Page 1

Model No.: LV-H135

Console HEPA Air Puriﬁer

Questions or Concerns?

Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT at [email protected] or (888) 726-8520.

Page 2

THANK YOU FOR PURCHASING THE LVH135 CONSOLE HEPA AIR PURIFIER BY LEVOIT!

If you have any questions or concerns, please reach out to us at [email protected]. We hope you enjoy your new air puriﬁer!

SHARE THE LEVOIT LOVE

Find @LevoitLifestyle on social media for wellness + style inspiration. We make every space mindful and chic.

@LevoitLifestyle

#LevoitLove • #LevoitLifestyle

Page 3

TABLE OF CONTENTS

PACKAGE CONTENTS

Package Contents Speciﬁcations Safety Information Getting to Know Your Air Puriﬁer LED Display Getting Started Using Your Puriﬁer

• General Operation

• Automatic Shuto

• Auto Mode

• Sleep Mode

• Timer

• Memory Function

Keeping Things Clean

• Cleaning the Air Puriﬁer

• Air Filter Indicator

• When Should I Replace the Air Filter?

• Resetting the Air Filter Indicator

• Cleaning the Dust Sensor Cover

• Replacing the Air Filter Troubleshooting Warranty Information Customer Support

10 10 10 10 10 10

12 13 13

3 3 4 5 6 8 9 9 9 9 9 9 9

1 x Air Puriﬁer 1 x True HEPA Filter (Pre-Installed) 1 x User Manual 1 x Filter Reminder Card

SPECIFICATIONS

Power Supply AC 120V, 60Hz

Rated Power 40W

Applicable Area ≤ 463 ft² (43 m²)

Temperature: 14°F–104°F

Operating Conditions

Noise Level ≤ 54dB

(Clean Air Delivery Rate)

Standby Power < 0.8W

(-10°C–40°C) Humidity: ≤ 95% RH

CADR

212 CFM (360 m³/h)

Page 4

SAFETY INFORMATION

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and safety guidelines.

General Safety Plug and Cord

• Only use your air puriﬁer as described in this manual.

• Do not use your air puriﬁer outdoors.

• Keep your air puriﬁer away from water, and wet or damp

areas. Never place in water or other liquids.

• Keep your air puriﬁer away from heat sources.

• Do not use where combustible gases or vapors are present.

• Supervise children when they are near the air puriﬁer.

• Do not place anything into any opening on the air puriﬁer,

unless directed by the manual.

• Do not sit or place heavy objects on the air puriﬁer.

• Keep the inside of the air puriﬁer dry. To prevent moisture

buildup, avoid placing in rooms with major temperature changes or underneath air conditioners.

• Always unplug your air puriﬁer before servicing (for example,

changing the air ﬁlter).

• Do not use your air puriﬁer if it is damaged or not working

correctly, or if the cord or plug is damaged. Do not try to repair it yourself. Contact Customer Support (see page 13).

• Not for commercial use. Household use only.

• Keep the air puriﬁer near the outlet it is plugged into.

• Never place the cord near any heat source.

• Do not cover the cord with a rug, carpet, or other covering. Do not place the cord under furniture or appliances.

• Keep the cord out of areas where people walk often. Place the cord where it will not be tripped over.

• Your air puriﬁer has a polarized plug (one prong is wider than the other), which ﬁts into a polarized outlet only one way. This is a safety feature to reduce the risk of electric shock. If the plug does not ﬁt, reverse the plug. If it still does not ﬁt, do not use the plug in that outlet. Do not bypass this safety feature.

WARNING

Do not use this air puriﬁer with solid-state speed controls (such as a dimmer switch).

READ AND SAVE

THESE INSTRUCTIONS

Page 5

GETTING TO KNOW YOUR AIR PURIFIER

Front Back

4 4 10

1. LED Display

2. Air Outlet

3. Housing

4. Air Intake

5. Air Quality Sensor

6. Sensor Cover Sponge

7. Sensor Cover

8. Safety Trigger

9. Filter Cover

10. True HEPA Filter

11. Power Cord

Page 6

LED CONTROL PANEL

On/O Button

• Press to turn the air puriﬁer on or o.

Timer Button

• Sets the timer and cycles through timer lengths (see page 9).

Fan Speed Button

• Cycles through fan speeds: low, medium, and high.

Fan Speed Chart

Fan Speed Indicator Fan Speed

Low

Auto Mode Button

• Turns Auto Mode on (see page 9).

Check Filter Button/Indicator

• Lights up red to remind you to check the air ﬁlter (see page 10).

Medium

High

Sleep Mode Button

• Turns Sleep Mode on (see page 9).

Display Button

• Turns the display o.

• Press any button (except ) to turn the display back on.

Page 7

Air Quality Indicator

• Displays air quality using the air quality sensor inside the air puriﬁer.

Changing Brightness

Use the palm of your hand to press the air quality indicator to change the brightness.

NOTE: Touching with just a ﬁngertip will not change the brightness.

Air Quality Indicator Chart

Color Air Quality

Red

Yellow

Green

Blue

Moderate

Very Good

Bad

Good

Page 8

GETTING STARTED

1. Pull the handle of the ﬁlter cover to open the housing. Remove the air ﬁlter from the housing. [Figure 1.1]

Figure 1.1

2. Take the ﬁlter out of its plastic packaging, then reinstall it into the housing. Make sure the pull tabs on the ﬁlter are facing out. [Figure 1.2]

3. Replace the ﬁlter cover by lining up the cover’s feet with the matching slots on the bottom of the housing. [Figure 1.3]

Figure 1.3

4. Push the cover securely closed. [Figure 1.4] The air puriﬁer uses a magnetic safety trigger to make sure that the ﬁlter cover is closed. If not properly closed, the air puriﬁer will not turn on.

pull tabs

facing out

Figure 1.2

NOTE: If you are not planning to use the air puriﬁer for a long period of time, we recommend leaving the ﬁlter inside its plastic packaging until it is ready to be used, to keep it clean.

Figure 1.4

Page 9

USING YOUR PURIFIER

General Operation

1. Place the air puriﬁer on a hard, ﬂat surface. Leave 15 inches (38 cm) of clearance on all sides of the puriﬁer. [Figure 2.1]

2. Press to turn on the air puriﬁer. The air puriﬁer fan will start automatically.

3. Optionally, press to change fan speed. You can also select Auto Mode or Sleep Mode, or select a timer.

• For best results, run the air puriﬁer at maximum speed for

15–20 minutes before using a lower speed or Auto Mode.

• To eectively clean air, keep windows closed while the air

puriﬁer is operating.

4. Press to turn o the air purifer.

38 cm

Figure 2.1

Automatic Shuto

As a safety feature, the air puriﬁer will automatically turn o if the ﬁlter cover is removed.

Auto Mode

Auto Mode uses the air quality sensor inside the air puriﬁer to adjust the fan speed automatically based on air quality. For example, if the air quality is bad, the fan will automatically be set to high speed. See Auto Mode Chart.

Press

NOTE: Pressing or will exit Auto Mode.

to turn Auto Mode on.

Auto Mode Chart

Color Air Quality Fan Speed

Red Bad High

Yellow

Green

Blue

Moderate Medium

Good Low

Very Good Sleep Mode

Sleep Mode

Sleep Mode uses the lowest possible fan speed to operate quietly.

Press to turn Sleep Mode on.

NOTE: Pressing or will exit Sleep Mode.

Timer

1. Press to turn on or o the timer, and to cycle through timer options (2, 4, or 8 hours).

2. The air puriﬁer will automatically power o once the timer is ﬁnished.

NOTE: Pressing or unplugging the air puriﬁer will cancel the timer.

Memory Function

The air puriﬁer will remember its programmed settings when turned o, and will resume these settings when turned back on.

NOTE: The air puriﬁer will not remember timers.

Page 10

KEEPING THINGS CLEAN

Cleaning the Air Puriﬁer

1. Wipe the outside of the air puriﬁer with a dry cloth. Do not clean with water or any other liquid, to avoid risk of electric shock.

2. Clean the outside of the ﬁlter with a brush or vacuum each month to prevent buildup of hair or dust. Do not clean the ﬁlter with water or other liquid.

Air Filter Indicator

will light up as a reminder to check the air ﬁlter. The indicator is automatic. You may not need to change your ﬁlter yet, but you need to check it when lights up.

When Should I Replace the Air Filter?

The air ﬁlter should be replaced every 6–8 months. You may need to replace your ﬁlter sooner or later depending on how often you use your air puriﬁer. Using your air puriﬁer in an environment with relatively high pollution may mean you will need to change the ﬁlter more often (even if

Watch out for the signs of an expired ﬁlter:

• Increased noise when the air puriﬁer is on

• Decreased airﬂow

• Unusual odors

• Visibly clogged ﬁlter

NOTE:

• Only use ocial Levoit LV-H135-RF replacement ﬁlters

• Scan the QR code to purchase new air ﬁlters.

is o).

for this air puriﬁer.

Resetting the Air Filter Indicator

Reset the air ﬁlter indicator when:

•

lights up.

1. Replace the air ﬁlter (see page 11).

2. Press and hold for 3 seconds.

3. The light will turn o after the ﬁlter indicator is successfully reset.

• The air ﬁlter was changed before

1. Press and hold for 3 seconds.

2. The air puriﬁer will chime after the ﬁlter indicator is successfully reset.

lit up.

Cleaning the Sensor Cover

If the air quality indicator does not seem to be accurate, clean the sensor cover.

1. Remove the sensor cover. [Figure 3.1]

NOTE: The sensor cover has a sponge inside to protect the air quality sensor from large particles.

2. Wipe the cover with a dry cloth. Wipe the cover with a dry cloth. Wash the sponge with clean water, then dry.

3. Replace the sensor cover.

NOTE: Do not throw away the sponge. If the sponge is not in the sensor cover, the air quality sensor may not work correctly.

Figure 3.1

Page 11

Replacing the Air Filter

1. Unplug the air puriﬁer and remove the ﬁlter cover. [Figure 4.1]

unplug

air puriﬁer

Figure 4.1

4. Unwrap the new air ﬁlter and place it into the housing. Make sure the pull tabs are facing out. [Figure 4.4]

pull tabs

facing out

Figure 4.4

2. Remove the old air ﬁlter and properly dispose of it. [Figure 4.2]

Figure 4.2

3. Clean any remaining dust and dirt from inside of the housing using a vacuum hose. [Figure 4.3]

Figure 4.3

5. Replace the ﬁlter cover. The air puriﬁer will not power on unless the cover is replaced correctly. [Figure 4.5]

Figure 4.5

6. Plug in the air puriﬁer and turn it on.

7. Press and hold the Air Filter Indicator, page 10).

for 3 seconds to reset it. (see Resetting

Page 12

TROUBLESHOOTING

Problem Solution

Plug in the air puriﬁer.

Check to see if the power cord is damaged. If so, stop using the air puriﬁer, and contact Customer Support (see page 13).

Air puriﬁer will not turn on or respond to button controls.

Air puriﬁer makes an unusual noise while the fan is on.

Properly place the ﬁlter cover on the air puriﬁer, so that the safety switch is activated (see Getting Started, page 8).

Plug the air puriﬁer into a dierent outlet.

Air puriﬁer may be malfunctioning. Contact Customer Support (see page 13).

Make sure the air ﬁlter is properly in place and removed from its plastic packaging (see Getting Started, page 8).

Replace the air ﬁlter (see Replacing the Air Filter, page 11).

The air puriﬁer may be damaged, or a foreign object may be inside. Stop using the air puriﬁer and contact Customer Support (see page 13). Do not open the air puriﬁer.

Make sure no objects are blocking the top or sides of the air puriﬁer (the inlet or outlet).

Close doors and windows while running the air puriﬁer.

Poor air puriﬁcation quality.

The air puriﬁer is producing an unpleasant odor.

is still illuminated after replacing the

air ﬁlter.

Make sure the air ﬁlter is properly in place (see Getting Started, page 8).

Make sure the room is smaller than 463 ft² (43 m²). The air puriﬁer may not be eective in larger rooms.

Replace the air ﬁlter (see Replacing the Air Filter, page 11).

Make sure that the air puriﬁer is in a room where the relative humidity is less than 85% RH. Higher humidity levels may cause mildew to grow on the air ﬁlter.

Reset (see Resetting the Air Filter Indicator, page 10).

If your problem is not listed, please contact Customer Support (see page 13).

Page 13

WARRANTY INFORMATION

Product Name Console HEPA Air Puriﬁer

Model Number LV-H135

Default Warranty Period 1 year

For your own reference, we strongly recommend that you record your order number and date of purchase.

Date of Purchase

Order Number

TERMS & POLICY

Levoit warrants all products to be of the highest quality in material, craftsmanship, and service, eective from the date of purchase to the end of the warranty period.

Levoit will replace any product found to be defective due to manufacturer ﬂaws based on eligibility. Refunds are available within the ﬁrst 30 days of purchase. Refunds are only available to the original purchaser of the product. This warranty extends only to personal use and does not extend to any product that has been used for commercial, rental, or any other use in which the product is not intended for. There are no warranties other than the warranties expressly set forth with each product.

This warranty is non-transferrable. Levoit is not responsible in any way for any damages, losses, or inconveniences caused by equipment failure by user negligence, abuse, or use noncompliant with the user manual or any additional safety, use, or warnings included in the product packaging and manual.

This warranty does not apply to the following:

• Damage due to abuse, accident, alteration, misuse, tampering, or

vandalism.

• Improper or inadequate maintenance.

• Damage in return transit.

• Unsupervised use by children under 18 years of age.

Levoit and its subsidiaries assume no liability for damage caused by the use of the product other than for its intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses so the foregoing disclaimer may not apply to you. This warranty gives you speciﬁc legal rights and you may also have other rights which may vary from state to state.

ALL EXPRESSED AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

Additional 1-Year Warranty

You can extend your 1-year warranty by an additional year. Log onto

www.levoit.com/warranty

or Houzz) within the ﬁrst 14 days of your purchase to register your new product for the extended warranty.

If you are unable to provide the order number for your product, please type a short note in the order number ﬁeld along with the date you received your product.

Defective Products & Returns

Should your product prove defective within the speciﬁed warranty period, please contact Customer Support via [email protected] with your order number. Once our Customer Support Team has approved your request, please return the unit with a copy of the invoice and your order number.

and enter your order number (e.g., from Amazon

CUSTOMER SUPPORT

If you encounter any issues or have any questions regarding your new product, feel free to contact our helpful Customer Support Team. Your satisfaction is our goal!

Customer Support

Arovast Corporation

Support Hours

Mon–Fri, 9:00 am–5:00 pm PST/PDT 1202 N. Miller St., Suite A Anaheim, CA 92806

*Please have your order invoice and order number ready before contacting Customer Support.

Contact Information

Email: [email protected] Toll-Free: (888) 726-8520
