LevelOne VDS-0120 User Manual

LevelOne

User Manual

VDS-0120

Ethernet over VDSL2 Converter (PSE)

V1.0

1

Table of Content

1. Introductions ......................................................... 3

2. Application Notes .................................................. 3

3. Features ............................................................... 4

4. Packing Contents .................................................. 4

5. LED Indicators ...................................................... 5

6. Dip Switches Settings ........................................... 5

7. Data Rates & Distances ........................................ 7

2

VDS-0200

VDS-0120

1. Introductions

The VDS-0120, a VDSL2 (Very high-bit-rate Digital Subscriber Line) PSE LAN Extender,
provides a broadband transmission up to 100/60Mbps of downstream/upstream data rate over
single pair copper line for point-to-point Ethernet connectivity. With 100/60Mbps data rate,
VDS-0120 supports transmission distance up to 300 meters, and 30/10 Mbps for 1km long range
connection. Users may also select a fixed data rate or a fixed SNR margin for different copper line
ranging. With Power Sourcing Equipment, VDS-0120 provides power supply over Ethernet cable to
the 802.3af compliant power device.

With plug and play features and minimum installation time, each VDS-0120 can be configured into
either CO for central side or RT for remote side by dip switch setting. The VDS-0120 conforms to
the ITU-T G.993.1 and G.993.2 to meet VDSL/VDSL2 and SG15Q4 DMT for network requirements.
A pair of VDS-102 and VDS-0120 offers a cost effective solution for bandwidth-hungry applications
such as LAN-to-LAN connectivity, Video Streaming, FTTB, and MDU/MTU over single twisted pair
telephone line.

2. Application Notes

1) Ethernet To Ethernet Bridge Extension

3
