PRODUCT DATA
Plug-in Dimmer with Wi-Fi Technology
decora smart
APPLICATIONS
Schedule or dim your plug-in lamps from anywhere.
Control connected loads and lights using the free
My Leviton app for iOS and Android, no hub required.
Simplify control of the residence – schedule lights
and connected loads to turn on/o at specific
times or based on sunrise/sunset, easily group
smart devices into rooms, and create scenes to
activate multiple lights at once. Integrate with
IFTTT, utilize auto-shuto feature as a countdown
timer in closets, hallways and bathrooms; plus
engage home vs. away to enact randomization of
lighting control, providing a lived-in appearance.
Customize your experience with adjustable fade
rates, maximum/minimum illumination levels, and
more if desired. Supports LED and CFL technologies
up to 100 Watts along with support for legacy
incandescent lighting loads up to 300 Watts.
Reduce energy consumption, provide dramatic
scene transitions, and utilize the wireless aordable
plug-in for table and floor lamps.
AMAZON ALEXA VOICE CONTROL
Compatible with all products that support Amazon
Alexa providing voice control of the load: “Alexa, dim
living room lights to 25%”. Alexa devices (including
Echo, Dot, and Tap) sold separately.
™
GOOGLE ASSISTANT VOICE CONTROL
“Ok Google, turn [My Leviton device name] On”.
Works with the Google Assistant. Google Home is
a voice enabled speaker powered by the Google
Assistant. Easily control smart devices around the
home. (Google Assistant devices sold separately).
LOW-WATTAGE LED LOADS
The new lighting control accessories are engineered
to function with extremely sensitive, low-wattage
light sources, such as a single LED bulb in a hallway
or a strand of holiday lights, ensuring LEDs do not
glow when o.
BENEFITS
• Control your lights from anywhere using the
free My Leviton app for iOS and Android, no hub
required.
• Amazon Alexa products provide voice control:
“Alexa, turn on living room lights”. (Echo, Tap, and
Dot sold separately).
• Works with Google Assistant including Google
Home for voice control. “Ok Google, set [My
Leviton device name] to [1-100]%”
• Integrate with IFTTT for additional third-party
functionality
• Simplify control of your home - schedule lights and
connected loads to turn on/o at specific times
or based on sunrise/sunset, easily group your
smart devices into rooms, and create scenes
to activate multiple lights at once.
FEATURES
• Button for manual control and dimming
• Transient surge protection to IEC Level 4
• ESD protection to IEC 1000 4-2 Level 4
to protect against damage
• Green LED locator
• Provides polarized 300W-120VAC NEMA
5-15R receptacle
• Provides manual ON/OFF
• Provides ON/OFF scene and zone control
compatibility
• 2-way status updates
• Protected memory maintains ON/OFF status
of loads during minor power fluctuations
Plug-in Dimmer with Wi-Fi Technology
Leviton Manufacturing Co., Inc. Global Headquarters
201 N. Service Rd. Melv ille, NY 11747-3138 Tech Line: 1-800-824-3005 Fax: 1-800-832-9538
Leviton Manufacturing Co., Inc. Energy Management, Controls and Automation.
4330 Micho ud Blvd., New Orleans, LA, 70129 Tel: 1-504-736-9810 Fax: 1-504-253-2954
Visit our Website at: www.leviton.com/decorasmart
©2017 Leviton Manufacturing Co., Inc. All rights reserved. Subject to c hange without notice.
Page 2
PRODUCT DATA
DR AWING
DW3HL
1.95 (44.5)
0.66 (16.8)
1.15 (29.2)
RATINGS
• Incandescent - 300W - 120VAC, 60Hz
• LED/CFL - 100W - 120VAC, 60Hz
AGENCY STANDARDS AND COMPLIANCE
• Complies with UL 1472
• CSA Certified (File #003413)
• NOM-ANCE Certified
• Wi-Fi CERTIFIED™
• Complies with FCC Part 15, Class B
0.47 (12.0)
2.97 (75.3)
WARRANTY INFORMATION
• Five-Year Limited Warranty
Plug-in Dimmer with Wi-Fi Technology
ORDERING INFORMATION
DESCRIPTION CAT. NO.
Plug-in Dimmer with Wi-Fi Technology –
120VAC 60Hz Incandescent, 300W, 2.5A LED/CFL; 100W
Leviton Manufacturing Co., Inc. Global Headquarters
201 N. Service Rd. Melv ille, NY 11747-3138 Tech Line: 1-800-824-3005 Fax: 1-800-832-9538
Leviton Manufacturing Co., Inc. Energy Management, Controls and Automation.
4330 Micho ud Blvd., New Orleans, LA, 70129 Tel: 1-504-736-9810 Fax: 1-504-253-2954
Visit our Website at: www.leviton.com/decorasmart
©2017 Leviton Manufacturing Co., Inc. All rights reserved. Subject to c hange without notice.
DW3HL-1BW
SAT-10114
REV JUL 2017
