Page 1
MS820e Series
Reliability. Security. Productivity.
MS826de
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc .). Class A products
are intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/domestic environments may cause
interference to radio communications and require corrective measures.
18KDO8089-1
Page 2
Lexmark MS820e Series
Large workgroups need maximum performance and the Lexmark MS820e Series delivers with a rst page as fast as 4 seconds
and output up to 66 pages per minute*. A 10.9 cm e-Task touch screen supports productivity-enhancing apps while Ultra High
Yield replacement toner** and exible input and output options keep things going for the longhaul.
Ready when you are
} Long-life fuser and imaging components extend uptime.
} Unison™ Toner replacement cartridges deliver up
to 55,000 pages** of high-quality printing. (see
specications per model)
} Steel frame and durable design stands up to heavy use
Get more done
and harsh environments.
} Powerful 1-GHz dual-core processor and up to 5 GB of
memory drives printing at up to 66 ppm.*
} Robust paper handling includes reliable feeding of a wide
range of media types and sizes, up to 4400 sheets of
standard input and optional nishing.
} Connect via Ethernet, USB, or simple mobile
printing options.
Interact with ease
} Intuitive 10.9 cm colour touch screen offers smooth,
tablet-like interaction with customisable convenience and
productivity apps.
} Front access to the paper path and power button means
you’ll virtually never have to access the back of the
device, allowing placement in or on cabinets.
} Innovative serviceability features, starting with single-
door access to parts and supplies, help you resolve
problems quickly.
Full-spectrum security
} Lexmark’s full-spectrum security architecture helps keep
your information safe—in the document, on the device and
over the network.
} Keypoint Intelligence - Buyers Lab honoured Lexmark
with a prestigious BLI PaceSetter award for Document
Imaging Security***.
Built for planet earth
} Energy management features reduce power consumption
in active use or sleep mode.
} Standard two-sided printing saves paper.
®
} Device is rated EPEAT
Silver and ENERGY STAR® certied.
} Recycle cartridges through the award-winning Lexmark
Cartridge Collection Programme (LCCP).
*Print and copy speeds measured in accordance with ISO/IEC 2473 4 and ISO/IEC 24735 respectively (ESAT). For more information see: ww w.lexmark.com/ISOspeeds.
**Average standard page yield value declared in accordance with ISO/IEC 19752. Ultra High Yield car tridge not available for all models.
***Award based on Western Europe data
lexmark.com
18KDO8089-1
2
Page 3
Lexmark MS820e Series
1 MS822de / MS826de with 10.9 cm
e-Task colour touch screen
41 x 428 x 510 mm
2 100-sheet multipurpose feeder
Dimensions included as part of base model
3 550-sheet tray
Dimensions included as part of base model
4 550-sheet tray
110 x 428 x 510 mm
5 2100-sheet tray
350 x 428 x 510 mm
6 Castor base
126 x 521 x 693 mm
Note 1: Support s up to 4 optional trays. For maximum paper input capacity, instal 3 optional 550-sheet trays and one optional 2100-sheet tray. When a 2100-sheet tray is
installed, it must be the bottom tray, and a castor base isrequired.
Note 2: Supports many output congurations, including: any combination of up to three output expanders and 4-bin let terboxes; OR staple nisher with 4-bin letterbox; OR
staple nisher with output expander; OR output expander with high capacity output expander; OR the staple, hole punch nisher; OR any single output option by itself.
When installing the optional stapler, it must always be on top. When in stalling the optional high capacity output expander, it must always be on thebottom.
Note 3: All measurements are shown as height x width x depth. For more information about supporte d congurations, refer to the Printer, Option and Stand Compatibility
Guide athttp://www.lexmark.com/publications/furniture_safety/
7 Staple, hole punch nisher
263 x 462 x 507 mm
8 Staple nisher
246 x 435 x 414 mm
9 Output expander
165 x 421 x 380 mm
10 4-Bin letterbox
272 x 421 x 384 mm
11 High capacity output expander
310 x 421 x 335 mm
12 250-sheet tray
80 x 428 x 510 mm
13 550-sheet lockable tray
110 x 428 x 510 mm
14 250-sheet lockable tray
80 x 428 x 510 mm
15 Swivel cabinet
263 x 476 x 600 mm
16 Adjustable printer stand
584.2 x 596.9 x 596.9 mm
17 Spacer to add additional height
110 x 428 x 510 mm
Standard
Optional
© 2018 Lexmark. All rights reser ved.
Lexmark, the Lexmark logo and Unison are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. AirPrint® and the AirPrint Logo
are trademarks of Apple, Inc. ENERGY STAR® is a U.S. registered mark. Google Cloud Print™ is a trademark of Google, Inc. MOPRIA®, the Mopria® Logo™ and the Mopria®
Alliance logos are trademarks, service marks, and certication marks of Mopria Alliance, In c. in the United States and other countries. All oth er trademark s are the proper ty
of their respective own ers.
This product includes software developed by the OpenSSL Project for use in the Open SSL Toolkit (http://www.openssl.org/).
lexmark.com
18KDO8089-1
®
3
Page 4
Product specications Lexmark MS822de Lexmark MS826de
Printing
Display
Print Speed: Up to
Time to First Page: As fast as
Print Resolution
Memory / Processor
Hard Disk
Recommended Monthly Page Volume
Maximum Monthly Duty Cycle: Up to
Supplies
Laser Cartridge Yields (up to)
Imaging Unit Estimated Yield: Up to
Cartridge(s) Shipping with Product
6
7
1
Paper Handling
Included Paper Handling
Optional Paper Handling
Paper Input Capacity: Up to
Paper Output Capacity: Up to
Media Types Supported
Media Sizes Supported
General Information
Standard Ports
Optional Network Ports / Optional
Local Ports
Noise Level: Operating
Specied Operating Environment
Product Guarantee
Size (mm - H x W x D) / Weight
4
2
3
1
Lexmark e-Task 4.3-inch (10.9 cm) colour touch screen Lexmark e-Task 10.9 cm (4.3-inch) colour touch screen
Black: 52 ppm Black: 66 ppm
Black: 4.5 seconds Black: 4.0 seconds
Black: 1200 Image Quality, 1200 x 1200 dpi, 2400 Image Quality, 300 x 300 dpi, 600 x 600 dpi
Standard: 1024 MB / Maximum: 5120 MB / Dual Core, 1000 MHz
Option available
3000 - 50000 pages 5000 - 100000 pages
250000 pages per month 350000 pages per month
7,500-page Cartridge, 15,000-page High Yield Cartridge 7,500-page Cartridge, 15,000-page High Yield Cartridge, 35,000-
page Extra High Yield Cartridge, 55,000-page Ultra High Yield
Cartridge
150000 pages, based on 3 average letter/A4-size pages per print job and ~ 5% coverage
11,000-page Starter Return Program Toner Cartridge
550-Sheet Input, 100-Sheet Multipurpose Feeder, 550-Sheet Output Bin, Integrated Duplex
250-Sheet Tray, 550-Sheet Tray, 2100-Sheet Tray, 250-Sheet
Lockable Tray, 550-Sheet Lockable Tray, 4-Bin Mailbox, Staple
Finisher, Staple Punch Finisher, High Capacity Output Expander,
Output Expander
550-Sheet Tray, 2100-Sheet Tray, 550-Sheet Lockable Tray, 4-Bin
Mailbox, Staple Finisher, Staple Punch Finisher, High Capacity
Output Expander, Output Expander
Standard: 650 pages 75 gsm bond / Maximum: 4400 pages 75 gsm bond
Standard: 550 pages 75 gsm bond / Maximum: 2550 pages 75 gsm bond
Card Stock, Dual Web Labels, Envelopes, Integrated Labels, Paper Labels, Plain Paper, Transparencies, Refer to the Card Stock &
10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal, Letter,
One Internal Card Slot, USB 2.0 Specication Hi-Speed Certied (Type B), Gigabit Ethernet (10/100/1000), Front USB 2.0 Specication
Marknet N8370 WiFi Option, MarkNet N8230 Fiber Ethernet Print
Server / Internal RS-232C serial, Internal 1284-B Bidirectional
Hi-Speed Certied port (Type A), Rear USB 2.0 Specication Hi-Speed Certied port (Type A)
Parallel
Label Guide.
Statement, Universal, Ocio, A6
Internal MarkNet N8350 802.11b/g/n Wireless / Internal RS-232C
serial, Internal 1284-B Bidirectional Parallel
Print: 57 dBA Print: 58 dBA
Humidity: 8 to 80% Relative Humidity, Temperature: 10 to 32°C (50 to 90°F), Altitude: 0 - 2896 Meters (9,500 Feet)
1-Year Onsite Repair, Next Business Day
441 x 428 x 510 mm / 25.6 kg
All information in this brochure is subject to change without notice. Lexmark is not liable for any errors or omissions. Some models
may be available without duplex.
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032,
etc.). Class A products are intended for use in non-residential/non-domestic environments. Use of a Class A product in
residential/domestic environments may cause interference to radio communications and require corrective measures.
1
Average standard page yield value declared in accordance with ISO/IEC 19752. 2”Recommende d Monthly Page Volume” is a range of pages that helps customers evaluate
Lexmark’s product offerings based on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per
month be within the stated range for optimum device performance, based on factors including: supplies replaceme nt inter vals, paper loading intervals, speed, and typical
customer usage.
provides a comparison of robustness in relation to other Lexmark printers and MFPs.
com/printerlicense for details.
of black-only printing and average print job complexity.
information see: www.lexmark.com/ISOspeeds.
com/regions for more details.
3
”Maximum Monthly Dut y Cycle” is dened as the maximum number of pages a device could d eliver in a month using a multishift operation. This metric
5
Actual Yield may vary based on other factors such as device spe ed, paper size and feed orientation, toner coverage, tray source, percentage
6
Print and copy speeds measured in accordance with ISO/IEC 24734 and ISO/IEC 24735 respectively (ESAT). For more
7
Product func tions only with replacement cartridges designed for use in a specic geographical region. See w ww.lexmark.
4
Printers are sold subject to cer tain license/agreement conditions. See www.lexmark.
