Page 1
CS622de
Reliability. Security. Productivity.
CS622de
This is a Class A device according to international electromagnetic emissions standards ( i.e. FCC Rules, EN 55022/EN 55032, etc.). Class A products are
intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/domestic environments may cause interference to
radio communications and require corrective measures.
Page 2
Lexmark CS622de
The Lexmark CS622de’s e-Task touch screen opens a world of convenience and productivity apps, while high-yield replacement toner
and tools that minimize toner consumption help you control the cost of color. And a robust paper feeding system supports printing at
up to 40 pages perminute*.
Interact with ease
} 4.3-inch/10.9-cm e-Task touch screen comes with
convenience and productivity apps and is customizable to
meet your needs.
} Front USB port allows walk-up printing from popular le
formats without a computer.
} Compact footprint allows exible placement in
more locations.
Ready when you are
} 1-GHz dual-core processor and 1 GB memory drives printing
at up to 40 ppm*.
} Steel frame and durable design stands up to heavy use and
harsh environments.
} Long-life fuser and imaging components extend uptime.
} Unison™ Toner replacement cartridges deliver up to 7000
color and 10,500 monochrome pages**.
} Keep printing in black even when color toner is empty.
} Connect easily via Ethernet, USB, or simple mobile
printing options.
Full-spectrum security
} Lexmark’s full-spectrum security architecture helps keep
your information safe—in the document, on the device and
over the network.
} Keypoint Intelligence - Buyers Lab honored Lexmark
with a prestigious BLI PaceSetter award for Document
Imaging Security***.
Color that keeps saving
} PANTONE® calibration, embedded color sample pages and
Lexmark Color Replacement produce accurate, professional
color output in-house.
} Save toner with suite of tools that let you choose when and
how much color to print.
Input that works
} Reliable, exible media handling supports cardstock, small
media, and envelopes from the main tray or a convenient
single-sheet feeder.
} 251 pages of standard input can grow to 1451.
*Print and copy speeds measured in accordance with ISO/IEC 2473 4 and ISO/IEC 24735 respectively (ESAT). For more information see: www.lexmark.com/ISOspeeds.
**Average continuous black or continuous composite color (CMY) declared yield in one-sided (simplex) mode up to this number of pages in accordance with ISO/IEC 19798. Actual
yield will vary considerably based upon many factors. See www.lexmark.com/yields for more information.
***Award based on Nor th America and/or Western Europe data
Built for planet earth
} Energy management features reduce power consumption in
active use or sleep mode.
} Standard two-sided printing saves paper.
} Recycle cartridges through the award-winning Lexmark
Cartridge Collection Program (LCCP).
lexmark.com
2
Page 3
Lexmark CS622de
1 Printer with 4.3-inch/10.9-cm e-Task color touch screen
12.1 x 17.4 x 16.6 inches
308 x 442 x 421 mm
2 650-sheet duo tray
5.2 x 16.7 x 16.4 inches
133 x 424 x 416 mm
3 Keyboard
1 x 11 x 5.1 inches
25 x 280 x 130 mm
4 550-sheet tray
5.2 x 16.7 x 16.4 inches
133 x 424 x 416 mm
Adjustable printer stand (not shown)
20.5 x 25.7 x 24.6 inches
521 x 653 x 625 mm
Swivel cabinet (not shown)
10.4 x 18.7 x 23.6 inches
263 x 476 x 600 mm
Standard
Optional
Note 1: Supports one optional 650-sheet duo tray; or one optional 650-sheet duo tray and one optional 550-sheet tray with the 650-sheet duo tray ontop.
Note 2: All measurements are shown as height x width x depth. For more information about supported congurations, refer to the Printer, Option and Stand Compatibility Guid e
athttp://www.lexmark.com/publications/furniture_safety/
© 2018 Lexmark. All rights reserved.
Lexmark, the Lexmark logo and Unison are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. AirPrint and the AirPrint Logo are
trademarks of Apple, Inc. Google Cloud Print is a trademark of G oogle, Inc. MOPRIA®, the Mopria® Logo™ and the Mopria® Alliance logos are trademarks, service marks, and
certication marks of Mopria Alliance, Inc. in the United State s and other countries. PANTONE®, PANTONE® Goe™ and other Pantone, Inc. trademarks are property of Pantone,
Inc. All other trademarks are the property of their respective owners.
This product includes software developed by the OpenSSL Project for use in the Open SSL Toolkit (http:// ww.openssl.org/).
lexmark.com
3
Page 4
Product specications Lexmark CS622de
Printing
Display
Print Speed: Up to
Time to First Page: As fast as
Print Resolution
Memory / Processor
Hard Disk
Recommended Monthly Page Volume
Maximum Monthly Duty Cycle: Up to
Supplies
Laser Cartridge Yields (up to)
Photoconductor Estimated Yield: Up to
Cartridge(s) Shipping with Product
6
2
3
7
1
5
1
Paper Handling
Included Paper Handling
Optional Paper Handling
Paper Input Capacity: Up to
Paper Output Capacity: Up to
Media Types Supported
Media Sizes Supported
General Information
Standard Ports
Optional Network Ports
Noise Level: Operating
Specied Operating Environment
Limited Warranty - See Statement of Limited
Warranty
Size (in. - H x W x D) / Weight (lb.)
4
Black: 1200 x 1200 dpi, 4800 Color Quality (2400 x 600 dpi) / Color: 1200 x 1200 dpi, 4800 Color Quality (2400 x 600 dpi)
5,000-page Color (CMY) High Yield Cartridges, 8,500-page High Yield Cartridge, 7,000-page Color (CMY) Extra High Yield
Cartridges, 1,400-page Colour (CMY) Cartridges, 2,000-page Black Cartridge, 10,500-page Black Extra High Yield Cartridge
125,000 pages, based on 3 average letter/A4-size pages per print job and ~ 5% coverage
2,000-page color (CMY) Return Program Toner Cartridges, 3,000-page Black Starter Return Program Toner Cartridge
250-Sheet Input, 125-Sheet Output Bin, Integrated Duplex, Single-Sheet Manual Feed
Standard: 250+1 pages 20 lb or 75 gsm bond / Maximum: 1450+1 pages 20 lb or 75 gsm bond
Standard: 125 pages 20 lb or 75 gsm bond / Maximum: 125 pages 20 lb or 75 gsm bond
Card Stock, Envelopes, Paper Labels, Plain Paper, Vinyl Labels, Refer to the Card Stock & Label Guide.
10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, C5 Envelope, DL Envelope, Hagaki Card, Executive, Folio, JIS-B5, Legal, Letter,
USB 2.0 Specication Hi-Speed Certied (Type B), Gigabit Ethernet (10/100/1000), Front USB 2.0 Specication Hi-Speed
Certied port (Type A), Rear USB 2.0 Specication Hi-Speed Certied Port (Type A)
Humidity: 8 to 80% Relative Humidity, Temperature: 10 to 32°C (50 to 90°F), Altitude: 0 - 2896 Meters (9,500 Feet)
Lexmark e-Task 4.3-inch (10.9 cm) color touch screen
Black: 40 ppm / Color: 40 ppm
Black: 9 seconds / Color: < 7 seconds
Standard: 1024 MB / Maximum: 1024 MB / Dual Core, 1000 MHz
Option available
1500 - 10000 pages
100000 pages per month
550-Sheet Tray, 550-Sheet Duo Tray with 100-Sheet Feeder
Statement, Universal, Ocio, A6
MarkNet N8352 802.11b/g/n Wireless, Marknet N8372 WiFi Option
Print: 51 dBA
1-Year Exchange, Onsite Service, Next Business Day
12.1 x 17.4 x 16.6 in. / 46 lb.
All information in this brochure is subject to change without notice. Lexmark is not liable for any errors or omissions.
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc.).
Class A products are intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/domestic
environments may cause interference to radio communications and require corrective measures.
1
Average continuous black or continuous composite CMY declared cartridge yield up to this number of standard pages in accordance with ISO/IEC 19798. 2”Recommended
Monthly Page Volum e” is a range of pages that helps customers evaluate Lexmark’s product offerings based on the average number of pages customers plan to print on the
device each month. Lexmark recommends that the number of pages per month be within th e stated range for optimum device performance, based on factors including: supplies
replacement intervals, paper loading intervals, speed, and typical customer usage. 3”Maximum Monthly Duty Cycle” is dened as the maximum number of pages a device could
deliver in a month using a multishift operation. This metric provides a comparison of robustness in relation to other Lexmark printers and MFPs. 4Printers are sold subject to
certain license/agreement conditions. See www.lexmark.com/printerlicense for details. 5Actual Yield may vary based on other factor s such as device speed, paper size and feed
orientation, toner coverage, tray source, percentage of black-only printing and average print job complexity. 6Print and copy speeds measured in accordance with ISO/IEC 24734
and ISO/IEC 24735 respectively (ESAT). For more information see: www.lexmark.com/ISOspeeds. 7Product functions only with replacement cartridges designed for use in a spe cic
geographical region. See www.lexmark.com/regions for more details.
