OWNER’S MANUAL

Safety and Reference

LED TV* * LG LED TV applies LCD screen with LED backlights.

Please read this manual carefully before operating your TV and retain it for future reference.

65SK9500PUA 55SK9500PUA 65SK9550PUA 65SK9000PUA 55SK9000PUA 65SK8550PUA 55SK8550PUA 75SK8070PUA 75SK8050PUA 75SK8070AUB 65SK8000AUB 55SK8000AUB 65SK8000PUA

*MFL70340102*

55SK8000PUA 49SK8000PUA 65SK8050PUA 55SK8050PUA 49SK8050PUA 65UK7700AUB 65UK7700PUD 55UK7700AUB 55UK7700PUD 49UK7700AUB 49UK7700PUD 65UK7500PUA 55UK7500PUA

(1807-REV04)

49UK7500PUA 86UK6570PUB 75UK6570PUB 75UK6570PUA 86UK6570AUA 75UK6570AUA 70UK6570PUB 70UK6550PUA 70UK6570AUB 65UK6500AUA 55UK6500AUA 50UK6500AUA 43UK6500AUA

65UK6550PUB 55UK6550PUB 50UK6550PUB 43UK6550PUB 65UK6300PUE 55UK6300PUE 50UK6300PUE 49UK6300PUE 43UK6300PUE 65UK6300BUB 65UK6350PUC 55UK6300BUB 55UK6350PUC

50UK6300BUB 49UK6300BUB 49UK6350PUC 43UK6300BUB 75UK6270PUB 65UK6200PUA 43UK6350PUC 60UK6200PUA 60UK6250PUB 55UK6200PUA 55UK6250PUB 49UK6200PUA 49UK6250PUB

43UK6200PUA 43UK6250PUB 32LK610BPUA 49LK5750PUA 43LK5750PUA 86UK6570PUA 32LK610BBUA 49LK5700PUA 49LK5700BUA 43LK5700PUA 43LK5700BUA 50UK6350PUC 75UK6190PUB

www.lg.com

Printed in Korea

70UK6190PUB 65UK6090PUA 60UK6090PUA 55UK6090PUA 50UK6090PUA 49UK6090PUA 43UK6090PUA 86UK7570PUB

Important Safety Instruction

• Read these instructions.

ENGLISH

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories specied by the manufacturer.

• Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

By using this product, you agree that all disputes between you and LG arising out of or relating in any way to this product (including but not limited to warranty disputes) shall be resolved exclusively through binding arbitration on an individual basis. The terms of the arbitration agreement (including details on the procedure for resolving disputes) is available at www.lg.com/us/arbitration (USA) or www.lg.ca/arbitration (Canada).

2

Warning! Safety Instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.

The symbol is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s

enclosure that may be of sucient magnitude to constitute a risk of electric shock to persons.

The symbol is intended to alert the user to the presence of important operating and maintenance (servicing)

instructions in the literature accompanying the device.

WARNING : TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

• TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER ITEMS WITH OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.

• Do not place the TV and/or remote control in the following

environments:

- Keep the product away from direct sunlight.

- An area with high humidity such as a bathroom

- Near any heat source such as stoves and other devices that

produce heat.

- Near kitchen counters or humidiers where they can easily be

exposed to steam or oil.

- An area exposed to rain or wind.

- Do not expose to dripping or splashing and do not place objects

lled with liquids, such as vases, cups, etc. on or over the apparatus (e.g., on shelves above the unit).

- Near ammable objects such as gasoline or candles, or expose

the TV to direct air conditioning.

- Do not install in excessively dusty places.

Otherwise, this may result in re, electric shock, combustion/ explosion, malfunction or product deformation.

• Ventilation

- Install your TV where there is proper ventilation. Do not install in

a conned space such as a bookcase.

- Do not install the product on a carpet or cushion.

- Do not block or cover the product with cloth or other materials

while unit is plugged in.

• Take care not to touch the ventilation openings. When watching the TV for a long period, the ventilation openings may become hot.

• Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.

• Do not move the TV whilst the Power cord is plugged in.

• Do not use a damaged or loosely tting power cord.

• Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV.

• Do not connect too many devices to the same AC power outlet as this could result in re or electric shock.

• Disconnecting the Device from the Main Power

- The power plug is the disconnecting device. In case of an

emergency, the power plug must remain readily accessible.

• Do not let your children climb or cling onto the TV. Otherwise, the TV may fall over, which may cause serious injury.

• Outdoor Antenna Grounding (Can dier by country):

- If an outdoor antenna is installed, follow the precautions below.

An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits as death or serious injury can occur. Be sure the antenna system is grounded to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code (NEC) in the U.S.A. provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements for the grounding electrode. Antenna grounding according to the National Electrical Code, ANSI/NFPA 70

ENGLISH

3

• Grounding (Except for devices which are not grounded.)

- TV with a three-prong grounded AC plug must be connected to

a three-prong grounded AC outlet. Ensure that you connect the

ENGLISH

earth ground wire to prevent possible electric shock.

• Never touch this apparatus or antenna during a lightning storm. You may be electrocuted.

• Make sure the power cord is connected securely to the TV and wall socket if not secured damage to the Plug and socket may occur and in extreme cases a re may break out.

• Do not insert metallic or inammable objects into the product. If a foreign object is dropped into the product, unplug the power cord and contact the customer service.

• Do not touch the end of the power cord while it is plugged in. You may be electrocuted.

• If any of the following occur, unplug the product

immediately and contact your local customer service.

- The product has been damaged.

- If water or another substance enters the product (like an AC

adapter, power cord, or TV).

- If you smell smoke or other odors coming from the TV

- When lightning storms or when unused for long periods of time.

Even the TV is turned o by remote control or button, AC power source is connected to the unit if not unplugged in.

• Do not use high voltage electrical equipment near the TV (e.g., a bug zapper). This may result in product malfunction.

• Do not attempt to modify this product in any way without written authorization from LG Electronics. Accidental re or electric shock can occur. Contact your local customer service for service or repair. Unauthorized modication could void the user’s authority to operate this product.

• Use only an authorized attachments / accessories approved by LG Electronics. Otherwise, this may result in re, electric shock, malfunction, or product damage.

• Never disassemble the AC adapter or power cord. This may result in re or electric shock.

• Handle the adapter carefully to avoid dropping or striking it. An impact could damage the adapter.

• To reduce the risk of re or electrical shock, do not touch the TV with wet hands. If the power cord prongs are wet or covered with dust, dry the power plug completely or wipe dust o.

• Batteries

- Store the accessories (battery, etc.) in a safe location out of the

reach of children.

- Do not short circuit, disassemble, or allow the batteries to

overheat. Do not dispose of batteries in a re. Batteries should not be exposed to excessive heat.

• Moving

- When moving, make sure the product is turned o, unplugged,

and all cables have been removed. It may take 2 or more people to carry larger TVs. Do not press or put stress on the front panel of the TV. Otherwise, this may result in product damage, re hazard or injury.

• Keep the packing anti-moisture material or vinyl packing out of the reach of children.

• Do not allow an impact shock, any objects to fall into the product, and do not drop anything onto the screen.

• Do not press strongly upon the panel with a hand or a sharp object such as a nail, pencil, or pen, or make a scratch on it. It may causedamage to screen.

• Cleaning

- When cleaning, unplug the power cord and wipe gently with a

soft/dry cloth. Do not spray water or other liquids directly on the TV. Do not clean your TV with chemicals including glass cleaner, any type of air freshener, insecticide, lubricants, wax (car, industrial), abrasive, thinner, benzene, alcohol etc., which can damage the product and/or its panel. Otherwise, this may result in electric shock or product damage.

4

Preparing

A

<

A

B

Optional Extras

• When the TV is turned on for the rst time after being shipped from the factory, initialization of the TV may take approximately one minute.

• Image shown may dier from your TV.

• Your TV’s OSD (On Screen Display) may dier slightly from that shown in this manual.

• The available menus and options may dier from the input source or product model that you are using.

• New features may be added to this TV in the future.

• The device must be easily accessed to a location outlet near the access. Some devices are not made by turning on / o button, turning o the device and unplugging the power cord.

• The items supplied with your product may vary depending upon the model.

• Product specications or contents of this manual may be changed without prior notice due to upgrade of product functions.

• For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39 inches) thick and 18 mm (0.7 inches) width.

• Use an extension cable that supports USB 2.0 if the USB cable or USB ash drive does not t into your TV’s USB port.

• Use a certied cable with the HDMI logo attached. If you do not use a certied HDMI cable, the screen may not display or a connection error may occur.

• Recommended HDMI cable types (3 m (9.84 feet) or less)

- High-Speed HDMI®/™ cable

- High-Speed HDMI®/™ cable with Ethernet

B

• How to use the ferrite core, (Depending upon model).

- Use the ferrite core to reduce the electromagnetic interference in

the power cord. Wind the power cord on the ferrite core once.

[Wall side]

10 cm (+ / -2 cm)

B

*A < 10 mm (0.39 inches)

18 mm (0.7 inches)

*B

[TV side]

Optional extras can be changed or modied for quality improvement without any notication. Contact your dealer for buying these items. These devices work only with certain models.

The model name or design may be changed due to the manufacturer’s circumstances or policies.

Magic Remote Control

(Depending upon model)

AN-MR18BA

Check whether your TV model supports Bluetooth in the Wireless Module Specication to verify whether it can be used with the Magic Remote.

Wall Mounting Bracket

(Depending upon model)

Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table.

49SK80* 49UK77* 49UK75*

Model

VESA (A x B) (mm)

Standard screw M6 M6

Number of screws 4 4

Wall mount bracket (optional)

43/50UK65* 43/50UK63* 43UK62* 32LK61* 43LK57* 43/50UK60*

200 x 200 300 x 300

LSW240B MSW240

55SK80* 55UK77* 55UK75* 55UK65* 49/55UK63* 49/55UK62* 49LK57* 49/55UK60*

OLW480B MSW240

ENGLISH

5

55/65SK95* 55/65SK90* 55/65SK85*

ENGLISH

Model

VESA (A x B) (mm)

Standard screw M6 M8

Number of screws 4 4 Wall mount bracket

(optional)

65SK80* 65UK77* 65UK75* 65UK65* 65UK63* 60/65UK62* 60/65UK60*

300 x 300 600 x 400

OLW480B LSW640B

Lifting and moving the TV

When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size.

• It is recommended to move the TV in the box or packing material that the TV originally came in.

• Before moving or lifting the TV, disconnect the power cord and all cables.

• When holding the TV, the screen should face away from you to avoid damage.

75SK80* 70/75/86UK65* 75UK62* 70/75UK61* 86UK75*

• Use at least two people to move a large TV.

• When transporting the TV by hand, hold the TV as shown in the following illustration.

• When transporting the TV, do not expose the TV to jolts or excessive vibration.

• When transporting the TV, keep the TV upright; never turn the TV on its side or tilt towards the left or right.

• When handling the TV, be careful not to damage the protruding buttons.

• Avoid touching the screen at all times, as this may result in damage to the screen.

• Do not place the product on the oor with its front facing down without padding. Failure to do so may result in damage to the screen.

• Do not move the TV by holding the cable holders, as the cable holders may break, and injuries and damage to the TV may occur, (Depending upon model).

• When attaching the stand to the TV set, place the screen facing down on a cushioned table or at surface to protect the screen from scratches.

Mounting on the Table

1 Lift and tilt the TV into its upright position on a table.

• Leave a minimum of 10 cm (4 inches) space from the wall for proper ventilation.

• Hold the top and bottom of the TV frame rmly. Make sure not to hold the transparent part, speaker, or speaker grille area.

6

10 cm (4 inches)

10 cm

(Depending upon model)

2 Connect the power cord to a wall outlet.

10 cm

• Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product. (Doing so may damage the product.)

• If you install the TV on a stand, you need to take actions to prevent the product from overturning. Otherwise, the product may fall over, which may cause injury.

• Do not use any unapproved items to ensure the safety and product life span.

• Any damage or injuries caused by using unapproved items are not covered by the warranty.

• Make sure that the screws are fastened tightly. (If they are not fastened securely enough, the TV may tilt forward after being installed.)

• Do not fasten the screws with excessive force otherwise they may strip and become loose.

Securing TV to the Wall

Mounting to the Wall

An optional wall mount can be used with your LG Television. Consult with your local dealer for a wall mount that supports the VESA standard used by your TV model. Carefully attach the wall mount bracket at the rear of the TV. Install the wall mount bracket on a solid wall perpendicular to the oor. If you are attaching the TV to other building materials, please contact qualied personnel to install the wall mount. Detailed instructions will be included with the wall mount. We recommend that you use an LG brand wall mount. The LG wall mount is easy to adjust or to connect the cables. When you do not use LG’s wall mount bracket, use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices. If you are using a non-adjustable mount, attach the mount to the wall. Attach the cables to the TV rst, then attach the TV to the mount.

10 cm (4 inches)

10 cm

ENGLISH

(Depending upon model)

1 Insert and tighten the eye-bolts, or TV brackets and bolts on the back

of the TV.

• If there are bolts inserted at the eye-bolts position, remove the bolts rst.

2 Mount the wall brackets with the bolts to the wall.

Match the location of the wall bracket and the eye-bolts on the rear of the TV.

3 Connect the eye-bolts and wall brackets tightly with a sturdy rope.

Make sure to keep the rope horizontal with the at surface.

• Use a platform or cabinet that is strong and large enough to support the TV securely.

• Brackets, bolts and ropes are not provided. You can obtain additional accessories from your local dealer.

(Depending upon model)

• Remove the stand before installing the TV on a wall mount by performing the stand attachment in reverse.

• For more information of screws and wall mount bracket, refer to the Separate purchase.

• If you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the back of the product. When you install the set to use the wall mounting bracket (optional parts), x it carefully so as not to drop.

• When mounting a TV on the wall, make sure not to install the TV by hanging the power and signal cables on the back of the TV.

• Do not install this product on a wall if it could be exposed to oil or oil mist. This may damage the product and cause it to fall.

7

Connections

ENGLISH

• Do not use a sharp object when you detached the cable cover. This could damage the cable or the cabinet. It may also cause personal harm, (Depending upon model).

• When installing the wall mounting bracket, it is recommended to cover the stand hole using tape, in order to prevent the inux of dust and insects, (Depending upon model).

Stand hole

You can connect various external devices to the TV. For more information on external device’s connection, refer to the manual provided with each device.

Antenna/Cable

Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may dier from the actual items and an RF cable is optional.

• Make sure not to bend the copper wire of the RF cable.

Copper wire

• Complete all connections between devices, and then connect the power cord to the power outlet to prevent damage to your TV.

• Use a signal splitter to use 2 TVs or more.

• DTV Audio Supported Codec: MPEG, Dolby Digital

• This TV cannot receive ULTRA HD (3840 x 2160 pixels) broadcasts directly because the related standards have not been conrmed, (Depending upon model).

Other connections

Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable.

HDMI

• HDMI Audio Supported Format: (Depending upon model) DTS (44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz), DTS HD (44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz / 176.4 kHz / 192 kHz), True HD (48 kHz), Dolby Digital / Dolby Digital Plus (32 kHz / 44.1 kHz / 48 kHz), PCM (32 kHz / 44.1 kHz / 48 kHz / 96 kHz / 192 kHz)

8

(Only UHD models)

• ( ) Picture Additional Settings

HDMI ULTRA HD Deep Color

- On : Support 4K @ 60 Hz (4:4:4, 4:2:2, 4:2:0)

- O : Support 4K @ 60 Hz 8 bit (4:2:0)

If the device connected to Input Port also supports ULTRA HD Deep Color, your picture may be clearer. However, if the device doesn’t support it, it may not work properly. In that case, change the TV’s HDMI ULTRA HD Deep Color setting to o.

- This feature is available only on certain models which support

HDMI ULTRA HD Deep Color.

External Devices

Supported external devices are: Blu-ray player, HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device.

• If you record a TV program on a Blu-ray/DVD recorder or VCR, make sure to connect the TV signal input cable to the TV through a DVD recorder or VCR. For more information about recording, refer to the manual provided with the connected device.

• The external device connections shown may dier slightly from illustrations in a manual.

• Connect external devices to the TV regardless about the order of the TV port.

• If you connect a gaming device to the TV, use the cable supplied with the gaming device.

• Refer to the external equipment’s manual for operating instructions.

• In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. If noise is present, change the PC output to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear. Depending upon the graphics card, some resolution settings may not allow the image to be positioned on the screen properly.

• Some USB Hubs may not work. If a USB device connected through a USB Hub is not detected, connect it directly to the USB port on the TV.

• When connecting via a wired LAN, it is recommended to use a CAT 7 cable.

• The TV may be capable of operating without a set-top-box from a multichannel video programming distributor (MVPD).

• For LK series, HDR (High Dynamic Range) pictures can be viewed over the Internet or via USB and HDMI 1.4 compatible devices.

Remote RS-232C setup

To obtain the RS-232C external control setup information, please visit www.lg.com. Download and read the manual, (Depending upon model).

• Do not drop the product or let it fall over when connecting external devices. Otherwise, this may result in injury or damage to the product.

• When connecting external devices such as video game consoles, make sure the connecting cables are long enough. Otherwise, the product may fall over, which may cause injury or damage the product.

Using Button

You can simply operate the TV functions, using the button.

Basic functions

Power On (Press) Power O 1 (Press and Hold) Menu Control (Press 2) Menu Selection (Press and Hold 3)

1 All running apps will close. 2 You can access and adjust the menu by pressing the button when

TV is on.

3 You can use the function when you access menu control.

Adjusting the menu

When the TV is turned on, press the button one time. You can adjust the Menu items using the button.

Turns the power o.

Changes the input source.

ENGLISH

Scrolls through the saved channels.

Adjusts the volume level.

9

Using Remote Control

* To use the button, press and hold for more than 3 seconds.

(Depending upon model)

ENGLISH

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly.

To install batteries, open the battery cover, replace batteries (1.5 V AAA) matching the and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote sensor.

Make sure to point the remote control toward the remote control sensor on the TV.

1 2

(POWER) Turns the TV on or o.

Returns to the last TV channel.

Activates or deactivates the subtitles.

(Q. Settings) Accesses the Quick Settings.

(Search) Shows the search mode.

(Input) Changes the input source.

Number button Enters numbers.

(Dash) Inserts a dash between numbers such as 2-1 and 2-2.

Accesses the saved channel list.

Alternates between the two last channels selected (pressing

repeatedly).

using the number buttons as registered.

Adjusts the volume level.

(MUTE) Mutes all sounds. * (MUTE) Accesses the Accessibility menu.

1, 2

Streaming Service.

screen. Navigation button (up / down / left / right) Scrolls through menus or options.

(Depending upon model).

(Depending upon model) , , , , Control buttons for media contents

menus.

* You can access the application or Live TV channel by

Accesses your favorite channel list.

Shows information on the current program.

Scrolls through the saved channels.

Moves to the previous or next screen.

Streaming Service buttons Connects to the Video

(Home) Accesses the Home menu. * (Home) Shows the previous history.

Displays the program event according to time scheduler.

By zooming in on the selected area, you can view it in full

Selects menus or options and conrms your input.

Returns to the previous screen.

Clears all on-screen displays and returns to TV viewing.

Enables SAP (Secondary Audio Program) Feature,

Starts to record. (Only Time Machine

, , , These access special functions in some

Ready

supported model)

(Some buttons and services may not be provided depending upon models or regions.)

10

Using Magic Remote Control

* To use the button, press and hold for more than 3 seconds.

(Depending upon model)

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly.

When the message “Magic remote battery is low. Please change the battery.” is displayed, replace the batteries.

To install batteries, open the battery cover, replace batteries (1.5 V AA) matching the and ends to the label inside the compartment, and close the battery cover. Be sure to point the magic remote toward the remote control sensor on the TV. To remove the batteries, perform the installation actions in reverse. This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote sensor.

1 2

(Some buttons and services may not be provided depending upon models or regions.)

(POWER) Turns the TV on or o.

You can turn your set-top box on or o by adding the set-

top box to the universal remote control for your TV.

Number buttons Enters numbers.

- (Dash) Inserts a dash between numbers such as 2-1 and 2-2. Accesses the saved channel list.

(Screen Remote) Displays the Screen Remote.

- Accesses the Universal Control Menu in some regions.

* (Screen Remote) SAP (Secondary Audio Program) Feature can

be enabled by pressing the key.

using the number buttons as registered.

* (Voice recognition)

Network connection is required to use the voice recognition function.

Once the voice display bar is activated on the TV screen, press and hold the button and speak your command out loud.

menu. You can change channels by using the Wheel button.

button to scroll the menu. If you press buttons while the pointer is in use, the pointer will disappear from the screen and Magic Remote will operate like a general remote control. To display the pointer on the screen again, shake Magic Remote to the left and right.

1, 2

Streaming Service.

, Control buttons for media contents

full screen.

pointed.

* You can access the application or Live TV channel by

Adjusts the volume level.

(MUTE) Mutes all sounds.

* (MUTE) Accesses the Accessibility menu.

Scrolls through the saved channels.

(HOME) Accesses the Home menu. * (HOME) Shows the previous history. Wheel (OK) Press the center of the Wheel button to select a

(up/down/left/right) Press the up, down, left or right

Returns to the previous level. * Clears on-screen displays and returns to last input viewing.

Displays the program event according to time scheduler.

Streaming Service buttons Connects to the Video

(INPUT) Changes the input source.

* (INPUT) Displays all the lists of external inputs. (Q. Settings) Accesses the Quick Settings. * (Q. Settings) Displays the All Settings menu.

, , , These access special functions in some menus.

By zooming in on the selected area, you can view it in

* You can zoom in on the area where the remote control is

ENGLISH

11

Registering Magic Remote Control

How to register the Magic Remote Control

To use the Magic Remote, rst pair it with your TV.

ENGLISH

1 Put batteries into the Magic Remote and turn the TV on. 2 Point the Magic Remote at your TV and press the Wheel (OK) on

the remote control.

* If the TV fails to register the Magic Remote, try again after turning

the TV off and back on.

How to deregister the Magic Remote Control

Press the and (HOME) buttons at the same time, for ve seconds, to unpair the Magic Remote with your TV.

* Pressing and holding the button will let you cancel and re-

register Magic Remote at the same time.

• Do not mix new batteries with old batteries. This may cause the batteries to overheat and leak.

• Failure to match the correct polarities of the battery may cause the battery to burst or leak, resulting in re, personal injury, or ambient pollution.

• This apparatus uses batteries. In your community there might be regulations that require you to dispose of these batteries properly due to environmental considerations. Please contact your local authorities for disposal or recycling information.

• Batteries inside or inside the product shall not be exposed to excessive heat such as sunshine, re or the like.

Troubleshooting

Cannot control the TV with the remote control.

• Check if anything such as tape has been placed over the receiver.

• Check if there is any obstacle between the product and the remote control.

• Replace the batteries with new fresh ones.

No image display and no sound is produced.

• Check if the product is turned on.

• Check if the power cord is connected to a wall outlet.

• Check if there is a problem in the wall outlet by connecting other products.

The TV turns o suddenly.

• Check the power control settings. The power supply may be interrupted.

• Check if the auto-o function is activated in the settings menu.

• If there is no signal while the TV is on, the TV will turn o automatically after 15 minutes of inactivity.

Abnormal Display

• If the TV feels cold to the touch, there may be a small icker when it is turned on. This is normal; there is nothing wrong with TV. Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse eect on the TV’s performance. Avoid touching the LCD screen or holding your nger(s) against it for long periods of time. Doing so may produce some temporary distortion eects on the screen.

• This panel is an advanced product that contains millions of pixels. In a very few cases, you could see ne dots on the screen while you’re viewing the TV. Those dots are deactivated pixels and do not aect the performance and reliability of the TV.

• Displaying a still image for a prolonged period of time may cause an image sticking. Avoid displaying a xed image on the TV screen for a extended length of time.

12
