LG 43LX341C User manual

OWNER’S MANUAL

Safety and Reference

LED TV*

* LG LED TVs are LCD TVs with LED backlighting.

Please read this manual carefully before operating
your TV and retain it for future reference.

32LX330C
42LX330C

49LX341C
55LX341C
60LX341C
65LX341C

*MFL68925802*

42LX530S 49LX540S

55LX540S
60LX540S
65LX540S

43LX310C
49LX310C

32LX300C

www.lg.com

P/NO : MFL68925802 (1505-REV00)

ENGLISH

Important Safety Instructions

Always comply with the following precautions
to avoid dangerous situations and ensure peak
performance of your product.

WARNING/CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead

symbol within an equilateral triangle is
intended to alert the user to the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock
to persons.

The exclamation point within an

equilateral triangle is intended to alert the
user to the presence of important operating
and maintenance (servicing) instructions in
the literature accompanying the appliance.

WARNING/CAUTION

- TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.

WARNING

If you ignore the warning message, you may
be seriously injured or there is a possibility of
accident or death.

CAUTION

If you ignore the caution message, you may
be slightly injured or the product may be
damaged.

NOTE

The note helps you understand and use the
product safely. Please read the note carefully
before using the product.

Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.

• Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.

• Protect the power cord from being walked on

or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.

WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm.

Wash hands

after handling.

2

• Only use attachments/accessories specified by

the manufacturer.

ENGLISH

• Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.

• Unplug this apparatus during lightning storms

or when unused for long periods of time.

appliance, and have the cord replaced with
an exact replacement part by an authorized
service. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. Do
not move the TV with the power cord plugged
in. Do not use a damaged or loose power cord.
Be sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord to
unplug the TV.

• Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.

• Do not press strongly upon the panel with a

hand or a sharp object such as a nail, pencil, or
pen, or make a scratch on it.

• Do not stick metal objects or any other

conductive material into the power cord. Do
not touch the end of the power cord while it is
plugged in.

• Keep the packing anti-moisture material or

vinyl packing out of the reach of children.
Anti-moisture material is harmful if swallowed.
If swallowed, induce vomiting and go to the
nearest hospital. Additionally, vinyl packing can
cause suffocation. Keep it out of the reach of
children.

• CAUTION concerning the Power Cord

(Can differ by country):
Check the specification page of this owner’s
manual to be certain. Do not connect too many
appliances to the same AC power outlet as this
could result in fire or electric shock. Do not
overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked
wire insulation are dangerous. Any of these
conditions could result in electric shock or fire.
Periodically examine the cord of your appliance,
and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the

• Warning - To reduce the risk of fire or electrical

shock, do not expose this product to rain,
moisture or other liquids. Do not touch the TV
with wet hands. Do not install this product near
flammable objects such as gasoline or candles,
or expose the TV to direct air conditioning.

• Do not expose to dripping or splashing and

do not place objects filled with liquids, such as
vases, cups, etc. on or over the apparatus (e.g.,
on shelves above the unit).

3

ENGLISH

• Grounding

(Except for devices which are not grounded.)
Ensure that you connect the earth ground wire
to prevent possible electric shock (i.e., a TV
with a three-prong grounded AC plug must
be connected to a three-prong grounded AC
outlet). If grounding methods are not possible,
have a qualified electrician install a separate
circuit breaker. Do not try to ground the unit by
connecting it to telephone wires, lightning rods,
or gas pipes.

Power
Supply

Circuit
Breaker

• As long as this unit is connected to the AC wall

outlet, it is not disconnected from the AC power
source even if the unit is turned off.

• Do not attempt to modify this product in any

way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this product.

• Outdoor Antenna Grounding

(Can differ by country):
If an outdoor antenna is installed, follow the
precautions below. An outdoor antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can come in contact with
such power lines or circuits as death or serious
injury can occur. Be sure the antenna system is
grounded to provide some protection against
voltage surges and built-up static charges.
Section 810 of the National Electrical Code (NEC)
in the U.S.A. provides information with respect
to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.

Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70

Antenna Lead in Wire

Antenna Discharge Unit

Ground Clamp

Electric Service

Equipment

Ground Clamp

NEC: National Electrical Code

(NEC Section 810-20)

Grounding Conductor
(NEC Section 810-21)

Power Service Grounding
Electrode System
(NEC Art 250, Part H)

• Cleaning

When cleaning, unplug the power cord and wipe
gently with a soft cloth to prevent scratching. Do
not spray water or other liquids directly on the
TV as electric shock may occur. Do not clean with
chemicals such as alcohol, thinners, or benzene.

4

• Moving

Make sure the product is turned off, unplugged,
and all cables have been removed. It may take 2
or more people to carry larger TVs. Do not press
or put stress on the front panel of the TV.

• Ventilation

Install your TV where there is proper ventilation.
Do not install in a confined space such as a
bookcase. Do not cover the product with cloth or
other materials while plugged. Do not install in
excessively dusty places.

• If you smell smoke or other odors coming from

the TV, unplug the power cord and contact an
authorized service center.

• Keep the product away from direct sunlight.

• Never touch this apparatus or antenna during a

lightning storm.

• When mounting a TV on the wall, make sure not

to install the TV by hanging the power and signal
cables on the back of the TV.

• Do not allow an impact shock, any objects to fall

into the product, and do not drop anything onto
the screen.

• DISCONNECTING THE DEVICE FROM THE

MAIN POWER

The power plug is the disconnecting device.
In case of an emergency, the power plug must
remain readily accessible.

• Batteries

Store the accessories (battery, etc.) in a safe
location out of the reach of children.

• This apparatus uses batteries. In your community

there might be regulations that require you
to dispose of these batteries properly due to
environmental considerations. Please contact
your local authorities for disposal or recycling
information.

• Do not dispose of batteries in a fire.

• Do not short circuit, disassemble, or allow the

batteries to overheat.

• Do not use high voltage electrical equipment

near the TV, (e.g., a bug zapper.)
This may result in product malfunction.

• Dot Defect

The panel is a high technology product with
resolution of two million to six million pixels.
In a very few cases, you could see fine dots on
the screen while you’re viewing the TV. Those
dots are deactivated pixels and do not affect the
performance and reliability of the TV.

• Generated Sound

Cracking noise A cracking noise that occurs
when watching or turning off the TV is
generated by plastic thermal contraction due to
temperature and humidity. This noise is common
for products where thermal deformation is
required.
Electrical circuit humming/panel buzzing
A low level noise is generated from a high­speed switching circuit, which supplies a large

ENGLISH

amount of current to operate a product. It varies
depending upon the product. This generated
sound does not affect the performance and
reliability of the product.

• Take care not to touch the ventilation openings.

When watching the TV for a long period, the
ventilation openings may become hot. This does
not affect the performance of the product or
cause defects in the product.

• Do not install this product on a wall if it could be

exposed to oil or oil mist. This may damage the
product and cause it to fall.

• If the TV feels cold to the touch, there may

be a small flicker when it is turned on. This is
normal; there is nothing wrong with TV. Some
minute dot defects may be visible on the screen,
appearing as tiny red, green, or blue spots.
However, they have no adverse effect on the TV’s
performance. Avoid touching the LCD screen or
holding your finger(s) against it for long periods
of time. Doing so may produce some temporary
distortion effects on the screen.

• If water or another substance enters the product

(like a AC adapter, power cord, TV), disconnect
the power cord and contact the service centre
immediately.
Otherwise, this may result in fire or electric
shock.

Preventing Image Burn or Burn-in on Your
TV Screen

• If a fixed image displays on the TV screen for

a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is image burn or burn-in and not
covered by the warranty.

• If the aspect ratio of the TV is set to 4:3 for a long

period of time, image burn may occur on the
letterboxed area of the screen.

• Avoid displaying a fixed image on the TV screen

for a long period of time to prevent image burn.

• Only use an authorized AC adapter and power

cord approved by LG Electronics. Otherwise, this
may result in fire, electric shock, malfunction or
product deformation.

• Never Disassemble the AC adapter or power

cord.
This may result in fire or electric shock.

5

ENGLISH

FCC Notice

(For USA)
This equipment has been tested and found to

comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment
and the receiver.

- Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.

- Consult the dealer or an experienced radio/TV
technician for help.

This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference and (2) this device must accept any
interference received, including interference that
may cause undesired operation of the device. Any
changes or modifications in construction of this
device which are not expressly approved by the
party responsible for compliance could void the
user’s authority to operate the equipment.

FCC Radio Frequency Interference
Requirements (for UNII devices)

High power radars are allocated as primary users
of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands.
These radar stations can cause interference with
and/or damage this device. This device cannot be
co-located with any other transmitter.

FCC RF Radiation Exposure Statement

[For having wireless function (WLAN, Bluetooth,...)]

This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be
colocated or operating in conjunction with any
other antenna or transmitter. This equipment
should be installed and operated with minimum
distance 20 cm (7.8 inches) between the radiator
and your body. Users must follow the specific
operating instructions for satisfying RF exposure
compliance.

Industry Canada Statement

(For Canada)
[For having wireless function (WLAN, Bluetooth,...)]

This device complies with RSS-210 of the Industry
Canada Rules. Operation is subject to the following
two conditions:

1. This device may not cause interference and

2. This device must accept any interference,
including interference that may cause undesired
operation of the device.

IC Radiation Exposure Statement

(For Canada)
[For having wireless function (WLAN, Bluetooth,...)]

This equipment complies with IC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with minimum distance 20 cm (7.8
inches) between the radiator & your body.

NOTE : THE MANUFACTURER IS NOT RESPONSIBLE
FOR ANY RADIO OR TV INTERFERENCE CAUSED
BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD
VOID THE USER’S AUTHORITY TO OPERATE THE
EQUIPMENT.

6

ENGLISH

WARNING

(For Canada)
[For product having the wireless function using 5
GHz frequency bands]

• The device for operation in the band 5150–5250

MHz is only for indoor use to reduce the
potential for harmful interference to co-channel
mobile satellite systems;

• The maximum antenna gain permitted for

devices in the bands 5250–5350 MHz and
5470–5725 MHz shall comply with the EIRP limit;
and

• The maximum antenna gain permitted for

devices in the band 5725–5825 MHz shall
comply with the EIRP limits specified for point­to-point and non point-to-point operation as
appropriate.

• High-power radars are allocated as primary users

(i.e. priority users) of the bands 5250–5350 MHz
and 5650–5850 MHz and that these radars could
cause interference and/or damage to LE-LAN
devices.

Note to Cable/TV Installer

(For USA and Canada)

This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected
to the grounding system of the building, as close
to the point of the cable entry as practical.

Preparing

NOTE

• Image shown may differ from your TV.

• Your TV’s OSD (On Screen Display) may differ

slightly from that shown in this manual.

• The available menus and options may differ from

the input source or product model that you are
using.

• New features may be added to this TV in the

future.

• The items supplied with your product may vary

depending upon the model.

• Product specifications or contents of this manual

may be changed without prior notice due to
upgrade of product functions.

• For an optimal connection, HDMI cables and USB

devices should have bezels less than 10 mm (0.39
inches) thick and 18 mm (0.7 inches) width.

• Use an extension cable that supports USB 2.0 if

the USB cable or USB flash drive does not fit into
your TV’s USB port.

• Use a certified cable with the HDMI logo

attached. If you do not use a certified HDMI
cable, the screen may not display or a
connection error may occur.

• Recommended HDMI cable types (3 m or less)

- High-Speed HDMI®/™ cable

- High-Speed HDMI®/™ cable with Ethernet

B

B

LG Recycling Policy

(For USA)

LG Electronics offers a customized e-waste
takeback and recycling service that meets
local needs and requirements in the countries
where e-waste regulations are in place, and also
provides product and packaging take-back and
recycling service voluntarily in some countries.
LG Electronics evaluates products’ recyclability at
the design step using LG’s recyclability evaluation
tool, with the goal of improving recyclability where
practicable.
Through these activities, LG seeks to contribute to
conserving natural resources and protecting the
environment.
For more information about the LG Recycling
Policy, please visit our global site at

http://www.lg.com/global/sustainability/
environment/take-back-recycling

A

*A 10 mm (0.39 inches)

*B 18 mm (0.7 inches)

A

CAUTION

• Do not use any unapproved items to ensure the

safety and lifespan of the product.

• Any damages or injuries by using unapproved

items are not covered by the warranty.

• Some models appear to have a thin film on the

screen. It is actually part of the screen; do not
remove it.

• When attaching the stand to the TV set, place

the screen facing down on a cushioned table or
flat surface to protect the screen from scratches.

• Make sure that the screws are fastened tightly.

(If they are not fastened securely enough, the TV
may tilt forward after being installed.)

• Do not fasten the screws with excessive force;

otherwise, they may be worn out and become
loose.

7

ENGLISH

Warning when using USB storage devices

• USB storage devices with a built-in auto

recognition program or its own driver may not
work.

• Some USB storage devices may not work or may

work improperly.

• Use only those USB storage devices formatted

with FAT32 or NTFS File System provided by
Windows.

• For external USB HDD, use devices with less than

5V-rated voltages and 500 mA-rated current.

• It is recommended to use USB flash drive with 32

GB or less and USB HDD with 2 TB or less.

• If a USB HDD with power-saving function does

not work properly, turn the power off and on.
For more information, refer to the user manual
of USB HDD.

• Data in the USB storage device can be damaged

so back up important files in other devices. Data
maintenance is the user’s responsibility. The
manufacturer is not responsible for data loss.

Maintenance

Cleaning Your TV

Clean your TV regularly to keep it at peak
performance and to extend the product’s lifespan.

CAUTION

• Before cleaning, turn the power off and

disconnect the power cord and all other cables.

• When the TV is left unattended or unused for a

long time, disconnect the power cord from the
wall outlet to prevent possible damage from
lightning or power surges.

CAUTION

• Do not push, rub, or hit the surface with your

fingernail or a sharp object, as this may result in
scratches on the screen and image distortions.

• Do not use any chemicals, such as waxes,

benzene, alcohol, thinners, insecticides, air
fresheners, or lubricants, as these may damage
the screen’s finish and cause discoloration.

• Do not spray liquid onto the surface. If water

enters the TV, it may result in fire, electric shock,
or malfunction.

Power Cord

Remove the accumulated dust or dirt on the power
cord regularly.

Lifting and Moving the TV

When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless of
its type and size.

• It is recommended to move the TV in the box or

packing material that the TV originally came in.

• Before moving or lifting the TV, disconnect the

power cord and all cables.

• When holding the TV, the screen

should face away from you to
avoid damage.

• Hold the top and bottom of the TV frame firmly.

Make sure not to hold the transparent part,
speaker, or speaker grille area.

Screen, Frame, Cabinet, and Stand

To remove dust or light dirt, wipe the surface with
a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a soft
cloth dampened in clean water or a diluted mild
detergent. Then wipe immediately with a dry cloth.

8

• Use at least two people to move

a large TV.

• When transporting the TV by

hand, hold the TV as shown in the
following illustration.

• When transporting the TV, do not expose the TV

to jolts or excessive vibration.

• When transporting the TV, keep the TV upright;

never turn the TV on its side or tilt towards the
left or right.

ENGLISH

CAUTION

(4 inches)

• Avoid touching the screen at all times, as this

may result in damage to the screen.

• Do not place the product on the floor with its

front facing down without padding. Failure to do
so may result in damage to the screen.

• Do not move the TV by holding the cable

holders, as the cable holders may break, and
injuries and damage to the TV may occur.
(Depending upon model)

Adjusting the Menu

When the TV is turned on, press the joystick button
one time. You can adjust the menu items moving
the joystick button up, down, left, or right.

Turns the power off.

Accesses the main menu.

Clears on-screen displays and returns to TV viewing

Changes the input source.

Using the Joystick Button

(Image shown may differ from your TV.)
You can operate the TV by pressing the button or
moving the joystick left, right, up, or down.

Joystick Button

Basic Functions

When the TV is turned off, place your
finger on the joystick button, press it

Power On

Power Off

Volume
Control

Channels

Control

once, and release it.
When the TV is turned on, place your

finger on the joystick button, press it
once for a few seconds, and release it.
(However, if the menu button is on the
screen, pressing and holding the joystick
button will let you exit the menu.)

If you place your finger over the joystick
button and move it left or right, you can
adjust the volume level.

If you place your finger over the joystick
button and move it up or down, you can
scroll through the saved channels.

Mounting on a Table

(Image shown may differ from your TV.)

1 Lift and tilt the TV into its upright position on a

table.

- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.

10 cm

10 cm

2 Connect the power cord to a wall outlet.

10 cm

10 cm

NOTE

• Move the joystick up, down, left, or right. Be

careful not to press the joystick button. If you
press the joystick button first, you may not be
able to adjust the volume level and/or scroll
through saved channels.

9
