Menu Map
Page 1 of 4
Menu Map
Menus list
Device Print Bookmark Setup Paper
Preferences
Notifications
Group Lists
Alert Types
Anti‑Spam Logic Description
Suppressing Duplicate Alerts
Power Management
Information Sent to Lexmark
Accessibility
Restore Factory Defaults
Maintenance
Visible Home Screen Icons
Update Firmware
About This Printer
Network/Ports USB Drive Security Reports
Network Overview
Wireless
AirPrint
Direct Wi-Fi Printing
Ethernet
TCP/IP
IPv6
SNMP
IPSec
LPD
Configuration
HTTP/FTP
ThinPrint
USB
Parallel [x]
Serial
Layout
Finishing
Setup
Quality
Job Accounting
XPS
PDF
HTML
PostScript
PCL
PPDS
Flash Drive Print Login Methods
Add Bookmark
Add Folder
Delete
Certificate Management
TCP/IP Port Access
Schedule USB Devices
Security Audit Log
Login Restrictions
Confidential Print
Disk Encryption
Erase Temporary Data Files
Miscellaneous
Tray Configuration
Media Configuration
Bin Configuration
Menu Settings Page
Device
Print
Shortcuts
Network
Event Log Summary
Using the control panel
Menu Map
Page 2 of 4
Use the To
1 Display
• Show the status of the printer.
• Set up and operate the printer.
2 Home button Go to the home screen.
3 Keypad Enter numbers or symbols on the printer.
4 Power button
• Turn the printer on or o.
• Wake the printer from Sleep or Hibernate mode.
5 Stop or Cancel button Stop the current job.
6 Indicator light Check the status of the printer. For more information, see the “Understanding the colors of
the indicator light” topic.
7 Volume buttons Adjust the volume of the headset or speaker.
8 Headset or speaker port Attach a headset or speaker.
9 Back button Return to the previous screen.
Understanding the colors of the indicator light
Indicator light Printer status
O The printer is o or in Hibernate mode.
Blue The printer is ready or processing data.
Red The printer requires user intervention.
Using the home screen
When the printer is turned on, the display shows the home screen. Use the home screen buttons and icons to initiate
an action.
Menu Map
Page 3 of 4
Note: Your home screen may vary depending on your home screen customization settings, administrative setup, and
active embedded solutions.
Tou ch To
1 Change
Language
2 Status Supplies
Change the language on the printer display.
• Show a printer warning or error message whenever the printer requires intervention to
continue processing.
• View more information on the printer warning or message, and on how to clear it.
Note: You can also access this setting by touching the top section of the home screen.
3 Settings Access the printer menus.
Note: Make sure to enable the printer menus. From the Embedded Web Server, click Settings >
Device > Maintenance > Configuration Menu > Panel Menus > On.
4 Shortcuts Organize all shortcuts.
5 USB View, select, or print photos and documents from a flash drive.
6 Document
Manager
Access held jobs, bookmarks, and applications.
These settings may also appear on the home screen:
Tou ch To
Job Queue Show all current print jobs.
Note: You can also access this setting by touching the top section of the home
screen.
App Profiles Access profiles and applications.
Lock Device Prevent users from accessing any printer functions from the home screen.
Features
Feature Description
Menu Map
Page 4 of 4
Warning
Printer IP address
Example: 123.123.123.123
If an error condition occurs, then this icon appears. Touch the top of the home screen
to show the error message.
The IP address of your printer is at the top of the home screen. Use the IP address
to access the Embedded Web Server and remotely configure printer settings.
