LG 5000 User Manual

LLGG55000000
LLGG55000000
MMaannuuaall ddeell uussuuaarriioo
User Guide
MMBB0178001
(
H
UUsseerr GGuuiiddee
LLGG55000000
Important Safety Precautions
Warning
Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.
Violation of the instructions may cause serious injury or death.
Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.
Never place your phone in a microwave oven as it will cause the battery to explode.
Do not dispose of your battery by fire or with hazardous or flammable materials.
Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. There is a risk of this causing a fire.
Store the battery out of reach of children.
Be careful that children do not swallow any parts such as rubber plugs (earphone, connection parts of the phone, etc.). This could cause asphyxiation or suffocation.
Unplug the power cord and charger during lightning storms to avoid electric shock or fire.
LG5000 1
Important Safety Precautions
When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is activated, you may be seriously injured.
Do not use a hand-held phone while driving.
Do not use the phone in areas where its use is prohibited. (For example: aircraft)
Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.
Never store your phone in temperatures less than -4°F or greater than 122°F.
Do not use harsh chemicals(such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. There is a risk of this causing a fire.
Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit boards of the phone.
Do not use your phone in high explosive areas as the phone may generate sparks.
Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.
2 LG5000
Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause fire or electric shock.
Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.
Do not disassemble the phone.
Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.
Only use the batteries, antennas, and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.
Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.
Do not hold or let the antenna come in contact with your body during a call.
An emergency call can be made only within a service area. For an emergency call, make sure that you are within a service area and that the phone is turned on.
LG5000 3
Contents
Important Safety Precautions . . . . .1
Contents . . . . . . . . . . . . . . . . . . . . . . . . .4
Welcome . . . . . . . . . . . . . . . . . . . . . . . . .7
Check Accessories . . . . . . . . . . . . . . . .7
Important Information . . . . . . . . . . . . . .7
FCC RF Exposure Information . . . . . . .9
Phone Overview . . . . . . . . . . . . . . . . .10
Menus Overview . . . . . . . . . . . . . . . . .11
Getting Started with Your Phone . .13
The Battery . . . . . . . . . . . . . . . . . . . . . .13
Turning the Phone On and Off . . . . .14
Screen Icons . . . . . . . . . . . . . . . . . . . . .15
Making Calls . . . . . . . . . . . . . . . . . . . . .16
Receiving Calls . . . . . . . . . . . . . . . . . . .16
Quick Access to Convenient
Features . . . . . . . . . . . . . . . . . . . . . . . . .17
Manner Mode . . . . . . . . . . . . . . . . . . . .17
Lock Mode . . . . . . . . . . . . . . . . . . . . . . .17
Mute Function . . . . . . . . . . . . . . . . . . .17
Volume Quick Adjustment . . . . . . . . .17
Call Waiting . . . . . . . . . . . . . . . . . . . . . .18
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . .18
Speed Dialing . . . . . . . . . . . . . . . . . . .18
Voice Command Dialing . . . . . . . . . . .18
4 LG5000
Entering and Editing Information . .19
Text Input . . . . . . . . . . . . . . . . . . . . . . . .19
Text Input Examples . . . . . . . . . . . . . .20
Contacts in Your Phone’s
Memory . . . . . . . . . . . . . . . . . . . . . . . . .22
Options to Customize Your
Contacts . . . . . . . . . . . . . . . . . . . . . . . . .23
Adding or Changing the Group . . . . .23
Changing the Call Ringer . . . . . . . . . .23
Changing the Message Ringer . . . . .24
Adding or Changing the Memo . . . . .24
Adding or Changing the Picture ID . .24
Changing the Secret Setting . . . . . . .25
Adding Speed Dial . . . . . . . . . . . . . . .25
Deleting a Speed Dial . . . . . . . . . . . . .25
Editing Contacts Entries . . . . . . . . . . .26
Adding Another Phone Number . . . .26
Default Numbers . . . . . . . . . . . . . . . .26
Editing Stored Phone Numbers . . . .27
Editing Stored Names . . . . . . . . . . . .27
Deleting . . . . . . . . . . . . . . . . . . . . . . . . .28
Deleting a Phone Number from a
Contact . . . . . . . . . . . . . . . . . . . . . . . .28
Deleting a Contact Entry . . . . . . . . . .28
Additional Ways to Delete a Contact 28
Phone Numbers With Pauses . . . . .28
Searching Your Phone’s Memory . .29 Making a Call From Your Phone’s
Memory . . . . . . . . . . . . . . . . . . . . . . . . .31
From Contacts . . . . . . . . . . . . . . . . . .31
From Recent Calls . . . . . . . . . . . . . . .31
Single Digit Speed Dialing . . . . . . . . .31
Double Digit Speed Dialing . . . . . . . .31
Voice Command Dialing . . . . . . . . . . .32
Prepending a Stored Number . . . . . .32
Using Phone Menus . . . . . . . . . . . . .33
Menu Access . . . . . . . . . . . . . . . . . . .33
Camera . . . . . . . . . . . . . . . . . . . . . . . .33
1. Take Photo . . . . . . . . . . . . . . . . . . . .34
2. Take Video . . . . . . . . . . . . . . . . . . . .34
3. Photo Gallery . . . . . . . . . . . . . . . . . .34
4. Video Gallery . . . . . . . . . . . . . . . . . .35
5. Photo Place . . . . . . . . . . . . . . . . . . .35
Contacts . . . . . . . . . . . . . . . . . . . . . . .35
1. List Contacts . . . . . . . . . . . . . . . . . . .36
2. New Number . . . . . . . . . . . . . . . . . .36
3. New E-mail . . . . . . . . . . . . . . . . . . . .36
4. Groups . . . . . . . . . . . . . . . . . . . . . . . .37
5. Speed Dials . . . . . . . . . . . . . . . . . . . .37
6. My Contact Info . . . . . . . . . . . . . . .37
Recent Calls . . . . . . . . . . . . . . . . . . . .38
1. Dialed Calls . . . . . . . . . . . . . . . . . . .38
2. Received Calls . . . . . . . . . . . . . . . . .39
3. Missed Calls . . . . . . . . . . . . . . . . . .39
4. Erase Calls . . . . . . . . . . . . . . . . . . . .39
5. Call Timer . . . . . . . . . . . . . . . . . . . . .39
6. KB Counter . . . . . . . . . . . . . . . . . . . .39
Messages . . . . . . . . . . . . . . . . . . . . . .40
1. Voice Mail . . . . . . . . . . . . . . . . . . . . .41
2. New Text Msg . . . . . . . . . . . . . . . . .41
3. New Photo Msg . . . . . . . . . . . . . . .44
4. Inbox . . . . . . . . . . . . . . . . . . . . . . . . .44
5. Outbox . . . . . . . . . . . . . . . . . . . . . . .45
6. Saved . . . . . . . . . . . . . . . . . . . . . . . .46
7. Msg Settings . . . . . . . . . . . . . . . . . . .46
7.1 Auto Save . . . . . . . . . . . . . . . . . .46
7.2 Auto Erase . . . . . . . . . . . . . . . . . .47
7.3 Text-Auto View . . . . . . . . . . . . . .47
7.4 Photo-Auto Receive . . . . . . . . . .47
7.5 Text-Callback # . . . . . . . . . . . . . .47
7.6 Voice Mail # . . . . . . . . . . . . . . . . .47
7.7 Entry Mode . . . . . . . . . . . . . . . . .47
7.8 Quick-Text . . . . . . . . . . . . . . . . . .47
7.9 Text-Auto Play . . . . . . . . . . . . . . .47
7.0 Text-Signature . . . . . . . . . . . . . .47
8. Erase All . . . . . . . . . . . . . . . . . . . . . .48
Brew Apps . . . . . . . . . . . . . . . . . . . . .48
1. Brew Apps . . . . . . . . . . . . . . . . . . . .49
2. Get Information . . . . . . . . . . . . . . . .49
Mobile Web . . . . . . . . . . . . . . . . . . . .50
1. Start Browser . . . . . . . . . . . . . . . . . .51
2. Web Messages . . . . . . . . . . . . . . . .53
3. Web Alerts . . . . . . . . . . . . . . . . . . . .53
Media . . . . . . . . . . . . . . . . . . . . . . . . .54
1. Images . . . . . . . . . . . . . . . . . . . . . . . .54
2. Sounds . . . . . . . . . . . . . . . . . . . . . . . .54
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . .55
1. Voice Commands . . . . . . . . . . . . . .55
2. Schedule . . . . . . . . . . . . . . . . . . . . . .56
3. Alarm Clock . . . . . . . . . . . . . . . . . . .57
4. Voice Memo . . . . . . . . . . . . . . . . . . .57
5. Notepad . . . . . . . . . . . . . . . . . . . . . .58
6. EZ Tip Calc . . . . . . . . . . . . . . . . . . . .58
7. Calculator . . . . . . . . . . . . . . . . . . . . .58
8. World Clock . . . . . . . . . . . . . . . . . . .58
Settings . . . . . . . . . . . . . . . . . . . . . . . .59
1. Sounds . . . . . . . . . . . . . . . . . . . . . . .59
1.1 Ringers . . . . . . . . . . . . . . . . . . . . .59
1.2 Volume . . . . . . . . . . . . . . . . . . . . .59
1.3 Message Alerts . . . . . . . . . . . . .60
1.4 Service Alerts . . . . . . . . . . . . . . .60
1.5 Power On/Off Tone . . . . . . . . . . .61
2. Display . . . . . . . . . . . . . . . . . . . . . . . .61
2.1 Banner . . . . . . . . . . . . . . . . . . . . .61
2.2 Backlight . . . . . . . . . . . . . . . . . . .61
2.3 Screens . . . . . . . . . . . . . . . . . . . . .62
2.4 Menu Style . . . . . . . . . . . . . . . . . .62
2.5 Clocks . . . . . . . . . . . . . . . . . . . . . .62
2.6 Theme Colors . . . . . . . . . . . . . . .62
2.7 Contrast . . . . . . . . . . . . . . . . . . . .63
2.8 Fonts . . . . . . . . . . . . . . . . . . . . . .63
2.9 Language . . . . . . . . . . . . . . . . . . .63
3. System . . . . . . . . . . . . . . . . . . . . . . . .64
3.1 Select System . . . . . . . . . . . . . . .64
3.2 Set NAM . . . . . . . . . . . . . . . . . . .64
3.3 Auto NAM . . . . . . . . . . . . . . . . . .64
3.4 Force Call . . . . . . . . . . . . . . . . . . .64
3.5 Serving System . . . . . . . . . . . . . .64
4. Security . . . . . . . . . . . . . . . . . . . . . . .65
4.1 Lock Phone . . . . . . . . . . . . . . . . .65
4.2 Restrict Calls . . . . . . . . . . . . . . . .65
4.3 Emergency #s . . . . . . . . . . . . . . .65
4.4 Change Lock . . . . . . . . . . . . . . . .66
4.5 Erase Contacts . . . . . . . . . . . . . .66
4.6 Reset Default . . . . . . . . . . . . . . .66
5. Call Setup . . . . . . . . . . . . . . . . . . . . .67
5.1 Auto Retry . . . . . . . . . . . . . . . . . .67
5.2 Answer Call . . . . . . . . . . . . . . . . .67
5.3 Auto Answer . . . . . . . . . . . . . . . .67
5.4 One-Touch Dial . . . . . . . . . . . . . .67
5.5 Voice Privacy . . . . . . . . . . . . . . . .68
5.6 Auto Volume . . . . . . . . . . . . . . . .68
5.7 TTY Mode . . . . . . . . . . . . . . . . . .68
6. Data Settings . . . . . . . . . . . . . . . . .68
6.1 Data/Fax . . . . . . . . . . . . . . . . . . . .69
6.2 PC Connection . . . . . . . . . . . . . .69
6.3 Mode(1X/QNC) . . . . . . . . . . . . . . .69
6.4 PAP ID . . . . . . . . . . . . . . . . . . . . . .69
LG5000 5
Contents
6.5 PAP Password . . . . . . . . . . . . . . .69
7. Voice Services . . . . . . . . . . . . . . . .70
7.1 Commands Prompt . . . . . . . . . .70
7.2 Driving Mode . . . . . . . . . . . . . . . .70
7.3 Announce Alerts . . . . . . . . . . . . .70
7.4 Best Match . . . . . . . . . . . . . . . . .70
7.5 Train Commands . . . . . . . . . . . . .71
7.6 Train Digits . . . . . . . . . . . . . . . . . .71
7.7 Help . . . . . . . . . . . . . . . . . . . . . .71
8. Location . . . . . . . . . . . . . . . . . . . . . .72
9. Phone Info . . . . . . . . . . . . . . . . . . . .72
9.1 My Phone Number . . . . . . . . . . .72
9.2 S/W Version . . . . . . . . . . . . . . . . .72
9.3 Icon Glossagry . . . . . . . . . . . . . . .72
9.4 Shortcut Help . . . . . . . . . . . . . . . .72
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . .73
TIA Safety Information . . . . . . . . . . .73
Exposure to Radio Frequency Signal
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Antenna Care . . . . . . . . . . . . . . . . . . .73
Phone Operation . . . . . . . . . . . . . . . .73
Tips on Efficient Operation . . . . . . . .73
Driving . . . . . . . . . . . . . . . . . . . . . . . . .74
Electronic Devices . . . . . . . . . . . . . . .74
Pacemakers . . . . . . . . . . . . . . . . . . . .74
Hearing Aids . . . . . . . . . . . . . . . . . . . .74
Other Medical Devices . . . . . . . . . . .74
Health Care Facilities . . . . . . . . . . . . .75
Vehicles . . . . . . . . . . . . . . . . . . . . . . . .75
Posted Facilities . . . . . . . . . . . . . . . . .75
Aircraft . . . . . . . . . . . . . . . . . . . . . . . . .75
6 LG5000
Blasting Areas . . . . . . . . . . . . . . . . . . .75
Potentially Explosive Atmosphere . . .75 For Vehicles Equipped with an Air Bag
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Safety Information . . . . . . . . . . . . . .76
Charger and Adapter Safety . . . . . . .76
Battery Information and Care . . . . . .76
Explosion, Shock, and Fire Hazards .76
General Notice . . . . . . . . . . . . . . . . . .77
FDA Consumer Update . . . . . . . . . .78
Consumer Information on SAR . . .85
10 Driver Safety Tips . . . . . . . . . . . . .86
Accessories . . . . . . . . . . . . . . . . . . . . .88
Warranty Information . . . . . . . . . . . .89
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Welcome
Thank you for choosing the advanced and compact LG5000 cellular phone, designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this phone offers:
Large, easy-to-read, 9-line backlight LCD with status
icons.
Paging, messaging, voice mail, and caller ID.Camera20-key keypad.Long battery standby and talk time.Menu-driven interface with prompts for easy operation
and configuration.
Any key answer, auto answer, auto retry, one-touch ,
speed dialing with 99 memory locations and voice commands.
Bilingual (English and Spanish) capabilities.
Check Accessories
Your mobile phone comes with a rechargeable battery and an AC adapter. Please verify that these accessories are included.
Important Information
This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your warranty.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.
Technical Details
The LG5000 is a tri-mode phone (1.9 Ghz CDMA, 800 Mhz CDMA/AMPS) that operates on both Code Division Multiple Access (CDMA) frequencies: cellular services at 800 Mhz and Personal Communication Services (PCS) at
1.9 Ghz. Also, the LG5000 works on Advanced Mobile
LG5000 7
Welcome
Phone Service(AMPS).
CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft / softer handoff, hard Handoff, and dynamic RF power control technologies combine to reduce call interruptions.
The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), and MS (Mobile Station). The following table lists some major CDMA standards.
* TSB -74: Protocol between an IS-95A system and ANSI
J-STD-008
1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. High-speed data transmission is also possible.
8 LG5000
CDMA
Standard
Basic Air Interface
Network
Service
Performance
Designator Description
TIA/EIA-95A TSB-74 ANSI J-STD-008 TIA/EIA-IS2000
TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124
TIA/EIA/IS-96-B TIA/EIA/IS-99 TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801
TIA/EIA/IS-707-A
TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and inter-band operations IS-95 adapted for PCS frequency band cdma2000 1xRTT Air Interface
MAS-BS PCSC-RS Intersystem operations Nom-signaling data comm.
Speech CODEC Async Data and Fax Short message service Packet Data Position Determination Service (gpsOne) High Speed Packet Data
Cellular base station Cellular mobile station PCS personal station PCS base station Speech CODEC
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies.
The design of this phone complies with the FCC guidelines and these international standards.
Bodily Contact During Operation
This device was tested for typical use with the back of the phone kept 0.6 inches (1.5 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.6 inches (1.5 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot maintain 0.6 inches (1.5 cm) distance between the user’s
body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.) A minimum separation distance of 8 inches (20 cm) must
be maintained between the user / bystander and the vehicle-mounted external antenna to satisfy FCC RF exposure requirements. For more information about RF exposure, visit the FCC website at www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin a minor burn may result. Contact your local dealer for a replacement antenna.
LG5000 9
Phone Overview
1
2
3
4
5 6
7
8 9
10
10 LG5000
Camera
Flash
Outside Display
1. Earpiece
2. Flip Flip open the case to answer an incoming call and close to end the call.
3. LCD Screen Displays messages and indicator icons.
4. Headset Jack
5. Left Soft Key Use to display the function setting menu.
6. Mobile Web Key Use for quick access for Mobile Web.
7. Side Keys Use to adjust the ringer volume in standby mode and the earpiece volume during a call.
8. Send Key Use to place or answer calls.
9. Voice Commands Key Use for quick access to Voice Commands.
10. Manner Mode Key Use to set the mode (from standby mode press and hold for about 3 seconds).
11. Navigation Key Use for quick access to Messages, Speaker, Mobile Web, Brew
11
12 13
14 15
16 17
18
19
20 21
Apps.
12. Right Soft Key Use to select an action within a menu.
13. Brew Apps Key Use for quick access to Brew Apps applications.
14. Message Key Use to retrieve voice mail or send photo and text messages.
15. Side Camera Key Use for quick access to Camera function.
16. END/POWER Key Use to turn the power on/off and to end a call. Also use to return to the main menu display screen.
17. Back Key Press to delete a single space or character. Press and hold to delete entire words. Press this key once in a menu to go back one level.
18. Camera Key Use to take pictures.
19. Alphanumeric Keypad Use to enter numbers and characters and select menu items.
20. Lock Mode Key Use in standby mode to set the lock function by pressing and holding the key for about 3 seconds.
21. Microphone
Press Left Soft Key Menu. Press to Scroll.
Menus Overview
Camera
1. Take Photo
2. Take Video
3. Photo Gallery
4. Video Gallery
5. Photo Place
Contacts
1. List Contacts
2. New Number
3. New E-mail
4. Groups
5. Speed Dials
6. My Contact Info
Recent Calls
1. Dialed Calls
2. Received Calls
3. Missed Calls
4. Erase Calls
1. Dialed Calls
2. Received Calls
3. Missed Calls
4. All Calls
5. Call Timer
1. Last Call
2. Home Calls
3. Roam Calls
4. All Calls
6. KB Counter
1. Received
2. Transmitted
3. Total
Messages
1. Voice Mail
2. New Text Msg
3. New Photo Msg
4. Inbox
5. Outbox
6. Saved
7. Msg Settings
1. Auto Save
2. Auto Erase
3. Text-Auto View
4. Photo-Auto Receive
5. Text-Callback #
6. Voice Mail #
7. Entry Mode
8. Quick-Text
9. Text-Auto Play
0. Text-Signature
8. Erase All
1. Inbox
2. Outbox
3. Saved
4. All
Brew Apps
1. Brew Apps
2. Get Information
Mobile Web
1. Start Browser
2. Web Messages
3. Web Alerts
LG5000 11
Menus Overview
Media
1. Images
2. Sounds
Tools
1. Voice Commands
2. Schedule
3. Alarm Clock
1. Alarm 1
2. Alarm 2
3. Alarm 3
4. Quick Alarm
4. Voice Memo
5. Notepad
6. EZ Tip Calc
7. Calculator
8. World Clock
Settings
1. Sounds
1. Ringers
2. Volume
3. Message Alerts
12 LG5000
4. Service Alerts
5. Power On/Off Tone
2. Display
1. Banner
2. Backlight
3. Screens
4. Menu Style
5. Clocks
6. Theme Colors
7. Contrast
8. Fonts
9. Language
3. System
1. Select System
2. Set NAM
3. Auto NAM
4. Force Call
5. Serving System
4. Security
1. Lock Phone
2. Restrict Calls
3. Emergency #s
4. Change Lock
5. Erase Contacts
6. Reset Default
5. Call Setup
1. Auto Retry
2. Answer Call
3. Auto Answer
4. One-Touch Dial
5. Voice Privacy
6. Auto Volume
7. TTY Mode
6. Data Settings
1. Data/Fax
2. PC Connection
3. Mode( 1X/QNC )
4. PAP ID
5. PAP Password
7. Voice Services
1. Commands Prompt
2. Driving Mode
3. Announce Alerts
4. Best Match
5. Train Commands
6. Train Digits
7. Help
8. Location
9. Phone Info
1. My Phone Number
2. S/W Version
3. Icon Glossary
4. Shortcut Help
Getting Started with Your Phone
The Battery
NNOO TTEE
The phone comes with a rechargeable battery. Keep the battery charged while not in use in order to maximize talk and standby time. The battery charge level is shown at the top of the LCD screen.
Installing the Battery
To install the battery, insert the battery into the opening on the back of the phone. Put the battery cover on the battery and push it slightly upwards.
Removing the Battery
Turn the power off. While pressing the PUSH button on the back of the phone, pull the battery cover downwards and remove it. Then remove the battery by pressing the upper area of it.
It is important to fully charge the battery before initial use of the phone.
Charging the Battery
To use the charger provided with your phone:
Warning! Use only the charger provided with the phone. Using any charger other than the one included with the LG5000 may damage your phone or battery.
1. Plug the round end of the adapter into the phone’s charger jack and the other end into an electrical outlet.
2. The charge time varies depending upon the battery level. The maximum charge time for a fully discharged battery is 3.5 hours.
Battery Charge Level
The battery charge level is shown at the top right of the LCD screen. When the battery charge level becomes low, the low battery sensor alerts you in three ways: sounding an audible tone, blinking the battery icon, and displaying
Low Battery If the battery charge level becomes
exceedingly low, the phone automatically switches off and any function in progress is not saved.
Fully DischargedFully Charged
LG5000 13
Getting Started with Your Phone
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery or connect the phone to an external power source such as a vehicle power charger or hands-free car kit.
2. Press for a few seconds until the LCD screen lights up.
NNOO TTEE
Turning the Phone Off
1. Press and hold until the display turns off.
Signal Strength
Call quality depends on the signal strength in your area. The signal strength is indicated on the screen as the number of bars next to the signal strength icon: The more bars, the better the signal strength. If the signal quality is poor, move to an open area. If you are in a building, the reception may be better near a window.
Like any other radio device, avoid any unnecessary contact with the antenna while your phone is on.
14 LG5000
Screen Icons
When the phone is powered on, the top line of the LCD screen displays icons indicating the status of the phone.
Signal Strength indicator. The strength of the signal received by the phone is indicated by the number of bars displayed.
No Service indicator. The phone is not receiving a system signal.
In Call State indicator. A call is in progress. * No icon indicates the phone is in standby mode.
Digital indicator. Digital service is in progress.
Roaming indicator. The phone is outside of the home service area.
IS-2000
New Voice Mails
New Msgs & Voice
New Messages
Manner Mode E911 Only
Battery Strength indicator. Indicates battery charge level.
Analog Alarm
Announce Alerts Driving Mode
Silence All Location On
SSL TTY
1x Data Active
1x Data Dormant
SSL TTY
QNC Data Active
LG5000 15
Getting Started with Your Phone
Making Calls
1. Make sure the phone is turned on. If not, press and hold about 3 seconds.
2. Enter the phone number (include the area code if needed).
3. Press .
Locked - indicates the phone is locked (if the phone is
locked enter the lock code).
Call Failed - indicates the call did not go through. Restricted - indicates outgoing calls are restricted.
NNOO TTEE
4. Press to end the call.
16 LG5000
If the phone is restricted, you can only dial phone numbers saved in the Emergency Numbers or your Contacts. To turn off this function:
Menu -> Settings -> Security -> Enter Lock Code -> Restrict Calls -> Off
Correcting Dialing Mistakes
If you make a mistake while dialing a number, press once to erase the last digit entered, or hold down for at least 2 seconds to delete all digits.
Redialing Calls
1. Press twice to redial the last number you dialed. The last 30 numbers are stored in the call history list and you can also select one of these to redial.
Receiving Calls
1. When the phone rings or vibrates, press to answer.
NNOO TTEE
2. Press twice to end the call.
If you press or (the side keys) while the phone is ringing, the ringing or vibration is muted for that call.
Quick Access to Convenient Features
Manner Mode
Use Manner Mode in public places. When Manner Mode is set, is displayed on the screen, the key tones are silent, and the phone is set to vibrate.
Manner Mode Quick Activation
1. From Main Menu Screen press for 3 seconds.
Manner Mode Quick Cancellation
1. Press to switch to Normal Mode.
Lock Mode
Use Lock Mode to prevent others from using your phone. When Lock Mode is set, your 4-digit password is required to use the phone.
NNOO TTEE
Lock Mode Quick Activation
1. From Main Menu Screen press for 3 seconds.
The lock code/password is the last 4 digits of your phone number. You can change to a new password using the Security menu.
Lock Mode Quick Cancellation
1. Press Right Soft Key Unlock then enter your 4-digit password.
Mute Function
The Mute Function prevents the other party from hearing your voice, but allows you to hear the other party.
Mute Quick Activation
1. Press Left Soft Key Mute during a call.
Mute Quick Cancellation
1. Press Left Soft Key Unmute again.
Volume Quick Adjustment
Use the side keys to adjust the earpiece and ringer volumes. The upper key increases the volume and the lower key decreases the volume.
Earpiece volume can be adjusted during a call.Ringer volume is muted while the phone is ringing.
NNOO TTEE
Key beep volume is adjusted through the Sounds Volume Menu -> -> -> -> .
LG5000 17
Quick Access to Convenient Features
Call Waiting
Your cellular service may offer call waiting. While a call is in progress, two beeps indicate another incoming call. When call waiting is enabled, you may put the active call on hold while you answer the other incoming call. Check with your cellular service provider for information about this function.
1. Press to receive a waiting call.
2. Press again to switch between calls.
Caller ID
Caller ID displays the number of the person calling when your phone rings. If the caller’s identity is stored in Contacts, the name appears with the number. Check with your service provider to ensure they offer this feature.
Speed Dialing
Speed Dialing is a convenient feature that allows you to make phone calls quickly and easily with a few keystrokes. Your phone recalls the number from your Contacts, displays it briefly, and then dials it. Speed Dial number 1 is set to access Voice Mail.
18 LG5000
Dialing Single Digit Speed Dials (1-9)
1. Press and hold the speed dial number. OR Enter the speed dial number and press .
Dialing Double Digit Speed Dials (10-99)
1. Press the first digit, then press and hold the key of the last digit.
OR Enter the first and second digits, then press .
Voice Command Dialing
Voice Dialing is a convenient feature that allows you to make phone calls quickly and easily by verbal command. Your phone recalls the number from your Contacts, displays it briefly, and then dials it.
1. Press the Voice Commands key ( ).
2. When prompted, say “Contacts”.
3. When prompted, say the name of the Contacts you want to call. The phone will ask you to confirm the name before dialing.
Entering and Editing Information
Text Input
You can input and edit your Banner, Schedule, Contacts, and Messages.
Key Functions
Right Soft Key (or Left Soft Key): Press to
access the following text input modes:
( )
T9Word -> Abc -> 123 -> Symbols -> Smileys
Shift: Press to change case. T9 : T9Word -> T9WORD -> T9word Abc : Abc -> ABC -> abc
Next: In T9Word mode, press to display other
matching words.
Space: Press to complete a word and insert a space.
Back: Press to delete a single space or character. Hold to delete words.
Punctuation: In T9Word mode, press to insert punctuation in a word and complete a sentence.
Text Input Modes
There are five modes for entering text, numbers, special characters, and punctuation. In a text entry field, pressing Right Soft Key (or Left Soft Key ) displays a pop-up list of text modes.
T9Word (T9) Mode
Use to type text using one keystroke per letter. The phone translates keystrokes into common words using the letters on each key and a compressed database.
Abc (Multi-tap) Mode
Use to add words to the T9 database.
123 (Numbers) Mode
Use to type numbers using one keystroke per number.
Symbols Mode
Use to insert special characters or punctuation. There are 39 special characters including “SP” which inserts a space and “LF” which forces text to the next line.
Smileys Mode
Use to insert smiley graphics. There are 40 smiley characters.
LG5000 19
Entering and Editing Information
Changing Letter Case
Using T9 and Abc text input modes you can set the capitalization. Press to reach the following:
Initial Cap (T9Word / Abc)
Only the first letter is capitalized and subsequent letters are lower case.
Caps Lock (T9WORD / ABC)
All letters are capitalized.
Lower Case (T9word / abc)
All letters are in lower case.
Text Input Examples
Display the text modes and select a text mode:
1. In a text entry field, press Right Soft Key (or Left Soft Key ) to display text modes.
2. Press to highlight the text input mode you want to use.
20 LG5000
3. Press to select the highlighted text input mode.
Using Abc (Multi-tap) Text Input
1. Press Right Soft Key (or Left Soft Key ) to change to Abc mode.
2. Press to change to ABC Caps Lock.
3. Press .
LG is displayed.
Using T9 Mode Text Input
1. Press Right Soft Key (or Left Soft Key ) to change to T9Word mode.
2. Press .
3. Press to complete the word and add a space.
4. Press
.
Call the office. is displayed.
Using the NEXT Key (T9 Mode)
After you have finished entering a word, if the word displayed is not the one you want, press to display
additional word choices from the database.
1. Press .
Good is displayed.
2. Press . The display gives you additional choices such as:
Home, Gone, Hood, etc.
Adding Words to the T9 Database
If a word is not in the T9 database, add it using Abc (Multi-tap) mode text entry. The word is automatically added to the T9 database.
1. Press Right Soft Key (or Left Soft Key ) to change to Abc (Multi-tap) mode.
2. Press .
Bop is displayed.
3. Press Right Soft Key (or Left Soft Key ) to change to T9 mode to add the word Bop to the T9 database.
4. Press to erase the existing word.
5. Press .
cop is displayed.
6. Press .
bop is displayed.
LG5000 21
Contacts in Your Phone’s Memory
Contacts Entries
This allows you to have easy access to your most frequently dialed phone numbers. You may store up to 500 entries with up to 5 phone numbers each. Each entry may be up to 22 characters. Each phone number may be up to 48 digits.
The Basics of Storing Contacts Entries
1. From standby mode, enter the phone number you want to save (up to 48 digits).
2. Press Left Soft Key Save
3. Use to select a Label, then press .
Home / Home2 / Office / Office2 / Mobile / Mobile2 / Pager / Fax / Fax2 / None
4. Use to select a New Name / Existing then press .
New Name / Existing
22 LG5000
.
NNOO TTEE
5. Enter a name for the phone
NNOO TTEE
NNOO TTEE
6. Use to highlight the information you want to edit, then press .
Name / Number / Add Number / Add E-mail / No Group / Default Ringer / Default Text Msg Ringer / Memo / Default / Not Secret
7. Change settings as desired, then press .
8. Press Left Soft Key Done to save the change(s). A
confirmation message is displayed.
Use Existing to add another phone number to a contact already stored in memory.
number (up to 22 characters), then press . A confirmation message is displayed briefly.
To skip name entry, press .
Once the confirmation message is displayed, you can press to return to the Main Menu screen.
Contacts in Your Phone’s Memory
Options to Customize Your Contacts
Once the basic phone number and name information is stored in your Contacts, you can edit and customize each entry.
1. Enter the phone number and name as described on the previous page.
2. Use to highlight the information you want to customize, then press .
Adding or Changing the Group
Allows you to manage your Contacts entries by organizing them into groups.
1. Access your Contacts and use to highlight an entry, then press .
2. Press Left Soft Key Edit
3. Use to highlight No Group,then press .
4. Use to select the Group, then press .
No Group / Family / Friends / Colleagues / Business / School
.
5. Press Left Soft Key Done to save the change.
NNOO TTEE
Use Menu ->->to add a new group, change the name of an existing group, or delete a group.
Changing the Call Ringer
Allows you to identify who is calling, by setting different ringers for different phone numbers in your Contacts. It is automatically set to the default ringer when the Contact is saved.
1. Access your Contacts and use to highlight an entry, then press .
2. Press Left Soft Key Edit.
3. Use to highlight Default Ringer, then press .
4. Use to select the Ringer Type, then press .
5. Press Left Soft Key Done to save the change.
LG5000 23
Contacts in Your Phone’s Memory
Changing the Message Ringer
Allows you to identify who is sending you a message, by setting different ringers for different phone numbers in your Contacts. It is automatically set to the default ringer when the Contact is saved.
1. Access your Contacts and use to highlight an entry, then press .
2. Press Left Soft Key Edit.
3. Use to highlight Default Text Msg Ringer, then press .
4. Use to select the Ringer Type, then press .
5. Press Left Soft Key Done to save the change.
Adding or Changing the Memo
Allows you to enter up to 64 characters as a memo to the Contact entry.
1. Access your Contacts and use to highlight an entry, then press .
2. Press Left Soft Key Edit.
24 LG5000
3. Use to highlight Memo, then press .
4. Enter text, then press .
5. Press Left Soft Key Done to save the change.
Adding or Changing the Picture ID
Allows the phone to display an image to identify the caller.
1. Access your Contacts and use to highlight an entry, then press .
2. Press Left Soft Key Edit.
3. Use to highlight Default, then press .
NNOO TTEE
4. Use to select a graphic , then press . Press
5. Press Left Soft Key Done to save the change.
Press Right Soft Key More to access three additional image groups including Images, Avatar, Message Pictures, and Gallery.
Left Soft Key Select.
Changing the Secret Setting
Allows you to hide certain entries from being displayed when your Contacts are searched to view the number, enter the lock code.
1. Access your Contacts and use to highlight an entry, then press .
2. Press Left Soft Key Edit.
3. Use to highlight Not Secret, then press .
4. Use to select the Secret setting, then press .
5. Press Left Soft Key Done to save the change.
Adding Speed Dial
1. Access your Contacts and use to highlight an entry, then press .
2. Use to highlight the phone number you want to set with a Speed Dial, then press Left Soft Key Edit.
3. Press Right Soft Key Options, then press Set Speed Dial.
4. Enter a Speed Dial digit. Use the Keypad, then press , or use to highlight the Speed Dial digit, then press .
5. Press Left Soft Key Done to continue editing the Contact entry, or press to return to the Idle.
Deleting a Speed Dial
1. Press Right Soft Key Contacts.
2. Use to highlight the Contact entry, then press .
3. Press Left Soft Key Edit.
4. highlight the phone number with the Speed Dial to be deleted, then press Right Soft Key Options.
5. Press Remove Speed Dial.
6. Press Remove. A confirmation message is displayed.
LG5000 25
Contacts in Your Phone’s Memory
Editing Contacts Entries
Adding Another Phone Number
From the Main Menu Screen
1. Enter the phone number you want to save (up to 48 digits).
2. Press Left Soft Key Save.
3. Use to highlight a Label, then press .
Home / Home2 / Office / Office2 / Mobile / Mobile2 / Pager / Fax / Fax2 / None
4. Use to highlight Existing then press .
5. Use to highlight the existing Contact entry, then press . A confirmation message is displayed.
Through Contacts
1. Press Right Soft Key Contacts to display your Contacts alphabetically.
2. Use to highlight the Contact entry you want to edit, then press .
26 LG5000
3. Press Left Soft Key Edit.
4. Use to highlight Add Number, then press .
5. Enter the number, then press .
6. Use to highlight a Label, then press . A confirmation message is displayed.
Default Numbers
The phone number saved when a Contact is created is the Default Number. If more than one number is saved in a Contact entry, another number can be designated as the Default Number.
NNOO TTEE
Changing the Default Number
1. Press Right Soft Key Contacts to display your
2. Use to highlight the Contact entry you want to
The Default Number cannot be deleted by itself. The entire Contact entry can be deleted or another number can be set as the Default Number allowing you to delete the original saved number and keep the Contact entry.
Contacts alphabetically.
edit, then press .
3. Press Left Soft Key Edit.
4. Use to highlight the phone number you want to set as the Default Number, then press Right Soft Key
Options.
5. Press Set as Default #. A confirmation message is displayed.
Editing Stored Phone Numbers
1. Press Right Soft Key Contacts to display your Contacts alphabetically.
2. Use to highlight the Contact entry you want to edit, then press .
3. Press Left Soft Key Edit.
4. Use to highlight the phone number, then press
.
5. Edit the phone number as necessary, then press .
6. Use to confirm the Label for the edited phone number, then press .
A confirmation message is displayed.
Editing Stored Names
1. Press Right Soft Key Contacts to display your Contacts alphabetically.
2. Use to highlight the Contact entry you want to edit, then press .
3. Press Left Soft Key Edit.
4. Use to highlight the name, then press .
5. Edit the name as necessary, then press .
6. Press Left Soft Key Done to save the change.
LG5000 27
Contacts in Your Phone’s Memory
Deleting
Deleting a Phone Number from a Contact
1. Press Right Soft Key Contacts.
2. Use to highlight the Contact entry, then press .
3. Press Left Soft Key Edit.
4. Use to highlight the phone number to be deleted.
5. Press Right Soft Key Options.
6. Press Erase Number.
7. Press Erase Number. A confirmation message is displayed.
Deleting a Contact Entry
1. Press Right Soft Key Contacts.
2. Use to highlight the Contact entry to be deleted, then press .
3. Press Right Soft Key Options.
4. Press Erase Contact.
5. Press Erase. A confirmation message is displayed.
28 LG5000
Additional Ways to Delete a Contact
At any time when your Contacts are displayed, the Right Soft Key Options gives you the option to erase the highlighted entry.
Phone Numbers With Pauses
When you call automated systems such as voice mail or credit billing numbers, you often have to enter a series of numbers. Instead of entering these numbers by hand, you can store the numbers in your Contacts separated by special pause characters (P, T). There are two different types of pauses you can use when storing a number:
Hard Pause (P)
The phone stops dialing until you press Left Soft Key
Release to advance to the next number.
2-sec Pause (T)
The phone waits 2 seconds before sending the next string of digits.
Storing a Number with Pauses
1. Press Left Soft Key Menu.
2. Press Contacts.
3. Press New Number.
4. Enter the number.
5. Press Right Soft Key Pause.
6. Use to select pause type, then press . Hard Pause / 2-sec Pause
7. Enter additional number(s) (e.g., pin number or credit card number), then press .
8. Use to select a Label, then press .
9. Enter a name (up to 22 characters), then press . A confirmation message is displayed.
Adding a Pause to an Existing Number
1. Press Right Soft Key Contacts.
2. Use to highlight the Contact entry to edit, then press .
3. Press Left Soft Key Edit.
4. Use to highlight the number, then press .
5. Press Right Soft Key Pause.
6. Use to select pause type, then press . Hard Pause / 2-sec Pause
7. Enter additional number(s), then press .
8. Use to confirm the Label, then press . A confirmation message is displayed.
Searching Your Phone’s Memory
The LG5000 phone is able to perform a dynamic search of the contents in your phone’s memory. A dynamic search compares entered letters or numbers against the entries in your Contacts. A matching list is displayed in descending order. You can then select a number from the list to call or edit. There are several ways to search:
By pressing Alphabetically
Searching by Letter
Searching by Options
LG5000 29
Loading...
+ 161 hidden pages
