LevelOne Bluetooth USB Adapter User Manual
Bluetooth USB Adapter User’s Manual
.
Bluetooth USB Adapter
User’s Manual
April 3, 2003 LEVELONE i
Bluetooth USB Adapter User’s Manual
REGULATION INFORMATION
The Bluetooth USB Adapter must be installed and used in strict accordance with the
manufacturer’s instructions. This device complies with the following radio frequency and
safety standards.
FCC (Federal Communications Commission)
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance 20cm between
the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
The equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction, may cause harmful interference to radio
communication. However, there is no grantee that interference will not occur in a particular
installation. If this equipment dose cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Notice: The Part 15 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification not expressly approved by the
party responsible could void the user’s authority to operate the device.
R&TTE Directive
This device complies with the specifications listed below:
• ETS 301 489 -1 & -17 General EMC requirements for Radio equipment.
• ETS 300 328 Technical requirements for Radio equipment.
• EN60950 Safety Requirements for Radio equipment
April 3, 2003 LEVELONE ii
Bluetooth USB Adapter User’s Manual
LICENSED SOFTWARE
© Copyright 2000 – 2003, DDCAsia, Ltd. (“LEVELONE”). All rights reserved.
Warning: This software and accompanying documentation are protected by copyright law and
international treaties. Unauthorized reproduction or distribution of this software, or any portion of it, may
result in severe civil and criminal penalties, and will be prosecuted to the maximum extent possible under the
law.
Use of this software is governed by the terms of the end user license agreement that accompanies or is
included with such software. Unless otherwise noted in the end user license agreement, or herein, no part of
the documentation accompanying this software, whether provided in printed or electronic form may be
reproduced in any form, or stored in a database or retrieval system, or transmitted in any form or by any
means, or used to make any derivative work (such as translation, transformation, or adaptation) without the
express, prior written consent of DDCAsia, Ltd
Trademark(s) ™ and Registered Trademark(s) ®
LEVELONE and the LEVELONE logo are trademarks of DDCAsia, Ltd
Bluetooth and the Bluetooth logos are trademarks owned by Bluetooth SIG, Inc., U.S.A. and licensed to
DDCAsia, Ltd.
Microsoft, Windows, Outlook are registered trademarks of Microsoft Corporation.
Other brand and product names may be registered trademarks or trademarks of their respective holders.
April 3, 2003 LEVELONE iii
Bluetooth USB Adapter User’s Manual
Table of Contents
1 INTRODUCTION.................................................................................................................. 1
1.1 Bluetooth Technology............................................................................................1
1.2 Bluetooth USB Adapter ........................................................................................1
2 SOFTWARE INSTALLATION ........................................................................................... 2
2.1 System Requirements ............................................................................................2
2.2 Before Installation .................................................................................................2
2.3 Install LevelOne Bluetooth Software.......................................................................2
2.4 Hardware Installation.............................................................................................7
3 INTRODUCTION.................................................................................................................. 8
3.1 Bluetooth Tray ......................................................................................................8
3.2 Access My Bluetooth Places................................................................................... 8
3.3 Icons Used for Bluetooth Devices and Services ........................................................9
4 BASIC OPERATIONS........................................................................................................12
4.1 Start or Stop Bluetooth.........................................................................................12
4.2 Create a Connection From the Bluetooth Icon in the System Tray ............................12
4.3 Create a Connection Using the Bluetooth Setup Wizard ..........................................12
4.4 Create a Connection From Entire Bluetooth Neighborhood .....................................12
4.5 Find Bluetooth Devices........................................................................................ 13
4.5.1 Periodic Search for Devices ..................................................................................13
4.6 Find A Service .................................................................................................... 14
4.7 Bluetooth Connection Status.................................................................................15
4.8 Send to Bluetooth................................................................................................16
5 CONFIGURE BLUETOOTH............................................................................................. 17
5.1 Access the Bluetooth Configuration Panel .............................................................17
5.2 Bluetooth Services versus Bluetooth Applications .................................................. 17
5.3 Bluetooth Exchange Folder ..................................................................................17
5.4 General Configuration Settings.............................................................................18
5.5 Bluetooth Applications ........................................................................................18
5.5.1 Overview ................................................................................................................ 18
5.5.2 General Configuration...........................................................................................18
5.5.3 Human Interface Device ........................................................................................19
5.5.4 Audio Gateway.......................................................................................................20
5.5.5 Bluetooth Serial Port .............................................................................................21
5.5.6 Dial-up Networking ...............................................................................................22
5.5.7 Fax ......................................................................................................................... 23
5.5.8 Headset ..................................................................................................................24
5.5.9 File Transfer ..........................................................................................................25
5.5.10 Network Access ...................................................................................................... 26
5.5.11 PIM Synchronization .............................................................................................27
5.5.12 PIM Item Transfer.................................................................................................. 29
5.5.13 Printer....................................................................................................................31
5.6 Bluetooth Services...............................................................................................32
5.6.1 Notifications...........................................................................................................33
5.6.2 Audio Gateway.......................................................................................................35
iv
Bluetooth USB Adapter User’s Manual
5.6.3 Bluetooth Serial Port .............................................................................................36
5.6.4 Dial-up Networking Service................................................................................... 37
5.6.5 Fax Service............................................................................................................. 37
5.6.6 File Transfer Service.............................................................................................. 38
5.6.7 Headset Service...................................................................................................... 39
5.6.8 Network Access ...................................................................................................... 40
5.6.9 PIM Item Transfer.................................................................................................. 42
5.6.10 PIM Synchronization .............................................................................................45
5.7 Hardware Settings ...............................................................................................46
5.7.1 Advanced Settings .................................................................................................. 47
5.8 Accessibility Settings...........................................................................................48
5.9 Discovery Settings...............................................................................................49
6 SECURITY...........................................................................................................................50
6.1 Authentication ....................................................................................................50
6.2 Authorization......................................................................................................50
6.3 Bluetooth Device Identity ....................................................................................50
6.4 Encryption..........................................................................................................50
6.5 Link Key ............................................................................................................ 50
6.6 Pairing Devices ...................................................................................................51
6.7 Passkey ..............................................................................................................51
6.8 Secure Connection...............................................................................................51
6.9 Security Request Dialog Box................................................................................51
7 TROUBLESHOOTING ...................................................................................................... 52
7.1 Cannot connect to a paired device .........................................................................52
7.2 Cannot discover services on an un-paired remote device .........................................52
7.3 Dial-up Networking service does not start.............................................................. 52
7.4 Determine the Bluetooth Device Address (BDA) of my hardware device..................52
7.5 Determine the version of the Host Controller Interface (HCI) ..................................52
7.6 Determine the version of the Link Manager Protocol (LMP)....................................52
7.7 Find information about the Bluetooth hardware attached to my computer .................52
7.8 Internet Connection Sharing Does Not Work .........................................................53
7.9 Test a Network Access connection ........................................................................53
7.10 Unknown Port message when using a Bluetooth Serial Port.................................53
7.11 Bluetooth Headset Doesn’t Always Function Under WIN 98 ...............................53
8 PRODUCT SPECIFICATIONS.........................................................................................55
9 GLOSSARY ......................................................................................................................... 56
v
Bluetooth USB Adapter User’s Manual
Table of Figures
Figure 2-1: Preparing to Install LevelOne Bluetooth Software .........................2
Figure 2-2: License Agreement Window .............................................................3
Figure 2-3: Destination folder selection ..............................................................3
Figure 2-4: Installation running window ............................................................4
Figure 2-5: Digital Signature dialog box.............................................................4
Figure 2-6: Bluetooth Device Insertion dialog box.............................................5
Figure 2-7: Installation finished window ............................................................6
Figure 2-8: Bluetooth icons .................................................................................6
Figure 2-9: Plug the Bluetooth USB Adapter into USB port on desktop PC.....7
Figure 2-10: Plug the Bluetooth USB Adapter into USB port on laptop PC.....7
Figure 3-1: Bluetooth Icon...................................................................................9
Figure 3-2: Device Icons for Windows 9x, Me and 2K.......................................9
Figure 3-3: Service Icons for Windows 9x, Me and 2K ...................................10
Figure 3-4: Device Icons for Windows XP ........................................................10
Figure 3-5: Service Icons for Windows XP .......................................................11
vi
Bluetooth USB Adapter User’s Manual
1 Introduction
1.1 BLUETOOTH TECHNOLOGY
Bluetooth Technology eliminates proprietary cables, allowing mobile users to connect to
mobile computing devices effortlessly and without wires. It is intended to be used for both
voice and data communications in local area within a range of 10 to 100 meters. Bluetooth
operates in the 2.4 GHz ISM (Industrial Scientific Medical) frequency band, which is
reserved for license-free operation in most countries. Its key features are robustness, low
complexity, low power and low cost. The technology also offers wireless access to LANs,
PSTN, the mobile phone network and the Internet for a host of home appliances and
portable handheld interfaces.
1.2 BLUETOOTH USB ADAPTER
The Bluetooth USB Adapter allows a computer with a USB port to communicate with
other Bluetooth-enabled devices. When used with the Bluetooth application software it can
perform wireless network applications such as information exchange, file transfer, network
access, dial-up networking, headset, audio gateway, printer application, and so on.
1
Bluetooth USB Adapter User’s Manual
2 Software Installation
2.1 SYSTEM REQUIREMENTS
It is necessary to install Bluetooth application software before starting to use the Bluetooth
USB Adapter. Therefore, please check your system in advance and ensure it meets the
minimum requirements as described below.
- Processor: Intel Celeron / Pentium III / Pentium IV; AMD Duron / Athlon
- Operating System: Microsoft Windows 98SE / ME / 2000 / XP
- System memory: 32MB at least
- Hard Drive Free Space: 11.5MB
2.2 BEFORE INSTALLATION
Don’t plug the Bluetooth USB Adapter into USB port on your PC before installation .
Please remove any previous version of LevelOne Bluetooth software existing in your
system. The remove procedures are as follows:
1. Click Start/Settings, then select Control Panel.
2. In the Control Panel window, double click Add/Remove programs icon.
3. Find out the item LevelOne Bluetooth Software x.x.x.x then remove it.
2.3 INSTALL LEVELONE BLUETOOTH SOFTWARE
Insert the Bluetooth Software CD into CD-ROM drive. If the Auto-Run function of
CD-ROM is enabled (in Windows, the default setting of this function is usually enabled),
installation program will start automatically. If not, you can utilize the Windows Explorer
to browse CD content and run Setup.exe manually.
Figure 2-1: Preparing to Install LevelOne Bluetooth Software
When ensuing window appears, please click Next button to continue the software
installation.
2
Bluetooth USB Adapter User’s Manual
Then in the License Agreement window, check the item I accept the terms in the license
agreement and click Next button to continue
Figure 2-2: License Agreement Window
.
The software default destination folder is located at C:\ Program Files \ LevelOne
MDU-0005USB \ . If you want to change the folder, click Change… button then select one
you prefer. If everything is ready and done, please click Next button.
Figure 2-3: Destination folder selection
Then click Install button to begin the installation.
3
Bluetooth USB Adapter User’s Manual
The software installation is processing now.
Figure 2-4: Installation running window
Note: During the processing of the Bluetooth Software installation under Windows 98SE or
Windows 2000, it is possible to meet Microsoft Digital Signature issues such as Bluetooth
Personal Area Network Driver, Bluetooth Communication Ports, LevelOne Bluetooth
Null Modem, LevelOne Bluetooth Modem, LevelOne Bluetooth Fax Modem, and
Unknown Software package. Please confirm them manually by pressing OK button in
these pop-up windows.
Figure 2-5: Digital Signature dialog box
4
Bluetooth USB Adapter User’s Manual
When the “Bluetooth device not found” window pops out, plug Bluetooth USB adapter
into laptop or PC and click “OK.”
Figure 2-6: Bluetooth Device Insertion dialog box
5
Bluetooth USB Adapter User’s Manual
Please reboot your system after the software installation is finished.
Figure 2-7: Installation finished window
After rebooting, when you log in Windows operating system there will be two new Bluetooth icons
appearing on the desktop and the Windows System Tray respectively.
Figure 2-8: Bluetooth icons
6
Bluetooth USB Adapter User’s Manual
2.4 HARDWARE INSTALLATION
The Bluetooth USB Adapter can be used by both desktop and laptop PC with USB port as
shown bellow:
Figure 2-9: Plug the Bluetooth USB Adapter into USB port on desktop PC
Figure 2-10: Plug the Bluetooth USB Adapter into USB port on laptop PC
7
Bluetooth USB Adapter User’s Manual
3 Introduction
3.1 BLUETOOTH TRAY
The Bluetooth tray resides in the Windows system tray, which is normally located in the
lower-right corner of the screen. The Bluetooth tray provides fast access to most Bluetooth
operations.
From the Bluetooth tray you can:
•
Access My Bluetooth Places—double-click the Bluetooth icon, or right-click the
Bluetooth icon and then select Explore My Bluetooth Places.
•
Access the Bluetooth Setup Wizard. This wizard will help you:
Configure how this computer accesses a service on another Bluetooth device
Locate remote Bluetooth devices
Configure the way that this computer provides services to remote Bluetooth
devices
Set the name and type of this Bluetooth device, e.g., “John's PC” and
“Desktop.”
•
Access the Bluetooth Configuration Panel—right-click the Bluetooth icon, and
then select Advanced Configuration.
•
Access the Quick Connect option—right-click the Bluetooth icon, select Quick
Connect, and then select the type of service to which you wish to connect.
•
Start/Stop Bluetooth on this computer.
3.2 ACCESS MY BLUETOOTH PLACES
My Bluetooth Places is part of Windows Explorer.
There are multiple ways to access My Bluetooth Places:
•
In the Windows system tray
Right-click the Bluetooth icon and select Explore My Bluetooth Places
or
Double-click the Bluetooth icon
•
On the desktop, double-click the Bluetooth icon
•
Open Windows Explorer and select My Bluetooth Places in the Folders pane or
from the Address shortcut menu.
8
Bluetooth USB Adapter User’s Manual
3.3 ICONS USED FOR BLUETOOTH DEVICES AND SERVICES
Bluetooth icons provide at-a-glance feedback about a device or service's status by
changing appearance.
The Bluetooth icon in the Windows system tray provides feedback about Bluetooth status.
Bluetooth Icon Indicates Bluetooth Status
Enabled Disabled Connected
Blue with White
Figure 3-1: Bluetooth Icon
Device Icons for Windows 9x, Me and 2K
Name Normal Connected Paired
Audio Gateway
Desktop
Headset
Human Interface Device
Laptop
Modem
Network Access Point
Personal Digital Assistant
Printer
Blue with Red
Blue with Green
Telephone
Unknown
Figure 3-2: Device Icons for Windows 9x, Me and 2K
9
Bluetooth USB Adapter User’s Manual
Service Icons for Windows 9x, Me and 2K
Name Normal Connected Not Available*
Audio Gateway
Dial-up Networking
Fax
Headset
Network Access
PIM Item Transfer
PIM Synchronization
Public Folder
Serial Port
*Services may be unavailable because they are in use or because the necessary hardware is not installed.
Figure 3-3: Service Icons for Windows 9x, Me and 2K
Device Icons for Windows XP
Name Normal Connected Paired
Audio Gateway
Desktop
Headset
Human Interface Device
Laptop
Modem
Network Access Point
Personal Digital Assistant
Printer
Telephone
Unknown Device
Figure 3-4: Device Icons for Windows XP
10
Bluetooth USB Adapter User’s Manual
Service Icons for Windows XP
Name Normal Connected Not Available*
Audio Gateway
Dial-up Networking
Fax
Headset
Network Access
PIM Item Transfer
PIM Synchronization
Public Folder
Serial Port
*Services may be unavailable because they are in use or because the necessary hardware is not installed.
Figure 3-5: Service Icons for Windows XP
11
Bluetooth USB Adapter User’s Manual
4 Basic Operations
4.1 START OR STOP BLUETOOTH
To start Bluetooth: in the Windows system tray, right-click the Bluetooth icon and select
Start the Bluetooth Device. The Bluetooth icon is blue in color with a white insert when
Bluetooth is running.
To stop Bluetooth: in the Windows system tray, right-click the Bluetooth icon and select
Stop the Bluetooth Device. The Bluetooth icon is blue in color with a red insert when
Bluetooth is stopped.
4.2 CREATE A CONNECTION FROM THE BLUETOOTH ICON IN THE SYSTEM TRAY
In the Windows system tray, right-click the Bluetooth icon, select Quick Connect and then
the Bluetooth service that you wish to use.
If this computer has created a connection to the desired type of service in the past, the
options on the shortcut menu are:
The name(s) of any device(s) with which prior connections to this type of service
•
have been established. Select a name from the list to re-establish connection.
•
Other Devices…Select this option to search for additional devices that potentially
provide the desired service, select a device from the list, and then click Connect.
If this computer has never created a connection to this type of service, the only option on
the shortcut menu is “Find Devices….” Select this option to search for devices that
potentially provide the desired service, select a device from the list, and then click Connect.
4.3 CREATE A CONNECTION USING THE BLUETOOTH SETUP WIZARD
•
From the Folders pane of Windows Explorer, right-click My Bluetooth Places and
select Bluetooth Setup Wizard
or
•
In Windows Explorer, with My Bluetooth Places selected, from the Bluetooth
menu, select Bluetooth Setup Wizard
or
•
From the Windows system tray: right-click the Bluetooth icon and select
Bluetooth Setup Wizard.
Follow the wizard's on-screen instructions.
4.4 CREATE A CONNECTION FROM ENTIRE BLUETOOTH NEIGHBORHOOD
From Windows Explorer:
•
In the Folders pane, select Entire Bluetooth Neighborhood, right-click a device
name and select “Connect …” the desired service.
or
•
In the Folders pane, expand Entire Bluetooth Neighborhood, select a device, and
then, in the right pane, right-click a service provided by that device and select
“Connect to…”
NOTE: Only available services are displayed in the menus.
12
Bluetooth USB Adapter User’s Manual
4.5 FIND BLUETOOTH DEVICES
Search for Devices looks for Bluetooth devices in the vicinity and displays the devices
that it finds in My Bluetooth Places.
To start a search for devices, in the Folders pane of My Bluetooth Places, select Entire
Bluetooth Neighborhood, and then, from the Bluetooth menu, select Search for Devices.
NOTE: The Bluetooth menu is only visible when My Bluetooth Places is active.
4.5.1 Periodic Search for Devices
Bluetooth can be configured to automatically search for devices on a regular basis
(Bluetooth Configuration Panel > Discovery tab).
One of the advantages of Bluetooth is the mobility that the wireless connections allow.
However, mobility means that devices may move in or out of connection range during the
time between the automatic updates performed by Bluetooth. To be certain that the
displayed list of devices in the neighborhood is current, or if automatic periodic inquiry is
not enabled, force an update of the device list using the technique described in Search for
Devices, above.
Some devices within connection range may not show up in the list of devices found
because:
Your device is configured to report only specific types or classes of devices
•
(Bluetooth Configuration Panel > Discovery tab, on your device).
• The unlisted device is configured to be non-discoverable (Bluetooth Configuration
Panel > Accessibility tab, on the un-listed device).
13
Loading...
