Page 1

Model No.: LV-H134

Tower Pro HEPA Air Puriﬁer

Questions or Concerns?

Please contact us Monday - Friday 9:00 am - 5:00 pm PT at [email protected] or (888) 726-8520.

Page 2

THANK YOU FOR PURCHASING THE LVH134 TOWER PRO HEPA AIR PURIFIER BY LEVOIT!

Should you have any questions or concerns regarding your new product, feel free to reach out to us at [email protected]. We hope you enjoy your new product!

GET STYLE INSPIRATION

Find @LevoitLifestyle on social media for wellness + style inspiration. We make every space mindful and chic.

@LevoitLifestyle

#LevoitLove • #LevoitLifestyle

Page 3

TABLE OF CONTENTS

PACKAGE CONTENTS

Package Contents Speciﬁcations Safety Information Getting to Know Your Air Puriﬁer LED Display Getting Started

· About the Safety Trigger

Operation

· General Operation

· Button Controls & Functions

· PM2.5 Value & Air Quality

· Air Quality Indicator

· Memory Function

Keeping Things Clean

· Replacing the Air Filter

· Resetting the Air Puriﬁer Troubleshooting Warranty Information Customer Support

3 3 4 5 5 6 7 7 7 8 9 9 9 9 10 11 12 14 14

1 x LV-H134 Tower Pro HEPA Air Puriﬁer 1 x Filter (Pre-installed) 1 x Power Cord 1 x User Manual 1 x Caution Card

SPECIFICATIONS

Power Supply AC 120V / 60Hz

Rated Power 45W

Applicable Area ≤ 710 ft² (66 m²)

Operating Conditions

Noise Level ≤ 54dB

CADR (Clean Air Delivery Rate)

Standby Power < 0.8W

Temperature: 14°F~104°F (-10°~40°C) Humidity: ≤ 95% RH

312 CFM (530 m³/h)

Page 4

SAFETY INFORMATION

IMPORTANT

Always follow the instructions and safety guidelines in this manual. Only use your Levoit Tower HEPA Air Puriﬁer as described in this manual.

General Safety

• Ensure the plug ﬁts properly into a polarized power socket.

• DO NOT operate if cord or plug is damaged.

• DO NOT handle with wet hands. Thoroughly dry your hands before

handling the air puriﬁer.

• DO NOT immerse air puriﬁer in water or liquid.

• DO NOT use the air puriﬁer in wet or humid environments.

• DO NOT use the air puriﬁer outdoors.

• DO NOT use the air puriﬁer in a room with major indoor temperature

changes. This may cause condensation to build up inside the appliance.

• DO NOT use the air puriﬁer in an enclosed space where toxic,

ﬂammable, combustible, or explosive gases or substances are present.

• If you are using the air puriﬁer where oxygen is being administered,

make sure the puriﬁer is at least 3-5 feet away from the oxygen tank.

• DO NOT insert ﬁngers or objects into the air outlet.

• Child supervision is required while the air puriﬁer is on. DO NOT allow

children to play on or near the air puriﬁer.

Use & Care

• Place the air puriﬁer on a ﬂat, level, solid surface before operation.

• DO NOT place the air puriﬁer near sources of heat, such as open ﬂames, stove tops, ovens, radiators, or computers.

• Place the air puriﬁer so that the power cord easily reaches a standard electrical outlet for a polarized plug.

• DO NOT route the cord under carpeting, rugs, furniture, or appliances. Place the power cord away from high-trac areas.

• WARNING: To reduce the risk of ﬁre or electric shock, DO NOT use this air puriﬁer with solid-state speed controls (such as a dimmer switch).

• DO NOT use an extension cord with this unit.

• DO NOT sit on or place anything on top of the puriﬁer.

• DO NOT place the air puriﬁer directly below an air conditioner, to

prevent any moisture from getting into the air puriﬁer.

• This air puriﬁer should be inspected frequently. Dirt that has collected should be removed regularly to prevent excessive accumulation that may result in a ﬂashover or ﬁre.

• DO NOT clean the appliance with water or any other liquid to avoid electric shock, ﬁres, or injury.

• If the air puriﬁer is damaged, or is not functioning properly, immediately stop use and contact Customer Support (page 14).

• DO NOT attempt to repair this device in any way or use any thirdparty parts to modify the air puriﬁer. Doing so will void your warranty. Contact Customer Support immediately if your device is no longer working.

SAVE THESE INSTRUCTIONS

Page 5

GETTING TO KNOW YOUR AIR PURIFIER

1 2

Front Back

1. LED Display

2. Air Outlet

3. Housing

4. Power Cord

5. Air Intake

6. Dust Sensor

7. Safety Trigger

8. Filter Cover

9. Air Filter

LED DISPLAY

Sleep Mode Button/ Indicator

Auto Mode Button/ Indicator

Fan Speed Button/ Indicator

Fan Speed Indicator

Timer Display

Power Button/ Indicator

Display Button

Change Filter Button/

Indicator

PM2.5 Value Display (µg/m³)

Timer Button/

Indicator

Air Quality Indicator

Page 6

GETTING STARTED

1. Pull the handle of the ﬁlter cover to open the housing. Remove the air ﬁlter from the housing. [Figure 1.1]

Figure 1.1

2. Take the ﬁlter out of its plastic packaging, then reinstall it into the housing. Make sure the handles on the ﬁlter are facing out. [Figure 1.2]

3. Replace the ﬁlter cover by aligning the bottom portion of the cover with the inlets on the bottom of the housing. [Figure 1.3]

Figure 1.3

4. Once the bottom portion is properly aligned, slowly close the cover by aligning its top part with the inlets at the top of the opening. [Figure 1.4]

handles

facing out

Figure 1.2

NOTE:

• If you are not planning to use the air puriﬁer for a long period of time, we recommend leaving the ﬁlter inside its plastic packaging until it is ready to be used. This helps prevent mold from building up on the air ﬁlter.

• If the ﬁlter cover is not properly installed, the air puriﬁer will not turn on.

Figure 1.4

Page 7

About the Safety Trigger

When replacing the ﬁlter cover onto the air puriﬁer, always make sure the magnetic safety trigger is properly aligned with its respective area. [Figure 2.1]

NOTE: If the trigger is not properly aligned, the air puriﬁer will not turn on.

OPERATION

General Operation

1. Place the air puriﬁer on a level surface. [Figure 3.1]

2. Plug the air puriﬁer into a powered electrical outlet.

3. Tap to turn on the air puriﬁer. It will start operating at medium speed.

4. (Optional) Tap to adjust the fan speed of the air puriﬁer. There are 3 fan speeds to choose from (see Button Controls & Functions, page 8).

5. Tap to turn o the air puriﬁer when you are ﬁnished using it.

NOTE: Always allow at least 15 inches (38 cm) of clearance on all sides of the puriﬁer. [Figure 3.2]

safety trigger

makes contact with

the base

Figure 2.1

Figure 3.1

38 cm

Figure 3.2

Page 8

Button Controls & Functions

Power Button

Turns the air puriﬁer on or o.

Fan Speed Button

to cycle through the adjustable fan speeds

Tap of the air puriﬁer: low, medium, and high (see Chart

A below).

Chart A

Fan Speed Indicator Fan Speed

Low

Medium

High

NOTE:

• The fan speed cannot be adjusted while on Auto or Sleep Modes.

• To eectively clean the air, make sure to keep your windows closed

while the air puriﬁer is operating.

• For best results, it is recommended to run the air puriﬁer at maximum

speed for 15-20 minutes before using a lower speed setting or setting the puriﬁer to Auto Mode.

Auto Mode Button

Tap to activate Auto (automatic) Mode on the air puriﬁer. This mode automatically adjusts the fan speed of the air puriﬁer according to the current air quality. The air quality indicator around the LED display will also illuminate a certain color based on the air quality (see Chart B below).

Sleep Mode Button

Tap

to activate Sleep Mode on the air puriﬁer. This function sets the air puriﬁer to its lowest speed setting to create a quiet environment while producing air.

Display Button

Turns the LED Display on or o while the air puriﬁer is operating.

NOTE:

• While the display is o, you can tap any button (except for

) to turn on the display.

Timer Button

Allows you to program a timer from 1 to 12 hours.

1. Tap repeatedly to choose a time.

2. Once you have reached the desired time, the timer display will ﬂash 5 times before setting.

3. The air puriﬁer will automatically power o once the timer has ﬁnished counting down.

4. To cancel the timer, tap repeatedly until the timer display reads “- - - -”. Wait until “- - - -” ﬂashes 5 times to exit out of the timer function.

NOTE:

• To quickly select a time, press and hold seconds, or until the desired time appears on the timer display.

• The timer function will remember your previously programmed time when you press

• The timer function is available for all modes.

for 2

Chart B

Indicator Color Air Quality Fan Speed

Blue Very Good Sleep Mode

Green Good Low Speed

Orange Moderate Medium Speed

Red Bad High Speed

Page 9

PM2.5 Value & Air Quality

Memory Function

The PM2.5 value on the display shows the amount of particles (µg) that are detected within 1 cubic meter (m³). [Figure 4.1]

Figure 4.1

PM2.5 refers to particulate matter (PM) that is less than or equal to 2.5 microns (µm) in diameter. These particles, also known as “ﬁne particles,” are so small that they can only be detected with an electron microscope and stay in the air longer than heavier air particles such as dust and mold.

Your new air puriﬁer is equipped with a laser dust sensor that is able to detect the amount of particles are in a given space (µg/ m³). A range from 0 to 135 indicates that there is a low to moderate amount of ﬁne particles in the air (generally, the lower the number, the better your air quality). A number above 135 indicates that there is an unhealthy amount of ﬁne particles in the air.

Air Quality Indicator

Outside of Auto Mode, the air quality indicator will also light up to denote the current air quality during normal operation. The table below shows the correlation among the PM2.5 value, indicator color, and air quality. [Chart C]

Chart C

The air puriﬁer will remember its programmed settings when turned o, and will resume these settings when it is turned back on.

NOTE: The memory function will not work with the built-in timer.

KEEPING THINGS CLEAN

NOTE: It is recommended to clean the pre-ﬁlter with a brush or vacuum each month to prevent buildup of hair or dust.

Change Filter Indicator

This indicator will light up red to remind you to check the air ﬁlter. turns on sooner or later depending on how often you use your air puriﬁer. It does not necessarily mean it is time to change the ﬁlter.

When Should I Replace the Air Filter?

It is recommended to change the air ﬁlter every 6-8 months. However, you may need to change your ﬁlter sooner or later depending the frequency of use and the air quality in the room. It is important to watch out for the following signs of an expired ﬁlter:

Indicator Color Air Quality

Blue Very Good

Green Good

Orange Moderate

Red Bad

NOTE:

• The air quality indicator is available for all modes on the air puriﬁer.

• Increased operating noise

• Decreased airﬂow

• Clogged ﬁlter

• Increased presence of odors

NOTE:

• The environment in which the air puriﬁer is being used may also extend or shorten the lifetime of the air ﬁlter. Using your air puriﬁer in an environment of relatively high pollution may mean you will need to change the air ﬁlter more often.

• If the air pollution in your environment is very high, there is a possibility that the ﬁlter may not be completely eective and may need to be replaced before the indicator lights up on the display.

• Remember to reset the air puriﬁer after changing the air ﬁlter.

Page 10

Replacing the Air Filter

1. Unplug the air puriﬁer and remove the ﬁlter cover. [Figure 5.1]

unplug

air puriﬁer

Figure 5.1

2. Remove the old air ﬁlter and properly dispose of it. [Figure

5.2]

Figure 5.2

3. (Optional) Clean any remaining dust and dirt from inside of the housing using a vacuum hose. [Figure 5.3]

4. Unwrap the new air ﬁlter and place it into the housing. Make sure the ﬁlter handles are facing out. [Figure 5.4]

handles

facing out

Figure 5.4

5. Replace the back cover onto the housing. [Figure 5.5]

Figure 5.5

6. Plug in and turn on the air puriﬁer. Then press and hold

for

3 seconds (see Resetting the Air Puriﬁer, page 11).

NOTE:

• Do not clean the ﬁlter with water or other liquid.

• The back cover must be placed back on the unit in order for it to power on.

Figure 5.3

Page 11

Purchasing a New Air Filter

To maintain your health and product performance, please only use ocial Levoit replacement ﬁlters. You can purchase new air ﬁlters from Amazon.com by searching for “B07DVYFBNY”. You can also scan the QR code below.

If you have any questions, please contact Customer Support (page 14).

Resetting the Air Puriﬁer

It is necessary to reset the air puriﬁer after changing the air ﬁlter. There are two scenarios where you must reset the air puriﬁer:

• Scenario 1:

1. Replace the air ﬁlter (see Replacing the Air Filter,

page 10).

2. Press and hold for 3 seconds.

3. The indicator light will turn o. This means that the air puriﬁer has been successfully reset.

• Scenario 2: The air ﬁlter has been changed before lights up.

1. Press and hold for 3 seconds.

2. The air puriﬁer will chime to indicate that it has been successfully reset.

lights up red.

Page 12

TROUBLESHOOTING

Problem Cause Solution

Air puriﬁer does not power on.

Air puriﬁer does not respond to button controls.

Air puriﬁer makes an unusual noise while operating.

Signiﬁcantly reduced airﬂow.

Unit is not plugged into an electrical outlet.

Outlet is not working properly. Try plugging the air puriﬁer into a dierent outlet.

Filter cover is not properly placed on the unit.

Power cord is damaged. Immediately discontinue use and contact Customer Support

Air puriﬁer is defective or malfunctioning.

Air puriﬁer is not plugged into an outlet. Connect the plug to a powered electrical outlet.

Filter cover is not properly placed on the unit.

Air puriﬁer is defective or malfunctioning.

Air ﬁlter needs to be replaced. Replace the air ﬁlter (see Replacing the Air Filter, page 10).

Filter does not ﬁt properly. Properly place the ﬁlter (see Getting Started and Replacing the

Foreign object inside the unit. Immediately discontinue use and contact Customer Support

Filter packaging has not been removed.

Fan speed is low.

Filter needs to be replaced. Replace the air ﬁlter (see Replacing the Air Filter, page 10).

Not enough clearance on all sides of the puriﬁer.

Connect the plug to a powered electrical outlet.

Properly replace the ﬁlter cover (see Getting Started, page 6).

(page 14).

Properly replace the ﬁlter cover (see Getting Started, page 6).

Immediately discontinue use and contact Customer Support (page 14).

Air Filter, pages 6 and 10).

(page 14). DO NOT attempt to open the air puriﬁer.

Remove the ﬁlter from its packaging before use.

Press

Ensure there is at least 15 inches (38 cm) of clearance on all sides of the puriﬁer.

to adjust fan speed.

Page 13

Problem Cause Solution

Poor air puriﬁcation quality.

Room is larger than the air puriﬁer’s applicable area.

Air intake or outlet is blocked. Remove objects blocking air intake or outlet.

Ensure the room is smaller than 538 ft² (50 m²).

The air puriﬁer is producing an unpleasant odor.

is still illuminated after replacing the air ﬁlter.

Filter is not properly placed inside the housing.

The ﬁlter is dirty and cannot produce fresh air anymore.

Not enough clearance on all sides of the puriﬁer.

The air ﬁlter is dirty and cannot produce fresh air anymore.

High humidity levels have caused mildew to grow on the air ﬁlters.

The air puriﬁer has been reset incorrectly.

Properly place the ﬁlter (see Getting Started and Replacing the Air Filter, pages 6 and 10).

Replace the air ﬁlter (see Replacing the Air Filter, page 10).

Ensure there is at least 15 inches (38 cm) of clearance on all sides of the puriﬁer.

Replace the air ﬁlter (see Replacing the Air Filter, page 10).

Replace the air ﬁlter, and move the air puriﬁer to a room where the relative humidity is less than 85% RH.

See the Resetting the Air Puriﬁer section on how to properly reset the unit (page 11).

Page 14

WARRANTY INFORMATION

Product Name Tower Pro HEPA Air Puriﬁer

Model Number LV-H134

Default Warranty Period 1 year

For your own reference, we strongly recommend that you record your order number and date of purchase.

Date of Purchase

Order Number

TERMS & POLICY

Levoit warrants all products to be of the highest quality in material, craftsmanship, and service, eective from the date of purchase to the end of the warranty period.

Levoit will replace any product found to be defective due to manufacturer ﬂaws based on eligibility. Refunds are available within the ﬁrst 30 days of purchase. Refunds are only available to the original purchaser of the product. This warranty extends only to personal use and does not extend to any product that has been used for commercial, rental, or any other use in which the product is not intended for. There are no warranties other than the warranties expressly set forth with each product.

This warranty is non-transferrable. Levoit is not responsible in any way for any damages, losses, or inconveniences caused by equipment failure by user negligence, abuse, or use noncompliant with the user manual or any additional safety, use, or warnings included in the product packaging and manual.

This warranty does not apply to the following:

• Damage due to abuse, accident, alteration, misuse, tampering, or vandalism.

• Improper or inadequate maintenance.

• Damage in return transit.

• Unsupervised use by children under 18 years of age.

Levoit and its subsidiaries assume no liability for damage caused by the use of the product other than for its intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses so the foregoing disclaimer may not apply to you. This warranty gives you speciﬁc legal rights and you may also have other rights which may vary from state to state.

ALL EXPRESSED AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

Additional 1-Year Warranty

You can extend your 1-year warranty by an additional year. Log onto

www.levoit.com/warranty

or Houzz) within the ﬁrst 14 days of your purchase to register your new product for the extended warranty.

If you are unable to provide the order number for your product, please type a short note in the order number ﬁeld along with the date you received your product.

Defective Products & Returns

Should your product prove defective within the speciﬁed warranty period, please contact Customer Support via [email protected] with your order number. Once our Customer Support Team has approved your request, please return the unit with a copy of the invoice and your order number.

and enter your order number (e.g., from Amazon

CUSTOMER SUPPORT

Should you encounter any issues or have any questions regarding your new product, feel free to contact our helpful Customer Support Team. Your satisfaction is our goal!

Customer Support

Arovast Corporation

1202 N. Miller St., Suite A

Support Hours

Monday - Friday:

9:00 am - 5:00 pm PT

Anaheim, CA 92806

*Please have your order invoice and order number ready before contacting Customer Support.

Contact Information

Email: [email protected] Toll-Free: (888) 726-8520

Page 15

Connect with us @LevoitLifestyle

Page 16

Levoit.com
