Lodging Guest Interactive Pro:Centric ® TVs
Commercial Mode Setup Guide
Note: Selected features shown in this guide may not be available on all models.
EXPERIENCED INSTALLER
EZ-Manager Wizard
pages 12 – 18
© Copyright 2015 LG Electronics U.S.A., Inc.
Custom Master TV Setup
pages 32 – 34
Cloning Procedures
pages 35 – 38
P/N: 206-4278 (Rev C)
For Customer Support/Service, please call:
1-888-865-3026
The latest product information and documentation is
available online at:
www.LGsolutions.com
MODEL and SERIAL NUMBER
The model and serial numbers of this TV are located on the
back of the cabinet. For future reference, LG suggests that you
record those numbers here:
Model No._________________ Serial No._______________
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
This product contains chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
POWER CORD POLARIZATION:
This product is equipped with a 3-wire grounding-type alternating current power plug. This plug will fit into the power
outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the 3-wire grounding-type plug.
NOTE TO CABLE/TV INSTALLER:
This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electrical Code
(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of the cable entry as practical.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc.
Unauthorized modification could void the user’s authority to operate this product.
COMPLIANCE:
The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc.
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632, USA • Phone: 1-201-816-2000
Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632
2
© Copyright 2015 LG Electronics U.S.A., Inc.
206-4278
IMPORTANT SAFETY INSTRUCTIONS
PORTABLE CART WARNING
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources, such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where it exits from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination in order to avoid injury from
tip-over.
13.
Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
14. Never touch this apparatus or antenna during a thunder or
lightning storm.
15. When mounting a TV on the wall, make sure not to install
the TV by the hanging power and signal cables on the back
of the TV.
16. Do not allow an impact shock or any objects to fall into the
product, and do not drop objects onto the screen.
17. Power Cord
Caution: It is recommended that appliances be placed
upon a dedicated circuit; that is, a single outlet circuit
which powers only that appliance and has no additional
outlets or branch circuits. Check the TV specifications.
Periodically examine the cord of your appliance, and if its
appearance indicates damage or deterioration, unplug it,
discontinue use of the appliance, and have the cord replaced
with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse,
such as twisting, kinking, or pinching or being closed in a
door or walked upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the appliance.
Do not use a damaged or loose power cord. Be sure to grasp
the plug when unplugging the power cord. Do not pull on the
power cord to unplug the TV.
18. Overloading
Do not connect too many appliances to the same AC power
outlet as this could result in fire or electric shock. Do not
overload wall outlets. Overloaded wall outlets, loose or
damaged wall outlets, extension cords, frayed power cords,
or damaged or cracked wire insulation are dangerous. Any of
these conditions could result in re or electric shock.
19. Outdoor Use/Wet Location
Warning: To reduce the risk of re or electrical
shock, do not expose this product to rain,
moisture or other liquids.
Do not touch the TV with wet hands. Do not install this product
near ammable objects such as gasoline or candles or expose
the TV to direct air conditioning.
Do not expose to dripping or splashing and do not place
objects lled with liquids, such as vases, cups, etc., on or over
the apparatus (e.g., on shelves above the unit).
20. Grounding
Ensure that you connect the earth ground wire to prevent
possible electric shock (i.e., a TV with a three-prong grounded
AC plug must be connected to a three-prong grounded AC
outlet). If grounding methods are not possible, have a qualied
electrician install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone wires, lightning
rods, or gas pipes.
21. Disconnect Device
The mains plug is the disconnecting device. The plug must
remain readily operable.
As long as this unit is connected to the AC wall outlet, it is not
disconnected from the AC power source even if you turn off
this unit by SWITCH.
(Continued on next page)
206-4278
3
IMPORTANT SAFETY INSTRUCTIONS
(Continued from previous page)
22. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, follow the precautions below.
An outdoor antenna system should not be located in the
vicinity of overhead power lines or other electric light or power
circuits or where it can come into contact with such power
lines or circuits as death or serious injury can occur.
Be sure the antenna system is grounded so as to provide
some protection against voltage surges and built-up static
charges.
Article 810 of the National Electrical Code (NEC) in the U.S.A.
provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna-discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
Antenna Grounding According to NEC, ANSI/NFPA 70
Ground Clamp
Electric Service
Equipment
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
23. Cleaning
When cleaning, unplug the power cord and wipe gently with
a soft cloth to prevent scratching. Do not spray water or other
liquids directly on the TV as electric shock may occur. Do not
clean with chemicals such as alcohol, thinners or benzene.
24. Transporting Product
Make sure the TV is turned Off and unplugged and that all
cables have been removed. It may take two or more people
to carry larger TVs. Do not press against or put stress on the
front panel of the TV during transport.
25. Ventilation
Install the TV where there is proper ventilation. Do not install
in a conned space such as a bookcase. Do not cover the TV
with cloth or other materials (e.g., plastic) while it is plugged
in. Do not install in excessively dusty places.
26. Do not touch the ventilation openings, as they may become
hot while the TV is operating.
27. If you smell smoke or other odors coming from the TV or
hear strange sounds, unplug the power cord, and contact an
authorized service center.
28. Do not press against the front panel of the TV with your
hand or a sharp object (e.g., a nail, pencil, or pen) or make a
scratch on it.
29. Keep the product away from direct sunlight.
30. Dot Defect
The LCD panel is a high technology product with resolution
of two million to six million pixels. In a very few cases, you
could see ne dots on the screen while you are viewing the
TV. Those dots are deactivated pixels and do not affect the
performance and reliability of the TV.
31. Generated Sound
“Cracking”: A cracking noise that occurs while the TV is
On or when it is turned Off is generated by plastic thermal
contraction due to temperature and humidity. This noise is
common for products where thermal deformation is required.
Electrical circuit humming/panel buzzing: A low level noise is
generated from a high-speed switching circuit, which supplies
a large amount of current to operate a product. It varies
depending on the product. This generated sound does not
affect the performance and reliability of the product.
32. For LCD TV
If the TV feels cold to the touch, there may be a small “icker”
when it is turned On. This is normal; there is nothing wrong
with the TV. Some minute dot defects may be visible on the
screen, appearing as tiny red, green, or blue spots. However,
they have no adverse effect on the TV’s performance. Avoid
touching the LCD screen or holding your nger(s) against it for
long periods of time. Doing so may produce some temporary
distortion effects on the screen.
4
206-4278
Table of Contents
Safety Warnings .................................. 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3 – 4
Table of Contents ................................. 5
Commercial Mode Overview .....................6 – 9
Setup Checklist ................................. 6
Pass-through Mode.............................. 6
FTG Mode..................................... 7
Determining the TV Operating Mode ................ 9
Pro:Centric Operation ........................10 – 11
Pro:Centric Interactive Menu Features .............. 10
Pro:Centric Interactive Menu Navigation ............ 10
Pro:Centric Setup ...............................11
EZ-Manager Wizard ..........................12
Before You Begin .............................. 12
Initiate Configuration or Exit the EZ-Manager Wizard .. 12
TV Configuration Options.......................... 13
Zone and Room Number Assignments .............. 14
Configure Pro:Centric Settings .................... 15
USB Configuration ............................. 18
Ez Download Utility ..........................19
Before You Begin .............................. 19
Accessing and Using the Ez Download Utility ........ 19
Installer Menu ...............................22 – 31
Accessing the Installer Menu ..................... 22
Using the Installer Menu ......................... 23
Exiting the Installer Menu and Activating Settings ..... 23
Custom Master TV Setup......................32
Before You Begin .............................. 32
Clonable TV Setup Menu Features ................ 32
Custom Master TV Setup Procedure ............... 33
Cloning Procedures ..........................35
Exporting a Clone File .......................... 35
Importing a Clone File........................... 36
FTG File Manager Utilities Overview ............39 – 44
Creating an FTG Configuration File ................ 39
FTG File Manager Main Screen ................... 41
– 18
– 21
– 34
–
38
FTG Channel Map Configuration Utility ............. 42
FTG Channel Map Editor ........................ 43
FTG Installer Menu Configuration Utility............. 44
IP Environment Setup ........................45 – 48
Accessing the IP Environment Menu ............... 45
Configuring the Network Connection ............... 45
Network Status ................................ 46
Pro:Centric Setup .............................. 47
References
Remote Jack Pack / TV Connections & Setup ......... 49
Updating TV/PTC Software using a USB Memory
Device......................................... 50
Downloading a Splash Screen Image using a USB
Memory Device ................................. 51
Power Consumption Settings....................52 – 53
TV Aux Input Configuration ........................ 54
b-LAN Setup & Overview .......................... 55
FTG Mode via EBL (Local Configuration) ............. 56
Auto Input(s) Sensing Feature ...................57 – 58
RJP Model List & Input Auto-sensing Hierarchy ........ 59
Restoring Factory Defaults on the TV(s) .............. 60
Using the TV Zoning Feature....................61
LX570H Rear and Side Jack Panels ................. 64
External Stereo Speaker Specifications............... 65
Installer Remote Control Typical Key Functions ........ 66
Troubleshooting ..............................67
General Troubleshooting......................... 67
Commercial Mode Check / FTG Operation
Troubleshooting ............................... 68
Glossary of Terms ............................... 69
Document Revision History / Open Source Software Notice 70
Back Cover..................................... 71
– 63
– 68
Notes
• Installer Menu content is intended for use primarily by qualied TV electronics technicians.
• Refer to the applicable Owner’s Manual for additional information on TV installation, specications, maintenance, and safety instructions.
• Design and specications subject to change without prior notice. This document provides examples of typical TV displays. Your displays may vary
from those shown in this document.
206-4278
5
Commercial Mode Overview
This document describes how to set up LX570H Pro:Centric ® TVs for Commercial Mode operation. LG
commercial TV functionality is based on “ownership” of the Channel Map; that is, the Channel Map resides
in the TV’s CPU, Protocol Translator Card (PTC), or the embedded b-LAN™ (EBL) module, or it resides
externally from the TV (i.e., in a device from the solution provider).
These TV models are capable of Free-To-Guest (FTG) Mode operation via the TV CPU. Alternatively, the
EBL module can be configured either for Pass-through Mode (default) or FTG Mode. When neither the CPU
nor EBL is in FTG Mode, these TV models also allow external control via the TV’s MPI port.
Setup Checklist
Note: This document provides information specific to Commercial Mode operation. Refer to the Owner’s
Manual for information on TV installation and hardware and cable connections.
Installation
__ Unpack TV and all accessories.
__ Install batteries in the Installer Remote.
__ Install TV on VESA mount or stand.
Note: It may be advisable to make all cable
connections before installing on VESA mount
or stand, as appropriate.
Hardware Connections
__ Install any additional hardware as
appropriate to your institution, LAN, etc.
Cable Connections
__ Make all rear jack panel connections, as
appropriate.
Commercial Mode Setup
__ Complete appropriate procedures as described
in this document for Commercial Mode operation.
Pass-through Mode
This mode allows you to configure individual TVs for Pro:Centric and/or FTG Mode via CPU operation.
This mode also allows external control via the GAME CONTROL/MPI port on the TV rear jack panel.
There are two methods for configuring individual TVs that are currently in Pass-through Mode: either
using the EZ-Manager Wizard or the Custom Master TV Setup procedure as described in this document.
EZ-Manager Wizard
When the TV is in a factory default state, the EZ-Manager Wizard provides automated or manual options
for conguring essential items for Pro:Centric operation and also provides an option for using a USB
memory device to congure the TV. Use the Installer Remote to make selections and complete each step.
See “EZ-Manager Wizard” on pages 12 to 18 for detailed information.
Custom Master TV Setup
The Custom Master TV Setup procedure enables you to create a customized Master TV Setup for
Pass-through Mode or FTG Mode via CPU configuration purposes. Use the Installer Remote to congure
Installer Menu items as required for TV operation and set up TV features (Channel, Picture, Audio, etc.).
See “Custom Master TV Setup” on pages 32 to 34 for detailed information.
6
206-4278
Commercial Mode Overview (Cont.)
Installer Menu
To create a Master TV Setup, you will need to know how to
access the commercial controller (PTC) Installer Menu and
make changes to the default values as required. If necessary,
familiarize yourself with the Installer Menu and how to make
and save changes. Refer to pages 22 to 31 for information on
accessing the Installer Menu and for detailed descriptions of
the Installer Menu items.
TV Setup Menus
On-screen setup menus control the features of the TV. Use the
Installer Remote to access the TV setup menus, and set the TV
features to the desired configuration for the end user.
Cloning
Cloning refers to the process of using a Master TV Setup to
configure a Target TV. The Master TV’s clonable setup menu
features should be configured as part of the Master TV Setup.
If there are features in the Master TV’s setup—channel icons
or labels, digital font options, etc.—that are not set or that are
set incorrectly, those features also will not be set or will be set
incorrectly in the Target TVs. Refer to pages 35 to 38 for
detailed information on cloning requirements and procedures.
xxLX570H PTC INSTALLER MENU
000 INSTALLER SEQ 000
UPN 000-000-000-000 ASIC D279
PTC V1.00.008 CPU V3.00.20.01
LOCK
CPU-CTV
Typical Installer Menu
AUDIO
OPTION
CHANNEL
INPUT
TIME
MY MEDIA
External MPI Control
To control the TV using an external MPI control device, you must
use the TV’s GAME CONTROL/MPI port for communication
purposes. In these TVs, Installer Menu item 118 POWER
SAVINGS controls the power circuitry for both the embedded
b-LAN module and the GAME CONTROL/MPI port; therefore, to
ensure that the GAME CONTROL/MPI port circuitry is powered,
thus enabling MPI communication, Installer Menu item 118
POWER SAVINGS must be set appropriately. See Installer Menu
item descriptions as well as Reference section, “b-LAN Setup &
Overview,” for further information.
Note: These TV models are not equipped with MPI card slots.
FTG Mode
In this mode, an FTG Channel Map enables the decryption of each Pro:Idiom ®
encrypted channel. The FTG Channel Map also provides logical channel mapping
of physical RF channels (analog and digital) and Aux inputs. The method for
creating the FTG Channel Map is ultimately determined by which element of the
TV will “own” the FTG Channel Map—the CPU or the EBL.
For these TV models, there are two FTG Modes—FTG Mode via CPU and FTG
Mode via EBL—which are separate and distinct FTG Modes of operation, each
with its own unique advantages and requirements, as outlined on the following
page.
TV Setup Menus
206-4278
7
Commercial Mode Overview (Cont.)
When the TV CPU is configured with an FTG Channel Map, the CPU controls and restricts the tuning
operation of the TV, and when the EBL is configured with an FTG Channel Map, the EBL controls and
restricts the tuning operation of the TV. In these models, FTG Mode via CPU also provides the option to
select either logical or physical tuning (see note below) during configuration. You must determine which
element of the TV will own the FTG Channel Map before you can begin configuration.
Note: Logical channel mapping of physical RF channels eliminates dash tuning; for example, physical
19-3 can be mapped to logical channel 9. It also allows physical RF channels and Aux inputs to be listed
in any order, not only in physical numeric ascending order. Physical channel tuning requires that you
include the dash when direct entering RF channel numbers and Aux inputs (the latter designated by 130-0
through 137-0).
FTG Mode via CPU
This mode provides the following features:
• Logical or physical tuning of physical RF channels and
Aux inputs.
• Mapping of RF channels with minor (program) numbers
up to 999.
• FTG Channel Map of up to 600 channels.
• Start Channel set for RF or Aux input delivered content.
• Pro:Centric data delivery over RF or IP.
• TV Zoning option for location-specic conguration.
LG’s FTG File Manager PC software enables you to
create an FTG Conguration (.tlx) le, which may be used
to congure the CPU for FTG Mode. You can also create a
Clone (.tlx) le from a Master TV Setup that may be used
to congure the CPU for FTG Mode. In this mode, the
CPU is the owner of the FTG Channel Map and must be
congured with an FTG Channel Map and FTG Installer
Menu settings using one of the following processes:
• Local: Congure an individual LX570H TV via its USB
port using a USB memory device / “.tlx” le. The le
may be either a Clone le (see “Cloning Procedures” on
pages 35 to 38) or an FTG Conguration le (see “FTG
File Manager Utilities Overview” on pages 39 to 44).
• Remote: Congure all LX570H TVs at the site using
a Pro:Centric server head end device (Example:
PCS200R). Refer to the Pro:Centric Server Admin
Client User Guide for further information.
FTG Mode via EBL
This mode provides the following features:
• Logical tuning of physical RF channels and Aux inputs.
• Mapping of RF channels with minor (program) numbers
up to 255.
• FTG Channel Map of up to 141 logical channels.
• Start Channel set for RF or Aux input delivered content.
• Pro:Centric data delivery over RF.
LG’s FTG Device Conguration Application PC software
is required to congure the EBL. In this mode, the EBL
is the owner of the FTG Channel Map and must be
congured with an FTG Channel Map and FTG Installer
Menu settings using one of the following processes:
• Local: Congure an individual LX570H TV’s EBL
via its TV-LINK CFG jack using a direct PC-to-TV
(EBL) connection and the FTG Device Conguration
Application. See Reference section, “FTG Mode via
EBL (Local Conguration),” for information on the
“Write” process for an FTG Channel Map and FTG
Installer Menu settings.
• Remote: Congure all LX570H TV EBLs at the site
using a Free-To-Guest Management Appliance (FMA)
head end device (Example: FMA-LG101). Refer to
the Free-To-Guest (FTG) Device Configuration
Application User Guide and/or the Installation &
Conguration Guide for the FMA device for further
information.
8
206-4278
Commercial Mode Overview (Cont.)
While the TV is in FTG Mode:
• Users can still access the Installer Menu using an LG Installer Remote; however, all Installer Menu items
will be read-only.
• FTG Mode via CPU conguration changes must be made using a “.tlx” le (typically edited in the FTG
File Manager), while FTG Mode via EBL conguration changes must be made using the FTG Device
Conguration Application. FTG Channel Map Conguration and FTG Installer Menu Conguration utilities
in both PC applications enable you to make changes, respectively, to the FTG Channel Map and FTG
Installer Menu settings as necessary. Based on the initial method used to congure the TV for FTG Mode
operation (via CPU or EBL), all subsequent changes must be transferred to either the TV CPU or the EBL
via a process that is in accordance or compatible with that method (see information on local conguration
in this document or refer to documentation for the head end device/server for information on remote
management).
• If it becomes necessary to restore the TV to Pass-through Mode, there are several options that will enable
you to do so. See Reference section, “Restoring Factory Defaults on the TV(s),” for further information.
Pages 39 to 44 provide overviews of the utilities that comprise the FTG File Manager. Refer to the Free-
To-Guest (FTG) File Manager User Guide for further information on the FTG File Manager. Refer to the
Free-To-Guest (FTG) Device Configuration Application User Guide for information on the FTG Device
Configuration Application.
Remote Management in FTG Mode
When the TV is configured for FTG Mode via CPU, remote management of the FTG Channel Map and FTG
Installer Menu settings is provided by a Pro:Centric server, via a Clone/Conguration (.tlx) file loaded on the
Pro:Centric server Admin Client. Refer to the Pro:Centric Server Admin Client User Guide for further
information.
When the TV is configured for FTG Mode via EBL, the b-LAN module, which is internal to the TV, allows
hotel/institution head end equipment (for example, an FMA-LG101) with b-LAN technology to provide remote
management of the FTG Channel Map and FTG Installer Menu settings. See Reference section, “b-LAN
Setup & Overview,” for further information.
Determining the TV Operating Mode
To determine the operating mode of the TV, press MENU SETTINGS on the Installer Remote. The menu
displayed depends on the operating mode. If the Function Menu (see example below) appears, the TV is in
a mode (FTG, PPV, etc.) that does not allow the end user to change the fundamental TV setup. If the TV
setup menus (see example on page 7) appear, the TV is in Pass-through Mode.
ASPECT RATIO
16:9
ABC
Just Scan
Set By Program
4:3
Zoom
Move
OK
Function Menu
Indicates the TV is not in Passthrough Mode . While the TV is in
this mode, Installer Menu settings
can be accessed as read-only.
206-4278
9
Pro:Centric Operation
Pro:Centric Interactive Menu Features
LG’s Pro:Centric application enables guests to locate and select television entertainment using an interactive
channel guide, check the daily weather, and view hotel and surrounding amenities via custom billboards and
points-of-interest maps.
Pro:Centric application features include:
• Portal and information screens/pages (including a “Welcome” page) that include branding logos.
• An optional customized user interface (custom “skins”).
• Billboards and points-of-interest maps that can be customized to focus on hotel amenities, local attractions
and businesses, restaurants, news, events, etc.
• An optional Weather billboard that includes a local radar map, current conditions, and a four day forecast.
• An interactive channel guide that provides a channel list with channel icons. An electronic program
guide (EPG) is an optional feature that displays up to three days of programming information viewable
by channel and time.
• Video spooling that enables the hotel to deliver a video le to guest TVs for promotion and information
purposes.
The Pro:Centric server Admin Client web editor/content wizard is provided for customer conguration of
portal messages and billboards/maps.
Note: Customized content is typically dened by the service integrator and/or hotel administrators. LG
does not provide hotel-specic content.
Pro:Centric Interactive Menu Navigation
An LG Pro:Centric-capable TV remote control provides access to both interactive menus and regular TV
features. Press PORTAL on the remote to access the interactive menus.
Note: Interactive menu options may vary, depending on Pro:Centric features enabled for the site. The
following are default interactive menus.
Channel Guide
Shows available TV networks and logical channels. When available, EPG
data provides additional channel and program information.
Information
Typically displays information on hotel amenities, for example, restaurants,
in-room dining, business centers, facilities, etc., as well as information on
local weather and attractions.
Help
Provides help for navigating the interactive menus.
Watch TV
Removes the interactive menu from the screen and returns to the previously
tuned TV channel.
10
206-4278
Pro:Centric Operation (Cont.)
Pro:Centric Setup
Administration and management options for the Pro:Centric server are described in detail in the
Pro:Centric Server Admin Client User Guide. This document describes only those settings that must
be specied on the TVs to enable Pro:Centric remote management and/or the Pro:Centric application.
• Remote management (TV E-Z Installation): The Pro:Centric server Admin Client provides remote
management facilities for downloading splash screen image and software/firmware updates as well as
facilities for downloading a Clone/Configuration (.tlx) file for FTG Mode via CPU configuration.
• Pro:Centric application: The application, which operates in conjunction with FTG and PPV Modes,
comprises the Pro:Centric interactive menus/features described on the previous page. Pro:Centric
application settings are managed via the Pro:Centric server Admin Client.
The Pro:Centric server settings can be congured using one of the methods described below.
TV in Factory Default State
When the TV is in a factory default state, the EZ-Manager Wizard provides automated or manual options
for conguring the Pro:Centric server settings.
The EZ-Manager Wizard also provides a USB conguration option that enables you to congure a TV for
FTG Mode via CPU using a Clone/Configuration (.tlx) le stored on a USB memory device. The “.tlx” le
incorporates FTG Installer Menu settings, including Installer Menu items 098 PRO:CENTRIC and 119 DATA
CHANNEL, which are used to set up the TV’s Pro:Centric feature.
Refer to “EZ-Manager Wizard” on pages 12 to 18 for further information on the EZ-Manager Wizard options.
Note: If Pro:Centric data delivery will be over IP and there is a DNS server at the site, you can create
a DNS entry “procentric.local” for the Pro:Centric server that will enable automated Pro:Centric IP
conguration via the EZ-Manager. If there is no DNS entry for procentric.local, you will need to manually
enter the Pro:Centric server IP address and port number during conguration.
TV in Pass-through Mode
If the TV is in Pass-through Mode, either:
• Set Installer Menu items 098 PRO:CENTRIC and 119 DATA CHANNEL to the appropriate values.
See Installer Menu information on pages 22 to 31 for further details. Also, as necessary, refer to “Custom
Master TV Setup” on pages 32 to 34 and/or cloning information on pages 35 to 38.
• Congure the appropriate Pro:Centric server settings in the IP Environment / Pro:Centric Menu. You
must use this option, in particular, if you wish to congure IP settings for the Pro:Centric server. See
“Accessing the IP Environment Menu” on page 45 and “Pro:Centric Setup” on pages 47 to 48 for further
information.
Note: When the TV is in either Pass-through Mode or FTG Mode via CPU, you can also leave Installer
Menu item 119 DATA CHANNEL set to its default value (255) to enable the TV’s Data Channel Auto Search
feature to set the DATA CHANNEL value. See item 119 description on page 31 for additional information.
TV in FTG Mode
If the TV is in FTG Mode (via CPU or EBL), use the appropriate FTG application software to update Installer
Menu items #98 Pro:Centric and #119 Data Channel (along with their afliated elds). Then, transfer the
FTG Installer Menu settings to the TV in accordance with the FTG Mode of conguration. Refer to the FTG
Mode overview on pages 7 to 9 for further information on FTG Mode operation and conguration. Also—for
FTG Mode via CPU only—see note above regarding the option to use the TV’s Data Channel Auto Search
feature to set the DATA CHANNEL value.
206-4278
11
EZ-Manager Wizard
The primary purpose of the EZ-Manager Wizard is to guide you through the process (automated or
manual) of configuring the essential Installer Menu items for Pro:Centric operation. The wizard will
appear on the screen each time the TV is turned ON, until one of its configuration methods has
been completed or the wizard is exited. Use the Installer Remote to make selections and complete
each wizard step.
While the EZ-Manager Wizard is intended primarily for Pro:Centric-related conguration, the
wizard also offers Zoning as well as USB conguration options.
• LX570H TVs support the TV Zoning feature, which enables location-specic settings (see
Reference section, “Using the TV Zoning Feature,” for further information). The EZ-Manager
Wizard enables you to set the TV Zone # in the TV as part of the conguration process.
• The EZ-Manager Wizard also enables you to redirect to the TV’s standard TV Manager / USB
Download Menu as part of the conguration process, if desired, to perform USB conguration
and/or update functions.
Caution: Do NOT unplug the TV power cord or remove the antenna cable or, if
applicable, the LAN cable during the conguration process, as doing so will interrupt
the current step and may corrupt the conguration data.
Before You Begin
• If you plan to create a Master TV Setup using the procedure described on pages 32 to 34, be sure
to exit the EZ-Manager Wizard in order to avoid setting modes that may restrict the custom setup
procedure. See also “Initiate Conguration or Exit the EZ-Manager Wizard” below.
• If it has been completed or exited and therefore does not display, the EZ-Manager Wizard can
be reactivated; however, this requires that you restore the TV to a factory default condition. See
Reference section, “Restoring Factory Defaults on the TV(s),” for further information.
• Each wizard step is allotted a time frame after which the wizard proceeds without user interaction.
If the Pro:Centric server is congured on the system and if no location-specic settings are
required in the TV, for example, TV Zone, Label, and/or Room Number settings, you can simply
turn ON the TV, and once initiated, the wizard will proceed through each of the conguration steps
with no further user interaction.
• If any of the conguration steps fails, you will see a “Diagnostics” screen with an indication of the
failure. You will then have the opportunity to reinitiate the conguration process from the previous
screen or exit the EZ-Manager Wizard.
Initiate Conguration or Exit the EZ-Manager Wizard
The Welcome screen provides a brief introduction to the EZ-Manager Wizard.
EZ-Manager Wizard
Welcome to LG’s EZ-Manager Wizard
• Use this setup wizard to congure the TV for Pro:Centric and/or Free-
To-Guest (FTG) operation.
Select ‘Next’ to continue.
• If a Pro:Centric Server will not be installed and/or you do not wish to use
the wizard to congure this TV for FTG Mode, you may exit the wizard.
Select ‘No Pro:Centric’ to disable the Pro:Centric feature of this TV, or
select ‘Exit’ to quit.
This setup wizard will start automatically in 10 seconds.
No Pro:Centric
Exit
Next
Note: If there is no user action in this screen within 10
seconds, the wizard will proceed to the rst conguration
step. Once the wizard has proceeded, it is not possible
to return to the Welcome screen; however, if you simply
wish to exit the wizard, you can do so by selecting the
“Exit” option from the subsequent screen(s).
12
206-4278
EZ-Manager Wizard (Cont.)
From the Welcome screen, you have the following options:
• To proceed with the EZ-Manager Wizard, use the arrow keys on the Installer Remote to select/
highlight Next and press OK. Then, continue to the “TV Conguration Options” section below.
• To exit the wizard, but retain the use of the Pro:Centric remote management feature on this TV
(i.e., Installer Menu item 119 DATA CHANNEL set to 255) in the future, use the arrow keys on the
Installer Remote to select/highlight Exit and press OK. In the conrmation pop-up window, select
OK, and then press OK once more on the Installer Remote.
• If you do not intend to install a Pro:Centric server on this system and you do not wish to use the
wizard’s Zoning or USB conguration options, exit the wizard as follows: Use the arrow keys on
the Installer Remote to select/highlight No Pro:Centric and press OK. This will disable the
Pro:Centric feature of this TV (i.e., Installer Menu item 119 DATA CHANNEL will be set to 0). In the
conrmation pop-up window, select OK, and then press OK once more on the Installer Remote.
TV Conguration Options
From the TV Conguration Options screen, you can choose how to proceed with the conguration of
this TV (assuming you do not opt to exit the wizard, which you may also do at any time).
Note: If you intend to use the Zoning feature on the TV for location-specic conguration
purposes, select the “Zone & Room Number” option from this screen and assign the
appropriate TV Zone # in the TV BEFORE you continue with additional conguration.
Z
EZ-Manager Wizard
4
3
2
1
TV Configuration Options
• To congure the TV for Pro:Centric operation, select ‘Next’.
• To set the optional Zoning feature, select ‘Zone & Room Number’.
• To access the TV’s USB Download Menu, select ‘USB Conguration’.
Note: If there is no user action in this
screen within one minute, the wizard
will automatically continue to the next
conguration step.
This setup wizard will continue automatically in 60 seconds.
Exit
USB Configuration
Zone & Room Number
Next
Use the Left/Right arrow keys on the Installer Remote to navigate between options on this screen.
Each time you select/highlight one of the following options, the screen text and elds will change in
accordance with your selection.
• To continue with Pro:Centric conguration, select Next (default) and press OK on the Installer
Remote. Refer to “Congure Pro:Centric Settings” on pages 15 to 17 for additional information.
• Select Zone & Room Number to set the Zoning feature on this TV. See “Zone and Room
Number Assignments” on the following page for further information.
• Select USB Conguration to access the TV Manager / USB Download Menu. See “USB
Conguration” on page 18 for further information.
Note: If you choose to exit the EZ-Manager Wizard from this point on, you will have the option to
save any settings made by selecting Save and Exit in the exit conrmation pop-up window. Or, you
can exit the wizard without saving any settings by simply selecting OK in the conrmation pop-up
window.
206-4278
13
EZ-Manager Wizard (Cont.)
CHAR/
NUM
Zone and Room Number Assignments
You may complete one or more of the elds in the Zone, Label, and Room Number screen or leave
them at their default settings (Zone) or blank (Label and Room Number), as desired; however, if you
intend to use the Zoning feature on this TV, you MUST specify the appropriate value in the Zone
eld as described below. See also Reference section, “Using the TV Zoning Feature,” for further
information.
Note: The Zoning feature is only applicable for TVs that will be congured using a “.tlx” le (local
or remote conguration).
Z
EZ-Manager Wizard
4
3
2
1
•
If creating Zones for Installer Menu settings and/or Channel Mapping, select the appropriate Zone # (0-8)
based on the Zone in which this TV is installed. (See Commercial Mode Setup Guide for more information.)
• Select a Label and/or use the alphanumeric keypad on the remote to input the Room Number.
• When done, select ‘Next’ to continue.
Zone
0
Exit
Zone, Label, and Room Number
-----
USB Configuration
Room NumberLabel
Zone & Room Number
Q.MENU
INPUT
2
1
3
TV
DVD
MARK
@
.,;
abc def
1 2 3
4
5 6
ghi jkl mno
4 5 6
pqrs tuv wxyz
7 809
7
FLASHBK
8
9
CHAR/NUM
CC
P
A
TIMER
G
CHVOL
E
DELETE
DEL
0
MUTE
PORTAL
INFO
GUIDE
Next
1. Complete the appropriate eld(s) as described below. Use the Left/Right arrow keys on the
Installer Remote to navigate between each of the elds.
• Zone: Enables you to set a TV Zone # so that the TV can be congured with Installer Menu
and/or TV Setup Menu settings intended only for the assigned Zone. The Installer Menu and/
or TV Setup Menu settings may be provided in a Clone/Conguration (.tlx) le. If the TV is
being congured for FTG Mode via CPU, the TV Zone # setting also allows the TV to omit
channels that have been restricted in the FTG Channel Map.
To change the TV Zone from its default value (0), navigate to the Zone eld at the left of the
screen, and use the Up/Down arrow keys to specify the desired TV Zone # (1–8).
• Label: Allows you to select a North, South, East, or West text label for this TV. In the Label
eld, use the Up/Down arrow keys to select the applicable label.
• Room Number: Allows you to specify the number of the room—up to 16 characters—in which
the TV is located. In the Room Number eld, you can use the number keys on the Installer
Remote to direct enter a room number. Use the Dash key on the Installer Remote as necessary
to toggle between number and letter characters in the Room Number eld. Also, you can use
the Flashback key on the Installer Remote to delete characters in this eld.
2. When you are ready to continue, select the appropriate option, as follows:
• To proceed to the next EZ-Manager screen, use the arrow keys to select Next, and then
press OK on the Installer Remote. Continue to the “Congure Pro:Centric Settings” section
on the following page.
• To use a USB memory device in conjunction with the TV Manager / USB Download Menu to
complete the conguration, continue to “USB Conguration” on page 18.
14
206-4278
Congure Pro:Centric Settings
Once you select “Next” from the TV Conguration Options screen,
the Searching for Pro:Centric Server screen is displayed (see
example at right), and you have the following options:
• You can allow the EZ-Manager Wizard to proceed with a series
of automated steps to congure the TV for Pro:Centric operation
and then to look for the Pro:Centric application and maintenance
(E-Z Installation) les to download. In this case, the wizard
uses a search algorithm to determine the Data Channel and the
Pro:Centric Application Mode to set in the TV.
Continue with the “Automated Pro:Centric Conguration” subsection below.
• If you already know the settings (i.e., Data Channel and
Pro:Centric Application Mode) that need to be congured in
order for the TV to connect to the Pro:Centric server and/or if
the Pro:Centric server is not yet installed, you may expedite
the setup process by entering this data manually.
Continue with the “Manual Pro:Centric Conguration” subsection
on the following page.
EZ-Manager Wizard (Cont.)
Z
EZ-Manager Wizard
4
3
1
2
Note: Select the “Back” button, where available, to
check previous settings, as necessary.
Searching for Pro:Centric Server...
It may take 1 min 32 second(s).
This step automatically searches for the Pro:Centric server.
If there is no Pro:Centric Server installed, you do not need to continue
with this procedure. Please select either ‘Exit’ or ‘Manual Pro:Centric’.
Status : Tuning channel 49
TV is now searching all of the channels for the data channel...
Back
Exit
Manual Pro:Centric
Automated Pro:Centric Conguration
Note: If the server is not yet congured on the system, use the
manual conguration option to congure the Pro:Centric operation.
See also note below.
Note: If Pro:Centric data delivery will be over IP and there is
a DNS server at the site, you can create a “procentric.local”
DNS entry for the Pro:Centric server that will enable automated
Pro:Centric IP conguration via the EZ-Manager. If there is no
DNS entry for procentric.local, you must use the manual
conguration option to congure the Pro:Centric IP operation.
Once the Pro:Centric data channel is found (a Pro:Centric
Server Was Found screen will be displayed) and the Pro:Centric
Application Mode is determined, the wizard will advance to the
Processing the Pro:Centric Conguration screen, which shows
the progress of the data downloads (see example at right). Note
that some steps may require a few minutes.
If the process is successful, no further user interaction is required,
though, in some instances, where the option (for example “Next”)
is available, you may manually move forward to subsequent steps
within the wizard to speed up the process.
Z
EZ-Manager Wizard
1
EZ-Manager Wizard
1
4
3
2
Pro:Centric Server was found...
It may take 2 second(s).
The Pro:Centric data channel was found!! (Data Channel: 75, Mode: GEM)
The Download window will open in 2 second(s). You may wait or select ‘Next’.
Otherwise, if you select ‘Exit’, the Pro:Centric server settings can be retained
and used during the next download by selecting ‘Save & Exit’ in the Exit window.
Status : Tuning channel 75
The Pro:Centric data channel is found!!
(Data Channel: 75, Mode: GEM)
Back
4
2
3
Processing the Pro:Centric Configuration...
Downloading the maintenance files takes several minutes.
Application files
Maintenance files
– Updating Configuration File
Warning - Do not remove AC power or the signal cables during these steps
Exit
Please wait...
Retrieving files from data channel 75
Next
GEM app downloaded
(Continued on next page)
20%
In progress...
206-4278
15
EZ-Manager Wizard (Cont.)
(Continued from previous page)
Note: If, after completing the search, the TV is unable to nd the
Pro:Centric data channel (while the Searching for Pro:Centric
Server screen is on display), the wizard will stop and show a
Diagnostics screen that enables you to manually return to the
previous screen (to reinitiate the conguration) or exit the wizard.
When the Pro:Centric Conguration is complete, an EZ-Manager
Conguration Complete screen is displayed, and after 10
seconds, the wizard exits, and the TV turns OFF.
Note: With the EZ-Manager Conguration Complete screen on
display, you can also manually turn off or reboot the TV. If
desired, select Turn Off or Reboot, respectively, and then press
OK on the Installer Remote.
Manual Pro:Centric Conguration
1. With the Searching for Pro:Centric Server screen on display,
use the arrow keys on the Installer Remote to select/highlight
Manual Pro:Centric at the bottom right of the screen, and
then press OK.
In the Pro:Centric Manual Conguration screen (see examples
at right below and on following page), you will be able to
congure the appropriate Pro:Centric settings in the TV. Use
the Up/Down arrow keys on the Installer Remote to navigate
between elds.
2. In the Pro:Centric Mode eld, use the Left/Right arrow keys to
select the appropriate Pro:Centric Application Mode—FLASH,
GEM, or Conguration Only.
Note: For remote management only, select Conguration
Only. The TV will search for TV E-Z Installation data down-
loads; however, Pro:Centric application data will not be
downloaded, i.e., Installer Menu item 098 PRO:CENTRIC
will be set to 0.
3. Refer to the appropriate subsection below, depending on the
Pro:Centric server conguration, to complete the remaining
elds.
RF Conguration
a) In the Media Type eld, use the Left/Right arrow keys to
select RF.
b) In the Data Channel eld, either key in or use the Left/
Right arrow keys to select the RF channel number that
will be used by the Pro:Centric server as its data channel.
The Data Channel value can be set from 1 to 135. *
EZ-Manager Wizard
3
2
1
4
EZ-Manager Configuration Complete
The TV will turn off in 3 second(s).
Installed Components
Z
EZ-Manager Wizard
1
2
4
3
Pro:Centric Application
Maintenance Files
Reboot
GEM application downloaded
LX570H_Config.tlx
Turn Off
Searching for Pro:Centric Server...
It may take 1 min 32 second(s).
This step automatically searches for the Pro:Centric server.
If there is no Pro:Centric Server installed, you do not need to continue
with this procedure. Please select either ‘Exit’ or ‘Manual Pro:Centric’.
Status : Tuning channel 49
TV is now searching all of the channels for the data channel...
Back
EZ-Manager Wizard
4
3
1
2
Exit
Manual Pro:Centric
Pro:Centric Manual Configuration
Pro:Centric Mode
Media Type
Data Channel
Signal Strength
Signal Quality
Back
GEM
< >
RF
1
No signal
Exit
Pro:Centric Manual Configuration Screen with
RF Media Fields
Next
0%
0%
* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.
16
(Continued on next page)
206-4278
(Continued from previous page)
IP Conguration
a) In the Media Type eld, use the Left/Right arrow keys to
select IP.
Note: By default, the Pro:Centric Manual Conguration
screen initially shows RF conguration elds. When you
select “IP” as the Media Type, the Data Channel and
Signal Strength/Quality elds are replaced with IP Address
and Port elds.
b) In the Address and Port elds, either key in or use the
Left/Right arrow keys to select the appropriate values for
the Pro:Centric server IP address and port number.
The IP address must match the IPv4 multicast address
and the port number must match the port number that is
set in the Pro:Centric server.
EZ-Manager Wizard (Cont.)
EZ-Manager Wizard
4
3
1
2
Pro:Centric Manual Configuration Screen with
Pro:Centric Manual Configuration
Pro:Centric Mode
Media Type
Addresss
Port
Back
GEM
IP
< >
255
0
Exit
IP Media Fields
255255255
Next
4. Once all elds are completed as required, you have two
options (see also note below):
• To save the data entered and exit the wizard, use the arrow
keys to select Exit and then press OK. In the subsequent
pop-up conrmation window, select Save and Exit, and then
press OK once more. The Pro:Centric application and/or
E-Z Installation data will be downloaded to the TV at a later
time. This option is useful, in particular, if the Pro:Centric
server has not yet been congured.
• To initiate a real-time download of Pro:Centric application
and/or E-Z Installation data, use the arrow keys to select
Next, and then press OK.
The EZ-Manager Wizard will proceed with the remaining
Pro:Centric application and/or E-Z Installation data download steps, as shown on the Processing the Pro:Centric
Conguration screen.
Note: With RF conguration, Pro:Centric server data must be
present on the RF channel selected as the TV’s Data Channel
in order for you to select “Next” (you will see a “Data channel
found” message below the Signal Quality indicator). With IP
conguration, Pro:Centric server data must be present via the
wired LAN cable connection in order for you to select “Next”
(you will see a “IP server found” message below the Port eld).
When the Pro:Centric conguration is complete, an EZ-Manager
Conguration Complete screen is displayed, and after 10
seconds, the wizard exits, and the TV turns OFF.
Note: With the EZ-Manager Conguration Complete screen on
display, you also have the option to manually turn off or reboot
the TV. If desired, select Turn Off or Reboot, respectively, and
then press OK on the Installer Remote.
EZ-Manager Wizard
4
3
1
2
EZ-Manager Wizard
2
1
EZ-Manager Wizard
2
1
Pro:Centric Manual Configuration
Are you sure you want to exit the wizard?
!
Pro:Centric Mode
If you select ‘OK’ now, your settings will be lost
< >
and you will exit the setup wizard.
Channel Number
This window will close and you will be returned to
Signal Strength
the previous page automatically in 2 seconds.
Signal Quality
Save and Exit
Back
4
3
Processing the Pro:Centric Configuration...
Downloading the Pro:Centric application files takes a few minutes.
Retrieving files from data channel 75
Application files
Maintenance files
Warning - Do not remove AC power or the signal cables during these steps
3
4
OK
Exit
Please wait...
EZ-Manager Configuration Complete
The TV will turn off in 3 second(s).
Installed Components
Pro:Centric Application
Maintenance Files
Reboot
GEM
1
Cancel
No signal
Next
1%
In progress...
Pending...
GEM application downloaded
LX570H_Config.tlx
Turn Off
0%
0%
206-4278
17
EZ-Manager Wizard (Cont.)
USB Conguration
The TV Manager / USB Download Menu provides options that enable you to download individual
conguration or software les individually to the TV. You can also use the Ez Download utility available
from the menu to select one of each type of le to be downloaded at one time using one process.
Each of the TV Manager / USB Download Menu functions requires that you have the appropriate
le(s) loaded on a USB memory device. If you wish to perform a software update or download a
splash screen image, the software/image le(s) must be stored in a folder named “LG_DTV” in the
root directory of the USB device. Clone/Conguration (.tlx) les should simply be stored in the root
directory of the USB device. The procedure below assumes that the desired le(s) is/are already
loaded onto the USB device. For further information on TV Manager / USB Download Menu functions
and le requirements, and/or for information on creating Clone or FTG Conguration (.tlx) les, refer
to the appropriate section(s) in this document.
Before You Begin
• If you intend to use the Zoning feature on this TV, make sure to assign the appropriate TV Zone #
in the EZ-Manager’s Zone, Label, and Room Number screen BEFORE continuing with USB
Conguration. See “TV Conguration Options” on page 13 for further information.
• Ensure the USB device to be used has been formatted with FAT format.
• When creating les to be downloaded, avoid using special characters (?, &, @, etc.) in lenames.
• Refer to “Ez Download Utility” on pages 19 to 21 for further information on the Ez Download utility.
• Refer to “Custom Master TV Setup” on pages 32 to 34 for information on creating a Clone (.tlx)
file, and/or refer to “Creating an FTG Conguration File” on pages 39 to 40 for information on
creating an FTG Conguration (.tlx) le for FTG Mode via CPU conguration.
• See Reference section, “Downloading a Splash Screen Image using a USB Memory Device,” for
splash screen image guidelines.
• See Reference section, “Updating TV/PTC Software using a USB Memory Device,” for further
information on software updates.
USB Conguration via EZ-Manager Wizard
With either the TV Conguration Options or the Zone, Label, and
Room Number screen on display, proceed as follows to congure the
TV using the USB memory device.
1. Insert the USB memory device with the appropriate le(s) into
the TV’s USB port.
2. Use the arrow keys on the Installer Remote to select USB
Conguration, and then press OK. You will be redirected to the
TV’s TV Manager / USB Download Menu (see example at right).
3. Select the appropriate option from the TV Manager / USB
Download Menu, and complete the download(s) as required.
Note: If you perform a software update, the TV will complete the
update and then reboot. Upon restart, the TV will display the
EZ-Manager TV Configuration Options screen. If desired, you can
re-access the USB Download Menu (to perform additional functions),
proceed with conguration via the wizard, or exit the wizard.
4. Remove the USB memory device, and verify that the appropriate
configuration/update(s) is/are resident on the TV.
18
TV Manager
USB
Diagnostics
Previous
Note: You can press on the
Installer Remote at any time to
return to the EZ-Manager Wizard.
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
OK
206-4278
Ez Download Utility
The Ez Download utility, available from the TV Manager / USB Download Menu, enables you to
select multiple les (one of each le type) at one time from the les loaded on a USB memory
device. You may use this utility to download any one or all of the following to a TV: a Clone or FTG
Conguration (.tlx) le, a TV CPU or PTC software update, a splash screen image.
Before You Begin
• Ensure the USB device has been formatted with FAT format.
• Software update and splash screen image les must be stored in a folder named “LG_DTV” in
the root directory of the USB memory device. Clone/Conguration (.tlx) les should simply be
stored in the root directory of the USB device.
• If the EZ-Manager Wizard appears on the screen when you turn ON the TV, you can use the
wizard’s “USB Conguration” option to access the Ez Download utility (see “TV Conguration
Options” and/or “USB Conguration” on pages 13 and 18, respectively, as necessary).
• If the TV is currently in Pass-through Mode and you intend to use the TV Zoning feature for
location-specic conguration purposes, make sure to assign the appropriate TV Zone # in the
TV when directed to do so in the procedure below.
• When creating les to be downloaded, avoid using special characters (?, &, @, etc.) in lenames.
• Refer to “Custom Master TV Setup” on pages 32 to 34 for information on creating a Clone (.tlx)
file, and/or refer to “Creating an FTG Conguration File” on pages 39 to 40 for information on
creating an FTG Conguration (.tlx) le for FTG Mode via CPU conguration.
• See Reference section, “Downloading a Splash Screen Image using a USB Memory Device,” for
splash screen image guidelines.
• See Reference section, “Updating TV/PTC Software using a USB Memory Device,” for further
information on software updates.
Caution: Do not unplug the TV power cord or remove the USB memory device
during a data download, as doing so may cause the TV to malfunction or harm the
USB device, respectively.
Accessing and Using the Ez Download Utility
1. If it is not ON already, turn ON the TV.
2. The next step depends on whether the EZ-Manager Wizard appears on the screen when you
turn ON the TV:
• If the wizard is displayed, you can access the Ez Download utility via the wizard, as indicated
above (see “Before You Begin”). However, to continue with this procedure and access the Ez
Download utility from the TV menus, exit the EZ-Manager Wizard. Then, continue with step 3.
• If the wizard is not displayed, go directly to step 3.
3. If the TV is currently in Pass-through Mode, you would like to transfer (import) a “.tlx” le to the
TV via the Ez Download utility, and you intend to use the TV Zoning feature, assign the appropriate
TV Zone # in the TV at this time. See Reference section, “Using the TV Zoning Feature,” for further
information.
206-4278
(Continued on next page)
19
Ez Download Utility (Cont.)
(Continued from previous page)
Note: In order for the proper location-specic TV Zone prole
data to be applied, the Zone designation must be assigned in
the Target TV(s) BEFORE you continue with the Ez Download
utility.
4. Insert the USB memory device with the appropriate le(s) into the TV’s
USB port.
5. To access the TV Manager / USB Download Menu from the TV menus:
• Press MENU SETTINGS on the Installer Remote to display the TV
setup menus (TV is in Pass-through Mode) or the Function Menu (TV
is not in Pass-through Mode).
• Use the arrow navigation keys to select/highlight either the Option
menu icon from the TV setup menus or the Lock menu icon from the
Function Menu. Then, press the number “7” key a total of seven times.
6. With the TV Manager / USB Download Menu on display (see example
at right), use the Up/Down arrow keys to select Ez Download, and then
press OK.
The Ez Download utility screen contains a listing of the CPU (EPK),
PTC, and LOGO (splash screen image) les stored in the LG_DTV
folder and the Clone/Conguration (TLX) les stored in the root directory
on the USB device.
Note: Press on the Installer Remote, as necessary, to exit the Ez
Download utility and/or the TV Manager / USB Download Menu. If you
accessed the TV Manager via the EZ-Manager Wizard, you will be
returned to the last screen on display before you selected the “USB
Conguration” option. If you accessed the TV Manager via the TV
menus, you will be returned to program viewing.
7. To select or de-select a le, respectively, use the Up/Down arrows on
the Installer Remote to highlight the lename, and press OK to add or
remove the checkmark at the left of the lename.
Note: The utility will only allow you to select one of each le type for
downloading. For example, if there are two TLX les in the Ez Download
list, you can only select one or the other of those two les.
Note: After the Ez Download utility is run, a le is automatically created
and stored on the USB device that was used. The le, which will have
a “.dzm” extension, maintains a history of the le(s) previously used
with the Ez Download utility. The next time(s) you use this USB device
with the Ez Download utility, the le(s) selected for the last download
will be pre-selected for the current download.
8. The elds at the right of the screen will change depending on the
currently highlighted le. Select the appropriate option(s) for each le,
as applicable.
TV Manager
USB
Diagnostics
Previous
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
OK
Note: TV Manager / Diagnostics
is for service use only.
Ez Download
[TLX] xxLX570H-UA00001.TLX
[LOGO] Splash Image 1920 X 1080 Pro
[EPK] xxLX570H_V03_00_USB.epk
Previous
Updating EPK File... 50 %
Do not remove the USB from the port! Do not unplug!
xxLX570H-UA00001.tlx
Splash Image 1920 x 1080 ProC.jpg
xxLX570H_V03.00_USB.epk
OK
[ TV Software Version ]
Current : 03.00.12.01 (CPU)
1.00.008 (PTC)
EPK : 03.00.20.01
[ Forced Update Option ]
SPI Boot
LG Boot Logo
Apply
20
(Continued on next page)
206-4278
Ez Download Utility (Cont.)
(Continued from previous page)
• For software and splash screen image les: The elds at the right of the screen show the TV
software versions and any available Forced Update options. Do not select any Forced Update
options unless you have been specically instructed to do so or have previous experience with
Expert Software Updates.
• For TLX les: If an FTG Channel Map is included in the selected Clone/Conguration (.tlx)
le, a Channel Tuning / Channel Banner Display eld at the right of the screen enables you
to choose the format for the channel tuning/banner display. Press the green button on
the Installer Remote to select Logical tuning, or press the yellow button on the Installer
Remote to select Physical tuning. A checkmark will appear at the left of the selected option.
Logical tuning is selected by default.
Note: If the selected TLX le does not include an FTG Channel Map, the message, “No
Channel Map in TLX le,” will be displayed at the right of the screen.
9. When you are ready to continue, use the arrow keys on the Installer Remote to select Apply,
and then press OK.
Update progress will be shown in a new window. Do NOT remove the USB device while
updates are in progress. When the Ez Download process is complete, the TV will briey
display an overview of the results and then either return to program viewing or reboot (the
latter if software has just been updated).
10. Remove the USB memory device, and verify that the appropriate configuration/update(s) is/are
resident on the TV.
Note for TLX configuration: When conguration is complete, the TV tunes according to the
Start Channel setting in the Installer Menu. If a Start Channel is specied, the TV will tune to that
channel, though in the case of FTG Mode via CPU conguration, a channel banner will only be
displayed if the Start Channel is included in the FTG Channel Map (depending on your selection
in step 8, the channel banner will display either the Start Channel’s logical channel number or
physical RF channel number). Otherwise, the TV will either return to the last channel tuned (TV
in Pass-through Mode) or tune to the rst channel in the FTG Channel Map (TV in FTG Mode via
CPU). In the latter case, remember that the channels in the FTG Channel Map are always
arranged in logical order, regardless of your selection in step 8.
206-4278
21
Installer Menu
Use the Installer Menu to set up, change, or view operational settings. This section describes how
to access, use, and exit the Installer Menu from the TV itself. However, you should also refer to
the Installer Menu descriptions in this document if you are conguring the TV CPU using an FTG
Conguration (.tlx) le created using LG’s FTG File Manager software or conguring the EBL locally
(.rml) or remotely (via FMA-LG101 / .fma) using the FTG Device Conguration Application software.
Refer to the table on pages 24 and 25 for brief descriptions of Installer Menu items. More detailed
descriptions follow the table listing.
Accessing the Installer Menu
1. Turn ON the TV.
If the EZ-Manager Wizard appears on the screen when you turn ON the TV, exit the wizard.
2. Using an Installer Remote, press MENU SETTINGS repeatedly until the on-screen display of
the TV setup menus (if the TV is in Pass-through Mode) or the Function Menu (if the TV is not
in Pass-through Mode) no longer toggles, and then press the Installer Menu entry sequence
(e.g., 9-8-7-6) + OK to access the Installer Menu.
Note: The default Installer Menu entry sequence is “9876”; however, if Installer Menu item 000
INSTALLER SEQUENCE has been modied, the entry sequence may be one of three additional
options. See Installer Menu detailed descriptions for further information.
The Installer Menu opens with item 000 INSTALLER SEQ 000.
xxLX570H PTC INSTALLER MENU
CPU-CTV
000 INSTALLER SEQ 000
UPN 000-000-000-000 ASIC D279
PTC V1.00.008 CPU V3.00.20.01
PTC Version
CPU Version
Typical Installer Menu
The Installer Menu header will vary
depending on the TV you are setting
up. In the Installer Menu footer, you
can see the current software versions
of the TV, as indicated.
Note: If the password (entry sequence) is not entered or registered correctly, you will see the
message “ENTER PASSWORD 0000” at the top of the screen instead of the Installer Menu
header. Once you re-enter the correct password (e.g., press 9-8-7-6 + OK), the Installer Menu will
display.
Note: If the TV is not in Pass-through Mode, the Installer Menu is accessible as read-only. Also,
the TV Zone # will be indicated in the Installer Menu header under the conguration mode indicator
described on the following page.
22
206-4278
Installer Menu (Cont.)
As part of the Installer Menu header (in all modes), two 3-character acronyms are displayed to indicate
the TV’s current conguration mode. The table below lists all possible mode identiers for these TV
models.
Acronym Description
CPU-CTV Pass-through Mode with channel lineup in CPU
CPU-FTG FTG Mode via CPU
CPU-P:C Application Tuning Mode via CPU
EBL-FTG FTG Mode via EBL
EBL-LNT SONIFI PPV Mode
MPI-EXT External MPI Control
PTC-CTV Pass-through Mode with channel lineup in PTC
Using the Installer Menu
Refer to the table starting on the next page for an overview of the available Installer Menu items,
including their item numbers, functions, value ranges, and default values.
Installer Menu items not relevant to these TV models are not present in the Installer Menu; therefore,
some numbers are missing. For example, item 006 will not appear. In addition, items that are
dependent on other Installer Menu item settings will not be initially accessible. For example, item 046
STRT AUX SRCE will not display in the Installer Menu unless item 004 STRT CHANNEL is set to 0.
See Installer Menu detailed descriptions for further information.
Navigation within the Installer Menu
Use the Up/Down arrow keys on the Installer Remote to sequence through the available menu items,
or access an item directly by keying in the item number and then pressing MENU SETTINGS. For
example, to access the SLEEP TIMER option, which is item 015, press 0-1-5 + MENU SETTINGS.
Changing Installer Menu Settings
To change an Installer Menu item value, use the Left/Right arrow keys on the Installer Remote, or
enter a valid value directly. To save the new setting, press OK, or use the Up/Down arrow keys to
navigate to a new Installer Menu item if you have additional items to edit. Note that invalid values will
not be saved.
Exiting the Installer Menu and Activating Settings
After you have adjusted all required Installer Menu item settings, press OK once on the Installer
Remote to save your changes; then, press OK again to exit the Installer Menu. Any changes you
make will be stored in non-volatile memory.
Note: Each time you exit the Installer Menu in Pass-through Mode, all V-Chip (Parental Control)
settings in the TV are reset to their default values; that is, the Lock System, if previously enabled
from the Lock setup menu, will now be disabled, and the individual Parental Control settings will be
restored to default values.
206-4278
Caution: Installer Menu settings may affect options available
from the TV setup menus or the Function Menu.
23
Installer Menu (Cont.)
Installer Menu Items 000 through 071
Item Function Value Range Default Value Brief Description of Function
000 INSTALLER SEQ 0 ~ 3 0 Leave default set to 0.
001 POWER MANAGE 0 ~ 7 0
002 AC ON 0 ~ 3 0
003 BAND/AFC 0 ~ 3 1 Selects Tuning Band: 0=Broadcast, 1=CATV, 2=HRC, 3=IRC
004 STRT CHANNEL 0 ~ 127, 255 255
005 CHAN LOCK 0 / 1 0 If set to 1, cannot tune from current channel.
007 STRT VOLUME 0 ~ 63, 255 255
008 MIN VOLUME 0 ~ 63 0 Sets minimum allowable volume setting.
009 MAX VOLUME 0 ~ 63 63 Sets maximum allowable volume setting.
010 MUTE DISABLE 0 / 1 0 Set to 1 to disable Mute Function.
011 KEY DEFEAT 0 / 1 0
015 SLEEP TIMER 0 / 1 1 Set to 1 to enable Sleep Timer.
016 EN. TIMER 0 / 1 0 Set to 1 to enable On/Off Timers.
017 ALARM 0 / 1 1 Set to 1 to enable Alarm.
020 FEATURE LEVEL 0, 16 ~ 24 0 Determines an additional IR code scheme to which the TV will respond.
021 V-CHIP 0 / 1 1 Set to 1 to enable V-Chip (Parental Control) functions.
022 MAX BLK HRS 0 ~ 99 12 Sets number of V-Chip blocking hours.
023 CAPTION LOCK 0 / 1 0 Set to 1 to retain caption setting set before TV turned OFF.
028 CH. OVERIDE 0 / 1 1
029 OLD OCV 0 / 1 0 Set to 1 to remap the PTC’s direct tune channels for Aux inputs from 13x to 9x.
030 ACK MASK 0 / 1 0 If set to 1, enables ACK feature of MPI.
031 POLL RATE 20 ~ 169 94 Selects poll rate for MPI.
032 TIMING PULSE 186 ~ 227 207 Sets baud rate for MPI.
035 HDMI1 ENABLE 0 ~ 2 1
039 REAR AUX EN. 0 / 1 1 Set to 1 to enable display panel Video 1 input jack.
041 SIMPLINK EN 0 ~ 3 0 Determines the status of the SIMPLINK feature. (See detailed descriptions.)
042 AUTO INPUTS 0 ~ 255 0
046 STRT AUX SRCE 1, 3 ~ 5, 7, 255 255 Sets the starting Aux source (if item 004 STRT CHANNEL is set to 0).
047 AUX STATUS 0 / 1 0
053 DIS. CH-TIME 0 / 1 0 Set to 1 to disable Channel-Time display.
069 EN. CH-T COL. 0 / 1 1 Set to 1 to enable custom color for the Channel-Time display.
070 FOR. CH-TIME 0 ~ 7 2 Chooses custom foreground color for the Channel-Time display.
071 BCK. CH-TIME 0 ~ 7 2 Chooses custom background color for the Channel-Time display.
Selects the number of hours of inactivity allowed before the TV automatically
turns itself OFF. Set to 0 to disable power management.
Set to 1 to enable TV to turn ON when AC power is applied. Set to 2 or 3 to
enable Instant ON when AC power is applied. (See detailed descriptions.)
Channel tuned when TV is turned ON. (Set to 255 to tune to channel
tuned before TV turned OFF.)
Volume level when TV is turned ON. (Set to 255 to use volume level
before TV turned OFF.)
If set to 1, joystick button menu navigation functions on display panel
are not available.
If set to 0, user access to channel settings in the TV setup menus is restricted
and users can only tune to channels that are included in the channel lineup.
Set to 0 to disable HDMI 1. Set to 1 (DTV Mode) or 2 (PC Mode), as
applicable, to enable HDMI 1.
Determines the Aux inputs for which auto-sensing is enabled. (See detailed
descriptions.)
Set to 1 for MPI Aux source to be reported as a channel number instead of
Channel 0.
24
206-4278
Installer Menu (Cont.)
Installer Menu Items 073 through 122
Item Function Value Range Default Value Brief Description of Function
073 CH NOT AVBLE 0 / 1 0
075 REVERT CH 0 / 1 0 If set to 1 and loss of MPI communication occurs, TV tunes to Start Channel.
078 UPN MSB 0 ~ 255 0 User programmable number, most significant byte.
079 UPN MSB-1 0 ~ 255 0 User programmable number, most significant byte - 1.
080 UPN MSB-2 0 ~ 255 0 User programmable number, most significant byte - 2.
081 UPN LSB 0 ~ 255 0 User programmable number, least significant byte.
082 CHKSM ERROR 0 / 1 1 Enforces rigid MPI checksum.
083 HANDSHK TIME 0 ~ 5 5 Relaxes MPI timing to be compatible with PC-based Windows-controlled systems.
084 PERMANENT BLK 0 / 1 0 Removes block hours setting for Parental Control and makes block permanent.
086 V. MUTE TIME 0 ~ 50 0 Use to extend the normal video mute time during channel change.
087 REAR RGB EN.
088 EN NOISE MUTE 0 / 1 1 (Analog channels only) If set to 1, audio is muted if no signal is present.
090 KEY LOCK 0 / 1 0 If set to 1, all display panel joystick button functions are locked. IR is still functional.
091 HDMI2 ENABLE 0 ~ 2 1
092 HDMI3 ENABLE 0 ~ 2 1
093 RJP AVAILABLE 0, 1, 2, 5, 6 0
094 SAP MENU EN 0 / 1 1 Set to 1 to enable SAP feature in Function Menu.
096 DEF. ASP. RATIO 0 ~ 4 2 Sets default aspect ratio at power up. See detailed descriptions and item 106.
097 AUDIO OUTPUT 0 ~ 9
098 PRO:CENTRIC 0 ~ 2
099 BACK LIGHTING 1 ~ 200, 255 255 Sets the level of the TV picture back lighting. (See detailed descriptions.)
102 ATSC BAND 0 ~ 4 4 Selects ATSC band.
103 ATSC TUNE MODE 0 / 1 1 Set to 1 (default) for Physical Channel scan. Set to 0 for Virtual Channel scan.
104 START MINOR CH 0 ~ 255 0 Selects Minor Start Channel. Set to 0 for NTSC.
106 ASP RATIO LOCK 0 / 1 0
116 VIDEO MUTE EN 0 / 1 0
117 FACT DEFAULT 0 / 1 0 Set to 1 to restore the factory default settings of all Installer Menu items.
118 POWER SAVINGS 1, 3, 7 3
119 DATA CHANNEL
121 UPDATE TIME HR 0 ~ 23, 128 128
122 UPDATE TIME MN 0 ~ 59 0 Sets the minute for Wake For Update.
0, 1, 17
0 ~ 135, 253,
255
1
7
0
255
If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL NOT
AVAILABLE” message is displayed if user attempts to direct tune a channel that
is not included in the channel lineup.
Dependent on item 093 RJP AVAILABLE setting. Set to 0 to disable RGB input.
Set to 1 to enable RGB input. Set to 17 for Auto Configure.
Set to 0 to disable HDMI 2. Set to 1 (DTV Mode) or 2 (PC Mode), as
applicable, to enable HDMI 2.
Set to 0 to disable HDMI 3. Set to 1 (DTV Mode) or 2 (PC Mode), as
applicable, to enable HDMI 3.
Set to 0 to disable. Set to 1, 2, 5, or 6 for HDMI or DVI Mode. (See
detailed descriptions.)
Set as required in accordance with external audio equipment connected to the
TV. See detailed descriptions.
Set to 0 to disable Pro:Centric operation. Set to 1 for Flash Mode. Set to 2 for
GEM (Java Application) Mode.
To retain set aspect ratio on power cycle, set to 1. Set to 0 for default ratio on
power cycle.
(Analog channels only) If set to 1, video mutes (blank screen) when no
signal is present.
Determines the powered status of the embedded b-LAN module and the GAME
CONTROL/MPI port. (See detailed descriptions.)
Set to 0 to disable. Set from 1 to 135 to match the RF channel number used by
the Pro:Centric server as its data channel. Set to 255 to use Auto Search to find
the Pro:Centric RF channel. (See detailed descriptions.)
Sets the Wake For Update hour. The value “128” is displayed as “OFF.” Directly
entering 128 turns the Wake For Update feature OFF.
206-4278
25
Installer Menu (Cont.)
Detailed Descriptions of Installer Menu Items
000 - INSTALLER SEQUENCE
Species entry sequence to the Installer Menu.
0 = 9876 1 = 4321
2 = 1478 3 = 3698
001 - POWER MANAGE (Power Management)
Energy saving feature. Determines the number of hours, in the
range 1 to 7, of inactivity allowed, either at the TV control panel
or from the remote, before the TV automatically turns itself OFF. If
set to 0, Power Management is disabled.
002 - AC ON (AC Power Switchable)
If set to 1, this allows the TV to turn ON when AC power is
applied. Pressing the POWER button is not necessary. This is
desirable if the TV is plugged into a switched AC outlet (i.e., a
set-top box). Set to 2 or 3 to enable the Instant ON feature (see
additional information below). Set to 0 (default) for standard TV
turn ON/OFF operation.
The Instant ON feature allows the TV to turn ON when AC power
is applied, but with video and audio muted (Muted ON). The TV
retains its ON status while appearing to be OFF. Pressing the
POWER button toggles Off/On the video and audio mutes, so that
the TV appears to turn ON instantly.
• If this item is set to 2, the TV will reboot and, if applicable (i.e.,
item 119 DATA CHANNEL set from 1 to 135 or 253), check for
and download any available updates from the Pro:Centric server
at every turn OFF. This setting is not recommended if the TV will
be congured with a resident application.
• If this item is set to 3, the TV will not reboot to check for and
download updates at turn OFF, with the following exception:
the rst time the TV is turned OFF after this item is set to 3, the
TV will reboot and initiate an update event (Data Channel Auto
Search and/or check for and download of updates—see also
paragraph below). This setting is recommended if the TV will be
congured with a resident application. In this mode, the standard
check for and download of updates is under application control.
Refer to your site-specic documentation for further information
on conguring the TV with a resident application.
When this item is set to 2 or 3, the TV also will reboot and initiate
an update event once every 24 hours. During the update event,
the TV, as applicable, performs a Data Channel Auto Search (item
119 set to 255) and/or checks for and downloads any available
updates from the Pro:Centric server (item 119 DATA CHANNEL
set from 1 to 135 or 253). The time at which this event occurs
depends on the setting of item 121 UPDATE TIME HR. See item
119 and 121 descriptions for further information. Once the update
cycle is complete, the TV completes the reboot and resumes its
Muted ON state.
Note: If set to 1, the TV does not respond to ON/OFF commands
from either the remote or the display panel, and the SLEEP TIMER
is also nonfunctional.
003 - BAND/AFC (Band/Automatic Frequency Control)
There are four possible settings for this option:
0 = Broadcast 1 = CATV (default)
2 = HRC 3 = IRC
If some channels were not found by Auto Tuning (Channel
Search), select the appropriate Band setting here, and add the
channels using the Channel Edit option in the Channel Menu.
004 - STRT CHANNEL (Start Channel)
If active, this function allows you to determine the initial Major
Start Channel number when the TV is turned ON. This feature is
useful for an in-house information channel, since the TV would
always select that channel when it is turned ON. If set to 255,
the last channel tuned before the TV was turned OFF will be the
channel tuned when the TV is turned ON again.
0 = Aux 127 = Map to Major CH 4
1 ~ 125 = Major CH # 255 = Last Channel
126 = Map to Major CH 3
Note: For a digital Start Channel, always remember to set item
104 to the Minor Start Channel number.
Note: 126 and 127 are mapped only in SONIFI PPV Mode.
005 - CHAN LOCK (Channel Lock)
Channel Lock is ideal if the system must always be on the same
channel. Changing channels with the Channel Up/Down or keypad
numbers is impossible. Channel Lock is inactive if set to 0 (default).
Generally, this feature is used in connection with item 004 STRT
CHANNEL where the Start Channel may, for example, be set to
3 or 4. If the Start Channel is 3, then the TV will remain locked on
channel 3.
NOTE: For items 007, 008, and 009
For legacy reasons, the scale used is 0 – 63. The PTC software
will translate this to the 0 – 100 scale used by the TV.
To translate a TV volume level to the Installer Menu value, use
the following formula:
Installer Value = TV Value x 63
100
Enter only the whole number (disregard fractions).
007 - STRT VOLUME (Start Volume)
This function allows the Installer to determine the initial volume
level setting when the TV is turned ON. This feature is useful for
an in-house information channel, since the TV will always select
that volume level when it is turned ON. The range of values is 0
to 63, 255. If set to 255, the last volume level before the TV was
turned OFF will be the current volume level when the TV is turned
ON again.
26
206-4278
Installer Menu (Cont.)
008 - MIN VOLUME (Minimum Volume)
This function determines the minimum volume level allowable
with the Volume (VOL) Up/Down control. In this way, for example,
someone cannot set the volume too low to hear. The value range
is from 0 to 63. The factory default is 0, which provides the full
range of volume control, if item 009 MAX VOLUME is set to 63. It
is recommended to set the same value on every TV.
Note: The minimum volume level cannot have a value setting
higher than the maximum volume level (described below).
009 - MAX VOLUME (Maximum Volume)
This function determines the maximum volume level allowable with
the Volume (VOL) Up/Down control. In this way, for example, someone cannot set the volume level high enough to disturb others. The
value range is 0 to 63, with 63 as the default, which gives the user
the full range of volume control, if item 008 MIN VOLUME is set to
0. It is recommended to set the same value on every TV.
Note: The maximum volume level cannot have a value setting
lower than the minimum volume level (described above).
010 - MUTE DISABLE
Enables or disables sound mute function. If set to 1, sound cannot
be muted. If set to 0, sound can be muted.
011 - KEY DEFEAT
If set to 1, Key Defeat is enabled, which means that end users
cannot access or navigate within the on-screen menu(s) from the
display panel; i.e., joystick button menu navigation functions will
not be available. Set to 0 to disable Key Defeat. Note that all IR
features remain functional regardless of this setting; users can
always access the TV menus by pressing MENU SETTINGS on
the remote.
015 - SLEEP TIMER
If set to 1, the Sleep Timer feature may be used. If set to 0, the
Sleep Timer is not available.
016 - EN. TIMER (Enable On/Off Timers)
If set to 1, the Timer function is available to the end user and
enabled continuously. Set to 0 to disable On/Off timers.
Note: The TV clock must be set in order for timers to be used.
Values IR Mode Bed #
0 Disabled N/A
16 – 24 Multi-code Remote 1 – 9
Note: For further information, see documentation for the accessory
package that includes the multi-code remote.
021 - V-CHIP (Parental Control)
Set to 1 to activate V-Chip (Parental Control) and have it available
to the end user to lter and control or otherwise restrict programming content that can appear. Set to 0 to turn the V-Chip feature
Off (not available to user); no programming restrictions can be set.
022 - MAX BLK HRS (Maximum Block Hours)
Sets hours from 0 to 99 for the maximum V-Chip (Parental Control)
block hours. Default setting is for 12 blocking hours.
Note: This item is not available in the Installer Menu when item 021
V-CHIP is set to 0 or when item 084 PERMANENT BLK is set to 1.
023 - CAPTION LOCK
If set to 0, captions are OFF when the TV is turned ON. Set to 1 to
use the caption setting congured before the TV was turned OFF
when the TV is turned ON.
028 - CH. OVERIDE (Channel Override)
Applicable for Pass-through Mode only. If set to 1, users can select
channels either with Channel Up/Down or by direct keypad entry.
This setting also allows full access to channel settings in the TV
setup menus (i.e., channels may be added or removed from the
channel lineup, channel labels and icons may be edited, etc.).
If set to 0, the channel lineup is locked. That is, user access to
channel settings in the TV setup menus is restricted, and users
can only tune to the channels that are included in the channel
lineup. Also, in this case, users can only select channels using
Channel Up/Down; direct keypad entry is not available.
029 - OLD OCV (On Command Video™)
Set to 1 to remap the PTC’s direct tune channels for Aux inputs
from 13x to 9x. This allows 2-digit only tuning systems (i.e., legacy
OCV) to direct tune Aux inputs. See also Reference section, “TV
Aux Input Conguration.”
017 - ALARM
Gives the installer the option of making the Alarm function available
to the end user. If set to 1, the Alarm function is available to the end
user. Set to 0 to disable the Alarm function.
Note: The TV clock must be set before the Alarm function will work.
020 - FEATURE LEVEL
Determines an additional IR code scheme to which the TV will
respond, allowing for the use of unique IR codes based on “bed
number” in a multi-TV single room installation. First determine the
IR mode; then select the bed number.
206-4278
030 - ACK MASK
MPI Communication Parameter. When set to 1, enables ACK
feature of MPI.
031 - POLL RATE
MPI Communication Parameter. Selects poll rate for MPI. Step size
of 16 ms. Changing from default may affect communication via MPI.
032 - TIMING PULSE
MPI Communication Parameter. Sets baud rate for MPI. Step size
of 4.3 uS. Changing from default may affect communication via
MPI.
27
Installer Menu (Cont.)
035 - HDMI1 ENABLE
Set to 1 to enable HDMI 1 input in DTV Mode. Set to 2 to enable
HDMI 1 input in PC Mode. Set to 0 to disable display panel HDMI
1 input.
Note: This setting is ignored if item 093 RJP AVAILABLE is set to 1.
039 - REAR AUX EN. (Rear Aux Enable)
Set to 1 to enable display panel rear Aux (Video 1) input. Set to 0
to disable display panel rear Aux (Video 1) input.
041 - SIMPLINK EN
Set to 0 to disable the SIMPLINK feature. Set to 1 to enable
SIMPLINK functionality without enabling remote control access to
the SIMPLINK Menu. Set to 2 to enable both SIMPLINK functionality and SIMPLINK Menu access, though note that the Speaker
menu option will be inaccessible/grayed out. Set to 3 to enable
all aspects of SIMPLINK feature and SIMPLINK Menu. If a home
theater device is connected to the TV, users can select either the
TV or HT (home theater) speaker.
Note: When both this item and item 042 AUTO INPUTS are
enabled in the Installer Menu, HDMI inputs will be detected by
SIMPLINK, but the Auto Input(s) Sensing Feature will not function.
042 - AUTO INPUTS
Determines the Aux inputs for which auto-sensing is enabled. Set
to 0 to disable auto-sensing for all available inputs. Set to 255 to
enable auto-sensing for all available inputs. For information on
options for individual input settings, see Reference section, “Auto
Input(s) Sensing Feature.”
Note: In order for auto-sensing to be enabled for an input, that
input must also be enabled in the Installer Menu. For example, to
enable auto-sensing for HDMI 1, item 035 HDMI1 ENABLE must
also be set to 1 or 2. Also, see note above regarding TV operation
when both this item and item 041 SIMPLINK EN are enabled.
Note: When this item is enabled in the Installer Menu, item 093
RJP AVAILABLE is automatically set to 0.
053 - DIS. CH-TIME (Disable Channel-Time)
Set to 1 to disable the Channel-Time display; Channel-Time display
will not appear. Set to 0 to enable the Channel-Time display.
069 - EN. CH-T COL. (Enable Channel-Time Custom Color)
Set to 1 to enable custom color for the Channel-Time display. Set
to 0 to disable custom color for the Channel-Time display.
070 - FOR. CH-TIME (Channel-Time Display Foreground Color)
Set according to Color Chart:
0 = Black 3 = Cyan 6 = Yellow
1 = Blue 4 = Red 7 = White
2 = Green 5 = Violet
Note: If foreground color and background color are the same, the
menu background will be transparent.
Note: Applies only to “Channel Not Available” message if item
073 CH NOT AVBLE is set to 1 (enabled). Also, items 070 FOR.
CH-TIME and 071 BCK. CH-TIME are not available in the Installer
Menu when item 069 EN. CH-T COL. is set to 0.
071 - BCK. CH-TIME (Channel-Time Display Background Color)
See description for item 070 FOR. CH-TIME above. The color
chart is the same for both items.
073 - CH NOT AVBLE (Channel Not Available)
If set to 1 and item 028 CH. OVERIDE is set to 0, a “CHANNEL
NOT AVAILABLE” message is displayed when a user attempts to
direct tune a channel that is not included in the channel lineup.
Note: This item is not available in the Installer Menu when item
028 CH. OVERIDE is set to 1.
075 - REVERT CH (Revert to Start Channel)
If set to 1 and loss of MPI communication occurs, TV automatically
tunes to the specied Start Channel.
Note: This item is not available in the Installer Menu when item
004 STRT CHANNEL is set to 255.
046 - STRT AUX SRCE (Start Aux Source)
Sets the starting Aux source. When turned ON, the TV will tune to
starting Aux source if item 004 STRT CHANNEL is set to 0.
1 = Video 1 4 = RGB 7 = HDMI 3
3 = HDMI 1 5 = HDMI 2 255 = Last Aux
Note: Above is applicable only if all Aux sources are enabled.
Note: This item is not available in the Installer Menu unless item
004 STRT CHANNEL is set to 0.
047 - AUX STATUS
Set to 1 for MPI Aux source to be reported as a channel number
instead of channel 0. Set to 0 to disable Aux identication change.
Controls MPI status channel response for Aux inputs.
28
078 - UPN MSB (UPN Most Signicant Byte)
User programmable number, most signicant byte readable by
MPI command. Note: Not linked to serial number.
079 - UPN MSB-1 (UPN Most Signicant Byte-1)
User programmable number, most signicant byte-1 readable by
MPI command. Note: Not linked to serial number.
080 - UPN MSB-2 (UPN Most Signicant Byte-2)
User programmable number, most signicant byte-2 readable by
MPI command. Note: Not linked to serial number.
081 - UPN LSB (UPN Least Signicant Byte)
User programmable number, least signicant byte readable by
MPI command. Note: Not linked to serial number.
206-4278
Installer Menu (Cont.)
082 - CHKSM ERROR (Checksum Error)
Enforces rigid MPI checksum validation. Set to 1 for validation.
Set to 0 to disable (does not check checksum on MPI async port).
SPI is always checked.
083 - HANDSHK TIME (Handshake Time)
Adds an additional delay to the handshake time which is 64 msec,
thus relaxing MPI timing requirements to be compatible with PCbased Windows controlled systems. Range is 0 - 5.
(Timeout = 25.5MS + [25.5 MS* Handshake time].)
084 - PERMANENT BLK (Permanent Block)
Allows Lock (Parental Control) blocking schemes to be permanent
by disabling the blocking hours function. Set to 1 to install Parental
Control restrictions permanently. Set to 0 for user-specied hours
control of blocking schemes.
Note: This item is not available in the Installer Menu when item
021 V-CHIP is set to 0.
086 - V. MUTE TIME (Video Mute Time)
Use to extend the normal video mute time during channel change.
For example, you may wish to extend the normal video mute time
to prevent the display of encrypted video (i.e., from a Pro:Idiom
encrypted channel) that has not yet been decrypted. When set to
0, the normal video mute time is not extended. Set from 1 to 50 to
increase the normal video mute time in 100 ms step increments up
to a maximum of 5 seconds (e.g., the value of 25 represents 2.5
seconds, or 25 x 100 ms = 2.5 seconds).
087 - REAR RGB EN. (Rear RGB Enable)
Controls access to rear RGB input on TV. Set to 0 to disable RGB
input. Set to 1 to enable RGB input. Set to 17 to initiate a one-
time automatic conguration after an AC power cycle; otherwise,
automatic adjustment will be performed each time the RGB input
is accessed.
088 - EN NOISE MUTE (Enable Noise Mute)
Applicable for analog channels only. If set to 1, audio mutes if no
signal is present.
090 - KEY LOCK
If set to 1, Key Lock is enabled, which means that all display panel
joystick button functions will be locked, i.e., non-functional. Set to
0 to disable Key Lock. Note that all IR features remain functional
regardless of this setting.
091 - HDMI2 ENABLE
Set to 1 to enable HDMI 2 input in DTV Mode. Set to 2 to enable
HDMI 2 input in PC Mode. Set to 0 to disable display panel HDMI
2 input.
092 - HDMI3 ENABLE
Set to 1 to enable HDMI 3 input in DTV Mode. Set to 2 to enable
HDMI 3 input in PC Mode. Set to 0 to disable display panel HDMI
3 input.
093 - RJP AVAILABLE (Remote Jack Pack Available)
• 0 = Remote jack pack is not available or disabled.
• 1 = Legacy Model RJPs: HDMI Mode
Enables RJP feature for use with full cable bundle models. In
this mode, when an HDMI source is connected to the RJP, both
digital video and audio are expected via the HDMI cable. If no
digital audio is present, no audio will be heard.
• 2 = Legacy Model RJPs: DVI Mode
Enables RJP feature for use with full cable bundle models. In
this mode, when an HDMI/DVI source is connected to the RJP,
only digital video is expected via the HDMI cable. Analog audio
is provided via a separate cable, from the source, connected to
an RJP AUDIO IN. If no analog audio cable is connected, tuner
audio will be heard.
• 5 = Scaler Model RJPs: HDMI Mode
Enables RJP feature for use with reduced cable bundle models.
In this mode, when an HDMI source is connected to the RJP,
both digital video and audio are expected via the HDMI cable. If
no digital audio is present, no audio will be heard.
• 6 = Scaler Model RJPs: DVI Mode
Enables RJP feature for use with reduced cable bundle models.
In this mode, when an HDMI/DVI source is connected to the RJP,
only digital video is expected via the HDMI cable. Analog audio
is provided via separate cable, from the source, connected to
an RJP AUDIO IN. If no analog audio cable is connected, tuner
audio will be heard.
Note: See also Reference section, “RJP Model List & Input Autosensing Hierarchy.” Settings 1, 2, 5, and 6 allow the lodge staff to
customize each TV’s RJP setup based on customer requirements.
Note: When this item is enabled in the Installer Menu, item 042
AUTO INPUTS is automatically set to 0.
094 - SAP MENU EN (2nd Audio Program)
Set to 1 to enable the SAP feature in the Function Menu, when
the Function Menu is available (i.e., TV is not in Pass-through
Mode). Set to 0 to disable the SAP feature in the Function Menu,
when the Function Menu is available.
096 - DEF. ASP. RATIO (Default Aspect Ratio)
Selects default aspect ratio at power up:
0 = Set By System 1 = 4:3
2 = 16:9 (default) 3 = Just Scan
4 = Zoom
Note: This item is not available in the Installer Menu unless item
106 ASP RATIO LOCK is set to 0.
206-4278
29
Installer Menu (Cont.)
097 - AUDIO OUTPUT
Determines availability and signal type/level (xed speaker,
variable speaker, or xed line level [amplier]) of the audio
output to be used by external audio equipment connected to the
SPEAKER OUT / LINE OUT jack on the TV. Set to 0 to disable
audio output. Otherwise, see the table below and set as required
in accordance with audio equipment. See also Reference section,
“External Stereo Speaker Specifications.”
Value Status
Speaker Output 1 Fixed 0.01 Watts
2 Fixed 0.03 Watts
3 Fixed 0.05 Watts
4 Fixed 0.10 Watts
5 Fixed 0.20 Watts
6 Fixed 0.50 Watts
7 Fixed 1.00 Watt (default)
8 Control with volume
Line Output 9 Fixed line level (typically 400 mVrms ±
100 mVrms @10KΩ) output
098 - PRO:CENTRIC
Selects the Pro:Centric Application Mode. Set to 0 (default) to
disable the Pro:Centric application. Set to 1 for Flash Mode. Set
to 2 for GEM (Java Application) Mode.
The TV must be turned OFF for a few seconds to initiate the
Pro:Centric application download. When the TV is turned back ON,
it may take several minutes to load the Pro:Centric application after
the initial download.
Note: This item is not available in the Installer Menu when item
119 DATA CHANNEL is set to 0.
099 - BACK LIGHTING
Sets the TV screen brightness at power up. Default setting is 255.
• 1 - 100 Static Back Lighting
(1 = Dimmest picture, 100 = Brightest picture)
• 101 - 200 Dynamic Back Lighting
(101 = Dimmest picture, 200 = Brightest picture)
If set between 101 and 200, the TV automatically controls back
lighting depending upon the picture level of the current program. If
set to 255, back lighting is controlled via the Picture settings in the
TV setup menus.
102 - ATSC BAND
Sets up TV to receive different types of incoming signals.
0 = Broadcast 1 = CATV 2 = HRC
3 = IRC 4 = Same as NTSC
103 - ATSC TUNE MODE
Sets ATSC tuning mode. Default set to 1 for Physical Channel
scan. Set to 0 for Virtual Channel scan.
104 - START MINOR CHANNEL
Sets Minor Start Channel number at power up. 0 = NTSC. If not
0, number selected is the digital channel’s Minor Start Channel
number.
Note: This item is not available in the Installer Menu when item
004 STRT CHANNEL is set to 0 or 255.
106 - ASP RATIO LOCK (Aspect Ratio Lock)
Set to 1 to retain previous aspect ratio with power off. Set to 0 to
retain default aspect ratio with power off. See item 096 DEF. ASP.
RATIO above.
116 - VIDEO MUTE EN (Video Mute Enable)
Applicable for analog channels only. If set to 1, video mutes
(blank screen) when no signal is present.
117 - FACT DEFAULT (Factory Default)
Set to 1 and press OK to restore the factory default settings of all
Installer Menu items. Once complete, the value returns to 0.
Caution: If set to 1, this clears all Installer Menu custom
settings and restores the factory default settings. It also
clears the channel lineup, including any assigned
channel icons and custom text labels.
Note: See also Reference section, “Restoring Factory Defaults on
the TV(s),” for further information.
118 - POWER SAVINGS
Default set to 3—the power circuitry for both the embedded b-LAN
module and the GAME CONTROL/MPI port is only powered when
the TV is turned ON. When the TV is turned OFF, the embedded
b-LAN and the GAME CONTROL/MPI port are not powered.
Note that the TV must be turned ON in order to communicate with
the embedded b-LAN module for conguration and control when
POWER SAVINGS is set to 3. If POWER SAVINGS is set to 1,
the b-LAN module is always powered.
Similarly, if MPI communication is required for external MPI
control, POWER SAVINGS should be set to 1 so that the GAME
CONTROL/MPI port circuitry is always powered.
Note: See Reference section, “b-LAN Setup & Overview,” for
further information.
Caution: POWER SAVINGS should NEVER be set to 7.
This setting is intended for factory use only.
30
206-4278
Installer Menu (Cont.)
119 - DATA CHANNEL
Set to 0 to disable. Set from 1 to 135 to match the RF channel
number that will be used by the Pro:Centric server as its data
channel. *
For TVs in Pass-through Mode or FTG Mode via CPU, if this item
is left at its default value (255), the TV’s Data Channel Auto Search
feature will be enabled (see additional information below).
Note: The Data Channel Auto Search feature is not available
when the TV’s EBL is in FTG Mode. If the DATA CHANNEL value
is 255 when the TV is congured for FTG Mode via EBL, DATA
CHANNEL is defaulted to 0.
Data Channel Auto Search feature: When this item is set to 255
(default), once every 24 hours, the TV will initiate a search of 10
predened channels (10, 20, 30, ... 100) and then, if necessary,
perform a complete search of the RF channels (1 to 135) in an
attempt to nd the RF channel used by the Pro:Centric server as
its data channel. If the Pro:Centric RF channel is found, the DATA
CHANNEL value will be changed from 255 to match the server’s
RF channel number. The time at which the Auto Search occurs
depends on the setting of item 121 P:C RF WAKE HR. See item
121 description for further information.
Note: Pro:Centric application updates are downloaded from the
Pro:Centric server to the TV when the TV is turned ON; however,
TV E-Z Installation updates are downloaded to the TV when the TV
is turned OFF. While E-Z Installation updates are in progress, it is
not possible to turn ON the TV.
Note: The Data Channel is automatically set to “253” if Media
Type is set to “IP” either in the EZ-Manager Wizard or in the IP
Environment / Pro:Centric Menu on the TV (see “EZ-Manager
Wizard” on pages 12 to 18 or “Pro:Centric Setup” on pages 47
to 48, respectively) or if Installer Menu item #119 Data Channel
is set to “IP Address” in the FTG File Manager, which is used to
congure TV CPUs for FTG Mode operation. It is not possible to
change the value to “253” directly in the Installer Menu.
Under standard TV OFF/ON operating conditions (i.e., item 002 AC
ON is set to 0), a Wake For Update event occurs when the TV is
OFF and causes the TV’s CPU to temporarily turn ON, perform the
update cycle, and then turn back OFF, all while the TV appears to
be OFF. If item 002 AC ON is set to 2 or 3 for Instant ON, then the
TV’s CPU is always ON and Wake For Update occurs when the TV
is in its Muted ON state (i.e., the TV only appears to be OFF). The
Wake For Update event causes the TV’s CPU to reboot in order
to perform the update cycle and then return to its Muted ON state.
See also description for item 002.
If this item is set to 128 (OFF), the time at which a Data Channel
Auto Search (item 119 set to 255) and/or an Instant ON update
(item 002 set to 2 or 3) occurs is determined as follows: The TV
initiates the search and/or checks for updates at 2:00 AM (if the
TV clock is set) or after two hours of elapsed time from when AC
power was applied (if the TV clock is not set). If the TV display
is ON when a Wake For Update event is to occur, the update will
take place the next time the TV is turned OFF.
Note: This item is not available in the Installer Menu when item
119 DATA CHANNEL is set to 0, except when item 002 AC ON is
set to 2 or 3 for Instant ON.
Note: The TV clock must be set in order for a Wake For Update
event to occur at the precise time of day in accordance with item
121 and item 122 settings.
122 - UPDATE TIME MN
Set the Wake For Update minute from 0 to 59. See also description
for item 121 UPDATE TIME HR above.
Note: This item is not available in the Installer Menu unless item
121 UPDATE TIME HR is set from 0 to 23.
Note: The TV clock must be set in order for a Wake For Update
event to occur at the precise time of day in accordance with item
121 and item 122 settings.
121 - UPDATE TIME HR
Based on the settings of this item and item 122 UPDATE TIME MN,
the Wake For Update feature wakes the TV once daily to check for
and, if applicable, download updates from the Pro:Centric server.
Set the Wake For Update hour from 0 to 23. This item uses the
24-hour clock format. The value “128” (default) is displayed as
“OFF.” Directly entering 128 resets the default value (OFF) for this
item, though note that this setting does not mean the TV will not
initiate update events—see additional information below.
* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.
206-4278
31
Custom Master TV Setup
This section describes how to create a customized Master TV Setup for cloning purposes when
the TV is in Pass-through Mode. All cloning (export and import) processes on the TV are performed
via USB memory device / “.tlx” le. The Master TV Setup may be exported to a Clone (.tlx) file,
which can then be used (i.e., imported) to configure either TVs that are to remain in Pass-through
Mode or TVs that are to be configured for FTG Mode via CPU.
Cloning requirements and procedures are described in detail on pages 35 to 38.
Note: You can also use the FTG File Manager to create an FTG Conguration (.tlx) le for FTG
Mode via CPU conguration, if desired (see pages 39 to 40). However, it is not possible to
customize TV setup menu settings in the FTG File Manager. If you wish to include customized TV
setup menu settings in the TV conguration, in addition to the channel lineup and Installer Menu
settings, perform the Master TV Setup procedure to create a Clone (.tlx) conguration le.
Before You Begin
• It is recommended that you disconnect all Aux inputs if you intend to run Auto Tuning (Channel
Search). Under certain conditions, Auto Tuning is disabled if there is an Aux input active.
• A Clone (.tlx) le comprises Installer Menu settings, IP Environment Menu settings (with the
exception of Network Connection settings), and all TV sources’ (analog, digital, AV1, HDMI, etc.)
clonable setup menu settings. See also “Clonable TV Setup Menu Features” list below.
• If the “.tlx” le (either a Clone or FTG Conguration le) to be imported on the Target TV(s)
contains an FTG Channel Map, the Target TV(s) will be congured for FTG Mode via CPU,
though as part of the import process, you will have the option to select either logical or physical
channel tuning. If you would like the Target TV(s) to remain in Pass-through Mode, the “.tlx” le
should not include an FTG Channel Map.
Clonable TV Setup Menu Features
Channel
Auto Tuning (Channel Lineup)
Manual Tuning
Channel Edit
Channel Label
Picture Mode
Audio
Sound Mode
Sound Effect
Auto Volume
Sound Out
AV Sync Adjust
Sound Optimizer
Note: Some menu options vary between analog and digital channels and Aux inputs.
Time
Clock
− Clock Mode (Auto/Manual)
− Time Zone
− Daylight Saving
Auto Off
Option
Language
Caption
Standby Light
32
206-4278
Custom Master TV Setup (Cont.)
Custom Master TV Setup Procedure
1. Turn ON the TV.
The next step depends on whether the EZ-Manager Wizard appears
on the screen when you turn ON the TV:
• If the wizard is displayed, the TV is in the required factory default state.
Exit the wizard, and then continue with step 2.
• If the wizard is not displayed, restore the TV to a factory default
condition before continuing with this procedure. See Reference
section, “Restoring Factory Defaults on the TV(s),” as necessary,
for further information.
2. Set Installer Menu items.
This step provides specic instruction only on the Installer Menu items
that should be set on a Master TV. Refer to pages 22 to 31 for detailed
information on all Installer Menu items.
a) Use the Installer Remote to access the PTC Installer Menu (see
“Accessing the Installer Menu” on page 22 for further information).
b) Set Installer Menu item 003 BAND/AFC, as appropriate.
• Broadcast: Set to 0. • HRC: Set to 2.
• CATV: Set to 1 (default). • IRC: Set to 3.
c) Set any other Installer Menu items that affect your TV programming
network to the required conguration. For example, enable/disable
Aux inputs, set a Start Channel, etc.
d) After you have adjusted all Installer Menu item settings as required,
and if you do not need to congure any IP Environment settings (see
note below), press OK once on the Installer Remote to save your
changes; then, press OK again to exit the menu.
Note: If you intend to congure settings in the IP Environment Menu,
which is accessible from the Installer Menu, you can proceed directly
to step 3. All Installer Menu settings will be saved automatically when
you access the IP Environment Menu.
3. Congure IP Environment settings.
Note: You cannot return directly to the Installer Menu from the IP
Environment Menu; thus, you may wish to set all Installer Menu items
as needed before you access the IP Environment Menu. Otherwise,
you will need to reaccess the Installer Menu to set additional items.
Navigate to Installer Menu item 119 DATA CHANNEL, and press
2-5-3 + MENU SETTINGS to launch the IP Environment Menu. Then,
complete network conguration as required. See “IP Environment
Setup” on pages 45 to 48 for further information.
xxLX570H PTC INSTALLER MENU
CPU-CTV
000 INSTALLER SEQ 000
UPN 000-000-000-000 ASIC D279
PTC V1.00.008 CPU V3.00.20.01
Typical Installer Menu
003 BAND/AFC 001
Adjust the value for this
Installer Menu item, as required.
206-4278
(Continued on next page)
33
Custom Master TV Setup (Cont.)
(Continued from previous page)
4. Set up TV features.
On-screen setup menus control the features of the TV. Press MENU
SETTINGS on the Installer Remote to access the TV setup menus,
and then set Channel, Picture, Audio, Time, etc. options to the
desired configurations. See “Clonable TV Setup Menu Features” list
on page 32 and also notes below.
Note: If you intend to use the TV Zoning feature, make sure to
assign the appropriate TV Zone # at this time as described in
Reference section, “Using the TV Zoning Feature.”
Note: If desired and if appropriate, you can run Auto Tuning (see
step 5) prior to completing this step.
5. (Optional) Run Auto Tuning.
If you are creating a Master TV Setup for cloning purposes and you
want the Target TV(s) to remain in Pass-through Mode, do NOT run
Auto Tuning. If you export a Master TV Setup that includes an autotuned/edited channel lineup, thereby creating a Clone (.tlx) file with
an FTG Channel Map, and then import the Clone file on a Target TV,
this will put the Target TV in FTG Mode via CPU.
Note: When you import a Clone/Configuration (.tlx) file that contains
an FTG Channel Map on a Target TV (for FTG Mode via CPU
configuration), you will have the option to select either logical or
physical channel tuning. For either selection, the channel sequence
will be based on the order in which the channels appear in FTG
Channel Map. You can view and/or edit the channel sequence in
the FTG File Manager, as required.
a) Use the Installer Remote to access the Channel Menu. Then,
select Auto Tuning and follow the on-screen instructions to
search for all available analog and digital channels.
b) Use the Channel Edit option in the Channel Menu to edit the
channel lineup, as necessary. Add/delete channels per your
system requirements.
6. Verify the TV setup.
Make sure the TV features are set per your requirements. Also, if
applicable, verify that the channel lineup is correct.
The Master TV Setup is now ready to be saved (exported) to a USB
memory device. See “Cloning Procedures” on pages 35 to 38.
LOCK
Use the TV setup menus to set the TV
features to the desired configuration
AUDIO
OPTION
for the end user.
CHANNEL
INPUT
CHANNEL
• Auto Tuning
• Manual Tuning
• Channel Edit
• Channel Label
(Optional) Use Channel Menu
options to run Auto Tuning and
edit the channel lineup.
Move
TIME
MY MEDIA
OK
34
206-4278
Cloning typically refers to the process of using a Master TV Setup to configure a
Target TV. This section describes how to save (export) a Master TV Setup and then
transfer (import) it to a Target TV using a USB memory device / Clone (.tlx) le.
You can also create an FTG Conguration (.tlx) le using the FTG File Manager and
then use the Import Clone File procedure to transfer the conguration to Target TVs.
Refer to “Creating an FTG Conguration File” on pages 39 to 40, as necessary.
Exporting a Clone File
This section describes how to export Master TV Setup conguration to a
USB memory device / Clone (.tlx) le.
Before You Begin
• Ensure the USB device has been formatted with FAT format.
• If the TV is NOT already in FTG Mode via CPU, complete the Custom
Master TV Setup procedure (see pages 32 to 34).
• If you would like the Target TV(s) to remain in Pass-through Mode after the
Clone le is imported, ensure the Master TV does not have an auto-tuned/
edited channel lineup; otherwise, importing the exported le will result in the
Target TV(s) being congured for FTG Mode via CPU.
• If you intend to use the TV Zoning feature, make sure to assign the
appropriate TV Zone # as described in Reference section, “Using the TV
Zoning Feature,” BEFORE performing the procedure below.
• It is not possible to clone a Master TV’s clock. Either set a Target TV’s
clock manually, or use the Auto Clock setting in the TV setup menus.
• Since the Export Clone File process retrieves the channel lineup from
the CPU, if the TV is currently in FTG Mode via EBL (FTG Channel Map
resides in EBL) it is not possible to export an FTG Channel Map.
Caution: Do not unplug the TV power cord or remove the USB
memory device while exporting is in progress, as doing so may
cause the TV to malfunction or harm the USB device, respectively.
Export Clone File Procedure
1. Ensure the Master TV is set up completely and turned ON.
2. Insert the USB memory device into the USB port on the Master TV.
3. Press MENU SETTINGS on the Installer Remote to display the TV
setup menus (TV is in Pass-through Mode) or the Function Menu (TV is
already in FTG Mode).
4. Use the arrow navigation keys to select/highlight either the Option menu
icon from the TV setup menus or the Lock menu icon from the Function
Menu. Then, press the number “7” key a total of seven times to display the
TV Manager / USB Download Menu.
5. To gain access to the “Export Clone File” option in the TV Manager / USB
Download Menu, key in the following number sequence on the Installer
Remote: 9-8-7-6.
Cloning Procedures
TV Manager
USB
Diagnostics
Previous
Note: TV Manager / Diagnostics
Export Clone File
Select the le name and press OK to start
Previous
Export Clone File... 25 %
Do not remove the USB from the port! Do not unplug!
xxLX570H-UA00001.tlx
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
Export Clone File
OK
is for service use only.
xxLX570H-UA00001.TLX
►
►
OK
(Continued on next page)
206-4278
35
Cloning Procedures (Cont.)
(Continued from previous page)
6. Use the Up/Down arrow keys to select Export Clone File, and then press OK.
7. In the Export Clone File window, to differentiate this Clone le from other LX570H Clone les,
you can use the Up/Down arrow keys to change the last ve digits of the lename. Press OK
when you are ready to continue.
Export progress will be shown in a new window. Do NOT remove the USB device while exporting
is in progress. When the export process is complete, the TV Manager / USB Download menu
will reappear on the screen.
8. Press on the Installer Remote to exit the TV Manager / USB Download Menu, and remove
the USB memory device from the Master TV.
Note: If the Master TV has a channel lineup, during the export process, logical channel
numbers are automatically assigned in ascending order, starting with 0 (zero), to the
physical RF channels of the TV channel lineup to create an FTG Channel Map. See also
note below.
Note: If the exported Clone file is to be used for FTG Mode via CPU configuration (i.e.,
it contains an FTG Channel Map), it is highly recommended that you open the file in
the FTG File Manager—BEFORE transferring (importing) the file to any Target TVs—to
verify FTG Channel Map and FTG Installer Menu settings. This will also enable you to
confirm channels and add channel attributes, labels, etc.
Importing a Clone File
This section describes how to transfer (import) a Clone or FTG Conguration (.tlx) le from a USB
memory device to a TV using the TV Manager / USB Download Menu “Import Clone File” option.
The “.tlx” le may be created either from a Master TV Setup that was saved (exported) from a
Master TV or in the FTG File Manager.
Before You Begin
• Ensure the USB device has been formatted with FAT format.
• Avoid using special characters, such as ?, &, @, etc., in the Clone/Conguration (.tlx) lename.
• If the EZ-Manager Wizard appears on the screen when you turn ON the Target TV, you can use
the wizard’s “USB Conguration” option to access the TV Manager / USB Download Menu and
complete the import procedure (see “TV Conguration Options” and/or “USB Conguration” on
pages 13 and 18, respectively, as necessary).
• You may also use the Ez Download utility to import the Clone/Conguration (.tlx) le. See “Ez
Download Utility” on pages 19 to 21 for further information.
• If the Target TV is currently in Pass-through Mode and you intend to use the TV Zoning feature—
i.e., the Clone/Conguration (.tlx) le you are importing contains an FTG Channel Map and/or
FTG prole(s) with TV Zone assignments—make sure to assign the appropriate TV Zone # in the
TV when directed to do so in the procedure below. See Reference section, “Using the TV Zoning
Feature,” for further information.
• If you would like the Target TV(s) to remain in Pass-through Mode after the Clone/Conguration
(.tlx) le is imported, ensure the “.tlx” le does not contain an FTG Channel Map; otherwise, the
import procedure will result in the Target TV(s) being congured for FTG Mode via CPU.
36
(Continued on next page)
206-4278
Cloning Procedures (Cont.)
(Continued from previous page)
• If a Clone (.tlx) le (exported Master TV Setup) contains an FTG Channel Map, the physical RF
channels in the FTG Channel Map have been assigned logical channel numbers (see “Exporting a
Clone File” above). When you import the Clone le with the FTG Channel Map on the Target TV(s),
you will have the option to select either logical or physical channel tuning. Even if you select
physical channel tuning, the (list of) physical RF channels in the FTG Channel Map will remain in
logical order.
• If an FTG Conguration (.tlx) le (created in the FTG File Manager) contains an FTG Channel
Map, each logical channel number in the FTG Channel Map has been assigned a physical RF
channel or an Aux input (the latter designated by 130-0 through 137-0—see also Reference
section, “TV Aux Input Conguration”).
Note: When you import the FTG Conguration le on the Target TV(s), you will have the option to
select either logical or physical channel tuning. If you select physical channel tuning, the physical
RF channels and Aux inputs in the FTG Channel Map will remain in logical order.
• If the Target TV EBL is already in FTG Mode, you cannot use this procedure to make changes
to the FTG Channel Map and FTG Installer Menu settings. You must use a direct PC-to-TV
connection as described in Reference section, “FTG Mode via EBL (Local Conguration),” or an
FMA head end device to recongure the EBL.
• If the preceding condition applies, but you wish to switch the TV to FTG Mode via CPU, see Reference section, “Restoring Factory Defaults on the TV(s),” for further information before proceeding.
• If the Clone/Conguration (.tlx) le was edited/created in the FTG File Manager, it may contain
multiple zoned FTG Installer Menu proles for different TV models. Make sure it includes the
appropriate Installer Menu prole(s) for the Target TV(s) before performing the procedure below.
Caution: Do not unplug the TV power cord or remove the USB memory device while
importing is in progress, as doing so may cause the TV to malfunction or harm the
USB device, respectively.
Import Clone File Procedure
1. Turn ON the Target TV.
2. The next step depends on whether the EZ-Manager Wizard appears on the screen when you
turn ON the TV:
• If the wizard is displayed, you can complete the import procedure via the wizard, as indicated
above (see “Before You Begin”). However, to continue with this procedure and access the
“Import Clone File” option from the TV menus, exit the EZ-Manager Wizard. Then, continue
with step 3.
• If the wizard is not displayed, go directly to step 3.
3. If applicable (see also “Before You Begin” above), make sure to assign the appropriate Zone
designation in the Target TV at this time.
Note: In order for the proper location-specic TV Zone prole data to be applied,
the Zone designation must be assigned in the Target TV(s) BEFORE importing is
initiated.
4. Insert the USB memory device with the Clone/Conguration (.tlx) le into the USB port on the
Target TV.
206-4278
(Continued on next page)
37
Cloning Procedures (Cont.)
(Continued from previous page)
5. Press MENU SETTINGS on the Installer Remote to display the TV
setup menus (TV is in Pass-through Mode) or the Function Menu (TV
is already in FTG Mode).
6. Use the arrow navigation keys to select/highlight either the Option
menu icon from the TV setup menus or the Lock menu icon from the
Function Menu. Then, press the number “7” key a total of seven times
to display the TV Manager / USB Download Menu.
7. With the TV Manager / USB Download Menu on display, use the Up/
Down arrow keys to select Import Clone File, and then press OK.
8. In the Import Clone File window, use the Up/Down arrow keys to select
the “.tlx” le you want to import.
Note: Filenames of exported Clone les are comprised of the TV
model and a ve-digit number, for example,
9. If the Clone/Conguration (.tlx) le includes an FTG Channel Map,
select the desired Channel Tuning / Channel Banner Display option at
the right side of the Import Clone File window:
• Press the green button on the Installer Remote to select
Logical tuning, or
• Press the yellow button on the Installer Remote to select
Physical tuning.
A checkmark will appear at the left of the selected option. Logical
tuning is selected by default.
Note: If the “.tlx” le does not include an FTG Channel Map, the
message, “No Channel Map in TLX le,” will be displayed at the right
of the screen.
10. Press OK on the Installer Remote when you are ready to continue.
Import progress will be shown in a new window. Do NOT remove the
USB device while importing is in progress. When the import process
is complete, an “Updating Complete” window is briey displayed, and
then the TV exits the TV Manager / USB Download Menu.
11. Remove the USB memory device from the Target TV, and verify that the
appropriate configuration is now resident on the Target TV.
xxLX570H-UA00001.TLX
.
TV Manager
USB
Diagnostics
Previous
Note: TV Manager / Diagnostics
Import Clone File
xxLX570H-UA00001.TLX
Previous
Updating Clone File... 50 %
Do not remove the USB from the port! Do not unplug!
xxLX570H-UA00001.tlx
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
OK
is for service use only.
OK
Channel Tuning /
Channel Banner Display
Logical
Physical
Note: If the Target TV was previously in Pass-through Mode and the Clone/Conguration
(.tlx) le that was imported contained an FTG Channel Map, the Target TV is now in FTG
Mode via CPU. After the import process is complete, the TV tunes according to the Start
Channel setting in the Installer Menu. If a Start Channel is specied, the TV will tune to that
channel, though, in the case of FTG Mode via CPU conguration, a channel banner will only
be displayed if the Start Channel is included in the FTG Channel Map (depending on your
selection in step 9, the channel banner will display either the Start Channel’s logical channel
number or physical RF channel number). Otherwise, the TV will either return to the last
channel tuned (TV in Pass-through Mode) or tune to the rst channel in the FTG Channel
Map (TV in FTG Mode via CPU). If the latter, remember that the channels in the FTG
Channel Map are always arranged in logical order, regardless of your selection in step 9.
38
206-4278
FTG File Manager Utilities Overview
As indicated in the introduction to this document, there are two separate and distinct methods for
configuring LX570H TVs for FTG Mode of operation: one method is to configure the TV CPU for FTG
Mode operation, while the other is to configure the TV EBL for FTG Mode operation. FROM A LOCAL
CONFIGURATION STANDPOINT, EACH OF THESE METHODS IS MUTUALLY EXCLUSIVE. IF THE
CPU IS IN FTG MODE, THE EBL CANNOT BE SWITCHED TO FTG MODE. LIKEWISE, IF THE EBL IS
IN FTG MODE, THE CPU CANNOT BE SWITCHED TO FTG MODE.
This section provides an overview of the FTG File Manager, which is used for FTG Mode via CPU
configuration. FTG File Manager software is available online at: www.LGsolutions.com/ftgsoftware.
Creating an FTG Conguration File
The procedure below describes how to use the FTG File Manager utilities (see sample screens on pages
41 to 44) to create an FTG Conguration (.tlx) le that can be saved to a USB memory device. In order
to enable decryption of Pro:Idiom encrypted channels, it is recommended that you create or view/edit an
FTG Conguration le using the FTG File Manager.
Note: There is also an option to save (export) FTG Conguration from a TV, which may be desirable or
required if you want to save customized TV setup menu settings to the FTG Conguration le and/or if
you do not know the RF channels at the site. See “
information.
This procedure provides an overview of the steps required to create an FTG Configuration (.tlx) file.
Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.
1. Install (if necessary) and launch the FTG File Manager (v1.2.4 or later) on the PC that will be used to
create the FTG Configuration (.tlx) file.
2. You have a number of options:
• To view and/or base a new FTG Conguration le on an existing FTG Conguration (.tlx) le, click
the Open button in the TLX File command section of the FTG File Manager main screen, and select/
double-click on the desired “.tlx” file.
A list of the file’s contents will be displayed in the TLX File Contents window. Either double-click on an
individual item to copy it, or click the Copy All button directly above the TLX File Contents window to
automatically copy all the contents of the opened file to the FTG Configuration List and, if applicable,
TV Setup Menu List. Note, though, that while TV setup menu settings can be included in the new FTG
Configuration file, the TV setup menu settings are not available for editing.
Edit the configuration of the items in the FTG Configuration List as well as the FTG Configuration
List itself and/or the TV Setup Menu List, as necessary, to create a new file. Then, proceed to step 3
when you are ready to continue.
• To open an existing FTG Conguration (.rml) le created in the FTG Device Conguration
Application to use its FTG Channel Map and/or FTG Installer Menu settings, click File and then Open
from the FTG File Manager menu bar, and select/double-click on the desired “.rml” le.
Edit channels and/or settings as necessary. Then, proceed to step 3 when you are ready to continue.
• Create a new FTG Channel Map using the FTG Channel Map Editor in the FTG Channel Map
Conguration Utility. Up to 600 channels can be defined in the FTG Channel Map.
When you are ready to continue, click Congure and then FTG File Manager from the FTG File
Manager menu bar to return to the FTG File Manager main screen, and then proceed to step 3.
Exporting
a Clone File
” on
pages 35 to 36 for further
206-4278
(Continued on next page)
39
FTG File Manager Utilities Overview (Cont.)
(Continued from previous page)
Note: To remove an individual item from the FTG Configuration List or the TV Setup Menu List, click on/
highlight the item to be removed, and then click the Remove Item button directly above the applicable
“List” window. To clear both the current FTG Configuration List and TV Setup Menu List contents, click the
Clear button in the List command section of the FTG File Manager main screen.
Note: To clear the current TLX File Contents, click the New button in the TLX File command section of
the FTG File Manager main screen (above the TLX File Contents window).
3. To add an FTG Channel Map to the FTG Configuration List, click under FTG Channel Map. This
will copy the current mapped channels to the FTG Configuration List.
Note: If you make any change(s) in the FTG Channel Map Configuration Utility to the current data to
be included in the FTG Configuration List, you will need to recopy the FTG Channel Map to the FTG
Configuration List.
4. (Optional) Load default FTG Installer Menu settings for the TV:
• Click the down arrow at the right of the Chassis eld in the Installer Menu Templates section of the
FTG File Manager main screen, and select the appropriate chassis (depending on the TV type) from
the drop-down list of available models.
• Click the Load button.
• Use the FTG Installer Menu Conguration Utility to modify settings, if necessary. Then, return to the
FTG File Manager main screen.
5. If you wish to change the Zone assignment for the current FTG Installer Menu settings, click on the
down arrow at the right of the Zone eld (below the FTG Installer Menu Settings eld), and select the
appropriate Zone (0–8).
Note: See Reference section, “Using the TV Zoning Feature,” for further information on the TV Zoning
feature and setting the TV Zone # in the TV(s).
6. To add FTG Installer Menu settings to the FTG Configuration List, click under FTG Installer Menu
Settings. This will copy the selected model settings to the FTG Conguration List.
Note: If you make any change(s) in the FTG Installer Menu Configuration Utility to the current data to
be included in the FTG Configuration List, you will need to recopy the FTG Installer Menu settings to
the FTG Configuration List.
Note: At the top of both the FTG Conguration List and TV Setup Menu List windows, an Edit Zone
eld enables you to change the Zone assignment for each LX570H Installer Menu and/or TV Setup
Menu prole, if desired. Select/highlight the desired prole, and then click on the down arrow at the
right of the applicable Edit Zone eld to select the appropriate Zone.
7. Click the Save button in the List command section of the FTG File Manager main screen to save the
FTG Configuration List and, if present, TV Setup Menu List contents to an FTG Configuration (.tlx) file
on the PC’s hard drive for later use.
In the Save As pop-up window, name the file (avoid using special characters, such as ?, &, @, etc.)
and click Save. The default folder path is C:\Program Files\Zenith\FTG\TLX. Note that the FTG
Configuration file will have a “.tlx” file extension.
Note: To remove an individual item from the FTG Conguration List or the TV Setup Menu List before
saving the new le, click on/highlight the item to be removed, and then click the Remove Item button
directly above the applicable window. To clear both the current FTG Conguration List and TV Setup Menu
List contents, click the Clear button in the List command section of the FTG File Manager main screen.
8. Transfer the FTG Configuration (.tlx) file to a USB memory device, and proceed to “Importing a Clone
File” on pages 36 to 38 to transfer the FTG Configuration file to an LX570H TV.
40
206-4278
FTG File Manager Utilities Overview (Cont.)
FTG File Manager Main Screen
The FTG File Manager main screen enables you to compile, modify, and save FTG Configuration (.tlx)
files. It also allows you to change the Zone assignment for each Installer Menu profile, if desired (see
Reference section, “Using the TV Zoning Feature,” for further information).
Filename of opened FTG
Configuration (.rml) file
created using FTG Device
Configuration Application.
Copy FTG Channel Map
to and from FTG
Configuration List.
Copy FTG Installer Menu
settings to and from FTG
Configuration List. Assign
Zone as applicable.
Load default FTG Installer
Menu for appropriate
LX570H chassis.
FTG CONFIGURATION LIST
Data to be saved in FTG
Configuration (.tlx) file.
CLEAR/SAVE
FTG Configuration
and TV Setup Menu
List options.
NEW/OPEN
TLX File options.
206-4278
TV SETUP MENU LIST
Data to be saved in FTG
Configuration file.
TLX FILE CONTENTS
Data contained in opened
FTG Configuration (.tlx) file.
Note: The data referenced in the FTG Conguration List is only a snap-
shot of the current FTG Channel Map and FTG Installer Menu settings
when copied to the list. If you make any change(s) to the current data
to be included in the FTG Conguration List, you will need to recopy
Channel Map and Installer Menu settings to the FTG Conguration List.
41
FTG File Manager Utilities Overview (Cont.)
FTG Channel Map Conguration Utility
The FTG Channel Map Configuration Utility enables you to create, view, edit, and print a Logical
Channel Map.
42
Filename of opened FTG
Configuration (.rml) file created
using FTG Device Configuration
Application.
EDIT/ADD MAP
Click to open the FTG
Channel Map Editor to create
or edit an FTG Channel Map
(see next page).
PRINT MAP
Click to display a printable
FTG Channel Map Report. The
report can also be exported as
an HTML or Text file.
206-4278
FTG File Manager Utilities Overview (Cont.)
FTG Channel Map Editor
The FTG Channel Map Editor shows a single Logical Channel’s data and the FTG Channel Map.
LOGICAL CHANNEL MAPPING
Select a Logical Channel number. Then,
assign the RF, Major, and Minor channel
numbers to complete the mapping.
CUSTOM CHANNEL LABELS/ICONS
Enter custom labels and select icons
by name on menu or by number.
SET CHANNEL ATTRIBUTES
Check/select Encrypted, OSD,
or Blank Video.
ZONE RESTRICTION
Select Zone restriction
for channel. See
Reference section,
“Using the TV Zoning
Feature,” for further
information.
206-4278
ADD
After defining a new
Logical Channel, click to
add channel to the FTG
Channel Map.
UPDATE
After editing an existing
Logical Channel’s data,
click to commit the changes
in the FTG Channel Map.
EXIT
Click to exit editor and
return to FTG Channel
Map Configuration Utility.
DELETE
Click to remove highlighted
channel from FTG Channel
Map.
43
FTG File Manager Utilities Overview (Cont.)
FTG Installer Menu Conguration Utility
CONFIGURATION SETTINGS
Select tabs for categories of Installer
Menu items to set up TV.
44
Filename of opened FTG Configuration
(.rml) file created using FTG Device
Configuration Application.
Notes:
• The Pro:Centric tab enables you to set up Pro:Centric-specic parameters. Refer to the Free-To-
Guest (FTG) File Manager User Guide for further information.
• LAN and Hospital parameters are not applicable for these TV models.
206-4278
The IP Environment Menu enables you to set up the network features
IP Environment
OK
Move
of the TV. With the exception of Network Connection settings, the IP
Environment settings are editable (with the Installer Remote) only if
the TV is in Pass-through Mode and read-only when the TV is not in
Pass-through Mode. Also, if you intend to create a Master TV Setup
for cloning purposes (see Master TV Setup procedure on pages 32 to
34), all IP Environment settings, with the exception of the Network
Connection settings, may be cloned.
Accessing the IP Environment Menu
1. Use the Installer Remote to access the Installer Menu (see
“Accessing the Installer Menu” on page 22 for further information).
2. Navigate to Installer Menu item 119 DATA CHANNEL, and press
2-5-3 + MENU SETTINGS to launch the IP Environment Menu
(see example at right).
Use the Up/Down arrow keys on the Installer Remote to select the
desired menu option and then press OK. Refer to the following
sections for information on each of the IP Environment setup options.
When you have completed your IP Environment conguration
as required, press EXIT or on the Installer Remote to exit the IP
Environment Menu.
IP Environment Setup
IP Environment
•
Network Connection
•
Network Status
•
Pro:Centric
•
MAC Address: 3C:CD:93:E5:78:8F
Note: When you enter the IP Environment Menu,
the Installer Menu is exited (all current settings are
saved automatically upon exit). If you are also in
the process of updating Installer Menu items, you
may wish to set all items as needed before you
access the IP Environment Menu. Otherwise, after
exiting the IP Environment Menu, you will need to
reaccess the Installer Menu to set additional items.
Move
OK
Conguring the Network Connection
This option enables you to set up the TV’s wired network connection.
1. With the IP Environment Menu on display, use the arrow keys
on the Installer Remote to select Network Connection. Then,
press OK.
The rst of a series of Network Setting windows will be displayed
on the screen.
2. If not already done, connect the appropriate cable between the
TV and the network. Then, use the arrow keys on the Installer
Remote to select Start Connection and press OK.
3. By default, the TV is congured for DHCP. If congured, the
DHCP server will assign an IP address to the TV once the TV
successfully connects to the network, and a “Wired network is
connected” message will be displayed at the top of the next
Network Setting screen (see example at right).
• If no further network conguration is required, use the arrow
keys on the Installer Remote to select Complete and press
OK to return to the IP Environment Menu.
• If a DHCP server is not congured and/or if you wish to set
static IP conguration data for the TV, continue with step 4.
4. Use the arrow keys on the Installer Remote to select Set
Expert from the Network Setting screen, and then press OK.
Network Setting
Connect a LAN cable to the back of TV.
Setting your network will enable network-related features on the TV.
Start Connection
Previous
Network Setting
For detailed settings, select [Set Expert].
Set Expert
Previous
i
Wired network is connected.
(Continued on next page)
Next
Complete
206-4278
45
IP Environment Setup (Cont.)
(Continued from previous page)
The next Network Setting window will enable you to specify
the IP and DNS conguration for this TV. Auto settings will
be selected by default. Use the arrow keys to select the
appropriate options, and specify the conguration data for
the IP and DNS modes. When all elds are completed, select
OK on the screen and press OK on the Installer Remote.
Note: You can specify a static DNS server with an auto-
congured IP address but not vice versa.
The TV will attempt to connect to the network and you will
see a progress screen that indicates status as each network
element is conrmed. When the network is connected
successfully, a “Wired network is connected” message will be
displayed at the right of the screen, along with the network
conguration data (see example at right below).
5. Select Complete (if not already selected), and then press OK
on the Installer Remote to return to the IP Environment Menu.
Note: If the network connection is not successful, the progress
screen will identify the network element in which the connection
failed. Check your cabling and/or, if necessary, press on the
Installer Remote to verify the conguration data.
Network Setting
Select the IP setting mode.
IP Mode
• IP Address
• Subnet Mask
• Gateway
DNS Mode
• DNS Server
Previous
255 . 255 . 0 . 0
OK
IP Auto Setting
0 . 0 . 0 . 0
0 . 0 . 0 . 0
DNS Auto Setting
0 . 0 . 0 . 0
Next
Network Status
This option enables you to check the status of the network
connection.
1. With the IP Environment Menu on display, use the arrow
keys on the Installer Remote to select Network Status.
Then, press OK.
The TV will display a status screen as it conrms each of
the network elements—TV, Gateway, DNS, and Internet
(see example at right). If the network is connected
successfully, a “Wired network is connected” message
will be displayed at the right of the screen, along with the
network conguration data.
Note: If a problem is detected, the status screen will
identify the network element in which the connection failed.
Check cabling and/or conguration data, as necessary.
If the status screen is still on display, you can select Test
and press OK to recheck the network status.
2. When the status screen shows that the network is
connected, select Complete (if not already selected)
and press OK on the Installer Remote to return to the IP
Environment Menu.
Note: If you wish to cancel the status check while it is in progress,
select “Close” or press to return to the IP Environment Menu.
Network Status
TV
Gateway
DNS
Internet
Setting CompleteTest
Auto mode
Wired network is connected.
MAC Address : 3C:CD:93:E5:78:8F
IP Address : 10.2.3.4
Subnet Mask : 255.255.255.0
Gateway : 10.10.10.10
DNS Server : 10.5.6.7
46
206-4278
Pro:Centric Setup
IP Environment
OK
Move
Pro:Centric options enable you to congure the TV with the
appropriate settings to connect to the Pro:Centric server. Use the
Up/Down arrow keys on the Installer Remote to navigate between
elds.
1. With the IP Environment Menu on display, use the arrow keys
on the Installer Remote to select Pro:Centric. Then, press OK.
Note: Options that are initially grayed out/inaccessible in the
Pro:Centric Menu are dependent upon other settings in the
display. For example, if “IP” is selected in the Media Type eld,
the Server IP and Port Number elds become accessible.
2. Refer to the appropriate subsection(s) below to congure the
TV’s Pro:Centric settings to match those of the Pro:Centric
server.
While the Pro:Centric application (Mode) itself is an additional
feature, the appropriate Pro:Centric server conguration must
be completed to enable TV E-Z Installation (splash screen,
conguration, and software/rmware) data downloads and, if
congured, the Pro:Centric application download.
Note: For those elds that permit direct entry of numerical
values (for example, Server IP, Port Number, Data Channel,
etc.), once you key in the maximum number of digits allowed in
the highlighted eld, the next available eld will be highlighted.
IP Environment Setup (Cont.)
IP Environment
•
Network Connection
Mode
•
Network Status
•
•
Media Type
Pro:Centric
Server IP
MAC Address: CC:2D:8C:87:8B:70
Port Number
Data Channel
Update Event
Update Time
Move
Configuration Only
0 0 0 0
12 AM
Close
OK
RF
0
255
Off
00
RF Conguration
a) In the Media Type eld, use the Left/Right arrow keys to select RF.
Note: If the Media Type has already been set in the EZ-Manager
Wizard, the specied value will be reected in this eld.
b) In the Data Channel eld, either key in or use the Left/Right arrow keys
to select the RF channel number that will be used by the Pro:Centric
server as its data channel. The Data Channel value can be set from 0
(disabled) to 135. *
For TVs in Pass-through Mode or FTG Mode via CPU, if this item
is left at its default value (255), the TV’s Data Channel Auto Search
feature will be enabled. See Installer Menu item 119 DATA CHANNEL
description on page 31 for further information.
Note: If the Data Channel has already been set in the Installer Menu
(Installer Menu item 119) or in the EZ-Manager Wizard, the specied
channel will appear in this eld. If you change the Data Channel in this
menu, Installer Menu item 119 will now show the value you entered
here.
* PCS150R and later Pro:Centric servers do not support HRC or IRC cable channel frequencies.
(Continued on next page)
206-4278
47
IP Environment Setup (Cont.)
(Continued from previous page)
IP Conguration
a) In the Media Type eld, use the Left/Right arrow keys to select IP.
Note: If the Media Type has already been set in the EZ-Manager Wizard, the specied
value will be reected in this eld.
Note: Setting the Media Type to “IP” automatically sets the Data Channel eld to “253.”
You cannot alter this setting (unless you revert Media Type to “RF”). Also, it is not possible
to direct enter “253” in the Data Channel eld.
b) In the Server IP and Port Number elds, either key in or use the Left/Right arrow keys to
select the appropriate values for the Pro:Centric server IP address and port number. The
IP address must match the IPv4 multicast address and the port number must match the
port number that is set in the Pro:Centric server.
Note: If the server IP address and port number have already been set in the EZ-Manager
Wizard, the specied data will be reected in these elds.
Pro:Centric Application Mode Conguration
In the Mode eld, use the Left/Right arrow keys to select the appropriate Pro:Centric
Application Mode setting—Conguration Only, FLASH, or GEM. If the Pro:Centric Mode is
set to “Conguration Only,” Pro:Centric application data will not be downloaded.
Note: If the mode has already been set in the Installer Menu (item 098 PRO:CENTRIC) or in
the EZ-Manager Wizard, the specied mode will be reected in this eld. If you change the
mode in this menu, Installer Menu item 098 will now reect the value you selected here.
3. In the Update Event eld, use the Left/Right arrow keys to select On or Off, as required. Based
on the Update Time settings, the Wake For Update feature wakes the TV once daily to check
for, and if applicable, download updates from the Pro:Centric server. See Installer Menu item
121 UPDATE TIME HR description on page 31 for additional information on Wake For Update
functionality. If you set Update Event to “On,” specify the appropriate Wake For Update time in
the Update Time elds, as desired. Note that the Update Time set in this menu is based on a
12-hour clock. Ensure the AM/PM specication is set accordingly.
4. Once all elds are completed as required, either select Close and then press OK on the Installer
Remote or press to return to the IP Environment Menu.
48
206-4278
Reference: Remote Jack Pack / TV Connections & Setup
Remote Jack Pack Setup
RJP Available? If you will use a Remote Jack Pack (RJP) in your system, set Installer Menu item 093
RJP AVAILABLE appropriately (for example, on a legacy model RJP: HDMI Mode, set RJP AVAILABLE
to 1). See Installer Menu detailed descriptions for further information.
093 RJP AVAILABLE 001
TV Connections
Caution: Make these connections ONLY after Master TV Setup and TV cloning procedures
are complete. Also, make sure to use the RJ-45 Control cable from the RJP cable bundle to
make the connection to the TV’s RJP port. Do NOT connect a standard Ethernet cable to
the RJP port, as this may damage the TV and network equipment.
Refer to the figure below, and connect the RJ-45 Control cable from the RJP cable bundle to the RJP
port on the TV’s rear jack panel. Then, connect HDMI, RGB, and Composite Video/Audio connectors, as
applicable, for the cable bundle.
Connect RGB connector
RGB IN (PC)
from RJP cable bundle
(legacy RJP only).
RESET
RESET
UPDATE
SERVICE ONLY
TV-LINK CFG
OPTICAL
SPEAKER OUT
AUDIO OUT
LINE OUT
LAN
L/MONO-AUDIO-R
VIDEO
AV IN / AUDIO IN (RGB DVI)
..........
RGB IN (PC)
L R
IN
1
GAME CONTROL
/ MPI
RJP
AUDIO/VIDEO IN
Connect Composite Video/Audio
connectors from RJP cable bundle.
(Composite Video on legacy RJP only.)
ANTENNA/
CABLE IN
HDMI IN 1
Connect HDMI connector
from RJP cable bundle.
RJP
Connect RJ-45 Control cable
from RJP cable bundle.
206-4278
49
Reference: Updating TV/PTC Software using a USB Memory Device
This section describes how to update TV (CPU) and/or PTC software using the
TV Manager / USB Download Menu “Update TV Software” and/or “Update PTC
Software” option(s), respectively, though you may also use the Ez Download utility
to update software, if desired. See “Ez Download Utility” on pages 19 to 21 for
further information.
Before You Begin
• Software update les must be stored in a folder named “LG_DTV” in the root
directory of the USB memory device.
• Ensure the USB device has been formatted with FAT format.
Update the TV/PTC Software
Note: You can check the TV/PTC software versions by accessing the Installer
Menu with the Installer Remote. See “Accessing the Installer Menu” on page
22 for further information. PTC and CPU versions are displayed in the Installer
Menu footer.
Note for TV CPU Software Update only: If the TV detects a later version of
software on the USB device, it will automatically display a dialog from which you
can start the software update immediately. Otherwise, you can close the dialog,
and access the TV Manager / USB Download Menu as described below.
1. Turn ON the TV, and then insert the USB memory device into the TV’s USB
port.
2.
Press MENU SETTINGS on the Installer Remote to display the TV setup
menus (TV is in Pass-through Mode) or the Function Menu (TV is not in
Pass-through Mode).
3. Use the arrow navigation keys to select/highlight either the Option menu
icon from the TV setup menus or the Lock menu icon from the Function
Menu. Then, press the number “7” key a total of seven times to display the
TV Manager / USB Download Menu.
4. With the TV Manager / USB Download Menu on display, use the Up/Down
arrow keys to select Update TV Software or Update PTC Software, as
applicable, and then press OK.
5. In the next window (TV Software Update or Update PTC Software depending
on your selection in step 4—see also screen samples at right), use the Up/
Down arrow keys to select/highlight the update le to download. Then, press
OK.
Note: Do not select Forced Update options unless you have been specically
instructed to do so or have previous experience with Expert Software Updates.
The TV will show update progress in a new window. Do NOT remove the USB
device until the software update is complete. When the software update is
complete, the TV will briey display a “Updating complete” window and then
automatically reboot.
TV Manager
USB
Previous
i
[ Current TV Software Version Information ]
EPK : 03.00.12
The following software files are found in the memory card.
Select the file you want to download to this TV
or press EXIT to cancel the update.
EPK: 03.00.20
[Forced Update Option]
SPI Boot
LOGO Image
xxLX570H_v3_00_USB
TV Manager
USB
Previous
Update PTC Software
xxLX570H_v1.00.008.txt
Previous
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
OK
TV Software Update (Expert)
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
OK
OK
Note: TV Manager / Diagnostics
is for service use only.
50
206-4278
Reference: Downloading a Splash Screen Image using a USB Memory
Device
This section describes how to download a splash screen image using the TV
Manager / USB Download Menu “Logo Image Download” option, though you
may also use the Ez Download utility to download the splash screen image, if
desired. See “Ez Download Utility” on pages 19 to 21 for further information.
Splash Screen Image File Guidelines
• The splash screen image must be a baseline (not progressive) JPEG.
• The image should be no larger than 1 MB.
• The maximum resolution allowed for a 32LX570H splash screen image is
1360 x 768 pixels (HD).
• The maximum resolution allowed for a 40/43/49/55/65LX570H splash screen
image is 1920 x 1080 pixels (FHD).
• Avoid using special characters, such as ?, &, @, etc., in the splash screen
image lename.
Before You Begin
• The splash screen image le must be stored in a folder named “LG_DTV” in
the root directory of the USB memory device.
• Ensure the USB device has been formatted with FAT format.
Download the Splash Screen Image
1. Turn ON the TV, and then insert the USB memory device into the TV’s USB
port.
2.
Press MENU SETTINGS on the Installer Remote to display the TV setup
menus (TV is in Pass-through Mode) or the Function Menu (TV is not in
Pass-through Mode).
3. Use the arrow navigation keys to select/highlight either the Option menu
icon from the TV setup menus or the Lock menu icon from the Function
Menu. Then, press the number “7” key a total of seven times to display the
TV Manager / USB Download Menu.
4. With the TV Manager / USB Download Menu on display, use the Up/Down
arrow keys to select Logo Image Download, and then press OK.
5. In the Logo Image Download window, use the Up/Down arrow keys to select
the image le to download, and then press OK.
The TV will show update progress in a new window. Do NOT remove the USB
device until the splash screen image update is complete. When the image update
is complete, the TV will briey display a “Updating complete” window and then
automatically reboot. During the reboot, you should see the new splash screen.
TV Manager
USB
Previous
Logo Image Download
Splash-Image-1920x1080-ProCentricJPEG
Previous
Note: TV Manager / Diagnostics
Ez Download
Logo Image Download
Update TV Software
Update PTC Software
Import Clone File
OK
OK
is for service use only.
206-4278
51
Reference: Power Consumption Settings
The following tables assume that Installer Menu item 118 POWER SAVINGS is set to 3 (default)
and Installer Menu item 099 BACK LIGHTING is set as shown below (default value is 255).
32LX570H 40LX570H 43LX570H
Item 099
Back Lighting
(Static)
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
100
90
80
70
60
50
40
30
20
10
1
Item 099
Back Lighting
(Dynamic)
200
190
180
170
160
150
140
130
120
110
101
46.9 0% 60.6 0% 52.9 0%
44.0 6% 56.0 8% 49.6 6%
41.2 12% 51.9 14% 48.8 8%
38.3 18% 47.7 21% 46.9 11%
37.1 21% 45.9 24% 45.5 14%
36.1 23% 44.1 27% 43.3 18%
34.4 27% 41.4 32% 41.6 21%
32.6 31% 39.0 36% 35.3 33%
27.8 41% 31.8 47% 30.4 43%
22.9 51% 24.4 60% 24.3 54%
18.5 60% 17.9 71% 19.6 63%
32LX570H 40LX570H 43LX570H
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
47.3 0% 60.8 0% 52.9 0%
44.1 7% 56.3 7% 49.7 6%
41.3 13% 52.1 14% 48.8 8%
38.4 19% 47.9 21% 47.1 11%
37.3 21% 46.1 24% 45.7 14%
36.2 23% 44.4 27% 43.5 18%
34.4 27% 41.7 31% 42.0 21%
32.7 31% 39.4 35% 35.5 33%
27.8 41% 32.0 47% 30.6 42%
22.9 52% 24.5 60% 24.4 54%
18.5 61% 18.0 70% 19.7 63%
Percent
Savings
Note: Values are results of controlled experiments under laboratory conditions.
52
206-4278
Item 099
Back Lighting
(Static)
49LX570H 55LX570H 65LX570H
Power
Consumption
(Watts)
Reference: Power Consumption Settings (Cont.)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
100
90
80
70
60
50
40
30
20
10
1
Item 099
Back Lighting
(Dynamic)
200
190
180
170
160
150
140
130
120
110
101
53.2 0% 61.2 0% 85.3 0%
50.2 6% 57.2 7% 78.8 8%
49.2 8% 56.2 8% 75.0 12%
47.4 11 % 53.9 12% 72.8 15%
46.2 13% 52.3 15% 69.9 18%
43.8 18% 49.2 20% 66.5 22%
42.1 21% 47.1 23% 62.8 26%
35.8 33% 39.1 36% 54.3 36%
31.1 42% 33.0 46% 43.6 49%
25.0 53% 25.2 59% 33.6 61%
20.2 62% 19.0 69% 23.8 72%
49LX570H 55LX570H 65LX570H
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
Percent
Savings
Power
Consumption
(Watts)
53.5 0% 62.0 0% 85.4 0%
50.4 6% 58.4 6% 79.0 7%
49.4 8% 56.9 8% 75.3 12%
47.8 11 % 54.6 12% 73.0 15%
46.4 13% 52.9 15% 70.0 18%
44.1 18% 49.8 20% 66.6 22%
42.5 21% 47.6 23% 63.0 26%
36.0 33% 39.5 36% 54.4 36%
31.2 42% 33.3 46% 43.8 49%
25.1 53% 25.5 59% 33.7 61%
20.4 62% 19.2 69% 23.9 72%
Percent
Savings
206-4278
53
Reference: TV Aux Input Conguration
ENABLE MPI DATA
DIRECT ACCESS
Tuning *
TV
Installer Menu
MPI DATA
STATUS TYPE
0x41 SOURCES
ENABLED (R/W)
Installer
Menu
Item 029
OLD OCV
= 0
131-0 91-0
132-0 92-0 HDMI2
133-0 93-0 HDMI1
134-0 94-0 RGB PC 87
135-0 95-0
* Use Installer Remote to enter channel number indicated based on OLD OCV Installer Menu setting.
Installer
Menu
Item 029
OLD OCV
= 1
Aux
Input
Video1
(Rear)
HDMI3
Input
Mode
CV 39
DTV
PC 2 2
DTV
PC 2 2
DTV
PC 2 2
Item Function Value
REAR AUX
EN
91
35
92
HDMI2
ENABLE
HDMI1
ENABLE
REAR RGB
EN
HDMI3
ENABLE
Enable
Bit
1 1 Rear Video (Aux) 1 0 VIDEO 1
1
2 S-Video Rear 2
1
3
1 5
1
6
DATA STATUS
TYPE 0xD2
CURRENT AV
SOURCE (R)
Label Value Value Description
Front
Computer
SVGA Rear
Computer
NTSC Rear
Computer
3
4 2
5
DATA STAT US
TYPE 0x0D
AUX SOURCE (R)
0 VIDEO
COMPUTER
0 VIDEO
COMPUTER
COMPUTER 4
0 VIDEO
COMPUTER
Installer
Menu Item
046 START
AUX SRCE
(Start Aux
Source)
Value
5
3
7
54
206-4278
Reference: b-LAN Setup & Overview
The b-LAN module is internal to the TV. It allows hotel/institution head end equipment with b-LAN technology
to communicate, via the institution’s RF distribution system, with the TV for configuration and control.
Installer Menu item 118 POWER SAVINGS controls the power circuitry for both the embedded b-LAN module
and the GAME CONTROL/MPI port. The default value is 3—the b-LAN module is only powered when the TV
is turned ON. See chart below.
TV OFF
POWER
SAVINGS
1 On On
3 (default) Off On
A b-LAN enabled head end device, such as an LG FMA-LG101, broadcasts over the RF distribution system
to communicate to multiple TVs. When the TV is first installed, it must be turned ON in order for its embedded
b-LAN module to receive communication from the head end device. At this point, if it is desired for the b-LAN
module to always be powered, including while the TV is turned OFF, set Installer Menu item 118 POWER
SAVINGS to 1.
Also, if MPI communication is required for external MPI control, set Installer Menu item 118 POWER SAVINGS
to 1 so that the GAME CONTROL/MPI port circuitry is always powered.
Caution: POWER SAVINGS should NEVER be set to 7. This setting is intended for factory use
only.
b-LAN & GAME
CONTROL/MPI Port
Power
CONTROL/MPI Port
TV ON
b-LAN & GAME
Power
206-4278
55
Reference: FTG Mode via EBL (Local Conguration)
The following steps outline local FTG configuration of individual TV EBLs using a direct PC-to-TV (EBL)
connection. Refer to the Free-To-Guest (FTG) Device Configuration Application User Guide for further
information.
FTG Device Conguration Application software is available online at: www.LGsolutions.com/ftgsoftware.
Note: If the TV CPU is already in FTG Mode, you cannot use this procedure to make changes to the FTG
Channel Map and FTG Installer Menu settings. Refer to FTG Mode information on pages 7 to 9 for further
details.
Note: If the preceding condition applies, but you wish to switch the TV to FTG Mode via EBL, see
Reference section, “Restoring Factory Defaults on the TV(s),” for further information before proceeding.
1. Install (if necessary) and launch the FTG Device Conguration Application (v5.4.8 or later) on the
PC that will be used to congure the EBL.
2. Build an FTG Channel Map using the FTG Channel Map Editor in the FTG Channel Map Conguration
Utility (or, if applicable, open an existing FTG Conguration [.rml] le).
Note: Up to 141 logical channels can be dened in the FTG Channel Map.
3. Connect the PC to the TV-LINK CFG jack on the TV’s rear jack panel using a USB-to-TTL serial cable
(TTL-232R-5V-AJ). If necessary, install the device driver on the PC.
4. Turn ON the TV.
Note: If Installer Menu item 118 POWER SAVINGS is set to 3 (default), the TV must be ON in order
for steps 5 and 6 below to be successful.
5. “Write” the FTG Channel Map to the EBL (switches the EBL from Pass-through Mode to FTG Mode).
Note: After a “Write” of new data, the TV will briey display a green text banner that shows the EBL
rmware version and release date.
6. “Read” the current FTG Installer Menu settings from the EBL using the FTG Installer Menu Conguration
Utility. If necessary to make changes to Installer Menu items, “Write” them back to the EBL in FTG Mode.
7. Save the FTG Channel Map and FTG Installer Menu settings to an FTG Conguration (.rml) le for
future use.
8. Tune the TV to a logical channel in the FTG Channel Map.
56
RESET
SERVICE ONLY
TV-LINK CFG
OPTICAL
SPEAKER OUT
AUDIO OUT
LINE OUT
LAN
RESET
UPDATE
RGB IN (PC)
L R
L/MONO-AUDIO-R
VIDEO
AV IN / AUDIO IN (RGB DVI)
TV-LINK CFG
Use to connect PC to TV (EBL) for local
FTG Mode via EBL configuration.
Laptop
PC
USB-to-TTL Serial Cable
Required for local FTG Mode
via EBL configuration.
206-4278
Reference: Auto Input(s) Sensing Feature
This section provides detailed settings information for Installer Menu item 042 AUTO INPUTS. To disable
auto-sensing for all available Aux inputs, set item 042 to 0. To enable auto-sensing for all available Aux
inputs, set item 042 to 255. For specications on all other available settings (i.e., settings for individual
inputs), refer to the table on the following page.
Note: When both item 042 AUTO INPUTS and item 041 SIMPLINK EN are enabled in the Installer Menu,
HDMI inputs will be detected by SIMPLINK, but the Auto Input(s) Sensing Feature will not function.
In the Installer Menu, an informational code is displayed at the right of each Auto Inputs value, for example:
xxLX570H PTC INSTALLER MENU
CPU-CTV
AUTO INPUTS Display Code
042 AUTO INPUTS 241 7654XXX0
UPN 000-000-000-000 ASIC D279
PTC V1.00.008 CPU V3.00.20.01
This example illustrates Installer Menu item 042 value
241, which enables auto-sensing for all available Aux
inputs. The input #s in the display code (7, 6, 5, 4, 0
in this example) identify the enabled Aux inputs. See
table below for a listing of the LX570H Aux inputs and
their corresponding display code input #s. The table
on the following page shows the display codes for all
item 042 values.
Each code consists of eight characters that identify the Aux input(s) for which auto-sensing is enabled.
The following table identies the Installer Menu display code Input # for each Aux input that is available on
the LX570H TV models. The table also identies the Installer Menu item associated with each Aux input.
Remember that in order for auto-sensing to be enabled for an input, that input must also be enabled in the
Installer Menu.
Installer Menu
Display Code
Input #
0 AV 1 039 REAR AUX EN
4 RGB 087 REAR RGB EN
6 HDMI 1 035 HDMI1 ENABLE
7 HDMI 2 091 HDMI2 ENABLE
5 HDMI 3 092 HDMI3 ENABLE
Aux
Input
Installer Menu
Item Function
206-4278
57
Reference: Auto Input(s) Sensing Feature (Cont.)
Item 042
Value
001 Enabled Disabled Disabled Disabled Disabled DDDDXXX0
016 Disabled Enabled Disabled Disabled Disabled DDD4XXXD
017 Enabled Enabled Disabled Disabled Disabled DDD4XXX0
032 Disabled Disabled Disabled Disabled Enabled DD5DXXXD
033 Enabled Disabled Disabled Disabled Enabled DD5DXXX0
048 Disabled Enabled Disabled Disabled Enabled DD54XXXD
049 Enabled Enabled Disabled Disabled Enabled DD54XXX0
064 Disabled Disabled Enabled Disabled Disabled D6DDXXXD
065 Enabled Disabled Enabled Disabled Disabled D6DDXXX0
080 Disabled Enabled Enabled Disabled Disabled D6D4XXXD
081 Enabled Enabled Enabled Disabled Disabled D6D4XXX0
096 Disabled Disabled Enabled Disabled Enabled D65DXXXD
097 Enabled Disabled Enabled Disabled Enabled D65DXXX0
112 Disabled Enabled Enabled Disabled Enabled D654XXXD
113 Enabled Enabled Enabled Disabled Enabled D654XXX0
128 Disabled Disabled Disabled Enabled Disabled 7DDDXXXD
129 Enabled Disabled Disabled Enabled Disabled 7DDDXXX0
144 Disabled Enabled Disabled Enabled Disabled 7DD4XXXD
145 Enabled Enabled Disabled Enabled Disabled 7DD4XXX0
160 Disabled Disabled Disabled Enabled Enabled 7D5DXXXD
161 Enabled Disabled Disabled Enabled Enabled 7D5DXXX0
176 Disabled Enabled Disabled Enabled Enabled 7D54XXXD
177 Enabled Enabled Disabled Enabled Enabled 7D54XXX0
192 Disabled Disabled Enabled Enabled Disabled 76DDXXXD
193 Enabled Disabled Enabled Enabled Disabled 76DDXXX0
208 Disabled Enabled Enabled Enabled Disabled 76D4XXXD
209 Enabled Enabled Enabled Enabled Disabled 76D4XXX0
224 Disabled Disabled Enabled Enabled Enabled 765DXXXD
225 Enabled Disabled Enabled Enabled Enabled 765DXXX0
240 Disabled Enabled Enabled Enabled Enabled 7654XXXD
241 Enabled Enabled Enabled Enabled Enabled 7654XXX0
AV1 RGB HDMI 1 HDMI 2 HDMI 3
Inputs
Installer Menu
Display
X = Aux input source is Disabled or Not Available (i.e., on these TV models)
D = Auto-sensing for input is Disabled
Input # = Auto-sensing for input is Enabled
58
206-4278
Reference: RJP Model List & Input Auto-sensing Hierarchy
RJP Legacy Models
• RJP-101M
• RJP-101ML
• RJP-110F
• RJP-110FW
• RJP-110W
• RJP-110WBR
• RJP-110S
• RJP-120G
• RJP-120T
• RJP-201B/202B
RJP Scaler Models
• RJP-201M
• RJP-301B
• RJP-401B
RJP Input Auto-sensing Hierarchy
Priority Video Audio
1st (Highest) Digital Video In Audio In (3.5mm)
2nd PC Video In Audio In (L/R)
3rd Video In Digital Video In
206-4278
59
Reference: Restoring Factory Defaults on the TV(s)
This section describes how to restore all factory defaults or just the Installer Menu factory defaults either on a
single TV that is currently in Pass-through or FTG Mode or on multiple TVs that are currently in FTG Mode.
Restore All Factory Defaults
This section describes how to restore a single TV, regardless of its mode, to a factory default condition.
The following procedure requires that you contact LG technical support to obtain a predened value/
password for Installer Menu item 117 FACT DEFAULT that enables access to initiate a factory “IN-STOP”
process, which restores all factory defaults. This procedure will also reactivate the EZ-Manager Wizard.
1. Use the Installer Remote to access the TV’s Installer Menu.
2. Navigate to Installer Menu item 117 FACT DEFAULT, and key in the value provided by technical support.
Then, press OK.
3. At the prompt for conrmation, key in the password provided by technical support. This will initiate the
IN-STOP that restores the factory defaults on the TV.
Installer Menu Item 117 FACT DEFAULT
If the TV is currently in Pass-through Mode, you can set Installer Menu item 117 FACT DEFAULT to 1 to
restore the Installer Menu factory defaults and clear the PTC Channel Map, including any assigned
channel icons and custom text labels. Note, however, that if a complete restoration of the TV’s factory defaults is required, see “Restore All Factory Defaults” above.
Additional FTG Mode via CPU Options
There are two additional options for restoring Pass-through Mode/Installer Menu factory defaults on TVs that
are in FTG Mode via the CPU. The rst enables you to restore a single TV to Pass-through Mode, while the
second enables you to restore multiple TVs to Pass-through Mode at one time. However, both options require
that you create a “Zero Mapped Channels” FTG Conguration (.tlx) le, i.e., an FTG Conguration le with no
data. Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.
• Using a USB memory device, import a “Zero Mapped Channels” FTG Conguration (.tlx) le on the TV.
Refer to “Importing a Clone File” on pages 36 to 38 for further information on the import procedure.
• If your system uses a Pro:Centric server for remote management, use the Pro:Centric server Admin
Client to load a “Zero Mapped Channels” FTG Conguration (.tlx) le on the Pro:Centric server. Refer to
the Pro:Centric Server Admin Client User Guide for further information.
Additional FTG Mode via EBL Options
There are two additional options for restoring Pass-through Mode/factory defaults on TVs that are in FTG
Mode via the EBL. The rst enables you to restore a single TV to Pass-through Mode, while the second
enables you to restore multiple TVs to Pass-through Mode at one time.
Note: While the IN-STOP process described above will clear both the PTC and the CPU, both
options below only clear the PTC. Thus, the current Channel Map and TV setup menu settings
will remain in the CPU after the reset is completed.
• Using a direct PC-to-TV connection, “Write” an unpopulated Channel Map—that is, a Channel Map with 0
(zero) channels—to the TV. See Reference section, “FTG Mode via EBL (Local Conguration),” and/or the
Free-To-Guest (FTG) Device Configuration Application User Guide for further information.
• If your system uses an FMA for remote management/broadcast conguration, congure the FMA device
with an FMA Conguration (.fma) le that only contains a “0 Mapped Channels” FTG Channel Map to
broadcast to the TV EBL(s). Refer to the Free-To-Guest (FTG) Device Configuration Application User
Guide and/or the Installation & Conguration Guide for the FMA device for further information.
60
206-4278
Reference: Using the TV Zoning Feature
This section describes the TV Zoning feature available with the LX570H model TVs. The TV Zoning
feature enables you to create localized congurations for TVs in selected locations, or “Zones,” within the
installation environment, for example, a hotel lobby, tness center, restaurant, etc. This feature is primarily
intended for use when the TV is congured for FTG Mode via CPU operation. However, selected elements
of TV Zoning (Installer Menu and TV Setup Menu prole Zone assignments) may also be used with TV
cloning processes using a USB memory device / “.tlx” le.
Refer to the appropriate section(s) below for further information on the TV Zoning feature and how to set the
TV Zone # in a TV that is currently in Pass-through Mode.
Using the TV Zoning Feature with FTG Mode via CPU Conguration
The FTG File Manager may be used to create an FTG Conguration (.tlx) le that contains multiple Installer
Menu and TV Setup Menu proles, each with its own Zone assignment. Up to nine unique Zones can be
designated for LX570H FTG Installer Menu and/or TV Setup Menu proles. Zone restrictions can also be
placed on individual channels in the FTG Channel Map. Thus, for example, you may create an FTG Installer
Menu and/or TV Setup Menu prole to specically congure a TV in the hotel lobby and also restrict the
channels that are available to be tuned on that TV.
The TV Zone # must be set appropriately on each TV in order for the TVs to be congured correctly. See
“Set the TV Zone # in the TV” on the following page, and set the TV Zone # in all the TVs in a select area,
so that the TVs are congured with corresponding FTG Installer Menu and/or TV Setup Menu settings
and/or can omit channels that have been restricted in the FTG Channel Map. TV Zone 0 is the default TV
Zone #.
The following subsections briey describe how to assign Zone designations in the FTG File Manager.
Refer to the Free-To-Guest (FTG) File Manager User Guide for further information.
FTG Installer Menu Prole Zone Assignments
The FTG File Manager main screen enables you to change the Zone assignment (default = Zone 0) for
each Installer Menu prole to be included in an FTG Conguration (.tlx) le. For example, you may wish
to create one LX570H Installer Menu prole for the hotel lobby and another LX570H Installer Menu prole
for the tness center, both of which are different from the FTG Installer Menu prole used for standard
guest rooms. The TV Zoning feature enables you to save multiple LX570H FTG Installer Menu proles,
each with its own Zone assignment, in one FTG Conguration (.tlx) le. If each TV in the aforementioned
locations (Zones) has had its TV Zone # set appropriately, as described in the procedure on the following
page or via the EZ-Manager Wizard, the TV(s) will only be congured by the Installer Menu prole that
matches its(their) Zone setting.
In the FTG File Manager main screen, you can also edit the Zone assignment for each Installer Menu
prole and/or TV Setup Menu prole already present in the FTG Conguration List and TV Setup Menu
List windows.
Note: See also the FTG File Manager main screen overview on page 41. In addition, note that TV Setup
Menu proles cannot be created in the FTG File Manager; they must be saved (exported) from a TV.
FTG Channel Map Zone Restrictions
The FTG Channel Map Editor in the FTG File Manager’s FTG Channel Map Conguration Utility enables
you to place Zone restrictions on individual channels that may be prohibited or deemed unsuitable for
selected locations. In the FTG Channel Map Editor, one or more Zone restrictions (1–8) may be placed on
each channel that is to be restricted. For example, if you wish to restrict a channel from Zones 2 and 4,
select both “Zone 2” and “Zone 4” in the Zone Restriction section of the FTG Channel Map Editor screen
when dening or editing that channel.
206-4278
61
Reference: Using the TV Zoning Feature (Cont.)
Note: While a channel can be restricted from up to eight Zones, a TV can only ever be in (set for) one
Zone. See also the FTG Channel Map Editor overview on page 43.
At the same time, keep in mind that the TV Zone designations are not mutually exclusive. That is, you may
opt to place Zone restrictions on selected channels in the FTG Channel Map, but at the same time, you can
choose to congure all TVs at the site with the same Installer Menu and/or TV Setup Menu settings. For
example, an FTG Conguration (.tlx) le being used to congure the TVs at a site may contain multiple
Installer Menu and TV Setup Menu proles with different Zone assignments, as well as an FTG Channel
Map with Zone restrictions on several channels. Each TV that still has the default TV Zone 0 setting will only
be congured by the Installer Menu and/or TV Setup Menu prole(s) with a Zone 0 designation. If, on the
other hand, the TV Zone # is set to 1, the TV will rst look in the le for the LX570H Installer Menu and/or
TV Setup Menu prole(s) with a Zone 1 designation. If none of the LX570H Installer Menu and/or TV Setup
Menu proles has a Zone 1 designation, the TV will then look for the LX570H prole(s) with a Zone 0
designation. For the FTG Channel Map conguration, when the TV Zone # is set to 0, the TV will ignore
any Zone restrictions (1–8) that may be placed on channels in the FTG Channel Map. However, when
the TV Zone # is set to 1, the TV will omit any channels that have been restricted from Zone 1 in the FTG
Channel Map.
Using the TV Zoning Feature with Cloning Conguration
A location-specic conguration / Clone (.tlx) le may be saved (exported) from a Master TV and then be
used to congure Target TVs. For example, if the TV Zone # in the Master TV is set to 3 before the Clone
le export is initiated, the Master TV’s Installer Menu and TV Setup Menu proles will be saved with the TV
Zone 3 assignment. In order to congure the Target TVs with the Zone 3 Installer Menu and TV Setup Menu
proles exported from the Master TV, you must set the TV Zone # accordingly in the Target TVs before
importing the Clone le. See “Set the TV Zone # in the TV” below. Also, see “Cloning Procedures” on
pages 35 to 38 for additional information on the cloning processes. TV Zone 0 is the default TV Zone #.
Set the TV Zone # in the TV
You can set the TV Zone # in the EZ-Manager Wizard (see “EZ-Manager Wizard” on pages 12 to 18) or,
if the TV is in Pass-through Mode, via the TV’s setup menus as described below. Note that the following
procedure can only be performed while the TV is in Pass-through Mode. You will also be able to specify a
Label (North, South, East, West) and Room Number for this TV, if desired.
1. Turn ON the TV.
2. Press MENU SETTINGS on the Installer Remote, and use the arrow navigation keys to select/highlight
the OPTION menu option. Then, press OK.
3. Use the Up/Down arrows to select Zones & Room Number, and then press OK.
4. In the Zone, Label, and Room Number pop-up window, complete the appropriate elds as described
below. Use the Left/Right arrow keys on the Installer Remote to navigate between each of the elds.
• Zone: Enables you to set a TV Zone # so that the TV can be congured with Installer Menu and/or TV
Setup Menu settings intended only for the assigned Zone. The Installer Menu and/or TV Setup Menu
settings may be provided in a Clone/Conguration (.tlx) le. If the TV is being congured for FTG Mode
via CPU, the TV Zone # setting also allows the TV to omit channels that have been restricted in the
FTG Channel Map (see “FTG Channel Map Zone Restrictions” on previous page).
62
(Continued on next page)
206-4278
NUM
Reference: Using the TV Zoning Feature (Cont.)
(Continued from previous page)
To change the TV Zone, navigate to the Zone eld, and use the Up/Down arrow keys to specify the
desired TV Zone # (0–8).
• Label: Allows you to select a North, South, East, or West text label for this TV. Use the Up/Down
arrow keys to select the applicable label.
• Room Number: Allows you to specify the number of the room in which the TV is located. You can use
the number keys on the Installer Remote to direct enter a room number. Use the Dash key on the
Installer Remote as necessary to toggle between number and letter characters in the Room Number
eld. Also, you can use the Flashback key on the Installer Remote to delete characters in this eld.
5. When you have completed the elds as necessary, select OK, and then press OK on the Installer
Remote to close the window and return to the Option Menu.
6. Press MENU SETTINGS to return to program viewing.
OPTION
Move
• Language
• Caption : Off
• Standby Light : Off
• DivX(R) VOD
• Set ID : 1
• Demo Mode
• Zone & Room Number
• Eject
Z
Change a room number
Zone, Label, and Room Number
•
If creating Zones for Installer Menu settings and/or Channel Mapping, select the appropriate Zone # (0-8)
based on the Zone in which this TV is installed. (See Commercial Mode Setup Guide for more information.)
• Select a Label and/or use the alphanumeric keypad on the remote to input the Room Number.
Zone
0
Label
-----
Room Number
CHAR/
OK
OK
Q.MENU
INPUT
2
1
3
TV
DVD
MARK
@
.,;
abc def
1 2 3
4
5 6
ghi jkl mno
4 5 6
pqrs tuv wxyz
7 809
7
FLASHBK
8
9
CHAR/NUM
CC
P
A
TIMER
G
CHVOL
E
DELETE
DEL
0
MUTE
PORTAL
INFO
GUIDE
206-4278
63
Reference: LX570H Rear and Side Jack Panels
..........
..........
USB IN
..........
IN 3
IN 2
Initiates a hardware reset and
(
3.5 mm jack) Use to connect PC to TV (EBL)
for local FTG Mode via EBL configuration.
SERVICE ONLY
Restricted to service updates.
RGB IN (PC)
Connection for RGB output
from PC.
UPDATE
Restricted to software updates.
RESET
turns the TV OFF.
TV-LINK CFG
SERVICE ONLY
SPEAKER OUT
LINE OUT
LAN
AUDIO OUT
HDMI IN 1
Connection for HDMI output
from external device.
RESET
RESET
UPDATE
TV-LINK CFG
..........
OPTICAL
RGB IN (PC)
L R
L/MONO-AUDIO-R
VIDEO
AV IN / AUDIO IN (RGB DVI)
GAME CONTROL/MPI
When the TV/EBL is in Pass-through Mode, the
MPI function enables an external MPI control
device (i.e., VOD/PPV STB, etc.) to control the TV.
Game Control—EBL in SONIFI PPV Mode only.
IN
1
GAME CONTROL
/ MPI
ANTENNA/
CABLE IN
ANTENNA/CABLE IN
Connect to Antenna/
RJP
CATV.
SPEAKER OUT / LINE OUT
(
3.5 mm jack) Connect external audio (xed
speaker, variable speaker, or xed line level
[amplier]) equipment. See Reference
section, “External Stereo Speaker
Specifications,” for further information.
LAN
Use for video IP and/or network connections.
OPTICAL AUDIO OUT
Use for amps and home theater systems.
Note: When the TV is OFF, this port is not
enabled.
AV IN/AUDIO IN (RGB DVI)
Connect to composite audio/
video output from external device, or
connect audio for RGB or DVI device.
64
RJP
Connection for Remote Jack Pack (RJP)
Control cable.
Caution: Do NOT connect a standard
Ethernet cable to the RJP port, as this may
damage the TV and network equipment.
Side Jack Panel
USB IN
Insert USB memory device
USB IN
IN
3
IN
2
..........
for software updates, cloning
purposes, FTG Mode via CPU
configuration, picture/music
entertainment, etc., as applicable.
HDMI IN 2 & 3
Connection for HDMI output
from external device.
206-4278
Reference: External Stereo Speaker Specications
EXTERNAL SPEAKER_R- (Sleeve)
EXTERNAL SPEAKER_L- (Ring 1)
EXTERNAL SPEAKER_R+ (Ring 2)
EXTERNAL SPEAKER_L+ (Tip)
The SPEAKER OUT / LINE OUT 3.5 mm stereo jack on the LX570H rear panel provides stereo speaker
signal outputs (xed speaker, variable speaker, or xed line level [amplier]) for external audio equipment.
Set Installer Menu item 097 AUDIO OUTPUT as required in accordance with external audio equipment
connected to the TV. Also, refer to the following diagram for pinout details.
Caution: Do NOT plug in a mono connector, as this may damage the TV.
SPEAKER OUT
3
1
2
LINE OUT
1 LEFT (Tip)
2 RIGHT (Ring)
3 GROUND (Sleeve)
206-4278
65
Reference: Installer Remote Control Typical Key Functions
The LG Installer Remote is supplied with and dedicated to operate the TV. The LG Installer Remote illustrated
below shows typical remote control functions and is provided for reference only. This Installer Remote may vary
from the Installer Remote supplied with the TV.
(POWER)
Turns the TV ON or OFF
Numbers (0 - 9) & DASH
Use to enter a channel or program number.
Dash is used for sub-channel numbers such
as 2-1, 2-2, etc.
FLASHBK (FLASHBACK)
Returns to the previously tuned channel or
input.
VOLUME UP/DOWN
Increases/decreases sound level.
CC
Activates subtitles.
TIMER
Sets the amount of time before the TV
automatically turns itself OFF.
MUTE
Switches sound ON or OFF.
CHANNEL/PAGE UP/DOWN
Changes channels based on channels in
the channel lineup. Moves to previous or
next screen in Pro:Centric channel guide.
DVD/USB buttons
Use to control DVD player or view USB
memory device content.
Accesses the AV devices connected to the
HDMI ports of the TV. Opens the SIMPLINK
Menu (when Installer Menu item 041
SIMPLINK EN is set to 2 or 3).
(PIP/SWAP options N/A for these TV models)
SAP
Analog Mode: Selects MTS sound (Mono,
Stereo, or SAP). DTV Mode: Changes audio
program language, if additional languages are
available. *
Q.MENU
TV/DVD
Select the remote’s operating mode:
TV or DVD.
INPUT
TV
DVD
INPUT
MARK
Displays available Aux inputs.
@
.,;
1 2 3
ghi jkl mno
4 5 6
abc def
(Q. MENU/MARK options N/A for these TV
models)
Arrows (Up/Down/Left/Right) & OK/ENTER
pqrs tuv wxyz
7 8
9
Use to navigate on-screen menus, direct tune
channels, and adjust TV settings.
0
FLASHBK
MENU SETTINGS
Displays and removes the TV setup menus (or, if
CHAR/NUM
CC
TIMER
DELETE
MUTE
P
A
G
CHVOL
E
applicable, the Function Menu).
PORTAL
Displays and removes the Pro:Centric interactive
menu.
INFO
Displays channel information.
PORTAL
INFO
GUIDE
GUIDE
Displays and removes the Pro:Centric channel
guide/EPG.
OK
ENTER
(RETURN)
Returns one level to the previous menu/
display.
EXIT
Clears all on-screen displays and returns to
MENU
SETTINGS
EXIT
PIP PIPCH+ PIPCH
SWAP
PIP
INPUT
-
SAP
program viewing.
Color buttons access special functions
in some menus.
*
SAP notes:
• If SAP is selected and no SAP is provided, sound
may not be heard on channel.
• Each channel may have its own SAP setting.
• Each time digital channels are tuned, the TV attempts
to locate the default audio program language. If the
default audio program language is not available, the
TV will use the rst available audio program.
66
206-4278
Troubleshooting
General Troubleshooting
Some Quick and Easy Tips for Resolving Problems
Installation
Symptom Possible Cause(s) Possible Solution(s)
Cannot direct enter
channel number.
Picture Reception and Sound
Symptom Possible Cause(s) Possible Solution(s)
No picture. TV is turned OFF. • Turn TV ON.
Normal picture,
poor or no sound.
Erratic Operation
Symptom Possible Cause(s) Possible Solution(s)
Installer Menu setup. Wrong Installer Menu settings. Adjust Installer Menu settings as required.
Installer Remote
Symptom Possible Cause(s) Possible Solution(s)
Remote doesn’t work. Remote not in TV Mode. Use MODE key to select “TV”; puts remote into TV Mode.
(TV in Pass-through Mode) Installer
Menu item 028 CH. OVERIDE is set to
0, i.e., disabled (recommended setting).
(TV in FTG Mode) The channel entered
is not included in the FTG Channel Map.
If Installer Menu item 028 CH. OVERIDE is set to 0, only
channels that are active in the TV’s channel lineup can be
selected. Set CH. OVERIDE to 1 to allow access for direct
keypad entry to all channels.
Channel access is restricted to channels included in the FTG
Channel Map. If necessary, make changes to the FTG
Channel Map using the FTG File Manager or the FTG Device
Configuration Application, as appropriate.
• Power failure?
Antenna/cable not connected. Connect antenna/cable signal to TV.
Connections incorrect. Check connections on TV.
MPI not connected. If applicable, connect MPI cable to MPI device.
Encrypted program. Try another channel.
Wrong tuning band. Adjust Installer Menu settings.
Audio muted. Press MUTE or use Volume Up key to increase sound level.
Broadcast problem. Try a different channel.
Not aimed at IR receiver. Point remote at IR receiver on TV.
Remote too far from IR receiver or
IR path is obstructed.
MPI not connected. If applicable, connect MPI cable to MPI device.
Weak batteries. Replace batteries.
Wrong battery polarity. Check that “+” and “-” match in battery compartment.
Too much light in room. Dim room light.
Wrong Installer Remote. Requires compatible LG Installer Remote. Contact your LG
Move remote closer to IR receiver on TV, darken room, and/or
remove obstructions.
representative.
206-4278
67
Troubleshooting (Cont.)
Commercial Mode Check / FTG Operation Troubleshooting
Commercial Mode Check
Use this flowchart to determine whether the TV is currently in Commercial Mode.
Press POWER on
Installer Remote.
TV
TV turned
ON?
No
connected
to AC
Power?
No
Plug into AC
Power outlet.
Yes
Leave the TV set ON,
and press MENU
SETTINGS on the
Installer Remote.
Function
Menu
on display?
Yes
TV is in
Commercial Mode.
No
SETTINGS repeatedly
Yes
Bad
TV
Press MENU
as if to access the
Installer Menu.
On-screen
menu display
no longer
toggles?
Yes
TV is in
Commercial Mode.
TV is not in Commercial
No
Mode. Call Technical
Support for assistance.
FTG Operation Troubleshooting
The following table provides troubleshooting information for when the EBL is configured for FTG Mode operation.
Symptom Possible Cause(s) Solution(s)
Communication Error
(“Communications
Timeout”)
Cable(s) not connected. Check and connect communication cables.
TV not powered. Check/connect the TV power cord.
TV not turned ON. TV needs to be turned ON (default setting of Installer Menu
item 118 POWER SAVINGS).
Wrong COM
(communication) port.
In the FTG Device Configuration Application, select the
correct COM port for the cable being used.
68
206-4278
Glossary of Terms
b-LAN
SONIFI Solutions, Inc. proprietary RF
communication system used to congure/
control TV via RF distribution system.
Channel Lineup
Channels set in the TV memory, via Auto
Tuning/manual editing.
Cloning
The process of capturing a Master TV
Setup and transferring it to a Target TV
using a USB memory device.
Commercial Mode
A mode of operation that provides a broad
range of commercial TV features based on
control (settings) provided by the PTC and/
or an MPI control device.
CPU
The TV’s Central Processing Unit.
Responsible for the presentation of video
and audio from content received via the
TV’s tuner or Aux inputs.
EBL
Embedded b-LAN module. See also b-LAN.
E-Z Installation
Enables splash screen image, TV
conguration, and software/rmware le
downloads to selected TV models from
a Pro:Centric server. Managed and
administered via the Pro:Centric Admin
Client.
EZ-Manager Wizard
Lodging model TV conguration wizard
that provides conguration options for
Pro:Centric operation as well as an option
for using a USB memory device to
congure a TV.
FTG Channel Map
Typically refers to a logical channel mapping
of physical RF channels. This allows digital
channels, like analog channels, to be tuned
without requiring the dash key. Also, channels (analog or digital) can be arranged in
any order that seems logical for customer
tuning/viewing.
FTG Mode
LG commercial TV mode that enables
decryption of Pro:Idiom encrypted channels
and uses logical channel mapping. Implementation and TV operation is based on the
“owner” of the FTG Logical Channel Map—
the CPU or the EBL. LG’s proprietary PC
software is required for conguration.
Function Menu
Available via Installer Remote “MENU” key.
Indicates the TV is not in Pass-through
Mode. Restricts menu options to a subset
of the TV setup menus, allowing users to
retain functional control, while disabling
setup options.
Installer Menu
Denes commercial TV functionality based
on the parameters set.
LG Free-To-Guest (FTG)
Refers to a particular commercial mode of
operation within an LG TV. See also FTG
Mode.
Logical Channel Number
A number assigned to either a physical or
virtual channel number in a Logical Channel
Map.
Major Channel Number
Typically, the RF channel number assigned
to a digital video stream.
Master TV
A TV whose Channel Map and Installer
Menu and TV setup menu settings have
been congured as a Master TV Setup for
cloning purposes.
Minor Channel Number
A sub-channel or program number
assigned to the content embedded in the
digital video stream.
MPI
Multiple Protocol Interface. An MPI port or,
for some TV models, an MPI card slot
provides external control options for solution
providers.
Pass-through Mode
The TV’s factory default mode of operation.
TVs can be congured for stand-alone use
or as Master TVs for cloning purposes,
and/or TVs may be controlled externally in
this mode.
Physical Channel Number
The major channel number assigned to
represent a specic 6 MHz RF band as
specied by either the broadcast or CATV
channel plan. See CEA (formerly EIA) or
NCTA specications for further information.
Pro:Centric Application
LG content delivery and communication
interface that provides interactive entertainment, weather, amenities, etc. information
for end users. (Powered by Pro:Centric
server.)
Pro:Centric Admin Client
Web editor/content wizard provided for
service provider and customer conguration
of Pro:Centric application elements.
Pro:Idiom
Zenith proprietary security software that
unlocks access to premium content to help
assure rapid, broad deployment of HDTV
and other high-value digital content.
PTC
Protocol Translator Card. The commercial
controller (microprocessor) of the commercial TV.
Target TV
A TV to which a Master TV Setup will be
transferred.
TV Setup Menus
Available via Installer Remote “MENU” key
in Pass-through Mode only. Menus provide
access to setup and functional features of
the TV.
USB Memory Device
A USB ash drive or USB storage device,
etc. that can be used for TV conguration
purposes (typically cloning or FTG Mode
via CPU conguration) or for updating TV
software.
Virtual Channel Number
An alias (virtual) channel number provided
in the data stream, by the broadcaster, of a
digital broadcast channel to be displayed
by consumer TVs in place of the physical
channel number. The major number is the
same as the original analog channel
number and the minor number is the nth
program available in that digital video
stream.
206-4278
69
Document Revision History / Open Source Software Notice
Document Revision History
Date Description
April 2015 Revision A: New document
April 2015 Revision B: Installer Menu item 099 BACK LIGHTING update
May 2015 Revision C: Import Clone File and Master TV Setup updates
Product documentation is available online at: www.LGsolutions.com.
Open Source Software Notice
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please
visit http://opensource.lge.com. In addition to the source code, all referenced license terms, warranty disclaimers and copyright
notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering
the cost of performing such distribution (such as the cost of media, shipping and handling) upon e-mail request to opensource@
lge.com. This offer is valid for three (3) years from the date on which you purchased the product.
70
206-4278
For Customer Support/Service, please call:
1-888-865-3026
www.LGsolutions.com
Pro:Idiom is a registered trademark of Zenith Electronics LLC. Pro:Centric and the “LG” logo
are registered trademarks of LG Electronics Inc. b-LAN is a trademark of SONIFI Solutions,
Inc. All other trademarks or registered trademarks are the property of their respective owners.
© Copyright 2015 LG Electronics U.S.A., Inc.
206-4278
Revision C
Loading...
