LG 27MB35PH-B, 23MB35PH-B User guide

ENGLISH

OWNER’S MANUAL

IPS LED MONITOR

Please read this manual carefully before operating your set and retain it for future reference.

IPS LED MONITOR MODEL

23MB35PH 24MB35PH 27MB35PH

www.lg.com

TABLE OF CONTENTS

2

ENGLISH

ENG

LICENSE

3

LICENSE

Each model has different licenses. Visit

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

www.lg.com

ENGLISH

ENG

for more information on the license.

The following content is only applied to the monitor which is sold in Europe market and which needs to meet the ErP Directive: * This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no adjustment to display. * To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.

ASSEMBLING AND PREPARING

4

ENGLISH

ENG

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.

CD / Card

D-SUB Cable

(This cable is not

included in all

countries.)

DVI-D Cable

(This cable is not

included in all

countries.)

Power Cord

Stand Base

23MB35PH

24MB35PH

One Screw

(This cable is not included in all

Cable Holder

HDMI Cable

countries.)

27MB35PH

CAUTION

Do not use any unapproved accessories to ensure the safety and product life span.

y

Any damages or injuries by using unapproved accessories are not covered by the warranty.

y

NOTE

The accessories supplied with your product may vary depending on the model.

y

Product specifications or contents in this manual may be changed without prior notice due to upgrade

y

of product functions.

Parts and buttons

23MB35PH

24MB35PH

ASSEMBLING AND PREPARING

Power Indicator

Lighting On: Turned on

y

Lighting Off: Turned off

y

5

ENGLISH

ENG

(Power Button)

Front Side Buttons

Connection panel (See p.17~19)

ENGLISH

ENG

ASSEMBLING AND PREPARING

6

Parts and buttons

27MB35PH

Power Indicator

Lighting On: Turned on

y

Lighting Off: Turned off

y

(Power Button)

Front Side Buttons

Connection panel (See p.17~19)

ASSEMBLING AND PREPARING

7

Moving and Lifting the Monitor

When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation regardless of its shape or size.

It is advisable to place the monitor in the

y

original box or packing material before attempting to move it. Before moving or lifting the monitor, discon-

y

nect the power cord and all cables. Hold the top and bottom of the monitor frame

y

firmly. Do not hold the panel itself.

When holding the monitor, the screen should

y

face away from you to prevent it being scratched.

When moving the monitor, avoid any strong

y

shock or vibrations to the product. When moving the monitor, keep it upright,

y

never turn the monitor on its side or tilt it sideways.

CAUTION

As far as possible, avoid touching the moni-

y

tor screen. This may result in damage to the screen or some of the pixels used to create images.

ENGLISH

ENG

ASSEMBLING AND PREPARING

8

ENGLISH

ENG

Setting up the Monitor set

Attaching the Stand Base

Place the Monitor set with the screen side

1

down on a flat and cushioned surface.

CAUTION

To protect the screen from scratches, cover

y

the surface with a soft cloth.

23MB35PH

Check the

2

the stand body, then mount the the

position (at the front and rear)

stand body

as shown in the figure.

Stand Body

stand base

of

on

24MB35PH

Check the

2

the stand body, then mount the the

Stand Base

position (at the front and rear)

stand body

as shown in the figure.

27MB35PH

Check the

2

the stand body, then mount the the

position (at the front and rear)

stand body

as shown in the figure.

Stand Body

stand base

Stand Body

stand base

of

on

of

on

Stand Base

Using a coin, turn the screw clockwise to se-

3

cure the

Stand Base

stand base.

Stand Base

Using a coin, turn the screw clockwise to se-

3

cure the

stand base.

Stand Base

ASSEMBLING AND PREPARING

9

Detaching the stand base

Place the monitor's screen face down.

1

To protect the screen from scratches, cover the surface with a soft cloth.

23MB35PH

Using a coin, turn the screw in the stand base

2

counterclockwise. Detach the

stand body

the

Stand Base

.

24MB35PH

Detach the

2

stand base

Stand Body

from the

stand body

from

.

27MB35PH

Using a coin, turn the screw in the stand base

2

counterclockwise. Detach the

stand body

the

.

Stand Body

Stand Base

stand base

CAUTION

The components appearing in the illustra-

y

tions may look different from the actual product. Do not carry the monitor upside-down as this

y

may cause it to fall off its stand, resulting in damage or injury. To avoid damaging the screen when lifting

y

or moving the monitor, only hold the stand or the plastic cover. This avoids putting unnecessary pressure on the screen. Only remove the tape and the locking pin

y

when the monitor is mounted on the stand base and is in an upright position. Otherwise, the stand body may protrude, which may lead to injury.

from

ENGLISH

ENG

ASSEMBLING AND PREPARING

10

ENGLISH

ENG

Detaching the stand body

Place the monitor's screen face down. To

1

protect the screen from scratches, cover the surface with a soft cloth.

Using a screwdriver, remove the four screws

2

and detach the stand from the monitor.

24MB35PH

23MB35PH

27MB35PH

Using the cable holder

1

Fix the Knob (Cable holder) to the Hole(Hingebody).

Use one screw to fix the Cable Holder and

2

monitor set.

3

Close the Cable holder.

27MB35PH

NOTE

The holes are used for wall mount bracket.

y

Varies depending upon your country or

y

model.

ASSEMBLING AND PREPARING

11

Mounting on a table

Lift the monitor and place it on the table in an

1

upright position.

Install at least ensure sufficient ventilation.

23MB35PH

24MB35PH

100 mm

away from the wall to

100 mm

23MB35PH

24MB35PH

Connect the Power cord to the monitor, then

2

plug the power cord into the wall outlet.

27MB35PH

2

1

Connect the Power cord to the monitor, then plug the power cord into the wall outlet. (Before connect please check the “ON/OFF” knob in “O” state).

2

Press the “ON/OFF” knob in “ ” state (Open the power).

ENGLISH

ENG

27MB35PH

100 mm

Press the (Power) button on the front of the

3

monitor to turn on the monitor.

CAUTION

Unplug the power cord prior to moving or

y

installing the monitor. There is risk of electric shock.

ASSEMBLING AND PREPARING

12

ENGLISH

ENG

Adjusting the angle

Place the monitor mounted on the stand base

1

in an upright position.

23MB35PH

24MB35PH

Adjust the angle of the screen. The angle of

2

the screen can be adjusted up to 5° forwards and 20° backwards for a comfortable viewing experience.

Rear Side

Front Side

WARNING

To avoid injury to the fingers when adjusting

y

the screen, do not hold the lower part of the monitor's frame as illustrated below.

Be careful not to touch or press the screen

y

area when adjusting the angle of the monitor.

27MB35PH

Adjust the angle of the screen. The angle of

2

the screen can be adjusted up to 5° forwards and 35° backwards for a comfortable viewing experience.

Rear Side

Front Side

Adjusting the stand height

Place the monitor mounted on the stand base

1

in an upright position.

ASSEMBLING AND PREPARING

WARNING

y

Do not put your finger between the screen and the base (chassis) when adjusting the screen's height.

13

ENGLISH

ENG

Remove the

2

of the

pin.

tape

stand body,

attached at the bottom rear

then pull out the

23MB35PH

Stand Body

Tape

24MB35PH 27MB35PH

Stand Body

Locking Pin

Tape

Locking Pin

locking

Using the Kensington locking device

The connector for the Kensington lock is located on the rear of the monitor. For more information on installation and usage, refer to the Kensington lock user manual or visit the website at http://www.kensington.com.

Connect the monitor to the table with the Kensing-

ton lock cable.

23MB35PH

24MB35PH

23MB35PH

3

24MB35PH

The height can be adjusted up to

27MB35PH

The height can be adjusted up to

CAUTION

Once the pin is removed, it is not necessary

y

to re-insert it to adjust the height.

110 mm

110.0mm

130 mm

130.0mm

.

27MB35PH

NOTE

Using the Kensington lock is optional. The

y

accessories can be purchased at your local electronics store.

ENGLISH

ENG

ASSEMBLING AND PREPARING

14

24MB35PH

Swivel stand

Image shown may differ from your Monitor

y

set.

Swivel 355 degrees and adjust the angle of the

1

Monitor set to suit your view.

Be careful with the cables when rotating the

3

screen.

23MB35PH

24MB35PH

Using the Pivot function

The pivot function allows you to rotate the screen 90 degrees clockwise.

Lift the monitor to its highest height to utilize

1

the Pivot function.

Landscape & Portrait : You can rotate the panel

2

90° clockwise. Please be cautious and avoid contact between the monitor head and the Stand Base when rotating the screen to access the Pivot function. If the monitor head touches the Stand Base, then the Stand Base could crack.

Head section

Stand section

27MB35PH

Swivel stand

Image shown may differ from your Monitor

y

set.

Swivel 355 degrees and adjust the angle of the

1

Monitor set to suit your view.

ASSEMBLING AND PREPARING

Be careful with the cables when rotating the

3

screen.

15

ENGLISH

ENG

Using the Pivot function

The pivot function allows you to rotate the screen 90 degrees clockwise.

Lift the monitor to its highest height to utilize

1

the Pivot function.

Landscape & Portrait : You can rotate the panel

2

90° clockwise. Please be cautious and avoid contact between the monitor head and the Stand Base when rotating the screen to access the Pivot function. If the monitor head touches the Stand Base, then the Stand Base could crack.

Head section

Stand section

ASSEMBLING AND PREPARING

16

ENGLISH

ENG

Mounting on a wall

For proper ventilation, allow a clearance of 100 mm on each side and from the wall. Detailed instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

100 mm

If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set. When you install the Monitor set using a wall mounting interface (optional parts), attach it carefully so it will not drop.

Please, Use the screw and wall mount interface

1

in accordance with VESA Standards.

If you use screw longer than standard, the

2

monitor might be damaged internally.

100 mm

Model

VESA (A x B) 100 x 100 200 x 100 Standard screw M4 M4 Number of screws 4 4

CAUTION

Disconnect the power cord first, and then

y

move or install the Monitor set. Otherwise electric shock may occur. If you install the Monitor set on a ceiling or

y

slanted wall, it may fall and result in severe injury. Use only an authorized LG wall mount

y

and contact the local dealer or qualified personnel. Do not over tighten the screws as this may

y

cause damage to the Monitor set and void your warranty. Use only screws and wall mounts that

y

meet the VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty. Screw length from outer surface of back

y

cover should be under 8mm.

Wall mount Pad

Standard screw

23MB35PH

24MB35PH

Wall mount Pad

Back Cover

27MB35PH

Back Cover

If you use improper screw, the product might be

3

damaged and drop from mounted position. In this case, LG Electronics is not responsible for it.

VESA compatible only with respect to screw

4

mounting interface dimensions and mounting screw specifications.

Please use VESA standard as below.

5

784.8 mm (30.9 inch) and under

y

* Wall Mount Pad Thickness : 2.6 mm

* Screw : Φ 4.0 mm x Pitch 0.7 mm x

Length 10 mm

787.4 mm (31.0 inch) and above

y

* Please use VESA standard wall mount pad

and screws.

Max.8mm

NOTE

Use the screws that are listed on the VESA

y

standard screw specifications. The wall mount kit will include an installation

y

manual and necessary parts. The wall mount bracket is optional. You can

y

obtain additional accessories from your local dealer. The length of screws may differ depending

y

on the wall mount. Be sure to use the proper length. For more information, refer to the

y

instructions supplied with the wall mount.

USING THE MONITOR SET

17

USING THE MONITOR SET

Connecting to a PC

Your Monitor set supports Plug & Play*.

y

*Plug & Play: A PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention.

D-SUB connection

Transmits analog video from your PC to the Monitor set. Connect the PC and the Monitor set with the supplied D-sub 15 pin signal cable as shown in the following illustrations.

23MB35PH

24MB35PH

DVI-D connection

Transmits a digital video signal from your PC to the Monitor set. Connect the PC and the Monitor set with a DVI cable as shown in the following illustrations.

23MB35PH

24MB35PH

NOTE

When using a D-Sub signal input cable

y

connector for Macintosh

Mac adapter

y

For Apple Macintosh use, a separate plug adapter is needed to change the 15 pin high density (3 row) D-SUB VGA connector on the supplied cable to a 15 pin 2 row connector.

ENGLISH

ENG

27MB35PH

USING THE MONITOR SET

18

ENGLISH

ENG

HDMI connection

Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the HDMI cable as shown in the following illustrations.

23MB35PH

24MB35PH

27MB35PH

NOTE

When you want to use two PC in our Monitor,

y

please connect the signal cable(D-SUB/ DVI-D/HDMI) respectively in Monitor set. If you turn the Monitor set on while it is cold,

y

the screen may flicker. This is normal. Some red, green, or blue spots may appear

y

on the screen. This is normal.

Connecting to AV Devices

HDMI connection

Transmits the digital video and audio signals from your AV devices to the monitor. Connect your AV device to the monitor with the HDMI cable as illustrated below.

23MB35PH

24MB35PH

NOTE

If you use HDMI PC, it can cause compatibility

y

problem.

CAUTION

Connect the signal

y

input cable and tighten it by turning the screws clockwise. Do not press the screen

y

with your finger for a long time as this may result in temporary distortion on the screen. Avoid displaying a fixed image on the

y

screen for a long period of time to prevent image burn. Use a screensaver if possible.

27MB35PH

NOTE

Using a DVI to HDMI cable may cause com-

y

patibility issues.

USING THE MONITOR SET

19

Connecting to External Devices

Peripheral device connection

Connect peripheral devices to the monitor using headphone ports.

23MB35PH

24MB35PH

27MB35PH

Self Image Setting Function

Press the power button on the bottom panel to turn the power on. When monitor power is turned on, the " automatically. (Only supported in Analog Mode)

Self Image Setting

" Function is executed

NOTE

"Self Image Setting" Function.

y

This function provides the user with optimal display settings.When the user connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual input signals.(Only supported in Analog Mode)

‘AUTO’ Function.

y

When you encounter problems such as blurry screen, blurred letters, screen flicker or tilted screen while using the device or after changing screen resolution, press the AUTO function button to improve resolution. (Only supported in Analog Mode)

ENGLISH

ENG

NOTE

Peripheral devices are sold separately.

y

Cables with angled plugs may have clear-

y

ance issues, use straight plugs when possible.

Angle Type Straight Type

NOTE

Headphones or speakers may not work nor-

y

mally, depending on the server PC settings.

CUSTOMIZING SETTINGS

20

ENGLISH

ENG

CUSTOMIZING SETTINGS

Press the desired button on the bottom of the Monitor set.

1

Change the value of the menu item by pressing the buttons on the bottom of the Monitor set.

2

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Select

3

EXIT

to leave the OSD menu.

Monitor set Buttons

Button Description

Accesses the main menus.(See p.20)

(Power Button)

OSD Locked/OSD Unlocked

Use this button to enter Reader Mode menu. Its function works to display screen as paper-like picture for Eye comfort.If you want to more information(See p.20).

Use this button to enter SMART ENERGY SAVING menu.(See p.20)

When adjusting your display settings, always press the AUTO button on the MONITOR SETUP OSD. (Only supported in Analog Mode)

The best display mode

You can choose the input signal.

• When two input signals are connected, you can select the input signal (D-SUB/DVI/

HDMI) you want.

• When only one signal is connected, it is automatically detected. The default setting is

D-SUB.

EXIT

EXIT the OSD(On Screen Display).

Turns the power on or off.

Power Indicator

This function allow you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. Then OSD of “OSD Lock” will appear. After that, user can select lock or unlock by pressing left/right button. If user selects the “Lock” icon by pressing the “OK” button, the message “OSD Locked” will appear. Otherwise, “OSD Unlocked” will appear. After selecting the “Lock”, If you want to change to Unlock, you can push the “MENU” button for several seconds. The message “OSD Unlocked” will appear.

1920 x 1080

The power indicator stays white if the display is running properly (On Mode). If the display is in Sleep Mode, the power indicator blinks white.

Customizing Settings

CUSTOMIZING SETTINGS

21

Menu Settings

Press

1

Set the options by pressing the ◄ or ► or ▼

2

Select the "

3

Select

4

Each option is explained below.

Brightness ● ● ●

Contrast ● ● ●

Response Time

Wide/Original

Reset

MENU

button on the bottom of the Monitor set

to display the

Menu

OSD.

buttons.

Next Menu

" button to enter the more

option settings.

EXIT

to leave the OSD menu.

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Menu Analog Digital HDMI Description

To adjust the brightness, contrast of the screen.

You can set a response time for displayed pictures based on the speed

● ● ●

of the screen. For a normal environment, it is recommended that you use 'Off'. For a fast-moving picture, it is recommended that you use 'High'.

Wide

Switch to full screen mode according to input image signal.

Original

Change the input image signal ratio to original. * This function works only if input resolution is lower than Monitor set ratio (16:9).

Restore all factory default settings. Press the immediately.

buttons to reset

, ►

◄

ENGLISH

ENG

Menu > Next Menu Analog Digital HDMI Description

Picture Sharpness ● ● ●

Black Level ●

Overscan ●

Color Gamma

Color Temp

Six Color

Color Reset

Display Horizontal

Vertical

Clock

Phase

Audio

Others Language

Analog:

y

Digital:

y

HDMI:

y

Volume ●

Power Indicator

Automatic Standby ● ● ●

D-SUB(Analog signal) input.

DVI-D(Digital signal) input.

HDMI(Digital signal) input.

● ● ●

●

● ● ●

To adjust the clearness of the screen

To set offset level

To improve the clarity and stability of the screen

To customize the color of the screen

To adjust the position of the screen

To improve the clarity and stability of the screen

To adjust the volume

To customize the screen status for a user's operating environment

ENGLISH

ENG

CUSTOMIZING SETTINGS

22


Press

1

MENU

to display the

button on the bottom of the Monitor set

Menu

OSD.

Select the "

2

option settings.

Enter to

3

Set the options by pressing the ◄ or ► or ▼

4

buttons.

Select

5

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Each option is explained below.

Menu > Next Menu > Picture Description

Sharpness

Black Level You can set the offset level. If you select 'High', the screen will be bright and if

Overscan To select the range of output image for DTV timing in HDMI input.(only for HDMI

Next Menu


EXIT

to leave the OSD menu.

" button to enter the more

by pressing the ▼ button.

To adjust the clearness of the screen.

you select ‘Low’, the screen will be dark.(only for HDMI input) * Offset?As the criteria for video signal, it is the darkest screen the monitor can show.

input)Recommend overscan function to turn on when connect AV equipment.

Color

Press

1

to display the

MENU

button on the bottom of the Monitor set

Menu

OSD.

CUSTOMIZING SETTINGS

23

ENGLISH

ENG

Select the "

2

Next Menu

" button to enter the more

option settings.

Select

3

Enter to

4

Set the options by pressing the ◄ or ► or ▼

5

Color

by pressing the ► button.

Color

by pressing the ▼ button.

buttons.

Select

6

EXIT

to leave the OSD menu.

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Each option is explained below.

Menu > Next Menu > Color Description

Gamma

Color Temp Custom

Six Color

Color Reset

Set your own gamma value. : Gamma 0, Gamma 1, Gamma 2 on the monitor, high gamma values display whitish images and low gamma values display blackish images.

• Red:

Set your own red color levels.

• Green:

• Blue:

Select the screen color.

Warm: Medium: Cool:

Sets and stores the hue and saturation for six colors(Red/Green/Blue/Cyan/ Magenta/Yellow) to satisfy the color requirements of a user.

Hue

Saturation

Resets the color settings to the factory default settings for the current input device.

Set your own green color levels.

Set your own blue color levels.

Set the screen to warm color temperature (more red).

Set the screen to medium color temperature.

Set the screen to cool color temperature (more blue).

Adjusts the screen hue.

Adjusts the color sharpness on the screen. Lower values make the color sharpness weaker and colors lighter while higher values make the color sharpness stronger and colors dark.

ENGLISH

ENG

CUSTOMIZING SETTINGS

24

Display

Press

1

MENU

to display the

button on the bottom of the Monitor set

Menu

OSD.

Select the "

2

option settings.

Select

3

Enter to

4

Set the options by pressing the ◄ or ► or ▼

5

buttons.

Select

6

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Each option is explained below.

Menu > Next Menu > Display Description

Horizontal

Vertical

Clock

Phase

Next Menu

Display

EXIT

by pressing the ► button.

Display

to leave the OSD menu.

" button to enter the more

by pressing the ▼ button.

To move image left and right.

To move image up and down.

To minimize any vertical bars or stripes visible on the screen background.The horizontal screen size will also change.

To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters.

Audio

Press

1

Select the "

2

Select

3

Enter to

4

Set the options by pressing the ◄ or ► buttons.

5

Select

6

Each option is explained below.

Volume To adjust the Volume of headphone/earphone.(Only for HDMI input)

MENU

button on the bottom of the Monitor set

to display the

option settings.

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Menu > Next Menu > Audio Description

Menu

OSD.

Next Menu

Audio

by pressing the ► button.

Volume

EXIT

to leave the OSD menu.

" button to enter the more

by pressing the ▼ button.

CUSTOMIZING SETTINGS

25

Others

Press

1

Select the "

2

Select

3

Enter to

4

Set the options by pressing the ◄ or ► or ▼

5

Select

6

Each option is explained below.

Language

Power Indicator

Automatic Standby If you do not press any button on the monitor set for a certain period, the monitor

MENU

button on the bottom of the Monitor set

to display the

option settings.

buttons.

To return to the upper menu or set other menu items, use the up arrow ( ) button.

Menu > Next Menu > Others Description

Menu

OSD.

Next Menu

Others

by pressing the ► button.

Others

EXIT

to leave the OSD menu.

" button to enter the more

by pressing the ▼ button.

To choose the language in which the control names are displayed.

Use this function to set the power indicator on the bottom side of the monitor to On or Off.If you set Off, it will go off. If you set On at any time, the power indicator will automatically be turned on.

set will automatically switch to standby mode.

ENGLISH

ENG

CUSTOMIZING SETTINGS

26

ENGLISH

ENG

SMART ENERGY SAVING

Press

1

Set the options by pressing the ► buttons.

2

Each option is explained below.

SMART ENERGY SAVING Description

High

Low

Off Disables SMART ENERGY SAVING.

SMART ENERGY SAVING:

*

display the

NOTE

button on the bottom of the Monitor set to

SMART ENERGY SAVING

Enables SMART ENERGY SAVING you can save energy with this energy- high efficient function.

Enables SMART ENERGY SAVING you can save energy with this energy- low efficient function.

Conserve energy by using luminance compensation algorithm.

OSD.

Saving Data depends on the Panel. So,those values should be different from each panel and panel

y

vendor.If option of SMART ENERGY SAVING is High or Low, monitor luminance become higher or lower depend on source. If option of SMART ENERGY SAVING is High or Low, Reader Mode will automatically be Reader Off.

y

ENGLISH

ENG

TROUBLESHOOTING

28

ENGLISH

ENG

TROUBLESHOOTING

Check the following before calling for service.

No image appears

Is the power cord of the display connected?

Is the power indicator light on?

Is the power on and the power indicator White?

Is the power indicator flickering?

Do you see an "OUT OF RANGE" message on the screen?

Do you see a "NO SIGNAL" message on the screen?

Do you see a "OSD LOCKED" message on the screen?

Do you see “OSD LOCKED” when you push MENU button?

yCheck and see if the power cord is connected properly to the power

outlet.

yPress the Power button.

yAdjust the brightness and the contrast.

yIf the display is in power saving mode, try moving the mouse or

pressing any key on the keyboard to bring up the screen.

yTry to turn on the PC.

yThis message appears when the signal from the PC (video card) is

out of horizontal or vertical frequency range of the display. See the 'Specifications' section of this manual and configure your display again.

yWhen the monitor is on "No-Signal" in 5 minutes, the monitor goes to

DPM mode.

yYou can secure the current control settings, so that they cannot be

inadvertently changed. You can unlock the OSD controls at any time by pushing the MENU button for several seconds: the message “OSD UNLOCKED” will appear.

Display image is incorrect

Display Position is incorrect.

On the screen background, vertical bars or stripes are visible.

Any horizontal noise appearing in any image or characters are not clearly portrayed.

yPress the

AUTO

button to automatically adjust your display image to

the ideal setting.

yPress the

AUTO

button to automatically adjust your display image to

the ideal setting.

yPress the

AUTO

button to automatically adjust your display image to

the ideal setting.

yCheck

Control Panel ► Display ► Settings

and adjust the display to the recommended resolution or adjust the display image to the ideal setting. Set the color setting higher than 24 bits (true color).

TROUBLESHOOTING

CAUTION

Control Panel ► Display ► Settings

Check

y

changed. If yes, readjust the video card to the recommend resolution. If the recommended resolution (optimal resolution) is not selected, letters may be blurred and the

y

screen may be dimmed, truncated or biased. Make sure to select the recommend resolution. The setting method can differ by computer and O/S (Operation System), and resolution mentioned

y

above may not be supported by the video card performance. In this case, please ask to the computer or the video card manufacturer.

Display image is incorrect

The screen color is mono or abnormal.

The screen blinks.

yCheck if the signal cable is properly connected and use a screwdriver

to fasten if necessary. yMake sure the video card is properly inserted in the slot. ySet the color setting higher than 24 bits (true color) at

► Settings

yCheck if the screen is set to interlace mode and if yes, change it to the

recommend resolution.

and see if the frequency or the resolution were

Control Panel

.

29

ENGLISH

ENG

Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message?

Have you installed the display driver?

The screen is flickering.

Did you select the recommended resolution?

yBe sure to install the display driver from our web site:

lg.com

.

yMake sure to check if the video card supports Plug&Play function.

yIf the selected resolution is HDMI

be flickering. Change the resolution to the recommended resolution

1080P

.

1080i

60/50 Hz, the screen may

http://www.

SPECIFICATIONS

30

ENGLISH

ENG

SPECIFICATIONS

23MB35PH

Display Screen Type

Pixel Pitch

Sync Input Horizontal Frequency

Vertical Frequency

Input Form

Video Input Signal Input

Input Form

Resolution Max

Recommend

Plug & Play

Power Consumption

Power Input

Dimensions (Width x Height x Depth)

Weight

Environmental conditions

DDC 2B(Analog,Digital,HDMI)

On Mode : 16.0 W Typ. (ENERGY STAR® standard ) *

19.9 W Typ. ( Outgoing condition ) **

Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W

AC 100-240 V~ 50/60 Hz 1.0 A

With Stand

Without Stand

4.8 kg

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

Flat Panel Active matrix-TFT LCD Anti-Glare coating

0.2652 mm x 0.2652 mm

30 kHz to 83 kHz (Automatic)

56Hz to 75Hz (D-SUB,DVI-D) 56Hz to 61Hz (HDMI)

Separate Sync. Digital

15 pin D-SUB Connector/DVI-D Connector(Digital) HDMI Connector

RGB Analog (0.7 Vp-p/ 75 ohm), Digital

D-SUB(Analog) : 1920 x 1080 @ 60 Hz DVI/HDMI (Digital) : 1920 x 1080 @ 60 Hz

VESA 1920 x 1080 @ 60 Hz

54.8 cm x 36.7 cm x 24.6 cm

54.8 cm x 33.5 cm x 16.6 cm

10°C to 35 °C 10 % to 80 %

-20°C to 60 °C 5 % to 90 % non-Condensing

Product specifications shown above may be changed without prior notice due to upgrade of product functions. * The power consumption level can be different by operating condition and monitor setting. * The On mode power consumption is measured with ENERGY STAR® test standard. ** The On mode power consumption is measured with LGE test standard (Full White pattern , Maximum

resolution)

SPECIFICATIONS

31

SPECIFICATIONS

24MB35PH

Display Screen Type Flat Panel Active matrix-TFT LCD

Anti-Glare coating

Pixel Pitch 0.275 mm x 0.275 mm

Sync Input Horizontal Frequency 30 kHz to 83 kHz (Automatic)

Vertical Frequency 56Hz to 75Hz (D-SUB,DVI-D)

Input Form Separate Sync. Digital

Video Input Signal Input 15 pin D-SUB Connector/DVI-D Connector(Digital)

Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital

Resolution Max D-SUB(Analog) : 1920 x 1080 @ 60 Hz

Recommend VESA 1920 x 1080 @ 60 Hz

Plug & Play DDC 2B(Analog,Digital,HDMI)

Power Consumption

Power Input AC 100-240 V~ 50/60 Hz 1.2 A

Dimensions (Width x Height x Depth)

Weight 5.0 kg

Environmental conditions

On Mode : 17.1 W Typ. (ENERGY STAR® standard ) *

24.3 W Typ. ( Outgoing condition ) **

Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W

With Stand 56.9 cm x 43.3 cm x 27.1 cm

Without Stand 56.9 cm x 34.2 cm x 6.3 cm

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

56Hz to 61Hz (HDMI)

HDMI Connector

DVI/HDMI (Digital) : 1920 x 1080 @ 60 Hz

10°C to 35 °C 10 % to 80 %

-20°C to 60 °C 5 % to 90 % non-Condensing

ENGLISH

ENG

Product specifications shown above may be changed without prior notice due to upgrade of product functions. * The power consumption level can be different by operating condition and monitor setting. * The On mode power consumption is measured with ENERGY STAR® test standard. ** The On mode power consumption is measured with LGE test standard (Full White pattern , Maximum

resolution)

SPECIFICATIONS

32

ENGLISH

ENG

SPECIFICATIONS

27MB35PH

Display Screen Type Flat Panel Active matrix-TFT LCD

Anti-Glare coating

Pixel Pitch 0.3114 mm x 0.3114 mm

Sync Input Horizontal Frequency 30 kHz to 83 kHz (Automatic)

Vertical Frequency 56Hz to 75Hz (D-SUB,DVI-D)

Input Form Separate Sync. Digital

Video Input Signal Input 15 pin D-SUB Connector/DVI-D Connector(Digital)

Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital

Resolution Max D-SUB(Analog) : 1920 x 1080 @ 60 Hz

Recommend VESA 1920 x 1080 @ 60 Hz

Plug & Play DDC 2B(Analog,Digital,HDMI)

Power Consumption

Power Input AC 100-240 V~ 50/60 Hz 1.5 A

Dimensions (Width x Height x Depth)

Weight 6.5 kg

Environmental conditions

On Mode : 20.3 W Typ. (ENERGY STAR® standard ) *

29.4 W Typ. ( Outgoing condition ) **

Sleep Mode ≤ 0.3 W Off Mode ≤ 0.3 W

With Stand 64.4 cm x 41.0 cm x 25.9 cm

Without Stand 64.4 cm x 38.7 cm x 6.4 cm

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

56Hz to 61Hz (HDMI)

HDMI Connector

DVI/HDMI (Digital) : 1920 x 1080 @ 60 Hz

10°C to 35 °C 10 % to 80 %

-20°C to 60 °C 5 % to 90 % non-Condensing

Product specifications shown above may be changed without prior notice due to upgrade of product functions. * The power consumption level can be different by operating condition and monitor setting. * The On mode power consumption is measured with ENERGY STAR® test standard. ** The On mode power consumption is measured with LGE test standard (Full White pattern , Maximum

resolution)

SPECIFICATIONS

Preset Modes (Resolution)

Display Modes (Resolution)

720 x 400 31.468 70 -/+

640 x 480 31.469 60 -/-

640 x 480 37.500 75 -/-

800 x 600 37.879 60 +/+

800 x 600 46.875 75 +/+

1024 x 768 48.363 60 -/-

1024 x 768 60.023 75 +/+

1152 x 864 67.500 75 +/+

1280 x 1024 63.981 60 +/+

1280 x 1024 79.976 75 +/+

1680 x 1050 65.290 60 -/+

1920 x 1080 67.500 60 +/+ Recommend Mode

Horizontal Frequency(kHz)

Vertical Frequency(Hz)

Polarity(H/V)

33

ENGLISH

ENG

HDMI Timing

Factory support mode (Preset Mode)

480P 31.50 60 O

576P 31.25 50 O

720P 37.50 50 O

720P 45.00 60 O

1080i 28.12 50 O

1080i 33.75 60 O

1080P 56.25 50 O

1080P 67.50 60

Horizontal Frequency(kHz)

Vertical Frequency(Hz)

Recommend Mode

Indicator

Mode LED Color

On Mode

Sleep Mode

Off Mode Off

White

Blinking White

HDMI

O

Make sure to read the Safety Precautions before using the product. The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service.

MODEL

SERIAL

ENERGY STAR is a set of power-saving guidelines issued by the U.S.Environmental Protection Agency(EPA).

As an ENERGY STAR Partner LGE U. S. A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efﬁciency.

LG 27MB35PH-B, 23MB35PH-B User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

OWNER’S MANUAL

CONTENTS

LICENSE

ASSEMBLING AND PREPARING

Unpacking

Parts and buttons

Moving and Lifting the Monitor

Setting up the Monitor set

Attaching the Stand Base

Detaching the stand base

Detaching the stand body

Using the cable holder

Mounting on a table

Adjusting the angle

Adjusting the stand height

Using the Kensington locking device

Swivel stand

Using the Pivot function

Swivel stand

Using the Pivot function

Mounting on a wall

USING THE MONITOR SET

Connecting to a PC

D-SUB connection

DVI-D connection

HDMI connection

Connecting to AV Devices

HDMI connection

Connecting to External Devices

Peripheral device connection

CUSTOMIZING SETTINGS

Customizing Settings

Menu Settings


Color

Display

Audio

Others

READER Setting

SMART ENERGY SAVING

TROUBLESHOOTING

SPECIFICATIONS

23MB35PH

24MB35PH

27MB35PH

Preset Modes (Resolution)

Indicator
