Page 1

OWNER’S MANUAL

LED TV

* LG LED TV applies LCD screen with LED backlights.

Please read this manual carefully before operating your set and retain it for future reference.

47LA7900 55LA7900

55LA8600 60LA8600

www.lg.comP/NO : MFL67652601 (1301-REV00)

Page 2

IMPORTANT SAFETY INSTRUCTIONS

Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product.

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

WARNING/CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to

alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING/CAUTION

- TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.

Do not use this apparatus near water.

y

Clean only with a dry cloth.

y

Do not block any ventilation openings. Install in

y

accordance with the manufacturer’s instructions.

Do not install near any heat sources such as

y

radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

WARNING

If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.

CAUTION

If you ignore the caution message, you may be slightly injured or the product may be damaged.

NOTE

The note helps you understand and use the product safely. Please read the note carefully before using the product.

WARNING

to the State of California to cause cancer and birth defects or other reproductive harm.

: This product contains chemicals known

:DVKKDQGVDIWHUKDQGOLQJ

Do not defeat the safety purpose of the polarized

y

or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet (Can differ by country).

Do not press strongly upon the panel with a hand or

y

a sharp object such as a nail, pencil or pen, or make a scratch on it.

Page 3

IMPORTANT SAFETY INSTRUCTIONS

Protect the power cord from being walked on

y

or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories specified by the

y

manufacturer.

Use only with a cart, stand, tripod, bracket, or table

y

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Unplug this apparatus during lightning storms or

y

when unused for long periods of time.

CAUTION concerning the Power Cord

y

(Can differ by country): It is recommended that appliances be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not connect too many appliances to the same AC power outlet as this could result in fire or electric shock. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. Do not move the TV with the power cord plugged in. Do not use a damaged or loose power cord. Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV.

ENGLISH

Refer all servicing to qualified service personnel.

y

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Do not stick metal objects or any other conductive

y

material into the power cord. Do not touch the end of the power cord while it is plugged in. Keep the packing anti-moisture material or vinyl

y

packing out of the reach of children. Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.

Warning

y

shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet hands. Do not install this product near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning.

Do not expose to dripping or splashing and do not

y

place objects filled with liquids, such as vases, cups, etc. on or over the apparatus (e.g. on shelves above the unit).

- To reduce the risk of fire or electrical

Page 4

IMPORTANT SAFETY INSTRUCTIONS

ENGLISH

Grounding

y

(Except for devices which are not grounded.) Ensure that you connect the earth ground wire to prevent possible electric shock (i.e. a TV with a three-prong grounded AC plug must be connected to a three-prong grounded AC outlet). If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes.

Short-circuit

Breaker

As long as this unit is connected to the AC wall

y

Power Supply

outlet, it is not disconnected from the AC power source even if the unit is turned off. Do not attempt to modify this product in any way

y

without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product.

Outdoor Antenna Grounding

y

(Can differ by country): If an outdoor antenna is installed, follow the precautions below. An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits as death or serious injury can occur. Be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code (NEC) in the U.S.A. provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements for the grounding electrode.

Antenna grounding according to the National Electrical Code, ANSI/NFPA 70

Cleaning

y

When cleaning, unplug the power cord and wipe gently with a soft cloth to prevent scratching. Do not spray water or other liquids directly on the TV as electric shock may occur. Do not clean with chemicals such as alcohol, thinners or benzine.

Moving

y

Make sure the product is turned off, unplugged and all cables have been removed. It may take 2 or more people to carry larger TVs. Do not press or put stress on the front panel of the TV.

Ventilation

y

Install your TV where there is proper ventilation. Do not install in a confined space such as a bookcase. Do not cover the product with cloth or other materials while plugged. Do not install in excessively dusty places. If you smell smoke or other odors coming from

y

the TV, unplug the power cord and contact an authorized service center. Keep the product away from direct sunlight.

y

Never touch this apparatus or antenna during a

y

thunder or lightning storm. When mounting a TV on the wall, make sure not

y

to install the TV by hanging the power and signal cables on the back of the TV. Do not allow an impact shock or any objects to fall

y

into the product, and do not drop anything onto the screen.

Disconnecting the Main Power

y

The power outlet used with this device must remain easily accessible. Store the accessories (battery, etc.) in a safe

y

location out of the reach of children. This apparatus use batteries. In your community

y

there might be regulations that require you to dispose of these batteries properly due to environmental considerations. Please contact your local authorities for disposal or recycling information. Do not dispose of batteries in a fire.

y

Do not short circuit, disassemble or allow the

y

batteries to overheat.

Ground Clamp

Electric Service

Equipment

Ground Clamp

NEC: National Electrical Code

Antenna Lead in Wire

Antenna Discharge Unit (NEC Section 810-20)

Grounding Conductor (NEC Section 810-21)

Power Service Grounding Electrode System (NEC Art 250, Part H)

Page 5

Dot Defect

y

The Plasma or LCD panel is a high technology product with resolution of two million to six million pixels. In a very few cases, you could see fine dots on the screen while you’re viewing the TV. Those dots are deactivated pixels and do not affect the performance and reliability of the TV.

Generated Sound

y

“Cracking” noise: A cracking noise that occurs when watching or turning off the TV is generated by plastic thermal contraction due to temperature and humidity. This noise is common for products where thermal deformation is required. Electrical circuit humming/panel buzzing: A low level noise is generated from a high-speed switching circuit, which supplies a large amount of current to operate a product. It varies depending on the product. This generated sound does not affect the performance and reliability of the product. Take care not to touch the ventilation openings.

y

When watching the TV for a long period, the ventilation openings may become hot. This does not affect the performance of the product or cause defects in the product. If the TV feels cold to the touch, there may be a

y

small “flicker” when it is turned on. This is normal, there is nothing wrong with TV. Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse effect on the TV’s performance. Avoid touching the LCD screen or holding your finger(s) against it for long periods of time. Doing so may produce some temporary distortion effects on the screen.

Preventing “Image burn” or “Burn-in” on your TV screen

IMPORTANT SAFETY INSTRUCTIONS

For USA and Canada

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and the receiver.

- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

ENGLISH

If a fixed image displays on the TV screen for a long

y

period of time, it will be imprinted and become a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the warranty. If the aspect ratio of the TV is set to 4:3 for a

y

long period of time, image burn may occur on the letterboxed area of the screen. Avoid displaying a fixed image on the TV screen for

y

a long period of time (2 or more hours for LCD, 1 or more hours for the Plasma TV) to prevent image burn.

NOTE TO CABLE/TV INSTALLER

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical.

Page 6

IMPORTANT SAFETY INSTRUCTIONS

Viewing 3D Imaging

ENGLISH

WARNING

Viewing Environment

Viewing Time

y

- When watching 3D content, take 5 - 15 minute breaks every hour. Viewing 3D content for a long period of time may cause headache, dizziness, fatigue or eye strain.

Those that have a photosensitive seizure or chronic illness

Some users may experience a seizure or other

y

abnormal symptoms when they are exposed to a flashing light or particular pattern from 3D content. Do not watch 3D videos if you feel nauseous,

y

are pregnant and/ or have a chronic illness such as epilepsy, cardiac disorder, or blood pressure disease, etc. 3D Content are not recommended for those who

y

suffer from stereo blindness or stereo anomaly. Double images or discomfort in viewing may be experienced. If you have strabismus (cross-eyed), amblyopia

y

(weak eyesight) or astigmatism, you may have trouble sensing depth and easily feel fatigue due to double images. It is advised to take frequent breaks than the average adult. If your eyesight varies between your right and left

y

eye, revise your eyesight prior to watching 3D content.

Symptoms which require discontinuation or refraining from watching 3D content

Do not watch 3D content when you feel fatigue

y

from lack of sleep, overwork or intoxication . When these symptoms are experienced, stop using/

y

watching 3D content and get enough rest until the symptom subsides.

- Consult your doctor when the symptoms persist. Symptoms may include headache, eyeball pain, dizziness, nausea, palpitation, blurriness, discomfort, double image, visual inconvenience or fatigue.

CAUTION

Viewing Environment

Viewing Distance

y

- Maintain a distance of at least twice the screen diagonal length when watching 3D content. If you feel discomfort in viewing 3D content, move further away from the TV.

Viewing Age

Infants / Children

y

- Usage/ Viewing 3D content for children under the age of 5 are prohibited.

- Children under the age of 10 may overreact and become overly excited because their vision is in development (for example: trying to touch the screen or trying to jump into it. Special monitoring and extra attention is required for children watching 3D content.

- Children have greater binocular disparity of 3D presentations than adults because the distance between the eyes is shorter than one of adults. Therefore they will perceive more stereoscopic depth compared to adults for the same 3D image.

Teenagers

y

- Teenagers under the age of 19 may be stimulated to light coming from 3D videos. Advise them not to watch 3D videos for a long time when they are tired.

Elderly

y

- The elderly may perceive less of a 3D effect than the youth. Do not sit closer to the TV than the recommended distance.

Cautions when using the 3D glasses

Make sure to use LG 3D glasses. Otherwise, you

y

may not be able to view 3D videos properly. Only use 3D glasses instead of your normal glasses,

y

sunglasses or protective goggles. Using modified 3D glasses may cause eye strain or

y

image distortion. Do not keep your 3D glasses in extremely high or

y

low temperatures. It will cause deformation. The 3D glasses are fragile and are easy to

y

scratched. Use a soft, clean piece of cloth when wiping the lenses. Do not scratch the lenses of the 3D glasses with sharp objects or clean/wipe them with chemicals.

Page 7

LICENSES / OPEN SOURCE SOFTWARE NOTICE

LICENSES

Supported licenses may differ by model. For more information about licenses, visit ‘www.lg.com’.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified more information and software tools to convert your files into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

“DivX Certified

, DivX Certified® and associated logos are trademarks of Rovi Corporation or its

“DivX subsidiaries and are used under license.”

“Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274”

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

to play DivX® video up to HD 1080p, including premium content.”

device that plays DivX video. Visit divx.com for

device must be registered in order to

ENGLISH

OPEN SOURCE SOFTWARE NOTICE

To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit ‘http://opensource.lge.com’.

In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.

LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to ‘[email protected]’. This offer is valid for three (3) years from the date on which you purchased the product.

Page 8

TABLE OF CONTENTS

2 IMPORTANT SAFETY INSTRUCTIONS

6 Viewing 3D Imaging

7 LICENSES

7 OPEN SOURCE SOFTWARE NOTICE

8 TABLE OF CONTENTS

9 INSTALLATION PROCEDURE

9 ASSEMBLING AND PREPARING

9 Unpacking 12 Optional Extras 13 Parts and Buttons 15 Lifting and moving the TV

ENGLISH

16 Setting up the TV 16 - Attaching the stand 18 - Mounting on a table 20 - Tidying cables 21 - Mounting on a wall

32 MAGIC REMOTE CONTROL

FUNCTIONS

33 Registering Magic Remote Control 33 How to use Magic Remote Control 33 Precautions to Take when Using the Magic

Remote Control

34 WATCHING TV

34 Turning the TV on for the first time

35 USING THE USER GUIDE

36 SPECIFICATIONS

40 EXTERNAL CONTROL DEVICE SETUP

41 MAINTENANCE

41 Cleaning Your TV 41 - Screen, frame, cabinet and stand 41 - Power cord

41 TROUBLESHOOTING

22 MAKING CONNECTIONS

22 Connecting to an antenna or cable 23 Connecting to a HD receiver, DVD Player or

VCR 23 - HDMI Connection 24 - DVI to HDMI Connection 25 - Connecting to a mobile phone 26 - Component Connection 27 - Composite Connection 28 Connecting a PC 28 - HDMI Connection or DVI to HDMI

Connection 30 Connecting to an Audio System 30 - Digital Optical Audio Connection 31 Connecting to a Headphone 31 Connecting a USB Device

NOTE

Image shown may differ from your TV.

y

Your TV’s OSD (On Screen Display) may differ

y

slightly from that shown in this manual. The available menus and options may differ from

y

the input source or product model that you are using. New features may be added to this TV in the

y

future.

Page 9

INSTALLATION PROCEDURE /

INSTALLATION PROCEDURE

Open the package and make sure all the accessories are included.

Attach the stand to the TV set.

Connect an external device to the TV set.

Make sure the network connection is available.

You can use the TV network functions only when the network connection is made.

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and item.

CAUTION

Do not use any unapproved items to ensure the safety and product life span.

y

Any damages or injuries by using unapproved items are not covered by the warranty.

y

Some models appear to have a thin film on the screen. It is actually part of the screen, do not remove it.

y

NOTE

The items supplied with your product may vary depending on the model.

y

Product specifications or contents of this manual may be changed without prior notice due to

y

upgrade of product functions. For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39

y

inches) thick and 18 mm (0.7 inches) width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit

y

into your TV's USB port.

ENGLISH

*A 10 mm (0.39 inches) *B

18 mm (0.7 inches)

Page 10

ASSEMBLING AND PREPARING

For LA7900 series

ENGLISH

Magic Remote Control, Batteries (AA)

(See p. 32)

Cable Holder

(See p. 20)

Stand Base, Stand Body

(See p. 16)

Owner’s Manual Power Cord

Tag On

Tag On Cable Management

2 EA (See p 20)

Cinema 3D Glasses

The number of 3D glasses may differ depending on the model or country.

Stand Screws

8 EA, M4 x 14 (See p. 16)

Component video cable

(See p. 26)

Composite video cable

(See p. 26,27)

Page 11

For LA8600 series

ASSEMBLING AND PREPARING

Magic Remote Control, Batteries (AA)

(See p. 32)

Cable Holder

(See p. 20)

Stand Screws

4EA, M4 x 16 (See p. 17)

Owner’s Manual Power Cord

Tag On

Stand Base

(See p. 17)

Cinema 3D Glasses

The number of 3D glasses may differ depending on the model or country.

(For 60LA8600) (For 60LA8600)

Tag On

Component video cable

(See p.26)

ENGLISH

Composite video cable

(See p. 26,27)

(For 60LA8600)

Bracket Screw

1 EA (See p.19)

Desk-mount Cable

1 EA (See p.19)

Desk-mount Screw

1 EA (See p.19)

Page 12

ASSEMBLING AND PREPARING

Optional Extras

Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer for buying these items. These devices only work with certain models. The model name or design may be changed due to the manufacturer’s circumstances or policies.

ENGLISH

AN-MR400P

Magic Remote Control

AN-VC***

Video Call Camera

&RPSDWLELOLW\

AN-MR400

AG-F***

AG-F**DP

Magic remote control

Cinema 3D glasses

Dual Play Glasses

AG-F***

Cinema 3D Glasses

Tag On

Tag On LG Audio device

/$ /$

AG-F**DP

Dual Play Glasses



AN-VC***

LG Audio device

Video Call Camera



(Built-in)



Page 13

Parts and Buttons

For LA7900 series

Screen

ASSEMBLING AND PREPARING

SETTINGS

INPUT

Remote control and

Intellgent sensors.

Logo light

Button Description

/ (^ / v)

/ (+ / -)

(OK )

(SETTINGS)

(INPUT )

( / I)

1.Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.

Scrolls through the saved channels.

Adjusts the volume level.

Selects the highlighted menu option or confirms an input.

Accesses the main menus, or saves your input and exits the menus.

Changes the input source.

Turns the power on or off.

Buttons

ENGLISH

Page 14

ASSEMBLING AND PREPARING

For LA8600 series

Screen

ENGLISH

Remote control and

Intellgent sensors.

Logo light

Button Description

/ (^ / v)

/ (+ / -)

(OK )

(SETTINGS)

(INPUT )

( / I)

Scrolls through the saved channels.

Adjusts the volume level.

Selects the highlighted menu option or confirms an input.

Accesses the main menus, or saves your input and exits the menus.

Changes the input source.

Turns the power on or off.

SETTINGS

INPUT

Buttons

1.Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.

Page 15

Lifting and moving the TV

When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size.

CAUTION

Avoid touching the screen at all times, as this may

y

result in damage to the screen.

It is recommended to move the TV in the box or

y

packing material that the TV originally came in. Before moving or lifting the TV, disconnect the

y

power cord and all cables. When holding the TV, the screen should face away

y

from you to avoid damage.

Hold the top and bottom of the TV frame firmly.

y

Make sure not to hold the transparent part, speaker, or speaker grill area.

ASSEMBLING AND PREPARING

When transporting a large TV, there should be at

y

least 2 people. When transporting the TV by hand, hold the TV as

y

shown in the following illustration.

When transporting the TV, do not expose the TV to

y

jolts or excessive vibration. When transporting the TV, keep the TV upright,

y

never turn the TV on its side or tilt towards the left or right.

ENGLISH

Page 16

ASSEMBLING AND PREPARING

Setting up the TV

Put your TV on a pedestal stand and mount the TV on a table or wall.

Attaching the stand

If you are not mounting the TV to a wall, use the following instructions to attach the stand.

CAUTION

When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat surface to

y

protect the screen from scratches. Make sure that the screws are fastened tightly. (If they are not fastened securely enough, the TV may tilt forward

y

after being installed.) Do not tighten the screws with too much force; otherwise they may be damaged and come loose later.

y

NOTE

Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.

y

For LA7900 series

ENGLISH

M4 x 14

4 EA

Stand body

Front

Stand base

M4 x 14

4 EA

Page 17

For LA8600 series

ASSEMBLING AND PREPARING

Wrapping bag (Depending on model)

Stand Base

M4 x 16

2 EA

M4 x 16

2 EA

ENGLISH

Page 18

ASSEMBLING AND PREPARING

Mounting on a table

ENGLISH

Lift and tilt the TV into its upright position on a table.

- Leave a

10 cm (4 inch) (minimum)

space from

the wall for proper ventilation.

10 cm

(

10 cm

Connect the power cord to a wall outlet.

CAUTION

Do not place the TV near or on sources of heat, as

y

this may result in fire or other damage.

Adjusting the angle of the TV to suit view

Swivel 15 degrees to the left or right and adjust the angle of the TV to suit your view. (For 47/55LA7900)

15˚15˚

Swivel 8 degrees to the left or right and adjust the angle of the TV to suit your view. (For 55/60LA8600)

8˚8˚

NOTE

When adjusting the angle of the TV, watch out for

y

your fingers.

Personal injury may occur if hands or fingers are



pinched. If the product is tilted too much, it may fall, causing damage or injury.

Rear

Front

Page 19

ASSEMBLING AND PREPARING

Securing the TV to a table

(For 60LA8600)

Connect the Desk-mount Cables to the Stand Base

using the Bracket Screws.

Fix the Desk-mount Cables to a table using the Desk-

mount Screws.

Once the TV is fixed, move the table close to the

wall. Children may go in, causing injuries.

Method A

Securing the TV to a wall (optional)

(Depending on model)

Insert and tighten the eye-bolts, or TV brackets and

bolts on the back of the TV.

- If there are bolts inserted at the eye-bolts position, remove the bolts first.

ENGLISH

P4 x 10 P4 x 20

Desk-mount Cable

Method B

WARNING

To prevent TV from falling over, the TV should be

y

securely attached to the floor/wall per installation instructions. Tipping, shaking, or rocking the TV may cause injury.

Mount the wall brackets with the bolts to the wall.

Match the location of the wall bracket and the eyebolts on the rear of the TV.

Connect the eye-bolts and wall brackets tightly with

a sturdy rope. Make sure to keep the rope horizontal with the flat surface.

CAUTION

Make sure that children do not climb on or hang on

y

the TV.

NOTE

Use a platform or cabinet that is strong and large

y

enough to support the TV securely. Brackets, bolts and ropes are optional. You can

y

obtain additional accessories from your local dealer.

Page 20

ASSEMBLING AND PREPARING

Tidying cables

(For LA7900)

Gather and bind the cables with the cable

management.

Gather and bind the cables with the cable holder on

the back of the TV.

Cable Holder

ENGLISH

(For LA8600)

Cable Management

Gather and bind the cables with the cable

management.

Gather and bind the cables with the cable holder on

the back of the TV.

Cable Holder

CAUTION

Do not move the TV by holding the cable holder

y

and cable management, as the cable holders may break, and injuries and damage to the TV may occur.

Page 21

ASSEMBLING AND PREPARING

Mounting on a wall

An optional wall mount can be used with your LG Television. Consult with your local dealer for a wall mount that supports the VESA standard used by your TV model. Carefully attach the wall mount bracket at the rear of the TV. Install the wall mount bracket on a solid wall perpendicular to the floor. If you are attaching the TV to other building materials, please contact qualified personnel to install the wall mount. Detailed instructions will be included with the wall mount. We recommend that you use an LG brand wall mount.

10 cm

)

10 cm

CAUTION

Disconnect the power before moving or installing

y

the TV. Otherwise electric shock may occur. If you install the TV on a ceiling or slanted wall, it

y

may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may cause

y

damage to the TV and void your warranty. Use the screws and wall mounts that meet the

y

VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty.

NOTE

Use the screws that are listed in the VESA

y

standard screw specifications. The wall mount kit includes an installation manual

y

and necessary parts. The wall mount bracket is optional. You can obtain

y

additional accessories from your local dealer. The length of screws may differ depending on the

y

wall mount. Make sure to use the proper length. For more information, refer to the manual supplied

y

with the wall mount.

ENGLISH

Make sure to use screws and wall mounts that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table.

Model 47LA7900

55LA7900 55LA8600 60LA8600

VESA (A x B)

400 x 400

Standard screw M6

Number of screws 4

Wall mount

LSW430B

bracket (optional)

Page 22

MAKING CONNECTIONS

This section uses illustrations of the LA8600 series.

y

You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device.

NOTE

If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable to the

y

TV through a DVD recorder or VCR. For more information of recording, refer to the manual provided with the connected device. The external device connections shown may differ slightly from illustrations in this manual.

y

Connect external devices to the TV regardless of the order of the TV port.

y

If you connect a gaming device to the TV, use the cable supplied with the gaming device.

y

Refer to the external equipment’s manual for operating instructions.

y

Connecting to an antenna or cable

Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may differ from the actual items and a RF cable is optional.

ENGLISH

(*Not Provided)

Coaxial (75Ω)

CAUTION

Make sure not to bend the copper wire of the RF

y

cable.

Copper wire

Complete all connections between devices, and

y

then connect the power cord to the power outlet to prevent damage to your TV.

VHF Antenna

UHF Antenna

Antenna

Terminal

NOTE

Use a signal splitter to use more than 2 TVs.

y

Visit ‘http://lgknowledgebase.com’ for more

y

information about the antenna and cable connection. Search for antenna. DTV Audio Supported Codec: MPEG, Dolby Digital,

y

DTS

Page 23

MAKING CONNECTIONS

Connecting to a HD receiver, DVD Player or VCR

Connect a HD receiver, DVD Player or VCR to the TV and select an appropriate input mode.

HDMI Connection

HDMI is the best way to connect a device.

Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration.

NOTE

Use the latest High Speed HDMI™ Cable that supports CEC (Customer Electronics Control) function.

y

High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.

y

HDMI Audio Supported Format: Dolby Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/88k/96k/176k/192k),

y

DTS supported.

Choose any HDMI input port to connect. It does not matter which port you use.

HDMI

(*Not Provided)

DVD / Blu-Ray / HD Cable Box / HD STB

ARC (Audio Return Channel)

When connected with a high-speed HDMI cable,

y

digital audio can be sent to a compactible device without an additional optical audio cable. ARC is only supported on the HDMI input 1 (ARC)

y

port. An external audio device that supports ARC should be connected to HDMI 1 if you wish to use ARC

ENGLISH

Page 24

MAKING CONNECTIONS

DVI to HDMI Connection

Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable.

Choose any HDMI/DVI input port to connect. It does not matter which port you use.

(*Not Provided)

ENGLISH

YELLOW

DVI OUT

(*Not Provided)

AUDIO OUT

DVD / Blu-Ray / HD Cable Box

Page 25

MAKING CONNECTIONS

Connecting to a mobile phone

Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile phones to television sets.

NOTE

Connect the mobile phone to the HDMI IN 3 (MHL) port to view the phone screen on the TV.

y

This only works for the MHL-enabled phone.

y

With some MHL supporting mobile phones, you can use the TV remote to control the phone.

y

An MHL passive cable is needed to connect the TV and a mobile phone.

y

Remove the MHL cable from the TV when

y

- the MHL function is disabled

- your mobile device is fully charged in standby mode

MHL Cable

(MHL)

(*Not Provided)

Mobile phone

ENGLISH

Page 26

MAKING CONNECTIONS

Component Connection

Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown in the following illustration.

NOTE

If cables are installed incorrectly, it could cause the image to display in black and white or with distorted color.

y

Check to ensure the cables are matched with the corresponding color connection.

y

COMPONENT

VIDEO AUDIOYPBP

ENGLISH

RED

GREEN

BLUE

RED

YELLOW

(Use the composite video cable provided.) (Use the component video cable provided.)

YELLOW

WHITE

AUDIO

DVD / Blu-Ray / HD Cable Box

VIDEO

Page 27

MAKING CONNECTIONS

Composite Connection

Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration.

NOTE

Check to ensure the cables are matched with the corresponding color connection.

y

COMPONENT

VIDEO AUDIOYPBP

YELLOW

(Use the composite video cable provided.)

YELLOW

YELLOW YELLOW

WHITE

ENGLISH

RED

VIDEO

( )

MONO

AUDIOLR

VCR / DVD / Blu-Ray / HD Cable Box

Page 28

MAKING CONNECTIONS

Connecting a PC

NOTE

It is recommended to use an HDMI connection for the best image quality.

y

Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use.

y

In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. If noise

y

is present, change the PC output to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear. The synchronization input form for Horizontal and Vertical frequencies is separate.

y

Depending on the graphics card, some resolution settings may not allow the image to be positioned on the screen

y

properly.

HDMI Connection or DVI to HDMI Connection

Choose method A or B to make connection.

Method A: HDMI Connection

Choose any HDMI input port to connect. It does not matter which port you use.

ENGLISH

HDMI

(*Not Provided)

Page 29

Method B: DVI to HDMI Connection

Choose any HDMI/DVI input port to connect. It does not matter which port you use.

MAKING CONNECTIONS

(*Not Provided)

YELLOW

(*Not Provided)

AUDIO OUT

ENGLISH

DVI OUT

Page 30

MAKING CONNECTIONS

Connecting to an Audio System

You may use an optional external audio system instead of the built-in speaker.

Digital Optical Audio Connection

Transmits a digital audio signal from the TV to an external device. Connect the external device and the TV with the optical audio cable as shown in the following illustration.

NOTE

Do not look into the optical output port. Looking at the laser beam may damage your vision.

y

Audio with ACP (Audio Copy Protection) function may block digital audio output.

y

ENGLISH

(*Not Provided)

OPTICAL AUDIO IN

Digital Audio System

Page 31

MAKING CONNECTIONS

Connecting to a Headphone

Listen to the sound through a headphone.

NOTE

AUDIO menu options are disabled when connecting a headphone.

y

When changing AV MODE with a headphone connected, the change is applied to video but not to audio.

y

Optical Digital Audio Out is not available when connecting a headphone.

y

Headphone impedance: 16

y

Max audio output: 10 mW to 15 mW

y

Headphone jack size: 0.35 cm (0.13 inches)

y

Connecting a USB Device

Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card reader to the TV and access the Smart Share menu to use various multimedia files.

NOTE

Some USB Hubs may not work. If a USB device connected using a USB Hub is not detected, connect it to the

y

USB port on the TV directly.

Choose any USB input port to connect. It does not matter which port you use.

(*Not Provided)

(1A) 3

(1.2A) 1

USB

USB HUB

ENGLISH

(*Not Provided)

HDD

Page 32

MAGIC REMOTE CONTROL FUNCTIONS

When the message “Magic remote control battery is low. Change the battery.” is displayed, replace the battery. To install batteries, open the battery cover, replace batteries (1.5 V AA) matching and the remote control at the remote control sensor on the TV. To remove the batteries, perform the installation actions in reverse.

This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote sensor.

ENGLISH

MAGIC REMOTE CONTROL FUNCTIONS

ends to the label inside the compartment, and close the battery cover. Be sure to point

CAUTION

Do not mix old and new batteries, as this may damage the remote control.

y

(POWER)

Turns the TV on or off.

Returns to the previous level.



Voice recognition

-This is a beta version and only available in selected functions for supported

-Network connection is required to use the voice recognition function.

1. Press the Voice recognition button.

2. Speak slowly and precisely.

When a voice is recognized, the

processing message appears on the



further than 10 cm from your face.

BACK

models.

screen.

VOL

Pointer (RF transmitter)

SMART

Accesses the Smart Home.

Wheel(OK)

Selects menus or options and confirms your input. Scrolls through the saved programmes. If you press the navigation button while moving the pointer on the screen, the pointer disappears, and the Magic Remote Control works as a regular remote control. To display the pointer again, shake the Magic Remote Control from side to side.

Adjusts the volume level.

+ VOL -

Used for viewing 3D video.

MUTE

Mutes all sounds.

Navigation buttons (up/down/left/right)

Scrolls through menus or options.

ᰜCHᰝ

Scrolls through the saved programmes or channels.

/Q.MENU

Accesses the quick menus. Accesses the Universal Control

Page 33

MAGIC REMOTE CONTROL FUNCTIONS

Registering Magic Remote Control

The Magic Remote Control operates by pairing with your TV. Once you purchased the TV, please register the Magic remote control as follows;

How to register the Magic Remote Control

To register automatically, turn the TV on and

press the is completed, the completion message appears on the screen.

(Wheel)

If registration fails, turn the TV off and back

on, then press the complete registration.

How to Re-register the Magic Remote Control

1 Press and hold the

SMART

BACK

SMART

to reset, then register it by following “How to register the Magic remote control” above.

2 To re-register the Magic remote control,

press and hold the seconds toward the TV.

Wheel (OK)

buttons together for 5 seconds

. When registration

Wheel (OK)

BACK

and

button for 5

132

If you press control, the screen above opens.

It shows information about the current program and screen.

Pressing this button will display number

keypad which you can select channel number.

You can select My Apps Menu.

Wheel (OK)

on the Magic remote

Precautions to Take when Using the Magic Remote Control

ENGLISH

How to use Magic Remote Control

1 You can move the pointer by moving the

remote up and down or left and right.

If the pointer does not work properly,



wait 10 seconds and then try again.

2 If the pointer disappears, move the remote

control slightly to left or right. It will then automatically appear on the screen.

If the pointer has not been used for a



certain period of time, it will disappear.

Use the Magic remote control within the maximum

y

communication distance (10 m, 32.8ft). Using the remote control beyond this distance, or with an object obstructing it, may cause a communication failure. A communication failure may occur due to nearby devices.

y

Electrical devices such as a microwave oven or wireless LAN product may cause interference, as these use the same bandwidth (2.4 GHz) as the Magic remote control. The Magic remote control may be damaged or may

y

malfunction if it is dropped or receives a heavy impact. Take care not to bump into nearby furniture or other

y

people when using the Magic remote control. Manufacturer and installer cannot provide service related

y

to human safety as the applicable wireless device has possibility of electric wave interference. It is recommended that an Access Point (AP) be located

y

more than 1 m (3.28 ft) away from the TV. If the AP is installed closer than 1 m (3.28 ft), the Magic remote control may not perform as expected due to frequency interference.

Page 34

WATCHING TV

Turning the TV on for the first time

When you turn the TV on for the first time, the Initial setting screen appears. Select a language and customize the basic settings.

ENGLISH

Connect the power cord to a power outlet.

In Standby mode, press the power button on the

remote control to turn the TV on. The Initial setting screen appears if you turn the TV on for the first time.

NOTE

You can also access

y

OPTION

Follow the on-screen instructions to customize your

in the main menu.

TV settings according to your preferences.

Language Selection*

Initial Setting

by accessing

Selects a language to display.

Enviroment Selection

Select home environment.

Home

* for the

Time Zone Setting

Network Connection

Select TV watching Type

Selects the time zone and daylight saving. (Depending on country)

Sets your network to enable network-related features on the TV.

Set the TV and set-top box for each watching type.

Auto Tuning

Scans and saves available channels automatically.

NOTE

Select

y

puts the TV in demo mode. If you select

y

settings will switch back to the default settings of

Store

The Standby light feature is disabled in Store

y

Demo mode.

When the basic settings are complete,

press the OK button.

* when prompted.

Home

Store

* in 5 minutes.

* mode

Store

*, the any customized

NOTE

If you do not complete the Initial setting, it will

y

appear whenever the TV turns on. Disconnect the power cord from the power outlet

y

when you do not use the TV for a long period of time.

To turn the TV off, press the power button on the

remote control.

Using camera and

microphone

Setting is completed.

Experience Magic

Remote Control

Confirms the setting options.

Simple guide of Magic Remote Control (Depending on model)

Page 35

USING THE USER GUIDE

User Guide allows you to easily access detailed TV information.

Press

SMART

button to access the Smart Home

menus.

Select

User Guid

and press the

Wheel (OK)

button.

User Guide

OPTION > To set language

SMART Ö Settings ¨ OPTION ¨ Language

Selects Menu Language and Audio Language displayed on the screen.

Selects a screen menu language.

Language

[In Digital Mode Only]

Audio

When watching a digital broadcast containing several audio

Language

languages, you can select the language you want.

[In Digital mode Only] Use the Subtitle function when two or more subtitle

Subtitle

languages are broadcast.

Language

If subtitle data in a selected language is not broadcast,

the default language subtitle will be displayed.

Shows the description of the selected menu. You

can use

Moves to the selected menu directly from the

User Guide.

/ to move between pages.

Try Now

ENGLISH

To use input device

To set time options

PROGRAMME Setting

PICTURE, SOUND Setting

OPTION

LG SMART Function

Advanced Function

Information

To set TV lock options

To set language

To set caption

To set other options

Index

2 3

4 5

(Depending on country)

Shows the video you were watching.

Guide categories.

List of topics in the current category. You can use

pages.

An index of key words present in the User Guide.

Provides the detailed information on the functions of LG Smart TV when the Internet is connected.

(It may not be available depending on the country/ language.)

/ button to move between

ONLINE USER GUIDE

Page 36

SPECIFICATIONS

Product specifications may be changed without prior notice due to upgrade of product functions.

Power requirement AC100 - 240 V ~ 50/60 Hz

Television System NTSC-M, ATSC, 64 & 256 QAM

Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135

External Antenna Impedance

Environment condition

Operating Temperature 0 - 40 °C

Operating Humidity Less than 80 %

Storage Temperature -20 - 60 °C

Storage Humidity Less than 85 %

ENGLISH

MODELS

Dimensions (Width x Height x Depth)

Weight

Current Value / Power consumption

Dimensions (Width x Height x Depth)

Weight

Current Value / Power consumption

With stand

Without stand

With stand 18.5 Kg (40.7 Ibs)

Without stand 16.8 Kg (37.0 Ibs)

MODELS

With stand

Without stand

With stand 25.3 Kg (55.7 Ibs)

Without stand 23 Kg (50.7 Ibs)

47LA7900

(47LA7900-UA)

1077 x 690 x 285 (mm)

42.4 x 27.2 x 11.2 (inch)

1077 x 612.0 x 34.1 (mm)

42.4 x 24.0 x 1.3 (inch)

1.3 A / 130 W

55LA7900

(55LA7900-UA)

1247 x 788 x 326 (mm)

49.0 x 31.0 x 12.8 (inch)

1247 x 709 x 34.1 (mm)

49.0 x 27.9 x 1.3 (inch)

1.5 A / 150 W

Page 37

SPECIFICATIONS

MODELS

Dimensions (Width x Height x Depth)

Weight

Current Value / Power consumption

Dimensions (Width x Height x Depth)

Weight

Current Value / Power consumption

With stand

Without stand

With stand 26.2 Kg (57.7 Ibs)

Without stand 23.4 Kg (51.5 Ibs)

MODELS

With stand

Without stand

With stand 30.5 Kg (67.2 Ibs)

Without stand 27.7 Kg (61.0 Ibs)

55LA8600

(55LA8600-UC)

1229 x 790 x 316 (mm)

48.3 x 31.1 x 12.4 (inch)

1229 x 721 x 36.0 (mm)

48.3 x 28.3 x 1.4 (inch)

1.5 A / 150 W

60LA8600

(60LA8600-UC)

1337 x 850 x 316 (mm)

52.6 x 33.4 x 12.4 (inch)

1337 x 769 x 34.1 (mm)

52.6 x 30.2 x 1.3 (inch)

1.7 A / 170 W

ENGLISH

Page 38

SPECIFICATIONS

ENGLISH

HDMI (DTV) supported mode

Resolution

720x480p

1280x720p

1920x1080i

1920x1080p

Horizontal

Frequency (kHz)

31.47 59.94

31.5 60.00

44.96 59.94

45.00 60.00

33.72 59.94

33.75 60.00

26.97 23.976

27.000 24.000

33.71 29.97

33.75 30.000

67.432 59.939

67.500 60

HDMI/DVI-PC supported mode

Resolution

640 x 350 31.468 70.09

720 x 400 31.469 70.08

640 x 480 31.469 59.94

800 x 600 37.879 60.31

1024 x 768 48.363 60.00

1152 x 864 54.348 60.053

1280 x 1024 63.981 60.020

1360 x 768 47.712 60.015

1920 x 1080 67.5 60

Horizontal

Frequency

(kHz)

Vertical

Frequency (Hz)

Vertical

Frequency

(Hz)

Wireless LAN module (WN8122E1) specification

6WDQGDUG

)UHTXHQF\5DQJH

2XWSXW3RZHU 7\SLFDO

Because band channel used by the country could

y

be different, the user can not change or adjust the operating frequency and this product is set for the regional frequency table. Contains FCC ID: BEJWN8122E1 / Contains IC:

y

2703H-WN8122E1

IEEE802.11a/b/g/n

2400 to 2483.5 MHz 5150 to 5250 MHz 5725 to 5850 MHz

802.11a: 16.5 dBm

802.11b: 16 dBm

802.11g: 15.5 dBm

802.11n - 2.4GHz: 15.5 dBm

802.11n - 5GHz: 16.5 dBm

Bluetooth module (BM-LDS401) specification

6WDQGDUG

)UHTXHQF\5DQJH

2XWSXW3RZHU0D[

Contains FCC ID: BEJLDS401 / Contains IC:

y

2703H-LDS401

Bluetooth Version 3.0

2400 ~ 2483.5 MHz

10 dBm or lower

Component port connecting information

Component ports on the

Video output ports

on DVD player

Y B-Y R-Y

YCbCr

YPbPr

Page 39

SPECIFICATIONS

3D supported formats

Video, which is input as below media contents is switched into the 3D screen automatically.

y

3D supported formats automatically

Input Signal

640 x 480

480p

720p

HDMI

1080i

1080p

USB

DLNA

1080p 33.75 30.000 1080p 33.75 30.000

Horizontal

Frequency

(kHz)

31.469 59.94

31.50 60.00

62.938 59.94

63.00 60.00

31.469 59.94

31.50 60.00

62.938 59.94

63.00 60.00

44.96 59.94

45.00 60.00

89.91 59.94

90.00 60.00

33.72 59.94

33.75 60.00

67.432 59.94

67.50 60.00

26.97 23.97

27.00 24.000

33.716 29.976

33.75 30.00

43.94 23.97

54.00 24.000

67.432 29.976

67.50 30.00

67.43 59.94

67.50 60.00

Vertical

Frequency

(Hz)

Playable 3D video format
