Page 1

USER MANUAL

True HEPA Air Puriﬁer

Model: Core 300

Questions or Concerns?

Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT at [email protected] or at (888) 726-8520.

Page 2

Thank you for purchasing the

CORE 300 TRUE HEPA AIR PURIFIER BY LEVOIT.

If you have any questions or concerns, please reach out to us at [email protected]. We hope you enjoy your new air puriﬁer!

Share the Levoit Love

Find @LevoitLifestyle on social media for wellness + style inspiration. We make every space mindful and chic.

@LevoitLifestyle

#LevoitLove • #LevoitLifestyle

Page 3

Table of Contents

Package Contents

Package Contents Speciﬁcations Safety Information Getting to Know Your Air Puriﬁer Controls Getting Started Using Your Puriﬁer About the Filter Keeping Things Clean Troubleshooting Warranty Information Customer Support

3 3 4 5 6 6 7

8 10 12 14 15

1 x Air Puriﬁer 1 x True HEPA 3-Stage Original Filter

(Pre-Installed)

1 x User Manual 1 x Quick Start Guide

Specifications

Power Supply AC 120V, 60Hz

Rated Power 45W

Eective Range ≤ 215 ft² / 20 m²

CADR 135+ CFM / 230+ m³/h

Operating Conditions

Noise Level 24–50dB

Standby Power < 0.8W

Dimensions 8.7 x 8.7 x 14.2 in /

Weight 7.5lb / 3.4kg

Temperature:

14°F–104°F /

-10°C–40°C

Humidity: < 85% RH

22 x 22 x 36 cm

Page 4

SAFETY INFORMATION

To reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and safety guidelines.

General Safety

• Only use your air puriﬁer as described in

this manual.

• Do not use without removing the plastic

wrap from the ﬁlter. The puriﬁer will not ﬁlter air, and may overheat, causing a ﬁre hazard.

• Do not use your air puriﬁer outdoors.

• Keep your air puriﬁer away from water,

and wet or damp areas. Never place in water or liquid.

• Do not use in excessively humid areas.

• Keep your air puriﬁer away from heat

sources.

• Do not use where combustible gases,

vapors, metallic dust, aerosol (spray) products, or fumes from industrial oil are present.

• Keep 5 ft / 1.5 m away from where oxygen

is being administered.

• Supervise children when they are near

the air puriﬁer.

• Do not place anything into any opening

on the air puriﬁer.

• Do not sit or place heavy objects on the

air puriﬁer.

• Keep the inside of the air puriﬁer dry. To

prevent moisture buildup, avoid placing in rooms with major temperature changes or underneath air conditioners.

• Always unplug your air puriﬁer before

servicing (such as changing the air ﬁlter).

• Do not use your air puriﬁer if it is

damaged or not working correctly, or if the cord or plug is damaged. Do not try to repair it yourself. Contact Customer

Support (see page 15).

• WARNING: Do not use this air puriﬁer

with solid-state speed controls (such as a dimmer switch).

• Not for commercial use. Household use

only.

Power and Cord

• Keep air puriﬁer near the outlet it is

plugged into.

• Never place the cord near any heat

source.

• Do not cover the cord with a rug, carpet,

or other covering. Do not place the cord under furniture or appliances.

• Keep the cord out of areas where people

walk often. Place the cord where it will not be tripped over.

• This appliance has a polarized plug (one

blade is wider than the other). To reduce the risk of electric shock, this plug is intended to ﬁt in a polarized outlet only one way. If the plug does not ﬁt fully in the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician. Do not attempt to defeat this safety feature.

• This air puriﬁer uses standard US 120V,

60Hz outlets. If using outside of the US, check for compatibility.

READ AND SAVE THESE

INSTRUCTIONS

Page 5

GETTING TO KNOW YOUR AIR PURIFIER

A. Fan Speed Indicators B. Fan Speed Button C. Sleep Mode Indicator/Button D. Timer Button E. Timer Indicators F. On/O Button G. Display Lock Button H. Check Filter Indicator

I. Display O Button J. Air Outlet K. Housing L. Air Inlet M. Power Cord N. Filter Cover O. True HEPA 3-Stage Original Filter

Front, upside downBack

Page 6

CONTROLS

GETTING STARTED

On/O Button

• Turns the air puriﬁer on/o.

Fan Speed Button

• Cycles through fan speeds:

I (low), II (medium), and III (high).

Sleep Mode Button

• Turns Sleep Mode on/o

(see page 8).

Timer Button

• Cycles through timer

options (see page 8).

Display Lock Button

• Prevents current settings

from being changed (see page 8).

1. Flip the air puriﬁer over. Twist the ﬁlter

cover counterclockwise and remove it.

[Figure 1.1]

2. Remove the ﬁlter from its plastic

packaging and place the ﬁlter back into the puriﬁer with the handle facing up.

[Figure 1.2]

Note: The ﬁlter does not have a top or bottom and can be installed either way.

Figure 1.1

Check Filter Indicator

• Lights up when the air ﬁlter

should be checked (see page 10).

Display O Button

• Turns the display o.

• Tap any button (except )

to turn the display back on.

Figure 1.2

Page 7

GETTING STARTED (CONT.)

3. Replace the ﬁlter cover and twist

clockwise to lock. [Figure 1.3]

4. Place the puriﬁer on a ﬂat, stable surface

with the display facing up. Allow at least 15 in / 38 cm of clearance on all sides of the puriﬁer. Keep away from anything that would block air ﬂow, such as curtains.

[Figure 1.4]

cover should

snap shut

USING YOUR PURIFIER

1. Plug in and tap to turn on the puriﬁer.

The fan will start on level I. [Figure 2.1]

2. Optionally, tap to change fan speed

between I, II, and III.

Note:

• The indicators are not buttons and

cannot be used to change the fan speed.

• The fan speed indicators will light up

when active.

• Fan speed III is the loudest, but cleans

air the quickest.

• For best results, or to address a speciﬁc

air quality issue such as smoke, run the air puriﬁer at maximum speed (level III) for 15–20 minutes before using a lower speed.

• To eectively clean air, keep windows

and doors closed while the air puriﬁer is on.

15 in / 38 cm

Figure 1.3

Figure 1.4

15 in / 38 cm

3. Tap to turn o the air puriﬁer.

Figure 2.1

Memory Function

When the air puriﬁer is plugged in, it will remember its previous fan speed setting.

Note: The air puriﬁer will not remember timers or Sleep Mode.

Page 8

USING YOUR PURIFIER (CONT.)

ABOUT THE FILTER

Sleep Mode

Sleep Mode operates quietly by using the lowest possible fan speed.

Tap to turn Sleep Mode on/o.

Note:

• All indicators will be at half brightness

while Sleep Mode is on.

• Tapping will exit Sleep Mode.

Timer

You can set a timer for 2, 4, 6, or 8 hours.

1. Tap repeatedly to select a time. The

timer will start automatically.

Note:

• The indicators are not buttons and

cannot be used to select a time.

• The timer indicators will light up blue

when active.

2. Once the timer has ﬁnished, the air

puriﬁer will power o.

3. To cancel a timer, tap until all timer

indicators are o.

Note:

• You can change the fan speed at any

time while the timer is on.

• The timer will restart if the time is

changed.

Display Lock

Locking the display prevents settings from being accidentally changed. Buttons will not respond to being tapped.

1. Tap and hold for 3 seconds to lock/

unlock the display.

Note: You can turn the display on and o even if the display is locked.

The air puriﬁer uses a 3-stage ﬁltration system to purify air.

A. Pre-Filter

• Captures large particles such as dust,

lint, ﬁbers, hair, and pet fur.

• Maximizes the ﬁlter’s life.

B. True HEPA Original Filter

• Removes at least 99.97% of airborne

particles 0.3 micrometers (µm) in diameter.

• Filters small particles such as smoke,

dust, mold spores, bacteria, viruses, and allergens such as pollen, dander, and mites.

C. Activated Carbon Filter

• Physically absorbs unwanted odors

and fumes.

• Filters compounds such as

formaldehyde, benzene, ammonia, hydrogen sulﬁde, and volatile organic compounds (VOCs).

Page 9

ABOUT THE FILTER (CONT.)

Clean Air Delivery Rate

This air puriﬁer has a Clean Air Delivery Rate of 135+ cubic feet per minute (CFM), or 230+ m³/h.

Clean Air Delivery Rate (CADR) measures the eciency of an air puriﬁer by indicating the volume of clean air that an air puriﬁer produces per minute. This is based on removal of dust, pollen, and smoke, which are the 3 most common indoor air pollutants. The higher the CADR, the more particles the air puriﬁer will remove and the larger the area it can clean. The rating is measured at the air puriﬁer’s highest speed.

Air Change per Hour

The air change rate is how many times all of the air in a room can be puriﬁed (or “changed”) by the air puriﬁer in 1 hour. Air changes per hour are calculated on the recommended room size assuming 8 ft / 2.4 m ceilings. For smaller rooms, the air change per hour will increase. The Core 300 has an air change per hour of 5, which means it can change air 5 times at the max speed. This puriﬁer is suggested for use in a single, closed room up to 215 ft² / 20 m².

Humidity

Moisture may damage the air ﬁlters. This air puriﬁer should be used in an area with a humidity level below 85% RH. If you use the air puriﬁer in excessively humid areas, the surface of the ﬁlter will become moldy.

Note: Water or moisture will allow mold to grow. Air puriﬁers cannot solve an existing mold problem, only remove mold spores and reduce odors.

Essential Oils

Do not add essential oils to the air puriﬁer

or air ﬁlter. The ﬁlter will become damaged by the oil and will eventually release an unpleasant smell. Do not use oil diusers near the puriﬁer.

Note: To eectively clean air, keep windows and doors closed while the air puriﬁer is on.

Page 10

KEEPING THINGS CLEAN

Cleaning the Air Purifier

• Unplug before cleaning.

• Wipe the outside of the air puriﬁer with

a soft, dry cloth. If necessary, wipe the housing with a damp cloth, then immediately dry.

• Vacuum the inside of the air puriﬁer.

• Do not clean with abrasive chemicals or

ﬂammable cleaning agents.

When Should I Replace the Air Filter?

The ﬁlter should be replaced every 6–8 months. You may need to replace your ﬁlter sooner or later depending on how often you use your air puriﬁer. Using your air puriﬁer in an environment with relatively high pollution may mean you will need to replace the ﬁlter more often, even if is o.

You may need to replace your ﬁlter if you notice:

• Increased noise when the air puriﬁer

is on

• Decreased airﬂow

• Unusual odors

• A visibly clogged ﬁlter

Note:

• To maintain the performance of your air

puriﬁer, only use ocial Levoit ﬁlters. To buy replacement ﬁlters, visit Levoit’s online store. Go to levoit.com for more information.

• Remember to reset after changing

the ﬁlter.

Check Filter Indicator

will light up as a reminder to check the air ﬁlter. Depending on how much you use the air puriﬁer, the indicator should turn on within 6–8 months. You may not need to replace your ﬁlter yet, but you should check it when

turns on.

Cleaning the Air Filter

The True HEPA 3-Stage Original Filter should be cleaned once a month to increase the eciency and extend the life of your ﬁlter. Clean the inside and outside of the ﬁlter using a soft brush or vacuum hose to remove hair, dust, and large particles. [Figure 3.1] Do

not clean the ﬁlter with water or other liquids.

Filter

Pre-Filter

True HEPA

& Activated

Carbon

Filter

When to

Clean

Every 2–4

weeks

Do not

clean

When to

Replace

6–8 months

Figure 3.1

Page 11

KEEPING THINGS CLEAN (CONT.)

Resetting the Check Filter Indicator

Reset the Check Filter Indicator when:

A. lights up.

1. Replace the air ﬁlter.

2. Turn on the air puriﬁer.

3. Press and hold for 3 seconds.

4. will turn o when successfully

reset.

B. The air ﬁlter was changed before

lit up.

1. Press and hold for 3 seconds.

This will turn on .

2. Press and hold again for 3

seconds.

3. will turn o when successfully

reset.

Replacing the Air Filter

1. Unplug the air puriﬁer. Flip the air puriﬁer

over and remove the ﬁlter cover (see

Getting Started, page 6).

2. Remove the old air ﬁlter.

3. Clean out any remaining dust or hair

inside the puriﬁer using a vacuum hose.

Do not use water or liquids to clean the

puriﬁer. [Figure 3.2]

4. Unwrap the new air ﬁlter and place it into

the housing (see Getting Started,

page 6).

5. Replace the cover and cap. Plug in the

air puriﬁer.

6. Reset the Check Filter Indicator (see

page 10).

Storage

If not using the air puriﬁer for an extended period of time, wrap both the puriﬁer and the ﬁlter in plastic packaging and store in a dry place to avoid moisture damage.

Figure 3.2

Page 12

TROUBLESHOOTING

Problem Possible Solution

Air puriﬁer will not turn on or respond to button controls.

Airﬂow is signiﬁcantly reduced. Make sure the ﬁlter is removed from its packaging and

Air puriﬁer makes an unusual noise while the fan is on.

Strange smell coming from the puriﬁer.

Plug in the air puriﬁer.

Check to see if the power cord is damaged. If so, stop using the air puriﬁer and contact Customer Support (see page 15).

Plug the air puriﬁer into a dierent outlet.

The air puriﬁer is malfunctioning. Contact Customer

Support (see page 15).

properly in place (see page 6).

Tap to increase the fan speed.

Make sure there are at least 15 in / 38 cm of clearance on all sides of the air puriﬁer.

The pre-ﬁlter may be clogged by large particles, such as hair or lint, blocking air ﬂow. Clean the pre-ﬁlter (see page 10).

Replace the air ﬁlter (see page 11).

Make sure the air ﬁlter is properly in place with plastic packaging removed (see page 6).

Make sure the air puriﬁer is operating on a hard, ﬂat, even surface.

Replace the air ﬁlter (see page 11).

The air puriﬁer may be damaged, or a foreign object may be inside. Stop using the air puriﬁer and contact Customer

Support (see page 15). Do not try to repair the air

puriﬁer.

Clean the ﬁlter or replace if necessary.

Contact Customer Support (see page 15).

Make sure not to use your puriﬁer in an area with high humidity or while diusing essential oils.

Page 13

TROUBLESHOOTING (CONT.)

Problem Possible Solution

Poor air puriﬁcation quality.

is still on after replacing the

air ﬁlter.

has not turned on within 8

months.

turned on before 6 months. is a reminder for you to check the air ﬁlter and will light

If your problem is not listed, please contact Customer Support (see page 15).

Tap to increase the fan speed.

Make sure no objects are blocking the sides or top of the air puriﬁer (the inlet or outlet).

Make sure the ﬁlter is removed from its packaging and properly in place (see page 6).

Close doors and windows while using the air puriﬁer.

Make sure the room is smaller than 215 ft² / 20 m². The air puriﬁer may not be as eective in larger rooms.

Replace the ﬁlter (see page 11).

Reset the Check Filter Indicator (see page 11).

is a reminder for you to check the air ﬁlter and will light up based on how long the air puriﬁer has been used (see page 11). If you don’t use your air puriﬁer often, will take longer to turn on.

up based on how long the air puriﬁer has been used (see page 11). If you run your air puriﬁer frequently, will turn on sooner.

Page 14

WARRANTY INFORMATION

Product Name True HEPA Air Puriﬁer

Model Core 300

Default Warranty

For your own reference, we strongly recommend

that you record your order ID and date of

Date of Purchase

Order ID

1 year

Period

purchase.

Terms & Policy

Arovast Corporation warrants all products to be of the highest quality in material, craftsmanship, and service, eective from the date of purchase to the end of the warranty period.

Arovast Corporation will replace any product found to be defective due to manufacturer ﬂaws based on eligibility. Refunds are available within the ﬁrst 30 days of purchase. Refunds are only available to the original purchaser of the product. This warranty extends only to personal use and does not extend to any product that has been used for commercial, rental, or any other use in which the product is not intended for. There are no warranties other than the warranties expressly set forth with each product.

This warranty is non-transferrable. Arovast Corporation is not responsible in any way for any damages, losses, or inconveniences caused by equipment failure or by user negligence, abuse, or use noncompliant with the user manual or any additional safety or use warnings included in the product packaging and manual.

Arovast Corporation and its subsidiaries assume no liability for damage caused by the use of the product other than for its intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses so the foregoing disclaimer may not apply to you. This warranty gives you speciﬁc legal rights and you may also have other rights which may vary from state to state.

ALL EXPRESSED AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

Additional 1-Year Warranty

You can extend your 1-year warranty by an additional year. Log onto www.levoit.com/warranty to register your new product for the extended warranty.

Please ﬁll out all required ﬁelds and include your order ID, place of purchase, and purchase date, if applicable.

Defective Products & Returns

If you discover your product is defective within the speciﬁed warranty period, please contact Customer Support via [email protected] with a copy of your invoice and order ID. DO NOT dispose of your product before contacting us. Once our Customer Support Team has approved your request, please return the product with a copy of the invoice and order ID.

This warranty does not apply to the following:

• Damage due to abuse, accident, alteration, misuse, tampering, or vandalism.

• Improper or inadequate maintenance.

• Damage in return transit.

• Unsupervised use by children under 18 years of age.

Page 15

CUSTOMER SUPPORT

If you encounter any issues or have any questions regarding your new product, feel free to contact our helpful Customer Support Team. Your satisfaction is our goal!

Customer Support

Arovast Corporation

1202 N. Miller St., Suite A Anaheim, CA 92806

Email: [email protected] Toll-Free: (888) 726-8520

Support Hours

Mon–Fri, 9:00 am–5:00 pm PST/PDT

*Please have your order invoice and order ID ready before contacting Customer Support.

Page 16
