LG 55SE3B-B User guide

OWNER’S MANUAL

LG Digital Signage

(MONITOR SIGNAGE)

Please read this manual carefully before operating your set and retain it

for future reference.

32SE3B 43SE3B 49SE3B 55SE3B 65SE3B

32SE3KB 43SE3KB 49SE3KB 55SE3KB 65SE3KB

43SL5B 49SL5B 55SL5B

www.lg.com

TABLE OF CONTENTS

ENGLISH

TABLE OF CONTENTS

3 LICENSES

4 ASSEMBLY AND PREPARATION

4 Accessories 5 Optional Accessories 7 Parts and Buttons 9 Connecting the Stand 10 Connecting the Speakers 11 Using the IR Receiver 12 Portrait Layout 13 Attaching and removing the LG Logo

Bracket

14 Installing on a Wall

16 REMOTE CONTROL

18 Displaying the Device Name

Connected to an Input Port 18 White Balance Adjust Menu 19 Using Picture ID

20 MAKING CONNECTIONS

20 Connecting to a PC 22 External Device Connection

25 USING THE MONITOR

25 Using the Input List 25 Adjusting Aspect Ratio

27 ENTERTAINMENT

27 Using the Network 27 - Connecting to a Network

29 - Network Status 29 Using the My Media

29 - Connecting USB storage devices 31 - Browsing Files 33 - Viewing Movies 36 - Viewing Photos 38 - Listening to Music 40 - Viewing the Contents List

41 CUSTOMIZING SETTINGS

41 Accessing Main Menus 42 - PICTURE Settings

45 - AUDIO Settings 46 - TIME Settings 47 - OPTION Settings 50 - NETWORK Settings

51 TROUBLESHOOTING

53 PRODUCT SPECIFICATIONS

65 IR CODES

67 TO CONTROL MULTIPLE

PRODUCTS

67 Connecting the Cable 68 RS-232C Configurations 68 - 4P Cable

68 - RS-232C Cable 68 Communication Parameter

69 Command Reference List 71 Transmission / Receiving Protocol

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

This DivX Certified® device has passed rigorous testing to ensure it plays DivX® video.

To play purchased DivX movies, first register your device at registration code in the DivX VOD section of your device setup menu.

DivX Certified® to play DivX® video up to HD 1080p, including premium content.

DivX®, DivX Certified® and associated logos are trademarks of DivX, LLC and are used under license.

Covered by one or more of the following U.S. patents:

7,295,673; 7,460,668; 7,515,710; 7,519,274.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

www.lg.com.

vod.divx.com

ENGLISH

. Find your

ASSEMBLY AND PREPARATION

ENGLISH

ASSEMBLY AND PREPARATION

Accessories

Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.

Remote Control,

Batteries (AAA) 2 EA

CD (Owner’s Manual)/

Cards

Power Cord

RS-232C Gender IR Receiver

D-sub 15-pin Signal

Cable

CAUTION

• Always use genuine components to ensure safety and product performance.

• The product warranty will not cover damage or injury caused by the use of counterfeit components.

NOTE

• The accessories provided with your product may vary depending on the model or region.

• Product specifications or contents in this manual may be changed without prior notice due to upgrade of

product functions.

• SuperSign Software & Manual

- Downloading from the LG Electronics website.

- Visit the LG Electronics website (

for your model.

www.lgecommercial.com/supersign

) and download the latest software

ASSEMBLY AND PREPARATION

Optional Accessories

Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories.

Screws

Length

(including

spring washer)

14 mm 8 EA

Quantity

Stand

ST-322T 32SE3*

ST-432T 43SE3*/43SL5B

ST-492T

ST-652T 65SE3*

49SE3*/55SE3* 49SL5B/55SL5B

Stand

Spacers

32SE3* -

43SE3* 43SL5B

49SE3* 49SL5B

55SE3* 55SL5B

65SE3*

2 EA

Stand kit

Diameter 4.0 mm x Pitch 0.7 mm

Model

32SE3* 10 mm 6 EA

43SE3* 43SL5B

49SE3* 49SL5B

55SE3* 55SL5B

65SE3* 16 mm 8 EA

ENGLISH

Speakers

SP-5000

Cable holder/

Cable Tie

Screws

Diameter 4.0 mm x Pitch

0.7 mm x Length 8 mm (including spring washer)

Screws

Diameter 4.0 mm x Pitch

1.6 mm x Length 10 mm

Speaker kit

(Only for **SE3B/**SL5B model)

NOTE

• Cable holder/cable tie may not be available in some areas or for some models.

• Optional accessories are available for some models. If necessary, please purchase them separately.

ENGLISH

ASSEMBLY AND PREPARATION

Media Player

MP500/ MP700

( It may not be supported depending on the model.)

Screws

Media Player kit

AN-WF500

Wi-Fi Dongle kit

CD (Owner's Manual)/

Cards

NOTE

• Optional accessories are available for some models. If necessary, please purchase them separately.

ASSEMBLY AND PREPARATION

Parts and Buttons

- The image may be different according to the model

32/43/49/55SE3B 32/43/49/55SE3KB

Buttons

43/49/55SL5B

RS-232CIN RS-232C

SPEAKER

OUT

ENGLISH

USB 2

5 V 1.0 A

USB 1

5 V 1.0 A

RGB IN

DVI-D IN LAN

OUT

EXT IR

AUDIO

OUT

(Only for

**SE3B/**SL5B

model)

Buttons Description

INPUT Changes the input source.

MENU Accesses the main menus, or saves your input and exits the menus.

Adjust the up and down.

Moves left and right.

AUTO/SET Displays the current signal and mode.

/ I

Turns the power on or off.

Connection

Panel

ASSEMBLY AND PREPARATION

ENGLISH

65SE3B 65SE3KB

USB 2

USB 1

5 V 1.0 A

RGB IN

DVI-D IN LAN

RS-232CIN RS-232C

SPEAKER

OUT

Buttons

(Only for **SE3B

model)

Buttons Description

INPUT Changes the input source.

MENU Accesses the main menus, or saves your input and exits the menus.

Adjust the up and down.

Moves left and right.

AUTO/SET Displays the current signal and mode.

/ I

Turns the power on or off.

OUT

EXT IR

AUDIO

OUT

Connection

Panel

ASSEMBLY AND PREPARATION

Connecting the Stand

- For certain models only.

- The image may be different according to the model

32SE3*

1 Place a soft cloth on the table and place the

product with the screen facing downward.

2 Use the screws to secure the stand to the back

of the product as shown below.

43/49/55/65SE3* 43/49/55SL5B

1 Place a soft cloth on the table and place the

product with the screen facing downward.

2 Tighten stand spacers on the back of the

product as shown below.

ENGLISH

3 Use the screws to secure the stand to the back

of the product as shown below.

ASSEMBLY AND PREPARATION

Connecting the Speakers

ENGLISH

- For certain models only. (Only for **SE3B/**SL5B model)

- The image may be different according to the

model.

32SE3B

1 Connect an input signal cable before installing

the speakers.

2 Mount the speakers by using screws as

shown below. Make sure the power cable is

disconnected before making a connection.

43/49/55/65SE3B 43/49/55SL5B

1 Connect an input signal cable before installing

the speakers.

2 Mount the speakers by using screws as

shown below. Make sure the power cable is

disconnected before making a connection.

3 Then connect the speaker cable. After installing

your speakers, use holders and cable ties to

organize the speaker cables.

3 Then connect the speaker cable. After installing

your speakers, use holders and cable ties to

organize the speaker cables.

ASSEMBLY AND PREPARATION

NOTE

• Please turn off the power before removing the

cable. Connecting or removing the speaker cable while turned on may result in no sound.

Using the IR Receiver

- The image may be different according to the model.

This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232C cable. Install the IR receiver towards the front of the set.

ENGLISH

IR Receiver cable

NOTE

• When you see from the back of the set, if the

IR receiver cable does not face front, the signal reception range may shorten.

• The IR receiver is made with a magnet.It is

detachable at the bottom (typical installation) or back (wall installation) of the set.

• Make sure that you unplug the power cord

before connecting or removing the IR Receiver.

ASSEMBLY AND PREPARATION

Portrait Layout

ENGLISH

To install in portrait mode, rotate the set counterclockwise 90 degrees when looking at from the front.

Using Kensington Lock

(This is not available for all models.)

The Kensington security system connector is located at the back of the monitor. For more information on installation and use of this system, refer to the manual provided with the Kensington security system or visit

com

Connect the Kensington security system cable between the monitor and a table.

http://www.kensington.

NOTE

• The Kensington security system is optional. You

can obtain additional accessories from most electronics retail stores.

ASSEMBLY AND PREPARATION

Attaching and removing the LG Logo Bracket

- For certain models only.

- The image may be different according to the model.

Removing the LG Logo Attaching the LG Logo on the right side

1 Lay a clean cloth on the floor, and then put the

monitor on it with the screen face down. Using a screwdriver, remove the screw that secures the LG Logo Bracket to the bottom rear of the monitor.

LG Logo Bracket

1 Lay a clean cloth on the floor, and then put the

monitor on it with the screen face down. Using a screwdriver, remove the screw that secures the LG Logo Bracket to the bottom rear of the monitor.

ENGLISH

After removing the screw, remove the LG Logo. When re-attaching the LG Logo, repeat the process in reverse order.

After removing the screw, remove the LG Logo. Attach the LG Logo Bracket with a screw, aligning it with the hole on the right side.

ASSEMBLY AND PREPARATION

Installing on a Wall

ENGLISH

CAUTION

For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

10 cm

To install your monitor on a wall, attach a wall mounting bracket (optional part) to the back of the monitor.

Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.

10 cm

1 Use only screws and wall mounting brackets

that conform to VESA standards.

2 Screws which are longer than standard length

may damage the inside of the monitor.

3 A non-VESA standard screw may damage

the product and cause the monitor to fall. LG

Electronics is not liable for any accidents related

to the use of non-standard screws.

4 Please use VESA standard as below.

• 785 mm and above

* Fixing screws: Diameter 6.0 mm x

Pitch 1.0 mm x Length 12 mm

• Disconnect the power cord before moving or

installing the monitor to avoid risk of electric shock.

• If you install the monitor on a ceiling or slanted

wall, it may fall and result in injury. Use an authorized LG wall mount and contact your local dealer or qualified personnel to assist with the installation.

• Do not over tighten the screws as this may

damage the monitor and void your warranty.

• Use only screws and wall mounting brackets

that meet the VESA standard. Any damage or injuries caused by misuse or use of improper accessories are not covered by the warranty.

• To prevent injury, this apparatus must be

securely attached to the wall in accordance with the installation instructions. (This pertains only to Australia and New Zealand.)

NOTE

• The wall mount kit includes the installation

guide and all necessary parts.

• The wall mounting bracket is optional. You can

obtain additional accessories from your local dealer.

• The length of screws required may differ

depending on the wall mount. Be sure to use the correct length.

• For more information, please refer to the guide

provided with the wall mount.

• The warranty will not cover any damages

caused by using the product in an excessively dusty environment.

785 mm

ASSEMBLY AND PREPARATION

Securing the monitor to a wall (optional)

Procedure may differ depending on the model.

1 Insert and tighten the eyebolts, or brackets and

bolts on the back of the monitor.

- If there are already bolts inserted in the

eyebolts’ position, remove the other bolts first.

2 Mount the wall brackets with the bolts to the

wall. Match the location of the wall bracket and the eyebolts on the rear of the monitor.

3 Connect the eyebolts and wall brackets tightly

with a sturdy cord. Make sure the securing cord is horizontal with the flat surface.

WARNING

• If the monitor is not positioned in a

sufficiently stable location, there is a danger that it will fall. Many injuries, particularly to children, can be avoided by taking simple precautions such as:

»» Using cabinets or stands recommended

by the manufacturer.

»» Only using furniture that can safely

support the monitor.

»» Ensuring the monitor is not overhanging

the edge of the supporting furniture.

»» Not placing the monitor on tall furniture

(for example, cupboards or bookcases) without anchoring both the furniture and the monitor to a suitable support.

»» Not placing cloth or other materials

between the monitor and supporting furniture.

»» Educating children about the dangers

of climbing on furniture to reach the monitor or its controls.

ENGLISH

CAUTION

• Make sure that children do not climb on or

hang from the monitor.

NOTE

• Use a platform or cabinet that is large and

strong enough to support the monitor securely.

• Brackets, bolts, and cords are sold separately.

You can obtain additional accessories from your local retail store.

• The illustration shows a general example of

installation and may look different from the actual product.

REMOTE CONTROL

ENGLISH

REMOTE CONTROL

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly.

To install batteries, open the battery cover, place batteries (1.5 V AAA) matching and terminals to the labels inside the compartment, and close the battery cover.

To remove the batteries, perform the installation actions in reverse. The illustrations may differ from the actual accessories.

CAUTION

• Do not mix old and new batteries, as this may

damage the remote control.

• Be sure to point the remote control toward the

remote control sensor on the monitor.

(POWER) Turns the monitor on or off.

MONITOR ON Turns the monitor on. MONITOR OFF Turns the monitor off. ENERGY SAVING Adjusts the brightness of the picture to reduce energy

INPUT Selects the input mode. 3D Used for viewing 3D videos. (This model does not support this.)

consumption.

1/a/A Toggles between numerical and alphabet ical.

(Depending upon the model, this feature may not be supported.)

Number and Alphabet buttons

Enters numerical or alphabetical characters depending upon the setting. (Depending upon the model, this feature may not be supported.)

CLEAR Deletes the entered numerical or alphabetical character.

(Depending upon the model, this feature may not be supported.)

Volume Up/Down Button Adjusts the volume. ARC Selects the Aspect Ratio mode. AUTO Automatically adjusts picture position and minimizes image

instability (available for RGB input only). (Depending upon the model, this feature may not be supported.)

MUTE Mutes all sounds. BRIGHTNESS Adjust the brightness by pressing the Up and Down

buttons on the remote control. In USB mode, the OSD menu has the Page function to move to the next file list. (Depending upon the model, this feature may not be supported.)

REMOTE CONTROL

PSM Selects the Picture Mode. INFO Views the information of the currently program and the screen. W.BAL Enters the White Balance menu.

SETTINGS Accesses the main menus or saves your input and exit menus. S.MENU SuperSign menu key (Depending upon the model, this feature

may not be supported.)

Navigation Buttons Scrolls through menus or options. OK Selects menus or options and confirms your input. BACK Allows you to move back one step in the user interaction function. EXIT Quit all OSD tasks and applications.

Allows you to control various multimedia devices to enjoy

multimedia simply by using the remote control through the SimpLink menu. (Depending upon the model, this feature

may not be supported.)

TILE Selects the TILE Mode. PICTURE ID ON/OFF When the Picture ID number matches the Set ID

number, you can control whichever monitor you want in multi-display format.

USB Menu Control Buttons Controls media playback.

ENGLISH

REMOTE CONTROL

Displaying the Device Name

ENGLISH

Connected to an Input Port

Display which devices are connected to which external input ports.

1 Access the Input list screen and press the red

(input label) button on the remote control.

2 You can assign an input label for every input

except USB.

NOTE

• External inputs supported : HDMI, DVI-D

• Labels available : PC, DTV

• The input labels are displayed on the Input Label

screen or at the top left of the screen when you change the external input setting.

• For DTV/PC-compatible signals, such as

1080p 60 Hz, the screen settings may change according to the input label. The Just Scan option is available if a PC is connected as an external device.

White Balance Adjust Menu

Press the W.BAL button on the remote control.

R-Gain : Adjusts the level of red. The higher

»y

the number, the redder the set. Decrease the number if the screen looks too red.

G-Gain : Adjusts the level of green. The

»y

higher the number, the greener the set. Decrease the number if the screen looks too green.

B-Gain : Adjusts the level of blue. The higher

»y

the number, the bluer the set. Decrease the number if the screen looks too blue.

Backlight : Adjusts the brightness. The

»y

higher the number, the brighter the set. This works in the same way as the backlight of the user menu.

Reset : Resets the white balance value to

»y

the factory settings.

REMOTE CONTROL

AUDIO

(RGB/DVI)

REMOTE

CONTROL IN

RS-232C OUT

RS-232C IN

RS-232C OUT

RS-232C IN

RS-232C OUT

RS-232C IN

Using Picture ID

Picture ID is used to change the settings of a specific display using a single IR receiver for multi-vision. The set receiving the IR signal communicates with another set via an RS-232C connection. Each set is identified by a Set ID. If you assign the Picture ID using the remote control, only displays with the same Picture ID and Set ID can be controlled remotely.

IR Receiver

RS-232C

Picture ID

Off

2X2 Multi-Vision

Set IDs are assigned as shown in the picture.

NOTE

• For example, if the Picture ID is assigned to

2, the upper right display (Set ID: 2) can be controlled by IR signals.

• For each set, you can change the settings for

the PICTURE, AUDIO, TIME, NETWORK and MY MEDIA menus or the hot keys on the remote control.

• If you press the green OFF button for Picture IDs,

the Picture IDs for all sets are turned off. If you then press any button on the remote control, all sets will start working again.

• Picture ID will be disabled while using the MY

MEDIA menu.

ENGLISH

1 Press the red ON button on the remote control

to assign the Picture ID.

2 To change the Picture ID, press the ON

button, or the left and right arrow buttons continuously. Assign the ID you want.

• If you assign the Set ID to each set with multi-

vision, and then assign the Picture ID using the red button on the remote control, the key command is displayed for the set with the same Set ID and Picture ID. A set with different Set IDs and Picture IDs cannot be controlled by IR signals.

MAKING CONNECTIONS

LAN

USB 1 USB 2

DVI-D IN LAN

USB 1 USB 2

RGB IN

ENGLISH

MAKING CONNECTIONS

You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect.

For more information about external device connections, see the user manual provided with each device.

Connecting to a PC

The illustrations may differ from the actual accessories. Some of the cables are not provided.

This monitor supports the Plug & Play* feature.

* Plug & Play: a feature that enables a PC to recognize devices attached by the user without device configuration or user intervention when powering up.

32/43/49/55SE3*

Mac

43/49/55SL5B

RGB IN

SPEAKER

OUT

(Only for **SE3B/ **SL5B model)

HDMI OUT

AUDIO OUTRGB OUT

(not included)

RS-232CIN RS-232C

OUT

(not included)

EXT IR

(not included)

DVI-D IN

AUDIO

OUT

(not included)

DVI OUTAUDIO OUT

MAKING CONNECTIONS

HDMI OUT

DVI-D IN LAN

USB 1 USB 2

SPEAKER

OUT

RS-232CIN RS-232C

OUT

EXT IR

AUDIO

OUT

AUDIO

DVI OUT

AUDIO OUT

AUDIO OUTRGB OUT

RGB IN

DVI-D IN LAN

USB 1 USB 2

RGB IN

65SE3*

(not included)

Mac

ENGLISH

(not included)

(Only for **SE3B model)

(not included)

MAKING CONNECTIONS

ENGLISH

External Device Connection

Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode.

The illustrations may differ from the actual accessories. Some of the cables are not provided. For the best picture and sound quality, connecting external devices to your monitor using HDMI cables is recommended.

32/43/49/55SE3*

43/49/55SL5B

USB 2

5 V 1.0 A

USB 1

5 V 1.0 A

(not included)

Direct Connection/

Using the Router/

Using the Internet

USB

HD Receiver/DVD/VCR

Camcorder/Camera/Gaming Device

SPEAKER

OUT

RS-232CIN RS-232C

OUT

(Only for **SE3B/ **SL5B model)

(not included)

HDMI OUT

EXT IR

RGB IN

DVI-D IN LAN

AUDIO

OUT

(not included)

Network

AV Receiver

MAKING CONNECTIONS

65SE3*

HDMI OUT

(not included)

ENGLISH

USB 2

5 V 1.0 A

USB 1

5 V 1.0 A

(not included)

USB

(not included)

HD Receiver/DVD/VCR

Camcorder/Camera/Gaming Device

OUT

RS-232CIN RS-232C

SPEAKER

(Only for **SE3B model)

OUT

AV Receiver

EXT IR

RGB IN

DVI-D IN LAN

AUDIO

OUT

(not included)

Network

Direct Connection/

Using the Router/

Using the Internet

MAKING CONNECTIONS

ENGLISH

NOTE

• The monitor set with the HDMI connection for the best image quality.

• To comply with the specifications of the product, use a shielded interface cable with ferrite core, such as a

D-sub 15-pin cable and DVI-D/HDMI cable.

• If you turn the monitor set on when the set becomes cold, the screen may flicker. This is normal.

• Some red, green, or blue spots may appear on the screen. This is normal.

• To minimize the impact of electromagnetic waves, secure the cables with cable ties.

• Use a High Speed HDMI®/™ Cable.

• If you want to use HDMI-PC mode, you must set the input label to PC mode.

• When HDMI PC is used, a compatiblity problem could occur.

• Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may

not display or a connection error may occur.

• Recommended HDMI cable types

-High-Speed HDMI®/™ Cable

-High-Speed HDMI®/™ Cable with Ethernet

• Use the standard Macintosh adapter since an incompatible adapter is available in the

market. (Different signaling system)

• Apple computers may require an adapter to connect to this monitor. Call or visit their

web site for more information.

CAUTION

• Connect the signal input cable and tighten it by turning the screws clockwise.

• Do not press the screen with your finger for a long time as this may result in

temporary distortion on the screen.

• Avoid displaying a fixed image on the screen for a long period of time to prevent

image burn. Use a screensaver if possible.

• If using a DP to HDMI dongle, make sure to use a dongle certified by the graphics card manufacturer.

• When connecting to multi-channel ports of a graphics card, make sure to use DP to HDMI dongles of the

same model.

USING THE MONITOR

Using the Input List

Press INPUT to access the Input List.

Press the navigation buttons to scroll to one of the input mode and press OK.

RGB : View a PC display on the screen.

»y

HDMI : Watch contents in a PC, DVD of digital set-top box other high definition devices.

»y

DVI-D : Displays multimedia contents on your PC, DVD and other HD devices.

»y

USB : Plays the multimedia file saved in the USB.

»y

Adjusting Aspect Ratio

Resize the image to view the image at its optimal size by pressing ARC while you are watching monitor set.

MODE

Aspect Ratio

16:9

Just Scan x o x o x

Set By Program x o x o x

4:3 o o o o o

Zoom x o x o x

Cinema Zoom1 x o x o x

RGB HDMI

PC DTV PC DTV PC

o o o

DVI-D

o o

ENGLISH

NOTE

• You can also change the image size by accessing the main menus.

• The Just Scan mode operates when a video signal has resolution of 720p or higher.

CAUTION

• If a fixed image displays on the screen for a long period of time, it will be imprinted and become a

permanent disfigurement on the screen. This is image burn or burn-in and not covered by the warranty.

• If you don't use your monitor, turn the power off or set a screen saver program from the PC or the system to

prevent image retention.

• If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the

screen.

+ 57 hidden pages
