Lenoxx Electronics CD85 User Manual
COMPACT DISC PLAYER
WITH ESP PLUS
OPERATING INSTRUCTIONS
TM
ANTI-SKIP PROTECTION
MODEL CD-85
PLAYS MUSIC COMPACT DISCS
BASS BOOST SYSTEM
6 DIGIT LCD VISUAL DISPLAY
TRACK REPEAT & DISC REPEAT
60 SECOND ESP (ELECTRONIC SHOCK PROTECTION) PLUS
DELUXE STEREO HEADPHONES INCLUDED
USES 2 SIZE AA BATTERIES (NOT INCLUDED)
LINE OUT JACK - CONNECTS TO YOUR STEREO SYSTEM
PLEASE READ CAREFULLY BEFORE USE
IB-CD85(21A-60C9)-WM-E-010603
TM
SYSTEM
LOCATION OF CONTROLS
5
4
3
2
1
6
7
8
9
10
11
12
13
14
15
1. CD DOOR OPEN BUTTON (slide to open)
2. CD DOOR
3. STOP AND POWER OFF BUTTON
4. BACKWARD SKIP/SEARCH BUTTON
5. REPEAT/RANDOM BUTTON
6. LCD DISPLAY
7. PROGRAM BUTTON (for programmed play)
8. FORWARD SKIP/SEARCH BUTTON
9. PLAY/PAUSE & POWER ON BUTTON
10. AC ADAPTOR JACK (AC ADAPTOR not included)
11. BASS BOOST SWITCH
12. LINE OUT JACK (for home stereo connection)
13. VOLUME CONTROL
14. PHONES JACK (headphones jack)
15. BATTERY DOOR
1
IB-CD85(21A-60C9)-WM-E-010603
POWER SOURCES
Power your CD player by connecting an optional AC ADAPTOR or by inserting 2 size
AA fresh alkaline batteries.
NOTE: Before you buy an optional AC Adaptor, please note the only AC ADAPTOR
suitable for this player is DC 4.5V 600mA, with polarity , others may
damage your player. Please check voltage and current (mA) before buying an
AC ADAPTOR.
Using with Batteries
Insert 2 size AA alkaline batteries
according to the + and - markings in
the BATTERY COMPARTMENT.
TIPS ON BATTERY USE
Reversing polarities will damage the batteries and possibly your set. Be sure to
follow polarity ( + and - ) as indicated.
Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),
or old batteries with new ones.
When not in use for an extended period of time, or while internal batteries will not
be used, remove them to prevent possible acid leakage or corrosion resulting in
damage to your player.
When the batteries have become discharged, they must be disposed of in a safe
manner that complies with all applicable laws.
Installation of batteries should only be done by an adult (for safety).
ALKALINE BATTERY LIFE
Bear in mind that battery life expectancy is based upon volume and bass listening
levels.
Maximum battery power consumption happens at maximum settings. Typical life for 2
size AA alkaline batteries is above 7.5 hours of continuous use for CD play.
WHEN
While CD playing, if the alkaline batteries are weak and discharged, this symbol
shows or flashes in the display, then the power automatically turns off. If this occurs,
replace the alkaline batteries (also if the display does not show anything, the batteries
are dead).
NOTE: You may use rechargeable batteries on this set. However, because
SHOWS IN THE DISPLAY
rechargeable batteries generally have lower voltage (1.2 volts instead of
1.5 volts). Your playing time will be much less than normal fresh alkaline
batteries.
2
IB-CD85(21A-60C9)-WM-E-010603
CONNECTING TO HOME STEREO SYSTEMS
The LINE OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the
cables mini plug to the LINE OUT jack on your player, and the other appropriate end
usually RCA JACKS to the CD/AUX INPUTS of your home stereo.
YOUR CD PLAYER
OPTIONAL CABLE (3.5mm)
TO RCA JACKS
YOUR STEREO
SYSTEM
TO AUX IN JACKSTO LINE OUT JACK
3
IB-CD85(21A-60C9)-WM-E-010603
CD PLAYING
1 Load the Disc.
Disc
Push
here
Slide right to open
2 Connect the Headphones.
Stereo Headphones
To PHONES jack
3 Press the PLAY/PAUSE button.
PLAY/PAUSE
button
VOLUME CONTROL
Label side up
TOTAL TRACKS
TRACK NUMBER
CURRENTLY
PLAYING
TOTAL PLAYING
TIME OF THE CD
ELAPSED PLAYING
TIME OF THE
CURRENT TRACK
NOTE: The ESP PLUS
button is pressed.
TM
function will turn on automatically when the PLAY/PAUSE
4 Adjust the Volume.
4
IB-CD85(21A-60C9)-WM-E-010603
