Lexmark 22Z0091 Datasheet

Lexmark C950de Colour Printer

Smart printing. Brilliant colour.

Lexmark C950de Colour Printer

Designed for your busy workgroup, the Lexmark C950de features professional
quality A3 colour printing, flexible features, outstanding media handling, an
intuitive touch screen and easy-to-use workflow solutions.

Colour Touch screen Solutions Up to 50 ppm

Duplex Network

32 x 122 cm

(12.6 x 48 inch)

Lexmark C950de Key Features

6

4

1

2

5

3

Lexmark C950de colour printer shown with
optional 2,520-Sheet Tandem Tray Module,
Booklet Finisher and 2,000-Sheet High
Capacity Feeder.

Features to optimise your work

1) Intuitive colour touch screen

The large 10.9-cm (4.3-inch) colour touch screen
allows you to operate your printer with ease
through intuitive navigation and easy access to
workflow solutions and shortcuts.

4) Exceptional media handling

Ultra-reliable paper feeding lets you load up to six
different types of media, including sizes up to 32
x 122 cm (12.6 x 48 inch) and weights up to 300
gsm.

2) Direct USB

The front USB port allows convenient walk-up
printing, and is compatible with many printable
image file formats.

5) Advanced finishing options

Easily create professional output in-house with
flexible finishing options, including multi-position
stapling, hole punch, expanded output stacking
and booklet capability.

3) Flexible input capacity

Choose the configuration that best fits your needs,
up to a maximum of 5,140 sheets.

6) Lexmark solutions

Reduce unnecessary printing and simplify
work processes through solutions applications
preloaded on your device. Choose additional
Lexmark solutions to fit your unique workflow
needs.

Lexmark C950de Overview

Outstanding Colour Output

Make a lasting impression on your customers and do more printing in-house with
vibrant, professional-quality output on a wide variety of media. With the advanced
technology of the C950de, you’ll get high-performance A3 (tabloid) printing capability
that produces consistent colour from the first page to the last.

l 

1200 x 1200 print resolution for rich vibrant colours and crisp black text.

l 

PANTONE® calibration for consistent colour tones.

l 

Named Colour Replacement for easy colour matching.

l 

Lexmark Colour Care Technology to manage colour use and control costs.

l 

Create professional collateral materials ranging from saddle stitch booklets to folded
brochures on media up to A3 (tabloid).

Productive and Intuitive

The Lexmark C950de combines high-performance printing with easy-to-use features
and time-saving workflow applications designed to boost your productivity.

l 

Print at speeds of up to 50 ppm black and 45 ppm colour: time to first page as
quick as 5.2 seconds.

l 

Easy to navigate 10.9-cm (4.3-inch) colour touch screen provides audible feedback
to make completing tasks intuitive.

l 

Preloaded applications help you drive greater efficiency in your workflow.

l 

Print Preview and Post Process Job Changes allow you to duplex, add finishing or
select individual pages for printing.

Built for Business

The Lexmark C950de features a robust print engine designed to handle the most
demanding workloads with the advanced features and flexibility you need to run your
business.

l 

Strong, multilayered security features help protect your devices, your documents,
your information and your network infrastructure.

l 

Robust connectivity makes it easy to integrate into almost any network environment.

l 

Simplify device monitoring and administration through the embedded web server,
Lexmark Universal Print Driver and Lexmark MarkVision Enterprise.

l 

Process graphic-intensive jobs easily with 1.2 GHz processor and 1GB RAM
standard.

l 

Choose from multiple input options to expand capacity up to 5,140 sheets.

l 

Easy-to-replace aftermarket cartridges provide yields of up to 38,000² pages black
and up to 24,000² pages colour.

True. Image. Always.

Lexmark is dedicated to designing and manufacturing products that deliver
exceptional quality and reliability. Maximise the return on your investment, optimise
the performance of your Lexmark printing equipment and make a lasting impression
by always insisting on Lexmark Genuine Supplies, Service and Parts. The C950de
is backed by Lexmark’s 1-Year Limited Warranty; extended warranty plans are also
available.

Lexmark C950de Productivity Made Easy

The right touch

The Lexmark e-Task colour touch screen is a key access
point to your printer. The customisable 10.9-cm (4.3-inch)
interface gives you the ability to preview thumbnails of
documents prior to printing, as well as to change print
jobs at the device. You can even view, select and print
specific pages within a document directly from the touch
screen. Easy-to-use, intuitive navigation provides fast
access to the functions, shortcuts and workflows you use
most. New interactive sensory features provide audible
feedback, helping to guide you through each operation,
confirming a touch has registered and indicating an action
is transpiring.

Solutions

4

Save time and money through solutions

The C950de features the Lexmark Embedded Solutions Framework, our platform that enables you to add a wide range of software
applications directly onto the device. Solutions are designed with your productivity in mind, helping you streamline—or even
eliminate—paper intensive business processes.

The following solutions are preloaded on the Lexmark C950de. A diverse portfolio of additional Lexmark solutions is
available to help accommodate your workflow needs.

Forms and Favourites

Eliminate waste and inefficiencies associated with pre­printed forms. Store frequently printed forms, marketing
materials or other documents online, then print them
on demand.

Change Language³

Easily switch the language displayed on the touch
screen – 18 languages supported.

Eco-Settings

Choose from multiple print settings that help reduce
energy, paper and toner consumption.

Showroom

Display a customisable, scrolling slideshow on the
colour touch screen to promote your business or
products, or to communicate important messages to
your customers or employees.

Easy device management

Manage your output environment effectively with Lexmark MarkVision Enterprise.
This free browser-based software gives you complete visibility into your entire fleet of
network printers and MFPs regardless of manufacturer. MarkVision Enterprise makes it
easy for administrators to configure, track, view, troubleshoot and proactively manage
your devices throughout their lifecycle, from the moment you connect them to the
network until the day you retire them.

Lexmark C950de Highlights

Print Less. Save More.

Print less? This may seem like a
surprising message for a company
dedicated solely to printing. But
when you consider that businesses
spend, on average, up to 6% of their
turnover on printing, and that active
print management can cut office print
costs by up to 30%¹, it makes a lot of
sense. Lexmark products, solutions and
services provide innovative ways to save
you time, drive down costs and reduce
your impact on the environment. We are
committed to helping you print less and
save more.

Desired Colour

PANTONE 346 C

Without

Named Colour

With Named Colour

Replacement

Consistent colour, every time

Produce professional documents confidently in-house knowing that the named
colours of your company’s brand and logo will print accurately and consistently
every time. Through Lexmark Named Colour Replacement, included standard
with your device, users can enter specific colour values for easy colour matching,
including PANTONE® Colour and colours in the DIC Colour Guide.

Protecting your information

From the data travelling through your network to the pages being printed, multilayered
security features and built-in capabilities help you protect your devices, documents,
data and network.

l 

Supports a variety of user authentication and authorisation controls.

l 

Card reader option allows users to authenticate with proximity or swipe cards.

l 

Advanced hard disk encryption protects sensitive data on the printer’s optional disk
drive.

l 

Automatic, scheduled or manual disk wiping removes latent data (hard disk optional).

l 

IPSec, SNMPv3 and 802.1x network security are supported.

l 

Security-audit logging tracks and identifies security risks.

Eco-responsible printing

The C950de makes it easy for you to print responsibly. Features include duplex to
save paper, Eco-Mode to reduce paper and toner consumption, and a Sleep Button
with hibernate mode to help you save energy. The C950de also helps you save energy
through its instant warm-up fuser and specially designed toner, which fuses at a low
temperature.

Lexmark C950de Ordering Information

Lexmark C950de

Integrated Duplex

Booklet Finisher

100-Sheet Multipurpose

Feeder

Feeder

Compatible with the C950de

Part # Laser Toner/Print Cartri dge

C950X2KG C950 Black Ex tra High Yield Toner Cartridge (38K)
C950X2CG C950 Cyan Extr a High Yield Toner Ca rtridge (24K)
C950X2MG C950 Magenta Extra High Yield Toner Cartridge (24K)
C950X2YG C950 Yellow Extra H igh Yield Toner Cartri dge (24K)
C950X71G C950, X950/2/4 Photoconductor Unit 1-Pac k
C950X73G C950, X950/2/4 Photoconductor Unit 3-Pac k
C950X76G C950, X950/2/4 Waste Toner Bottle
25A0013 Staple Cartr idges (3 pack)
21Z0357 Saddle St aple Cartridges (4 pack )

Part # Memory Opti ons

1025041 256MB DDR2- DRAM
1025042 512MB DDR2- DRAM
1025043 1024MB DDR2 -DRAM
14F0245 256MB F lash Card
27X0014 160+ GB Har d Disk

Part # Application S olutions

22Z0183 C950 Card for IPDS
22Z0184 C950 Card for PRESCRIBE Emulatio n
22Z0182 C950 Forms and Bar Code Card
57X9000 Lexmark Pri ntCryption Card

Part # Connectivity

27X0030 MarkNet N82 50 802.11b/g/n Wireless Pri nt Server
14F0037 MarkNet N8120 Gigabit Ethernet Print Server
14F0042 MarkNet N8130 Fiber Ethernet 100B aseFX, 10BaseFL Print Serv er

14T0220 MarkNet N 7020e Gigabit Ethernet P rint Server
1021294 USB (2 Mete r) Cable
14F0000 Parallel 1284-B Interface Card
1021231 Parallel (10 ’) Cable
14F0100 RS-232C Serial Interface Card

Part # User Replacea ble Parts

40X7569 C950, X95x Fus er Maintenance Kit, 320K, 220-24 0V
40X7540 C950, X95x 160 K Maintenance Kit

Standard

Optional

2,520-Sheet Tandem Tray Module2,000-Sheet High Capacity

Lexmark C950de Ordering Information

Lexmark C950de

Part # Model

22Z0091 Lexmark C 950de

Part # Paper Handlin g

22Z0014 C950, X95x 25 20-Sheet Tandem Tray Modul e
22Z0013 C950, X95x 3x 520-Sheet Drawer Stand
22Z0012 C950, X95x 52 0-Sheet Drawer Stand
22Z0015 C950, X95x 20 00-Sheet High Capacity Feeder
22Z0175 C950, X95x 35 00-Sheet Finisher (4-Hole )
22Z0176 C950, X95x Bo oklet Finisher (4-Hole)

Part # Extended Warranties

2354207P C 950 2-Years Total Onsi te Service, Next Business Day
2354208P C 950 3-Years Total Onsi te Service, Next Business Day
2354209P C 950 4-Years Total Onsi te Service, Next Business Day
2354211P C 950 1-Year Onsite Service Rene wal, Next Business Day

Part # NC

2354214 C950 Instal lation Service

In the box

Lexmark C950 de colour pr inter, Up to 12,000*-page
colour (CMY) toner cartr idges, Up to 19,000*-page
black toner cartridge, Black , cyan, magenta,and
yellow Imag ing units, Softw are and Docum entation
CD, Power Cord(s), Setup Guides (network and
local attac hment), Statemen t of limited guarantee,
Lexmark Cart ridge Collec tion Program information
*Average cont inuous black or continuou s composite
CMY declared cartridge y ield up to th is number of
standard pa ges in accord ance with IS O/IEC 19798.

Lexmark C950de Product Specifications

Lexmark C950de

Printing
Print Technology

Print Speed (A4 mono): Up to

Print Speed (A4 colour): Up to

Time to First Page (Black)

Time to First Page (Colour)

Print Resolution, Black

Print Resolution, Colour

Memory, standard

Memory, maximum

Print Noise Level, Operating

Maximum Monthly Duty Cycle: Up to

Recommended Monthly Page Volume

Supplies
Supplies Yield

Paper Handling
Paper Handling Standard

Paper Handling Optional

Paper Input Capacity, Standard: Up to

Paper Input Capacity, Maximum: Up to

Media Types Supported

Colour LED

50 ppm

45 ppm

As fast as 5.2 seconds

as fast as 7.7 seconds

1200 x 1200 dpi, 2400 Image Quality

1200 x 1200 dpi, 2400 Image Quality

1024 MB

2048 MB

53 dBA

225000 pages per month

4000 - 33000 Pages

Average continuous black or continuous composite CMY declared cartridge yield up to this number of standard pages

in accordance with ISO/IEC 19798., 24,000*-page Colour (CMY) Toner Cartridges, 38,000*-page Black Toner Cartridge

500-Sheet Output Bin, Integrated Duplex, 100-Sheet Multipurpose Feeder, 520-Sheet Input Tray

2,000-Sheet High Capacity Feeder, 3,500-Sheet Finisher, 3 x 520-Sheet Drawer Stand, Booklet Finisher, 2,520-Sheet

Tandem Tray Module, 520-Sheet Drawer Stand

620 pages 75 gsm bond

5140 pages 75 gsm bond

Card Stock, Envelopes, Glossy paper, Labels, Plain Paper, Transparencies, Refer to the Card Stock & Label Guide

General
Function

Product Guarantee

Product Certifications

Size (mm - H x W x D)

Recommended Monthly Page Volume

«Recommended Monthly Page Volume» is a range of pages that helps customers evaluate Lexmark’s product
offerings based on the average number of pages customers plan to print on the device each month. Lexmark
recommends that the number of pages per month be within the stated range for optimum device performance,
based on factors including: supplies replacement intervals, paper loading intervals, speed, and typical customer
usage.

Maximum Monthly Duty Cycle

«Maximum Monthly Duty Cycle» is defined as the maximum number of pages a device could deliver in a month
using a multishift operation. This metric provides a comparison of robustness in relation to other Lexmark
printers and MFPs.

Footnotes

1

Source: InfoTrends/CapVentures., «Network Document Solutions Forecast 2007-2012, Network Document

Solutions Consulting Service», August, 2008

2

Average continuous black or composite CMY declared cartridge yield in accordance with ISO/IEC 19798.

3

Change Language is an option during installation.

4

Illustration shows enlarged description of touch screen.

Colour Printing

1-Year Onsite Service, Next Business Day

www.lexmark.co.uk

565 x 640 x 685 mm

Trademarks

Lexmark and Lexmark with the diamond design are trademarks of Lexmark International, Inc., registered in the
United States and/or other countries. All other trademarks are the property of their respective owners. ENERGY
STAR® is a U.S. registered mark. Information in this document is subject to change without notice. PANTONE®
is a registered trademark of Pantone, Inc. This product features Adobe® Flash® technology. For further informa­tion, visit http://www.adobe.com/software/flash/about/

Print Less. Save More.

ww w.lexmar k.co .uk
