Lenoxx Electronics CD-90 User Manual

AM/FM DIGITAL RADIO

CD PLAYER WITH 20 SECOND ESP PLUS

MODEL CD-90

OPERATING INSTRUCTIONS

DIGITAL AM/FM RECEIVER



5 AM & 5 FM PRESET STATION BUTTONS



PLAYS ALL MUSIC COMPACT DISCS



6 DIGIT RADIO & CD VISUAL DISPLAY



TRACK REPEAT & DISC REPEAT



20 SECOND ESP (ELECTRONIC SHOCK PROTECTION) PLUS



AC ADAPTOR INCLUDED



USES 2 SIZE AA BATTERIES (NOT INCLUDED)



LINE OUT JACK - CONNECTS TO YOUR STEREO SYSTEM



PLEASE READ CAREFULLY BEFORE USE

CD90(90A-E2)030400 NL v.1 E

SYSTEM

INTRODUCTION

Your new Lenoxx Sound Model CD-90 portable compact disc player with digital

radio, uses the latest technology to give you crisp clean sound from all your

compact discs, and digital AM/FM radio reception.

Please read these operating instructions completely to take advantage of all the features

of this set.

ACCESSORIES INCLUDED

AC ADAPTOR

STEREO HEADPHONES

LIMITED WARRANTY

We warrant this product to be free from defects in material and workmanship under

normal use for a period of 90 days after purchase and we will repair it free of charge or

replace it at no charge, should it become defective under this warranty, providing you

submit proof of purchase (sales slip) with the set.

During the initial 90 day period after original purchase, we will service or exchange,

at no charge, the set that is returned to LENOXX ELECTRONICS CORP. (LENOXX will

pay the shipping back to you). After the initial 90 day period expires, and for a period

of 12 months from original purchase, we will repair the unit covering any part(s) that

need to be replaced at no charge, but will charge for the cost of labor, return postage

paid by Lenoxx.

This warranty does not apply to any products which have been subject to misuse,

neglect or accident. This warranty does not cover broken headphones or cabinet.

UNDER NO CIRCUMSTANCES WILL LENOXX ELECTRONICS CORP. BE LIABLE FOR

ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the

exclusion or limitation of incidental or consequential damages, so the above limitations

or exclusions may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights

which vary from state to state. The following charges apply to repairs beyond the

warranty period: $35.00. Be sure to pack carefully and return postage paid insured

together with your money order (personal checks will not be accepted) and sales

receipt to :

LENOXX ELECTRONICS CORP. 2 GERMAK DRIVE, CARTERET N.J. 07008

LOCATION OF CONTROLS

1.5 AM & 5 FM MEMORY PRESET BUTTONS

2.RADIO MEMORY STORE BUTTON

3.AM/FM BAND BUTTON

4.RADIO LCD DISPLAY

5.RADIO TUNING UP BUTTON

6.RADIO TUNING DOWN BUTTON

7.CD DOOR

8.PHONES JACK (headphone jack)

9.LINE OUT JACK

(for home stereo connection)

10.VOLUME CONTROL

11. FORWARD SEARCH BUTTON (

)

12.BACKWARD SEARCH BUTTON (

13.PLAY/PAUSE BUTTON (POWER ON)

14.STOP AND POWER OFF BUTTON

15.BASS BOOST SWITCH

16.CD DISPLAY

17.CD/RADIO FUNCTION SWITCH

18. RADIO ON INDICATOR LAMP

19. PROGRAM BUTTON

20. ESP (ELECTRONIC SHOCK

PROTECTION) BUTTON

21. REPEAT/RANDOM BUTTON

)

22. CD DOOR OPEN BUTTON

23. CD DOOR CLOSE AREA

24. BATTERY DOOR

25. AC ADAPTOR JACK

POWER SOURCES

1.Using Battery Power

Insert two size AA alkaline batteries

according to the + and - markings in

the battery compartment.

TIPS ON BATTERY USE

Reversing polarities will damage the batteries and possibly your set. Be sure to



follow polarity ( + and - ) as indicated.

Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),



or old batteries with new ones.

When not in use for an extended period of time, or while internal batteries will not



be used, remove them to prevent possible acid leakage or corrosion resulting in

damage to your player.

When the batteries have become discharged, they must be disposed of in a safe



manner that complies with all applicable laws.

Installation of batteries should only be done by an adult (for safety).



ALKALINE BATTERY LIFE

Bear in mind that battery life expectancy is based upon volume and bass listening

levels.

Maximum battery power consumption happens at maximum settings. Typical life

for 2 size AA alkaline batteries is above 8 hours of continuous use.

WHEN THIS SYMBOL

If the alkaline batteries are weak and discharged, this symbol   shows in the

display, then the power automatically turns off. If this occurs, replace the alkaline

batteries (also if display does not show anything, the batteries are dead).

NOTE: You may use rechargeable batteries on this set. However, because

rechargeable batteries generally have lower voltage (1.2 volts instead of

1.5 volts). Your playing time will be much less than normal fresh alkaline

batteries.

SHOWS IN THE DISPLAY

2.Using AC Wall Outlet Power

Your player may be powered from any household 120V AC outlet, using the AC

adaptor included. Insert the adaptors small connector plug into the DC 4.5V Jack

marked on player (on the rear of the set), and plug the adaptor into

an AC outlet.

NOTE: If the AC Adaptor is connected, and regular batteries are installed, the

CAUTION:

To prevent electric shock, do not use this AC Adaptor with an extension cord or outlet,

unless it can be fully inserted without exposing any part of the blades. Do not use any

other adaptor to power this set or you may damage your set.

player automatically switches to the AC Adaptor power and the batteries

are not used.

CONNECTING TO HOME STEREO SYSTEMS

The LINE OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the

cables mini plug to the LINE OUT jack on your player, and the other appropriate end

usually RCA JACKS to the CD/AUX INPUTS of your home stereo.

TO AUX IN JACKSTO LINE OUT JACK

YOUR

CD PLAYER

OPTIONAL CABLE

3.5mm TO RCA JACKS

YOUR STEREO

SYSTEM
