Page 1
SohoCon_FSW-2106
one world_one brand_one level_
5-port 10/100Mbps + 1-port SC Fiber Switch
FSW-2106
Related Products
FNC-0113TX
10/100Mbps Ethernet Card
FSW-2218
8-port 10/100Mbps Fast
Ethernet Switch
Provides Wire-speed, Non-blocking Performance - LevelOne FSW-2106 Fast
Ethernet Switch is a wire-speed, non-blocking networking device that
provides 5 ports 10/100 Mbps Fast Ethernet and 1 port SC Fiber connecti ons.
This switch combines dynamic memory allocation with a store-and-forward
switching architecture to ensure that the buffer is effectively allocated for
each port. It also controls the data flow between transmit and receive
nodes to guarantee against all possible packet loss.
Integrated Network Connection-- The FSW-2106 features full-duplex
operations to effectively double bandwidth to a throughtput of 200Mbps for
maximun performance. All Fast Ethernet ports support Auto-MDI X allowing
uplinking to another switch with either cross-over or straight cabl e. The fiber
port with SC interface allow users to extend the network connection
distance or to integrate other advanced solutions in the future without
further investment.
Easy Configuration, Internal Power Switch--LevelOne FSW-2106 Fast Ethernet
switch is "Plug-&-Play". It does not require software configuration. Users can
immediately use any of the features of this product simply by attaching the
cables and turning on the power. For instant error detection, this switch is
equipped with a full range of LEDs to help you monitor and troubleshoot
problems on your network.
Compact Size Design --This unit is compact specially desi gned to fit on the
desktop or in other space-limited locations. The FSW-2106 switch provides an
ideal solution for businesses that crave a rel iable network to exchange large
data files and multimedia i nformation with bandwidth-starving workgroups,
departments, and offices.
GSW-0504
5-port Gigabit Switch w/
Internal Power
Key Features
Provides 5 x 10/100Mbps + 1 x SC fiber connections
Complies IEEE 802.3 10Base-T, 802.3u 100Base-T,
100Base-FX and 802.3x flow control
Compact size design
Wire-speed and non-blocking forwarding rate
Store –and-forward switching ensures error-free
transmission
2K MAC address table
Auto MDI/MDIX on all ports
N-way Auto-negotiation on all ports
Full-duplex IEEE802.1x flow control
Half-duplex back pressure flow control
Plug-and-Play, nothing to configure
LEDs on front panel for easy access and real time
viewing status of switch
Page 2
SohoCon_FSW-2106
one world_one brand_one level_
Technical Specification
Standards Compliance
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX, 100Base-FX Fast Ethernet
IEEE 802.3x Flow Control and Back Pressure
Ports
5 x 10/100 Mbps RJ-45 ports
1 x SC fiber port
Protocol
CSMA/CD
Switch Architecture
Store-and-Forward
MAC Address Table
2K MAC Address Table
Packet Buffer
96KBytes
Transfer Rate
14,880 Packets per second for 10Mbps
148,800 Packets per second for 100Mbps
Flow Control
Half Duplex: backpressure
Full Duplex: pause frame
Network Cables
10Base-T: 2-pair UTP/STP Cat.3/4/5 cable EIA/TIA-568 100Ω(100m)
100Base-TX: 2-pair UTP/STP Cat. 5, cable EIA/TIA-568 100Ω(100m)
LEDs
Per Device: System Power
Per RJ-45 port: Link/Activity, Full duplex/Collision, 100Mbps
Power Supply
External Power Supply, DC 9V, 700mA
Power Consumption
6 Watts (max)
Temperature
Operating: 0ﾟC ~45ﾟC (32ﾟF ~ 113ﾟF)
Humidity
Operating: 10% ~ 90% (Non-condensing)
Dimension
164mm(L) * 100mm(W) * 26mm(H)
EMI
FCC Class A, CE
Product Diagram
Ordering Information
FSW-2106: 5-port 10/100Mbps +1-port SC Fiber Switch
For more information, please contact your LevelOne representative, or visit www.level1.com
All technical specifications are subject to change without notice.
All mentioned brand names are registered trademarks and property of their owners
