Artistic Space
Beyond Display,
LG Wallpaper
OLED Signage
65EJ5E
This sophisticated wallpaper OLED signage achieves the
best possible picture quality, concealing its presence by
blending in with the wall. Minimal space is required for
installation, which simplifies the construction process. The
luxurious atmosphere generated with this signage will
provide customers with an extraordinary experience,
making them feel like VIPs.
Artistic Space Beyond Display, LG Wallpaper OLED Signage
65EJ5E
Unrivaled Picture Quality
Perfect Black
Limitless contrast and the deepest blacks
Self-lighting pixels switch off completely to
reproduce absolutes blacks with no light bleed,
offering infinite contrast
LG OLED SignageLCD LG OLED SignageLCD
Perfect Color
Accurate & stable color reproduction
Self-lighting pixels bring colors to life with superb
accuracy.
Perfect Viewing Screen
Wide viewing angle
LG OLED Signage delivers awe-inspiring picture quality
across the entire screen, even from wide viewing angles.
Artistic Space Beyond Display, LG Wallpaper OLED Signage
65EJ5E
Ultimate Elegance of Design
Perfect Design
LG’s OLED technology unlocks the new worlds of design flexibility with
unbelievably lightweight and slim display. The advantages the OLED display
brings are countless from the easier installation to a sleek look.
Hide in Plain Sight
The subtle edge of the wallpaper OLED totally blends in with the wall, giving
audiences the sensation that content is being played directly within the wall
itself. Integrating with and adding to a luxurious interior design, the wallpaper
OLED is an effective method for delivering advertisements and information.
Artistic Space Beyond Display, LG Wallpaper OLED Signage
65EJ5E
Realizing an Immersive View
N×N Expandable Screen Size
By tiling up displays horizontally and vertically, the screen size can be as
large as users want. Expansive, large screens are more effective at moving
viewers by providing an incredibly immersive viewing experience.
Seam (On-Bezel)
① 18.8(T+B) mm
② 16.6(L+R) mm
LAN Daisy Chain Management
A LAN daisy chain allows you to execute commands to control and monitor
the screens and even update their firmware.
LAN
LAN
LAN
LAN
Artistic Space Beyond Display, LG Wallpaper OLED Signage
SignageBox
65EJ5E
Easy Installation
Wall Fixers Optimized for Simple Tiling
The overall installation process of the wallpaper OLED has gotten much easier.
Once the dedicated wall fixers are driven into a wall, a display can be easily hung
on them. Video wall tiling has become more convenient, thanks to its front
installation feature, which departs from the conventional side-sliding method.
Conventional
EJ5E
Enhanced Flexibility of Cables
As a result of in-depth consideration of usage scenarios, improvements have
been made to the flexibility of common cables connecting the display to the
signage box. These new cables are pliable enough to be easily embedded in a
wall or other structures.
Dimension
65"
(unit: mm)
1445.1
6
Head
822.6
Signage Box
96
239
754
782.8
Connectivity
110
(Signage Box)
35.5
FFC Cable Path
1 52 3 4 6 7 8 9 10 11
1
USB 2.0
2
HDMI IN
3
DP IN
4
DP OUT
5
USB 2.0
6
LAN IN
7
LAN OUT
8
IR IN
Download
LG Information Display
Mobile App
Google Play Store
9
RS232C IN
10
RS232C OUT
11
AUDIO OUT
www.lg.com/b2b
www.youtube.com/c/LGECommercialDisplay
www.facebook.com/LGInformationDisplay
www.linkedin.com/company/LGInformationDisplay
LG may make changes to specifications and product descriptions without notice.
Copyright © 2018 LG Electronics Inc. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
The names of products and brands mentioned here may be the trademarks of their respective owners.
Specifications
Screen Size 65"
Panel Technology OLED
Aspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD)
Brightness (Typ.)
PANEL
CONNECTIVITY
PHYSICAL
SPECIFICATION
SPECIAL FEATURES
ENVIRONMENT
CONDITIONS
POWER
STANDARD
(CERTIFICATION)
MEDIA PLAYER
COMPATIBILITY
SOFTWARE
COMPATIBILITY
ACCESSORIES
1) Network Based Control 2) Compatibility may differ by equipment.
Viewing Angle (H x V) 178 x 178
Response Time 1ms (G to G), 8ms (MPRT)
Surface Treatment (Haze)
Life Time (Typ.) 30,000 Hrs
Operation Hours 12 Hrs / 7 Days (Moving Video Only)
Orientation
Input
Output DP, Audio
External Control
Bezel Color
Bezel Width
Dimension (W x H x D)
Weight 13.5 kg (Set)
Carton Dimensions (W x H x D) 1,590 x 965 x 205 mm
Packed Weight
Operation Temperature Range
Operation Humidity Range
Power Supply
Power Type Built-In Power
Power Consumption
Safety
EMC FCC Class "A" / CE / KC
ErP / Energy Star
OPS Type Compatible
External Media Player Attachable Yes
Content Management Software SuperSign CMS
Control and Monitoring Software
Basic
Typ. / Max.
65EJ5E
2
400/150 cd/m
Anti-reflection Treatment of the Front Polarizer (Reflectance Typ. 1.2%)
RS232C In/out, RJ45 In/out, External IR Receiver
(On bezel) 8.1 mm (T), 10.7 mm (B), 8.3 mm (L/R)
(Head) 1,445.1 x 822.6 x 6.0 mm
(Signage Box) 754 x 239 x 35.5 mm
Internal Memory (64GB), Temperature Sensor, webOS 3.0+,
Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager),
Fail Over, Content Sync (RS232C, Local Network), OSD Rotation, Tile Mode Setting,
Setting Data Cloning, Firmware Update by Network, SNMP, ISM Mode,
Control Manager, Crestron Connected
Wake on LAN, Power on Delay, HDMI-CEC
440 W (8 color bar) / 478 W (8 color bar)
IEC 60950-1 / EN 60950-1 / UL 60950-1
Remote Controller (2ea Batteries Included), Power Cord, QSG,
IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p),
FFC Cables (1,150mm x 4ea for Connection Between Panel and Signage Box),
SuperSign Control+ / Control
DP Cable, LAN Cable, LC (VLC Cable)
(APL 25%/100%)
* Average Picture Level
Hard Coating (2H),
Portrait & Landscape
HDMI, DP, USB 2.0 (2)
Black
(Off bezel) 0.9 mm (Even)
23.4 kg
Ⓡ1)
DPM, Energy Saving, PM Mode,
2)
0°C ~ 40°C
10% ~ 80%
100-240V~, 50/60Hz
, SI Server Setting, webRTC
Yes / No
No
