This is a User Guide installed on the TV.
The contents of this guide are subject to change without prior notice for quality improvement.
To view Program information
Displays information about the current Program and/or current time, etc.
1 Move the pointer of the Magic remote control to the top of the TV screen. 2 Click the activated channel banner area.
3 The Program details will be displayed at the bottom of the TV screen.Image shown may differ from your TV.
|
|
|
Prev./Next Ch. Change |
Watch |
|
|
Current time |
|
|
|
Thu. |
|
|
|
|
|
|
|
|
|
|
||
|
PM 4 : 28 |
PM 4 : 43 |
|
|
|
|
|
|
|
|
|
UP |
|
|
|
|
|
|
|
DOWN |
|
|
|
|
|
|
|
|
|
|
|
Program name |
Detailed Program information |
|
(for digital broadcast) |
To set favorite channels
SMART Settings SETUP Channel Edit
1 Move to the desired channel on Wheel (OK) button. Channel is selected. 2 Press Set as Favorite.
3 Select the desired favorite channel group.
4 Select Enter. Favorite is set.
To use Favorite
SMART Ch. List
Channel list will appear. Select the desired preset favorite channel from Favorite List A to D.
SMART TV Guide
[In Digital Mode Only]
Obtains information about Programs and airtime. Obtains Program information and viewing/recording schedules.
[Image shown may differ from your TV.]
TV Guide
Today OO OO. OOOO AM 9:00
Press Wheel (OK) button after moving to a program of your choice to view or view / record.
Select schedule by date |
Schedule List |
CH |
-24H |
CH |
+24H |
After viewing the schedule, makes revisions or deletions.
Schedule reservation by selecting date/time/channel. Makes repeat schedule reservation.
To set Auto Tuning
SMART Settings SETUP Auto Tuning
Automatically tunes the channels.
Channelsarenotregisteredproperlyunlesstheantenna/cableisconnected correctly.
Auto Tuning only sets channels that are currently broadcasting.
If Lock System is turned on, a pop-up window will appear asking for password.
To set channels manually
SMART Settings SETUP Manual Tuning
Adjusts channels manually and saves the results.
For digital broadcasting, signal strength, etc. can be checked.
To edit channels
SMART Settings SETUP Channel Edit
Edits the saved channels.
Set as favorite, block/unblock and Add/Delete etc. the selected channel.
SMART Settings PICTURE Aspect Ratio
Selects the screen aspect ratio.
16:9 |
|
Resizes the image ratio to fit a 16:9 screen. |
|
||
Just Scan |
|
Displays high-quality image without loss. |
|
In DTV/HDMI/Component (over 720p) mode, Just Scan is |
|
|
|
available. |
Original |
|
When your TV receives a wide screen signal it will automatically |
|
change to the picture format broadcasted. |
|
|
|
|
Full Wide
4:3
14:9
Zoom
Cinema
Zoom
When TV receives the wide screen signal, it will let you adjust the picture horizontally or vertically, in a linear proportion, to fill the entire screen fully.
4:3 and 14:9 video is supported in full screen without any video distortion through DTV input.
In DTV mode, Full Wide is available. Resizes the image ratio to fit 4:3 screen.
You can view a picture format of 14:9 or a general TV Program in the 14:9 mode. The 14:9 screen is viewed in the same way as in 4:3, but is moved up or down.
Resizes the image to fit the screen width. The top and bottom parts of the image may be cut off.
Formats an image to the cinemascope ratio (2.35:1) and zooms in on the ratio.
While viewing an external device, these cases may result in image burn:
-a video with stationary caption (such as network name)
-4:3 aspect ratio mode for an extended period
Take caution when using these functions.
Available picture size may differ depending on the input signal.
The screen aspect ratios on HDMI-PC input are available in 4:3 and 16:9 only.
[For models supporting 2160p] When a 2160p signal is input or your PC resolution is set to 3840 x 2160, the Aspect Ratio is fixed to Just Scan.
SMART Settings PICTURE Energy Saving
Reduces power consumption by adjusting screen brightness.
Off |
Turns off the Energy Saving mode. |
Minimum/ |
|
Medium/ |
Applies the pre-set Energy Saving mode. |
Maximum |
|
|
Screen is turned off and only sound is played. |
Screen Off |
Press any button except Power button on the remote |
|
control to turn the screen back on. |
SMART Quick Menu AV Mode
Views the TV with the best picture / audio optimized for different AV modes.
Off |
|
Views with the value set at the picture / sound menu. |
|
||
Cinema |
|
Optimizes picture and audio settings for movies. |
Game |
|
Optimizes picture and audio settings for games. |
|
|
|
To adjust pictures with Picture Wizard
SMART Settings PICTURE Picture Wizard
Use the remote control and follow the instructions of the Picture Wizard to calibrate and adjust for optimum picture quality without expensive pattern devices or help from a specialist.
Follow the instructions to obtain the optimum picture quality.
To select Picture Mode
SMART Settings PICTURE Picture Mode
Selects the picture mode optimized for the viewing environment or the program.
Vivid
Standard
Eco
Cinema / Game
Heightens contrast, brightness and sharpness to display vivid images.
Displays images in standard levels of contrast, brightness and sharpness.
The Energy Saver feature changes settings on the TV to reduce power consumption.
Displays the optimum picture for movie, game.
Menu for adjusting picture quality that allows experts and amateurs to enjoy the best TV viewing. This menu
Expert is ISF-certified and provided for picture tuning experts. (ISF logo can only be used on ISF-certified TV units.)
ISFccc : Imaging Science Foundation Certified Calibration Control
Depending on the input signal, the available range of picture modes may differ.
Expert mode is for picture tuning professionals to control and fine-tune using a specific image. For normal images, the effects may not be dramatic.
To fine-tune picture mode
SMART Settings PICTURE Picture Mode Backlight / Contrast / Brightness / Sharpness / Color / Tint / Color Temp.
First select a Picture Mode of your choice.
Backlight
Contrast
Brightness
Sharpness
Adjusts the display brightness by varying the brightness of the LCD panel.
Adjusts the difference between bright and dark regions of the screen.
Adjusts the overall screen brightness.
Adjusts the sharpness of the borders between bright and dark.
Color |
Adjusts the colors on the screen darker or lighter. |
Tint |
Adjusts the red/green color balance. |
Color Temp. |
Adjusts the overall tone of colors to warm or cool. |
|
|
Depending on the input signal or other picture settings, the range of detailed items for adjustment may differ.
To set advanced control
SMART Settings PICTURE Picture Mode Advanced control/Expert Control
Calibrates the screen for each picture mode or adjusts picture settings for a special screen.
First select a Picture Mode of your choice.
Dynamic Contrast |
Adjusts the contrast to the optimal level according to the |
brightness of the image. |
|
Dynamic Color |
Adjusts colors for more natural-looking colors. |
|
|
Preferred Color
Super Resolution
Gamma
Color Gamut
Edge Enhancer
xvYCC
Skin Color : Skin color spectrum can be separately set to implement the skin color as defined by the user.
Grass Color : Natural color spectrum (meadows, hills, etc.) can be separately set.
Sky Color : Sky color is set separately.
Provides a crystal-clear picture by improving the details in areas where the picture is blurry or unclear.
Sets the gradation curve according to the output of the picture signal in relation to the input signal.
Selects the range of colors that can be expressed.
Shows clearer and distinctive yet natural edges of the video.
[Depending on model] Expresses richer colors.
Color Filter
Expert Pattern
White Balance
Color
Management
System
Filters a specific color spectrum in RGB colors to fine-tune color saturation and hue accurately.
Patterns used for expert adjustment.
Adjusts the overall tone of the screen as desired.
In Expert mode, detailed fine-tuning can be set via the Method / Pattern etc.
This is a function used by experts when they adjust colors using a test pattern of six colors (Red / Green / Blue / Cyan / Magenta / Yellow) without affecting other color areas. For normal images, adjustments may not result in noticeable color changes.
Depending on input signal or other picture settings, the range of detailed items for adjustment may differ.
To set additional picture options
SMART Settings PICTURE Picture Mode Picture Option
Adjusts detailed setting for images.
Noise Reduction
MPEG Noise
Reduction
Black Level
Real Cinema
Reduces screen noise in the video.
Reduces noise caused by compressing digital video.
Adjusts the brightness or darkness of the screen to suit the black level of the picture input using the degree of darkness (black level) of the screen.
Optimizes the screen for movie viewing.
Eye Care |
[Depending on model] |
|
Adjusts screen brightness to prevent eye glare. |
||
|
[Depending on model]
Saves power consumption by adjusting the brightness
Motion Eye Care corresponding to the movement of the image on the screen.
It does not work while watching 3D images.
Depending on input signal or other picture settings, the range of detailed items for adjustment may differ.
To reset Picture Mode
SMART Settings PICTURE Picture Mode Picture Reset
Resets values customized by the user.
Each picture mode is reset. Select the picture mode you wish to reset.
SMART Settings PICTURE Picture Mode Picture Option TruMotion
[Depending on model]
Corrects images to display smoother motion sequences.
Smooth
Clear
Clear Plus
User
De-Judder/De-Blur value is set at 3.
De-Judder/De-Blur value is set at 7.
The screen appears clearer when Clear is selected.
Clear Plus cannot be selected in 3D mode.
Depending on model
De-Judder/De-Blur can be set manually.
• De-Judder : This function adjusts juddering of the screen.
•De-Blur : This function adjusts and eliminates blurring of the screen.
To use Sound Mode
SMART Settings SOUND Sound Mode
Optimizes TV audio to the selected sound mode.
Standard
Music/Cinema/
Sport/Game
User Setting
Suitable for all types of video.
[Depending on model]
Sets audio optimized for a specific genre.
Adjusts the volume to the desired level using the User EQ.
To fine-tune the volume
SMART Settings SOUND Sound Mode User EQ
Sets Sound Mode at User Setting first.
100 Hz / 300 Hz / 1 kHz/ |
Sets EQ by manually adjusting sound bands. |
3 kHz / 10 kHz |
|
Reset |
Resets previously changed equalizer value. |
|
|
To use Smart Sound Mode
SMART Settings SOUND Smart Sound Mode
Provides optimized sound adjusted for each content type.
If the Smart Sound Mode function is enabled, Sound Mode, Virtual Surround Plus, and Clear Voice II are automatically adjusted.
To use Virtual Surround sound
SMART Settings SOUND Virtual Surround plus
LG’s proprietary audio processing technology allows 5.1 channel-like surround sound from two speakers.
If Clear Voice ll is set to ON, Virtual Surround plus will not be chosen.
To use Clear Voice ll function
SMART Settings SOUND Clear Voice ll
Boosts voice clarity.
To set Volume Mode
SMART Settings SOUND Volume Mode
Sets various modes for volume control.
Auto Volume
Volume Control
Sets Auto Volume to On. The volume varies from channel to channel and program to program. When clicking through the channels, the volume is adjusted automatically to maintain the same level.
Using a single volume curve may result in an inaudible or loud sound depending on the environment. Adjusts volume levels depending on the time of day (day/night).
To synchronize audio and video
SMART Settings SOUND AV Sync. Adjust
Synchronizes video and audio directly when they do not match.
If you set AV Sync. Adjust to ON, you can adjust the sound output (TV speakers or SPDIF) to match the video.
[Depending on model]
Adjusts the synchronization of the sound from the TV's internal TV Speaker speakers.
The + and - buttons allow the viewer to synchronize the audio with the video.
