TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE. TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. TO
PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE PLUG TO WIDE SLOT, FULLY
INSERT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to the presence
of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of
sufficient magnitude to
constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
See bottom of the set.
IMPORTANT SAFETY INSTRUCTIONS
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with dry cloth.
7.Do not block any ventilation openings, install in accordance with the
manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9.Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Unplug this apparatus during lightning storms or when unused for long periods of
time.
13.Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally or
has been dropped.
14.This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquid such as vases shall be placed on the apparatus.
15.Power Sources - This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power supply
to your home, consult your product dealer or local power company. For products
intended to operate from battery power, or other sources, refer to the operating
instructions.
16.Overloading - Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
17.Servicing - Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
18.Safety Check - Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in
proper operating condition.
Do not apply oil or petroleum products or solvents to any part of this set.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
This compact disc player is classified as CLASS 1 LASER PRODUCT as
stated on the bottom of the set.
Please read important information displayed on the rating plate located on the
bottom enclosure before connecting to AC Mains or any operation.
Connect the AC power cord into a live wall outlet.
1
Clock display will show “12:00 ” flashing.
In case you want to reduce the brightness of the
display when you are sleeping, you can press the
DIMMER button.
DIMMER button
Large display for
clock, radio & CD play
If the plug of the AC power cord does
not match your outlet, do not force it.
Reverse it and try again. This plug is
polarized and only fits one way into
the wall outlet.
2
Hold the CLOCK SET button
SET
SET
NOTE: To change PM to AM time, advance the clock time 12 hours.
down, and press the HOUR
button, until the right hour time
is shown in the display.
Hold the CLOCK SET button
3
down, and press the
MINUTE button until the right
minutes time shows in the
display.
PM will show in the
display for PM time.
Example: 10:26 P.M.
3
IB-CDR1906(AD-CL)-WM-E-012105
2. Setting the Alarm Time
OFF
BUZZER
ON
This set has dual alarms. You may set ALARM 1 to wake you at a certain time, or
ALARM 2 to wake you at a different time, or ALARM 1+2 - both alarms will sound
at the time you set.
This feature is useful for a husband & wife waking up at
different time or a single person who likes to wake up at
different time during weekdays and weekends.
To set ALARM 1, slide the ALARM switch to position 1,
the words “ALARM 1” will show in the display.
To set ALARM 2, slide the ALARM switch to position 2,
the words “ALARM 2” will show in the display.
SLEEP button
HOUR button
MINUTE button
LEFT SIDE VIEW
ALARM SET button
AUTO
Press the ALARM SET button together with the HOUR button until the display
2
shows the desired alarm hour time.
Press the ALARM SET button together with the MINUTE button until the display
3
shows the correct alarm minutes.
Release the ALARM SET button, the clock display will show the normal time of day.
4
NOTE 1: When the ALARM switch is in the ALARM 1+2 position, you can’t set the
NOTE 2: If you want this set to wake you up in the morning, the letters “PM” should
NOTE 3: To wake to ALARM 1 time, slide ALARM switch to position 1.
ALARM time.
not show on alarm time (when pressing ALARM SET button), this means
AM (morning time). To change PM to AM time, advance the clock time 12
hours. To have this set wake you up, slide the BUZZER/AUTO/OFF/ON
switch to AUTO or BUZZER position. Auto position will wake you up to CD
or RADIO. Buzzer position will have a sound buzzer to wake you up.
To wake to ALARM 2 time, slide ALARM switch to position 2.
To wake to both times, slide ALARM switch to position 1+2.
For additional clock & alarm points, see pages 11 and 12.
Slide the BUZZER/AUTO/OFF/ON switch to
1
BUZZER or AUTO position. Press the ALARM SET
button to check the alarm time.
Connect the AC power cord (see Setting the Clock).
CD
Slide the FM/AM/CD FUNCTION
switch to CD position and the
BUZZER/AUTO/OFF/ON
switch to ON position. Two
flashing zeros “” will show
in the display, then “”.
Lift either side of the CD DOOR
to open it and place a CD in the
CD compartment. The label side
of the CD should face upward.
button
3
4
Remember to slide the BUZZER/AUTO/OFF/ON switch to BUZZER or AUTO
position after listening, so that the buzzer alarm, CD music or radio will wake
you up at your preset time. Make sure the volume control is adjusted loud
enough to wake you up.
Close the CD DOOR by
pushing it down. The CD display
will show the total track
numbers of the disc.
Press the CD PLAY/PAUSE
button. The player will play all
the tracks once. The CD display
will show the track number of
the song currently playing and
the play symbol “ ” .
5
IB-CDR1906(AD-CL)-WM-E-012105
Total track numbers
of the disc
CD Track number
4. More about CD operation
PAUSE symbol
Tip
When the CD play
is paused, the
display will show the
pause symbol “”
and no music will
play.
To resume play,
press the PLAY/
PAUSE button again.
Remember to slide
the BUZZER/
AUTO/OFF/ON
switch to BUZZER
or AUTO position
after listening, so
that the buzzer
alarm, CD music or
radio will wake you
up at your preset
time. Make sure the
volume control is
adjusted loud
enough to wake you
up. If you want to
listen to the CD for
a short time, simply
press the SLEEP
button. See page 12
for full sleep
instructions.
Use these buttons for additional operations
CD PLAY/PAUSE
CD STOP button
To
Adjust the volume
Stop playback
Pause playback
Go to the next track
Go back to the previous
track
Locate a point in a song
To enjoy the music
without disturbing
others
Remove the CD
Turn off the CD player
button
Open the disc
door by lifting here
SKIP/SEARCH
buttons
Phones jack
Volume control
FM/AM/CD
function switch
Press or Adjust
Volume Control
STOP
PLAY/PAUSE
Display will show the pause
symbol “” during pause.
Press again to resume play.
SKIP/SEARCH
FORWARD
SKIP/SEARCH
BACKWARD
or while playing, press
and hold down until you find the
point you want in a song.
Insert your headphones (not
included) into the PHONES
jack (at the right side of the set).
Remember to unplug the
headphones if you want the set
to wake you up in the morning.
Press the STOP button first,
then lift the CD door.
Press the CD STOP button, then
slide the BUZZER/AUTO/OFF/
ON switch to OFF position.
You can make a program of up to 20 tracks in the order you want them to be played.
STOP button
BUZZER/AUTO/
OFF/ON switch
(on the left side)
1.Slide the BUZZER/AUTO/OFF/ON switch to ON position and
the FM/AM/CD FUNCTION switch to CD position. Wait until
the total track number shows in the display and the CD disc is
not rotating.
2.Press the PROGRAM/REPEAT button. The letters “PROG”
will show and two zeros “” will flash.
3.Press SKIP/SEARCH buttons or
you want to program in the order you want.
4.Press the PROGRAM/REPEAT button to confirm. The two
zeros “” will flash for your next selection of the track.
5.Repeat steps 3 and 4. You can program up to 20 tracks.
6.Press to start programmed play. The letters “PROG”
will show in the display.
PLAY/PAUSE
button
to select the tracks
To change the current program
Just create a new program following the programming procedure.
To cancel Programmed Play
Press the STOP button to stop the programmed play. The programmed memory will
be lost only when the BUZZER/AUTO/OFF/ON switch is slided to OFF position or
the CD door is opened.
RANDOM button
PROGRAM/REPEAT
button
SKIP/SEARCH
buttons
FM/AM/CD
function switch
PROG
PROG
2. Random Play
To play the songs in random order
During play or in STOP mode, press the CD RANDOM button,
the letters “RAND” will show in the display, and the set will play
all the tracks in random order.
Press SKIP/SEARCH button to skip to the next random song.
To resume normal play
Press the CD RANDOM button again, the letters “RAND” will disappear.
Connect the supplied AC power cord (see Setting the Clock).
1
FM
AUTO
2
3
4
AUTO
NOTE:
This set uses an analog (rotary) tuner with a digital display. The digital display is
very useful when locating your favorite station and also assists you to pinpoint
the exact tuning frequency. This set does not have radio memory presets.
BUZZER/AUTO/
OFF/ON switch
CD
Slide theFM/AM/CD switch to AM or
FM position and the BUZZER/AUTO/
OFF/ON switch to ON.
Tune into the station you prefer using
the TUNING control. Adjust for the
clearest sound. The display will show
you the frequency of the station tuned
in. This is useful when you know the
station’s frequency.
Adjust the VOLUME control for
desired loudness.
Slide the BUZZER/AUTO/OFF/ON
switch to OFF position to turn off the
radio.
TUNING
control
FM/AM/CD
switch
RIGHT SIDE VIEW
VOLUME
control
FM
PHONES
jack
Remember to slide the BUZZER/AUTO/OFF/ON switch to BUZZER or AUTO
position after listening, so that the buzzer alarm, CD music or radio will wake
you up at your preset time. Make sure the volume control is adjusted loud
enough to wake you up. If you want to listen to the radio for a short time, simply
press the sleep button. See page 12 for full sleep instructions.
Fully stretch out the FM ANTENNA for better FM reception.
Reorient the player itself for better AM reception.
Or locate the set near a window.
To listen without disturbing others
Connect your headphones (optional - not included) into the PHONES jack at the
right side of the set. The speakers will automatically be silenced. Remember to
unplug the headphones if you want the set to wake you up in the morning.
To use battery backup
Install a 9V battery for Clock backup, so that if your home power is momentarily off
due to a power outage, you will not have to set up the time & alarm settings.
NOTE: During power outages the CLOCK display will not show the time but the time
will be kept in memory and will reappear when power is restored.
NOTE:When the BUZZER/AUTO/OFF/ON switch is set to ON or OFF position, the
words “ALARM 1” or “ALARM 2” will not show in the display and no alarm
buzzer, CD music or radio will come out at the set alarm time.
1. Waking up to alarm
AUTO
1
Alarm buzzer will sound at the set alarm time.
1.Set the BUZZER/AUTO/OFF/ON switch to
BUZZER position.
2.Set the alarm time as previously instructed
and slide the ALARM switch to ALARM 1,
ALARM 2 or ALARM 1+2, the proper
ALARM status will show in the display.
2. Waking up to CD
AUTO
1
FM
CD
The CD Disc will start playing from the first
track at the set alarm time.
3. Waking up to radio
AUTO
1
FM
CD
1.Set the BUZZER/AUTO/OFF/ON switch to
AUTO position.
2.Set the alarm time as previously instructed
and slide the ALARM switch to ALARM 1,
ALARM 2 or ALARM 1+2, the proper
ALARM status will show in the display.
3.Make sure the FM/AM/CD switch is set to
CD position.
4.Make sure there is a CD disc loaded in the
compartment and the volume setting is
loud enough to wake you up.
1.Refer to Listening to the radio for radio
operation instructions. Select the desired AM
or FM band using the FM/AM/CD switch and
TUNING control. Adjust the volume control
to your preference.
2.Set the BUZZER/AUTO/OFF/ON switch to
AUTO position.
3.Set the alarm time as previously instructed
and slide the ALARM switch to ALARM 1,
ALARM 2 or ALARM 1+2, the proper ALARM
status will show in the display.
4.Set the FM/AM/CD switch to FM or AM position.
The radio will start playing at the set alarm time.
Just press the SNOOZE button, the alarm or music will stop
and come on after 7 minutes.
2. To stop the alarm buzzer, CD music or radio
Just press the ALARM/SLEEP/OFF button, the alarm
buzzer, CD music or radio will stop and come on next day.
AUTO
3. To off the alarm function
Just slide the BUZZER/AUTO/OFF/ON switch to OFF
position.
Going to Sleep with CD music
The SLEEP control will allow the set to play 59 minutes (or 1 hour and 59 minutes)
before the set turns itself off.
1.Slide the FM/AM/CD switch to CD position.
2.Slide the BUZZER/AUTO/OFF/ON switch to BUZZER or AUTO position.
3.Press the SLEEP button, the display will show 59 minutes and the word “SLEEP”,
the CD will start to play.
4.Holding the SLEEP and MINUTE buttons down, the display will count down.
Release the buttons when the display shows your desired amount of time you
want the CD to play before shutting itself off.
5.Pressing the SLEEP and HOUR buttons simultaneously down, will change the
sleep time to 1 hour and 59 minutes. You may reduce the sleep time by following
the above Step 4.
6.To turn the CD off before the playing time has expired, simply press the ALARM/
SLEEP/OFF button.
Going to Sleep with RADIO
The SLEEP control will allow the set to play 59 minutes (or 1 hour and 59 minutes)
before the set turns itself off.
1.Slide the FM/AM/CD switch to AM or FM position.
2.Slide the BUZZER/AUTO/OFF/ON switch to BUZZER or AUTO position.
3.Press the SLEEP button, the display will show 59 minutes and the word “SLEEP”,
the RADIO will start to play.
4.Holding the SLEEP and MINUTE buttons down, the display will count down. Release
the buttons when the display shows your desired amount of time you want the
RADIO to play before shutting itself off.
5.Pressing the SLEEP and HOUR buttons simultaneously down, will change the
sleep time to 1 hour and 59 minutes. You may reduce the sleep time by following
the above Step 4.
6.To turn the RADIO off before the playing time has expired, simply press the
player section is harmful to the eyes,
do not attempt to disassemble the
casing. Refer servicing to qualified
personnel only.
Should any solid object or liquid fall into
•
the player, unplug the player, and have
it checked by qualified personnel
before operating it any further.
On placement
Do not leave the player in a location
•
near heat source, or in a place subject
to direct sunlight, excessive dust or
mechanical shock or vibration.
Do not place the player on an inclined
•
or unstable place.
Do not place anything within 1 inch of
•
the back of the cabinet. The ventilation
holes must be unobstructed for the
player to operate properly and prolong
the life of its components.
Since a strong magnet is used for the
•
speakers, keep personal credit cards
using magnetic coding or springwound watches away from the player
to prevent possible damage from the
magnet.
On power sources
For battery backup, you may use a 9V
•
battery (optional), so that you will not
have to re-set the clock every time you
disconnect the power.
The nameplate indicating operating
•
voltage, power consumption, etc. is
located at the bottom of the set.
On operation
If the player is brought directly from a
•
cold to a warm location, or is placed in
a very damp room, moisture may
condense on the lens inside the CD
player section. Should this occur, the
player will not operate properly. In this
case, remove the CD and wait about
an hour for the moisture to evaporate.
This CD player is designed to be played
•
on a stable no vibration position. If you
bump the set during CD play, the music
will stop or skip for a few seconds. This
is normal for this type of player.
thinner, commercially available
cleaners or anti-static spray intended
for vinyl LPs.
Do not expose the CD to direct sunlight
•
or heat sources such as hot air ducts,
nor leave it in a car parked in direct
sunlight as there can be a considerable
rise in temperature inside the car.
Do not stick paper or sticker on the
•
CD, nor scratch the surface of the CD.
After playing, store the CD in its case.
•
If there is a scratch, dirt or fingerprints
on the CD, it may cause tracking error.
Cleaning the lens
If the lens becomes dirty, it may cause a
skipping of sound during CD operation.
Clean with a commercially available lens
cleaner blower or a cotton swab.
Cleaning the cabinet
Clean the cabinet, panel and controls with
a soft cloth slightly moistened with a mild
detergent solution. Do not use any type
of abrasive pad, scouring powder, or
solvent, such as alcohol or benzine.
“”appears in the display
even when a CD is in place.
CD does not play.
CD player
Remedy
Connect the AC power cord to a wall outlet
•
securely. Make sure that outlet has power.
Make sure the FUNCTION switch is at the
•
right position as you want.
Adjust the volume.
•
Unplug the headphones when listening
•
through speakers.
AM or PM is not set correctly. Is alarm time
•
set in AM range (“PM” should disappear from
the display)?
BUZZER/AUTO/OFF/ON switch is not set to
•
the proper position. Does the “ALARM” show
in the display?
Insert the CD with the label side up.
•
Make sure that the CD compartment is closed.
•
Place the CD with the label side up.
•
CD play is paused, press again.
•
Clean the CD or try another compact CD,
•
this set will not play MP3 or WMA discs.
Replace the disc (this set will not play
damaged or scratched CDs), or buy a disc
repair polisher to repair it yourself.
Take out the CD and leave the CD door open
•
for about an hour to dry moisture condensation.
Make sure the FM/AM/CD switch is at CD
FM reception.
Bring the set near a window, or rotate the set
•
for AM reception.
15
IB-CDR1906(AD-CL)-WM-E-012105
Specification
GENERAL DESCRIPTION
Power source:
Speakers:3” 8 ohm
Output power:
Dimensions:Width:6 1/2”
CD SECTION
Plays disc type:Any compact discs bearing this logo
Laser wavelength:760 - 800 NM
Tracking method:3 - spot error detection 3.86 mm lens
Frequency response: 50 Hz - 15 kHz (+1/-2dB)
NOTE: This CD player will play normal music CDs (or CD-R/CD-RW CDs).
RADIO SECTION
Frequency range:FM: 88 - 108 MHzAM: 530 - 1700 kHz
LENOXX reserves the right to make design and specification changes for product improvement.
PROTECT YOUR FINE FURNITURE!
WE RECOMMEND A CLOTH OR OTHER PROTECTIVE MATERIAL BE PLACED UNDER THE SET
WHEN PLACING IT ON SURFACE WITH A NATURAL OR LACQUER FINISH.
We warrant this product to be free from defects in material and workmanship under normal use
for a period of 90 days after purchase and we will repair it free of charge or replace it at no charge,
should it become defective under this warranty, providing you submit proof of purchase (sales slip)
with the set.
During the initial 90 day period after original purchase, we will service or exchange, at no charge,
the set that is returned to LENOXX ELECTRONICS CORP. After the initial 90 day period expires, and for
a period of 12 months from original purchase, we will repair the unit covering any part(s) that need to be
replaced at no charge, but will charge for the cost of labor, return postage paid by Lenoxx.
This warranty does not apply to any products which have been subject to misuse, neglect or
accident. This warranty does not cover broken cord or cabinet. UNDER NO CIRCUMSTANCES
WILL LENOXX ELECTRONICS CORP. BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. The following charges apply to repairs beyond the warranty period: $12.00. Be
sure to pack carefully and return postage paid insured together with your money order (personal
checks will not be accepted) and sales receipt to:
