OWNER’S MANUAL

MONITOR SIGNAGE

Please read this manual carefully before operating the your set and retain it for future reference.

MONITOR SIGNAGE MODELS

32LS33A 42LS33A 47LS33A 55LS33A 65LS33A

42LS35A 47LS35A 55LS35A

www.lg.com

TABLE OF CONTENTS

ENGLISH

TABLE OF CONTENTS

ENG

3 LICENSES

4 ASSEMBLING AND

4 Accessories

5 Optional Accessories

6 Parts and Buttons

7 Connecting the Stand

8 Connecting the Speaker

9 Using the IR Receiver

9 Portrait Layout

10 Mounting on a Wall

12 REMOTE CONTROL

14 MAKING CONNECTIONS

15 RGB Connection

16 HDMI Connection

16 IR Receiver Connection

17 USB Connection

17 LAN Connection

18 USING THE MONITOR

18 Using the Input List

18 Adjusting Aspect Ratio

PREPARING

30 - Viewing Photos

32 - Listening to Music

35 - Viewing the Contents List

36 CUSTOMIZING SETTINGS

36 Accessing Main Menus

37 - PICTURE Settings

40 - AUDIO Settings

41 - TIME Settings

42 - OPTION Settings

43 - NETWORK Settings

45 TROUBLESHOOTING

47 SPECIFICATIONS

63 IR CODES

64 CONTROLLING THE MULTIPLE

PRODUCT

64 Connecting the Cable

64 RS-232C Configurations

64 Communication Parameter

65 Command Reference List

67 Transmission / Receiving Protocol

20 ENTERTAINMENT

20 Using the Network

20 - Connecting to a Network

22 - Network Status

22 Using the My Media

22 - Connecting USB storage devices

24 - Browsing Files

27 - Viewing Movies

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

This DivX Certified® device has passed rigorous testing to ensure it plays DivX® video. To play purchased DivX movies, first register your device at vod.divx.com. Find your registration code in the DivX VOD section of your device setup menu. DivX Certified® to play DivX® video up to HD 1080p, including premium content. DivX®, DivX Certified® and associated logos are trademarks of DivX, LLC and are used under license. Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274.

ENGLISH

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

ASSEMBLING AND PREPARING

ENGLISH

ASSEMBLING AND PREPARING

ENG

Accessories

Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.

Remote Control and

Batteries

Power Cord D-sub 15-pin Signal Cable

IR Receiver

CD (Owner's Manual)

/ Cards

CAUTION

Do not use any unauthorized items to ensure the safety and product life span.



Any damages or injuries by using unauthorized items are not covered by the warranty.



NOTE

The accessories supplied with your product may vary depending on the model.



Product specifications or contents in this manual may be changed without prior notice due to upgrade



of product functions. SuperSign software and manual.



- Downloading from the LG Electronics website.

- Visit the LG Electronics website (http://www.lgecommercial.com/supersign) and download the latest software for your model.

ASSEMBLING AND PREPARING

Optional Accessories

Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories.

Stand

ST-321T 32LS33A ST-421T 42LS33A/ 42LS35A

ST-471T

ST-651T 65LS33A

Diameter 4.0 mm x Pitch 0.7 mm

x Length 14 mm (Included Spring

47LS33A/ 47LS35A 55LS33A/ 55LS35A

Screws

Washer)

Speaker SP-2100

Screws

Diameter 4.0 mm x Pitch

0.7 mm x Length 8 mm

(Included Spring Washer)

Cable holder/

Cable Tie

Screws

Diameter 4.0 mm x

Pitch 1.6 mm x Length

10 mm

ENGLISH

ENG

Stand kit Speaker kit

Media Player

MP500/ MP700

NOTE

Cable holder/cable tie may not be available in some areas or for some models.



Optional accessories are not included for all models.



Screws

Media Player kit

CD (Owner's Manual)/

Cards

Wi-Fi Dongle kit

AN-WF500

ASSEMBLING AND PREPARING

ENGLISH

Parts and Buttons

ENG

Connection Panel

Screen Buttons

No. Description

Moves the selection up and down.

Adjusts the volume level.

Displays the current signal and mode.

Press this button to adjust the screen automatically (available only in RGB mode)

Accesses the main menus, or saves your input and exits the menus.

Changes the input source.

Turns the power on or off.

ASSEMBLING AND PREPARING

Connecting the Stand

- Only on some models.

Place a soft cloth on the table and put the

product with the screen facing downward.

Use the screws to secure the stand on the rear

side of the product as shown in the diagram.

ENGLISH

ENG

ASSEMBLING AND PREPARING

ENGLISH

Connecting the Speaker

ENG

- Only on some models.

32LS33A

Connect the input signal cable to the monitor

before installing the speakers. Use a cable tie to organize the cables.

Mount the speaker by using a screw as shown

in the following. Make sure the power cable is disconnected.

42LS33A

42LS35A

47LS33A

47LS35A

55LS33A

55LS35A

65LS33A

Connect the input signal cable to the monitor

before installing the speakers. Use a cable tie to organize the cables.

Mount the speaker by using a screw as shown

in the following. Make sure the power cable is disconnected.

Then connect the speaker cable. After installing

your speakers, use holders and cable ties to organize the speaker cables.

Then connect the speaker cable. After installing

your speakers, use holders and cable ties to organize the speaker cables.

ASSEMBLING AND PREPARING

Using the IR Receiver

This allows a remote control sensor to be placed in a custom location. The IR receiver is made with a magnet. You can attach it to the monitor edge.

Using the Kensington security system

The Kensington security system connector is located at the back of the monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit

Connect the Kensington security system cable between the monitor set and a table.

http://www.kensington.com

ENGLISH

ENG

Portrait Layout

To install in portrait mode, rotate the set counterclockwise 90 degrees when looking at from the front.

NOTE

The Kensington security system is optional.



You can obtain additional accessories from most electronics stores.

ASSEMBLING AND PREPARING

ENGLISH

Mounting on a Wall

ENG

For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

If you intend to mount the monitor to a wall, attach a Wall mounting interface (optional parts) to the back of the set. When you install the monitor using a wall mounting interface (optional parts), attach it carefully so it will not fall.

10 cm

CAUTION

Disconnect the power cord first, and then



move or install the monitor set. Otherwise electric shock may occur. If you install the monitor set on a ceiling or



slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and



contact the local dealer or qualified personnel. Do not overtighten the screws as this may



cause damage to the monitor set and void your warranty. Use the screws and wall mounts that meet



the VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty. To prevent injury, this apparatus must be



securely attached to the wall in accordance with the instrallation instructions. (This pertains to Australia and New Zealand only.)

NOTE

Please, use a wall mount and screws in

accordance with VESA Standards.

If you use screws longer than standard, the

monitor might be damaged internally.

If you use improper screws, the product might

be damaged and drop from mounted position. In this case, LG Electronics is not responsible for damage.

Please use VESA standard as below.

785 mm or greater



* Fastening screw: Diameter 6.0 mm x Pitch 1.0

mm x Length 12 mm

785 mm

The wall mount kit includes an installation



manual and necessary parts. The wall mount bracket is optional. You can



obtain additional accessories from your local dealer. The length of screws may differ depending



upon the wall mount. Be sure to use the proper length. For more information, refer to the instructions



supplied with the wall mount. The warranty will not cover any damages



caused by using the product in an excessively dusty environment.

ASSEMBLING AND PREPARING

Securing the product to a wall (optional)

(Depending on model)

Insert and tighten the eye-bolts, or product

brackets and bolts on the back of the product.

- If there are bolts inserted at the eye-bolts position, remove the bolts first.

WARNING

If a product is not positioned in a sufficiently



stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as:

»Using cabinets or stands recommended

by the manufacturer of the product.

»Only using furniture that can safely

support the product.

»Ensuring the product is not overhanging

the edge of the supporting furniture.

»Not placing the product on tall furniture

(for example, cupboards or bookcases) without anchoring both the furniture and the product to a suitable support.

»Not standing the product on cloth or other

materials placed between the product and supporting furniture.

»Educating children about the dangers of

climbing on furniture to reach the product or its controls.

ENGLISH

ENG

Mount the wall brackets with the bolts to the

wall.

Match the location of the wall bracket and the eye-bolts on the rear of the product.

Connect the eye-bolts and wall brackets tightly

with a sturdy rope.

Make sure to keep the rope horizontal with the flat surface.

CAUTION

Make sure that children do not climb on or



hang on the product.

NOTE

Use a platform or cabinet that is strong and



large enough to support the product securely. Brackets, bolts and ropes are optional. You



can obtain additional accessories from your local dealer. The illustration shows a general example of



installation and may look different from the actual product.

REMOTE CONTROL

ENGLISH

REMOTE CONTROL

ENG

The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse.

CAUTION

Do not mix old and new batteries, as this



may damage the remote control. Make sure to point the remote control to the



remote control sensor on the monitor set.

(POWER)

Turns the monitor set on or off.

MONITOR ON

Turn on the monitor.

MONITOR OFF

Turn off the monitor.

ENERGY SAVING( )

Adjusts the brightness of the screen to reduce energy consumption.

INPUT

Selects the input mode.

1/a/A Button

Toggles between numerical

and alphabetical.

ARC

Selects the Aspect Ratio

Mode.

Volume Up / Down

Adjusts the volume level.

PSM

Selects the Picture Status

Mode.

MUTE

Mutes all sounds.

This button selection is not applicable.

Number and Alphabet buttons

Enters numerical or alphabetical characters depending on the setting.

CLEAR

Deletes the entered numerical or alphabetical character.

BRIGHTNESS Key

Adjust the brightness by pressing the Up and Down buttons on the remote control. In USB mode, the OSD menu has the Page function to move to the next file list.

REMOTE CONTROL

ENGLISH

ENG

INFO

Views the information of the

currently program and the

screen.

SETTINGS

Accesses the main menus

or saves your input and exit

menus.

Selects menus or options and

confirms your input.

BACK

Allows the user to move back

one step in user interaction

function.

Allows you to control various

multimedia devices simply

by using the remote control

through the SimpLink menu.

(It may not be supported

depending on the model.)

ⓘ

AUTO

Automatically adjusts picture position and minimizes image instability.(RGB input only)

W.BAL

This button selection is not applicable.

S.MENU

(SuperSign Menu Key)

This button does not apply to this model.

Navigation Buttons

Scrolls through menus or options.

EXIT

Clears all on-screen displays and returns to Monitor set viewing from any menu.

TILE

Selects the TILE Mode.

ID ON/OFF

When the number of Picture

ID is equal to Set ID you can

control the monitor which

you want in the multi display

condition.

USB Menu control buttons

Controls media playback.

MAKING CONNECTIONS

ENGLISH

MAKING CONNECTIONS

ENG

Connect various external devices to the ports on the monitor set’s back panel.

HDMI

Find an external device you want to connect to your monitor set shown on the following illustration.

Check the connection type of the external device.

Go to the appropriate illustration and check the connection details.

HD Receiver DVD VCR

HDMI

Speaker

HDMI

USB

RGB HDMI LAN

Camcorder/Camera

HDMI

Gaming device

HDMI

NOTE

If you connect a gaming device to the monitor set, use the cable supplied with the gaming device.



It is recommended you to use the optional speaker provided.



MAKING CONNECTIONS

Instructions for connecting to PC

Your monitor supports the Plug & Play* feature.

* Plug & Play: A PC will have a built-in driver for the monitor ; no extra software is needed.

NOTE

It is recommended you use an HDMI



connection for the best image quality. Use a shielded signal interface cable, such



as D-sub 15-pin signal cable and DVI/HDMI cable, with a ferrite core to maintain standard compliance for the product. If you turn the monitor set on when the set is



cold, the screen may flicker. This is normal. Some red, green, or blue spots may appear



on the screen. This is normal. If you use a cable longer than the D-sub 15-



pin signal cable provided, certain images may appear blurry.

RGB Connection

Transmits an analog video signal from your PC to the monitor. Connect the PC and the monitor with the 15-pin signal cable as shown an following illustration. Select RGB input. To transmit an audio signal, connect an optional audio cable.

Back of the product.

Macintosh Adapter

(not included)

(not

included)

ENGLISH

ENG

CAUTION

Connect the signal



input cable and tighten it by turning the screws clockwise.

Do not press the screen with your finger for



a long time as this may result in temporary distortion on the screen. Avoid displaying a fixed image on the screen



for a long period of time to prevent image burn. Use a screensaver if possible.

PC/MAC

NOTE

Use the standard



Macintosh adapter since an incompatible adapter is available in the market. (Different signaling system)

Apple computers may require an adapter to



connect to this monitor. Call or visit their web site for more information.

MAKING CONNECTIONS

ENGLISH

HDMI Connection

ENG

Transmits digital video and audio signals from your PC or external device to the monitor. Connect the PC or the external device and the Monitor using the HDMI cable as shown in the following diagrams. Select the HDMI input after connecting.

IR Receiver Connection

Allows the use of a wired remote or IR receiver extension.

Back of the product.

(not included)

NOTE

Use a High Speed HDMI®/™ Cable.



Please check the PC environment if you



cannot hear audio in HDMI mode. Some PCs require you to manually change the default audio output to HDMI. If you want to use HDMI-PC mode, you must



set the input label to PC mode. When HDMI PC is used, a compatiblity



problem might occur. Use a certified cable with the HDMI logo



attached. If you do not use a certified HDMI cable, the screen may not display or a connection error may occur. Recommended HDMI cable types



-High-Speed HDMI®/™ Cable

-High-Speed HDMI®/™ Cable with Ethernet

NOTE

Make sure the power cable is disconnected.



MAKING CONNECTIONS

Network

Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory card reader to the monitor set and access the USB menu to use various multimedia files.

LAN ConnectionUSB Connection

Using a router (Switch)

Monitor

Using the Internet.

ENGLISH

ENG

Switch

Monitor

USING THE MONITOR

ENGLISH

USING THE MONITOR

ENG

Using the Input List

Press

Press the navigation buttons to scroll to one of

INPUT

to access the

the input mode and press OK.

Input mode Description

RGB

HDMI

USB

View a PC display on the screen

Watch contents in a PC, DVD of digital set-top box other high definition devices

Plays the multimedia file saved in the USB.

Input List

Adjusting Aspect Ratio

Resize the image to view the image at its optimal size by pressing monitor set.

Aspect Ratio

16:9

Just Scan

Set By Program

4:3

Zoom

Cinema Zoom

NOTE

ARC

MODE

while you are watching

RGB HDMI

PC DTV PC

o o o

x o x

o o o

x o x

You can also change the image size by



accessing the main menus. The Just Scan mode operates when a video



signal has resolution of 720p or higher.

CAUTION

If a fixed image displays on the screen for a



long period of time, it will be imprinted and become a permanent disfigurement on the screen. This is image burn or burn-in and not covered by the warranty. If you don't use your monitor, turn the power



off or set a screen saver program from the PC or the system to prevent image retention. If the aspect ratio is set to 4:3 for a long



period of time, image burn may occur on the letterboxed area of the screen.

USING THE MONITOR

16:9

This selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen (useful for viewing 4:3 formatted DVDs).

Just Scan

- the picture of best quality without loss of original picture in high resolution image. Note: If there is noise in original Picture, You can see the noise at the edge.

This Selection will allow you view

4:3

This selection will allow you to view a picture with an original 4:3 aspect ratio, black bars will appear on both the left and right of the screen.

Zoom

This selection will allow you to view the picture without any alteration, while filling the entire screen. However, the top and bottom of the picture will be cropped.

ENGLISH

ENG

Just Scan

Set By Program

screen aspect ratio changes to 4:3 or 16:9.

Depending on the input signal,

Set By Program

Cinema Zoom

- want to enlarge the picture in correct proportion. Note: When enlarging or reducing the picture, the image may become distorted.

Choose Cinema Zoom when you

ENTERTAINMENT

ENGLISH

ENTERTAINMENT

ENG

Using the Network

Connecting to a Network

For wired network connections, connect the display to a local area network (LAN) via the LAN port as shown on the following diagram. Then, set up the network settings. For wireless network connections, connect the Wi-Fi USB module to the USB port. Then, set up the network settings. After making a physical connection, a small number of home networks may require the display network settings to be adjusted. For most home networks, the display will connect to automatically without any adjustments. For detail information, contact your internet provider or router manual.

Router

LAN

LANWAN

To set up the network settings: (Even if your display has already connected automatically, running setup again will not harm anything),

Connecting to a wired network

1 Press SETTINGS to access the main menus.

2 Press the navigation buttons to scroll to NET-

WORK and press OK.

3 Press the navigation buttons to select Network

Setting and press OK.

4 If you already set network setting, select

Resetting. The new connection settings resets

the current network settings.

5 Select IP Auto Setting or IP Manual Setting.

- IP Manual Setting press the navigation and number buttons. IP addresses will need to be input manually.

- IP Auto Setting Select this if there is a DHCP server (Router) on the local area network (LAN) via wired connection, the display will automatically be allocated an IP address. If you’re using a broadband router or broadband modem that has a DHCP (Dynamic Host Configuration Protocol) server function. The IP address will automatically be determined.

Internet

Cable modem

ETHERNET

CAUTION

 Do not connect a modular phone cable to

the LAN port.

 Since there are various connection meth-

ods, please follow the specifications of your telecommunication carrier or internet service provider.

6 When you are finished, press EXIT.

ENTERTAINMENT

Connecting to a wireless network

1 Press SETTINGS to access the main menus.

2 Press the navigation buttons to scroll to NET-

WORK and press OK.

3 Press the navigation buttons to select Network

Setting and press OK.

4 Select Setting from the AP list or Simple

setting (WPS-button mode).

-Setting from the AP list Select an AP to connect to a wireless network.

Simple setting (WPS-button mode)

Press the button on the wireless router that supports PBC to easily connect to the router.

5 When you are finished, press EXIT.

CAUTION

 Network setting menu will not be avail-

able until the display connected to physical network.

 Since there are various connection meth-

ods, please follow the specifications of your telecommunication carrier or internet service provider.

NOTE

 If you want to access the Internet directly on

your display, the Internet connection should always be on.

 If you cannot access the Internet, check

the network conditions from a PC on your network.

 When you use Network Setting, check the

LAN cable or check if DHCP in the router is turned on.

 If you do not complete the network settings,

the network may not work properly.

Tips for Network setting

 Use a standard LAN cable with this display.

Cat5 or better with a RJ45 connector.

 Many network connection problems during set

up can often be fixed by re-setting the router or modem. After connecting the display to the home network, quickly power off and/or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.

 Depending on the internet service provider

(ISP), the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP.

 LG is not responsible for any malfunction of the

display and/or the internet connection feature due to communication errors/malfunctions associated with your internet connection, or other connected equipment.

 LG is not responsible for problems within your

internet connection.

 You may experience undesired results if the

network connection speed does not meet the requirements of the content being accessed.

 Some internet connection operations may not

be possible due to certain restrictions set by the Internet service provider (ISP) supplying your Internet connection.

 Any fees charged by an ISP including, without

limitation, connection charges are your responsibility.

 A 10 Base-T or 100 Base-TX LAN port is

required when using a wired connection to this display. If your internet service does not allow for such a connection, you will not be able to connect the display.

 A DSL modem is required to use DSL service

and a cable modem is required to use cable modem service. Depending on the access method of and subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this display or you may be limited to the number of devices you can connect at the same time. (If your ISP limits sub scription to one device, this display may not be allowed to connect when a PC is already connected.)

 The use of a router may not be allowed or its

usage may be limited depending on the policies and restrictions of your ISP. For details, contact your ISP directly.

ENGLISH

ENG

ENTERTAINMENT

ENGLISH

ENG

Tips for Wireless Network Setting

 Wireless networks can be subject to interfer-

ence from other devices operating at a frequency of 2.4 GHz (wireless phones, Bluetooth devices or microwave ovens). There may also be interference from devices with a frequency of 5 GHz, same as other Wi-Fi devices.

 The surrounding wireless environment can

cause the wireless network service to run slowly.

 For an AP connection, an access point device

that supports wireless connection is required and the wireless connection feature must be enabled on the device. Contact your service provider regarding availability of wireless connection on your access point.

 Check the SSID and security settings of the

AP for AP connection. Refer to the appropriate documentation for SSID and security settings of the AP.

 Invalid settings on network devices (wired/wire-

less line sharer, hub) can cause the monitor to run slowly or not operate properly. Install the devices correctly according to the appropriate manual and set the network.

 Connection method may differ according to the

AP manufacturer.

Using the My Media

Connecting USB storage devices

Connect USB storage devices such as a USB flash memory, external hard drive to the display and use multimedia features. Connect a USB flash memory or USB memory card reader to the Display as shown on the following illustration. The My Media screen appears.

Network Status

1 Press SETTINGS to access the main menus. 2 Press the navigation buttons to scroll to NET-

WORK and press OK.

3 Press the navigation buttons to select Network

Status.

4 Press OK to check the network status. 5 When you are finished, press EXIT.

Option Description

Setting Return to the network setting menu.

Test

Close Return to the previous menu.

Test the current network status after setting the network.

CAUTION

 Do not turn the display off or remove a USB

storage device while MY MEDIA menu is activated, as this could result in loss of files or damage to the USB storage device.

 Back up your files saved on a USB storage

device frequently, as you may lose or damage the files and this may be not covered by the warranty.

ENTERTAINMENT

Tips for using USB storage devices

 Only a USB storage device is recognizable.  If the USB storage device is connected

through a USB hub, the device is not recognizable.

 A USB storage device using an automatic

recognition program may not be recognized.

 A USB storage device which uses its own

driver will not be recognized.

 The recognition speed of a USB storage

device may depend on each device.

 Please do not turn off the display or unplug

the USB device when the connected USB storage device is working. When such a device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged.

 Please do not connect the USB storage

device which was artificially maneuvered on the PC. The device may cause the product to malfunction. Only use a USB storage device which has normal music files, image files or movie files.

 Please use only a USB storage device which

was formatted as a FAT32 file system, NTFS file system by with the Windows operating system. In case of a storage device formatted with a different utility programme which is not supported by Windows, it may not be recognized.

 Please connect power to a USB storage de-

vice (over 0.5 A) which requires an external power supply. If not, the device may not be recognized.

 Please connect a USB storage device with

the cable included by the device maker.

 Some USB storage devices may not be sup-

ported or operate smoothly.

 File alignment method of USB storage devic-

es is similar to Window XP and the monitor can recognize up to 100 English characters.

 Be sure to back up important files since data

stored on a USB memory device may be damaged. We will not be responsible for any data loss.

 If the USB HDD does not have an external

power source, the USB device may not be detected. So be sure to connect the external power source.

- Please use a power adaptor for an external power source.

 If your USB memory device has multiple

partitions, or if you use a USB multi-card reader, you can use up to 4 partitions or USB memory devices.

 If a USB memory device is connected to a

USB multi-card reader, its volume data may not be detected.

 If the USB memory device does not work

properly, disconnect and reconnect it.

 How fast a USB memory device is detected

differs from device to device.

 If the USB is connected in Standby Mode,

that drive will automatically be loaded when the display is turned on.

 The recommended capacity is 1 TB or less

for a USB external hard disk and 32 GB or less for USB memory.

 Any device with more than the recommend-

ed capacity may not work properly.

 If a USB external hard disk with a Energy

Saving function does not work, turn the hard disk off and on again to make it work properly.

 USB storage devices below USB 2.0 are

supported as well. But they may not work properly with videos.

 A maximum of 999 folders or files can be

recognized under one folder.

 It is recommended you use a certified USB

storage device and cable. Otherwise, a USB storage device may not be detected or a playback error may occur.

 Only a USB memory device can be used

to play back the files distributed and stored by SuperSign Manager. A USB hard disk or multi-card reader will not work.

 Only an FAT 32 file formatted storage device

can play back the files distributed and stored by SuperSign manager.

 A USB 3.0 storage device may not work.

ENGLISH

ENG

ENTERTAINMENT

ENGLISH

Browsing Files

ENG

Browse files saved in a USB storage device.

Press SETTINGS to access the main menu.

Press the search button to scroll to MY MEDIA and press OK.

Press the Search button to go to the Movie List, Photo List, Music List, or Content List that you want,

and press OK.

Page 1/1

Page ChangePAG E

All Media

USB -

Movie ListAll Media

Photo List

Music List Contents List

Page 1/1

Page ChangePAG E

All Media

USB -

Drive1

Page 1/1

001

005

009

No. Description

Returns to the previous level.

Current page/total pages of the folder above

Lower item of

Current page/total pages of

Remote control button

002

006

010

003

007

011

004

008

012

ExitGo to root folder Go to upper folder

Supported file format

Type Supported file format

Movie Codec Media Container

Video MPEG1 / MPEG2 DAT, MPG, MPEG,

DVD, TS, TP

MPEG4 (DivX 3.11, DivX 4, DivX 5, DivX 6, Xvid 1.01, Xvid 1.02, Xvid 1.03, Xvid 1.10beta1/2)

H.264 AVI, MP4, MKV, TS,

Audio MP3 MP3 8 kbps to 320 kbps(Bit rate)

AC3 AC3 32 kbps to 640 kbps(Bit rate)

MPEG MP3 32 kbps to 448 kbps(Bit rate)

AAC, HEAAC MP4 8 kHz to 48 kHz(Sample rate)

LPCM AIF, WAV 64 kbps to 1.5 Mbps(Bit rate)

Bit rate : within 8 kbps to 320 kbps(MP3) External Subtitle format : *.smi/*.srt/*.sub(MicroDVD, Subviewer1.0/2.0)/*.ass/*.ssa/*.txt(TMPlayer)/*. psb(PowerDivX) Internal Subtitle format : only, XSUB (It is the subtitle format used in DivX6 files)

AVI, DIVX, MP4, MKV, TS, TRP

TRP, TP

ENTERTAINMENT

Profile

1080P @ 30 fps

1080P @ 60 fps

16 kHz to 48 kHz(Sample rate)

32 kHz, 44.1 kHz, 48 kHz(Sample rate)

16 kHz to 48 kHz(Sample rate)

8 kHz to 48 kHz(Sample rate)

ENGLISH

ENG

ENGLISH

ENG

ENTERTAINMENT

Type Supported file format


Music

Content (when using SuperSign Manager)

JPEG Baseline : 64 x 64 to 15360 x 8640 Progressive : 1024 x 768 PNG Interlace : 1200 x 800 BMP 9600 x 6400

 Non-supported files are displayed in the form of predefined icon.

MP3 Bit rate : 8 kbps to 320 kbps

 Sampling rate MPEG1/2 Layer3 : 16 kHz to 48 kHz

File Extensions : *.cts/ *.cse

Movie

File Extensions

mp4(motion JPEG)/*.mkv(motion JPEG)

Video format

Xvid 1.00,Xvid 1.01, Xvid 1.02, Xvid 1.03,Xvid 1.10-beta1/2, JPEG

Audio format

: *.mpg/*.mpeg/*.dat/*.ts/*.trp/*.tp/*.mp4/*.mkv/*.avi/*. avi(motion JPEG)/*.

: MPEG1, MPEG2, MPEG4,H.264, DivX 3.11, DivX 4, DivX 5, DivX 6,

: MP3, Dolby Digital, LPCM, AAC, HE-AAC

ENTERTAINMENT

Viewing Movies

Plays movie files saved in the USB storage device.

Press SETTINGS to access the main menu.

Press the navigation button to scroll to MY MEDIA and press OK.

Press the navigation button to scroll to Movie List and press OK.

Press the navigation buttons to scroll to a folder you want and press OK.

Press the navigation buttons to scroll to a file you want and press OK.

Movie List

USB -

003002001 004 005

HR1.mp4 01:00:00

HR5.mp4 01:09:00

HR2.mp4 01:03:00

HR6.mp4 03:00:00

HR3.mp4 01:05:00

HR7.mp4 03:01:00

Page 1/3

HR4.mp4 01:07:00

HR8.mp4 03:03:00

ENGLISH

ENG

Page ChangePAG E

Page 1/1

HR9.mp4 03:05:00

Returns to the home screen of My Media.

ExitGo to root folder Go to upper folder

Returns to the previous screen. Exits My Media.

6 During movie playback, press OK to access the following settings.

Option Hide Exit

Remote

button

Stops the playback.

Plays a video.

Pauses or resumes the playback.

Scans backward in a file.

Scans forward in a file.

Adjusts the screen brightness to save energy.

SETTINGS Show the Option menu.

Hide the menu on the full-sized screen.

BACK

EXIT Returns to Movie List.

Skips to specific points in a file during playback. The time of a specific point will appear on the status bar. In some files, this function may not work properly.

Tips for using playing video files

 Some user-created subtitles may not work

properly.

 Some special characters are not supported

in subtitles.

 HTML tags are not supported in subtitles.  Subtitles in languages other than the sup-

ported languages are not available.

 The screen may suffer temporary interrup-

tions (image stoppage, faster playback, etc.) when the audio language is changed.

 A damaged movie file may not be played

correctly, or some player functions may not be usable.

 Movie files produced with some encoders

may not be played correctly.

 If the video and audio structure of recorded

file is not interleaved, either video or audio is outputted.

 HD videos with a maximum of

1920x1080@25/30P or 1280x720@50/60P are supported, depending on the frame.

Description

 Videos with resolutions higher than

1920X1080@25/30P or 1280x720@50/60P may not work properly depending on the frame.

 Movie files other than the specified types and

formats may not work properly.

 Max bitrate of playable movie file is 20 Mbps.

(only, Motion JPEG : 10 Mbps)

 We do not guarantee smooth playback of

profiles encoded level 4.1 or higher in H.264/ AVC.

 DTS Audio codec is not supported.  A movie file more than 30 GB in file size is

not supported for playback.

 A DivX movie file and its subtitle file must be

located in the same folder.

 A video file name and its subtitle file name

must be identical for it to be displayed.

 Playing a video via a USB connection that

doesn’t support high speed may not work properly.

 Files encoded with GMC(Global Motion

Compensation) may not be played.

ENTERTAINMENT

Video options

1 Press SETTINGS to access the Pop-Up

menus.

2 Press the navigation buttons to scroll to Set

Video Play., Set Video, or Set Audio, and press OK.

NOTE

 The option values changed in Movie List

do not affect Photo List or Music List. Therefore, they are not affected by option values changed in Photo List or Music List.

 The option values changed in Photo List

and Music List do affect each other.

 When replaying the video file after stopping,

you can play from where it stopped previously.

Menu Description

Size Selects your desired Subtitle size

during movie play.

Repeat Turn on/off repeat function of

movie playback. When turned on, the file within the folder will be played back repeatedly. Even when the repeated playback is turned off, it can run the playback if the file name is similar to the previous file.

NOTE

 Only 10,000 of sync blocks can be supported

within the subtitle file.

 When playing a video, you can adjust the

picture size by pressing the ARC button.

 Subtitles in your language are only sup-

ported when the OSD menu is also in this language.

 The code page options may be disabled de-

pending on the language of the subtitle files.

 Select the appropriate code page for the

subtitle files.

ENGLISH

ENG

Select Set Video Play to access the following menus:

Menu Description

Picture Size Selects your desired picture

format during movie play.

Audio

Language

Subtitle

Language Language Activated for SMI subtitle and

Code Page Can select the font for subtitle.

Sync Adjusts the time synchronisation of

Position Changes the position of the

Changes the Language Group of the audio during movie play. Files with a single audio track cannot be selected. Turn on/off the subtitle.

can select the language within the subtitle.

When set to default, same font as general menu will be used.

the subtitle from -10 secs to +10 secs by steps of 0.5 secs during movie play.

subtitle either up or down during movie play.

For more details about the Set Video. menu, see the CUSTOMIZE SETTINGS section. See page 37.

For more details about the Set Audio. menu, see the CUSTOMIZE SETTINGS section. See page 40.

ENTERTAINMENT

ENGLISH

ENG

View image files saved in the USB storage device.

Viewing Photos

Press SETTINGS to access the main menu.

Press the navigation button to scroll to MY MEDIA and press OK.

Press the navigation button to scroll to Photo List and press OK.

Press the navigation buttons to scroll to a folder you want and press OK.

Press the navigation buttons to scroll to a file you want and press OK.

Photo List

USB -

003002001 004 005

HR1.jpg 01/23/2014

HR5.jpg 02/21/2014

HR2.jpg 01/23/2014

HR6.jpg 02/21/2014

HR3.jpg 01/23/2014

HR7.jpg 02/21/2014

Page 1/3

Page ChangePAG E

HR4.jpg 01/23/2014

HR8.jpg 02/21/2014

Page 1/1

HR9.jpg 02/21/2014

Returns to the home screen of My Media.

ExitGo to root folder Go to upper folder

Returns to the previous screen. Exits My Media.

ENTERTAINMENT

6 While viewing photos, you can access the following settings.

BGMSlideshow

Menu Description

Slideshow Starts or stops a slideshow with selected photos. If there are no selected photos, all photos saved in

the current folder display during a slideshow. To set a slideshow speed, select Option.

BGM Turns the background music on or off. To set the background music folder, select Option.

You can adjust option by SETTINGS button on the remote control. Rotates photos clockwise (90°, 180°, 270°, 360°).

Option

NOTE

 The supported photo size is limited. You cannot rotate a photo if the resolution of the

rotated width is larger than the supported resolution size.

Enlarges the photo by 100%, 200% or 400%.

NOTE

 Photos with a resolution of 100 x 100 or less cannot be enlarged.

Hide Exit

ENGLISH

ENG

Adjusts the screen brightness to save energy.

Option To display the options

Hide Hides the option window. To display the options, press OK.

Exit Return to Photo List.

Photo options

1 Press SETTINGS to show the Option menus.

2 Press the navigation buttons to scroll to Set

Photo View., Set Video, or Set Audio, and press OK.

NOTE

 The option values changed in Movie List

do not affect Photo List or Music List. Therefore, they are not affected by option values changed in Photo List or Music List.

 The option values changed in Photo List

and Music List do affect each other.

Select Setting Photo View to access the following menus:

Menu Description

Slide Speed Select a slideshow speed.

(Options: Fast, Medium or Slow.)

BGM Selects a music folder for the back-

ground music.

For more details about the Set Video. menu, see the CUSTOMIZE SETTINGS section. See page 37.

For more details about the Set Audio. menu, see the CUSTOMIZE SETTINGS section. See page 40.

ENTERTAINMENT

ENGLISH

ENG

Plays music files saved in the USB storage device.

Listening to Music

Press SETTINGS to access the main menu.

Press the navigation button to scroll to MY MEDIA and press OK.

Press the navigation button to scroll to Music List and press OK.

Press the navigation buttons to scroll to a folder you want and press OK.

Press the navigation buttons to scroll to a file you want and press OK.

Music List

USB -

003002001 004 005

HR1.mp3 03:03

HR5.mp3 02:03

HR2.mp3 05:03

HR6.mp3 04:03

HR3.mp3 09:03

HR7.mp3 06:03

Page 1/3

Page ChangePAG E

HR4.mp3 04:03

HR8.mp3 05:03

Page 1/1

HR9.mp3 02:21

Returns to the home screen of My Media.

Returns to the

previous screen.

Opens the settings

window for music.

This feature is activated

only during playback.

ExitGo to root folder Open Music PlayerGo to upper folder

Exits My Media.

ENTERTAINMENT

6 During music playback, press OK or the blue button ( ) to access the following settings.

Selects the desired point and plays.

ENGLISH

ENG

HR1.mp3

Remote

button

Stops playing back the file and moves back to the Music List.

Plays a music file.

Pauses or resumes playback.

Skips to the previous file.

Skips to the next file.

Adjusts the screen brightness to save energy.

SETTINGS Show the Option menu.

Hides the option window.

BACK

EXIT Return to Music List.

To display the options, press OK.

Skips to specific points in a file during playback. The time of a specific point will appear on the status bar. In some files, this function may not work properly.

01:40 / 03:03

Option Hide Exit

Description

ENTERTAINMENT

ENGLISH

ENG

Tips for playing music files

This unit cannot support the ID3 Tag



embedded MP3 files.

NOTE

 A damaged or corrupted music file does not

play but displays 00:00 in playtime.

 A music downloaded from a paid service with

 If you press OK, buttons, screen saver is

stopped.

 The , , , , buttons on the re-

mote control are also available in this mode.

 You can use the button to select the next

music and the button to select the previous music.

file name

Music options

1 Press SETTINGS to access the pop-up menus.

2 Press the navigation buttons to scroll to Set Au-

dio Play or Set Audio and press OK.

NOTE

 The option values changed in Movie List

do not affect Photo List or Music List. Therefore, they are not affected by option values changed in Photo List or Music List.

 The option values changed in Photo List

and Music List do affect each other.

When you select the Set Audio Play,

Menu Description

Repeat Repeats the music playback.

Random

Plays random music tracks.

002. B02.mp3 00:31 / 04:04

Time elapsed/ Duration

For more details about the Set Audio menu, see the CUSTOMIZE SETTINGS section. See page

40.

ENTERTAINMENT

Viewing the Contents List

Plays back the stored files using the Export option in SuperSign Manager.

Press SETTINGS to access the main menu.

Press the navigation button to scroll to MY MEDIA and press OK.

Press the navigation button to scroll to Contents List and press OK.

Press the navigation buttons to scroll to a folder you want and press OK.

Press the navigation buttons to scroll to a file you want and press OK.

Contents List

USB -

003002001 004 005

HR1.cts 01/01/2014

HR5.cts 01/01/2014

HR2.cts 01/01/2014

HR6.cts 01/01/2014

HR3.cts 01/01/2014

HR7.cts 01/01/2014

Page 1/3

Page ChangePAG E

HR4.cts 01/01/2014

HR8.cts 01/01/2014

ENGLISH

ENG

Page 1/1

HR9.cts 01/01/2014

ExitGo to root folder Go to upper folder

Returns to the home

Returns to the previous screen. Exits My Media.

screen of My Media.

NOTE

 While playing media files from Contents List, only the BACK, EXIT, or volume button are available.

Selecting the BACK or EXIT button stops playing media files and returns to the Contents List.

 If there is the AutoPlay folder in the USB device and its files are in supported formats, they can be

played back automatically when the USB device is connected to the monitor.

CUSTOMIZING SETTINGS

ENGLISH

CUSTOMIZING SETTINGS

ENG

Accessing Main Menus

Press

SETTINGS

to access the main menus.

Press the navigation buttons to scroll to one of the following menus and

press OK.

Press the navigation buttons to scroll to the setting or option you want

and press OK.

When you are finished, press

When you return to the previous menu, press


Adjusts the image size, quality, or effect.

EXIT

BACK

AUDIO

Adjusts the sound quality, effect, or volume level.

OPTION

Customizes the general settings.


OPTION

NETWORK

Sets up the network setting.

NETWORK

AUDIO TIME

MY MEDIA

TIME

Sets the time, date, or timer feature.

MY MEDIA

Display and play movie, photo and music contents stored on your USB or signage device (Internal storage device).

CUSTOMIZING SETTINGS

PICTURE Settings

Press

Press the navigation buttons to scroll to

Press the navigation buttons to scroll to the setting or

When you are finished, press

The available picture settings are described in the following:

Saving

Smart Energy Saving

Picture Mode

Aspect Ratio

SETTINGS

to access the main menus.


and

press OK.

option you want and press OK.

BACK

- To return to the previous level, press

EXIT

When you return to the previous menu, press

BACK

Setting Description

Energy

Sets to automatically adjust the screen brightness corresponding to the surroundings.

Option

Off

Minimum/

Disables Energy Saving function.

Selects the brightness level of the backlight.

Medium/ Maximum

Screen Off

The screen turns off in 3 seconds.

Adjusts the backlight and contrast depending on the screen brightness.

Option

Off

Disables the Smart Energy Saving function.

Enables the Smart Energy Saving function to save power consumption as much as the value set in the smart energy saving rate.

Selects the picture mode optimized for the viewing environment or the programme.

Option

Vivid

Standard

APS

Heightens contrast, brightness, and sharpness to display vivid images.

Displays images in standard levels of contrast, brightness, and sharpness.

The Energy Saver feature changes settings on the monitor to reduce power consumption.

Cinema

Optimizes the video image for a cinematic look to enjoy movies as if you are in a movie theater.

Sport

Optimizes the video image for high and dynamic actions by emphasizing primary Colors such as white, grass, or sky blue.

Game

Expert1·2

Optimizes the video image for a fast gaming screen such as PCs or games.

Menu for adjusting picture quality that allows experts and amateurs to enjoy the best Monitor viewing. This menu is ISF-certified and provided for picture tuning experts. (ISF logo can only be used on ISF-certified Monitor units.) ISFccc: Imaging Science Foundation Certified Calibration Control

Changes the image size to view images at its optimal size.


Energy Saving

Smart Energy Saving

Picture Mode

Aspect Ratio

Screen

Move

: Off (User)

: Off

: Standard

Backlight

Contrast

Brightness

Sharpness

Color

Tint

Color Temp.

Advanced Control /

Picture Option

Picture Reset

: 16:9

Expert Control

100

R G

W C

ENGLISH

ENG

ENGLISH

ENG

CUSTOMIZING SETTINGS

Setting Description

Screen (In RGB Mode Only)

Customizes the PC display options in RGB mode.

Option

Resolution

Auto Configure

Position/Size/ Phase

Reset

Selects a proper resolution.

Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress.

Adjusts the options when the picture is not clear, especially when characters are shaky, after the auto configuration.

Restores the options to the default setting.

Basic image options

Setting Description

Backlight

Contrast

Brightness

Sharpness

Color

Tint

Color Temp.

Advanced Control/ Expert Control

Picture Option

Picture Reset

Adjusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss.

Increases or decreases the gradient of the video signal. You may use Contrast when the bright part of the picture is saturated.

Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of the picture is saturated.

Adjusts the level of crispness in the edges between the light and dark areas of the picture. The lower the level, the softer the image.

Adjusts intensity of all colors.

Adjusts the balance between red and green levels.

Set to warm to enhance hotter Colors such as red, or set to cool to make picture bluish.

You can adjust the picture for each a specific picture image. First, select a desired * This option is unavailable if

Sets additional picture option.

Restores the options to the default setting.

Picture Mode

NOTE

Picture Mode

is set to

, or adjust the picture settings according to

Vivid

When you select a picture mode, related menus are set automatically.



When using the Smart Energy Saving function, the screen may look saturated in the white area of a



still image. If Energy Saving is set to Minimum, Medium, or Maximum, the Smart Energy Saving function is



disabled.

Advanced Control - Picture Mode (Standard/ APS/ Sport/ Game)

Setting Description

Dynamic Contrast

Dynamic Color

Color Gamut

Skin Color

Sky Color

Grass Color

Gamma

Adjusts the contrast to the optimal level according to the brightness of the image.

Adjusts color for more natural-looking colors.

Selects the range of colours that can be expressed.

Skin color spectrum can be separately set to implement the skin color as defined by the user.

Sky color is set separately.

Natural color spectrum (meadows, hills, etc.) can be separately set.

Sets the gradation curve according to the output of the picture signal in relation to the input signal.

Expert Control - Picture Mode (Cinema/ Expert1/ Expert2)

Setting Description

Dynamic Contrast

Color Gamut

Edge Enhancer

Color Filter

Color Temperature

Color Management System

Adjusts the contrast to the optimal level according to the brightness of the image.

(Function works in the following mode - HDMI-DTV)

Selects the range of colours that can be expressed.

Shows clearer and distinctive yet natural edges of the video.

Filters a specific colour spectrum in RGB colours to fine-tune colour saturation and hue accurately.

Adjusts the overall tone of the screen as desired. In Expert mode, detailed fine-tuning can be set via Gamma method, etc.

This is a system that experts use when they adjust colour with a test pattern. They can select from six colour areas (Red / Green / Blue / Cyan / Magenta / Yellow) without affecting other colours. For normal images, adjustments may not result in noticeable colour changes.

CUSTOMIZING SETTINGS

ENGLISH

ENG

Picture Option - HDMI(DTV) Mode

Setting Description

Noise Reduction

MPEG Noise Reduction

Black Level

Real Cinema

Motion Eye Care

TruMotion (Only for 65LS33A model)

Reduces screen noise in the video.

Reduces noise caused by compressing digital video.

Adjusts the brightness or darkness of the screen to suit the black level of the picture input using the degree of darkness (black level) of the screen.

Optimizes the screen for movie viewing.

Adjusts screen brightness to prevent eye glare. (Depending on model)

Corrects images to display smoother motion sequences.

• Off : Turn off the TruMotion.

• Smooth/ Clear : De-Judder / De-Blur can be set Auto.

• User : De-Judder / De-Blur can be set manually.

- De-Judder : This function adjusts juddering of the screen.

- De-Blur : This function adjusts and eliminates blurring of the screen.

TruMotion

• De-Judder Auto

• De-Blur Auto

◄

Smooth

►

CUSTOMIZING SETTINGS

AUDIO Settings

ENGLISH

ENG

The available audio options are described in the following:

SETTINGS

to access the main menus.

AUDIO

and press

Press

Press the navigation buttons to scroll to

Press the navigation buttons to scroll to the setting or

option you want and press OK.

- To return to the previous level, press

When you are finished, press

EXIT

When you return to the previous menu, press

Setting Description

Sound Mode

Sound Effect

AV Sync. Adjust

Allows optimized sound for custom Monitor installation.

Option

Standard

News/ Music/ Cinema/ Sport/ Game

the user can select various sound effects.

Sound Effect

Option

Clear Voice ll

Virtual Surround

Equalizer

Balance

Reset

Synchronizes video and audio directly when they do not match. If you set AV Sync. to ON, you can adjust the sound output to the screen image.

Speaker

sound output faster and the "+" button slower than the default value.

Bypass

as it takes time to process video input into the Monitor.

function is available only for

: Adjusts the synchronization of the sound from the speakers. The "-" button makes the

: The audio of an external device without audio delay. Audio may be output before video

BACK

Suitable for all types of video.

Sets audio optimized for a specific genre.

Boosts voice clarity.

LG’s proprietary audio processing technology allows 5.1ch-like surround sound from two speakers.

Clear Voice ll

- If

Adjusts the volume to a level of your choice using the Equalizer.

Adjusts left/right audio balance.

You can reset the settings under the Sound Effects menu.

is set to On,

Standard

AUDIO

• Sound Mode : Standard

• Sound Effect

• AV Sync. Adjust : Off

mode in

Virtual Surround

Sound Mode

menu.

will not be chosen.

Move

NOTE

Some models may not have built-in speakers. In that case, you need to connect external speakers to



listen to sound.

CUSTOMIZING SETTINGS

TIME Settings

Press

Press the navigation buttons to scroll to

Press the navigation buttons to scroll to the setting or option

When you are finished, press

The available time settings are described in the following:

Clock

On/Off Time

Auto Off(15Min.)

Automatic Standby

SETTINGS

to access the main menus.

TIME

and press OK.

you want and press OK.

BACK

- To return to the previous level, press

EXIT

When you return to the previous menu, press

Setting Description

Sets the time feature.

Sets the time to turn on or off the monitor set.

If Auto-off is active and there is no input signal, the set switches to off mode automatically after 15 minutes.

If the monitor is left unattended for a set period of time, it automatically goes into standby mode.

TIME

• Clock

• Off Time : Off

• On Time : Off

• Auto Off(15Min.) : Off

• Automatic Standby : Off

Move OK

ENGLISH

ENG

NOTE

Off Time/ On Time can be saved for up to seven schedules; the monitor is turned on or off at the preset



time in the schedule list. If multiple preset times are stored in the schedule list, this function works at the nearest time from the current time. Once the on or off time is set, these functions operate daily at the preset time.



When the scheduled power-on and power-off times are the same, the power-off time has priority over the



power-on time if the set is turned on, and vice versa if the set is turned off.

CUSTOMIZING SETTINGS

OPTION Settings

ENGLISH

ENG

The available option settings are described in the following:

OPTION

• Language

• Country

• ISM Method : Normal

• DivX(R) VOD

• Initial Setting

• Set ID : 1

• Tile Mode

SETTINGS

to access the main menus.

OPTION

and press

Press

Press the navigation buttons to scroll to

Press the navigation buttons to scroll to the setting or option

you want and press OK.

- To return to the previous level, press

When you are finished, press

EXIT

When you return to the previous menu, press

Setting Description

Language Selects a language for the display text.

Country Select your country.

ISM Method This function removes image sticking which is caused by prolonged display of static images.

Option

Normal Minimizes image sticking by gradually lowering the brightness when

Color Wash Removes image sticking by moving every pixel in a certain pattern on the

DivX(R) VOD Registers or releases DivX.

Initial Setting Deletes all optional settings and returns to initial default mode.

Set ID You can assign a unique Set ID NO (name assignment) to each product when several products

Tile Mode Tile Mode To use this function

Checks DivX Registration Code for playing DivX-protected videos. Register at http://vod.divx.com. Uses Registration Code to rent or purchase movies at www.divx.com/vod. * Rented/purchased DivX files cannot be played if the DivX Registration Code of a different device is used. Use only the DivX Registration Code granted to this device. * Converted files not conforming to the DivX Codec Standard may not play or may produce abnormal images.

are connected for display. Specify the number (1 to 255 or 1 to 1,000) using the button and exit. Use the assigned Set ID to individually control each product using the Product Control Program.

Auto Config. Sets to adjust the screen position, clock, and phase automatically.

Position Moving the screen position horizontally and vertically.

Size Adjust the horizontal and vertical size of the screen taking into account the size

Natural The image is omitted by the distance between the screens to be naturally

Reset Function to initialize and release Tile.

BACK

displaying static images and by increasing the brightness when displaying moving images.

screen for a specific period of time. Please use this function to remove temporary image sticking.

- Must be displayed with various other products.

- Select Tile Mode, set rows and columns, and then enter the tile ID to set the location.

- Tile Mode: row x column (row = 1-15, column = 1-15).

- 15 x 15 available.

The displayed image may be unstable for a few seconds while the configuration is in progress.

of the bezel.

shown.

All Tile setting are released when selecting Tile recall and the screen returns to Full screen.

Natural

is not initialized.

Move OK

CUSTOMIZING SETTINGS

NETWORK Settings

Press

Press the navigation buttons to scroll to

Press the navigation buttons to scroll to the setting or option

When you are finished, press

The available option settings are described in the following:

Network Setting Configure the network settings.

Network Status Display the network status.

SETTINGS

to access the main menus.

NETWORK

and

press OK.

you want and press OK.

- To return to the previous level, press

EXIT

When you return to the previous menu, press

Setting Description

Network setting When the Wi-Fi dongle is connected, you can view and connect to any

BACK

available wireless network.

NETWORK

• Network Setting

• Network Status

Move OK

ENGLISH

ENG

Network Connection Options

Setting Description

Setting from the AP list Select an AP to connect to a wireless network.

Simple setting (WPSbutton mode)

Press the button on the wireless router that supports PBC to easily connect to the router.

ENGLISH

ENG

This monitor can be tiled with additional monitors to create a large tiled display.

CUSTOMIZING SETTINGS

Tile Mode

Off

When the Tile Mode

option is disabled

4X4

When using 16 monitors

ID 1

ID 5

ID 9

ID 13

ID 2

ID 6

ID 10

ID 14

ID 3

ID 7

ID 11

ID 15

1X2

When using 2 monitors

ID 1

ID 2

Tile ID

ID 4

ID 8

ID 12

ID 16

2X2

When using 4 monitors

ID 3

ID 2

ID 4

ID 1

5X5

When using 25 monitors

ID 3

ID 2

ID 1

ID 8

ID 7

ID 6

ID 13

ID 12

ID 11

ID 17

ID 22

ID 18

ID 23

ID 16

ID 21

ID 4 ID 5

ID 9 ID 10

ID 14 ID 15

ID 19

ID 20

ID 24

ID 25

3X3

When using 9 monitors

ID 1

ID 4

ID 7

ID 2

ID 5

ID 8

ID 3

ID 6

ID 9

Tile Mode - Natural mode

When active, the part of the image that would normally be displayed in the gap between the monitors is omitted.

Before After

TROUBLESHOOTING

No image is displayed

Problem Resolution

Is the product power cord connected?

Does the Out of range message appear?

Does the Check signal cable message appear?

'Unknown Product' message appears when the product is connected.

Problem Resolution

Did you install the driver?  See if the plug&play function is supported by referring to the video

 See if the power cord is properly connected to the outlet.

 The signal from the PC (video card) is out of the vertical or horizontal

frequency range of the product. Adjust the frequency range by referring to the Specifications in this manual.

 The signal cable between PC and product is not connected. Check

the signal cable.

 Press the 'INPUT' menu in the remote Control to check the input

signal.

card user manual.

ENGLISH

ENG

The screen image looks abnormal.

Problem Resolution

Is the screen position wrong? D-Sub analog signal - Press the "AUTO" button in the remote control

to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, select [PICTURE] [Screen] - [Position] in OSD menu.

See if the video card resolution and frequency are supported by the

product. If the frequency is out of range, set to the recommended resolution in the Control Panel "Display" Setting menu.

Do thin lines appear on the background screen?

Horizontal noise appears or the characters look blurred.

The screen is displayed abnormally.

D-Sub analog signal - Press the "AUTO" button in the remote control

to automatically select an optimal screen status that fits into the current mode. If adjustment is not satisfactory, select [PICTURE] [Screen] - [Size] in OSD menu.

D-Sub analog signal - Press the "AUTO" button in the remote control

to automatically select an optimal screen status that fits into the current mode. If adjustment is not satisfactory, select [PICTURE] [Screen] - [Phase] in OSD menu.

 The proper input signal is not connected to the signal port. Connect

the signal cable that matches with the source input signal.

ENGLISH

ENG

TROUBLESHOOTING

After-image appears on the product.

Problem Resolution

After-image appears when the product is turned off.

The audio function does not work.

Problem Resolution

No sound? See if the audio cable is connected properly.

Sound is too dull. Select the appropriate equalize sound.

Sound is too low.  Adjust the volume.

Screen color is abnormal.

If you use a fixed image for a long time, the pixels may be damaged

quickly. Use the screen-saver function.

When a dark image is displayed on the screen after an image with

high contrast (black and white or gray), this may cause image sticking. This is normal for LCD screen.

Adjust the volume.  See if the sound is set properly.

Problem Resolution

Screen has poor color resolution (16 colors).

Screen color is unstable or mono-colored.

Do black spots appear on the screen?

The operation does not work normally.

Problem Resolution

The power suddenly turned off. Is Off Timer set?

 Set the number of colors to more than 24 bits (true color) Select

Control Panel - Display - Settings - Color Table menu in Windows.

Check the connection status of the signal cable. Or, re-insert the PC

video card.

 Several pixels (red, green, white or black color) may appear on the

screen, which can be attributable to the unique characteristics of the LCD panel. It is not a malfunction of the LCD.

 Check the power control settings. Power interrupted.

SPECIFICATIONS

32LS33A

LCD Panel Screen Type

Pixel Pitch 0.36375 mm (H) x 0.36375 mm (V)

Video Signal Max. Resolution 1920 x 1080 @ 60 Hz

Recommended Resolution 1920 x 1080 @ 60 Hz

Horizontal Frequency RGB : 30 kHz to 83 kHz

Vertical Frequency RGB : 50 Hz to 75 Hz

Synchronization Type Separate Sync, Digital

Input Connector 15-pin D-Sub, HDMI, Audio In, Speaker Out, IR, USB,

Power Rated Voltage AC 100-240 V~ 50/60 Hz 1.3 A

Power Consumption On Mode : 45 W Typ.

Environmental conditions

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

80 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 80 cm

- It may not be supported depending on the OS or video card type.

HDMI : 30 kHz to 83 kHz

HDMI : 56 Hz to 60 Hz

RS-232C IN/OUT, LAN

Sleep Mode (RGB) : ≤ 0.5 W Sleep Mode (HDMI) : ≤ 0.7 W Off Mode : ≤ 0.5 W

0 °C to 40 °C 10 % to 80 %

-20 °C to 60 °C 5 % to 95 %

ENGLISH

ENG

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

SPECIFICATIONS

Dimensions (Width x Height x Depth) / Weight

730.9 mm x 430.1 mm x 55.5 mm / 5.6 kg

730.9 mm x 480.2 mm x 207 mm / 5.8 kg

730.9 mm x 430.1 mm x 105.1 mm / 6.4 kg

730.9 mm x 480.2 mm x 207 mm / 6.6 kg

* Applicable only for models that support the speakers

Audio RMS Audio Output 10 W + 10 W (R + L)

Input Sensitivity 0.7 Vrms

Speaker Impedance 8 Ω

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

42LS33A 42LS35A

SPECIFICATIONS

ENGLISH

ENG

LCD Panel Screen Type

Pixel Pitch 0.4833 mm (H) x 0.4833 mm (V)

Video Signal Max. Resolution 1920 x 1080 @ 60 Hz

Recommended Resolution 1920 x 1080 @ 60 Hz

Horizontal Frequency RGB : 30 kHz to 83 kHz

Vertical Frequency RGB : 50 Hz to 75 Hz

Synchronization Type Separate Sync, Digital

Input Connector 15-pin D-Sub, HDMI, Audio In, Speaker Out, IR, USB,

Power

42LS33A Rated Voltage AC 100-240 V~ 50/60 Hz 1.2 A

Power Consumption On Mode : 70 W Typ.

42LS35A Rated Voltage AC 100-240 V~ 50/60 Hz 1.2 A

Power Consumption On Mode : 75 W Typ.

Environmental conditions

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

106 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 106 cm

- It may not be supported depending on the OS or video card type.

HDMI : 30 kHz to 83 kHz

HDMI : 56 Hz to 60 Hz

RS-232C IN/OUT, LAN

Sleep Mode (RGB) : ≤ 0.5 W Sleep Mode (HDMI) : ≤ 0.7 W Off Mode : ≤ 0.5 W

0 °C to 40 °C 10 % to 80 %

-20 °C to 60 °C 5 % to 95 %

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

SPECIFICATIONS

Dimensions (Width x Height x Depth) / Weight

959.5 mm x 559 mm x 55.5 mm / 9.1 kg

959.5 mm x 610.8 mm x 218 mm / 9.3 kg

959.5 mm x 559 mm x 91 mm / 9.9 kg

959.5 mm x 610.8 mm x 218 mm / 10.1 kg

* Applicable only for models that support the speakers

Audio RMS Audio Output 10 W + 10 W (R + L)

Input Sensitivity 0.7 Vrms

Speaker Impedance 8 Ω

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

47LS33A 47LS35A

SPECIFICATIONS

ENGLISH

ENG

LCD Panel Screen Type

Pixel Pitch 0.5415 mm (H) x 0.5415 mm (V)

Video Signal Max. Resolution 1920 x 1080 @ 60 Hz

Recommended Resolution 1920 x 1080 @ 60 Hz

Horizontal Frequency RGB : 30 kHz to 83 kHz

Vertical Frequency RGB : 50 Hz to 75 Hz

Synchronization Type Separate Sync, Digital

Input Connector 15-pin D-Sub, HDMI, Audio In, Speaker Out, IR, USB,

Power

47LS33A Rated Voltage AC 100-240 V~ 50/60 Hz 1.3 A

Power Consumption On Mode : 73 W Typ.

47LS35A Rated Voltage AC 100-240 V~ 50/60 Hz 1.3 A

Power Consumption On Mode : 80 W Typ.

Environmental conditions

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

119 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 119 cm

- It may not be supported depending on the OS or video card type.

HDMI : 30 kHz to 83 kHz

HDMI : 56 Hz to 60 Hz

RS-232C IN/OUT, LAN

Sleep Mode (RGB) : ≤ 0.5 W Sleep Mode (HDMI) : ≤ 0.7 W Off Mode : ≤ 0.5 W

0 °C to 40 °C 10 % to 80 %

-20 °C to 60 °C 5 % to 95 %

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

SPECIFICATIONS

Dimensions (Width x Height x Depth) / Weight

1071 mm x 621.6 mm x 55.8 mm / 12.2 kg

1071 mm x 675.1 mm x 247 mm / 12.5 kg

1071 mm x 621.6 mm x 90.4 mm / 13.0 kg

1071 mm x 675.1 mm x 247 mm / 13.3 kg

* Applicable only for models that support the speakers

Audio RMS Audio Output 10 W + 10 W (R + L)

Input Sensitivity 0.7 Vrms

Speaker Impedance 8 Ω

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

55LS33A 55LS35A

SPECIFICATIONS

ENGLISH

ENG

LCD Panel Screen Type

Pixel Pitch 0.630 mm (H) x 0.630 mm (V)

Video Signal Max. Resolution 1920 x 1080 @ 60 Hz

Recommended Resolution 1920 x 1080 @ 60 Hz

Horizontal Frequency RGB : 30 kHz to 83 kHz

Vertical Frequency RGB : 50 Hz to 75 Hz

Synchronization Type Separate Sync, Digital

Input Connector 15-pin D-Sub, HDMI, Audio In, Speaker Out, IR, USB,

Power

55LS33A Rated Voltage AC 100-240 V~ 50/60 Hz 1.5 A

Power Consumption On Mode : 92 W Typ.

55LS35A Rated Voltage AC 100-240 V~ 50/60 Hz 1.5 A

Power Consumption On Mode : 95 W Typ.

Environmental conditions

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

139 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 139 cm

- It may not be supported depending on the OS or video card type.

HDMI : 30 kHz to 83 kHz

HDMI : 56 Hz to 60 Hz

RS-232C IN/OUT, LAN

Sleep Mode (RGB) : ≤ 0.5 W Sleep Mode (HDMI) : ≤ 0.7 W Off Mode : ≤ 0.5 W

0 °C to 40 °C 10 % to 80 %

-20 °C to 60 °C 5 % to 95 %

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

SPECIFICATIONS

Dimensions (Width x Height x Depth) / Weight

1240.9 mm x 717.2 mm x 56.8 mm / 17.8 kg

1240.9 mm x 770.8 mm x 247 mm / 18.1 kg

1240.9 mm x 717.2 mm x 91.4 mm / 18.6 kg

1240.9 mm x 770.8 mm x 247 mm / 18.9 kg

* Applicable only for models that support the speakers

Audio RMS Audio Output 10 W + 10 W (R + L)

Input Sensitivity 0.7 Vrms

Speaker Impedance 8 Ω

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

65LS33A

SPECIFICATIONS

ENGLISH

ENG

LCD Panel Screen Type

Pixel Pitch 0.744 mm (H) x 0.744 mm (V)

Video Signal Max. Resolution 1920 x 1080 @ 60 Hz

Recommended Resolution 1920 x 1080 @ 60 Hz

Horizontal Frequency RGB : 30 kHz to 83 kHz

Vertical Frequency RGB : 50 Hz to 75 Hz

Synchronization Type Separate Sync, Digital

Input Connector

Power Rated Voltage AC 100-240 V~ 50/60 Hz 2.0 A

Power Consumption On Mode : 145 W Typ.

Environmental conditions

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

164 cm Wide TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 164 cm

- It may not be supported depending on the OS or video card type.

HDMI : 30 kHz to 83 kHz

HDMI : 56 Hz to 60 Hz

15-pin D-Sub, HDMI, Audio In, Speaker Out, IR, USB, RS-232C IN/OUT, LAN

Sleep Mode (RGB) : ≤ 0.5 W Sleep Mode (HDMI) : ≤ 0.7 W Off Mode : ≤ 0.5 W

0 °C to 40 °C 10 % to 80 %

-20 °C to 60 °C 5 % to 95 %

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

SPECIFICATIONS

Dimensions (Width x Height x Depth) / Weight

1461.6 mm x 843 mm x 57.6 mm / 30.9 kg

1461.6 mm x 900.6 mm x 313 mm / 32.3 kg

1461.6 mm x 843 mm x 92.6 mm / 31.7 kg

1461.6 mm x 900.6 mm x 313 mm / 33.1 kg

* Applicable only for models that support the speakers

Audio RMS Audio Output 10 W + 10 W (R + L)

Input Sensitivity 0.7 Vrms

Speaker Impedance 8 Ω

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

Dimensions

The illustrations in this manual may differ from the actual product and accessories. Please see the Mounting on a Wall section for sizes of screws.

32LS33A

SPECIFICATIONS

(Unit : mm)

ENGLISH

ENG

14.6

430.1

18.6

121.7

265.4

730.9

200

55.5

38.5

15.1

480.2

207

200

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

The illustrations in this manual may differ from the actual product and accessories. Please see the Mounting on a Wall section for sizes of screws.

SPECIFICATIONS

Dimensions

(Unit : mm)

42LS33A 42LS35A

55.5

13.3

18.8

55.8

13.3

279.8

959.5

400

559

41.5

610.8

218

400

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

Dimensions

The illustrations in this manual may differ from the actual product and accessories. Please see the Mounting on a Wall section for sizes of screws.

47LS33A 47LS35A

SPECIFICATIONS

(Unit : mm)

ENGLISH

ENG

621.6

675.1

13.2

18.7

335.5

13.2

129

1071

400

55.8

40.8

247

400

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

ENGLISH

ENG

The illustrations in this manual may differ from the actual product and accessories. Please see the Mounting on a Wall section for sizes of screws.

SPECIFICATIONS

Dimensions

(Unit : mm)

55LS33A 55LS35A

13.218.7

13.2

420.5

224.6

1240.9

400

717.2

56.8

41.8

770.8

247

400

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

Dimensions

The illustrations in this manual may differ from the actual product and accessories. Please see the Mounting on a Wall section for sizes of screws.

65LS33A

SPECIFICATIONS

(Unit : mm)

ENGLISH

ENG

900.6

843

420.5

1461.6

400 530.8530.8

57.6

313

400164 278.5

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

SPECIFICATIONS

ENGLISH

ENG

RGB (PC) supported mode

Resolution

720 x 400

640 x 480

800 x 600

1024 x 768

1280 x 720

1280 x 960

1152 x 864

1280 x 1024

1920 x 1080

Horizontal Frequency(kHz)

31.468 70.8

31.469 59.94

37.879 60.317

48.363 60

44.772 59.855

60 60

57.717 59.934

63.981 60.02

67.5 60

HDMI (PC) supported mode

Vertical Frequency(Hz)

HDMI (DTV) supported mode

Resolution

480/60P

576/50P

720/50P

720/60P

1080/50i

1080/60i

1080/50P

1080/60P

Horizontal Frequency(kHz)

31.5 60

31.25 50

37.5 50

45 60

28.1 50

33.75 60

56.25 50

67.5 60

Vertical Frequency(Hz)

Resolution

640 x 480

800 x 600

1024 x 768

1280 x 720

1366 x 768

1280 x 1024

1680 x 1050

1920 x 1080

Horizontal Frequency(kHz)

31.469 59.94

37.879 60.317

48.363 60

44.772 59.855

47.7 60

63.981 60.02

65.290 59.954

67.5 60

Vertical Frequency(Hz)

NOTE

PC resolutions available as the input label



option in RGB and HDMI input mode : 640 x 480 / 60 Hz, 1280 x 720 / 60 Hz, 1920 x 1080 / 60 Hz and DTV resolutions : 480p, 720p, 1080p.

NOTE

Vertical frequency: To enable the user to



watch the product display, screen image should be changed tens of times every second like a fluorescent lamp. The vertical frequency or refresh rate is the times of image display per second. The unit is Hz. Horizontal frequency: The horizontal interval



is the time to display one vertical line. When 1 is divided by the horizontal interval, the number of horizontal lines displayed every second can be tabulated as the horizontal frequency. The unit is kHz.

IR CODES

All models do not support the HDMI/USB function.



Some key codes are not supported depending on the model.



Code (Hexa) Function Note

0B INPUT R/C BUTTON

C4 MONITOR ON R/C BUTTON

C5 MONITOR OFF R/C BUTTON

95 ENERGY SAVING ( ) R/C BUTTON

DC 3D R/C BUTTON

10 to 19 Number Key 0 to 9 R/C BUTTON

53 1/a/A R/C BUTTON

2F CLEAR R/C BUTTON

79 ARC R/C BUTTON

99 AUTO R/C BUTTON

09 MUTE R/C BUTTON

E0 BRIGHTNESS (Page UP) R/C BUTTON

E1 BRIGHTNESS (Page Down) R/C BUTTON

4D PSM R/C BUTTON

5F W.BAL R/C BUTTON

43 SETTINGS R/C BUTTON

40 Up ▲ R/C BUTTON

41 Down ▼ R/C BUTTON

07 Left ◄ R/C BUTTON

06 Right ► R/C BUTTON

3F S.MENU R/C BUTTON

44 OK R/C BUTTON

28 BACK R/C BUTTON

5B EXIT R/C BUTTON

7E R/C BUTTON

7B TILE (Tile Mode) R/C BUTTON

B1 R/C BUTTON

B0 R/C BUTTON

BA R/C BUTTON

8F R/C BUTTON

8E R/C BUTTON

72 Red Key (PICTURE ID ON) R/C BUTTON

71 Green Key (PICTURE ID OFF) R/C BUTTON

63 Yellow Key R/C BUTTON

61 Blue Key R/C BUTTON

Power

Volume

INFO

R/C BUTTON

ENGLISH

ENG

CONTROLLING THE MULTIPLE PRODUCT

ENGLISH

CONTROLLING THE MULTIPLE PRODUCT

ENG

Connecting the Cable

Connect the RS-232C cable as shown in the picture.

Use this method to connect several products to a single PC. You can control several products at a



time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 255 (or from 1 to 1,000) without being duplicated.



The RS-232C protocol is used for communication between the PC and product. You can turn the



product on/off, select an input source or adjust the OSD menu from your PC.

Monitor 1 Monitor 2Monitor 3Monitor 4

RS-232C Configurations

8-Wire Configurations (Cross-over RS-232C cable)

PC Set

DCD

RXD

TXD

GND

DTR

DSR

RTS

CTS

D-Sub 9 D-Sub 9

(Female) (Female)

DCD

TXD

RXD

GND

DSR

DTR

CTS

RTS

Communication Parameter

Baud Rate : 9600 BPS



Data Length : 8 bit



Parity Bit : None



Stop Bit : 1bit



Flow Control : None



Communication Code : ASCII code



Use a crossed (reverse) cable



RS-232C Cable (not included)

NOTE

When using 3-wire connections (non-



standard), an IR daisy chain cannot be used.

CONTROLLING THE MULTIPLE PRODUCT

Command Reference List

COMMAND

1 2

01 Power k a 00 to 01

02 Select input x b See [Select input]

03 Aspect ratio k c See [Aspect ratio]

04 Energy saving j q See [Energy saving]

05 Picture mode d x See [Picture mode]

06 Contrast k g 00 to 64

07 Brightness k h 00 to 64

08 Sharpness k k

09 Color k i 00 to 64

10 Tint k j 00 to 64

11 Color temperature x u 00 to 64

12 H position f q 00 to 64

13 V position f r 00 to 64

14 H size f s 00 to 64

15 Auto Config. j u 01

16 Balance k t 00 to 64

17 Sound Mode d y See [Sound mode]

18 Mute k e 00 to 01

19 Volume k f 00 to 64

20 Clock 1 (year/month/day) f a See [Clock 1]

21 Clock 2 (hour/minute/second) f x See [Clock 2]

22 Off time schedule f c 00 to 01

23 On time schedule f b 00 to 01

24 Off timer (repeat mode/time) f e See [Off timer]

25 On timer (repeat mode/time) f d See [On timer]

26 On timer input f u See [On timer input]

27 Automatic Standby m n 00 to 01

28 Auto off f g 00 to 01

29 Language f i See [Language]

30 ISM method j p See [ISM method]

31 Reset f k 00 to 02

32 Current temperature d n FF

33 Key m c See [Key]

34 Time elapsed d l FF

35 Product serial number f y FF

36 Software version f z FF

37 White balance red gain j m 00 to FE

38 White balance green gain j n 00 to FE

39 White balance blue gain j o 00 to FE

40 Backlight m g 00 to 64

41 Screen off k d 00 to 01

42 Tile Mode d d See [Tile Mode]

00 to 32

(Hexadecimal)

ENGLISH

ENG

DATA

ENGLISH

ENG

CONTROLLING THE MULTIPLE PRODUCT

COMMAND

1 2

43 Tile Mode Check d z FF

44 Tile ID d i Refer to ‘Tile ID'.

45 Tile H Position d e 00 to 32

46 Tile V Position d f 00 to 32

Tile H Size

48 Tile V Size d h 00 to 32

Natural Mode (In Tile mode)

d g

d j

00 to 32

00 to 01

DATA

(Hexadecimal)

NOTE

During USB operations such as Dvix or EMF, all commands except Power (k a) and Key (m c) are not



executed and treated as NG. Some commands are not supported depending on the model.



The ‘f f’ command which shows the status of a certain command does not display the OSD as the



result in order to be compatible with SuperSign program.

CONTROLLING THE MULTIPLE PRODUCT

Transmission / Receiving Protocol

Transmission

[Command1][Command2][ ][Set ID][ ][Data][Cr]

* [Command1] Identifies the factory setting and the user setting modes.

* [Command2] Controls monitors.

* [Set ID] Used for selecting a set you want to control. A Set ID can be assigned to each set from 1

to 255 (from 01H to FFH), or from 1 to 1,000 (from 001H to 3e8H) in certain models, under OPTION in the OSD menu. Selecting '00H' or '000H' for Set ID allows the simultaneous control of all connected monitors. (It may not be supported depending on the model.)

* [Data] Transmits command data.

Data count may increase depending on the command.

* [Cr] Carriage Return. Corresponds to '0x0D' in ASCII code.

* [ ] White Space. Corresponds to '0x20' in ASCII code.

Acknowledgement

[Command2][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

ENG

* The Product transmits an ACK (acknowledgement) based on this format when receiving normal data. At

this time, if the data is FF, it indicates the present status data. If the data is in data write mode, it returns the data of the PC computer.

* If a command is sent with Set ID '00' (=0x00) or '000 (=0x000)', the data is reflected to all monitor sets and

they do send any acknowledgement (ACK).

* If the data value 'FF' is sent in control mode via RS-232C, the current setting value of a function can be

checked (only for some functions).

* Some commands may not be supported on some models.

CONTROLLING THE MULTIPLE PRODUCT

01. Power (Command: k a)

ENGLISH

ENG

02. Select input (Command: x b)

Controls the power on/off of the set.

Transmission

[k][a][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[a][ ][Set ID][ ][OK/NG][Data][x]

* Only when the monitor is fully powered on, the acknowledgement signal is returned properly. * There may be a delay between the transmission and acknowledgement signals.

Selects an input signal.

Transmission

[x][b][ ][Set ID][ ][Data][Cr]

Data 60: RGB 90: HDMI (HDMI1) (DTV) A0: HDMI (HDMI1) (PC)

Acknowledgement

[b][ ][Set ID][ ][OK/NG][Data][x]

* Some input signals may not be supported on some models.

04. Energy saving (Command: j q)

Sets the energy saving function.

Transmission

[j][q][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: Minimum 02: Medium 03: Maximum 04: Automatic 05: Screen off

Acknowledgement

[q][ ][Set ID][ ][OK/NG][Data][x]

** This may not be supported on some models.

05. Picture mode (Command: d x)

Selects a picture mode.

Transmission

[d][x][ ][Set ID][ ][Data][Cr]

Data 00: Vivid 01: Standard 02: Cinema 03: Sport 04: Game 05: Expert 1 06: Expert 2 08: Eco

Acknowledgement

[x][ ][Set ID][ ][OK/NG][Data][x]

03. Aspect ratio (Command: k c)

Adjusts the aspect ratio.

Transmission

[k][c][ ][Set ID][ ][Data][Cr]

Data 01: 4:3 02: 16:9 04: Zoom (HDMI)(DTV) 06: Auto ratio (HDMI)(DTV)

09: Original (≥ 720p) (HDMI) (DTV)

10 to 1F: Cinema zoom 1 to 16 (HDMI) (DTV) * Available data types differ depending on the input signal. For more information, see the aspect ratio section of the owner's manual. * The aspect ratio may differ depending on the model's input configuration.

Acknowledgement

[c][ ][Set ID][ ][OK/NG][Data][x]

06. Contrast (Command: k g)

Adjusts the screen contrast.

Transmission

[k][g][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Contrast 0 to 100

Acknowledgement

[g][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

07. Brightness (Command: k h)

Adjusts the screen brightness.

Transmission

[k][h][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Brightness 0 to 100

Acknowledgement

[h][ ][Set ID][ ][OK/NG][Data][x]

08. Sharpness (Command: k k)

Adjusts the screen sharpness.

Transmission

[k][k][ ][Set ID][ ][Data][Cr]

Data 00 to 32: Sharpness 0 to 50

Acknowledgement

[k][ ][Set ID][ ][OK/NG][Data][x]

10. Tint (Command: k j)

Adjusts the screen tint.

Transmission

[k][j][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Tint red 50 to green 50

Acknowledgement

[j][ ][Set ID][ ][OK/NG][Data][x]

11. Color temperature (Command: x u)

Adjusts the screen color temperature.

Transmission

[x][u][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Warm 50 to cool 50

Acknowledgement

[u][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

ENG

09. Color (Command: k i)

Adjusts the screen color.

Transmission

[k][i][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Color 0 to 100

Acknowledgement

[i][ ][Set ID][ ][OK/NG][Data][x]

12. H position (Command: f q)

Adjusts the horizontal position of the screen. This function is only available when the Tile Mode is set to Off. * The operational range varies depending on the RGB input resolution. (Only available in RGB-PC input mode)

Transmission

[f][q][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Min -50 (left) to max 50 (right)

Acknowledgement

[q][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

13. V position (Command: f r)

ENGLISH

ENG

14. H size (Command: f s)

Adjusts the vertical position of the screen. This function is only available when the Tile Mode is set to Off. * The operational range varies depending on the RGB input resolution. (Only available in RGB-PC input mode)

Transmission

[f][r][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Min -50 (down) to max 50 (up)

Acknowledgement

[r][ ][Set ID][ ][OK/NG][Data][x]

Adjusts the horizontal size of the screen. This function is only available when the Tile Mode is set to Off. * The operational range varies depending on the RGB input resolution. (Only available in RGB-PC input mode)

Transmission

[f][s][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Min -50 (small) to max 50 (large)

Acknowledgement

[s][ ][Set ID][ ][OK/NG][Data][x]

16. Balance (Command: k t)

Adjusts the sound balance.

Transmission

[k][t][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Left 50 to right 50

Acknowledgement

[t][ ][Set ID][ ][OK/NG][Data][x]

17. Sound mode (Command: d y)

Selects a sound mode.

Transmission

[d][y][ ][Set ID][ ][Data][Cr]

Data 01: Standard 02: Music 03: Cinema 04: Sport

05. Game

07. News

Acknowledgement

[y][ ][Set ID][ ][OK/NG][Data][x]

15. Auto Config. (Command: j u)

Automatically corrects position and shaking of the picture. (Only available in RGB-PC input mode)

Transmission

[j][u][ ][Set ID][ ][Data][Cr]

Data 01: Execution

Acknowledgement

[u][ ][Set ID][ ][OK/NG][Data][x]

18. Mute (Command: k e)

Mutes/unmutes the sound.

Transmission

[k][e][ ][Set ID][ ][Data][Cr]

Data 00: Mute 01: Unmute

Acknowledgement

[e][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

19. Volume (Command: k f)

Adjusts the playback volume.

Transmission

[k][f][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Volume 0 to 100

Acknowledgement

[f][ ][Set ID][ ][OK/NG][Data][x]

20. Clock 1 (year/month/day) (Command: f a)

Adjusts the Clock 1 (year/month/day) value.

Transmission

[f][a][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1 00 to 14: Year 2010 to 2040 Data2 01 to 0C: January to December Data3 01 to 1F: 1st to 31st * Enter "fa [Set ID] ff" to view the Clock 1 (year/ month/day) settings.

Acknowledgement

[a][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

22. Off time schedule (Command: f c)

Enables/disables the on time schedule.

Transmission

[f][c][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[c][ ][Set ID][ ][OK/NG][Data][x]

23. On time schedule (Command: f b)

Enables/disables the on time schedule.

Transmission

[f][b][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[b][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

ENG

21. Clock 2 (hour/minute/second) (Command: f x)

Adjusts the Clock 2 (hour/minute/second) value.

Transmission

[f][x][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1 00 to 17: 00 to 23 hours Data2 00 to 3B: 00 to 59 minutes Data3 00 to 3B: 00 to 59 seconds * Enter "fa [Set ID] ff" to view the Clock 2 (hour/minute/second) settings. ** This function is only available when Clock 1 (year/ month/day) is set.

Acknowledgement

[x][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

CONTROLLING THE MULTIPLE PRODUCT

24. Off timer (repeat mode/time) (Command: f e)

ENGLISH

ENG

Configures the off time (repeat mode/time) settings.

Transmission

[f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1

1. F1 to F7 (reading data) F1: Read the 1st off timer data F2: Read the 2nd off timer data F3: Read the 3rd off timer data F4: Read the 4th off timer data F5: Read the 5th off timer data F6: Read the 6th off timer data F7: Read the 7th off timer data

2. E1 to E7 (deleting one index), E0 (deleting all indexes) E0: Erase all off timer setting E1: Erase the 1st off timer setting E2: Erase the 2nd off timer setting E3: Erase the 3rd off timer setting E4: Erase the 4th off timer setting E5: Erase the 5th off timer setting E6: Erase the 6th off timer setting E7: Erase the 7th off timer setting

3. 01 to 0C (setting the day of the week for off timer) 01: Once

02. Daily 03: Mon - Fri 04: Mon - Sat 05: Sat - Sun

06. Every Sunday

07. Every Monday

08. Every Tuesday

09. Every Wednesday 0A. Every Thursday 0B. Every Friday 0C. Every Saturday Data2 00 to 17: 00 to 23 hours Data3 00 to 3B: 00 to 59 minutes * To read or delete the Off Time list, set FFH for [Data2] and [Data3]. Example 1: fe 01 f1 ff ff - Read the 1st index data from off timer. Example 2: fe 01 e1 ff ff - Delete the 1st index data from off timer. Example 3: fe 01 04 02 03 - Sets Off Timer to 02:03 for Monday-Saturday. * This function is only available when Clock 1 (year/ month/day) and Clock 2 (hour/minute/second) are set.

Acknowledgement

[e][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

25. On timer (repeat mode/time) (Command: f d)

Configures the on time (repeat mode/time) settings.

Transmission

[f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1

1. F1 to F7 (reading data) F1: Read the 1st on timer data F2: Read the 2nd on timer data F3: Read the 3rd on timer data F4: Read the 4th on timer data F5: Read the 5th on timer data F6: Read the 6th on timer data F7: Read the 7th on timer data

2. E1 to E7 (deleting one index), E0 (deleting all indexes) E0: Erase all on timer setting E1: Erase the 1st on timer setting E2: Erase the 2nd on timer setting E3: Erase the 3rd on timer setting E4: Erase the 4th on timer setting E5: Erase the 5th on timer setting E6: Erase the 6th on timer setting E7: Erase the 7th on timer setting

3. 01 to 0C (setting the day of the week for the on timer) 01: Once

02. Daily 03: Mon - Fri 04: Mon - Sat 05: Sat - Sun

06. Every Sunday

07. Every Monday

08. Every Tuesday

09. Every Wednesday 0A. Every Thursday 0B. Every Friday 0C. Every Saturday Data2 00 to 17: 00 to 23 hours Data3 00 to 3B: 00 to 59 minutes * To read or delete an on timer list you have set, [Data2][Data3] must be set to FFH. Example 1: fd 01 f1 ff ff - Read the 1st index data from on timer. Example 2: fd 01 e1 ff ff - Delete the 1st index data from on timer. Example 3: fd 01 04 02 03 - Set on timer at 02:03 on Monday to Saturday. * This function is only available when Clock 1 (year/ month/day) and Clock 2 (hour/minute/second) are set.

Acknowledgement

[d][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

CONTROLLING THE MULTIPLE PRODUCT

26. On timer input (Command: f u)

Adds a new schedule entry by selecting input for the current on timer setting.

Transmission

[f][u][ ][Set ID][ ][Data1][Cr]

[f][u][ ][Set ID][ ][Data1][Data2][Cr]

Data (adding schedule) 60: RGB 90: HDMI (HDMI1)

Data1

1. f1h to f7h (reading data) F1: Select the 1st schedule input source F2: Select the 2nd schedule input source F3: Select the 3rd schedule input source F4: Select the 4th schedule input source F5: Select the 5th schedule input source F6: Select the 6th schedule input source F7: Select the 7th schedule input source

Data2

1. ffh (reading data) To read the schedule input, enter FFH for [Data2]. If no schedule is available for [Data1] when attempting to read or change the schedule data, the text NG will be displayed and the operation will fail. (Example 1: fu 01 60 - Move existing schedule entries down one row each and save RGB as input source for the 1st schedule entry.) (Example 2: fu 01 f1 ff - Read the 1st schedule input data.) * This function is only supported when 1 (year/month/ date), 2 (hour/minute/second) and On Time (repeat mode/time) are set. ** Input may not be supported on some models.

Acknowledgement

[u][ ][Set ID][ ][OK/NG][Data][x]

[u][ ][Set ID][ ][OK/NG][Data1][Data2][x]

28. Auto off (Command: f g)

Configures the automatic off settings.

Transmission

[f][g][ ][Set ID][ ][Data][Cr]

Data 00: Off (Will not turn off after 15 minutes) 01: On (Off after 15 minutes)

Acknowledgement

[g][ ][Set ID][ ][OK/NG][Data][x]

29. Language (Command: f i)

Sets the OSD language.

Transmission

[f][i][ ][Set ID][ ][Data][Cr]

Data 00: Czech 01: Danish 02: German 03: English 04: Spanish (Europe) 05: Greek 06: French 07: Italian 08: Dutch 09: Norwegian 0A: Portuguese 0B: Portuguese (Brazil) 0C: Russian 0D: Finnish 0E: Swedish 0F: Korean 10: Chinese (Cantonese) 11: Chinese (Mandarin)

Acknowledgement

[i][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

ENG

27. Automatic standby (Command: m n)

Configures the automatic standby settings.

Transmission

[m][n][ ][Set ID][ ][Data][Cr]

Data 00: Off (Will not turn off after 4/6/8 hours) 01: 4 hours (Off after 4 hours) 02: 6 hours (Off after 6 hours) 03: 8 hours (Off after 8 hours)

Acknowledgement

[n][ ][Set ID][ ][OK/NG][Data][x]

30. ISM method (Command: j p)

Selects an ISM Method option.

Transmission

[j][p][ ][Set ID][ ][Data][Cr]

Data 08: Standard 20: Color wash

Acknowledgement

[p][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

31. Reset (Command: f k)

ENGLISH

ENG

32. Current temperature (Command: d n)

Resets settings for Picture, Screen and Audio or restores factory settings. (Screen reset can only be performed in RGB input mode.)

Transmission

[f][k][ ][Set ID][ ][Data][Cr]

Data 00: Picture reset 01: Screen reset 02: Initial settings (factory reset)

Acknowledgement

[k][ ][Set ID][ ][OK/NG][Data][x]

Checks the inside temperature value.

Transmission

[d][n][ ][Set ID][ ][Data][Cr]

Data FF: Check status

Acknowledgement

[n][ ][Set ID][ ][OK/NG][Data][x]

[n][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

* Temperature is displayed as a hexadecimal value.

34. Time elapsed (Command: d l)

Checks the elapsed time.

Transmission

[d][l][ ][Set ID][ ][Data][Cr]

Data FF: Read status

Acknowledgement

[l][ ][Set ID][ ][OK/NG][Data][x]

* The data received is shown as a hexadecimal value.

35. Product serial number (Command: f y)

Checks the serial number of the product.

Transmission

[f][y][ ][Set ID][ ][Data][Cr]

Data FF: Check product serial number

Acknowledgement

[y][ ][Set ID][ ][OK/NG][Data][x]

* Data is in ASCII code.

33. Key (Command: m c)

Sends a key code for the IR remote control.

Transmission

[m][c][ ][Set ID][ ][Data][Cr]

Data IR_KEY_CODE

Acknowledgement

[c][ ][Set ID][ ][OK/NG][Data][x]

For key codes, see IR Codes. * Some key codes may not be supported on some models.

36. Software version (Command: f z)

Checks the software version of the product.

Transmission

[f][z][ ][Set ID][ ][Data][Cr]

Data FF: Check software version

Acknowledgement

[z][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

37. White balance red gain (Command: j m)

Adjusts the white balance red gain value.

Transmission

[j][m][ ][Set ID][ ][Data][Cr]

Data 00 to FE: Red gain 0 to 254

Acknowledgement

[m][ ][Set ID][ ][OK/NG][Data][x]

38. White balance green gain (Command: j n)

Adjusts the white balance green gain value.

Transmission

[j][n][ ][Set ID][ ][Data][Cr]

Data 00 to FE: Green gain 0 to 254

Acknowledgement

[n][ ][Set ID][ ][OK/NG][Data][x]

40. Backlight (Command: m g)

Adjusts the back light brightness.

Transmission

[m][g][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Back light brightness 0 to 100

Acknowledgement

[g][][set ID][][OK/NG][Data][x]

** This may not be supported on some models.

41. Screen off (Command: k d)

Turns the screen on or off.

Transmission [k][d][ ][Set ID][ ][Data][Cr]

Data 00: Turns the screen on 01: Turns the screen off

Acknowledgement

[d][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

ENG

39. White balance blue gain (Command: j o)

Adjusts the white balance blue gain value.

Transmission

[j][o][ ][Set ID][ ][Data][Cr]

Data 00 to FE: Blue gain 0 to 254

Acknowledgement

[o][ ][Set ID][ ][OK/NG][Data][x]

42. Tile Mode (Command: d d)

To set a Tile Mode and Tile Column/ Row values.

Transmission

[d][d][ ][Set ID][ ][Data][Cr]

Data 00 to FF: 1st byte - Tile Row 2nd byte - Tile Column *00, 01, 10, 11 means Tile Mode Off ** It may not be supported depending on the model.

Acknowledgement

[d][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

43. Tile Mode Check (Command: d z)

ENGLISH

ENG

44. Tile ID (Command: d i)

To check Tile Mode status.

Transmission

[d][z][ ][Set ID][ ][Data][Cr]

Data FF: Check Tile Mode status. ** It may not be supported depending on the model.

Acknowledgement

[z][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

Data1 00: Tile Mode Off 01: Tile Mode On Data2 00 to 0F: Tile Row Data3 00 to 0F: Tile Column

To set Tile ID.

Transmission

[d][i][ ][Set ID][ ][Data][Cr]

Data 01 to E1: Tile ID 01 to 225** FF: Check Tile ID ** Data could not be set over (Tile Column) x (Tile Row). ** It may not be supported depending on the model.

Acknowledgement

[i][ ][Set ID][ ][OK/NG][Data][x]

*NG will be return if data is over (Tile Column) x (Tile Row), except 0xFF.

46. Tile V Position (Command: d f)

To adjust the Tile Vertical position. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][f][ ][Set ID][ ][Data][Cr]

Data 0 to 32: 0 (Bottom) to 50 (Top) * Bottom/Top values depend on Tile Vertical size. ** It may not be supported depending on the model.

Acknowledgement

[f][ ][Set ID][ ][OK/NG][Data][x]

47. Tile H Size (Command: d g)

To adjust the Tile Horizontal Size. *Set Tile H Position to 0x32 before setting Tile H Size. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][g][ ][Set ID][ ][Data][Cr]

Data 00 to 32: 0 to 50 ** It may not be supported depending on the model.

Acknowledgement

[g][ ][Set ID][ ][OK/NG][Data][x]

45. Tile H Position (Command: d e)

To adjust the Tile Horizontal position. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][e][ ][Set ID][ ][Data][Cr]

Data 00 to 32: -50 (Left) to 0 (Right) *Left/Right values depend on Tile H size. ** It may not be supported depending on the model.

Acknowledgement

[e][ ][Set ID][ ][OK/NG][Data][x]

48. Tile V Size (Command: d h)

To adjust the Tile Vertical size. *Set Tile V Position to 0x00 before setting Tile V Size. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][h][ ][Set ID][ ][Data][Cr]

Data 00 to 32: 0 to 50 ** It may not be supported depending on the model.

Acknowledgement

[h][ ][Set ID][ ][OK/NG][Data][x]

CONTROLLING THE MULTIPLE PRODUCT

49. Natural Mode (In Tile Mode) (Command : d j)

To display the image naturally, the part of the image that would normally be displayed in the gap between the monitors is omitted.

Transmission

[d][j][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[j][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

ENG

NOTE

ENERGY STAR(EPA) can not be supported



in 65LS33A model.

Make sure to read the Safety Precautions before using the product. Keep the Owner's Manual (CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service.

To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http:// opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the product.

WARNING

environment this product may cause radio interference in which case the user may be required to take adequate measures.

-This is a class A product. In a domestic

MODEL

SERIAL

Temporary noise is normal when powering ON or OFF this device.

LG 42LS33A-5B, 65LS33A-5B, 32LS33A-5D, 47LS33A-5B User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

LICENSES

ASSEMBLING AND PREPARING

Accessories

Optional Accessories

Parts and Buttons

Connecting the Stand

Connecting the Speaker

Using the IR Receiver

Portrait Layout

Mounting on a Wall

REMOTE CONTROL

MAKING CONNECTIONS

RGB Connection

HDMI Connection

IR Receiver Connection

LAN ConnectionUSB Connection

USING THE MONITOR

Using the Input List

Adjusting Aspect Ratio

ENTERTAINMENT

Using the Network

Connecting to a Network

Using the My Media

Connecting USB storage devices

Network Status

Browsing Files

Viewing Movies

Viewing Photos

Listening to Music

Viewing the Contents List

CUSTOMIZING SETTINGS

Accessing Main Menus

PICTURE Settings

AUDIO Settings

TIME Settings

OPTION Settings

NETWORK Settings

TROUBLESHOOTING

SPECIFICATIONS

IR CODES

CONTROLLING THE MULTIPLE PRODUCT

Connecting the Cable

RS-232C Configurations

Communication Parameter

Command Reference List

Transmission / Receiving Protocol
