XC16 Air Conditioner ◆ Up to 17.20 SEER

LEnnoX’ ELItE® SErIES

Home Comfort Systems

Xc16

High-efficiency, two-stage cooling

Compatible with the exclusive Humiditrol®
whole-home dehumidification system—
indoor air quality you can feel

Elite® Series XC16 Air Conditioner

Two-stage operation optimizes

™

cooling performance, resulting
in more even temperatures
and lower utility bills

Efficient design can result in
significant energy savings

Ozone-responsible
R410A meets the EPA’s
(Environmental Protection
Agency) most stringent
environmental guidelines

Compatible with the exclusive
Humiditrol® whole-home
dehumidification system*

SmartHinge™ louvered access
panels provide improved coil
protection and fast, efficient
servicing

ENERGY STAR® qualified

Innovation never felt so good.

EFFICIENCY RATING

Up to 17.20 SEER (Seasonal
Energy Efficiency Ratio).

Want to feel more comfortable at home? With the XC16 air conditioner, you

can feel more comfortable, without feeling the pinch of high utility bills. That’s

because it has two levels of cooling for a higher level of comfort and efficiency.

A HIGHER LEVEL OF COOL, EFFICIENT COMFORT

With its two-stage design, the XC16 makes the distinction between mild

and extremely hot days, using only the energy necessary to keep you

comfortable. It runs mostly at low stage, so you can avoid temperature

swings and high utility bills.

And, when you combine the XC16 with a ComfortSense™ 7000 Series

touchscreen thermostat*** and Humiditrol® dehumidification system, you

can also find relief from high humidity.

5-YEAR COOLING SAVINGS

Efficient Can save you

hundreds of dollars each year

on utility bills

The XC16 has a SEER of up to

17.20, so it can significantly lower

your utility bills, even during the

hottest summer months. It keeps

you comfortable, while keeping

your energy costs down.

Choosing an ENERGY STAR® product can
help you improve comfort and save money.
Get details at www.itpaystolivesmart.com.

$1500

$1200

$900

$600

$300

0

seer

17.00 SEER XC16 air conditioner,
compared to older, less-efficient units

This chart compares the 5-year savings you can expect from
an XC16 air conditioner vs. units with lower efficiency ratings.
The regions used to calculate household fuel and utility
costs reflect a cross-section of cities in the U.S. using
2006 Department of Energy national average energy rates.
In addition to geography, cooling costs are based on 3-ton
capacity specification, with 1,600 cooling hours per year.
Your actual costs will vary depending on the weather, local
fuel rates, systems settings and your personal lifestyle.

$1305

$575

17.00 vs. 8.0 17.00 vs. 10.0

WARRANTY**

10-year limited warranty
on compressor.

5-year limited warranty
on all remaining covered
components.

*Must be accompanied by either a

variable speed air handler or furnace
and the ComfortSense™ 7000 Series
touchscreen thermostat.

** Applies to residential applications only.

2

See actual warranty certificate for details.

Responsible Conserves energy,

while preserving the environment

The two-stage scroll compressor uses the new R410A refrigerant, which

meets the EPA’s standards for environmental safety. Because R410A

contains no chlorine, it’s ozone-responsible.

*** ComfortSense thermostat is required for proper operation of the Humiditrol system air

conditioners and heat pumps. ComfortSense thermostat will not control the packaged
rooftop unit version of the Humiditrol system.
