Lexmark M1100, M3100 User Manual

Download

M1100 and M3100 Series

User's Guide

Important: Click here before using this guide.

June 2017 www.lexmark.com

Machine type(s):

4514

Model(s):

639, 649

Contents 2

Safety information........................................................................................ 6

Conventions.......................................................................................................................................................... 6

Overview........................................................................................................ 8

Using this guide....................................................................................................................................................8

Finding information about the printer.............................................................................................................8

Selecting a location for the printer........................................................... 10

Additional printer setup..............................................................................12

Installing internal options................................................................................................................................. 12

Available internal options........................................................................................................................................... 12

Accessing the controller board ................................................................................................................................12

Installing an optional card..........................................................................................................................................12

Installing a memory card ............................................................................................................................................14

Installing an Internal Solutions Port.........................................................................................................................16

Installing a printer hard disk ..................................................................................................................................... 23

Removing a printer hard disk...................................................................................................................................25

Installing hardware options............................................................................................................................ 26

Installing optional trays ..............................................................................................................................................26

Setting up the printer software......................................................................................................................28

Installing the printer software...................................................................................................................................28

Adding available options in the print driver ......................................................................................................... 28

Networking..........................................................................................................................................................29

Preparing to set up the printer on a wireless network......................................................................................29

Connecting the printer using the Wireless Setup Wizard ................................................................................30

Connecting the printer to a wireless network using Wi‑Fi Protected Setup ...............................................30

Connecting the printer to a wireless network using the Embedded Web Server ...................................... 31

Verifying printer setup................................................................................................................................................32

Using M1145................................................................................................ 33

Learning about the printer.............................................................................................................................. 33

Printer conﬁgurations................................................................................................................................................. 33

Using the printer control panel................................................................................................................................ 34

Understanding the colors of the Sleep button and indicator lights...............................................................35

Attaching cables .......................................................................................................................................................... 35

Accessing the controller board ................................................................................................................................37

Loading paper and specialty media.............................................................................................................38

Setting the paper size and type .............................................................................................................................. 38

Contents 3

Conﬁguring Universal paper settings .................................................................................................................... 38

Using the standard bin and paper stop................................................................................................................. 38

Loading trays................................................................................................................................................................ 39

Loading the multipurpose feeder............................................................................................................................ 43

Linking and unlinking trays........................................................................................................................................47

Printing.................................................................................................................................................................49

Printing a document....................................................................................................................................................49

Printing from a mobile device ..................................................................................................................................50

Printing from a ﬂash drive ..........................................................................................................................................51

Printing conﬁdential and other held jobs.............................................................................................................. 53

Printing information pages........................................................................................................................................ 54

Canceling a print job .................................................................................................................................................. 54

Managing the printer........................................................................................................................................55

Checking the virtual display .....................................................................................................................................55

Conﬁguring supply notiﬁcations from the Embedded Web Server ...............................................................55

Modifying conﬁdential print settings......................................................................................................................56

Copying printer settings to other printers.............................................................................................................56

Creating a printer control panel PIN....................................................................................................................... 57

Printing a menu settings page................................................................................................................................. 57

Printing a network setup page.................................................................................................................................58

Checking the status of parts and supplies ...........................................................................................................58

Saving energy ..............................................................................................................................................................58

Restoring factory default settings............................................................................................................................ 61

Securing the printer....................................................................................................................................................62

Using M3150............................................................................................... 64

Learning about the printer..............................................................................................................................64

Printer conﬁgurations................................................................................................................................................. 64

Using the printer control panel................................................................................................................................65

Understanding the colors of the Sleep button and indicator lights...............................................................65

Understanding the home screen ............................................................................................................................66

Using the touch-screen buttons .............................................................................................................................. 67

Attaching cables ..........................................................................................................................................................68

Accessing the controller board ............................................................................................................................... 70

Setting up and using the home screen applications................................................................................72

Finding the IP address of the computer................................................................................................................ 72

Finding the IP address of the printer...................................................................................................................... 72

Accessing the Embedded Web Server.................................................................................................................. 72

Customizing the home screen..................................................................................................................................73

Activating the home screen applications...............................................................................................................73

Setting up Remote Operator Panel ........................................................................................................................ 75

Exporting and importing a conﬁguration............................................................................................................... 75

Loading paper and specialty media............................................................................................................. 76

Contents 4

Setting the paper size and type .............................................................................................................................. 76

Conﬁguring Universal paper settings .................................................................................................................... 76

Using the standard bin and paper stop................................................................................................................. 76

Loading trays.................................................................................................................................................................77

Loading the multipurpose feeder.............................................................................................................................81

Linking and unlinking trays.......................................................................................................................................85

Printing................................................................................................................................................................. 87

Printing forms ............................................................................................................................................................... 87

Printing a document.................................................................................................................................................... 87

Printing from a mobile device .................................................................................................................................. 88

Printing from a ﬂash drive ......................................................................................................................................... 89

Printing conﬁdential and other held jobs..............................................................................................................90

Printing information pages........................................................................................................................................92

Canceling a print job ..................................................................................................................................................92

Managing the printer........................................................................................................................................92

Setting up serial printing (Windows only)..............................................................................................................92

Changing port settings after installing an internal solutions port................................................................... 93

Checking the virtual display ..................................................................................................................................... 93

Conﬁguring supply notiﬁcations from the Embedded Web Server ...............................................................94

Modifying conﬁdential print settings...................................................................................................................... 94

Copying printer settings to other printers.............................................................................................................95

Creating a printer control panel PIN.......................................................................................................................95

Printing a menu settings page.................................................................................................................................96

Printing a network setup page.................................................................................................................................96

Checking the status of parts and supplies ...........................................................................................................96

Saving energy .............................................................................................................................................................. 97

Restoring factory default settings......................................................................................................................... 100

Securing the printer....................................................................................................................................................101

Paper and specialty media guide........................................................... 105

Using specialty media.................................................................................................................................... 105

Paper guidelines.............................................................................................................................................. 107

Supported paper sizes, types, and weights.............................................................................................. 110

Understanding the printer menus........................................................... 113

Menus list............................................................................................................................................................ 113

Paper menu........................................................................................................................................................ 114

Reports menu....................................................................................................................................................122

Network/Ports menu.......................................................................................................................................123

Security menu................................................................................................................................................... 134

Settings menu...................................................................................................................................................138

Help menu......................................................................................................................................................... 159

Contents 5

Saving money and the environment...................................................... 160

Saving paper and toner................................................................................................................................. 160

Recycling............................................................................................................................................................160

Maintaining the printer............................................................................ 162

Cleaning the printer........................................................................................................................................ 162

Ordering supplies............................................................................................................................................ 162

Estimated number of remaining pages......................................................................................................163

Storing supplies................................................................................................................................................164

Replacing supplies...........................................................................................................................................164

Moving the printer........................................................................................................................................... 168

Clearing jams.............................................................................................170

Avoiding jams....................................................................................................................................................170

Identifying jam locations..................................................................................................................................171

Paper jam in the front door............................................................................................................................172

Paper jam in the rear door.............................................................................................................................174

Paper jam in the standard bin.......................................................................................................................175

Paper jam in the duplex unit......................................................................................................................... 176

Paper jam in trays.............................................................................................................................................177

Paper jam in the multipurpose feeder........................................................................................................ 177

Troubleshooting........................................................................................ 179

Understanding the printer messages.........................................................................................................179

Solving printer problems................................................................................................................................192

Solving print problems................................................................................................................................... 199

Solving home screen application problems............................................................................................225

Embedded Web Server does not open....................................................................................................225

Contacting customer support......................................................................................................................227

Notices.......................................................................................................228

Product information........................................................................................................................................228

Edition notice................................................................................................................................................... 228

Power consumption........................................................................................................................................233

Index...........................................................................................................239

Safety information 6

Safety information

Conventions

Note: A note identiﬁes information that could help you.

Warning: A warning identiﬁes something that could damage the product hardware or software.

CAUTION: A caution indicates a potentially hazardous situation that could injure you.

Dierent types of caution statements include:

CAUTION—POTENTIAL INJURY: Indicates a risk of injury.

CAUTION—SHOCK HAZARD: Indicates a risk of electrical shock.

CAUTION—HOT SURFACE: Indicates a risk of burn if touched.

CAUTION—TIPPING HAZARD: Indicates a crush hazard.

CAUTION—PINCH HAZARD: Indicates a risk of being caught between moving parts.

CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to

an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.

CAUTION—POTENTIAL INJURY: Do not use this product with extension cords, multioutlet power strips, multioutlet extenders, or UPS devices. The power capacity of these types of accessories can be easily overloaded by a laser printer and may result in a risk of ﬁre, property damage, or poor printer performance.

CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not place or use this product near water or wet locations.

CAUTION—POTENTIAL INJURY: This product uses a laser. Use of controls or adjustments or performance of procedures other than those speciﬁed in the User’s Guide may result in hazardous radiation exposure.

This product uses a printing process that heats the print media, and the heat may cause the media to release emissions. You must understand the section in your operating instructions that discusses the guidelines for selecting print media to avoid the possibility of harmful emissions.

CAUTION—POTENTIAL INJURY: The lithium battery in this product is not intended to be replaced. There is a danger of explosion if a lithium battery is incorrectly replaced. Do not recharge, disassemble, or incinerate a lithium battery. Discard used lithium batteries according to the manufacturer's instructions and local regulations.

This equipment is not suitable for use in locations where children are likely to be present.

CAUTION—POTENTIAL INJURY: Before moving the printer, follow these guidelines to avoid personal injury or printer damage:

• Turn the printer o using the power switch, and then unplug the power cord from the electrical outlet.

• Disconnect all cords and cables from the printer before moving it.

Safety information 7

• If an optional tray is installed, then remove it from the printer. To remove the optional tray, slide the latch on

the right side of the tray toward the front of the tray until it clicks into place.

• Use the handholds located on both sides of the printer to lift it.

• Make sure your ﬁngers are not under the printer when you set it down.

• Before setting up the printer, make sure there is adequate clearance around it.

Use only the power cord provided with this product or the manufacturer's authorized replacement.

CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer o, and unplug the power cord from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn them o as well, and unplug any cables going into the printer.

CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, make sure that all external connections (such as Ethernet and telephone system connections) are properly installed in their marked plug-in ports.

This product is designed, tested, and approved to meet strict global safety standards with the use of speciﬁc manufacturer's components. The safety features of some parts may not always be obvious. The manufacturer is not responsible for the use of other replacement parts.

CAUTION—POTENTIAL INJURY: Do not cut, twist, bind, crush, or place heavy objects on the power cord. Do not subject the power cord to abrasion or stress. Do not pinch the power cord between objects such as furniture and walls. If any of these things happen, a risk of ﬁre or electrical shock results. Inspect the power cord regularly for signs of such problems. Remove the power cord from the electrical outlet before inspecting it.

Refer service or repairs, other than those described in the user documentation, to a service representative.

CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock when cleaning the exterior of the printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before proceeding.

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed.

CAUTION—SHOCK HAZARD: Do not set up this product or make any electrical or cabling connections, such as the fax feature, power cord, or telephone, during a lightning storm.

SAVE THESE INSTRUCTIONS.

Overview 8

Overview

Using this guide

This User’s Guide provides general and speciﬁc information on using the printer models that are listed on the cover page.

The following chapters contain information applicable to all printer models:

• Safety information

• Selecting a location for the printer

• Additional printer setup

• Paper and specialty media guide

• Understanding printer menus

• Saving money and the environment

• Maintaining the printer

• Clearing jams

• Trou blesho oting

To ﬁnd instructions for your printer:

• Use the table of contents.

• Use the Search function or the Find toolbar of your application to search for page content.

Finding information about the printer

What are you looking for? Find it here

Initial setup instructions:

• Connecting the printer

• Installing the printer software

Additional setup and instructions for using the printer:

• Selecting and storing paper and specialty media

• Loading paper

•

Conﬁguring

• Viewing and printing documents and photos

• Setting up and using the printer software

• Conﬁguring the printer on a network

• Caring for and maintaining the printer

• Troubleshooting and solving problems

printer settings

Setup documentation—The setup documentation came with the printer and is also available at

http://support.lexmark.com.

User's Guide and Quick Reference Guide—The guides are available on the Documentation CD.

Note: These guides are also available in other languages.

Information on setting up and conﬁguring the accessibility features of your printer.

Lexmark Accessibility Guide—This guide is available

http://support.lexmark.com.

Overview 9

What are you looking for? Find it here

Help using the printer software Windows or Mac Help—Open a printer software

program or application, and then click Help.

Click

Notes:

to view context‑sensitive information.

• Help is automatically installed with the printer

software.

• The printer software is located in the printer

program folder or on the desktop, depending on your operating system.

The latest supplemental information, updates, and customer support:

• Documentation

• Driver downloads

• Live chat support

• E‑mail support

• Voice support

Lexmark support Web site—

http://support.lexmark.com

Note: Select your country or region, and then select

your product to view the appropriate support site. Support telephone numbers and hours of operation

for your country or region can be found on the support Web site or on the printed warranty that came with your printer.

Record the following information (located on the store receipt and at the back of the printer), and have it ready when you contact customer support so that they may serve you faster:

• Machine Type number

• Serial number

• Date purchased

• Store where purchased

Warranty information Warranty information varies by country or region:

• In the U.S.—See the Statement of Limited

Warranty included with this printer, or go to

http://support.lexmark.com.

• In other countries and regions—See the printed

warranty that came with this printer.

Selecting a location for the printer 10

Selecting a location for the printer

When selecting a location for the printer, leave enough room to open trays, covers, and doors. If you plan to install any options, then leave enough room for them also. It is important to:

• Set up the printer near a properly grounded and easily accessible electrical outlet.

• Make sure airﬂow in the room meets the latest revision of the ASHRAE 62 standard or the CEN Technical

Committee 156 standard.

• Provide a ﬂat, sturdy, and stable surface.

• Keep the printer: – Clean, dry, and free of dust. – Away from stray staples and paper clips. – Away from the direct airﬂow of air conditioners, heaters, or ventilators. – Free from direct sunlight and humidity extremes.

• Observe the recommended temperatures and avoid

Ambient temperature 15.6 to 32.2°C (60 to 90°F)

ﬂuctuations.

Storage temperature 1 to 35°C (34 to 95°F)

1 Right side 110 mm (4.33 in.)

2 Front 305 mm (12 in.)

3 Left side 65 mm (2.56 in.)

4 Rear 100 mm (3.94 in.)

5 Top 305 m m ( 1 2 i n .)

Selecting a location for the printer 11

1 Right side 110 mm (4.33 in.)

2 Front 305 mm (12 in.)

3 Left side 65 mm (2.56 in.)

4 Rear 100 mm (3.94 in.)

5 Top 305 m m ( 1 2 i n .)

Additional printer setup 12

Additional printer setup

Installing internal options

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

or memory devices sometime after setting up the printer, then turn the printer o, and unplug the power cord from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn them o as well, and unplug any cables going into the printer.

Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board electronic components or connectors.

Available internal options

• DDR3 DIMM

• Flash memory – Fonts – Firmware

• Forms Barcode

• Prescribe

• IPDS

• Printcryption

• Hard disk

• Internal Solutions Ports (ISP) – Parallel 1284‑B interface – MarkNet N8130 10/100 ﬁber interface – RS‑232‑C serial interface

This internal option is available only in the M3150de printer model.

Accessing the controller board

Access the controller board to install internal options.

For M1145, see For M3150, see

“Accessing the controller board” on page 37.

“Accessing the controller board” on page 70.

Installing an optional card

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

or memory devices sometime after setting up the printer, then turn the printer cord from the electrical outlet before continuing. If you have other devices attached to the printer, then turn them o as well, and unplug any cables going into the printer.

and unplug the power

o,

Additional printer setup 13

1 Access the controller board.

For the M1145 printer models, see For the M3150de printer model, see

“Accessing the controller board” on page 37.

“Accessing the controller board” on page 70.

2 Unpack the optional card.

Warning—Potential Damage: Avoid touching the connection points along the edge of the card.

3 Holding the card by its sides, align the plastic pins (1) on the card with the holes (2) on the controller board.

Additional printer setup 14

4 Push the card ﬁrmly into place as shown in the illustration.

Warning—Potential Damage: Improper installation of the card may cause damage to the card and the

controller board.

Note: The entire length of the connector on the card must touch and be board.

ﬂushed

against the controller

5 For the M1145 printer models, close the controller board access door.

For the M3150de printer model, close the controller board shield, and then close the access door.

Note: When the printer software and any hardware options are installed, you may need to manually add the options in the printer driver to make them available for print jobs. For more information, see

available options in the print driver” on page 28.

“A dd in g

Installing a memory card

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

Additional printer setup 15

An optional memory card can be purchased separately and attached to the controller board.

1 Access the controller board.

For the M1145 printer models, see For the M3150de printer model, see

“Accessing the controller board” on page 37.

“Accessing the controller board” on page 70.

2 Unpack the memory card.

Warning—Potential Damage: Do not touch the connection points along the edge of the card. Doing so

may cause damage.

3 Align the notch (1) on the memory card with the ridge (2) on the connector.

Additional printer setup 16

4 Push the memory card straight into the connector and forward into the controller board wall until it clicks

into place.

5 For the M1145 printer models, close the controller board access door.

For the M3150de printer model, close the controller board shield, and then close the access door.

Note: When the printer software and any hardware options are installed, you may need to manually add the options in the printer driver to make them available for print jobs. For more information, see

available options in the print driver” on page 28.

“A dd in g

Installing an Internal Solutions Port

The controller board supports one optional LexmarkTM Internal Solutions Port (ISP). This option is supported only in the M3150de printer model.

Note: This task requires a

‑head screwdriver.

ﬂat

Additional printer setup 17

1 Open the controller board access door.

2 Lightly press the stop on the left side of the access door, and then slide the access door to remove.

3 Unpack the ISP kit.

Note: Make sure to remove and discard the small cable attached to the white connector.

Additional printer setup 18

1 ISP solution

2 Screw to attach the ISP solution to the plastic bracket

3 ISP exterior cover

4 Screws to attach the ISP solution to the ISP exterior cover

5 Plastic bracket

6 Long ISP cable

4 Place the plastic bracket inside the ISP exterior cover until it clicks into place.

5 Slide and push the ISP solution into the plastic bracket.

Additional printer setup 19

6 Secure the ISP solution to the plastic bracket using the long screw.

7 Tighten the two screws on the end of the ISP solution.

Additional printer setup 20

8 Attach the white plug of the ISP solution interface cable into the white receptacle on the ISP.

9 Slightly close the ISP exterior cover up to 65 degrees, and then slide the cover to attach.

Additional printer setup 21

10 Run the ISP cable through the controller board shield door.

11 Open the shield using the green handle.

12 Attach the blue plug of the ISP solution interface cable into the blue receptacle on the controller board.

Note: If you have installed a printer hard disk, then you need to remove it. For more information, see

“Removing a printer hard disk” on page 25. To reinstall the printer hard disk, see “Installing a printer hard disk” on page 23.

Additional printer setup 22

13 Close the shield.

14 Close the ISP exterior cover.

Note: When the printer software and any hardware options are installed, you may need to manually add

the options in the printer driver to make them available for print jobs. For more information, see

available options in the print driver” on page 28.

“Adding

Additional printer setup 23

Installing a printer hard disk

Note: This option is available only in the M3150de printer model.

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

or memory devices sometime after setting up the printer, then turn the printer cord from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn them o as well, and unplug any cables going into the printer.

1 Access the controller board.

For more information, see

“Accessing the controller board” on page 70

and unplug the power

o,

Note: This task requires a

‑head screwdriver.

ﬂat

2 Unpack the printer hard disk.

3 Install the printer hard disk on the controller board:

Warning—Potential Damage: Hold only the edges of the printed circuit board assembly. Do not touch or

press on the center of the printer hard disk. Doing so may cause damage.

a Using a ﬂat‑head screwdriver, loosen the screws.

Additional printer setup 24

b Align the screws on the printer hard disk to the slots on the controller board bracket, and then slide the

printer hard disk onto the brackets.

c Tighten the two screws.

d Insert the plug of the printer hard disk interface cable into the receptacle of the controller board.

Note: The plug and the receptacle are color‑coded blue.

Additional printer setup 25

4 Close the controller board shield, and then close the access door.

Note: When the printer software and any hardware options are installed, you may need to manually add

the options in the printer driver to make them available for print jobs. For more information, see

available options in the print driver” on page 28.

“Adding

Removing a printer hard disk

Note: This option is supported only in the M3150de printer model.

Warning—Potential Damage: Controller board electronic components are easily damaged by static

electricity. Touch a metal surface on the printer before touching any controller board electronic components or connectors.

1 Access the controller board.

For more information, see “Accessing the controller board” on page 70.

Note: This task requires a ﬂat‑head screwdriver.

2 Loosen the screws that connect the printer hard disk to the controller board bracket.

Additional printer setup 26

3 Unplug the printer hard disk interface cable from the receptacle in the controller board, leaving the cable

attached to the printer hard disk. To unplug the cable, squeeze the paddle at the plug of the interface cable to disengage the latch before pulling the cable out.

4 Hold the printer hard disk by the edges, and then remove it from the printer.

5 Close the controller board shield, and then close the access door.

Installing hardware options

Installing optional trays

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

1 Turn o the printer using the power switch, and then unplug the power cord from the electrical outlet.

and unplug the power

o,

2 Unpack the tray, and then remove all packing materials.

Additional printer setup 27

3 Pull the tray completely out of the base.

4 Remove any packing material from inside the tray.

5 Insert the tray into the base.

6 Place the tray near the printer.

7 Align the printer with the tray, and then lower the printer into place.

Note: Optional trays lock together when stacked.

8 Connect the power cord to the printer, then to a properly grounded electrical outlet, and then turn on the

printer.

Additional printer setup 28

Note: When the printer software and any hardware options are installed, you may need to manually add the options in the printer driver to make them available for print jobs. For more information, see

available options in the print driver” on page 28.

To uninstall the optional trays, slide the latch on the right side of the printer toward the front of the printer until it clicks into place, and then remove stacked trays one at a time from the top to the bottom.

“Adding

Setting up the printer software

Installing the printer software

1 Obtain a copy of the software installer package.

• From the software CD that came with your printer.

• Go to http://support.lexmark.com, and then select your printer and operating system.

2 Run the installer, and then follow the instructions on the computer screen.

3 For Macintosh users, add the printer.

Note: Obtain the printer IP address from the TCP/IP section in the Network/Ports menu.

Adding available options in the print driver

For Windows users

1 Open the printers folder.

2 Select the printer you want to update, and then do the following:

• For Windows 7 or later, select Printer properties.

• For earlier versions, select Properties.

3 Navigate to the Conﬁguration tab, and then select Update Now ‑ Ask Printer.

4 Apply the changes.

For Macintosh users

1 From System Preferences in the Apple menu, navigate to your printer, and then select Options & Supplies.

2 Navigate to the list of hardware options, and then add any installed options.

Additional printer setup 29

3 Apply the changes.

Networking

Notes:

• Purchase a MarkNet

network. For information on installing the wireless network adapter, see the instruction sheet that came with the adapter.

• A Service Set

Wi-Fi Protected Access (WPA), WPA2, and 802.1X - RADIUS are types of security used on a network.

Preparing to set up the printer on a wireless network

Notes:

• Make sure your wireless network adapter is installed in your printer and working properly. For more

information, see the instruction sheet that came with the wireless network adapter.

• Make sure your access point (wireless router) is turned on and is working properly.

Identiﬁer

N8352 wireless network adapter before setting up the printer on a wireless

(SSID) is a name assigned to a wireless network. Wired Equivalent Privacy (WEP),

Make sure you have the following information before setting up the printer on a wireless network:

• SSID—The SSID is also referred to as the network name.

• Wireless Mode (or Network Mode)—The mode is either infrastructure or ad hoc.

• Channel (for ad hoc networks)—The channel defaults to automatic for infrastructure networks.

Some ad hoc networks will also require the automatic setting. Check with your system support person if you are not sure which channel to select.

• Security Method—There are four basic options for Security Method: – WEP key

If your network uses more than one WEP key, then enter up to four in the provided spaces. Select the key currently in use on the network by selecting the default WEP transmit key.

– WPA or WPA2 preshared key or passphrase

WPA includes encryption as an additional layer of security. The choices are AES or TKIP. Encryption must be set for the same type on the router and on the printer, or the printer will not be able to communicate on the network.

– 802.1X–RADIUS

If you are installing the printer on an 802.1X network, then you may need the following:

• Authentication type

• Inner authentication type

• 802.1X user name and password

•

Certiﬁcates

– No security

If your wireless network does not use any type of security, then you will not have any security information.

Note: We do not recommend using an unsecured wireless network.

Additional printer setup 30

Notes:

– If you do not know the SSID of the network that your computer is connected to, then launch the wireless

utility of the computer network adapter, and then look for the network name. If you cannot ﬁnd the SSID or the security information for your network, then see the documentation that came with the access point, or contact your system support person.

– To ﬁnd the WPA/WPA2 preshared key or passphrase for the wireless network, see the documentation

that came with the access point, see the Embedded Web Server associated with the access point, or consult your system support person.

Connecting the printer using the Wireless Setup Wizard

Before you begin, make sure that:

• A wireless network adapter is installed in the printer and is working properly. For more information, see the

instruction sheet that came with the wireless network adapter.

• The Ethernet cable is disconnected from the printer.

• Active NIC is set to Auto. To set this to Auto, navigate to either of the following:

– > Settings > > Network/Ports > > Active NIC > > Auto >

– > Network/Ports > Active NIC > Auto

Note: Make sure to turn o the printer, then wait for at least ﬁve seconds, and then turn the printer back on.

1 Depending on your printer model, navigate to either of the following:

• > Settings > > Network/Ports > > Network [x] > > Network [x] Setup > > Wireless

> Wireless Connection Setup >

• > Network/Ports > Network [x] > Network [x] Setup > Wireless > Wireless Connection Setup

2 Select a wireless connection setup.

Use To

Search for networks Show available wireless connections.

Note: This menu item shows all broadcast secured or unsecured SSIDs.

Enter a network name Manually type the SSID.

Note: Make sure to type the correct SSID.

Wi‑Fi Protected Setup Connect the printer to a wireless network using Wi‑Fi Protected Setup.

3 Follow the instructions on the printer display.

Connecting the printer to a wireless network using Wi‑Fi Protected Setup

Before connecting the printer to a wireless network, make sure that:

• The access point (wireless router) is Wi‑Fi Protected Setup (WPS) certiﬁed or WPS‑compatible. For more

information, see the documentation that came with your access point.

• A wireless network adapter is installed in your printer and is working properly. For more information, see

the instruction sheet that came with the wireless network adapter.

Additional printer setup 31

Using the Push Button Conﬁguration Method

Depending on your printer model, navigate to either of the following:

• > Settings > > Networks/Ports > > Network [x] > > Network [x] Setup > >

Wireless >

Button Method >

> Wireless Connection Setup > > Wi‑Fi Protected Setup > > Start Push

• > Network/Ports > Network [x] > Network [x] Setup > Wireless > Wireless Connection Setup

> Wi‑Fi Protected Setup > Start Push Button Method

2 Follow the instructions on the printer display.

Using the Personal Identiﬁcation Number (PIN) Method

Depending on your printer model, navigate to either of the following:

• > Settings > > Networks/Ports > > Network [x] > > Network [x] Setup > >

Wireless >

Method >

> Wireless Connection Setup > > Wi‑Fi Protected Setup > > Start PIN

• > Network/Ports > Network [x] > Network [x] Setup > Wireless > Wireless Connection Setup

> Wi‑Fi Protected Setup > Start PIN Method

2 Copy the eight‑digit WPS PIN.

3 Open a Web browser, and then type the IP address of your access point in the address ﬁeld.

Notes:

• The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are accessing a proxy server, then temporarily disable it to load the Web page correctly.

4 Access the WPS settings. For more information, see the documentation that came with your access

point.

5 Enter the eight‑digit PIN, and then save the setting.

Connecting the printer to a wireless network using the Embedded Web Server

Before you begin, make sure that:

• Your printer is connected temporarily to an Ethernet network.

• A wireless network adapter is installed in your printer and working properly. For more information, see the

instruction sheet that came with the wireless network adapter.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer control panel. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

Additional printer setup 32

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Network/Ports > Wireless.

3 Modify the settings to match the settings of your access point (wireless router).

Note: Make sure to enter the correct SSID, security method, preshared key or passphrase, network

mode, and channel.

4 Click Submit.

5 Turn o the printer, and then disconnect the Ethernet cable. Then wait for at least ﬁve seconds, and then

turn the printer back on.

6 To verify if your printer is connected to the network, print a network setup page. Then in the Network Card

[x] section, see if the status is Connected.

Verifying printer setup

When all hardware and software options are installed and the printer is turned on, verify that the printer is set up correctly by printing the following:

• Menu settings page—Use this page to verify that all printer options are installed correctly. A list of installed

options appears toward the bottom of the page. If an option you installed is not listed, then it is not installed correctly. Remove the option, and then install it again. For more information, see “Printing a menu settings

page” on page 57 for non‑touch‑screen printer models, or “Printing a menu settings page” on page 96

for touch‑screen printer models.

• Network setup page—If your printer has Ethernet or wireless capability and is attached to a network, then

print a network setup page to verify the network connection. This page also provides important information that aids network printing conﬁguration. For more information, see

page 58 for non‑touch screen printer models, or “Printing a network setup page” on page 96 for

touch‑screen printer models.

“Printing a network setup page” on

Using M1145 33

Using M1145

Learning about the printer

Printer

conﬁgurations

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately.

Keep all other trays closed until needed.

M1145dn printer model

1 Printer control panel

2 Paper stop

3 Standard bin

4 Front door release button

5 Controller board access door

6 100‑sheet multipurpose feeder

7 Standard 250‑sheet tray

8 Optional 250‑ or 550‑sheet trays

Using M1145 34

Using the printer control panel

Use the To

1 Display

• View the printer status and messages.

• Set up and operate the printer.

2 Left arrow button Scroll to the left.

3 Select button

• Select menu options.

• Save settings.

4 Up arrow button Scroll up.

5 Right arrow button Scroll to the right.

6 Keypad Enter numbers, letters, or symbols.

7 Sleep button Enable Sleep mode or Hibernate mode.

The following actions wake the printer from Sleep mode:

• Pressing any hard button

• Opening a tray or the front door

• Sending a print job from the computer

• Performing a power‑on reset using the main power switch

• Attaching a device to the USB port

8 USB port Connect a ﬂash drive to the printer.

Notes:

• Only the front USB port supports ﬂash drives.

• This feature is available only in select printer models.

9 Stop or cancel button Stop all printer activity.

10 Back button Return to the previous screen.

11 Down arrow button Scroll down.

12 Home button Go to the home screen.

13 Indicator light Check the status of the printer.

Using M1145 35

Understanding the colors of the Sleep button and indicator lights

The colors of the Sleep button and indicator lights on the printer control panel signify a certain printer status or condition.

Indicator light Printer status

O The printer is o or in Hibernate mode.

Blinking green The printer is warming up, processing data, or printing.

Solid green The printer is on, but idle.

Blinking red The printer requires user intervention.

Sleep button light Printer status

O The printer is o, idle or in Ready state.

Solid amber The printer is in Sleep mode.

Blinking amber The printer is entering or waking from Hibernate mode.

Blinking amber for 0.1 second, then goes completely o for 1.9 seconds in a slow, pulsing pattern

The printer is in Hibernate mode.

Attaching cables

Connect the printer to the computer using a USB or parallel cable, or to the network using an Ethernet cable.

Make sure to match the following:

• The USB symbol on the cable with the USB symbol on the printer

• The appropriate parallel cable with the parallel port

• The appropriate Ethernet cable with the Ethernet port

Warning—Potential Damage: Do not touch the USB cable, any network adapter, or the printer in the area shown while actively printing. Loss of data or a malfunction can occur.

Using M1145 36

Use the To

1 USB port Attach an optional wireless network adapter.

2 USB printer port Connect the printer to a computer.

3 Ethernet port Connect the printer to an Ethernet network.

4 Parallel port

Note: This port is available only in select printer

models.

5 Power switch Turn on or turn o the printer.

6 Printer power cord socket Connect the printer to an electrical outlet.

7 Security slot Attach a lock that will secure the printer in place.

Connect the printer to a computer.

Using M1145 37

Accessing the controller board

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

1 Open the controller board access door.

and unplug the power

o,

2 Use the following illustration to locate the appropriate connector.

Warning—Potential Damage: Controller board electronic components are easily damaged by static

electricity. Touch a metal surface on the printer before touching any controller board electronic components or connectors.

1 Memory card connector

2 Option card connector

Using M1145 38

Loading paper and specialty media

The selection and handling of paper and specialty media can information, see

“Avoiding jams” on page 170 and “Storing paper” on page 110.

how reliably documents print. For more

aect

Setting the paper size and type

1 From the printer control panel, navigate to:

> Settings > > Paper Menu > > Paper Size/Type >

2 Press the up or down arrow button to select the tray or feeder, and then press .

3 Press the up or down arrow button to select the paper size, and then press .

4 Press the up or down arrow button to select the paper type, and then press to change the settings.

Conﬁguring Universal paper settings

The Universal paper size is a user‑deﬁned setting that lets you print on paper sizes that are not preset in the printer menus.

Notes:

• The smallest Universal paper size is 6 x 127 mm (3 x 5 inches), and is supported only from the

multipurpose feeder.

• The largest Universal paper size is 216 x 355.6 mm (8.5 x 14 inches), and is supported from all paper

sources.

1 From the printer control panel, navigate to:

> Settings > > Paper Menu > > Universal Setup > > Units of Measure > > select a

unit of measure >

2 Select Portrait Width or Portrait Height, and then press .

3 Press the left or right arrow button to change the setting, and then press .

Using the standard bin and paper stop

The standard bin holds up to 150 sheets of 75‑g/m2 (20‑lb) paper. It collects prints facedown. The standard bin includes a paper stop that keeps paper from sliding out the front of the bin as it stacks.

Using M1145 39

To open the paper stop, pull it so that it ﬂips forward.

Note: Close the paper stop when moving the printer to another location.

Loading trays

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately.

Keep all other trays closed until needed.

1 Pull out the tray completely.

Note: Do not remove trays while a job prints or while Busy appears on the printer display. Doing so may

cause a jam.

4 A

XEC E

5 A

6 A

Using M1145 40

2 Squeeze and then slide the width guide tab to the correct position for the size of the paper you are loading.

LTR

E XE

B 5

A 5

A 4

L TR

E X E

B 5

A 5

3 Squeeze and then slide the length guide tab to the correct position for the size of the paper you are loading.

LTR

LGL

EXEC

A 4

LTR

E X

E C

B 5

Notes:

• For some paper sizes like letter, legal, and A4, squeeze and slide the length guide tab backward to

accommodate their length.

Using M1145 41

• When loading legal‑size paper, the length guide extends beyond the base leaving the paper exposed

to dust. To protect the paper from dust, you can purchase a dust cover separately. For more information, contact customer support.

• If you are loading A6-size paper in the standard tray, then squeeze and then slide the length guide

tab toward the center of the tray to the A6‑size position.

• Make sure the width and length guides are aligned with the paper size indicators on the bottom of

the tray.

LT R

E X E

A 5

A 4

E X

E C

4 Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten

the edges on a level surface.

Using M1145 42

5 Load the paper stack.

Notes:

• Load with the printable side facedown when using recycled or preprinted paper.

• Load prepunched paper with the holes on the top edge toward the front of the tray.

• Load letterhead facedown, with the top edge of the sheet toward the front of the tray. For two‑sided

printing, load letterhead faceup with the bottom edge of the sheet toward the front of the tray.

• Make sure the paper is below the maximum paper ﬁll indicator located on the side of the width guide.

LTR

LGL

EXEC

Using M1145 43

6 Insert the tray.

7 From the printer control panel, set the paper size and paper type in the Paper menu to match the paper

loaded in the tray.

Note: Set the correct paper size and type to avoid paper jams and print quality problems.

Loading the multipurpose feeder

Use the multipurpose feeder when printing on dierent paper sizes and types or specialty media, such as card stock, transparencies, paper labels, and envelopes. You can also use it for single‑page print jobs on letterhead.

1 Open the multipurpose feeder.

Using M1145 44

a Pull the multipurpose feeder extender.

b Pull the extender gently so that the multipurpose feeder is fully extended and open.

2 Squeeze the tab on the left width guide, and then move the guides for the paper you are loading.

Using M1145 45

3 Prepare the paper or specialty media for loading.

• Flex sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper.

Straighten the edges on a level surface.

• Hold transparencies by the edges. Flex the stack of transparencies back and forth to loosen them, and

then fan them. Straighten the edges on a level surface.

Note: Avoid touching the printable side of the transparencies. Be careful not to scratch them.

• Flex the stack of envelopes back and forth to loosen them, and then fan them. Straighten the edges on

a level surface.

4 Load the paper or specialty media.

Notes:

• Do not force paper or specialty media into the multipurpose feeder.

• Make sure the paper or specialty media is below the maximum paper ﬁll indicator located on the

paper guides. Overﬁlling may cause paper jams.

Using M1145 46

• Load paper, transparencies, and card stock with the recommended printable side faceup and the top

edge entering the printer the transparencies came in.

Note: When loading A6‑size paper, make sure the multipurpose feeder extender rests lightly against the edge of the paper so that the last few sheets of paper remain in place.

For more information on loading transparencies, see the packaging that

ﬁrst.

Using M1145 47

• Load letterhead faceup with the top edge entering the printer ﬁrst. For two‑sided (duplex) printing, load

letterhead facedown with the bottom edge entering the printer

ﬁrst.

• Load envelopes with the

Warning—Potential Damage: Never use envelopes with stamps, clasps, snaps, windows, coated linings, or self‑stick adhesives. These envelopes may severely damage the printer.

on the left side facedown.

ﬂap

5 From the printer control panel, set the paper size and paper type in the Paper menu to match the paper or

specialty media loaded in the multipurpose feeder.

Linking and unlinking trays

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer control panel in the TCP/IP section under the

Network/Ports menu. The IP address appears as four sets of numbers separated by periods, such as

123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Paper Menu.

3 Change the paper size and type settings for the trays you are linking.

• To link trays, make sure the paper size and type for the tray match that of the other tray.

• To unlink trays, make sure the paper size or type for the tray does not match that of the other tray.

4 Click Submit.

Using M1145 48

Note: You can also change the paper size and type settings using the printer control panel. For more information, see

Warning—Potential Damage: Paper loaded in the tray should match the paper type name assigned in the printer. The temperature of the fuser varies according to the speciﬁed paper type. Printing issues may occur if settings are not properly conﬁgured.

“Setting the paper size and type” on page 38.

Creating a custom name for a paper type

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Paper Menu > Custom Names.

3 Select a custom name, and then type a new custom paper type name.

4 Click Submit.

5 Click Custom Types, and then verify if the new custom paper type name has replaced the custom name.

Using the printer control panel

1 From the printer control panel, navigate to:

> Settings > > Paper Menu > > Custom Names

2 Select a custom name, and then type a new custom paper type name.

3 Press .

4 Press Custom Types, and then verify if the new custom paper type name has replaced the custom name.

Assigning a custom paper type

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Paper Menu > Custom Types.

3 Select a custom paper type name, and then select a paper type.

Note: Paper is the factory default paper type for all user‑deﬁned custom names.

4 Click Submit.

Using M1145 49

Using the printer control panel

1 From the printer control panel, navigate to:

> Settings > > Paper Menu > > Custom Types

2 Select a custom paper type name, and then select a paper type.

Note: Paper is the factory default paper type for all user‑deﬁned custom names.

3 Press .

Printing

Printing a document

Printing from a computer

Note: For labels, card stock, and envelopes, set the paper size and type in the printer before sending the

print job.

1 From the document that you are trying to print, open the Print dialog.

2 If necessary, adjust the settings.

3 Send the print job.

Adjusting toner darkness

Using the Embedded Web Server

1 Open a Web browser, and then type the IP address of the printer in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Print Settings > Quality Menu > Toner Darkness.

3 Adjust the toner darkness, and then click Submit.

Using the printer control panel

1 From the printer control panel, navigate to:

> Settings > > Print Settings > > Quality Menu > > To n er Da r k n ess

2 Adjust the toner darkness, and then press .

Using M1145 50

Printing from a mobile device

Note: Make sure that the printer and mobile device share the same wireless network. For information on

conﬁguring

Printing from a mobile device using Mopria Print Service

Mopria® Print Service is a mobile printing solution for mobile devices running on Android version 4.4 or later. It allows you to print directly to any Mopria‑certiﬁed printer.

Note: Before printing, make sure that the Mopria Print Service is enabled.

1 From the home screen of your mobile device, launch a compatible application.

2 Tap Print, and then select the printer.

3 Send the print job.

Printing from a mobile device using Google Cloud Print

Google Cloud PrintTM is a mobile printing service that allows enabled applications on mobile devices to print to any Google Cloud Print‑ready printer.

the wireless settings of your mobile device, see the documentation that came with the device.

1 From the home screen of your mobile device, launch an enabled application.

2 Tap Print, and then select the printer.

3 Send the print job.

Printing from a mobile device using AirPrint

AirPrint is a mobile printing solution that allows you to print directly from Apple devices to an AirPrint‑certiﬁed printer.

Note: This application is supported only in some Apple devices.

1 From the home screen of your mobile device, launch a compatible application.

2 Select an item to print, and then tap the share icon.

3 Tap Print, and then select the printer.

4 Send the print job.

Printing from a mobile device using Lexmark Mobile Print

Lexmark Mobile Print allows you to send documents and images directly to a supported Lexmark printer.

1 Open the document, and then send or share the document to Lexmark Mobile Print.

Note: Some third‑party applications may not support the send or share feature. For more information, see

the documentation that came with the application.

2 Select a printer.

3 Print the document.

Using M1145 51

Printing from a ﬂash drive

Notes:

• Before printing an encrypted PDF ﬁle, you will be prompted to enter the ﬁle password from the printer

control panel.

• You cannot print ﬁles for which you do not have printing permissions.

1 Insert a ﬂash drive into the USB port.

Notes:

• A ﬂash drive icon appears on the printer control panel and in the held jobs icon when a ﬂash drive is

installed.

• If you insert the ﬂash drive when the printer requires attention, such as when a jam has occurred,

then the printer ignores the ﬂash drive.

• If you insert the ﬂash drive while the printer is processing other print jobs, then Busy appears. After

these print jobs are processed, you may need to view the held jobs list to print documents from the ﬂash drive.

Warning—Potential Damage: Do not touch the printer or the ﬂash drive in the area shown while actively printing, reading, or writing from the memory device. Loss of data can occur.

Using M1145 52

2 From the printer control panel, select the document you want to print.

3 Press the left or right arrow button to specify the number of copies for printing, and then press .

Notes:

• Do not remove the

drive from the USB port until the document has

ﬂash

ﬁnished

printing.

• If you leave the ﬂash drive in the printer after leaving the initial USB menu screen, then access held

jobs from the printer control panel to print ﬁles from the ﬂash drive.

Supported ﬂash drives and ﬁle types

Flash drive File type

• Lexar JumpDrive 2.0 Pro (256MB, 512MB, or 1GB sizes)

• SanDisk Cruzer Mini (256MB, 512MB, or 1GB sizes)

Notes:

• Hi‑speed USB

devices are not supported.

• USB

formatted with New Technology File System (NTFS) or any other supported.

drives must support the File Allocation Table (FAT) system. Devices

ﬂash

drives must support the full‑speed standard. Low-speed USB

ﬂash

system are not

ﬁle

Documents:

• .pdf

• .xps

Images:

• .dcx

• .gif

• .JPEG or .jpg

• .bmp

• .pcx

• .TIFF or .tif

• .png

Using M1145 53

Printing conﬁdential and other held jobs

Storing print jobs in the printer

1 From the printer control panel, navigate to:

> Security > Conﬁdential Print

2 Select a print job type.

Use To

Conﬁdential Job Expiration Hold print jobs in the computer until you enter the PIN from the printer

control panel. Note: The PIN is set from the computer. It must be four digits, using the

numbers 0–9.

Max Invalid PIN Limit the number of times an invalid PIN can be entered.

Note: When the limit is reached, the print jobs for that user name and PIN are deleted.

Repeat Job Expiration Print and store print jobs in the printer memory.

Reserve Job Expiration Store print jobs for printing at a later time.

Note: The print jobs are held until deleted from the Held Jobs menu.

Verify Job Expiration Print one copy of a print job and hold the remaining copies. It lets you

examine if the ﬁrst copy is satisfactory. Note: The print job is automatically deleted from the printer memory

once all copies are printed.

Notes:

•

Conﬁdential, process additional held jobs.

Verify, Reserve, and Repeat print jobs may be deleted if the printer requires extra memory to

• You can set the printer to store print jobs in the printer memory until you start the print job from the

printer control panel.

• All print jobs that can be initiated by the user at the printer are called held jobs.

3 Press .

Printing held jobs

1 From the document you are trying to print, open the Print dialog.

2 Select the printer, and then do either of the following:

• For Windows users, click Properties or Preferences, and then click Print and Hold.

• For Macintosh users, select Print and Hold.

3 Select the print job type.

4 If necessary, assign a user name.

5 Send the print job.

Using M1145 54

6 From the printer home screen, select Held Jobs.

7 Send the print job.

Printing information pages

Printing a font sample list

1 From the printer control panel, navigate to:

> Settings > > Reports > > Print Fonts

2 Press the up or down arrow button to select the font setting.

3 Press .

Note: The PPDS fonts appear only when the PPDS data stream is activated.

Printing a directory list

From the printer control panel, navigate to:

> Settings > Reports > > Print Directory >

Note: The Print Directory menu item appears only when an optional ﬂash memory or printer hard disk is installed.

Canceling a print job

Canceling a print job from the printer control panel

From the printer control panel, press > .

Canceling a print job from the computer

For Windows users

Open the printers folder, and then select your printer.

2 From the print queue, select the print job you want to cancel, and then delete it.

For Macintosh users

From System Preferences in the Apple menu, navigate to your printer.

2 From the print queue, select the print job you want to cancel, and then delete it.

Using M1145 55

Managing the printer

Checking the virtual display

1 Open a Web browser, and then type the printer IP address in the address

Notes:

ﬁeld.

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Check the virtual display that appears at the top left corner of the screen.

The virtual display works as an actual display would work on a printer control panel.

Conﬁguring

You can determine how you would like to be notiﬁed when supplies run nearly low, low, very low, or reach their end‑of‑life by setting the selectable alerts.

Notes:

supply

notiﬁcations

from the Embedded Web Server

• Selectable alerts can be set on the toner cartridge, imaging unit, and maintenance kit.

• All selectable alerts can be set for nearly low, low, and very low supply conditions. Not all selectable

alerts can be set for the end‑of‑life supply condition. E‑mail selectable alert is available for all supply conditions.

• The percentage of estimated remaining supply that prompts the alert can be set on some supplies for

some supply conditions.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Print Settings > Supply Notiﬁcations.

3 From the drop‑down menu for each supply, select one of the following notiﬁcation options:

Notiﬁcation Description

O The normal printer behavior for all supplies occurs.

E‑mail Only The printer generates an e-mail when the supply condition is reached. The status of

the supply will appear on the menus page and status page.

Warning The printer displays the warning message and generates an email about the status

of the supply. The printer does not stop when the supply condition is reached.

The printer generates an e-mail about the status of the supply when supply notiﬁcation is enabled.

The printer stops when some supplies become empty to prevent damage.

Using M1145 56

Notiﬁcation Description

Continuable Stop

Non Continuable Stop

The printer generates an e-mail about the status of the supply when supply notiﬁcation is enabled.

The printer stops when some supplies become empty to prevent damage.

The printer stops processing jobs when the supply condition is reached, and the user needs to press a button to continue printing.

1,2

The printer stops when the supply condition is reached. The supply must be replaced to continue printing.

4 Click Submit.

Modifying

Note: This feature is available only in network printers or printers connected to print servers.

conﬁdential

1 Open a Web browser, and then type the printer IP address in the address

Notes:

print settings

ﬁeld.

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings tab > Security >

Conﬁdential

Print Setup.

3 Modify the settings:

• Set a maximum number of PIN entry attempts. When a user exceeds a speciﬁc number of PIN entry

attempts, all of the jobs for that user are deleted.

• Set an expiration time for

time, all of the jobs for that user are deleted.

conﬁdential

print jobs. When a user has not printed the jobs within the

4 Save the modiﬁed settings.

Copying printer settings to other printers

Note: This feature is available only in network printers.

speciﬁed

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click the Copy Printer Settings.

3 To change the language, select a language from the drop-down menu, and then click Click here to submit

language.

4 Click Printer Settings.

Using M1145 57

5 Type the IP addresses of the source and target printers in their appropriate ﬁelds.

Note: If you want to add or remove a target printer, then click Add Target IP or Remove Target IP.

6 Click Copy Printer Settings.

Creating a printer control panel PIN

The Panel PIN Protect menu lets you restrict access to the menus from the printer control panel. To restrict access to the menus, create a Personal Identiﬁcation Number (PIN), and then assign the PIN to each menu.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Security > Panel PIN Protect.

3 From the Create User PIN or Create Admin PIN sections, enter your PIN.

Note: Your can enter up to 16 digits for your PIN.

4 Click Modify.

5 From any menu in the Administrative Menus, Management, or Function Access sections, select User PIN

Protected or Admin PIN Protected or Admin PIN and User PIN Protected.

Note: Using an Admin PIN, you can still access a menu assigned with a User PIN.

6 Click Submit.

If you try to access a PIN‑protected menu from the printer control panel, the printer will require you to enter the PIN.

Note: After you enter the last digit of the PIN, make sure to press than three seconds.

on the printer control panel for more

Printing a menu settings page

Print a menu settings page to view the current menu settings and to verify if the printer options are installed correctly.

From the printer control panel, navigate to:

> Settings > Reports > > Menu Settings Page >

Note: If you have not changed any menu settings, then the menu settings page lists all the factory default settings. Settings saved from the menus replace the factory default settings as user default settings. A user default setting remains in eect until you access the menu again, select another value, and save it.

Using M1145 58

Printing a network setup page

If the printer is attached to a network, then print a network setup page to verify the network connection. This page also provides important information that aids network printing conﬁguration.

1 From the printer control panel, navigate to:

> Settings > Reports > > Network Setup Page >

Note: If an optional internal print server is installed, then Print Network [x] Setup Page appears.

2 Check the

If the status is Not Connected, then the LAN drop may not be active, or the network cable may be malfunctioning. Consult your system support person for a solution, and then print another network setup page.

section of the network setup page, and

ﬁrst

conﬁrm

that the status is Connected.

Checking the status of parts and supplies

A message appears on the printer display when a replacement supply item is needed or when maintenance is required.

Checking the status of parts and supplies on the printer control panel

From the printer control panel, navigate to:

> Status/Supplies > > View Supplies >

Checking the status of parts and supplies from the Embedded Web Server

Note: Make sure the computer and printer are connected to the same network.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Device Status > More Details.

Saving energy

Using Eco‑mode

Use Eco‑Mode to quickly select one or more ways to reduce your printer's environmental impact.

1 From the printer control panel, navigate to:

> Settings > Settings > > General Settings > > Eco‑Mode > > select the setting you want

Using M1145 59

Use To

O Use the factory default settings for all settings associated with Eco‑Mode. This setting supports

the performance speciﬁcations for your printer.

Energy Reduce energy use, especially when the printer is idle.

• Printer engine motors do not start until a job is ready to print. You may notice a short delay

before the

page is printed.

ﬁrst

• The printer enters Sleep mode after one minute of inactivity.

Energy/Paper Use all the settings associated with Energy and Paper modes.

Plain Paper

• Enable the automatic two‑sided (duplex) feature.

• Turn o print log features.

2 Press .

Reducing printer noise

Use Quiet mode to reduce the printer noise.

1 From the printer control panel, navigate to:

> Settings > Settings > > General Settings > > Quiet Mode >

2 Select a setting you want.

Use To

On Reduce printer noise.

Notes:

• Print jobs will process at a reduced speed.

• Printer engine motors do not start until a

document is ready to print. There is a short delay before the ﬁrst page is printed.

O Use factory default settings.

Note: This setting supports the performance speciﬁcations

of the printer.

3 Press .

Adjusting Sleep mode

1 From the control panel, navigate to:

> Settings > > Settings > > General Settings > > Timeouts > > Sleep Mode >

2 In the Sleep Mode

3 Apply the changes.

select the number of minutes the printer is idle before it enters Sleep mode.

ﬁeld,

Using M1145 60

Using Hibernate mode

Hibernate is an ultra‑low‑power saving mode.

Notes:

• Three days is the default amount of time before the printer enters Hibernate mode.

• Make sure to wake the printer from Hibernate mode before sending a print job. A hard reset or a long

press of the Sleep button wakes the printer from Hibernate mode.

• If the printer is in Hibernate mode, then the Embedded Web Server is disabled.

1 From the control panel, navigate to:

> Settings > > Settings > > General Settings >

2 Select Press Sleep Button or Press and Hold Sleep Button, and then press .

3 Press Hibernate > .

Setting Hibernate Timeout

Hibernate Timeout lets you set the amount of time the printer waits after a print job is processed before it goes into a reduced power state.

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address

Notes:

ﬁeld.

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings > Timeouts.

3 From the Hibernate Timeout menu, select the number of hours, days, weeks, or months you want for the

printer to wait before it goes into a reduced power state.

4 Click Submit.

Using the printer control panel

1 From the printer control panel, navigate to:

> Settings > > Settings > > General Settings > > Timeouts > > Hibernate Timeout

2 Select the amount of time the printer waits after a print job is processed before it enters Hibernate mode.

3 Press .

Using M1145 61

Using Schedule Power Modes

Schedule Power Modes lets you schedule when the printer goes into a reduced power state or into the Ready state.

Note: This feature is available only in network printers or printers connected to print servers.

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings > Schedule Power Modes.

3 From the Action menu, select the power mode.

4 From the Time menu, select the time.

5 From the Day(s) menu, select the day or days.

6 Click Add.

Adjusting the brightness of the printer display

To save energy, or if you have trouble reading the display, adjust its brightness settings.

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings.

3 In the Screen Brightness ﬁeld, enter the brightness percentage you want for the display.

4 Click Submit.

Restoring factory default settings

If you want to keep a list of the current menu settings for reference, then print a menu settings page before restoring the factory default settings. For more information, see

“Printing a menu settings page” on page 57.

If you want a more comprehensive method of restoring the printer factory default settings, then perform the Wipe All Settings option. For more information, see

Warning—Potential Damage: Restoring factory defaults returns most printer settings to the original factory default settings. Exceptions include the display language, custom sizes and messages, and network/port menu settings. All downloads stored in the RAM are deleted. Downloads stored in the ﬂash memory or in printer hard disk are not aected.

“Erasing non‑volatile memory” on page 63.

Using M1145 62

From the printer control panel, navigate to:

> Settings > Settings > > General Settings > > Factory Defaults > > Restore Now >

Securing the printer

Using the security lock feature

The printer is equipped with a security lock feature. Attach a security lock compatible with most laptop computers in the location shown to secure the printer in place.

Statement of Volatility

Your printer contains various types of memory that can store device and network settings, and user data.

Type of memory Description

Volatile memory Your printer uses standard random access memory

(RAM) to temporarily buer user data during simple print jobs.

Non-volatile memory Your printer may use two forms of non-volatile memory:

EEPROM and NAND (ﬂash memory). Both types are used to store operating system, device settings, and network information.

Erase the content of any installed printer memory in the following circumstances:

• The printer is being decommissioned.

• The printer is being moved to a dierent department or location.

• The printer is being serviced by someone from outside your organization.

• The printer is being removed from your premises for service.

• The printer is being sold to another organization.

Using M1145 63

Erasing volatile memory

The volatile memory (RAM) installed in your printer requires a power source to retain information. To erase the buered data, turn o the printer.

Erasing non‑volatile memory

Erase individual settings, device and network settings, security settings, and embedded solutions by following these steps:

1 Turn o the printer.

2 Hold down 2 and 6 on the keypad while turning the printer on. Release the buttons only when the screen

with the progress bar appears. The printer performs a power-on sequence, and then the Conﬁguration menu appears. When the printer is

fully turned on, a list of functions appears on the printer display.

3 Press the up or down arrow button until Wipe All Settings appears.

The printer will restart several times during this process.

Note: Wipe All Settings securely removes device settings, solutions, jobs, and passwords from the printer memory.

4 Navigate to:

Back > Exit Conﬁg Menu

The printer will perform a power‑on reset, and then return to normal operating mode.

Finding printer security information

In high-security environments, it may be necessary to take additional steps to make sure that stored in the printer cannot be accessed by unauthorized persons. For more information, visit the

Lexmark security Web page.

You can also see the Embedded Web Server — Security: Administrator’s Guide for additional information:

1 Go to www.lexmark.com, and then navigate to Support & Downloads > select your printer.

2 Click the Manuals tab, and then select Embedded Web Server — Security: Administrator’s Guide.

conﬁdential

data

Using M3150 64

Using M3150

Learning about the printer

Printer

Basic and

1 Printer control panel

2 Paper stop

conﬁgurations

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately.

Keep all other trays closed until needed.

conﬁgured

models

3 Standard bin

4 Front door release button

5 Controller board access door

6 100‑sheet multipurpose feeder

7 Standard 550‑sheet tray

8 Optional 250‑ or 550‑sheet tray

Using M3150 65

Using the printer control panel

Use the To

1 Display

• View the printer status and messages.

• Set up and operate the printer.

2 Home button Go to the home screen.

3 Keypad Enter numbers, letters, or symbols.

4 Sleep button Enable Sleep mode or Hibernate mode.

The following actions wake the printer from Sleep mode:

• Touching the screen

• Pressing any hard button

• Opening a tray or the front door

• Sending a print job from the computer

• Performing a power‑on reset using the main power switch

• Attaching a device to the USB port

5 Stop or cancel button Stop all printer activity.

6 Indicator light Check the status of the printer.

7 USB port Connect a ﬂash drive to the printer.

Note: Only the front USB port supports ﬂash drives.

Understanding the colors of the Sleep button and indicator lights

The colors of the Sleep button and indicator lights on the printer control panel signify a certain printer status or condition.

Indicator light Printer status

O The printer is o or in Hibernate mode.

Blinking green The printer is warming up, processing data, or printing.

Solid green The printer is on, but idle.

Blinking red The printer requires user intervention.

Using M3150 66

Sleep button light Printer status

O The printer is o, idle or in Ready state.

Solid amber The printer is in Sleep mode.

Blinking amber The printer is entering or waking from Hibernate mode.

Blinking amber for 0.1 second, then goes completely o for 1.9 seconds in a slow, pulsing pattern

The printer is in Hibernate mode.

Understanding the home screen

When the printer is turned on, the display shows a basic screen, referred to as the home screen. Use the home screen buttons and icons to initiate an action.

Note: Your home screen may vary depending on your home screen customization settings, administrative setup, and active embedded solutions.

To uc h To

1 Change Language Change the primary language of the printer.

2 Bookmarks Create, organize, and save a set of bookmarks (URLs) into a tree view of folders and

ﬁle links. Note: The tree view does not include bookmarks created within Forms and

Favorites, and the ones in the tree are not usable in Forms and Favorites.

3 Held Jobs Display all current held jobs.

4 USB View, select, or print photos and documents from a ﬂash drive.

Note: This icon appears only when you return to the home screen while a memory

card or

5 Menus Access printer menus.

Note: These menus are available only when the printer is in Ready state.

6 Status message bar

• Show the current printer status such as Ready or Busy.

drive is connected to the printer.

ﬂash

• Show the status of printer supplies.

• Show intervention messages and the instructions on how to clear them.

Using M3150 67

To uc h To

7 Status/Supplies

• Show a printer warning or error message whenever the printer requires intervention

to continue processing.

• View more information on the printer warning or message, and on how to clear it.

8 Tips View a context‑sensitive help information.

These may also appear on the home screen:

To uc h To

Search Held Jobs Search current held jobs.

Jobs by user Access print jobs saved by user.

Proﬁles and Apps Access proﬁles and applications.

Features

Feature Description

Attendance message alert

Warning

If an attendance message aects a function, then this icon appears and the red indicator light blinks.

If an error condition occurs, then this icon appears.

Printer IP address Example: 123.123.123.123

The IP address of your printer is located at the top left corner of the home screen. You can use the IP address when accessing the Embedded Web Server to view and remotely

conﬁgure

printer settings.

Using the touch-screen buttons

Note: Your home screen may vary, depending on your home screen customization settings, administrative

setup, and active embedded solutions.

Using M3150 68

Touc h t h e To

1 Radio button Select or clear an item.

2 Up arrow Scroll up.

3 Down arrow Scroll down.

4 Accept button Save a setting.

5 Cancel button

• Cancel an action or a selection.

• Return to the previous screen.

To uc h To

Return to the home screen.

Open a context-sensitive Help dialog on the printer control panel.

Scroll to the left.

Scroll to the right.

Attaching cables

Connect the printer to the computer using a USB cable or parallel cable, or to the network using an Ethernet cable.

Using M3150 69

Make sure to match the following:

• The USB symbol on the cable with the USB symbol on the printer

• The appropriate parallel cable with the parallel port

Note: The parallel port is available only when an Internal Solutions Port is installed.

• The appropriate Ethernet cable with the Ethernet port

Warning—Potential Damage: Do not touch the USB cable, any network adapter, or the printer in the area shown while actively printing. Loss of data or a malfunction can occur.

Use the To

1 Security slot Attach a lock that will secure the controller board.

2 USB printer port Connect the printer to a computer.

3 USB port Connect a ﬂash drive to the printer.

4 USB port Attach an optional wireless network adapter.

5 Ethernet port Connect the printer to an Ethernet network.

6 Power switch Turn on or o the printer.

7 Printer power cord socket Connect the printer to an electrical outlet.

Using M3150 70

Accessing the controller board

CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware

1 Open the controller board access door.

and unplug the power

o,

2 Open the controller board shield using the green handle.

3 Use the following illustration to locate the appropriate connector.

Using M3150 71

1 Memory card connector

2 Option card connector

3 Printer hard disk connector

4 Internal Solutions Port connector

4 Close the controller board shield, and then close the controller board access door.

Using M3150 72

Setting up and using the home screen applications

Notes:

• Your home screen may vary depending on your home screen customization settings, administrative

setup, and active embedded applications. Some applications are supported only in some printer models.

• There may be additional solutions and applications available for purchase. For more information, go to

www.lexmark.com or contact the place where you purchased the printer.

Finding the IP address of the computer

For Windows users

In the Run dialog box, type cmd to open the command prompt.

2 Type ipconfig, and then look for the IP address.

For Macintosh users

From System Preferences in the Apple menu, select Network.

2 Select your connection type, and then click Advanced > TCP/IP.

3 Look for the IP address.

Finding the IP address of the printer

Note: Make sure your printer is connected to a network or to a print server.

You can ﬁnd the printer IP address:

• From the top left corner of the printer home screen.

• From the TCP/IP section in the Network/Ports menu.

• By printing a network setup page or menu settings page, and then ﬁnding the TCP/IP section.

Note: An IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.

Accessing the Embedded Web Server

The Embedded Web Server is the printer Web page that lets you view and remotely conﬁgure printer settings even when you are not physically near the printer.

1 Obtain the printer IP address:

• From the printer control panel home screen

• From the TCP/IP section in the Network/Ports menu

• By printing a network setup page or menu settings page, and then

ﬁnding

the TCP/IP section

Note: An IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.

2 Open a Web browser, and then type the printer IP address in the address ﬁeld.

3 Press Enter.

Note: If you are using a proxy server, then temporarily disable it to load the Web page correctly.

Using M3150 73

Customizing the home screen

1 Open a Web browser, and then type the printer IP address in the address

Note: View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

ﬁeld.

2 Do one or more of the following:

• Show or hide the icons of basic printer functions.

a Click Settings > General Settings > Home screen customization. b Select the check boxes to specify which icons appear on the home screen.

Note: If you clear a check box beside an icon, then the icon does not appear on the home

screen.

c Click Submit.

• Customize the icon for an application. For more information, see “Finding information about the home

screen applications” on page 73 or see the documentation that came with the application.

Activating the home screen applications

Finding information about the home screen applications

Your printer comes with preinstalled home screen applications. Before you can use these applications, you must ﬁrst activate and set up these applications using the Embedded Web Server. For more information on accessing the Embedded Web Server, see

“Accessing the Embedded Web Server” on page 72.

For more information on conﬁguring and using the home screen applications, do the following:

1 Go to http://support.lexmark.com.

2 Click Software Solutions, and then select either of the following:

• Scan to Network—This lets you ﬁnd information about the Scan to Network application.

• Other Applications—This lets you ﬁnd information about the other applications.

3 Click the Manuals tab, and then select the document for the home screen application.

Using Background and Idle Screen

Icon Description

The application lets you customize the background and idle screen of your printer home screen.

1 From the home screen, navigate to:

Change Background > select background to use

2 To u ch .

Using M3150 74

Setting up Forms and Favorites

Note: A later version of this User's Guide may contain a direct link to the Administrator’s Guide of this

application. To check for updates of this User’s Guide, go to

Use To

Streamline work processes by letting you quickly ﬁnd and print frequently used online forms directly from the printer home screen.

Note: The printer must have permission to access the network folder, FTP site, or Web site where the bookmark is stored. From the computer where the bookmark is stored, use sharing, security, and ﬁrewall settings to allow the printer at least a read access. For help, see the documentation that came with your operating system.

http://support.lexmark.com.

1 Open a Web browser, and then type the printer IP address in the address

Note: View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

ﬁeld.

2 Click Settings > Apps > Apps Management > Forms and Favorites.

3 Click Add, and then customize the settings.

Notes:

• See the mouse-over help beside each ﬁeld for a description of the setting.

• To make sure the location settings of the bookmark are correct, type the correct IP address of the

host computer where the bookmark is located. For more information on obtaining the IP address of the host computer, see

“Finding the IP address of the computer” on page 72.

• Make sure the printer has access rights to the folder where the bookmark is located.

4 Click Apply.

To use the application, touch Forms and Favorites on the printer home screen, and then navigate through form categories, or search for forms based on a form number, name, or description.

Understanding Eco‑Settings

Icon Description

The application lets you easily manage energy consumption, noise, toner, and paper usage settings to help reduce the environmental impact of your printer.

Using M3150 75

Setting up Remote Operator Panel

This application enables you to interact with the printer control panel even when you are not physically near the network printer. From your computer, you can view the printer status, release held print jobs, create bookmarks, and do other print-related tasks.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Note: View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

2 Click Settings > Remote Operator Panel Settings.

3 Select the Enable check box, and then customize the settings.

4 Click Submit.

To use the application, click Remote Operator Panel > Launch VNC Applet.

Exporting and importing a conﬁguration

You can export conﬁguration settings into a text ﬁle, and then import the ﬁle to apply the settings to other printers.

1 Open a Web browser, and then type the printer IP address in the address

Note: View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

ﬁeld.

2 Click Settings > Apps > Apps Management.

3 From the list of installed applications, click the name of the application you want to conﬁgure.

4 Click Conﬁgure, and then do one of the following:

• To export a conﬁguration to a ﬁle, click Export, and then follow the instructions on the computer screen

to save the conﬁguration ﬁle.

Notes:

– When saving the conﬁguration ﬁle, you can type a unique ﬁle name or use the default name. – If a "JVM Out of Memory” error occurs, then repeat the export process until the conﬁguration ﬁle

is saved.

• To import a conﬁguration from a ﬁle, click Import, and then browse to the saved conﬁguration ﬁle that

was exported from a previously conﬁgured printer.

Notes:

– Before importing the conﬁguration ﬁle, you can choose to preview it ﬁrst or load it directly. – If a timeout occurs and a blank screen appears, then refresh the Web browser, and then click

Apply.

Using M3150 76

Loading paper and specialty media

The selection and handling of paper and specialty media can information, see

“Avoiding jams” on page 170 and “Storing paper” on page 110.

how reliably documents print. For more

aect

Setting the paper size and type

From the home screen navigate to:

> Paper Menu > Paper Size/Type > select a tray > select the paper size or type >

Conﬁguring

The Universal paper size is a user‑deﬁned setting that lets you print on paper sizes that are not preset in the printer menus.

Notes:

• The smallest Universal paper size is 6 x 127 mm (3 x 5 inches), and is supported only from the

multipurpose feeder.

• The largest Universal paper size is 216 x 355.6 mm (8.5 x 14 inches), and is supported from all paper

sources.

1 From the printer control panel, navigate to:

Universal paper settings

> Paper Menu > Universal Setup > Units of Measure > select a unit of measure >

2 To u ch Portrait Width or Portrait Height.

3 Select the width or height, and then touch .

Using the standard bin and paper stop

Using M3150 77

To open the paper stop, pull it so that it ﬂips forward.

Note: When moving the printer to another location, make sure the paper stop is closed.

Loading trays

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately.

Keep all other trays closed until needed.

1 Pull out the tray completely.

Note: Do not remove trays while a job prints or while Busy appears on the printer display. Doing so may

cause a jam.

4 A

XEC E

5 A

6 A

Using M3150 78

2 Squeeze and then slide the width guide tab to the correct position for the size of the paper you are loading.

LTR

E XE

B 5

A 5

A 4

L TR

E X E

B 5

A 5

3 Squeeze and then slide the length guide tab to the correct position for the size of the paper you are loading.

LTR

LGL

EXEC

A 4

LTR

E X

E C

B 5

Notes:

• For some paper sizes like letter, legal, and A4, squeeze and slide the length guide tab backward to

accommodate their length.

Using M3150 79

• When loading legal‑size paper, the length guide extends beyond the base leaving the paper exposed

to dust. To protect the paper from dust, you can purchase a dust cover separately. For more information, contact customer support.

• If you are loading A6-size paper in the standard tray, then squeeze and then slide the length guide

tab toward the center of the tray to the A6‑size position.

• Make sure the width and length guides are aligned with the paper size indicators on the bottom of

the tray.

LT R

E X E

A 5

A 4

E X

E C

4 Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten

the edges on a level surface.

Using M3150 80

5 Load the paper stack.

Notes:

• Load with the printable side facedown when using recycled or preprinted paper.

• Load prepunched paper with the holes on the top edge toward the front of the tray.

• Load letterhead facedown, with the top edge of the sheet toward the front of the tray. For two‑sided

printing, load letterhead faceup with the bottom edge of the sheet toward the front of the tray.

• Make sure the paper is below the maximum paper ﬁll indicator located on the side of the width guide.

LTR

LGL

EXEC

Using M3150 81

6 Insert the tray.

7 From the printer control panel, set the paper size and paper type in the Paper menu to match the paper

loaded in the tray.

Note: Set the correct paper size and paper type to avoid paper jams and print quality problems.

Loading the multipurpose feeder

1 Open the multipurpose feeder.

Using M3150 82

a Pull the multipurpose feeder extender.

b Pull the extender gently so that the multipurpose feeder is fully extended and open.

2 Squeeze the tab on the left width guide, and then move the guides for the paper you are loading.

Using M3150 83

3 Prepare the paper or specialty media for loading.

• Flex sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper.

Straighten the edges on a level surface.

• Hold transparencies by the edges. Flex the stack of transparencies back and forth to loosen them, and

then fan them. Straighten the edges on a level surface.

Note: Avoid touching the printable side of the transparencies. Be careful not to scratch them.

• Flex the stack of envelopes back and forth to loosen them, and then fan them. Straighten the edges on

a level surface.

4 Load the paper or specialty media.

Notes:

• Do not force paper or specialty media into the multipurpose feeder.

• Make sure the paper or specialty media is below the maximum paper ﬁll indicator located on the

paper guides. Overﬁlling may cause paper jams.

Using M3150 84

• Load paper, transparencies, and card stock with the recommended printable side faceup and the top

edge entering the printer the transparencies came in.

Note: When loading A6‑size paper, make sure the multipurpose feeder extender rests lightly against the edge of the paper so that the last few sheets of paper remain in place.

For more information on loading transparencies, see the packaging that

ﬁrst.

Using M3150 85

• Load letterhead faceup with the top edge entering the printer ﬁrst. For two‑sided (duplex) printing, load

letterhead facedown with the bottom edge entering the printer

ﬁrst.

• Load envelopes with the

Warning—Potential Damage: Never use envelopes with stamps, clasps, snaps, windows, coated linings, or self‑stick adhesives. These envelopes may severely damage the printer.

on the left side facedown.

ﬂap

5 From the printer control panel, set the paper size and paper type in the Paper menu to match the paper or

specialty media loaded in the multipurpose feeder.

Linking and unlinking trays

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Paper Menu.

3 Change the paper size and type settings for the trays you are linking.

• To link trays, make sure the paper size and type for the tray match that of the other tray.

• To unlink trays, make sure the paper size or type for the tray does not match that of the other tray.

4 Click Submit.

Using M3150 86

Note: You can also change the paper size and type settings using the printer control panel. For more information, see

“Setting the paper size and type” on page 76.

Creating a custom name for a paper type

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Paper Menu > Custom Names.

3 Select a custom name, and then type a custom paper type name.

4 Click Submit.

5 Click Custom Types, and then verify if the new custom paper type name has replaced the custom name.

Using the printer control panel

1 From the home screen, navigate to:

> Paper Menu > Custom Names

2 Select a custom name, and then type a custom paper type name.

3 To u ch .

4 To u ch Custom Types, and then verify that the new custom paper type name has replaced the custom name.

Assigning a custom paper type

Using the Embedded Web Server

Assign a custom paper type name to a tray when linking or unlinking trays.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Paper Menu > Custom Types.

Using M3150 87

3 Select a custom paper type name, and then select a paper type

Note: Paper is the factory default paper type for all user‑

deﬁned

custom names.

4 Click Submit.

Using the printer control panel

1 From the home screen, navigate to:

> Paper Menu > Custom Types

2 Select a custom paper type name, and then select a paper type

Note: Paper is the factory default paper type for all user‑deﬁned custom names.

3 To u ch .

Printing

Printing forms

Use Forms and Favorites to quickly and easily access frequently used forms or other information that is regularly printed. Before you can use this application, ﬁrst set it up on the printer. For more information, see

Forms and Favorites” on page 74.

“Setting up

1 From the home screen, navigate to:

Forms and Favorites > select the form from the list > enter the number of copies > adjust other settings

2 Apply the changes.

Printing a document

Printing from a computer

Note: For labels, card stock, and envelopes, set the paper size and type in the printer before printing the

document.

1 From the document that you are trying to print, open the Print dialog.

2 If necessary, adjust the settings.

3 Print the document.

Adjusting toner darkness

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address

ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

Using M3150 88

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Print Settings > Quality Menu > Toner Darkness.

3 Adjust the setting, and then click Submit.

Using the printer control panel

1 From the home screen, navigate to:

> Settings > Print Settings > Quality Menu > To n e r Dark n e s s

2 Adjust the setting, and then touch .

Printing from a mobile device

Note: Make sure that the printer and mobile device share the same wireless network. For information on

conﬁguring the wireless settings of your mobile device, see the documentation that came with the device.

Printing from a mobile device using Mopria Print Service

Mopria® Print Service is a mobile printing solution for mobile devices running on Android version 4.4 or later. It allows you to print directly to any Mopria‑certiﬁed printer.

Note: Before printing, make sure that the Mopria Print Service is enabled.

1 From the home screen of your mobile device, launch a compatible application.

2 Tap Print, and then select a printer.

3 Print the document.

Printing from a mobile device using Google Cloud Print

Google Cloud Print is a mobile printing service that allows enabled applications on mobile devices to print to any Google Cloud Print‑ready printer.

1 From the home screen of your mobile device, launch an enabled application.

2 Tap Print, and then select a printer.

3 Print the document.

Printing from a mobile device using AirPrint

AirPrint is a mobile printing solution that allows you to print directly from Apple devices to an AirPrint‑ printer.

certiﬁed

Note: This application is supported only in some Apple devices.

1 From the home screen of your mobile device, launch a compatible application.

2 Select an item to print, and then tap the share icon.

3 Tap Print, and then select the printer.

4 Send the print job.

Using M3150 89

Printing from a mobile device using Lexmark Print

Lexmark Print allows you to send documents and images directly to a Lexmark device.

1 Open the document, and then send or share the document to Lexmark Print.

Note: Some third‑party applications may not support the send or share feature. For more information, see

the documentation that came with the application.

2 Select a device.

3 Print the document.

Printing from a ﬂash drive

Notes:

• Before printing an encrypted PDF ﬁle, you will be prompted to type the ﬁle password from the printer

control panel.

• You cannot print ﬁles for which you do not have printing permissions.

1 Insert a ﬂash drive into the USB port.

Notes:

• A ﬂash drive icon appears on the printer home screen when a ﬂash drive is inserted.

• If you insert the ﬂash drive when the printer requires attention, such as when a jam has occurred,

then the printer ignores the ﬂash drive.

• If you insert the ﬂash drive while the printer is processing other print jobs, then Busy appears. After

these print jobs are processed, you may need to view the held jobs list to print documents from the ﬂash drive.

Warning—Potential Damage: Do not touch the printer or the ﬂash drive in the area shown while actively printing, reading, or writing from the memory device. Loss of data can occur.

Using M3150 90

2 From the printer control panel, touch the document you want to print.

3 Touch the arrows to specify the number of copies for printing, and then touch Print.

Notes:

• Do not remove the ﬂash drive from the USB port until the document has ﬁnished printing.

• If you leave the ﬂash drive in the printer after leaving the initial USB menu screen, then touch Held

Jobs on the home screen to print ﬁles from the ﬂash drive.

Supported ﬂash drives and ﬁle types

Flash drive File type

• Lexar JumpDrive 2.0 Pro (256MB, 512MB, or 1GB sizes)

• SanDisk Cruzer Mini (256MB, 512MB, or 1GB sizes)

Notes:

• High‑speed USB ﬂash drives must support the fullspeed standard. Low-speed USB

devices are not supported.

• USB ﬂash drives must support the File Allocation Table (FAT) system. Devices

formatted with New Technology File System (NTFS) or any other ﬁle system are not supported.

Documents:

• .pdf

• .xps

Images:

• .dcx

• .gif

• .jpeg or .jpg

• .bmp

• .pcx

or .tif

•

.ti

• .png

• .ﬂs

Printing conﬁdential and other held jobs

Storing print jobs in the printer

1 From the home screen, navigate to:

Using M3150 91

> Security >

Use To

Max Invalid PIN Limit the number of times an invalid PIN can be entered.

Conﬁdential Job Expiration Hold print jobs in the computer until you enter the PIN from the printer

Repeat Job Expiration Print and store print jobs in the printer memory.

Verify Job Expiration Print one copy of a print job and hold the remaining copies. It lets you

Reserve Job Expiration Store print jobs for printing at a later time.

Notes:

Conﬁdential

Print > select a print job type

Note: When the limit is reached, the print jobs for that user name and

PIN are deleted.

control panel. Note: The PIN is set from the computer. It must be four digits, using the

numbers 0–9.

examine if the ﬁrst copy is satisfactory or not. The print job is automatically deleted from the printer memory when all copies are printed.

Note: The print jobs are held until deleted from the Held Jobs menu.

• Conﬁdential, Verify, Reserve, and Repeat print jobs may be deleted if the printer requires extra memory to

process additional held jobs.

• You can set the printer to store print jobs in the printer memory until you start the print job from the

printer control panel.

• All print jobs that can be initiated by the user at the printer are called held jobs.

2 To u ch .

Printing held jobs

1 From the document that you are trying to print, open the Print dialog.

2 Select the printer, and then do either of the following:

• For Windows users, click Properties or Preferences, and then click Print and Hold.

• For Macintosh users, select Print and Hold.

3 Select the print job type.

4 If necessary, assign a user name.

5 Send the print job.

6 From the printer home screen, touch Held Jobs.

7 Send the print job.

Using M3150 92

Printing information pages

Printing a font sample list

1 From the home screen, navigate to:

> Reports > Print Fonts

2 To u ch PCL Fonts or PostScript Fonts.

Printing a directory list

A directory list shows the resources stored in a

From the home screen, navigate to:

> Reports > Print Directory

memory or on the printer hard disk.

ﬂash

Canceling a print job

Canceling a print job from the printer control panel

1 From the printer control panel, touch Cancel Job or press on the keypad.

2 Touch the print job you want to cancel, and then touch Delete Selected Jobs.

Note: If you press

Canceling a print job from the computer

For Windows users

Open the printers folder, and then select your printer.

2 From the print queue, select the print job you want to cancel, and then delete it.

on the keypad, then touch Resume to return to the home screen.

For Macintosh users

From System Preferences in the Apple menu, navigate to your printer.

2 From the print queue, select the print job you want to cancel, and then delete it.

Managing the printer

Setting up serial printing (Windows only)

After installing the serial or communication (COM) port, conﬁgure the printer and the computer.

Using M3150 93

Note: Serial printing reduces print speed.

1 Set the parameters in the printer.

a From the control panel, navigate to the menu for the port settings. b Locate the menu for the serial port settings, and then adjust the settings, if necessary. c Save the settings.

2 From your computer, open the printers folder, and then select your printer.

3 Open the printer properties, and then select the COM port from the list.

4 Set the COM port parameters in Device Manager.

Use the Run dialog box to open the command prompt, and then type devmgmt.msc.

Changing port settings after installing an internal solutions port

Notes:

• If the printer has a static IP address, then do not change the conﬁguration.

• If the computers are conﬁgured to use the network name instead of an IP address, then do not change

the conﬁguration.

• If you are adding a wireless internal solutions port (ISP) to a printer previously conﬁgured for an Ethernet

connection, then disconnect the printer from the Ethernet network.

For Windows users

Open the printers folder.

2 From the shortcut menu of the printer with the new ISP, open the printer properties.

3 Conﬁgure the port from the list.

4 Update the IP address.

5 Apply the changes.

For Macintosh users

From System Preferences in the Apple menu, navigate to the list of printers, and then select + > IP.

2 Type the IP address in the address ﬁeld.

3 Apply the changes.

Checking the virtual display

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

Using M3150 94

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Check the virtual display that appears at the top left corner of the screen.

The virtual display works as an actual display would work on a printer control panel.

Conﬁguring

You can determine how you would like to be notiﬁed when supplies run nearly low, low, very low, or reach their end‑of‑life by setting the selectable alerts.

Notes:

supply

notiﬁcations

from the Embedded Web Server

• Selectable alerts can be set on the toner cartridge, imaging unit, and maintenance kit.

• All selectable alerts can be set for nearly low, low, and very low supply conditions. Not all selectable

alerts can be set for the end‑of‑life supply condition. E‑mail selectable alert is available for all supply conditions.

• The percentage of estimated remaining supply that prompts the alert can be set on some supplies for

some supply conditions.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Print Settings > Supply Notiﬁcations.

3 From the drop‑down menu for each supply, select one of the following notiﬁcation options:

Notiﬁcation Description

O The normal printer behavior for all supplies occurs.

E‑mail Only The printer generates an e‑mail when the supply condition is reached. The status of

the supply appears on the menus page and status page.

Warning The printer displays the warning message and generates an e‑mail about the status

of the supply. The printer does not stop when the supply condition is reached.

Continuable Stop

Non Continuable Stop

The printer generates an e-mail about the status of the supply when supply notiﬁcation is enabled.

The printer stops when some supplies become empty to prevent damage.

The printer stops processing jobs when the supply condition is reached, and the user needs to press a button to continue printing.

1,2

The printer stops processing jobs when the supply condition is reached. The supply must be replaced to continue printing.

4 Click Submit.

Modifying

conﬁdential

print settings

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Using M3150 95

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Security >

Conﬁdential

Print Setup.

3 Modify the settings:

• Set a maximum number of PIN entry attempts. When a user exceeds that number, all of the jobs for that

user are deleted.

• Set an expiration time for

all of the jobs for that user are deleted.

conﬁdential

print jobs. When a user has not printed the jobs within that time,

4 Click Submit to save the modiﬁed settings.

Copying printer settings to other printers

Note: This feature is available only in network printers.

1 Open a Web browser, and then type the printer IP address in the address

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Copy Printer Settings.

3 To change the language, select a language from the drop‑down menu, and then click Click here to submit

language.

ﬁeld.

4 Click Printer Settings.

5 Type the IP addresses of the source and target printers.

Note: If you want to add or remove target printers, then click Add Target IP or Remove Target IP.

6 Click Copy Printer Settings.

Creating a printer control panel PIN

1 Open a Web browser, and then type the printer IP address in the address

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > Security > Panel PIN Protect.

ﬁeld.

Using M3150 96

3 From the Create User PIN or Create Admin PIN section, enter your PIN.

Note: Your can enter up to 16 digits for your PIN.

4 Click Modify.

5 From any menu in the Administrative Menus, Management, or Function Access sections, select User PIN

Protected, Admin PIN Protected, or Admin PIN and User PIN Protected.

Note: Using Admin PIN, you can still access a menu assigned with User PIN.

6 Click Submit.

If you try to access a PIN‑protected menu from the printer control panel, then the printer will require you to enter the PIN.

Note: After you enter the last digit of the PIN, make sure to press than three seconds.

from the printer control panel for more

Printing a menu settings page

From the home screen, navigate to:

> Reports > Menu Settings Page

Printing a network setup page

If the printer is attached to a network, then print a network setup page to verify the network connection. This page also provides important information that aids network printing conﬁguration.

1 From the home screen, navigate to:

> Reports > Network Setup Page

2 Check the

If the status is Not Connected, then the LAN drop may not be active, or the network cable may be malfunctioning. Consult a system support person for a solution, and then print another network setup page.

section of the network setup page, and

ﬁrst

conﬁrm

that the status is Connected.

Checking the status of parts and supplies

A message appears on the printer display when a replacement supply item is needed or when maintenance is required.

Checking the status of parts and supplies on the printer control panel

From the home screen, touch Status/Supplies > View Supplies.

Checking the status of parts and supplies from the Embedded Web Server

Note: Make sure the computer and the printer are connected to the same network.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Using M3150 97

Notes:

• View the printer IP address on the home screen. The IP address appears as four sets of numbers

separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Device Status > More Details.

Saving energy

Using Eco‑Mode

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings > Eco‑Mode > select a setting

Use To

O Use the factory default settings for all settings associated with Eco‑Mode. O supports the

performance speciﬁcations of the printer.

Energy Reduce energy use, especially when the printer is idle.

• Printer engine motors do not start until it is ready to print. You may notice a short delay before

the ﬁrst page is printed.

• The printer enters Sleep mode after one minute of inactivity.

Energy/Paper Use all the settings associated with Energy and Paper modes.

Plain Paper

• Enable the automatic two‑sided (duplex) feature.

• Tur n

print log features.

o

3 Click Submit.

Reducing printer noise

Enable Quiet Mode to reduce printer noise.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address on the printer home screen. The IP address appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings > Quiet Mode > select a setting

Using M3150 98

Use To

On Reduce printer noise.

Notes:

• Print jobs are processed at a reduced speed.

• Printer engine motors do not start until a

document is ready to print. There will be a short delay before the ﬁrst page is printed.

O Use factory default settings.

Note: This setting supports the performance speciﬁcations of the printer.

3 Click Submit.

Adjusting Sleep mode

1 From the home screen, navigate to:

> Settings > General Settings > Timeouts > Sleep Mode

2 In the Sleep Mode ﬁeld, select the number of minutes the printer is idle before it enters Sleep mode.

3 Apply the changes.

Using Hibernate mode

Hibernate is an ultra‑low‑power saving mode.

Notes:

• Three days is the default amount of time before the printer enters Hibernate mode.

• Make sure to wake the printer from Hibernate mode before sending a print job. A hard reset or a long

press of the Sleep button wakes the printer from Hibernate mode.

• If the printer is in Hibernate mode, then the Embedded Web Server is disabled.

1 From the home screen, navigate to:

> Settings > General Settings

2 To u ch Press Sleep Button or Press and Hold Sleep Button.

3 To u ch Hibernate > .

Setting Hibernate Timeout

Hibernate Timeout lets you set the amount of time the printer waits after a print job is processed before it goes into a reduced power state.

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address

ﬁeld.

Using M3150 99

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings > Timeouts.

3 From the Hibernate Timeout menu, select the number of hours, days, weeks, or months you want for the

printer to wait before it goes into a reduced power state.

4 Click Submit.

Using the printer control panel

1 From the printer control panel, navigate to:

> Settings > General Settings > Timeouts > Hibernate Timeout

2 Select the amount of time the printer waits after a print job is processed before it enters Hibernate mode.

3 To u ch .

Using Schedule Power Modes

Schedule Power Modes lets you schedule when the printer goes into a reduced power state or into the Ready state.

Note: This feature is available only in network printers or printers connected to print servers.

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Notes:

• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears

as four sets of numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Click Settings > General Settings > Schedule Power Modes.

3 From the Action menu, select the power mode.

4 From the Time menu, select the time.

5 From the Day(s) menu, select the day or days.

6 Click Add.

Adjusting the brightness of the printer display

To save energy, or if you have trouble reading from the display, adjust the brightness of the display.

Using the Embedded Web Server

1 Open a Web browser, and then type the printer IP address in the address ﬁeld.

Using M3150 100

Notes:

• The IP address is located on the upper portion of the home screen. It appears as four sets of

numbers separated by periods, such as 123.123.123.123.

• If you are using a proxy server, then temporarily disable it to load the Web page correctly.

2 Select Settings > General Settings.

3 In the Screen Brightness

enter the brightness percentage you want for the display.

ﬁeld,

4 Apply the changes.

Using the control panel

1 From the home screen, navigate to:

> Settings > General Settings

2 In the Screen Brightness ﬁeld, enter the brightness percentage you want for the display.

3 Apply the changes.

Restoring factory default settings

If you want to keep a list of the current menu settings for reference, then print a menu settings page before restoring the factory default settings. For more information, see

If you want a more comprehensive method of restoring the printer factory default settings, then perform the Wipe All Settings option. For more information, see

“Erasing non‑volatile memory” on page 102.

“Printing a menu settings page” on page 96.

From the home screen, navigate to:

> Settings > General Settings > Factory Defaults > Restore Now >

Lexmark M1100, M3100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Safety information

Conventions

Overview

Using this guide

Finding information about the printer

Selecting a location for the printer

Additional printer setup

Installing internal options

Available internal options

Accessing the controller board

Installing an optional card

Installing a memory card

Installing an Internal Solutions Port

Installing a printer hard disk

Removing a printer hard disk

Installing hardware options

Installing optional trays

Setting up the printer software

Installing the printer software

Adding available options in the print driver

Networking

Preparing to set up the printer on a wireless network

Connecting the printer using the Wireless Setup Wizard

Connecting the printer to a wireless network using the Embedded Web Server

Verifying printer setup

Using M1145

Learning about the printer

Using the printer control panel

Understanding the colors of the Sleep button and indicator lights

Attaching cables

Accessing the controller board

Loading paper and specialty media

Setting the paper size and type

Using the standard bin and paper stop

Loading trays

Loading the multipurpose feeder

Linking and unlinking trays

Linking and unlinking trays

Creating a custom name for a paper type

Assigning a custom paper type

Printing

Printing a document

Printing from a computer

Adjusting toner darkness

Printing from a mobile device

Printing from a mobile device using Mopria Print Service

Printing from a mobile device using Google Cloud Print

Printing from a mobile device using AirPrint

Printing from a mobile device using Lexmark Mobile Print

Storing print jobs in the printer

Printing held jobs

Printing information pages

Printing a font sample list

Printing a directory list

Canceling a print job

Canceling a print job from the printer control panel

Canceling a print job from the computer

Managing the printer

Checking the virtual display

Copying printer settings to other printers

Creating a printer control panel PIN

Printing a menu settings page

Printing a network setup page

Checking the status of parts and supplies

Checking the status of parts and supplies on the printer control panel

Checking the status of parts and supplies from the Embedded Web Server

Saving energy

Reducing printer noise

Adjusting Sleep mode

Using Hibernate mode

Setting Hibernate Timeout

Using Schedule Power Modes

Adjusting the brightness of the printer display

Restoring factory default settings

Securing the printer
