LG 55UH615V-ZB User manual

AAA

LED TV

UH61**

X 4

(M4 X L14)

www.lg.com

P/No: MFL69366828 (1602-REV00)

Printed in Korea

1

2

3

4

A

B

5

6

ANTENNA /

CABLE IN

HDMI IN

HDMI IN/ARC

USB IN

LAN

LAN

USB IN

AUDIO OUT/

H/P OUT

Satellite IN

OPTICAL DIGITAL

AUDIO OUT

PCMCIA CARD SLOT

COMPONENT IN AV IN

VIDEO/Y P

VIDEO AUDIO

B

PRL/MONO AUDIO R

VIDEO/Y P

B

PRL/MONO AUDIO R

VIDEO L/MONO AUDIO R

1 2

3 4

1

2

0

A

E

55UH615V-ZB
55UH6157-ZB
55UH6159-ZB
60UH615V-ZB
60UH6157-ZB
60UH6159-ZB

Power requirement

D

G

1

F

A

B

C

D

G

B

2

C

E

F

1240 778 237 722 56.7 18.1 17.8

1348

(Güç gereksinimi)

839 263 782

58.5

23.7 23.3

AC 100 - 240 V ~ 50 / 60 Hz

G

F

G

2

1

65UH615V-ZB
65UH6157-ZB
65UH6159-ZB

Power requirement

A

1460

B

902 263 846

(Güç gereksinimi)

C

D

E

58.5

F

G

F

1

27.4 27.0

G

2

AC 100 - 240 V ~ 50 / 60 Hz

OWNER’S MANUAL

Safety and Reference

LED TV*

* LG LED TV applies LCD screen with LED

backlights.

Please read this manual carefully before operating your set and
retain it for future reference.

*MFL69361119*

www.lg.com

P/NO : MFL69361119(1607-REV02)

Printed in Korea

ENGLISH

Safety instructions

Please read these safety precautions
carefully before using the product.

WARNING

Do not place the TV and/or remote control in
the following environments:

•  A location exposed to direct sunlight

•  An area with high humidity such as a

bathroom

•  Near any heat source such as stoves and
other devices that produce heat

•  Near kitchen counters or humidiers where
they can easily be exposed to steam or oil

•  An area exposed to rain or wind

•  Near containers of water such as vases

Otherwise, this may result in re, electric
shock, malfunction or product deformation.

Do not touch the power plug with wet hands.
Additionally, if the cord pin is wet or covered
with dust, dry the power plug completely or
wipe dust o. You may be electrocuted due to
excess moisture.

Make sure to connect Mains cable to compliant
AC mains socket with Grounded earth pin.
(Except for devices which are not grounded
on earth.) Otherwise possibility you may be
electrocuted or injured.

Insert power cable plug completely into wall
socket otherwise if not secured completely into
socket, re ignition may break out.

Do not place the product where it might be
exposed to dust. This may cause a re hazard.

Mains Plug is the TV connecting/disconnecting
device to AC mains electric supply. This plug
must remain readily attached and operable
when TV is in use.

2

Ensure the power cord does not come into
contact with hot objects such as a heater. This
may cause a re or an electric shock hazard.

Do not place a heavy object, or the product
itself, on power cables.
Otherwise, this may result in re or electric
shock.

ENGLISH

Bend antenna cable between inside and
outside building to prevent rain from owing
in. This may cause water damaged inside the
Product and could give an electric shock.

Do not let your children climb or cling onto the
TV.
Otherwise, the TV may fall over, which may
cause serious injury.

When mounting TV onto wall make sure to
neatly install and isolate cabling from rear of
TV as to not create possibility of electric shock /
re hazard.

Do not plug too many electrical devices into a
single multiple electrical outlet. Otherwise, this
may result in re due to over-heating.

Do not drop the product or let it fall over when
connecting external devices. Otherwise, this
may result in injury or damage to the product.

Keep the anti-moisture packing material or
vinyl packing out of the reach of children.
Anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can cause
suocation. Keep it out of the reach of children.

Dispose of used batteries carefully to ensure
that a small child does not consume them.
Please seek Doctor- Medical Attention
immediately if child consumes batteries.

Do not insert any metal objects/conductors
(like a metal chopstick/cutlery/screwdriver)
between power cable plug and input Wall
Socket while it is connected to the input
terminal on the wall. Additionally, do not touch
the power cable right after plugging into the
wall input terminal. You may be electrocuted.
(Depending on model)

Do not put or store inammable substances
near the product. There is a danger of
combustion/explosion or re due to careless
handling of the inammable substances.

3

ENGLISH

Do not drop metallic objects such as coins,
hair pins, chopsticks or wire into the product,
or inammable objects such as paper and
matches. Children must pay particular
attention. Electrical shock, re or injury can
occur. If a foreign object is dropped into the
product, unplug the power cord and contact the
service centre.

Do not spray water on the product or scrub
with an inammable substance (thinner or
benzene). Fire or electric shock accident can
occur.

Do not allow any impact, shock or any objects
to fall into the unit, and do not drop anything
onto the screen. You may be injured or the
product can be damaged.

Never touch the wall outlet when there
is leakage of gas, open the windows and
ventilate. It may cause a re or a burn by a
spark.

Do not disassemble, repair or modify the
product at your own discretion. Fire or electric
shock accident can occur.
Contact the service centre for check, calibration
or repair.

If any of the following occur, unplug the
product immediately and contact your local
service centre.

•  The product has been impacted by shock

•  The product has been damaged

•  Foreign objects have entered the product

•  The product produced smoke or a strange

smell

This may result in re or electric shock.

Never touch this product or antenna during a
thunder or lighting storm.
You may be electrocuted.

4

Unplug the TV from AC mains wall socket if you
do not intend to use the TV for a long period of
time. Accumulated dust can cause re hazard
and insulation deterioration can cause electric
leakage/shock/re.

ENGLISH

Apparatus shall not be exposed to dripping or
splashing and no objects lled with liquids,
such as vases, shall be placed on the apparatus.

Do not install this product on a wall if it could
be exposed to oil or oil mist. This may damage
the product and cause it to fall.

If water enters or comes into contact with TV,
AC adapter or power cord please disconnect
the power cord and contact service centre
immediately. Otherwise, this may result in
electric shock or re.

Only use an authorized AC adapter and power
cord approved by LG Electronics. Otherwise, this
may result in re, electric shock, malfunction or
product deformation.

Be careful in handling the adapter to prevent
any external shocks to it. An external shock may
cause damage to the adapter.

Make sure the power cord is connected securely
to the power plug on the TV. (Depending on
model)

CAUTION

Install the product where no radio wave occurs.

There should be enough distance between an
outside antenna and power lines to keep the
former from touching the latter even when the
antenna falls. This may cause an electric shock.

Never Disassemble the AC adapter or power
cord. This may result in re or electric shock.

Do not install the product on places such as
unstable shelves or inclined surfaces. Also avoid
places where there is vibration or where the
product cannot be fully supported. Otherwise,
the product may fall or ip over, which may
cause injury or damage to the product.

5

ENGLISH

If you install the TV on a stand, you need to
take actions to prevent the product from
overturning. Otherwise, the product may fall
over, which may cause injury.

Only use the specied type of battery. This could
cause damage to the remote control.

If you intend to mount the product to a wall,
attach VESA standard mounting interface
(optional parts) to the back of the product.
When you install the set to use the wall
mounting bracket (optional parts), x it
carefully so as not to drop.

Only use the attachments / accessories specied
by the manufacturer.

When installing the antenna, consult with a
qualied service technician. If not installed by
a qualied technician, this may create a re
hazard or an electric shock hazard.

We recommend that you maintain a distance
of at least 2 to 7 times the diagonal screen size
when watching TV. If you watch TV for a long
period of time, this may cause blurred vision.

Do not mix new batteries with old batteries.
This may cause the batteries to overheat and
leak.

Batteries should not be exposed to excessive
heat. For example, keep away from direct
Sunlight, open replace and electric heaters.

Do not place non-rechargeable batteries in
charging device.

Make sure there are no objects between the
remote control and its sensor.

Signal from Remote Control can be interrupted
due to external/internal lighting eg Sunlight,
uorescent lighting. If this occurs turn o
lighting or darken viewing area.

6

ENGLISH

When connecting external devices such as
video game consoles, make sure the connecting
cables are long enough. Otherwise, the product
may fall over, which may cause injury or
damage the product.

Do not turn the product On/O by plugging­in or unplugging the power plug to the wall
outlet. (Do not use the power plug for switch.)
It may cause mechanical failure or could give an
electric shock.

Please follow the installation instructions
below to prevent the product from overheating.

•  The distance between the product and the
wall should be more than 10cm.

•  Do not install the product in a place with
no ventilation (e.g., on a bookshelf or in a
cupboard).

•  Do not install the product on a carpet or
cushion.

•  Make sure the air vent is not blocked by a
tablecloth or curtain.

Otherwise, this may result in re.

Take care not to touch the ventilation openings
when watching the TV for long periods as the
ventilation openings may become hot. This
does not aect the operation or performance of
the product.

Periodically examine the cord of your appliance,
and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with
an exact replacement part by an authorized
servicer.

Prevent dust collecting on the power plug pins
or outlet. This may cause a re hazard.

Protect the power cord from physical or
mechanical abuse, such as being twisted,
kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the
appliance.

Do not press strongly upon the panel with a
hand or sharp object such as nail, pencil or pen,
or make a scratch on it, as it may causedamage
to screen.

7

ENGLISH

Avoid touching the screen or holding your
nger(s) against it for long periods of time.
Doing so may produce some temporary or
permanent distortion/damage to screen.

When cleaning the product and its components,
unplug the power rst and wipe it with a soft
cloth. Applying excessive force may cause
scratches or discolouration. Do not spray with
water or wipe with a wet cloth. Never use glass
cleaner, car or industrial shiner, abrasives or
wax, benzene, alcohol etc., which can damage
the product and its panel. Otherwise, this may
result in re, electric shock or product damage
(deformation, corrosion or breakage).

As long as this unit is connected to the AC wall
outlet, it is not disconnected from the AC power
source even if you turn o this unit by SWITCH.

When unplugging the cable, grab the plug and
unplug it, by pulling at the plug.
Don’t pull at the cord to unplug the power
cord from the power board, as this could be
hazardous.

When moving the product, make sure you turn
the power o rst. Then, unplug the power
cables, antenna cables and all connecting
cables.
The TV set or power cord may be damaged,
which may create a re hazard or cause electric
shock.

When moving or unpacking the product,
work in pairs because the product is heavy.
Otherwise, this may result in injury.

Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.

If the product feels cold to the touch, there may
be a small “icker” when it is turned on. This is
normal, there is nothing wrong with product.

8

ENGLISH

This panel is an advanced product that contains
millions of pixels. You may see tiny black dots
and/or brightly coloured dots (red, blue or
green) at a size of 1ppm on the panel. This does
not indicate a malfunction and does not aect
the performance and reliability of the product.
This phenomenon also occurs in third-party
products and is not subject to exchange or
refund.

Generated Sound

“Cracking” noise: A cracking noise that
occurs when watching or turning o the TV
is generated by plastic thermal contraction
due to tempera-ture and humidity. This
noise is common for products where thermal
deformation is required. Electrical circuit
humming/panel buzzing: A low level noise is
generated from a high-speed switching circuit,
which supplies a large amount of current to
operate a product. It varies depending on the
product.
This generated sound does not aect the
performance and reliability of the product.

You may nd dierent brightness and color
of the panel depending on your viewing
position(left/right/top/down).
This phenomenon occurs due to the
characteristic of the panel. It is not related
with the product performance, and it is not
malfunction.

Displaying a still image for a prolonged period
of time may cause image sticking. Avoid
displaying a xed image on the TV screen for a
long period of time.

Do not use high voltage electrical goods near
the TV (e.g. electric mosquito-swatter). This
may result in product malfunction.

9

ENGLISH

A

A

<

Viewing 3D imaging (Only
3D models)

CAUTION

•  Children should be supervised by an
adult when viewing 3D video. If a child
experiences eye fatigue, headaches or
blurred vision while watching 3D, they
should take a break, before they resume
watching 3D content.

•  When viewing a 3D video, some may
experience discomfort such as a headache,
dizziness, fatigue, or blurred vision. In this
case, stop watching the 3D video and take
a rest.

•  If you watch a 3D video for a long time, you
may experience eye fatigue. In this case,
stop watching the 3D video and take a rest.

•  Only use LG 3D glasses. Otherwise, you may
not be able to view 3D videos properly.

•  Do not use 3D glasses instead of your
normal glasses, sunglasses, or protective
goggles.

•  Do not keep your 3D glasses in extremely
high or low temperatures. It will cause
deformation.

•  Do not use 3D glasses while walking or
moving around. It may cause an accident or
injury.

•  Be careful not to poke your eye with the
frames of the 3D glasses.

•  Do not watch 3D content if you have
photosensitive seizures, epilepsy, or heart

disease.

Preparing

NOTE

•  If the TV is turned on for the rst time
after it was shipped from the factory,
initialization of the TV may take a few
minutes.

•  Image shown may dier from your TV.

•  Your TV’s OSD (On Screen Display) may dier

slightly from that shown in this manual.

•  The available menus and options may dier
from the input source or product model that
you are using.

•  New features may be added to this TV in the
future.

•  The items supplied with your product may
vary depending on the model.

•  Product specications or contents of this
manual may be changed without prior
notice due to upgrade of product functions.

•  For an optimal connection, HDMI cables
and USB devices should have bezels less
than 10 mm thick and 18 mm width. Use an
extension cable that supports USB 2.0 if the
USB cable or USB memory stick does not t
into your TV’s USB port.

B

•  Use a certied cable with the HDMI logo
attached.

•  If you do not use a certied HDMI cable, the
screen may not display or a connection error
may occur. (Recommended HDMI Cable
Types)

B

*A < 10 mm

18 mm

*B

10

ENGLISH

- High-Speed HDMI®/TM cable (3 m or less)

- High-Speed HDMI®/TM cable with Ethernet
(3 m or less)

•  How to use the ferrite core (Depending on
model)

- Use the ferrite core to reduce the
electromagnetic interference in the power
cord. Wind the power cord on the ferrite
core once.

[Wall side]

[TV side]

10 cm (+ / -2 cm)

•  Antenna Isolator Installation Guide
(Depending on model)

- Use this to install TV in a place where there
is a voltage dierence between TV Set and
GND of antenna signal.

»If there is a voltage difference between
TV Set and GND of antenna signal, the
antenna contact might be heated and
excessive heat might cause an accident.

Wall

ANTENNA/
CABLE IN

Cable /
Antenna

or

Isolator

1. Connect to TV.

2. Connect to Set-Top box.

- Connect one end of the isolator to cable/
antenna jack and the other to TV set or
set-top box.

- “Equipment connected to the protective
earthing of the building installation
through the mains connection or through
other equipment with a connection
to protective earthing - and to a cable
distribution system using coaxial cable,
may in some circumstances create a re
hazard. Connection to a cable distribution
system has therefore to be provided
through a device providing electrical
isolation below a certain frequency range
(galvanic isolator, see EN 60728-11)”

- When applying the RF Isolator, a slight loss

of signal sensitivity can occur.

- You can improve the safety when watching
TV by eciently removing power voltage
from TV antenna. It is recommended to
mount the isolator to the wall. If it cannot
be mounted to the wall, mount it on the
TV. Avoid disconnecting the antenna
Isolator after installation.

- Before starting, be sure that the TV
antenna is connected.

11

ENGLISH

CAUTION

Separate purchase

•  Do not use any unapproved items to ensure

the safety and product life span.

•  Any damage or injuries caused by using

unapproved items are not covered by the
warranty.

•  Some models have a thin lm attached on

to the screen and this must not be removed.

•  When attaching the stand to the TV

set, place the screen facing down on a
cushioned table or at surface to protect
the screen from scratches.

•  Make sure that the screws are inserted

correctly and fastened securely. (If they are
not fastened securely enough, the TV may
tilt forward after being installed.) Do not
use too much force and over tighten the
screws; otherwise screw may be damaged
and not tighten correctly.

•  Make sure to wring any excess water or

cleaner from the cloth.

•  Do not spray water or cleaner directly onto

the TV screen.

•  Make sure to spray just enough of water or

cleaner onto a dry cloth to wipe the screen.

•  When cleaning the product, be careful not

to allow any liquid or foreign objects to
enter the gap between the upper, left or
right side of the panel and the guide panel.
(Depending on model)

Separate purchase items can be changed or
modied for quality improvement without any
notication. Contact your dealer to buy these
items. These devices only work with certain
models.
The model name or design may be changed
depending on the upgrade of product functions,
manufacturer’s circumstances or policies.

(Depending on model)

AG-F***

Cinema 3D Glasses

AN-VC550

Smart camera

AN-MR650

Magic Remote

AG-F***DP

Dual Play Glasses

Lifting and moving
the TV

Please note the following advice to prevent the
TV from being scratched or damaged and for
safe transportation regardless of its type and
size.

•  It is recommended to move the TV in
the box or packing material that the TV
originally came in.

•  Before moving or lifting the TV, disconnect
the power cord and all cables.

•  When holding the TV, the screen should
face away from you to avoid damage.

12

ENGLISH

•  Hold the top and bottom of the TV
frame rmly. Make sure not to hold the
transparent part, speaker, or speaker grill
area.

•  When transporting a large TV, there should
be at least 2 people.

•  When transporting the TV by hand, hold the
TV as shown in the following illustration.

Using the button

(Depending on model)
You can simply operate the TV functions,
pressing or moving the button.

NOTE

•  43/49UH60, 43/49UH61, 43/49UH62 series
does not have a Joystick functions but has

only a power On/O button.

<A type>

•  When transporting the TV, do not expose
the TV to jolts or excessive vibration.

•  When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.

•  Do not apply excessive pressure to cause
exing /bending of frame chassis as it may
damage screen.

•  When handling the TV, be careful not to
damage the protruding buttons.

CAUTION

•  Avoid touching the screen at all times, as
this may result in damage to the screen.

•  Do not move the TV by holding the cable
holders, as the cable holders may break,
and injuries and damage to the TV may
occur.

Dome Button

<B type>

Joystick Button

or

Joystick Button

13

ENGLISH

Basic functions

2 Connect the power cord to a wall outlet.

Power On (Press)
Power O (Press
and hold)

Volume Control

Programmes
Control

1 All running apps will close, and any

recording in progress will stop.

1

Adjusting the menu

When the TV is turned on, press the button
one time. You can adjust the Menu items
pressing or moving the buttons.

Turns the power o.

Clears on-screen displays and returns
to TV viewing.

Changes the input source.
Accesses the settings menu.

Mounting on a
table

1 Lift and tilt the TV into its upright position

on a table.

•  Leave a 10 cm (minimum) space from the
wall for proper ventilation.

10 cm

10 cm

10 cm

CAUTION

•  Do not place the TV near or on sources
of heat, as this may result in re or other
damage.

Securing the TV to a wall

(This feature is not available for all models.)

1 Insert and tighten the eye-bolts, or TV

brackets and bolts on the back of the TV.

•  If there are bolts inserted at the eye-bolts
position, remove the bolts rst.

2 Mount the wall brackets with the bolts to

the wall.
Match the location of the wall bracket and
the eye-bolts on the rear of the TV.

3 Connect the eye-bolts and wall brackets

tightly with a sturdy rope. Make sure to keep
the rope horizontal with the at surface.

CAUTION

•  Make sure that children do not climb on or
hang on the TV.

NOTE

•  Use a platform or cabinet that is strong and
large enough to support the TV securely.

•  Brackets, bolts and ropes are not provided.
You can obtain additional accessories from
your local dealer.

14

10 cm

10 cm

ENGLISH

Mounting on a wall

Attach an optional wall mount bracket at the
rear of the TV carefully and install the wall
mount bracket on a solid wall perpendicular
to the oor. When you attach the TV to other
building materials, please contact qualied
personnel. LG recommends that wall mounting
be performed by a qualied professional
installer. We recommend the use of LG’s wall
mount bracket. LG’s wall mount bracket is
easy to move with cables connected. When
you do not use LG’s wall mount bracket, please
use a wall mount bracket where the device is
adequately secured to the wall with enough
space to allow connectivity to external devices.
It is advised to connect all the cables before
installing xed wall mounts.

10 cm

10 cm

Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are
described in the following table.

10 cm

10 cm

Separate purchase(Wall
mounting bracket)

Model

VESA (A x
B) (mm)
Standard
screw
Number
of screws
Wall
mount
bracket

43UH60**
43UH61**
40/43UH62**
40UH63**
43UH65**
43UH66**
40/43UH67**
43UH74**
43UH75**

200 x 200 300 x 300

M6 M6

4 4

LSW240B
MSW240

49/55UH60**
49/55UH61**
49/55UH62**
50UH63**
49/55UH65**
49/55UH66**
49/50/55UH67**
49/55UH74**
49/55UH75**
49/55UH77**
49/55UH79**
49/55UH80**
49/55UH84**
49/55UH85**

LSW350B
MSW240

15

ENGLISH

A

B

60/65UH60**
60/65UH61**
60/65UH62**
58UH63**
60/65UH65**
60/65UH66**

Model

58/60/65UH67**
60UH74**
60/65UH75**
60/65UH77**
60/65UH80**
60UH84**
60/65UH85**

VESA (A x
B) (mm)
Standard
screw
Number
of screws

300 x 300 600 x 400

M6 M8

4 4

Wall
mount

LSW350B LSW640B

bracket
Model 55/65UH95**
VESA (A x
B) (mm)
Standard
screw
Number
of screws

300 x 200

M6

4

Wall
mount

OTW420B

bracket

70UH63**
75UH65**
70UH67**
70UH70**
75UH77**
75UH78**
75UH80**
75UH85**
79/86UH95**

CAUTION

•  Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.

NOTE

•  When installing the wall mounting bracket,
use the adhesive label or protective cover
provided. The adhesive label or protective
cover will protect the opening from
accumulating dust and dirt. (Only when the
label or cover is provided)

Provided item

Adhesive label

Provided item

Adhesive label

Provided item

Protective cover

16

ENGLISH

•  When installing the wall mounting bracket,
it is recommended to cover the stand hole
using tape, in order to prevent the inux of
dust and insects. (Depending on model)

Stand hole

•  When attaching a wall mounting bracket
to the TV, insert the wall mount spacers
into the TV wall mount holes to adjust the
vertical angle of the TV. (Only when the
item of the following form is provided)

Provided

Item

Wall Mount

Spacer

•  Depending on the shape of the stand, use
a at tool to remove the stand cover as
illustrated below. (e.g., a at screwdriver)

(Only when the item of the following form
is provided)

Flat tool

Connections
(notications)

Connect various external devices to the TV
and switch input modes to select an external
device. For more information of external device’s
connection, refer to the manual provided with
each device.
Available external devices are: HD receivers, DVD
players, VCRs, audio systems, USB storage devices,
PC, gaming devices, and other external devices.

NOTE

•  The external device connection may dier
from the model.

•  Connect external devices to the TV regardless
of the order of the TV port.

•  If you record a TV program on a DVD recorder
or VCR, make sure to connect the TV signal
input cable to the TV through a DVD recorder
or VCR. For more information of recording,
refer to the manual provided with the
connected device.

•  Refer to the external equipment’s manual
for operating instructions.

•  If you connect a gaming device to the TV, use
the cable supplied with the gaming device.

•  In PC mode, there may be noise associated
with the resolution, vertical pattern, contrast
or brightness. If noise is present, change
the PC output to another resolution, change
the refresh rate to another rate or adjust
the brightness and contrast on the PICTURE
menu until the picture is clear.

•  In PC mode, some resolution settings
may not work properly depending on the
graphics card.

17

ENGLISH

•  If ULTRA HD content is played on your PC,
video or audio may become disrupted
intermittently depending on your PC’s
performance. (Depending on model)

Antenna connection

Connect the TV to a wall antenna socket with
an RF cable (75 Ω).

•  Use a signal splitter to use more than 2 TVs.

•  If the image quality is poor, install a signal

amplier properly to improve the image
quality.

•  If the image quality is poor with an
antenna connected, try to realign the
antenna in the correct direction.

•  An antenna cable and converter are not
supplied.

•  Supported DTV Audio: MPEG, Dolby Digital,
Dolby Digital Plus, HE-AAC

•  For a location that is not supported with
ULTRA HD broadcasting, this TV cannot
receive ULTRA HD broadcasts directly.
(Depending on model)

Satellite dish connection

(Only satellite models)
Connect the TV to a satellite dish to a satellite
socket with a satellite RF cable (75 Ω).

18

CI module connection

(Depending on model)
View the encrypted (pay) services in digital TV mode.

•  Check if the CI module is inserted into the
PCMCIA card slot in the right direction. If
the module is not inserted properly, this can
cause damage to the TV and the PCMCIA
card slot.

•  If the TV does not display any video and
audio when CI+ CAM is connected, please
contact to the Terrestrial/Cable/Satellite
Service Operator.

USB connection

Some USB Hubs may not work. If a USB device
connected using a USB Hub is not detected,
connect it to the USB port on the TV directly.

Other connections

Connect your TV to external devices. For the
best picture and audio quality, connect the
external device and the TV with the HDMI cable.
Some separate cable is not provided.

• 
ULTRA HD Deep Colour

- On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2,

4:2:0)

- Off : Support 4K @ 50/60 Hz 8 bit (4:2:0)

If the device connected to Input Port also
supports ULTRA HD Deep Colour, your picture
may be clearer. However, if the device doesn’t
support it, it may not work properly. In that
case, connect the device to a dierent HDMI
port or change the TV’s HDMI ULTRA HD
Deep Colour setting to Off.
(This feature is available on certain models
which are supported ULTRA HD Deep Colour
only.)

General HDMI

ENGLISH

NOTE

A

•  Supported HDMI Audio format :
Dolby Digital (32 kHz, 44.1 kHz, 48 kHz),
DTS (44.1 kHz, 48 kHz),
PCM (32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz)
(Depending on model)

Remote control

The descriptions in this manual are based on
the buttons on the remote control. Please read
this manual carefully and use the TV correctly.

To replace batteries, open the battery cover,
replace batteries (1.5 V AAA) matching the and

ends to the label inside the compartment, and
close the battery cover. To remove the batteries,
perform the installation actions in reverse.

Make sure to point the remote control toward
the remote control sensor on the TV.

(Depending on model)

A

2

1

(POWER) Turns the TV on or o.

Selects Radio, TV and DTV

programme.

(INPUT) Changes the input source.

(Q. Settings) Accesses the Quick Settings.

1

, 2 By zooming in on the
selected area, you can view it in full screen.
(Depending on model)

1

, 2

Views the information of the

current programme and screen. (Depending
on model)

1

(SEARCH) Search for content such as
TV programmes, movies and other videos, or
perform a web search by entering text in the
search bar. (Depending on model)

Recalls your preferred subtitle in

2

digital mode. (Depending on model)
Number buttons Enters numbers.

Accesses the saved programmes list.

(Space) Opens an empty space on the

screen keyboard.

Shows programme guide.

3

(Depending on model)

Returns to the previously viewed

3

programme. (Depending on model)

3

4
5

B

19

ENGLISH

B

Views the information of the

4

current programme and screen. (Depending
on model)

4

, 5

(SEARCH) Search for content such

as TV programmes, movies and other videos,
or perform a web search by entering text in
the search bar. (Depending on model)

4

, 5 Shows programme guide.

(Depending on model)

5

Used for viewing 3D video. (Depending

on model)

(MUTE) Mutes all sounds.

Adjusts the volume level.

Scrolls through the saved programmes.
Moves to the previous or next

screen.

RECENT

6

8

LIVE

MENU

7

9

C

10

D

C

6

, 8 Returns to the previous level.

(Depending on model)

6

, 7 , 8 , 9 Teletext buttons (

) These buttons are used for

teletext. (Depending on model)

7

, 9 Clears on-screen displays and

returns to TV viewing. (Depending on model)

Navigation buttons (up/down/left/right)

Scrolls through menus or options.

Selects menus or options and conrms

your input.

D

By pressing the AD button, audio

descriptions function will be enabled.

10

Starts to record and displays

record menu.

(Only Time Machine

(Depending on model)

By zooming in on the

10

selected area, you can view it in full screen.

(Depending on model)

10

Selects the MHP TV menu source.

(Depending on model)

Returns to LIVE TV.

Control buttons ( )

Controls media contents.

Coloured buttons These access special

functions in some menus.

( : Red, : Green, : Yellow,

: Blue)

Ready

supported model)

Shows the previous history.

(HOME) Accesses the Home menu.

Shows the list of Programmes and

Recommended. (Depending on model)

20

ENGLISH

Magic remote functions

A

(Depending on model)
When the message “Magic remote battery is
low. Change the battery.” is displayed, replace
the battery.

To replace batteries, open the battery
cover, replace batteries (1.5 V AA) matching
the and ends to the label inside the
compartment, and close the battery cover. Be
sure to point the magic remote toward the
remote control sensor on the TV. To remove the
batteries, perform the installation actions in
reverse.

A

B

(POWER) Turns the TV on or o.

(STB POWER) You can turn your set­top box on or o by adding the set-top box to
the universal remote control for your TV.
Number buttons Enters numbers.

Accesses the saved programmes list.

(Space) Opens an empty space on the

screen keyboard.

(Screen Remote) Displays the Screen
Remote.
* Accesses the Universal Control Menu.

(Depending on model)

B

Adjusts the volume level.

Scrolls through the saved programmes.

(MUTE) Mutes all sounds.

* By pressing and holding the button,

audio descriptions function will be
enabled. (Depending on model)

(SEARCH) Search for content such as TV

programmes, movies and other videos, or
perform a web search by entering text in the
search bar.

(Voice recognition)

(Depending on model)
Network connection is required to use the
voice recognition function.
1 Press the voice recognition button.
2 Speak when the voice display window

appears on the TV screen.

(HOME) Accesses the Home menu.

Shows the previous history.

21

ENGLISH

Displays the set-top box Home

menu.
* When you are not watching via a set-top

box: the display changes to the set-top box
screen.

C

D

C

Wheel (OK) Press the center of the Wheel

button to select a menu. You can change
programmes by using the Wheel button.

(up/down/left/right) Press

the up, down, left or right button to scroll
the menu. If you press buttons
while the pointer is in use, the pointer will
disappear from the screen and Magic Remote
will operate like a general remote control. To
display the pointer on the screen again, shake
Magic Remote to the left and right.

D

Returns to the previous screen.

Clears on-screen displays and returns to

last input viewing.

Shows programme guide.

Used for viewing 3D video. (Only 3D models)
(INPUT) Changes the input source.

* Pressing and holding the button dis-

plays all the lists of external inputs.

(Q. Settings) Accesses the Quick Settings.

* Pressing and holding the button dis-

plays the All Settings menu.

Coloured buttons These access special
functions in some menus.
( : Red, : Green, : Yellow,
: Blue)

Teletext buttons ( , ) These

buttons are used for teletext.

You can zoom in on the area where the

remote control is pointed.

By zooming in on the selected

area, you can view it in full screen.

22

ENGLISH

Registering magic remote

Open source

How to register the magic
remote

To use the Magic Remote, rst pair it with your TV.
1 Put batteries into the Magic Remote and

turn the TV on.

2 Point the Magic Remote at your TV and press

the Wheel (OK) on the remote control.

* If the TV fails to register the Magic Remote,

try again after turning the TV off and back
on.

How to deregister the magic
remote

Press and hold the and (HOME)
buttons at the same time for ve seconds, to
unpair the Magic Remote with your TV.
* Pressing and holding the button will

let you cancel and re-register Magic Remote
at once.

software notice
information

To obtain the source code under GPL, LGPL, MPL
and other open source licenses, that is contained
in this product, please visit http://opensource.

lge.com.

In addition to the source code, all referred
license terms, warranty disclaimers and
copyright notices are available for download.
LG Electronics will also provide open source code
to you on CD-ROM for a charge covering the cost
of performing such distribution (such as the cost
of media, shipping, and handling) upon email
request to [e-mail]. This oer is
valid for three (3) years from the date on which
you purchased the product.

External control

Licenses

Supported licenses may dier by model. For
more information about licenses, visit www.
lg.com.

(Only UH95**,
UH85**, UH77**,
75UH78**, 70UH70**)

device setup

To obtain the external control device setup
information, please visit www.lg.com.

23

ENGLISH

Troubleshooting

Cannot control the TV with the remote control.

•  Check the remote control sensor on the
product and try again.

•  Check if there is any obstacle between the
product and the remote control.

•  Check if the batteries are still working and
properly installed ( to , to ).

No image display and no sound is produced.

•  Check if the product is turned on.

•  Check if the power cord is connected to a

wall outlet.

•  Check if there is a problem in the wall outlet
by connecting other products.

The TV turns o suddenly.

•  Check the power control settings. The
power supply may be interrupted.

•  Check if the Sleep Timer / Timer Power
Off is activated in the Timers settings.

•  Check if the Auto Power O is activated
in the General -> Eco Mode settings.
(Depending on model)

•  If there is no signal while the TV is on,
the TV will turn o automatically after 15

minutes of inactivity.

When connecting to the PC (HDMI), ‘No signal’
or ‘Invalid Format’ is displayed.

•  Turn the TV o/on using the remote control.

•  Reconnect the HDMI cable.

•  Restart the PC with the TV on.

24

ENGLISH

Specications

Wireless module specification

•  As band channels can vary per country, the user cannot change or adjust the operating
frequency. This product is congured for the regional frequency table.

•  For consideration of the user, this device should be installed and operated with a minimum
distance of 20 cm between the device and the body.

(Only UH60**, UH61**, UH62**)

Wireless LAN module (TWFM-B006D) specifications

Standard IEEE802.11a/b/g/n

Frequency Range Output Power (Max.)

2400 to 2483.5 MHz

5150 to 5250 MHz

5725 to 5850 MHz (for Non EU)

(Only UH63**, UH65**, UH66**, UH67**, UH70**, UH74**, UH75**, UH77**, UH78**, UH79**,
UH80**, UH84**, UH85**, UH95**)

Wireless module (LGSBWAC61) specifications

Wireless LAN (IEEE 802.11a/b/g/n/ac)

Frequency Range Output Power (Max.)

2400 to 2483.5 MHz

5150 to 5725 MHz

5725 to 5850 MHz (Not for EU)

Bluetooth

Frequency Range Output Power (Max.)

2400 to 2483.5 MHz 10 dBm

* “IEEE802.11ac” is not available in all countries.

14 dBm

12.5 dBm

15.5 dBm

15.5 dBm

17.5 dBm

8.0 dBm

25

ENGLISH

CI Module (W x H x D) 100.0 mm x 55.0 mm x 5.0 mm

Operating Temperature 0 °C to 40 °C

Environment

condition

(Depending on country)

Satellite Terrestrial Cable

Television

system

DVB-S/S2*

Channel

coverage

950 ~ 2150 Mhz

(Band)

Maximum

number of

storable

programmes

Operating Humidity Less than 80 %

Storage Temperature -20 °C to 60 °C

Storage Humidity Less than 85 %

Digital TV Analogue TV

DVB-T

DVB-T2*

DVB-C

VHF III : 174 ~ 230 Mhz

UHF IV : 470 ~ 606 Mhz

UHF V : 606 ~ 862 Mhz

46 ~ 862 Mhz 46 ~ 862 Mhz

S Band II : 230 ~ 300 Mhz

S Band III : 300 ~ 470 Mhz

6,000 3,000

Terrestrial /

Cable

PAL/SECAM

B/G, D/K, I,

SECAM L

External
antenna

impedance

* Sadece DVB-T2/C/S2 destekli modeller.

26

75 Ω

Record the model number and serial number of the TV.
Refer to the label on the back cover and quote this
information to your dealer when requiring any service.

MODEL

SERIAL

OWNER’S MANUAL

EXTERNAL CONTROL
DEVICE SETUP

Please read this manual carefully before operating the set and retain it for
future reference.

www.lg.com

KEY CODES

2

2

ENGLISH

ENG

KEY CODES

• This feature is not available for all models.

Code

(Hexa)

00 CH +, PR + R/C Button 53 List R/C Button

01 CH -, PR - R/C Button 5B Exit R/C Button

02 Volume + R/C Button 60 PIP(AD) R/C Button

03 Volume - R/C Button 61 Blue R/C Button

06 > (Arrow Key / Right Key) R/C Button 63 Yellow R/C Button

07 < (Arrow Key / Left Key) R/C Button 71 Green R/C Button

08 Power R/C Button 72 Red R/C Button

09 Mute R/C Button 79 Ratio / Aspect Ratio R/C Button

0B Input R/C Button 91 AD (Audio Description) R/C Button

0E SLEEP R/C Button 9E LIVE MENU R/C Button

0F TV, TV/RAD R/C Button 7A User Guide R/C Button

10 - 19 * Number Key 0 - 9 R/C Button 7C Smart / Home R/C Button

1A Q.View / Flashback R/C Button 7E SIMPLINK R/C Button

Function Note

Code

(Hexa)

Function Note

1E FAV (Favorite Channel) R/C Button 8E ►►(Forward) R/C Button

20 Text (Teletext) R/C Button 8F ◄◄(Rewind) R/C Button

21 T. Opt (Teletext Option) R/C Button AA Info R/C Button

28 Return (BACK) R/C Button AB Program Guide R/C Button

30 AV (Audio / Video) Mode R/C Button B0 ►(Play) R/C Button

39 Caption/Subtitle R/C Button B1 ꕗ (Stop / File List) R/C Button

40 Λ

41

42 My Apps R/C Button BB Soccer R/C Button

43 Menu / Settings R/C Button BD ꔄ (REC) R/C Button

44 OK / Enter R/C Button DC 3D R/C Button

45 Q.Menu R/C Button 99 AutoConfig R/C Button

4C List, - (ATSC Only) R/C Button 9F App / * R/C Button

4D PICTURE R/C Button 9B TV / PC R/C Button

52 SOUND R/C Button

* Key code 4C (0x4C) is available on ATSC/ISDB models which use major/minor channel.

(For South Korea, Japan, North America, Latin America except Colombia models)

(Arrow Key / Cursor Up)

V (Arrow Key / Cursor

Down)

R/C Button B5 RECENT R/C Button

R/C Button BA

ꕘ (Freeze / Slow Play /

Pause)

R/C Button

EXTERNAL CONTROL DEVICE SETUP

USB IN

(TV)

(PC)

3

3

EXTERNAL CONTROL DEVICE SETUP

• Image shown may differ from your TV.

Connect the USB to Serial converter/RS-232C input jack to an external control device (such as a computer
or an A/V control system) to control the product’s functions externally.

Note: The type of control port on the TV can be different between model series.

* Please be advised that not all models support this type of connectivity.

* Cable is not provided.

USB to Serial converter with USB Cable

USB Type

(PC)

• LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter

which is not made nor provided by LG.

• It can be purchased from computer stores that carry accessories for IT support professionals.

USB IN

RS-232C With RS232C Cable

DE9 (D-Sub 9pin) Type

• You need to purchase the RS-232C (DE9, D-Sub 9pin female-to-female type) to RS-232C cable required

for the connection between the PC and the TV, which is specified in the manual.

(TV)

ENGENGLISH

(PC)

The connection interface may differ from your TV.

(CONTROL & SERVICE)

RS-232C IN

(TV)

EXTERNAL CONTROL DEVICE SETUP

USB IN

(TV)

(PC)

(PC)

RS-232C IN

(CONTROL & SERVICE)

(TV)

(PC

USB IN

(TV)

(PC)

(PC)

RS-232C IN

(CONTROL & SERVICE)

(TV)

(TV)

(PC)

(PC

SERVICE ONLY

1

3

2

4

4

ENGLISH

ENG

Phone jack Type

• You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and

the TV, which is specified in the manual.

* For other models, connect to the USB port.

* The connection interface may differ from your TV.

1

3

(TV)

(TV)

- or

)

2

1

3

SERVICE ONLY

)

RS-232C IN

2

(CONTROL & SERVICE)

Customer Computer RS-232C configurations

3-Wire Configurations(Not standard)

1

5

RXD 2 2 TXD

PC TV

TXD 3 1 RXD

GND 5 3 GND

6

RS-232C

(Serial port)

Set ID

For Set ID number, see "Real Data Mapping" on p. 6

1. Press SETTINGS to access the main menus.

2. Press the Navigation buttons to scroll to (*General → About this TV or OPTION) and press OK.

3. Press the Navigation buttons to scroll to SET ID and press OK.

4. Scroll left or right to select a set ID number and select CLOSE. The adjustment range is 1-99.

5. When you are finished, press EXIT.

* (Depending on model)

9

RXD 3 2 TXD

TXD 2 1 RXD

GND 5 3 GND

D-Sub 9 Phone

OR

Communication Parameters

• Baud rate : 9600 bps (UART)

• Data length : 8 bits

• Parity : None

Command reference list

(Depending on model)

EXTERNAL CONTROL DEVICE SETUP

• Stop bit : 1 bit

• Communication code : ASCII code

• Use a crossed (reverse) cable.

5

5

ENGENGLISH

COMMAND1 COMMAND2

01. Power* k a 00 to 01 15. Balance k t 00 to 64

02. Aspect
Ratio

03. Screen
Mute

04. Volume
Mute

05. Volume
Control

06. Contrast k g 00 to 64

07.
Brightness

08. Color/
Colour

09. Tint k j 00 to 64

10.
Sharpness

11. OSD
Select

12. Remote
Control Lock
Mode

13. Treble k r 00 to 64

k c (p. 7)

k d (p. 7)

k e 00 to 01 18. Equalizer j v (p. 8)

k f 00 to 64

k h 00 to 64

k i 00 to 64 22. Key m c Key Codes

k k 00 to 32

k l 00 to 01

k m 00 to 01

DATA

(Hexadecimal)

16. Color
(Colour)
Temperature

17. ISM
Method (Only
Plasma TV)

19. Energy
Saving

20. Tune
Command

21. Channel
(Programme)
Add/Del(Skip)

23. Control
Backlight,
Control Panel
Light

24. Input
select (Main)

25. 3D (Only
3D models)

26. Extended
3D (Only 3D
models)

27. Auto
Configure

COMMAND1 COMMAND2

x u 00 to 64

j p (p. 8)

j q 00 to 05

m a (p. 9)

m b 00 to 01

m g 00 to 64

x b (p. 11)

x t (p. 11)

x v (p. 11)

j u (p. 12)

DATA

(Hexadecimal)

14. Bass k s 00 to 64

* Note: During playing or recording media, all commands except Power (ka) and Key (mc) are not

executed and treated as NG.
With RS232C cable, TV can communicate "ka command" in power-on or power-off status. but with
USB-to-Serial converter cable, the command works only if TV is on.

EXTERNAL CONTROL DEVICE SETUP

6

6

ENGLISH

ENG

Transmission / Receiving Protocol

Transmission

[Command1][Command2][ ][Set ID][ ][Data][Cr]

[Command 1] : First command to control the TV. (j, k, m or x)
[Command 2] : Second command to control the TV.
[Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu.

Adjustment range in TV is 1 to 99. If [Set ID] value is selected to ‘0’, every connected set
can be controlled.

* [Set ID] is indicated as decimal (1 to 99) on menu and as Hexadecimal (0x00 to 0x63) on

transmission/receiving protocol.
[DATA] : To transmit command data (hexadecimal). Transmit ‘FF’ data to read status of command.
[Cr] : Carriage Return - ASCII code ‘0x0D’
[ ] : Space – ASCII code ‘0x20’

OK Acknowledgement

[Command2][ ][Set ID][ ][OK][Data][x]

* The set transmits ACK (acknowledgement) based on this format when receiving normal data. At this time,

if the data is data read mode, it indicates present status data. If the data is data write mode, it returns the
data of the PC computer.

Error Acknowledgement

[Command2][ ][Set ID][ ][NG][Data][x]

* The set transmits ACK (acknowledgement) based on this format when receiving abnormal data from

non-viable functions or communication errors.

Data 00: Illegal Code

Real data mapping (Hexadecimal b Decimal)

* When you enter the [data] in hexadecimal, refer to following conversion table.

* Channel Tune (ma) Command uses two-byte hexadecimal value([data]) to select channel number.

00 : Step 0 32 : Step 50 (Set ID 50) FE : Step 254
01 : Step 1 (Set ID 1) 33 : Step 51 (Set ID 51) FF : Step 255

... ... ...

0A : Step 10 (Set ID 10) 63 : Step 99 (Set ID 99) 01 00 : Step 256

... ... ...

0F : Step 15 (Set ID 15) C7 : Step 199 27 0E : Step 9998
10 : Step 16 (Set ID 16) C8 : Step 200 27 0F : Step 9999

... ... ...

EXTERNAL CONTROL DEVICE SETUP

* Commands may work differently depending on model and signal.

01. Power (Command: k a)

► To control Power *On or Off of the set.

Transmission[k][a][ ][Set ID][ ][Data][Cr]

Data 00 : Power Off 01 : *Power On

Ack [d][ ][Set ID][ ][OK/NG][Data][x]

* In case of video mute on only, TV will display On

Screen Display(OSD). But, in case of Screen mute
on, TV will not display OSD.

7

7

ENGENGLISH

Ack [a][ ][Set ID][ ][OK/NG][Data][x]

► To Show TV is Power On or *Off

Transmission [k][a][ ][Set ID][ ][FF][Cr]

Ack [a][ ][Set ID][ ][OK][Data][x]

* Similarly, if other functions transmit ‘FF’ data

based on this format, Acknowledgement feedback
presents status about each function.

02. Aspect Ratio (Command: k c)
(Main Picture Size)

► To adjust the screen format. (Main picture format)

You can also adjust the screen format using the
Aspect Ratio in the Q.MENU. or PICTURE menu.

Transmission [k][c][ ][Set ID][ ][Data][Cr]

Data 01 : Normal screen

(4:3)

02 : Wide screen

(16:9)
04 : Zoom
05 : Zoom 2
(Latin America

except Colombia
Only)

06 : Set by Program/

Original

Ack [c][ ][Set ID][ ][OK/NG][Data][x]

07 : 14:9
(Europe, Colombia, Mid-East,
Asia except South Korea and
Japan)
09 : * Just Scan
0B : Full Wide
(Europe, Colombia, Mid­East, Asia except South
Korea and Japan)
10 to 1F : Cinema Zoom 1 to 16
0c : 21:9 (Depending on model)

* Using the PC input, you select either 16:9 or 4:3

screen aspect ratio.

* In DTV/HDMI/Component mode (high-definition),

Just Scan is available.

* Full wide mode may work differently based on

model and is supported for DTV fully, and ATV,
AV partially.

04. Volume Mute (Command: k e)

► To control volume mute on/off.

You can also adjust mute using the MUTE button
on remote control.

Transmission [k][e][ ][Set ID][ ][Data][Cr]

Data 00 : Volume mute on (Volume off)
01 : Volume mute off (Volume on)

Ack [e][ ][Set ID][ ][OK/NG][Data][x]

05. Volume Control (Command: k f)

► To adjust volume.

You can also adjust volume with the volume
buttons on remote control.

Transmission [k][f][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [f][ ][Set ID][ ][OK/NG][Data][x]

06. Contrast (Command: k g)

► To adjust screen contrast.

You can also adjust contrast in the PICTURE
menu.

Transmission [k][g][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [g][ ][Set ID][ ][OK/NG][Data][x]

07. Brightness (Command: k h)

► To adjust screen brightness.

You can also adjust brightness in the PICTURE
menu.

Transmission [k][h][ ][Set ID][ ][Data][Cr]

03. Screen Mute (Command: k d)

► To select screen mute on/off.

Transmission [k][d][ ][Set ID][ ][Data][Cr]

Data 00 : Screen mute off (Picture on)

Video mute off
01 : Screen mute on (Picture off)
10 : Video mute on

Data Min : 00 to Max : 64

Ack [h][ ][Set ID][ ][OK/NG][Data][x]

08. Color/Colour (Command: k i)

► To adjust the screen Color(Colour).

You can also adjust colour in the PICTURE menu.

Transmission [k][i][ ][Set ID][ ][Data][Cr]

EXTERNAL CONTROL DEVICE SETUP

8

8

ENGLISH

ENG

Data Min : 00 to Max : 64

Ack [i][ ][Set ID][ ][OK/NG][Data][x]

09. Tint (Command: k j)

► To adjust the screen tint.

You can also adjust tint in the PICTURE menu.

Transmission [k][j][ ][Set ID][ ][Data][Cr]

Data Red : 00 to Green : 64

Ack [j][ ][Set ID][ ][OK/NG][Data][x]

10. Sharpness (Command: k k)

► To adjust the screen sharpness.

You can also adjust sharpness in the PICTURE
menu.

Transmission [k][k][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 32

Ack [k][ ][Set ID][ ][OK/NG][Data][x]

11. OSD Select (Command: k l)

► To select OSD (On Screen Display) on/off when

controlling remotely.

Transmission [k][l][ ][Set ID][ ][Data][Cr]

Data 00 : OSD off 01 : OSD on

* (Depending on model)

14. Bass (Command: k s)

► To adjust Bass.

You can also adjust in the AUDIO menu.

Transmission [k][s][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [s][ ][Set ID][ ][OK/NG][Data][x]

* (Depending on model)

15. Balance (Command: k t)

► To adjust balance.

You can also adjust balance in the AUDIO menu.

Transmission [k][t][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [t][ ][Set ID][ ][OK/NG][Data][x]

16. Color(Colour) Temperature (Command: x u)

► To adjust colour temperature. You can also adjust

Color(Colour) Temperature in the PICTURE menu.

Transmission [x][u][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [u][ ][Set ID][ ][OK/NG][Data][x]

Ack [l][ ][Set ID][ ][OK/NG][Data][x]

12. Remote control lock mode (Command: k m)

► To lock the front panel controls on the monitor and

remote control.

Transmission [k][m][ ][Set ID][ ][Data][Cr]

Data 00 : Lock off 01 : Lock on

Ack [m][ ][Set ID][ ][OK/NG][Data][x]

* If you are not using the remote control, use this

mode.
When main power is off & on (plug-off and plug-in,
after 20 - 30 seconds), external control lock is
released.

* In the standby mode (DC off by off timer or ‘ka’,

‘mc’ command), and if key lock is on, TV will not
turn on by power on key of IR & Local Key.

13. Treble (Command: k r)

► To adjust treble.

You can also adjust in the AUDIO menu.

Transmission [k][r][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [r][ ][Set ID][ ][OK/NG][Data][x]

17. ISM Method (Command: j p) (Only Plasma TV)

► To control the ISM method. You can also adjust

ISM Method in OPTION menu.

Transmission [j][p][ ][Set ID][ ][Data][Cr]

Data Min : 02: Orbiter

08: Normal
20: Color(Colour) Wash

Ack [p][ ][Set ID][ ][OK/NG][Data][x]

18. Equalizer (Command : j v)

► Adjust EQ of the set.

Transmission [j][v][ ][Set ID][ ][Data][Cr]

MSB

0 0 0 0 0 0 0 0

LSB

Frequency Data

7 6 5

0 0 0

0 0 1

0 1 0

0 1 1

Frequency

1st Band

2nd Band

3rd Band

4th Band

4 3 2 1 0 Step

0 0 0 0 0

0 0 0 0 1

... ... ... ... ...

1 0 0 1 1

0(decimal)

1(decimal)

...

19(decimal)

EXTERNAL CONTROL DEVICE SETUP

9

9

1 0 0

Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x]

* It depends on model, and can adjust when sound
mode is EQ adjustable value.

5th Band

1 0 1 0 1

20(decimal)

19. Energy Saving (Command: j q)

► To reduce the power consumption of the TV. You

can also adjust Energy Saving in PICTURE menu.

Transmission [j][q][ ][Set ID][ ][Data][Cr]

Data
00 : Off
01 : Minimum
02 : Medium
03 : Maximum
04 : Auto (For LCD TV / LED TV) /

Intelligent sensor (For PDP TV)

05 : Screen off

* (Depending on model)

Ack [q][ ][Set ID][ ][OK/NG][Data][x]

20. Tune Command (Command: m a)

* This command may work differently depending on

model and signal.

• For Europe, Mid-East, Colombia, Asia except

South Korea and Japan Model

► Select channel to following physical number.

Transmission [m][a][ ][Set ID][ ][Data 00][ ]

[Data 01][ ][Data 02][Cr]

* Analog Antenna/Cable

[Data 00][Data 01] Channel Data
Data 00 : High byte channel data
Data 01 : Low byte channel data

- 00 00 ~ 00 C7 (Decimal : 0 ~ 199)

Data 02 : Input Source (Analog)

- 00 : Antenna TV (ATV)

- 80 : Cable TV (CATV)

* Digital Antenna/Cable/Satellite

[Data 00][Data 01]: Channel Data
Data 00 : High Channel data
Data 01 : Low Channel data

- 00 00 ~ 27 0F (Decimal: 0 ~ 9999)

Data 02 : Input Source (Digital)

- 10 : Antenna TV (DTV)

- 20 : Antenna Radio (Radio)

- 40 : Satellite TV (SDTV)

- 50 : Satellite Radio (S-Radio)

- 90 : Cable TV (CADTV)

- a0 : Cable Radio (CA-Radio)

* Tune Command Examples:

1. Tune to the Analog antenna (PAL) Channel 10.

Set ID = All = 00
Data 00 & 01 = Channel Data is 10 = 00 0a
Data 02 = Analog Antenna TV = 00
Result = ma 00 00 0a 00

2. Tune to the digital antenna (DVB-T) Channel 01.
Set ID = All = 00
Data 00 & 01 = Channel Data is 1 = 00 01
Data 02 = Digital Antenna TV = 10
Result = ma 00 00 01 10

3. Tune to the satellite (DVB-S) Channel 1000.
Set ID = All = 00
Data 00 & 01 = Channel Data is 1000 = 03 E8
Data 02 = Digital Satellite TV = 40
Result = ma 00 03 E8 40

Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]

[Data 02][x][a][ ][Set ID][ ][NG][Data 00][x]

• For South Korea, North/Latin America except

Colombia Model

► To tune channel to following physical/major/minor

number.

Transmission [m][a][ ][0][ ][Data00][ ][Data01]

[ ][Data02][ ][Data03][ ][Data04][ ][Data05][Cr]

Digital channels have a Physical, Major, and Minor
channel number. The Physical number is the actual
digital channel number, the Major is the number that
the channel should be mapped to, and the Minor is
the sub-channel. Since the ATSC tuner automatically
maps the channel from the Major / Minor number,
the Physical number is not required when sending a
command in Digital.

* Analog Antenna/Cable

Data 00 : Physical Channel Number

- Antenna (ATV) : 02~45 (Decimal: 2 ~ 69)

- Cable (CATV) : 01, 0E~7D (Decimal : 1, 14~125)

[Data 01 ~ 04]: Major/Minor Channel Number
Data 01 & 02: xx (Don't care)
Data 03 & 04: xx (Don't care)
Data 05: Input Source (Analog)

- 00 : Antenna TV (ATV)

- 01 : Cable TV (CATV)

* Digital Antenna/Cable

Data 00 : xx (Don't care)

[Data 01][Data 02]: Major Channel Number
Data 01 : High byte Channel Data
Data 02 : Low byte Channel Data

- 00 01 ~ 27 0F (Decimal: 1 ~ 9999)

[Data 03][Data 04]: Minor Channel Number
Data 03 : High byte Channel Data
Data 04 : Low byte Channel Data

Data 05 : Input Source (Digital)

- 02 : Antenna TV (DTV) – Use Physical Channel

Number

- 06 : Cable TV (CADTV) – Use Physical Channel

ENGENGLISH

EXTERNAL CONTROL DEVICE SETUP

10

10

ENGLISH

ENG

Number

- 22 : Antenna TV (DTV) – Don’t Use Physical
Channel Number

- 26 : Cable TV (CADTV) - Don’t Use Physical
Channel Number

- 46 : Cable TV (CADTV) – Use Physical/Major
Channel Number Only (One Part Channel)

- 66 : Cable TV (CADTV) – Use Major Channel
Number Only (One Part Channel)

Two bytes are available for each major and minor
channel data, but usually the low byte is used alone
(high byte is 0).

* Tune Command Examples:

1. Tune to the Analog cable (NTSC) channel 35.

Set ID = All = 00
Data 00 = Channel Data is 35 = 23
Data 01 & 02 = No Major = 00 00
Data 03 & 04 = No Minor = 00 00
Data 05 = Analog Cable TV = 01
Total = ma 00 23 00 00 00 00 01

2. Tune to the digital antenna (ATSC) channel 30-3.

Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 30 = 00 1E
Data 03 & 04 = Minor is 3 = 00 03
Data 05 = Digital Antenna TV = 22
Total = ma 00 00 00 1E 00 03 22

Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]

[Data 02][Data 03][Data 04][Data 05]

[x][a][ ][Set ID][ ][NG][Data 00][x]

• For Japan Model

► To tune channel to following physical/major/minor

number.

Transmission [m][a][ ][0][ ][Data00][ ][Data01]

[ ][Data02][ ][Data03][ ][Data04][ ][Data05][Cr]

Data 05 = Digital Antenna TV = 02
Total = ma 00 00 00 11 00 01 02

2. Tune to the BS (ISDB-BS) channel 30.
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 30 = 00 1E
Data 03 & 04 = Don’t Care = 00 00
Data 05 =
Total = ma 00 00 00 1E 00 00 07

* This feature is varied based on the model.

Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]

[Data 02][Data 03][Data 04][Data 05]

[x][a][ ][Set ID][ ][NG][Data 00][x]

Digital BS TV = 07

21. Channel(Programme) Add/Del(Skip)

(Command: m b)

► To skip current channel(programme) for next time.

Transmission [m][b][ ][Set ID][ ][Data][Cr]

Data 00 : Del(ATSC,ISDB)/Skip(DVB) 01 : Add

Ack [b][ ][Set ID][ ][OK/NG][Data][x]

* Set the saved channel status to del(ATSC, ISDB)/

skip(DVB) or add.

22. Key (Command: m c)

► To send IR remote key code.

Transmission [m][c][ ][Set ID][ ][Data][Cr]

Data Key code - p. 2.

* Digital Antenna/Satellite
Data 00: xx (Don't care)

[Data 01][Data 02]: Major Channel Number
Data 01: High byte Channel Data
Data 02: Low byte Channel Data

- 00 01 ~ 27 0F (Decimal: 1 ~ 9999)

[Data 03][Data 04]: Minor/Branch Channel Number

(Don’t care in Satellite)
Data 03: High byte Channel Data
Data 04: Low byte Channel Data

Data 05 : Input Source (Digital/Satellite for Japan)

- 02 : Antenna TV (DTV)

- 07 : BS (Broadcasting Satellite)

- 08 : CS1 (Communication Satellite 1)

- 09 : CS2 (Communication Satellite 2)

* Tune Command Examples:
1

Tune to the digital antenna (ISDB-T) channel 17-1
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 17 = 00 11
Data 03 & 04 = Minor/Branch is 1 = 00 01

Ack [c][ ][Set ID][ ][OK/NG][Data][x]

23. Control Backlight (Command: m g)

• For LCD TV / LED TV

► To control the backlight.

Transmission [m][g][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

Ack [g][ ][Set ID][ ][OK/NG][Data][x]

Control Panel Light (Command: m g)

• For Plasma TV

► To control the panel light.

Transmission [m][g][ ][Set ID][ ][Data][Cr]

Data Min : 00 to Max : 64

.

Ack [g][ ][Set ID][ ][OK/NG][Data][x]

EXTERNAL CONTROL DEVICE SETUP

11

11

24. Input select (Command: x b)
(Main Picture Input)

► To select input source for main picture.

Transmission [x][b][ ][Set ID][ ][Data][Cr]

Data
00 : DTV
02 : Satellite DTV

ISDB-BS (Japan)
03 : ISDB-CS1 (Japan)
04 : ISDB-CS2 (Japan)
11 : CATV

20 : AV or AV1 21 : AV2

40 : Component1
60 : RGB

90 : HDMI1
92 : HDMI3

Ack [b][ ][Set ID][ ][OK/NG][Data][x]

* This function depends on model and signal.

01 : CADTV
10 : ATV

41 : Component2

91 : HDMI2
93 : HDMI4

25. 3D(Command: x t) (only 3D models)

(Depending on model)

► To change 3D mode for TV.

Transmission [x][t][ ][Set ID][ ][Data 00][ ][Data 01]

[ ][Data 02][ ][Data 03][Cr]

* (Depending on model)

Data Structure
[Data 00] 00 : 3D On

01 : 3D Off
02 : 3D to 2D
03 : 2D to 3D

[Data 01] 00 : Top and Bottom

01 : Side by Side
02 : Check Board
03 : Frame Sequential
04 : Column interleaving
05 : Row interleaving

[Data 02] 00 : Right to Left

01 : Left to Right

[Data 03] 3D Effect(3D Depth): Min : 00 - Max : 14

(*transmit by Hexadecimal code)

* [Data 02], [Data 03] functions depend on model

and signal.

* If [Data 00] is 00 (3D On), [Data 03] has no

meaning.

* If [Data 00] is 01 (3D off) or 02 (3D to 2D), [Data

01], [Data 02] and [Data 03] have no meaning.

* If [Data 00] is 03 (2D to 3D), [Data 01] and

[Data 02] have no meaning.

* If [Data 00] is 00 (3D On) or 03 (2D to 3D), [Data

03] works when 3D Mode (Genre) is manual only.

* All 3D pattern options ([Data 01]) may not be

available according to broadcasting/video signal.

[Data 00] [Data 01] [Data 02] [Data 03]

00 O O O

01 X X X

02 X X X

03 X O O

X : don’t care

Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02]

[Data03][x]

[t][ ][Set ID][ ][NG][Data00][x]

26. Extended 3D(Command: x v) (only 3D models)
(Depending on model)

► To change 3D option for TV.

Transmission [x][v][ ][Set ID][ ][Data 00][ ]

[Data 01][Cr]

[Data 00] 3D option

00 : 3D Picture Correction
01 : 3D Depth (3D Mode is Manual Only)
02 : 3D Viewpoint
06 : 3D Color Correction
07 : 3D Sound Zooming
08 : Normal Image View
09 : 3D Mode (Genre)

[Data 01] It has own range for each 3D option

determined by [Data 00].

1) When [Data 00] is 00

00 : Right to Left
01 : Left to Right

2) When [Data 00] is 01, 02

Data Min: 0 - Max: 14 (*transmit by Hexadecimal

code)
Data value range(0 - 20) converts Viewpoint range
(-10 - +10) automatically (Depending on model)
* This option works when 3D Mode (Genre) is manual

only.

3) When [Data 00] is 06, 07

00 : Off

01 : On

4) When [Data 00] is 08

00 : Revert to 3D video from 3D-to-2D

converted 2D video

01 : Change 3D video to 2D video, except

2D-to-3D video

* If conversion condition doesn’t meet, command is

treated as NG.

5) When [Data 00] is 09

00 : Standard
02 : Cinema
04 : Manual

Ack [v][ ][Set ID][ ][OK][Data00][Data01][x]

[v][ ][Set ID][ ][NG][Data00][x]

01 : Sport
03 : Extreme
05 : Auto

ENGENGLISH

ENGLISH

ENG

EXTERNAL CONTROL DEVICE SETUP

12

12

27. Auto Configure (Command: j u)
(Depending on model)

► To adjust picture position and minimize image

shaking automatically. It works only in RGB (PC)
mode.

Transmission [j][u][ ][Set ID][ ][Data][Cr]

Data 01 : Run Auto Configure

Ack [u][ ][Set ID][ ][OK/NG][Data][x]
