Page 1
MS820 Series
Reliability. Security. Productivity.
ENERGY STAR® certifcation is dn models only
MS823dn
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc .). Class A products are
intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/domestic environments may cause interference to
radio communications and require corrective measures.
Page 2
Lexmark MS820 Series
Satisfy large-workgroup requirements for performance, reliability and security with the Lexmark MS820 Series. They deliver a rst
page in as little as 4 seconds and print up to 70 pages per minute*. Robust paper handling, Ultra High Yield replacement toner** and
exible input and output options add up to uninterruptedproductivity.
Ready when you are
} Long-life fuser and imaging components extend uptime.
} Unison™ Toner replacement cartridges deliver up to
55,000 pages** of high-quality printing (see specications
per model).
} Steel frame and durable design stands up to heavy use and
harsh environments.
Get more done
} Powerful 1-GHz dual-core processor and up to 4.5 GB of
memory drives printing at up to 70 ppm.*
} Robust paper handling includes reliable feeding of a wide
range of media types and sizes, up to 4400 sheets of
standard input and optional nishing.
} Connect via Ethernet, USB, or simple mobile printing options.
Interact with ease
} 2.4-inch/6-cm color LCD lets you congure, interact and
monitor vital system information.
} Front access to the paper path and power button means
you’ll virtually never have to access the back of the device,
allowing placement in or on cabinets.
} Innovative serviceability features, starting with single-
door access to parts and supplies, help you resolve
problems quickly.
Full-spectrum security
} Lexmark’s full-spectrum security architecture helps keep
your information safe—in the document, on the device and
over the network.
} Keypoint Intelligence - Buyers Lab honored Lexmark
with a prestigious BLI PaceSetter award for Document
Imaging Security***.
Built for planet earth
} Energy management features reduce power consumption in
active use or sleep mode.
} Models with standard two-sided printing save paper.
®
} All models with two-sided printing are rated EPEAT
and ENERGY STAR® certied.
Silver
} Recycle cartridges through the award-winning Lexmark
Cartridge Collection Program (LCCP).
*Print and copy speeds measured in accordance with ISO/IEC 2473 4 and ISO/IEC 24735 respectively (ESAT). For more information see: ww w.lexmark.com/ISOspeeds.
**Average standard page yield value declared in accordance with ISO/IEC 19752. Ultra High Yield car tridge not available for all models.
***Award based on North America and/or Western Europe data
lexmark.com
2
Page 3
Lexmark MS820 Series
1 Printer with 2.4-inch (6 cm) display
17.5 x 16.85 x 20.1 inches
445 x 428 x 510 mm
2 100-sheet multipurpose feeder
Dimensions included as part of base model
3 550-sheet tray
Dimensions included as part of base model
4 550-sheet tray
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
5 2100-sheet tray
13.8 x 16.85 x 20.1 inches
350 x 428 x 510 mm
6 Caster base
5 x 20.5 x 27.3 inches
126 x 521 x 693 mm
Note 1: Support s up to 4 optional trays. For maximum paper input capacity, install 3 optional 550-sheet trays and one option al 2100-sheet tray. When a 2100-sheet tray is
installed, it must be the bottom tray, and a caster base isrequired.
Note 2: Supports many output congurations, including: any combination of up to three output expanders and 4-bin mailboxes; OR staple nisher with 4-bin mailb ox; OR staple
nisher with output expander; OR output expander with high capacit y output expander; OR the staple, hole punch nisher; OR any single output option by itself. When installing
the optional stapler, it must always be on top. W hen installing the optional high capacity output expander, it must always be on the bottom.
Note 3: All measurements are shown as height x width x depth. For more information about supporte d congurations, refer to the Printer, Option and Stand Compatibility Guide
athttp://www.lexmark.com/publications/furniture_safety/
7 Staple, hole punch nisher
10.3 x 18.2 x 20.0 inches
263 x 462 x 507 mm
8 Staple nisher
9.7 x 17.1 x 16.3 inches
246 x 435 x 414 mm
9 Output expander
6.5 x 16.6 x 15.0 inches
165 x 421 x 380 mm
10 4-Bin mailbox
10.7 x 16.6 x 15.1 inches
272 x 421 x 384 mm
11 High capacity output expander
12.2 x 16.6 x 13.2 inches
310 x 421 x 335 mm
12 250-sheet tray
3.2 x 16.85 x 20.1 inches
80 x 428 x 510 mm
13 550-sheet lockable tray
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
14 250-sheet lockable tray
3.2 x 16.85 x 20.1 inches
80 x 428 x 510 mm
15 Swivel cabinet
10.4 x 18.7 x 23.6 inches
263 x 476 x 600 mm
16 Adjustable printer stand
23 x 23.5 x 23.5
584.2 x 596.9 x 596.9
17 Spacer to add additional height
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
Standard
Optional
© 2018 Lexmark. All rights reser ved.
Lexmark, the Lexmark logo and Unison are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. AirPrint® and the AirPrint Logo
trademarks of Apple, Inc. ENERGY STAR® is a U.S. registered mark. Google Cloud Print™ is a trademark of Google, Inc. MOPRIA®, the Mopria® Logo™ and the Mopria® Alliance
logos are trademarks, service marks, and certication marks of Mopria Alliance, Inc . in the United States and other countries. All other trademarks are the property of their
respective owners.
This product includes software developed by the OpenSSL Project for use in the Open SSL Toolkit (http://www.openssl.org/).
lexmark.com
®
are
3
Page 4
Product specications Lexmark MS821dn Lexmark MS823dn Lexmark MS825dn
Printing
Display
Print Speed: Up to
Time to First Page: As fast as
Print Resolution
Memory / Processor
Hard Disk
Recommended Monthly Page Volume
Maximum Monthly Duty Cycle: Up to
Supplies
Laser Cartridge Yields (up to)
Imaging Unit Estimated Yield: Up to
Cartridge(s) Shipping with Product
6
7
1
Paper Handling
Included Paper Handling
Optional Paper Handling
Paper Input Capacity: Up to
Paper Output Capacity: Up to
Media Types Supported
Media Sizes Supported
General Information
Standard Ports
Optional Network Ports / Optional
Local Ports
Noise Level: Operating
Specied Operating Environment
Limited Warranty - See Statement of
Limited Warranty
Size (in. - H x W x D) / Weight (lb.)
4
Black: 55 ppm Black: 65 ppm Black: 70 ppm
Black: 4.5 seconds Black: 4.2 seconds Black: 4.0 seconds
Black: 1200 Image Quality, 1200 x 1200 dpi, 2400 Image Quality, 300 x 300 dpi, 600 x 600
Standard: 512 MB / Maximum: 4608 MB / Dual Core, 1000 MHz
2
3
7,500-page Cartridge, 15,000-page Black
3000 - 50000 pages 5000 - 75000 pages 5000 - 100000 pages
250000 pages per month 300000 pages per month 350000 pages per month
High Yield Cartridge
150000 pages, based on 3 average letter/A4-size pages per print job and ~ 5% coverage
1
550-Sheet Input, 100-Sheet Multipurpose Feeder, 550-Sheet Output Bin, Integrated Duplex
250-Sheet Tray, 550-Sheet Tray, 2100-Sheet Tray, 250-Sheet Lockable Tray, 550-Sheet
Lockable Tray, 4-Bin Mailbox, Staple Finisher, Staple Punch Finisher, High Capacity Output
Expander, Output Expander
Standard: 650 pages 20 lb or 75 gsm bond / Maximum: 4400 pages 20 lb or 75 gsm bond
Standard: 550 pages 20 lb or 75 gsm bond / Maximum: 2550 pages 20 lb or 75 gsm bond
Card Stock, Dual Web Labels, Envelopes, Integrated Labels, Paper Labels, Plain Paper, Transparencies, Refer to the Card Stock & Label
10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal, Letter, Statement,
One Internal Card Slot, USB 2.0 Specication Hi-Speed Certied (Type B), Gigabit Ethernet (10/100/1000), Front USB 2.0 Specication Hi-
Marknet N8370 WiFi Option, MarkNet N8230 Fiber Ethernet Print Server / Internal RS-232C serial, Internal 1284-B Bidirectional Parallel
Print: 57 dBA Print: 58 dBA
Humidity: 8 to 80% Relative Humidity, Temperature: 10 to 32°C (50 to 90°F), Altitude: 0 - 2896 Meters (9,500 Feet)
2.4-inch (60 mm) Color LCD display
dpi
Black: 1200 Image Quality, 1200 x 1200
dpi, 300 x 300 dpi, 600 x 600 dpi, 2400
Enhanced Mode
Option available
7,500-page Cartridge, 15,000-page High Yield Cartridge, 35,000-page Extra High Yield
Cartridge, 55,000-page Ultra High Yield Cartridge
11,000-page Starter Return Program Toner Cartridge
550-Sheet Tray, 2100-Sheet Tray, 550-Sheet
Lockable Tray, 4-Bin Mailbox, Staple
Finisher, Staple Punch Finisher, High
Capacity Output Expander, Output Expander
Guide.
Universal, Ocio, A6
Speed Certied port (Type A)
1-Year Advanced Exchange, Next Business Day
17.5 x 16.85 x 20.1 in. / 56.0 lb.
All information in this brochure is subject to change without notice. Lexmark is not liable for any errors or omissions. Some models may
be available without duplex.
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc.).
Class A products are intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/
domestic environments may cause interference to radio communications and require corrective measures.
1
Average standard page yield value declared in accordance with ISO/IEC 19752. 2”Recommende d Monthly Page Volume” is a range of pages that helps customers evaluate
Lexmark’s product offerings based on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per
month be within the stated range for optimum device performance, based on factors including: supplies replaceme nt inter vals, paper loading intervals, speed, and typical
customer usage.
comparison of robustness in relation to other Lexmark printers and MFPs.
for details.
and average print job complexity.
lexmark.com/ISOspeeds.
3
”Maximum Monthly Dut y Cycle” is dened as the maximum number of pages a device could d eliver in a month using a multishift operation. This metric provides a
5
Actual Yield may vary based on other factors such as device spe ed, paper size and feed orientation, toner coverage, tray source, percentage of black-only printing
6
Print and copy speeds measured in accordance with ISO/IEC 24734 and ISO/IEC 24735 respectively (ESAT). For more inform ation see: www.
7
Product func tions only with replacement cartridges designed for use in a specic geographical region. See w ww.lexmark.com/regions for more details.
4
Printers are sold subject to cer tain license/agreement conditions. See www.lexmark.com/printerlicense
lexmark.com
4
