Page 1
QUICK REFERENCE GUIDE
LED LCD TV
Please read this manual carefully before operating your set and retain it
for future reference.
55LS675H
P/NO : MFL67415433 (1211-REV00)
www.lgsolutions.com
Page 2
ENGLISH
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Short-circuit
Breaker
Power Supply
Short-circuit
Breaker
Power Supply
ENG
IMPORTANT SAFETY INSTRUCTIONS
2
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
Read these instructions.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
y
Clean only with a dry cloth.
y
Do not block any ventilation openings. Install
y
in accordance with the manufacturer’s
instructions.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING
: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
Wash hands after handling.
Do not install near any heat sources such
y
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the
y
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet (Can differ by country).
Page 3
IMPORTANT SAFETY INSTRUCTIONS
Short-circuit
Breaker
Power Supply
Short-circuit
Breaker
Power Supply
3
Protect the power cord from being walked on
y
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
Only use attachments/accessories specified
y
by the manufacturer.
Use only with a cart, stand, tripod, bracket,
y
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning
y
storms or when unused for long periods of
time.
Refer all servicing to qualified service
y
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Keep the packing anti-moisture material or
y
vinyl packing out of the reach of children.
Anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can
cause suffocation. Keep it out of the reach of
children.
CAUTION concerning the Power Cord
y
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
ENGLISH
ENG
Do not stick metal objects or any other
y
conductive material into the power cord. Do
not touch the end of the power cord while it
is plugged in.
Page 4
IMPORTANT SAFETY INSTRUCTIONS
4
ENGLISH
ENG
Warning
y
- To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
Do not expose to dripping or splashing and
y
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
Grounding
y
(Except for devices which are not grounded.)
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
ANTENNAS Outdoor Antenna Grounding
y
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Antenna Lead in Wire
Ground Clamp
Electric Service
Equipment
Ground Clamp
NEC: National Electrical Code
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Short-circuit
Breaker
DISCONNECTING THE MAIN POWER
y
Power Supply
The power outlet used with this device must
remain easily accessible.
As long as this unit is connected to the AC
y
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
Do not attempt to modify this product in any
y
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
Cleaning
y
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
Moving
y
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
Ventilation
y
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
Page 5
IMPORTANT SAFETY INSTRUCTIONS
Short-circuit
Breaker
Power Supply
5
If you smell smoke or other odors coming
y
from the TV, unplug the power cord and
contact an authorized service center.
Do not press strongly upon the panel with a
y
hand or a sharp object such as a nail, pencil
or pen, or make a scratch on it.
Keep the product away from direct sunlight.
y
Never touch this apparatus or antenna during
y
a thunder or lightning storm.
When mounting a TV on the wall, make sure
y
not to install the TV by hanging the power
and signal cables on the back of the TV.
Do not allow an impact shock or any objects
y
to fall into the product, and do not drop
anything onto the screen.
Dot Defect
y
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
Generated Sound
y
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a highspeed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
Take care not to touch the ventilation
y
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product.
If the TV feels cold to the touch, there may
y
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
Preventing “Image burn” or “Burn-in” on your TV screen
If a fixed image displays on the TV screen
y
for a long period of time, it will be imprinted
and become a permanent disfigurement on
the screen. This is “image burn” or “burn-in”
and not covered by the warranty.
If the aspect ratio of the TV is set to 4:3 for
y
a long period of time, image burn may occur
on the letterboxed area of the screen.
Avoid displaying a fixed image on the TV
y
screen for a long period of time (2 or more
hours for LCD, 1 or more hours for the
Plasma TV) to prevent image burn.
For USA and Canada
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides
guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected
to the grounding system of the building, as close
to the point of the cable entry as practical.
ENGLISH
ENG
Page 6
LICENSES / OPEN SOURCE SOFTWARE NOTICE
6
LICENSES
Supported licenses may differ by model. For more information about licenses, visit 'www.lg.com'.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified
DivX video. Visit divx.com for more information and software tools to convert your
files into DivX video.
®
device that plays
ENGLISH
ENG
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified
in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your registration.
“DivX Certified
®
“DivX
or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
, DivX Certified® and associated logos are trademarks of Rovi Corporation
®
to play DivX® video up to HD 1080p, including premium content.”
®
device must be registered
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit 'http://opensource.lge.com'.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date on which you purchased the
product.
Page 7
TABLE OF CONTENTS
TABLE OF CONTENTS
7
2 IMPORTANT SAFETY INSTRUCTIONS
6 LICENSES
6 OPEN SOURCE SOFTWARE NOTICE
7 TABLE OF CONTENTS
8 INSTALLATION PROCEDURE
8 ASSEMBLING AND PREPARING
8 Unpacking
10 Parts and buttons
11 Setting up the TV
11 - Attaching the stand
12 - Mounting on a table
13 - Mounting on a wall
14 - Tidying cables
14 - External speaker out
15 REMOTE CONTROL
17 SPECIFICATIONS
18 GENERAL TROUBLESHOOTING
NOTE
Image shown may differ from your TV.
y
Your TV’s OSD (On Screen Display) may
y
differ slightly from that shown in this manual.
The available menus and options may differ
y
from the input source or product model that
you are using.
New features may be added to this TV in the
y
future.
ENGLISH
ENG
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation of the device.
Any changes or modifications in construction of this device which are not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
Page 8
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING
8
INSTALLATION PROCEDURE
Open the package and make sure all the accessories are included.
1
Attach the stand to the TV set.
2
Connect an external device to the TV set.
3
ENGLISH
ENG
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
CAUTION
To ensure safety and product life span, do not use any unapproved items.
y
Any damages or injuries sustained due to use of unapproved items are not covered by the warranty.
y
In the case of some models, the thin film on the screen is a part of TV and should not be removed.
y
NOTE
The items supplied with your product will vary depending on the model.
y
Product specifications and/or manual contents subject to change without prior notice due to upgrade
y
of product functions.
Page 9
ASSEMBLING AND PREPARING
AV MODE
INPUT
ENERGY
TV
SAVING
1 2 3
4 5 6
7 809
FLASHBK
LIST
MARK
FAV
P
A
G
3D
CHVOL
E
MUTE
INFO
MENU
Q.MENU
ENTER
EXIT
BACK
L/R SELECT
FREEZE
RATIO
9
Remote Control,
Batteries (AAA)
(See p.15)
Stand Body, Stand Base
(See p.11)
Wall Mount Inner Spacers
4 EA
(See p.13)
Quick Reference Guide Power Cord
Stand Screws
8 EA, M4 x 20
Desk-Mount Screw
(See p.12)
(See p.11)
Cable Holder
(See p.14)
ENGLISH
ENG
Page 10
ASSEMBLING AND PREPARING
10
Parts and buttons
USB
Input
HDMI
Input
ENGLISH
ENG
Side Connection Panel
USB IN
IN
3
RJP
INTERFACE
GAME CO NTROL
/M.P.I
SPEAKER OUT
(8 )
1
RESET
RS-232C
(SERVICE ONLY)
RGB IN (PC)
2
/ DVI IN
UPDATE
L R
AV IN
Screen
Speakers
VIDEO
PTC SERVICE
(SERVICE ONLY)
L/MONO
-AUDIO-
TV -LINK CFG
R
AUDIO IN
(RGB/DVI)
ANTENN A/
CABLE IN
Rear Connection
Panel
Remote Control and
Intelligent
1
Sensors
Power Indicator
OK
SETTINGS
Touch Buttons
INPUT
2
Touch button Description
/
I
Turns the power on or off.
INPUT Changes the input source.
SETTINGS Accesses the Home menu, or saves your input and exits the menus.
ꔉ
OK
Selects the highlighted menu option or confirms an input
- + Adjusts the volume level.
v
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
Page 11
ASSEMBLING AND PREPARING
Setting up the TV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
CAUTION
When attaching the stand to the TV set, place the screen facing down on a cushioned table or flat
y
surface to protect the screen from scratches.
Make sure that the screws are fastened tightly. (If they are not fastened securely enough, the TV may
y
tilt forward after being installed.)
Do not tighten the screws with too much force; otherwise they may be damaged and come loose
y
later.
NOTE
Remove the stand before installing the TV on a wall mount by performing the stand attachment in
y
reverse.
11
1
Stand Body
Stand Base
3
4 EA
M4 x 20
Front
Top View
2
ENGLISH
ENG
4 EA
M4 x 20
Page 12
ASSEMBLING AND PREPARING
12
ENGLISH
ENG
Mounting on a table
Lift and tilt the TV into its upright position on a
1
table.
- Leave a 10 cm (4 inch) (minimum) space from
the wall for proper ventilation.
10 cm
(4 inch)
10 cm
Connect the power cord to a wall outlet.
2
CAUTION
Do not place the TV near or on sources
y
of heat, as this may result in fire or other
damage.
10 cm
10 cm
Adjusting the angle of the TV to suit view
(Depending on model)
Swivel 20 degrees to the left or right and adjust
the angle of the TV to suit your view.
20˚20˚
CAUTION
When adjusting the angle of the TV,
y
watch out for your fingers.
- Personal injury may occur if hands or
fingers are pinched. If the product is
tilted too much, it may fall, causing
damage or injury.
Attaching the TV to a desk
Securing the TV to a table
Fix the TV to a table to prevent from tilting
forward, damage, and potential injury.
To secure the TV to a table, insert and tighten the
supplied screw on the rear of the stand.
WARNING
To prevent TV from falling over, the TV should
y
be securely attached to the floor/wall per
installation instructions. Tipping, shaking, or
rocking the TV may cause injury.
The TV should be attached to a desk so it cannot
be pulled in a forward/backward direction,
potentially causing injury or damaging the product.
4-Screws
(Not provided as parts of the product)
Stand
Desk
Page 13
ASSEMBLING AND PREPARING
13
Mounting on a wall
Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
LG recommends that wall mounting be performed
by a qualified professional installer.
10 cm
(4 inch)
10 cm
10 cm
10 cm
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described
in the following table.
Model 55LS675H
VESA 400 x 400
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
LSW400BX(G), LSW420BX
CAUTION
Disconnect the power before moving or
y
installing the TV.
If you install the TV on a ceiling or slanted
y
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
Do not over tighten the screws as this may
y
cause damage to the TV and void your
warranty.
Only use screws and wall mounts that meet
y
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
NOTE
A wall mount bracket is optional. You can
y
obtain additional accessories from your local
dealer.
Use screws that are listed on the VESA
y
standard screw specifications.
The wall mount kit includes an installation
y
manual and necessary parts.
The length of screws may differ depending
y
on the wall mount. Make sure to use the
proper length.
For more information, refer to the manual
y
supplied with the wall mount bracket.
When attaching a third-party wall mounting
y
bracket to the TV, insert the wall mount
inner spacers into the TV wall mount holes
to move your TV in vertical angle. Please
make sure not to use the spacers for LG wall
mounting bracket.
ENGLISH
ENG
Wall Mount Inner Spacer
Page 14
ASSEMBLING AND PREPARING
14
ENGLISH
ENG
Tidying cables
Gather and bind the cables with the cable
1
holder.
Cable Holder
CAUTION
Do not move the TV by holding the cable
y
holder, as the cable holders may break, and
injuries and damage to the TV may occur.
External speaker out
Connect the external speaker.
RJP
INTERFACE
GAME C ONTROL
/M.P.I
SPEAKE R
OUT (8 )
Make sure that the external speaker should
y
be connected with TV under power-off
state.
Use EXT speaker with BTL type (4p)
y
NOTE
RESET
RS-232C
(SERVICE ONLY)
RGB IN (PC)
UPDATE
/ DVI IN
AUDIO IN
(RGB/DVI)
AV IN
VIDEO
PTC SERVICE
(SERVICE ONLY)
L/MONO
L R
-AUDIO-
TV -LINK
CFG
21
R
L L+
R +
R -
ANTENN A/
CABLE IN
Page 15
REMOTE CONTROL
REMOTE CONTROL
The descriptions in this manual are based on the buttons on the remote control.
Please read this manual carefully and use the TV correctly.
To install batteries, open the battery cover, insert batteries (1.5 V AAA) matching the
and ends to the label inside the compartment, and close the battery cover. To
remove the batteries, perform the installation actions in reverse.
CAUTION
Do not mix old and new batteries, as this may damage the remote control.
y
This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote
sensor.
15
INPUT
TV
DVD
@
.,;
1 2 3
4 5 6
7 809
VOL
PORTAL
abc def
ghi jkl mno
pqrs tuv wxyz
CHAR/NUM
CC
TIMER
DELETE
MUTE
INFO
OK
ENTER
Q.MENU
MARK
FLASHBK
CH
GUIDE
(POWER
)
Turns the TV on or off.
Q. MENU
Not functional
TV
Selects the remote’s operating mode: TV.
DVD
Selects the remote’s operating mode: DVD.
ENGLISH
ENG
INPUT
INPUT: Rotates through inputs. Also switches the TV on from standby.
MARK
Not functional
Number button
Enters channel numbers or other numbers required.
P
A
G
E
Also supports characters.
— (DASH)
Selects a program number for multiple program channels
such as 2-1, 2-2, etc.
FLASHBK
Tunes to the last channel or input viewed.
VOL
Adjusts the volume level.
MENU
EXIT
SETTINGS
PIP PIPCH+ PIPCH
SWAP
PIP
INPUT
-
SAP
CC
Selects a closed caption.
CHAR/NUM
Switches between Letter and Number input modes.
TIMER
Turns the TV off in a set amount of time.
MUTE
Mutes all sounds.
DELETE
Deletes letters and numbers.
CH
v
^
Scrolls through the saved channels.
PAGE
Moves to the previous or next screen.
Page 16
REMOTE CONTROL
16
Q.MENU
PORTAL
Displays and removes the interactive menu.
ENGLISH
ENG
INPUT
TV
DVD
@
.,;
1 2 3
4 5 6
7 809
VOL
PORTAL
abc def
ghi jkl mno
pqrs tuv wxyz
CHAR/NUM
CC
TIMER
DELETE
MUTE
INFO
OK
ENTER
MENU
EXIT
SETTINGS
MARK
FLASHBK
CH
GUIDE
INFO
Views the information of the current program and screen.
GUIDE
Displays and removes the electronic program guide.
Navigation buttons
(up/down/left/right)
Scrolls through menus or options.
OK/ENTER
ꔉ
Selects menus or options and confirms your input.
ꕣ (
BACK)
Returns to the previous level.
MENU/SETTINGS
P
A
G
E
Accesses the main menu.
ꕯ
EXIT
Clears all on-screen displays and returns to TV viewing.
Color buttons ( : Red, : Green, : Yellow, : Blue )
These access special functions in some menus.
VCR/DVD/USB control buttons ( , , , , )
Controls video cassette recorders or DVD players or USB.
Accesses the AV devices connected to the TV;
Opens the SIMPLINK menu.
PIP PIPCH+ PIPCH
SWAP
PIP
INPUT
SAP
PIP
Not functional
-
PIP CH +/-
Not functional
SWAP
Not functional
PIP INPUT
Not functional
SAP
Analog mode: Selects MTS sound (Mono, Stereo or SAP)
DTV mode: Changes the audio language.
Page 17
SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement AC100 - 240 V ~ 50/60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
Maximum number of storable programs 700
External Antenna Impedance 75
Environment
condition
Operating
Temperature
Operating Humidity Less than 80%
Storage Temperature -20 - 60°C
Storage Humidity Less than 85%
Ω
0 - 40°C
17
MODELS
Dimensions
(W x H x D)
Weight With stand 25.5 kg (56.2 lbs)
Current Value / Power consumption 1.5 A / 150 W
RGB(PC), HDMI (PC) supported mode
Resolution
640x350 31.46 70.09
720x400 31.46 70.08
640x480 31.46 59.94
800x600 37.87 60.31
1024x768 48.36 60.00
1280x768 47.77 59.87
1360x768 47.71 60.01
1280x1024 63.98 60.02
1600x1200 75.00 60.00
1920x1080
RGB-PC
1920x1080
HDMI-PC
Horizontal
Frequency (KHz)
66.58 59.93
67.50 60.00
With stand 1,263 x 822 x 315 (mm)
Without stand 1,263 x 754 x 35.5 (mm)
Without stand 21.9 kg (48.2 lbs)
HDMI (DTV) supported mode
Vertical
Frequency (Hz)
Resolution
720x480p
1280x720p
1920x1080i
1920x1080p
55LS675H
(55LS675H-UA)
49.7 x 32.3 x 12.4 (inch)
49.7 x 29.6 x 1.3 (inch)
Horizontal
Frequency (KHz)
31.47
31.50
44.96
45.00
33.72
33.75
26.97
27.00
33.71
33.75
67.43
67.50
Vertical
Frequency (Hz)
59.94
60.00
59.94
60.00
59.94
60.00
23.97
24.00
29.97
30.00
59.94
60.00
ENGLISH
ENG
Page 18
GENERAL TROUBLESHOOTING
18
GENERAL TROUBLESHOOTING
Installation
Symptom Possible Cause(s) Possible Solution(s)
Cannot direct enter
channel number.
No channels present after
setup.
(TV in Pass-through Mode) Installer
y
Menu item 028 CH. OVERIDE is set
to 0, i.e., disabled (recommended
setting).
(TV in FTG Mode) The channel entered
y
is not part of the FTG Channel Map.
Auto Tuning (Channel Search) not run. yRefer to Express Script or Custom Master TV
y
If the channel lineup is locked, only channels
y
that are active in the TV’s channel lineup can
be selected. Set Installer Menu item 028 CH.
OVERIDE to 1 to allow access for direct keypad
entry to all channels.
Channel access is restricted to channels
y
included in the FTG Channel Map. If necessary,
make changes to the FTG Channel Map using
the FTG File Manager or the FTG Configuration
Application, as appropriate.
Setup procedure, as appropriate. Auto Tuning
must be run in order for the channel lineup
to be populated. Note for Express Script: You
must select “Execute Auto Search” in the Auto
Search screen to run the search. To re-activate
the Express Script, set Installer Menu item 117
FACT DEFAULT to 001.
ENGLISH
ENG
Picture Reception and Sound
Symptom Possible Cause(s) Possible Solution(s)
No picture.
Normal picture, poor or
no sound.
TV is turned OFF.
y
Antenna/cable not connected.
y
Connections incorrect.
y
MPI not connected
y
Encrypted program.
y
Wrong tuning band.
y
Broadcast problem.
y
Audio muted
y
Pillow/TV speaker not configured
y
properly.
Erratic Operation
Symptom Possible Cause(s) Possible Solution(s)
Installer Menu setup.
Wrong Installer Menu settings.
y
Turn TV ON.
y
Power failure?
y
Connect antenna/cable signal to TV.
y
Check connections on TV.
y
If applicable, connect MPI cable to MPI device.
y
Try another channel.
y
Adjust Installer Menu settings.
y
Try a different channel.
y
Press MUTE or use Volume Up key to increase
y
sound level.
Check that Installer Menu items 020 FEATURE
y
LEVEL and 027 HOSPITAL MODE are set as
required. Also, if applicable, select TV Speaker in
the Audio Menu.
Adjust Installer Menu settings as required.
y
Page 19
Installer Remote
Symptom Possible Cause(s) Possible Solution(s)
Remote doesn’t work.
Remote not in TV Mode.
y
Not aimed at IR remote sensor.
y
Remote too far from IR sensor.
y
MPI not connected.
y
IR path to TV’s receiver obstructed.
y
Weak batteries.
y
Wrong battery polarity.
y
Too much light in room.
y
Wrong Installer Remote.
y
Bed Switch set to wrong bed.
y
GENERAL TROUBLESHOOTING
Use MODE key to select “TV”; puts remote into
y
TV Mode.
Point remote at TV’s IR receiver on TV.
y
Move remote closer to TV’s IR receiver or darken
y
room.
If applicable, connect MPI cable to MPI device.
y
Remove obstructions.
y
Replace batteries.
y
Check that “+” and “-” match in battery
y
compartment.
Dim room light.
y
Requires compatible Installer Remote. Contact
y
your LG dealer.
Set Bed Switch or update Installer Menu, as
y
necessary.
19
ENGLISH
ENG
Page 20
Page 21
Page 22
Page 23
CHILD SAFETY:
It Makes A Difference How and Where
You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind:
THE ISSUE
yThe home theater entertainment experience is a growing trend and
larger flat panel displays are popular purchases. However, flat panel
displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
yFlat panel displays that are inappropriately situated on dressers,
bookcases, shelves, desks, speakers, chests or carts may fall over and
cause injury.
THIS MANUFACURER CARES!
yThe consumer electronics industry is committed to making home
entertainment enjoyable and safe.
TUNE INTO SAFETY
yO n e s i z e do e s N O T f it a ll . Fo ll ow t he ma nu fa ct u r e r ’ s
recommendations for the safe installation and use of your flat panel
display.
yCarefully read and understand all enclosed instructions for proper use
of this product.
yDon’t allow children to climb on or play with furniture and television
sets.
yDon’t allow place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
yRemember that chi ldren can become excite d while wat ching
a program, especially on a “larger than life” flat panel display.
Care should be taken to place or install the display where it cannot be
pushed, pulled over, or knocked down.
yCare should be taken to route all cords and cables connected to the
flat panel display so that they cannot be pulled or grabbed by curious
children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT
YOUR FLAT PANEL DISPLAY, ALWAYS:
yUse a moun t t ha t ha s be en reco m me n de d by t he disp l ay
ma n uf ac tu re r and /o r lis t ed by a n ind e pen d en t lab o ra to ry
(such as UL, CSA, ETL).
yFollow all instructions supplied by the display and wall mount
manufacturers.
yIf you have any doubts about your ability to safely install your flat
panel display, contact your retailer about professional installation.
yMake sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with stee l st u d s o r ol d ci n d er bloc k co n s truc t i on.
If you are unsure, contact a professional installer.
yA mi n im u m of tw o pe o pl e ar e re q ui r ed fo r in st al l at i on .
Flat panel displays can be heavy
Page 24
The model and serial numbers of the TV are
located on the back and/or one side of the TV.
Record them below should you ever need service.
MODEL
SERIAL
LG Customer Information Center
For inquires or comments, visit www.lg.com or call:
1-888-865-3026
1-888-542-2623
USA, Commercial User
CANADA
Pro:Centric is a trademark of LG Electronics U.S.A., Inc. Pro:Idiom is
a registered trademark of Zenith Electronics LLC. b-LAN is a trademark
of LodgeNet Interactive Corporation. All other trademarks or registered
trademarks are the property of their respective owners.
This product qualifies for ENERGY STAR in the
“factory default (Home Use)” setting.
Changing the factory default settings or enabling other
features may increase power consumption that could
exceed the limits necessary to quality for ENERGY STAR.
Loading...
