Page 1
// CONFERENCE SERIES
A CLEAR MESSAGE
LEWITT GmbH
Page 2
// CONFERENCE SERIES
CONFERENCE SERIES
A CLEAR MESSAGE
Modular system
Tailored to your needs
The LEWITT conference system consists of three distinguished components - capsule, gooseneck, base and can be tailored according to your specific application and room. The LEWITT Conference Series provides
pleasantly clear and intelligible voice reproduction for podiums, houses of worship and conference rooms of
any size. State-of-the-art decoupling minimizes structure-borne noise. Handling noise is strongly reduced.
Adapt to your preferences without compromises. All components are built from sturdy, reliable materials and
can be exchanged effortlessly.
LEWITT GmbH
Page 3
5.0 in
Ø 6 mm
Ø 0.2 in
12.7 cm
Ø 10 mm
Ø 0.4 in
5.3 in
13.5 cm
Interchangeable Capsule
S10
S6
// CONFERENCE SERIES
A CLEAR MESSAGE
Condenser capsule
Our conference condenser capsules, S6 and S10, provide natural, transparent, and most intelligible voice reproduction.
With highly efcient off-axis rejection and high gain before feedback, your voice will stay in focus regardless of the
specic room situation. Compatible with all of our available goosenecks (GN15X, GN35X, GN35X2).
S6
Features
Highly efcient off-axis rejection
High gain before feedback
Clear speech intelligibility
48 V phantom power
Dimensions
Specications S6
Acoustical operating principle
S10
Pressure gradient transducer,
permanently polarized
Dynamic range 81.8 dB (A)
Transducer Ø 10 mm, 0.4 in Max. SPL for 0.5 % THD 110.6 dBSPL
Frequency range 65 ... 16,000 Hz Supply voltage 48 V ± 4 V
Sensitivity 32.3 mV / Pa, -29.8 dBV Current consumption 1.8 mA
Equivalent noise level 28.8 dB (A)
LEWITT GmbH
Connector Custom
thread
Page 4
Specications S10
// CONFERENCE SERIES
A CLEAR MESSAGE
Acoustical operating principle
Transducer Ø 10 mm, 0.4 in Max. SPL for 0.5 % THD 107 dBSPL
Frequency range 65 ... 16,000 Hz Supply voltage 48 V ± 4 V
Sensitivity 50.5 mV / Pa, -25.9 dBV Current consumption 1.8 mA
Equivalent noise level 21.8 dB (A) Connector
Pressure gradient transducer,
permanently polarized
Dynamic range 85.2 dB (A)
Custom
thread
LEWITT GmbH
Page 5
5.0 in
Ø 6 mm
Ø 0.2 in
12.7 cm
14.5 in
36.9 cm
14.5 in
36.9 cm
6.7 in
17.1 cm
Ø 10 mm
Ø 0.4 in
5.3 in
13.5 cm
Interchangeable Capsule
GN15X
3-pin XLR Goosenecks
GN35X
GN35X2
S10
S6
// CONFERENCE SERIES
A CLEAR MESSAGE
Gooseneck
Our goosenecks are compatible with any microphone base featuring a 3-pin XLR connector. Fully adjustable with
minimal handling noise for professional ease of use. Available in different sizes. Compatible with the S6 and S10
condenser capsule.
GN15X GN35X2
Features
Rugged metal construction
Highly exible and stable
Minimal handling noise
48 V phantom power
3-pin XLR connector
Dimensions
GN35X
LEWITT GmbH
Page 6
5.0 in
Ø 6 mm
Ø 0.2 in
12.7 cm
14.5 in
36.9 cm
14.5 in
36.9 cm
6.7 in
17.1 cm
Ø 10 mm
Ø 0.4 in
5.3 in
13.5 cm
6.3 in 16.0 cm
4.8 in
12.2 cm
1.4 in 3.5 cm
Interchangeable Capsule
GN15X
3-pin XLR Goosenecks
Conference Bases
GN35X
GN35X2
B80AS
Switch
Version
No Switch
Version
B70A
S10
S6
Ø 10 mm
Ø 0.4 in
5.3 in
13.5 cm
Microphone base
These modern shapes efciently minimize structure-borne noise. The material is rugged and features a non-reective
matte black coating. Provides a solid base for 3-pin XLR gooseneck microphones. Features a mute button with clear
visual feedback (B70AS).
// CONFERENCE SERIES
CONFERENCE SERIES
A CLEAR MESSAGE
B70A B70AS
Features
Dampens structure-borne noise
Mute button with clear visual feedback (B70AS)
Sturdy and reliable zinc die-cast housing
48 V phantom power
3-pin XLR connector
Dimensions
3-pin XLR
B70A
No Switch
Version
LEWITT GmbH
3-pin XLR
