LG 49UX960H, 60UX960H USER GUIDE

INSTALLATION MANUAL

LED TV*

Please read this manual carefully before operating your set and retain it for future reference.

UX96**

www.lg.com

TABLE OF CONTENTS

ENGLISH

ENG

TABLE OF CONTENTS

3 EZMANAGER

3 INTRODUCTION 3 EZ-MANAGER WIZARD 4 LANGUAGE & COUNTRY SELECTION 5 - Automatically for Setup 8 - Manually for Setup 11 - USB LG Smart Install Utility

13 INSTALLATION MENU

13 INTRODUCTION 14 LG HOTEL MODE 14 - Hotel Mode Operation 14 - Power On Status 15 - Volume 15 - Key Management 16 - Limited Mode 16 - DTV Programme Update 17 - Power On Default 17 - Power Management 17 - Radio Video Blank 17 - Factory Reset 18 NETWORK 18 - MAC Address 18 - Network Setting 19 - IP Stream Control 19 - Wake On LAN 20 PRO:CENTRIC 20 - Mode 20 - WORF 20 - Room Number Setting 21 - Media Type 21 - Receive Data 21 - Native EPG 21

22 GENERAL 22 - Configuration Setup 25 - External Speaker 25 - Set ID Setup 25 - Power Saving 26 - HCEC Setup 27 - Clock Setup 28 - Password Change 28 - PreLoaded App 28 - Lock Mode 29 MEDIA SHARE 29 - SmartShare 29 - Screen Share 29 - DMR 29 - Bluetooth Sound Sync

30 - Alljoyn 30 - DIAL 30 - TV Name 30 - SoftAP 31 TV MANAGER 31 - USB Download Menu

EZMANAGER

• Image show n may differ fro m your TV.

INTRODUCTION

The Pro:Centric Platform enables you to simply install, manage and use guest-centric solutions. The default Domain “procentric.local” and IP Server Address are needed to be registered in DNS TV will contact the IP Server using the default Domain “procentric.local” via IP on server search page. If TV doesn’t contact the Server, TV will search the pre-defined channel earlier than all channels. (Only DVB-C)

The frequencies of pre-defined channels are below. Germany: ‘51000, 858000, 778000, 698000, 618000, 538000, 458000, 378000, 298000, 218000, 138000 khz’. Philippines 6Mhz: ‘57000, 651000, 591000, 531000, 471000, 411000, 351000, 291000, 231000, 171000, 111000 khz’. Other Country: ‘50000, 842000, 762000, 682000, 602000, 522000, 442000, 362000, 282000, 202000, 122000 khz’.

EZ-MANAGER WIZARD

ENGENGLISH

-If you are using Pro:Centric, this setup wizard till help you easily set up the TV. Select ‘NEXT’ to continue.

-Otherwise, if you will not be installing a Pro:Centric Server, select ‘EXIT’ to quit.

EZMANAGER

ENGLISH

ENG

LANGUAGE & COUNTRY SELECTION

(Except for Iran)

-Please select the Language and Country. Some countries need to select the Time Zone.

(Only Iran)

-Please select the Language.

EZMANAGER

Automatically for Setup

1 From the TV Conguration Options screen, you can choose how to proceed with the conguration of this TV. Whether you will

congure the TV for Pro:Centric operation via the wizard or use a USB memory device to congure the TV, you may rst wish to set the Room Number on the TV.

-If you intend to set Room Number as part of the TV configuration, use the Room Number option to assign the Room # for this TV before you continue with additional configuration.

-In the Label field, use the Left/Right arrow keys to specify a North, South, East, or West designation for this TV.

-In the Room Number field, you can use the number keys on the Installer Remote to direct enter a room number or use the virtual keyboard on the TV screen.

-To continue, move and select ‘NEXT’.

ENGENGLISH
