture Message

3. Touch the address field and enter the recipient's address.

4. Touch the enter a subject for your message.

Subject

High

Cancels editing

and

tab and

Slide1

5. Touch the Text, Image/ Video, and Audio to your message.

Image/Video: Image/ Video/

tab to add

Take Photo/ Record Video

6. Touch the Image or Video you want to add.

TIP

Touch the selected image smoothly on the screen to move to the previous/next images.

Audio

7. Touch option you want to select.

, then touch the

Add Audio/ Record Voice

8. Select the option(s) to customize.

* Editing the Receiver

Contacts/ Recent Calls/ Recent messages/ Groups/ Online Album/ Priority Level/ Delivery Notice/ Cancel

* Editing the Text

Preview

Shows your message

before sending.

Add Quick-Text/Slide

Save As Draft

Priority Level Normal

Delivery Notice

Quick-Text

Informs

High

you that the message has been successfully delivered to the recipient.

Enhanced/Normal

Remove Image/Video

Audio

Slide

Cancels the contents of

Cancel

message field.

* Editing Subject

Preview/Add Quick-Text Save As/Priority Level

Delivery Notice/Cancel

9. Touch to send.

Send

3. Inbox

The phone alerts you in 3 ways when you receive a new message by:

Displaying a notification message on the screen.

Displaying the message icon

(It blinks when the

message is urgent).

Playing an audio tone or

Using Phone Menus

vibrating, depending on your

personal sound settings.

Received text messages, page messages, picture messages and e-mail lists may be searched and the contents viewed. Received messages are displayed from

newest to oldest.

Viewing Your Inbox

Up to 400 messages (200 text messages + 100 received picture messages + 100 picture message

Using Phone Menus

notifications) can be stored in the Inbox.

1. Touch .

2. Touch

Messaging

3 Inbox

3. Touch an Inbox message.

Touch

Using Phone Menus

message.

Touch to choose from the following options:

Text Messages

Forward/ Save Contact/ Lock/ Delete Multiple/ Information

Picture Messages

Call/ Delete/ Forward/ Save Contact/ Lock/ Delete Multiple/ Message Info

4. While viewing the selected message, touch

and

to reply to the

: Call/ Delete/

: Reply/

or .

Save Media

Audio

media to your phone. (Only for messages with Images or Audio attached.)

Save Video

video to your phone. (Only for messages with video attached.)

Delete

message.

Forward

message to other destination address(es).

Reply with Copy

reply by entering text within the body of the received message.

Save Contact

number, e-mail address, and numbers in the received message into your Contacts.

Call Back

the received message.

Choose


to save the attached

Saves the attached

Deletes the selected

Forwards a received

Allows you to

Stores the callback

Calls the number in

Go to website

website by starting Axcess Web. (Only for messages containing a URL.)

Lock/Unlock

the selected message.

Information

type priority and status.

Accesses the

Locks or unlocks

Shows the message

4. Sent

Up to 100 messages (50 sent text messages + 50 sent picture messages) can be stored in the Sent folder. View lists and contents of sent messages and verify whether the transmission was successful or not.

1. Touch .

Messaging

2. Touch

4 Sent

3. Touch an Outbox message. While viewing the selected Outbox message, touch

and

Resend

or touch .

Save Media

Audio

media to your phone. (Only for messages with images or audio attached.)

Save Video

video to your phone. (Only for messages with video attached.)

Delete

message.

Forward

message to other destination address(es).

Save Contact

Entry

phone number in your Contacts.

Save as Quick-Text

message as quick text for future messages.

Lock/Unlock

the selected message.

Choose


to save the attached

Saves the attached

Deletes the selected

Forwards a received

Choose

Existing Entry

Stores the

Locks or unlocks

New

to save the

Using Phone Menus

Go to website

website by starting Axcess Web. (Only for messages containing a URL.)

Information

Type, Priority, and Status.

Accesses the

Shows the message's

5. Drafts

Displays saved messages and draft messages.

Using Phone Menus

1. Touch .

Messaging

2. Touch

5 Drafts

3. Touch a Saved message.

4. Touch to choose from the following options:

Delete

Deletes the selected

message from the Drafts.

Save Contact

Entry

phone number in your Contacts.

Choose

Existing Entry

and

New

to save the

Lock/Unlock

so that it is not erased if the Erase Saved or Erase All feature is used.

Delete Multiple

messages at one time.

5. Touch message.

While viewing the message, touch to choose from the following options:

Locks a message

Deletes multiple

Edit

to edit the Draft

Add/ Text Format/ Save As/ Priority Level/ Callback #/ Delivery Notice/ Cancel Message

When you are finished editing the message, press Send to send it.

6. Voicemail

Allows you to view new voice messages recorded in your voice mail box. Your phone will alert

you when you receive a new voice message.

Checking Your Voicemail Box

1. Touch .

2. Touch

Messaging

6 Voicemail

and

3. Choose from the following options:

Clear

Touch to clear the voice mail count.

Call

Touch to listen to the message(s).

7. Quick-Text

Allows you to display, edit, and add text phrases. These text strings allow you to reduce manual text input into messages.

1. Touch .

2. Touch

7 Quick-Text

Messaging

and

3. Touch a Quick-Text message and touch to choose from the following options:

Edit/ Add/ Delete/ Delete Multiple

8. Settings

Allows you to configure 9 settings for received messages.

1. Touch .

2. Touch

Messaging

8 Settings

3. Touch

All Messages Message/ Picture Message/ Edit Voicemail #.

4. Touch one of the settings.

Message Settings Sub-Menu Descriptions

and

/ Te x t

Using Phone Menus

All Messages

1. Auto Save (Auto Save/ Prompt/ Do Not Save)

With this feature on, messages are automatically saved in the Sent folder when transmitted.

2. Auto Delete (On/ Off)

Using Phone Menus

With this feature on, read messages are automatically deleted when you exceed the storage limit.

3. Entry Mode

Allows you to select the default input method including

12 3 .

4. Signature

Allows you to make/edit a signature to automatically send with your messages.

T9Word, Abc and

5. Speed Messaging (On/ Off)

This feature allows you to speed dial text and picture messages.

For example:

1. Assign the number 2 as a speed dial for one of your contacts.

2. Compose a new text or picture message. In the destination address window, hold down the number 2 key instead of entering the address, and the message will be automatically sent to that contact.

Text Message

1. Auto Play (On/ Off)

Allows the display to automatically scroll down while viewing messages.

2. Callback #

With this feature on, you can input the callback number that will automatically be included when you send a message.

Picture Message

1. Auto Receive (On/ Off)

With this feature on, any media attached to a Picture Message will automatically download when the message is received.

Edit Voicemail #

Allows you to manually enter the access number for Voicemail Service. This feature should only be used when a VMS (Voicemail Service) access number is not provided from the network.

9. Delete All

Allows you to erase all the messages stored in your Inbox, Sent, or Saved messages folders. You can also erase all messages at the same time.

1. Touch .

2. Touch

Messaging

9 Delete All

3. Touch

Delete Inbox/ Delete

/ Delete Drafts/ Delete

Sent All Messages

and

Using Phone Menus

New Events Manager

This menu allows you to view a list of your missed alerts. When there are multiple types of missed alerts (Voicemail, Messaging, Missed Calls, etc.), they will all be displayed in the New Events Manager. If there is only one alert, it will be displayed independently on your

Using Phone Menus

screen, not in the New Events Manager.

1. Touch .

2. Touch

New Events Manager

3. Touch the event you wish to view.

Axcess Web

The Axcess Web feature allows you to view Internet content. Accessibility and selections within this feature are dependent upon your service provider. For specific information on Axcess Web contact your service provider.

1. Start Browser

Allows you to initiate an Axcess Web session.

1. Touch .

Axcess Web

2. Touch

1 Start Browser

3. After a few seconds, you will see the home page.

Ending an Axcess Web Session

End an Axcess Web session by pressing .

and

Navigating Through the Browser

On-screen items may be presented in one of the following ways:

Numbered options

You can use your numeric keypad or you can select the items by moving the cursor and pressing the appropriate Soft Key(s).

Links embedded in content

You can act on the options or the links by using the Soft Keys at the bottom of the display screen.

Text or numbers

You can select the items by moving the cursor and pressing the appropriate Soft Keys.

Scrolling

Use to scroll through the content if the current page does not fit on one screen. The currently selected item is indicated by a cursor on the screen.

Fast Scrolling

Press and hold to quickly move the cursor up and down on the current screen.

Soft Keys

To navigate to different screens or select special functions, use the Soft Keys. The function associated with the Soft Keys can change for each page and depends on each highlighted item.

Touch Soft Keys

The Left Touch Soft Key is used primarily for first options or

Using Phone Menus

selecting an item, but its function may change depending on the content displayed.

The Right Touch Soft Key is used primarily for secondary options or a menu of secondary options.

Entering Text, Numbers, or Symbols

Using Phone Menus

When prompted to enter text, the current text entry mode is displayed on the upper right side of the Touch Screen. To change the input mode, touch the Text Input Mode Touch Key located on the upper right side of the screen. Touch the option you wish to select:

123/ Abc/ ABC/ abc/ T9 Word/ T9 WORD/ T9 word

Clearing Out Text/Numbers

Entered

When entering text or numbers, press to clear the last number, letter, or symbol. Press and hold to clear the input field completely.

Initiating a Phone Call From Axcess Web

You can make a phone call from Axcess Web if the site you are using supports the feature. The browser connection is terminated when you initiate the call. After you end the call, your phone returns to the screen from which you initiated the call.

2. Web Messages

Allows you to view Web messages. If there are any browser messages, the list is

displayed from newest to oldest.

1. Touch .

2. Touch

Axcess Web

2 Web Messages

Your list of Web Messages is displayed.

and

3. Web Settings

Allows you to select a browser alert sound.

1. Touch .

Axcess Web

2. Touch

3 Web Settings

Prompt

Touch an option.

At Start/At End/Both None

Alert Beep

Touch an option.

Mute/2 Beeps/4 Beeps

and

Axcess Shop

AxcessSMShop allows you to do more than just talk on your phone. Axcess Shop is a technology and service that allows you to download and use applications on your phone. With Axcess Shop, it is quick and easy to personalize your phone to suit your lifestyle and tastes. Just download the applications that appeal to you. With a wide range of software available, from ringtones and wallpapers to games and productivity tools, you can be assured that you will find something useful, practical, or downright entertaining.

Downloading Applications

You can download applications and use Axcess Shop anywhere on the network, as long as your handset has a digital signal available. Most applications do

Using Phone Menus

not use a network connection while in use.

Incoming Calls

While downloading an application, incoming calls will automatically be sent to your voice mail, if available. If you do not have voice mail, downloading will not be interrupted by an

Using Phone Menus

incoming call, and the caller will receive a busy signal.

When using applications, an incoming call will automatically pause the application and allow you to answer the call. When you complete your call, you can resume using the application.

1. Axcess Shop

Allows you to download selected applications while displaying the Axcess Apps application list relayed from the server connection.

1. Touch .

2. Touch

Axcess Shop

3. Touch

Axcess Shop

4. Touch Catalog to browse through the available applications, or press Search to search for a specific application.

Note

If you try to download an application when the file memory is full, the following message will be displayed: "File Memory is full. To make enough storage space to install this app, the following app(s) will be temporarily disabled:...You can restore disabled apps by simply starting them, at no additional purchase cost. Proceed?" If you select Yes, the app(s) will be disabled.

2. Axcess Info

Allows you to decide whether or not your phone displays the Airtime Charges Warning message when you start Axcess Shop.

1. Touch .

2. Touch

Axcess Shop

3. Touch

Axcess Info

4. Touch

Ye s

or No.

Managing Your Axcess Apps Applications

Add new applications and remove old ones at any time.

Removing Applications

Only removing an application deletes it completely from the memory of the phone. To restore an application once it has been removed, you will be charged to download it again.

1. Access your Axcess Shop applications.

2. Touch

Settings.

Manage Apps.

3. Touch

4. Touch the application to be deleted.

5. Touch

Remove

Using Phone Menus

Multimedia

Music

Allows you to transfer songs stored in your memory card. To access this feature, there should be stored music in your memory card.

1. Touch .

2. Touch .

Music

3. Touch

4. You can view the list of All

Multimedia

Songs, Playlists, Recently Played, Artists, Genres, Albums.

Notes

Be sure to use only recommended microSDTMcards. Using nonrecommended microSDTMcards could cause data loss and damage your phone.

The microSDTMcard and its adapter can be easily damaged by improper operation. Please be careful when inserting, removing, or handling it.

Do not remove a microSD while files are being accessed or transferred. It will result in loss or damage of data.

card

Shuffle

Allows you to customize your phone's Wallpaper and Ringtone shuffle lists.

1. Touch .

2. Touch .

3. Touch

Shuffle

4. Touch

Ringtone List

Wallpaper List

5. Touch the Images or Ringtones you want to add to your list.

6. When you are finished, touch

Done

Using the Side Camera Key

You can use the Side Camera Key

to access the sub menu list.

1. Press the Side Camera Key for about 3 seconds to enter the Take Photo mode.

2. Take a picture by pressing Side Camera Key .

Zoom

My Images

Record Video

Take Photo

1. Touch .

2. Touch .

Take Photo

3. Touch

Touch the option(s) to customize.

My Images

Changes from Camera mode

to Video mode.

Flash

View Normal View/

Wide View

Photo Settings Resolution 2M/ 1.3M/

Flash

Screen Mode

Photo Settings

Settings

Back

Multimedia

VGA(640*480)/ QVGA(320*240)

Quality Fine/ Normal/

Economy

Memory Storage Phone

Memory/ Card Memory

AxcessMyPics Reminder

Enable/ Disable

Settings Self Timer Off/ 3 Seconds/

5 Seconds/ 10 Seconds

Multishot 1 shot/ 3 shots/

6 shots

Brightness Night Mode On White Balance Auto/

Tungsten/ Fluorescent/ Sunny/ Cloudy

Color Effects Color/

Mono/ Negative/ Sepia/ Aqua

Templates On/ Off Shutter Sound Sound 1/

Sound 2/ Sound 3/ Sound 4/Say Cheese/ None

/ Off

4. Take a picture by pressing .

5. Touch to save the picture.

The picture is stored in

Images


Allows you to select images to customize your phone's Main Screen, or Picture ID.

1. Touch .

2. Touch .


3. Touch

My Image/Default

4. Touch

My Image

Highlight an image and touch

Send

to send the image to somebody else, or touch to choose from the following options:

Set as/ Take Photo/ Delete/

Rename/ Move/Copy/ Lock/ List View/ Information/ Delete Multiple/ Sort by/ Send Via Bluetooth/ Send to AxcessMyPics.com

Default

Highlight an image and touch

to choose from the

following options:

Set as/ List View/ Information

Record Video

1. Touch .

2. Touch .

3. Touch

Record Video

Zoom

My Videos

Take Photo

Touch the option(s) to customize.

My Videos

Changes from Video mode

to Camera mode.

Flash

Mute/ Unmute

Video Settings Resolution

QVGA(320*240)/ QCIF(176*144)

Quality Fine/ Normal/

Economy

Record Time 15 sec/ 1

hour

Flash

Mute/ Unmute

Video Settings

Settings

Back

Multimedia

Memory Storage Phone

Memory/ Card Memory

AxcessMyPics Reminder

Enable/ Disable

Settings Brightness White Balance Auto/

Tungsten/ Fluorescent/ Sunny/ Cloudy

Color Effects Color/ Mono/

Negative/ Sepia/ Aqua

Cue Sound Cue 1/ Cue 2/

Multimedia

Cue 3/ Off

4. Press to begin recording.

5. Press to stop recording.

6. Touch to save the video.

The video is stored in

Videos

Video

Allows you to choose video clips.

1. Touch .

2. Touch .

3. Touch

Video

4. Touch

5. Touch a video and touch to send it to somebody else, or touch to choose from the following options:

Record Video/ Delete/ Rename/ Move/ Copy/ Lock/ List View/ Information/ Delete Multiple/ Sort By/ Send Via Bluetooth/ Send to AxcessMyPics.com

Video.

Send

Audio

Allows you to choose audio clips.

1. Touch .

2. Touch .

3. Touch

Audio

My Audio/Default

4. Touch

My Audio

Touch an audio clip and touch

Send

to send it to somebody else, or touch to choose from the following options:

Record Voice/ Delete/ Rename/ Move/ Copy/ Lock/ Information/ Delete Multiple/ Sort By/ Send Via Bluetooth

Default

Highlight a ringtone and touch

to choose from the

following options:

Set as/ Information

Axcess TV

This menu allows you to watch more than 40 different TV channels. You can access news, entertainment, sports, and much more.

You can view your favorite channels by touching the Right Soft Key, and control volume by using the volume keys on the side of your phone.

You can access on-screen instructions for Axcess TV by touching the Left Soft Key Help.

1. Touch .

2. Touch .

3. Touch

Axcess TV

Multimedia

Tools

Voice Command

Allows you to make phone calls quickly and easily by voice. Your phone recalls the number from your Contacts, displays it briefly, and then dials it. This menu also includes a feature for those who are driving or blind. It delivers time and date information by voice and allows you to check missed calls, messages and voicemails.

1. Touch .

2. Touch .

Tools

3. Touch

Voice Command

4. Touch

1 Start Command

5. When prompted, say “Call”.

6. When prompted, say the name or phone number of the Contact you want to call. The phone will ask you to confirm the name or phone number before dialing.

Call <Name/Number>/ Voicemail Messages/Time & Date Help

Alarm Clock

Allows you to set up to four alarms. At the alarm time, any set alarm will sound the tone of your choice, and a notification message will be displayed on your screen.

1. Touch .

2. Touch .

Alarm Clock

3. Touch

4. Touch the alarm number.

5. Set the alarm time.

6. Touch Once (recurring

setting).

7. Touch to select one of the following.

Missed Calls

Once/Daily/Mon - Fri

Weekends

8. Touch

My Audio/Default

9. Touch a tone and touch

10. Touch

Save

Set

Calendar

Allows you to store and access your agenda(s). Simply store your appointments in your Calendar and your phone will alert you with a reminder.

1. Touch .

2. Touch .

Calendar

3. Touch

4. Touch the scheduled day.

5. Touch to select .

New

6. Enter your schedule

information including:

Add

Set TimelTopic

ReminderlRepeat

Set Period lRingtone

7. Touch

Save

World Clock

Allows you to determine the current time in another time zone or country.

1. Touch .

2. Touch .

World Clock

3. Touch

4. Scroll through countries by touching the arrows under the globe.

5. Touch a country to view cities.

6. Touch a city to view the current date and time in that city.

Tools

7. Touch

Cities

list of available cities.

8. Touch a city from the list. Touch the selected city on the globe to view the current date and time.

9. Touch to turn Daylight Savings Time on or off.

Calculator

Allows you to perform simple mathematical calculations. You can enter numbers up to the

Tools

sixth decimal place.

1. Touch .

2. Touch .

Calculator

3. Touch

4. Enter data.

Use keypad to enter numbers.

to choose from a

Use to enter decimals.

Touch to delete the last digit entered, or touch and hold to erase the entire entry.

Touch the corresponding Touch Keys to enter functions ( +, -, x, / ).

Touch to complete

equation.

Ez Tip Calc

Allows you to quickly and easily estimate the tip and total amount of a bill by inputting the bill amount before tip, the tip percentage, and divide it by the number of people paying.

1. Touch .

2. Touch .

3. Touch

Ez Tip Calc

Notepad

Allows you to add, read, edit, and erase notes to yourself.

1. Touch .

2. Touch .

3. Touch

Notepad

4. Touch to write a new

Add

note.

5. Type the note, then touch

Save

A confirmation message displays briefly, then displays your list of notes.

Viewing a Notepad Entry

1. Access Notepad and highlight the entry.

2. To erase, touch .

Edit lAdd New

Delete

Delete All

Touch the entry, touch and touch and

Edit

Edit.

View

. Or touch

Unit Converter

Allows you to convert units of measurement.

1. Touch .

2. Touch .

Unit Converter

3. Touch

4. Touch the unit of measurement you want to convert:

Area/ Length/ Temperature/ Mass/ Volume/ Velocity

Tools

Settings

Display

Options to customize your phone's display screen.

1. Wallpaper

Allows you to choose the kind of background to be displayed on the phone.

1. Touch .

2. Touch .

Display

3. Touch

Settings

1 Wallpaper

4. Touch

Wallpaper

5. Touch a submenu.

My Picture/My Video

6. Touch your choice, then touch

Set

Screen/ Shuffle/ Buy

and

2. Banner

Allows you to enter a string of characters which display on the LCD screen.

1. Touch .

2. Touch .

3. Touch

Display

2 Banner

4. Touch the Status field and touch

On/ Off

5. Touch the Text field and type your Banner text.

6. When you are finished, touch

Save

and

3. Backlight

Allows you to set the duration of the Display and Keypad backlighting.

1. Touch .

2. Touch .

3. Touch

Display

3 Backlight

4. Touch a submenu.

and

Display/ Keypad

5. Touch a duration time:

7 seconds/ 10 seconds/ 15 seconds/ 30 seconds/ Always Off

4. Languages

Allows you to set the bilingual feature according to your preference. Choose between English and Spanish.

1. Touch .

2. Touch .

3. Touch

4 Languages

4. Touch

Display

English

and

Spanish

5. Clocks & Calendar

Allows you to select the type of clocks displayed on the LCD screen.

1. Touch .

2. Touch .

3. Touch

Display

5 Clocks & Calendar

4. Touch the left or right arrow buttons to scroll through the available options, and touch the option you want to select:

Off/ Analog Clock/ Digital Clock/Dual Clock(Set City in World Clock)/Calendar

5. Touch .

Save

and

Settings

6. Font Settings

Allows you to select the type of font displayed on LCD.

1. Touch .

2. Touch .

3. Touch

Display

6 Font Settings

4. Touch a sub-menu.

Font Type/ Font Size

Options for Font Type

Settings

LG Gothic/ LG Serif/ LG Edge/ LG Joy/ LG Script

Options for Font Size

Messaging/Browser/ Notepad

7. Color Scheme

Allows you to choose the color of the background screen.

1. Touch .

2. Touch .

and

3. Touch

Display

7 Color Scheme

Background Style

4. Touch

Menu Icons Style

Options for Background Style

Black/ Blue/ Pond/ Metal

Options for Menu Icons Style

Black & White/ Color

and

Sound & Touch

Options to customize the phone’s sounds.

1. Ringers

Allows you to assign ringtones for incoming calls.

1. Touch .

2. Touch .

3. Touch

Sound & Touch

and

1 Ringers

4. Touch

Caller ID Shuffle/ Buy Ringtones

5. Touch

6. Touch a ringer, then touch

Set

All Calls/Caller ID/No

Restricted Calls

My Audio/ Default

2. Volume

Allows you to set various volume settings.

1. Touch .

2. Touch .

Sound & Touch

3. Touch and

2 Volume

4. Touch

Master Volume

Keypad/Earpiece/Speaker

5. Adjust the volume by touching up or down arrow buttons and

touch to save the setting.

3. Message Alert

Allows you to select the alert tones for new messages.

1. Touch .

2. Touch .

Sound & Touch

3. Touch and

3 Message Alert

Settings

4. Touch

Text Message/Picture

Message Messages Reminder.

5. Touch

6. Touch a ringtone, then touch

Set

For the option, choose from the following settings:

Once/ Every 2 Minutes/ Every 15 Minutes/ Off

Settings

4. Alert Type

Allows you to select the alert types.

1. Touch .

2. Touch .

3. Touch and

4. Touch the option you want to

Voicemail/All

Message

My Audio/Default

Message Reminder

Sound & Touch

4 Alert Type

customize:

Call Alert/Message Alert Schedule Alert/Alarm Alert

5. Choose from the following

settings:

Ring Only/ Vibration/ Ring & Vib

5. Service Alerts

Allows you to set any of the 3 Service Alert options to On or Off.

1. Touch .

2. Touch .

Sound & Touch

3. Touch and

5 Service Alerts

4. Touch an alert option.

Minute Beep

Alerts you 10 seconds before the end of every minute during a call.

Call Connect

Alerts you when the call is connected.

Low Battery

Alerts you when the battery charge level is low.

5. Touch a setting.

On/Off

(for Low Battery option,

Announce/Tone

)

6. Power On/Off Tones

Allows you to set the phone to sound a tone when the phone is powered on and off.

1. Touch .

2. Touch .

Sound & Touch

3. Touch and

6 Power On/Off Tones

4. Touch a setting.

On/Off

7. Slide Tone

Allows you to set a slide tone that will play when you slide your phone open or closed.

1. Touch .

2. Touch .

3. Touch

Sound & Touch

and

7 Slide Tone

4. Touch a setting.

On/Off

8. Touch Key Feedback

Allows you to customize your Touch Screen's sound and vibration settings.

1. Touch .

2. Touch .

Sound & Touch

3. Touch and

8 Touch Key Feedback

Settings

4. Touch the option you want to customize:

Type Silence/ Vibration/ Sound/ Vibration & Sound

Sound Sound 1/ Sound 2/ Sound 3/ Sound 4

Vibration Vibration 1/ Vibration 2/ Vibration 3/ Vibration 4

Level

Settings

Level 1/ Level 2/ Level 3/ Level 4

9. Touch Calibration

Allows you to calibrate the Touch Screen to ensure it is working properly.

1. Touch .

2. Touch .

Sound & Touch

3. Touch and

9 Touch Calibration

4. Touch the target on the screen to start calibration, then touch the target each time it appears.

Bluetooth

The Glimmer™is compatible with devices that support the

Bluetooth

headset and handsfree profile(s)*. You may create and store 25 pairings within the

™

Glimmer

and connect to one device at a time. The approximate communication range for

Bluetooth

wireless technology is up to 30 feet (10 meters).

Bluetooth QD ID B013122

Note

Read user guide of each accessory that you are trying to pair with your phone because the instructions may be different.

Bluetooth

Note

The

Bluetooth

handset may not be compatible with all Your service provider or handset manufacturer cannot be held responsible for compatibility issues with devices not sold by the service provider or handset manufacturer.

features of this

Bluetooth

enabled devices.

1. Powe r

Allows you to set the power On/Off.

1. Touch .

2. Touch .

3. Touch

1 Power

Bluetooth

and

4. Touch a setting.

On/Off

Note

By default, your device’s functionality is turned off.

Bluetooth

2. Add New

Pairing is the process that allows the handset to locate, establish and register 1-to-1 connection with the target device.

Pairing a new Bluetooth device

1. Touch .

2. Touch .

Bluetooth

3. Touch

2 Add New

4. Follow the

Bluetooth

accessory instructions to set the device to pairing mode.

and

Settings

5. If

Bluetooth

off, you will be prompted to turn power on. Touch

6. The device will appear in the Found Devices menu once it has been located. Touch the device.

7. The handset will prompt you for the passkey. Consult the

Bluetooth

instructions for the appropriate passkey (typically

Settings

“0000” - 4 zeroes). Enter the passkey and touch .

8. Once pairing is successful, touch device.

Once connected, you will see the device listed in the Paired Devices menu.

power is set to

accessory

Ye s to connect with the

Ye s .

Pair

3. Paired Devices

Allows you to view the list of paired devices with your phone.

1. Touch .

2. Touch .

3. Touch 3

Paired Devices

Bluetooth

and

4. Settings

4.1 Power

Allows you to set the power On/Off.

1. Touch .

2. Touch .

Bluetooth

3. Touch

4 Settings

4. Touch a setting.

and

On/Off

1 Power

4.2 Visibility

Allows you to set the visibility of your Bluetooth feature.

1. Touch .

2. Touch .

3. Touch

Bluetooth

4 Settings

and

2 Visibility

4. Touch a setting.

Hidden/Visible for 1 min

Note

If you turn on My Visibility, your device is able to be searched by other in-range

Bluetooth

devices.

4.3 Device Name

Allows you to edit the name of the

Bluetooth

device.

1. Touch .

2. Touch .

3. Touch

4 Settings Name

Bluetooth

and

3 Device

4. Hold down to clear the existing name.

5. Use the alphanumeric keypad to enter a new alias.

6. Touch to save and exit.

Save

4.4 Device Info

Allows you to view your phone's

Bluetooth

information.

1. Touch .

2. Touch .

3. Touch

4 Settings

Bluetooth

and

4 Device Info

Settings

USB Connection

Allows you to select the data port.

1. Touch .

2. Touch .

USB Connection

3. Touch

4. Touch a setting.

USB Modem/ USB Mass Storage

Using Glimmer

Settings

Mode

Note

Users who use a memory card reader do not require a USB cable and would not need to follow all those steps.

The supported files may vary depending on the software version of your phone.

™

USB Drive

Requirements:

Glimmer™Phone

Glimmer™USB Cable

microSDTMcard installed on the phone

Windows XP®Computer

Steps to using USB Mass Storage mode:

1. Install the USB Cable drivers into the computer.

2. After installing the USB cable drivers, connect the cable to the computer and attach the phone. Allow the computer to detect the phone USB drivers and install them.

3. Make sure the microSD has been formatted on the phone so the required folders will be created for use with your phone. To format the memory card navigate the

card

phone to Menu > Settings > Phone Information >

6. Memory > 3. Card Memory and select the Format option. Select YES to format the

™

microSD

card.

4. On the phone, go to Menu > Settings > USB Connection > USB Mass Storage. A prompt will be displayed stating “PC Connection Set”. Press END key to return to standby mode. After a few seconds, a new explorer window containing the following folders should pop up on the computer screen:

My_Audios

My_Images

My_Music

My_Videos

5. The Music Player files will need to be copied into the music folder. Music Player only supports MP3 files, AAC files, AAC+ files and WMA files. (Not enhanced AAC files)

6. Once you are done transferring files, disconnect the phone. When you launch Music Player or go into the My Media folders, an "Initializing..." folder will pop up on the phone while it refreshes the memory card contents.

Settings

Security

The Security menu allows you to secure the phone electronically.

1. Lock Phone

Keeps your phone from unauthorized use. Once the phone is locked, it is in restricted mode until the lock code is entered. You can still receive phone calls and make emergency calls. You can modify the lock code by navigating to

Lock Code

Settings

menu.

1. Touch .

2. Touch .

3. Touch

4. Enter the four-digit lock code.

within the Security

Security

The default lock code is commonly the last 4 digits of your phone number.

Change

1 Lock Phone

5. Touch

6. Touch an option.

Unlock

The phone is never locked (Lock mode can still be used).

Lock

The phone is always locked. When locked, you can receive incoming calls and make only emergency calls.

On Power Up

locked when it is turned on.

The phone is

2. Restrictions

Allows you to restrict incoming and/or outgoing calls.

Note

You can receive the incoming calls from saved contacts on your phone, when Incoming Only is on.

1. Touch .

2. Touch .

3. Touch

Security

4. Enter the four-digit lock code.

2 Restrictions.

5. Touch

6. Enter the four-digit lock code.

7. Touch a Restrictions submenu, then the setting.

Calls

(Outgoing Only/

Incoming Only/ All/ None)/

Messaging

Incoming Only/ All/ None)/

Camera

(Unlock/Lock) /

Data

(Unlock/Lock)

(Outgoing Only/

3. Emergency #s

Allows you to enter 3 emergency numbers. You can call these emergency numbers and 911, even when the phone is locked or restricted.

1. Touch .

2. Touch .

3. Touch

Security

4. Enter the four-digit lock code.

3 Emergency #s

5. Touch

6. Touch the emergency number you want to edit.

4. Change Lock Code

Allows you to enter a new fourdigit lock code.

1. Touch .

2. Touch .

3. Touch

Security

4. Enter the four-digit lock code.

5. Touch

4 Change Lock Code

6. Touch

1 Phone Only

2 Call & Applications

7. Enter a new 4-digit lock code.

8. For confirmation, it will ask you to enter the new lock code again.

Settings

5. Reset Default

Allows you to reset your phone to the factory default settings.

1. Touch .

2. Touch .

Security

3. Touch

4. Enter the four-digit lock code.

5 Reset Default

5. Touch

6. Read the disclaimer and touch

Settings

to continue.

7. A message will pop up that says "User preferences will be restored to factory default."

Ye s

Touch

or No.

Call Settings

The Call Settings menu allows you to designate how the phone handles both incoming and outgoing calls.

1. Answer Options

Allows you to determine how to handle an incoming call.

1. Touch .

2. Touch .

Call Settings

3. Touch and

1 Answer Options

4. Touch a setting.

Open Slide/Press Any Key Press Send Key Only/Auto Answer

2. End Options

Allows you to determine how the phone will disconnect from a call.

1. Touch .

2. Touch .

Call Settings

3. Touch and

2 End Options

4. Touch a setting.

Close Slide/Press End Key Only

3. Auto Retry

Allows you to set the length of time the phone waits before automatically redialing a number when the attempted call fails.

1. Touch .

2. Touch .

3. Touch and

Call Settings

3 Auto Retry

4. Touch a setting.

Off/Every 10 Seconds

Every 30 Seconds/Every 60 Seconds

4. One-Touch Dial

Allows you to initiate a speed dial call by pressing and holding the speed dial digit. If set to Off, Speed Dial numbers designated in your Contacts will not function.

1. Touch .

2. Touch .

Call Settings

3. Touch and

4 One-Touch Dial

4. Touch a setting.

On/Off

Settings

5. Voice Privacy

Allows you to set the voice privacy feature for CDMA calls as Enhanced or Standard. CDMA offers inherent voice privacy. Check with your service provider for availability.

1. Touch .

2. Touch .

Call Settings

3. Touch and

5 Voice Privacy

4. Touch a setting.

Settings

Enhanced/ Standard

6. Auto Volume

When this feature is enabled, it provides a better audio experience by controlling the dynamic range and volume of the sending and receiving voices across different environments and conditions.

1. Touch .

2. Touch .

Call Settings

3. Touch and

6 Auto Volume

4. Touch a setting.

On/Off

7. Airplane Mode

Only allows you to use features on your phone that do not require wireless communications.

1. Touch .

2. Touch .

Call Settings

3. Touch and

7 Airplane Mode

4. Read the disclaimer and touch

5. Touch a setting.

On/Off

8. TTY Mode

Allows you to attach a TTY (Teletype writer) device enabling you to communicate with parties also using a TTY device. A phone with TTY support is able to translate typed characters to voice. Voice can also be translated into characters and then displayed on the TTY.

1. Touch .

2. Touch .

Call Settings

3. Touch and

8 TTY Mode

4. Read the disclaimer and touch

5. Touch a setting.

TTY Full/TTY + Talk/TTY +

TTY Off

Hear

System

The System menu allows you to designate specific system network settings.

1. Network

1.1 System Select

Allows you to set up the phone producer’s management environment. Leave this setting as the default unless you want to alter system selection as instructed by your service provider.

1. Touch .

2. Touch .

System

3. Touch

1 Network

Select

4. Touch a setting.

Home Only/Automatic A/ Automatic B

and

1 System

Settings

1.2 Set NAM

Allows you to select the phone’s NAM (Number Assignment Module) if the phone is registered with multiple service providers.

1. Touch .

2. Touch .

System

3. Touch

1 Network

4. Touch a setting.

Settings

NAM1/NAM2

1.3 Auto NAM

Allows the phone to automatically switch between programmed telephone numbers corresponding to the service provider area.

1. Touch .

2. Touch .

and

2 Set NAM

System

3. Touch

1 Network

4. Touch a setting.

and

On/Off

1.4 Serving System

Identifies the channel number of a system that is served as a SID Number. This information should only be used for technical

support.

1. Touch .

2. Touch .

System

3. Touch

1 Network System

and

3 Auto NAM

4 Serving

2. Location

Menu for GPS (Global Positioning System: Satellite assisted location information system) mode.

1. Touch .

2. Touch .

System

3. Touch

2 Location

4. Touch

a setting

Location On/E911 Only

Note

GPS satellite signals are not always transmitted, especially under bad atmospheric and environmental conditions, indoors etc.

and

Phone Information

The Phone Information menu provides you with specific information pertaining to your phone model.

1. Touch .

2. Touch .

3. Touch

Phone Information

1. My Number

Allows you to view your phone number.

1. Touch .

2. Touch .

Phone Information

3. Touch and

1 My Number

Settings

2. ESN/MEID

Allows you to view the ESN and MEID information of your phone.

1. Touch .

2. Touch .

Phone Information

3. Touch and

2 ESN/MEID

3. Icon Glossary

Allows you to view all the icons and their meanings.

Settings

1. Touch .

2. Touch .

Phone Information

3. Touch and

3 Icon Glossary

4. Version

Allows you to view the versions of various applications.

1. Touch .

2. Touch .

Phone Information

3. Touch

and

4 Version

5. Software Update

Allows you to update your phone's software, if updates are available.

1. Touch .

2. Touch .

Phone Information

3. Touch

and

4. Touch

5 Software Update

1 Check for Update

6. Memory

Allows you to check out the memory status of your phone.

1. Touch .

2. Touch .

Phone Information

3. Touch and

6 Memory

4. Touch an option:

Save Options

Image/ Video/ Audio

Phone Memory

Reserved Memory/ Multimedia

Card Memory

Settings

Safety

TIA Safety Information

The following is the complete TIA Safety Information for wireless handheld phones.

Exposure to Radio Frequency Signal

Your wireless handheld portable phone is a low power radio transmitter and receiver. When ON, it receives and sends out Radio Frequency (RF) signals.

In August, 1996, the Federal

Safety

Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:

ANSI C95.1 (1992) *

NCRP Report 86 (1986)

ICNIRP (1996)

* American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection.

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments

could damage the phone and may violate FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.

Tips on Efficient Operation

For your phone to operate most efficiently:

Don’t touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in the areas where you drive and

always obey them. Also, if using your phone while driving, please observe the following:

Give full attention to driving -driving safely is your first responsibility;

Use hands-free operation, if available;

Pull off the road and park before making or answering a call if driving conditions or the law require it.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association

Safety

recommends that a minimum separation of six (6) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Persons with pacemakers:

Should ALWAYS keep the phone more than six (6)

Safety

inches from their pacemaker when the phone is turned ON;

Should not carry the phone in a breast pocket;

Should use the ear opposite the pacemaker to minimize the potential for interference;

Should turn the phone OFF immediately if there is any

reason to suspect that

interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air.

Switch OFF your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations);

Safety

below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

Safety

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Safety Information

Please read and observe the following information for safe and proper use of your phone and to prevent damage. Also, keep the user guide in an accessible place at all times after reading it.

CCaauuttiioonn!

instructions may cause minor or serious damage to the product.

Charger and Adapter Safety

The charger and adapter are intended for indoor use only.

Insert the battery pack charger vertically into the wall power socket.

Use the correct adapter for your phone when using the battery pack charger abroad.

Violation of the

Only use the approved battery charger. Otherwise, you may cause serious damage to your phone.

Battery Information and Care

Please dispose of your battery properly or take it to your local wireless carrier for recycling.

The battery doesn't need to be empty before recharging.

Use only LG-approved chargers specific to your phone model since they are designed to maximize battery life.

Do not disassemble or shortcircuit the battery.

Keep the battery’s metal contacts clean.

Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.

Recharge the battery after long periods of non-use to maximize battery life.

Battery life will vary due to usage patterns and environmental conditions.

Use of extended backlighting, Browser, and data connectivity kits affect battery life and talk/standby times.

The self-protection function of the battery cuts the power of the phone when its operation is in an abnormal state. In this case, remove the battery from the phone, reinstall it, and turn the phone on.

Explosion, Shock, and Fire Hazards

Do not put your phone in a place subject to excessive dust and keep the minimum required distance between the power cord and heat sources.

Safety

Unplug the power cord prior to cleaning your phone, and clean the power plug pin when it’s dirty.

When using the power plug, ensure that it’s firmly connected. If not, it may cause excessive heat or fire.

If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

Don’t short-circuit the battery. Metallic articles such as a coin, paperclip or pen in your pocket or bag may shortcircuit the + and – terminals of the battery (metal strips on the battery) upon moving. Short-circuit of the terminal

may damage the battery and cause an explosion.

Do not disassemble or crush the battery. It may cause a fire.

General Notice

Using a damaged battery or placing a battery in your mouth may cause serious injury.

Do not place items containing magnetic components such as a credit card, phone card, bank book, or subway ticket near your phone. The magnetism of the phone may damage the data stored in the magnetic strip.

Talking on your phone for a long period of time may reduce call quality due to heat generated during use.

When the phone is not used for a long period time, store it

in a safe place with the power cord unplugged.

Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference to the phone.

Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna.

Do not immerse your phone in water. If this happens, turn it off immediately and remove the battery. If the phone does not work, take it to an LG Authorized Service Center.

Do not paint your phone.

The data saved in your phone might be deleted due to careless use, repair of the phone, or upgrade of the software. Please backup your

important phone numbers. (Ring tones, text messages, voice messages, pictures, and videos could also be deleted.) The manufacturer is not liable for damage due to the loss of data.

When you use the phone in public places, set the ringtone to vibration so you don't disturb others.

Do not turn your phone on or off when putting it to your ear.

Use accessories, such as earphones and headsets, with caution. Ensure that cables are tucked away safely and do not touch the antenna unnecessarily.

Safety

Warning! Important safety information

Avoiding hearing damage

Permanent hearing loss may occur if you use your phone and/or headset at a high volume. Set the volume to a safe level. You can adapt over time to a higher volume of sound that may sound normal but can be damaging to your hearing. If you experience ringing in your ears or muffled speech, stop listening

Safety

and have your hearing checked. The louder the volume, the less time is required before your hearing could be affected. Hearing experts suggest that to protect your hearing:

Limit the amount of time you use your phone and/or headset at high volume.

Avoid turning up the volume to block out noisy surroundings.

Turn the volume down if you can’t hear people speaking near you.

For information about how to set a maximum volume limit on your phone, see the features guide for your phone.

Using your phone safely

Use of your phone while operating a vehicle is not recommended and is illegal in some areas. Be careful and attentive while driving. Stop using your phone if you find it disruptive or distracting while operating any type of vehicle or performing any other activity that requires your full attention.

Avoiding hearing damage

Permanent hearing loss may occur if you use your headset at a high volume. Set the volume to a safe level. You can adapt over time to a higher volume of sound that may sound normal but can be damaging to your hearing. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked. The louder the volume, the less time is required before your hearing could be affected. Hearing experts suggest that to protect your hearing:

Limit the amount of time you use headset at high volume.

Avoid turning up the volume to block out noisy surroundings.

Turn the volume down if you can’t hear people speaking near you.

For information about how to set a maximum volume limit on your handset, please refer to the features guide for your handset.

Using headsets safely

Use of headsets to listen to music while operating a vehicle is not recommended and is illegal in some areas. Be careful and attentive while driving. Stop using this device if you find it disruptive or distracting while operating any type of vehicle or performing any other activity that requires your full attention.

Safety

FDA Consumer Update

The U.S. Food and Drug Administration’s Center for Devices and Radiological Health Consumer Update on Mobile Phones:

1. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless

Safety

phones are absolutely safe. Wireless phones emit low levels of Radio Frequency (RF) energy in the microwave range while being used. They also emit very low levels of RF when in standby mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known

adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

2. What is the FDA's role concerning the safety of wireless phones?

Under the law, the FDA does not review the safety of radiationemitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit Radio Frequency (RF)

LG AX830 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Welcome

Technical Details

FCC RF Exposure Information

Bodily Contact During Operation

FCC Notice and Cautions

Phone Overview

Touch Sensitive Soft Keys

Touch Screen Shortcut Menu

Menus Overview

Menu Access

Getting Started with Your Phone

The Battery

Installing the Battery

Removing the Battery

Charging the Battery

Battery Charge Level

Turning the Phone On and Off

Turning the Phone On

Turning the Phone Off

Signal Strength

Screen Icons

Making Calls

Correcting Dialing Mistakes

Redialing Calls

Receiving Calls

Lock Mode

Mute Function

Volume Quick Adjustment

Call Waiting

Caller ID

Speed Dialing

Text Input

Contacts in Your Phone’s Memory

Phone Numbers With Pauses

Storing a Number with Pauses

Searching Your Phone’s Memory

Accessing Options

Using Phone Menus

Recent Calls

1. Missed Calls

2. Received Calls

3. Dialed Calls

4. Data

5. All Calls

6. Call Timer

7. Data Counter

Contacts

1. New Contact

2. Contact List

3. My Circle

4. Groups

5. Speed Dials

6. My Name Card

Messaging

1. New Text Message

2. New Picture Message

3. Inbox

4. Sent

5. Drafts

6. Voicemail

7. Quick-Text

8. Settings

9. Delete All

New Events Manager

Axcess Web

1. Start Browser

2. Web Messages

3. Web Settings

Axcess Shop

1. Axcess Shop

2. Axcess Info

Multimedia

Music

Shuffle

Take Photo
