Lenoxx Electronics PH568 User Manual
TWO LINE CALLER ID SPEAKERPHONE
MODEL PH-568
OPERATING INSTRUCTIONS
Two phone lines can be conferenced for 3 Way conversations
•
Caller ID shows you caller’s name and number on line 1 or line 2
•
Hands-free speakerphone with LED indicator and volume control
•
80 name and number caller ID memory
•
Tone / pulse switchable dialing
•
Automatic time and date display
•
One-touch caller ID call back of received numbers
•
13 memory telephone (3 one-touch & 10 two-touch)
•
Wall / desk usable
•
Requires 4 size “AA” batteries (not included) or the supplied AC adaptor
•
Remember to connect the supplied AC adaptor before use.
To use the caller ID feature of this phone, you must subscribe to caller ID service
from your phone company.
To use the two line and conference functions, you need to have 2 incoming phone
lines from your phone company and use the supplied AC adaptor.
NOTE: READ AND FOLLOW THESE INSTRUCTIONS BEFORE USING YOUR TELEPHONE
IB-PH568-WM-E-040506
IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM1
TABLE OF CONTENTS
Important Safety Instructions ...............................................................................1
Battery Safety Instructions ...................................................................................2
Important Telephone Company & FCC Information .......................................... 3,4
Checking the Package Contents ...........................................................................5
Location of Controls .............................................................................................. 6
Settings
Installing the Batteries ........................................................................................... 7
Connecting the Handset and the AC Adaptor ........................................................7
Connecting the Telephone Line Cord ...................................................................... 8
To Connect a Two-line Telephone Jack ............................................................ 8
To Connect Two Single-line Telephone Jacks ................................................... 8
If You Want to Use This Phone Only as a Single-line Telephone ........................ 8
Customizing Your Phone ....................................................................................... 9,10
Telephone Basics
Making Calls ....................................................................................................... 11
Answering Calls ..................................................................................................... 11
Volume Control and Ringer Setting ....................................................................... 11
Using the Other Line During a Conversation ......................................................... 11
Conference Call ..................................................................................................... 11
Telephone Features
Last Number Redialing .......................................................................................... 12
Storing Phone Numbers into Memory ................................................................... 12
Memory Dialing ...................................................................................................... 12
Pause Function ...................................................................................................... 12
Flash Function ....................................................................................................... 12
Mute Function ....................................................................................................... 12
Caller ID Operation
Viewing the Caller ID List ..................................................................................... 13
Calling Back from the Caller ID List .................................................................... 13
Storing Phone Numbers from the Caller ID List ................................................... 13
Deleting Data from the Caller ID List ................................................................... 13
Using Message Waiting/Mailbox ............................................................................ 13
Desk Use / Wall Mounting ..................................................................................... 14
Trouble Shooting .................................................................................................. 15,16
Limited Warranty .................................................................................................... 17
IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM2
IB-PH568-WM-E-040506
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of fire, electric shock and personal injury, including the following:
1.Read and follow all instructions and warnings.
2.Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a slightly dampened cloth only.
3.Do not use this product near water, for example, near a bathtub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or near a swimming pool.
4.Do not place this product on an unstable cart, stand or table. The product may fall,
causing serious damage to the phone.
5.Slots and openings in back or bottom of the phone are for ventilation, and should not
be blocked or covered. The openings should never be blocked by placing the product
on the bed, sofa, rug, or other similar surface. This product should never be placed near
or over a radiator, heat register or a built-in installation such as a bookcase or cabinet
unless proper ventilation is provided.
6.Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short out parts that could result in risk of fire or
electric shock. Never spill liquid of any kind on the product.
7.To reduce the risk of electric shock, do not take this telephone apart. When service or
repair work is required, take it to a qualified service representative, opening or
removing covers may expose you to dangerous voltage or other risks. Incorrect
reassembly can cause electric shock when the appliance is subsequently used.
8.Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
A. When the cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions because
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance.
9.Avoid using a telephone (other than a cordless type) during an electrical storm. There
may be a remote risk of electric shock from lightning.
10.Do not use the telephone to report a gas leak in the vicinity of the leak.
11.Do not allow anything to rest on the telephone cord. Do not locate this product where
the cord will be damaged by persons walking on it.
12.Never install telephone wiring during a lightning storm.
13.Never install telephone jacks in wet locations unless the jack is specially designed for
wet locations.
14.Never touch uninsulated telephone wires or terminals, unless the telephone line has
beendisconnected at the network interface.
15.Be careful when installing or modifying telephone lines.
CAUTION:TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND
PERSONAL INJURY, DO NOT OPEN CABINET.
1
IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM3
IB-PH568-WM-E-040506
BATTERY SAFETY INSTRUCTIONS
CAUTION:TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY, READ AND
FOLLOW THESE INSTRUCTIONS.
1.Use only the following type and size of batteries: 4 size “AA” alkaline batteries (not
included).
2.Do not dispose of the batteries into a fire. The cells may explode. Check with local
codes for possible special disposal instructions.
3.Do not open or mutilate the batteries. Released electrolyte is corrosive and may cause
damage to the eyes or skin. It may be toxic if swallowed.
4.Exercise care in handling batteries in order not to short the battery with conducting
materials such as rings, bracelets and keys. The battery or conductor may over heat
and cause burns.
5.Do not attempt to recharge the batteries that are used with this product. The batteries
may leak corrosive electrolyte or explode.
6.Do not attempt to rejuvenate the batteries identified for use with this product by heating
them. Sudden release of the battery electrolyte may cause burns or irritation to eyes or
skin.
7.All batteries should be replaced at the same time. Mixing fresh and discharged batteries
could increase internal cell pressure and rupture the batteries.
8.When inserting batteries into this product, the proper polarity or direction must be
observed. Reverse insertion of batteries may result in leakage or explosion.
9.Remove the batteries from this product if the product will not be used for a long period
of time (several months or more) since during this time the batteries could leak, damaging
the product.
10.Discard weak or dead batteries as soon as possible since they are more likely to leak in
the product. Batteries should be replaced when the display gets dim or if the Low
Battery Indicator appears in the display.
11.Do not store this product in high temperature areas. Batteries that are stored in a
freezer or refrigerator for the purpose of extending shelf life should be protected from
condensation during storage and defrosting. Batteries should be stabilized at room
temperature prior to use after cold storage.
12.If this product does not operate normally, see TROUBLE SHOOTING on pages 15 and
16. If you cannot resolve the problem, or if the product is damaged, refer to the
LENOXX WARRANTY INFORMATION on the last page. Opening or removing covers
may expose you to dangerous voltages or other risks. Incorrect reassembly can
cause electric shock when the appliance is subsequently used.
13.Installation of batteries should only done by an adult for safety.
SAVE THESE INSTRUCTIONS
IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM4
2
IB-PH568-WM-E-040506
IMPORTANT TELEPHONE COMPANY & FCC INFORMATION
Consumer Information:
a)This equipment complies with Part 68 of the FCC rules and the requirements adopted by
the ACTA (Administrative Council for Terminal Attachment). On the bottom of this equipment
is a label that contains, among other information, a product identifier in the format
US:TEDTE11B2568A. If requested, this number must be provided to the telephone company.
b)An applicable certification jacks Universal Service Order Codes (USOC) for the equipment
is provided (i.e., RJ11C or RJ14C) in the packaging with each piece of approved terminal
equipment.
c)A plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements adopted by
the ACTA. A compliant telephone cord and modular plug is provided with this product. It
is designed to be connected to a compatible modular jack that is also compliant. See
installation instructions for details.
d)The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not ringing
in response to an incoming call. In most but not all areas, the sum of RENs should not
exceed five (5.0). To be certain of the number of devices that may be connected to a line,
as determined by the total RENs, contact the local telephone company. [For products
approved after July 23, 2001, the REN for this product is part of the product identifier
that has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN
without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is
separately shown on the label.]
e)If this equipment causes harm to the telephone network, the telephone company will
notify you in advance that temporary discontinuance of service may be required. But if
advance notice isn’t practical, the telephone company will notify the customer as soon as
possible. Also, you will be advised of your right to file a complaint with the FCC if you
believe it is necessary.
f)The telephone company may make changes in its facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the telephone
company will provide advance notice in order for you to make necessary modifications to
maintain uninterrupted service.
g)Should you experience trouble with this equipment, please contact our Customer Service
Department at 1-800-315-5885, or visit our website: http://www.lenoxx.com, or e-mail
to: evergo@att.net for repair or read the warranty information on the last page of this
manual. If the equipment is causing harm to the telephone network, the telephone
company may request that you disconnect the equipment until the problem is resolved.
h)Please follow instructions for repairing if any (e.g. battery replacement section); otherwise
do not alternate or repair any parts of device except specified.
i)Connection to party line service is subject to state tariffs. Contact the state public utility
commission, public service commission or corporation commission for information.
j) NOTICE: If your home has specially wired alarm equipment connected to the telephone
line, ensure the installation of this equipment does not disable your alarm equipment. If
you have questions about what will disable alarm equipment, consult your telephone
company or a qualified installer.
k)This equipment is hearing aid compatible.
NOTICE: According to telephone company reports, AC electrical surges, typically resulting
from lightning strikes, are very destructive to telephone equipment connected to AC power
sources. To minimize damage from these types of surges, a surge arrestor is recommended.
IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM5
3
IB-PH568-WM-E-040506
IMPORTANT TELEPHONE COMPANY & FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
IB-PH568-WM-E-040506(RTT).pmd 7/4/2006, 4:28 PM6
4
IB-PH568-WM-E-040506
Loading...
