Lenoxx Electronics CD625 User Manual

AM/FM STEREO RADIO

PROGRAMMABLE CD PLAYER

MODEL CD-625

OPERATING INSTRUCTIONS

BUILT-IN AM/FM RADIO RECEIVER



PLAYS MUSIC COMPACT DISCS



6 DIGIT LCD VISUAL DISPLAY



TRACK REPEAT & DISC REPEAT



BASS BOOST SYSTEM



DELUXE STEREO HEADPHONES INCLUDED



USES 2 SIZE AA BATTERIES (NOT INCLUDED)



PLEASE READ CAREFULLY BEFORE USE

IB-CD625(CDR92C-0L8)-WM-E-121803

LOCATION OF CONTROLS

1. CD PROGRAM BUTTON ( )

2. CD BACKWARD SKIP/SEARCH BUTTON ( )

3.CD STOP AND POWER OFF BUTTON ( )

4.CD DOOR

5.AM/FM DIAL LENS

6.CD DOOR OPEN BUTTON

7. AM/FM TUNING CONTROL

8.POWER ON INDICATOR

9.CD/OFF/RADIO FUNCTION SWITCH

10.CD PLAY/PAUSE AND POWER ON BUTTON (

11.CD FORWARD SKIP/SEARCH BUTTON (

12.CD REPEAT BUTTON (

)

13.CD LCD VISUAL DISPLAY

14.BATTERY DOOR

15 .BASS BOOST SWITCH

16.FM STEREO INDICATOR

17.VOLUME CONTROL

18.PHONES JACK (HEADPHONE JACK)

19.AM/FM/FM STEREO BAND SWITCH

20 .AC ADAPTOR JACK (AC ADAPTOR NOT INCLUDED)

)

IB-CD625(CDR92C-0L8)-WM-E-121803

POWER SOURCES

Power this player by connecting an optional (not included) AC ADAPTOR or by inserting

2 size AA fresh alkaline batteries.

Before you buy an AC Adaptor, please note the only AC ADAPTOR suitable for

NOTE:

this player is DC 4.5V 600mA, with polarity , others may damage the

player. Please check voltage & current (mA) before buying an AC ADAPTOR.

Using with Batteries

Insert two size AA alkaline batteries

according to the + and - markings on

the bottom of the set.

TIPS ON BATTERY USE

Reversing polarities will damage the batteries and possibly this set. Be sure to



follow polarity ( + and - ) as indicated.

Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),



or old batteries with new ones.

When not in use for an extended period of time, or while internal batteries will not



be used, remove them to prevent possible acid leakage or corrosion resulting in

damage to this player.

When the batteries have become discharged, they must be disposed of in a safe



manner that complies with all applicable laws.

Installation of batteries should only be done by an adult (for safety).



ALKALINE BATTERY LIFE

Bear in mind that battery life expectancy is based upon volume and bass listening

levels.

Maximum battery power consumption happens at maximum settings. Typical life

for 2 size AA fresh alkaline batteries is above 8 hours of continuous use for CD

play and 5 hours longer for radio use.

WHEN SHOWS OR FLASHES IN THE DISPLAY

While CD playing, if the alkaline batteries are weak and discharged, this symbol

  shows or flashes in the display, then the power automatically turns off. If this

occurs, replace the alkaline batteries (also if the display does not show anything,

the batteries are dead).

NOTE 1: The display is blank when you listen to the radio, so when the display

NOTE 2: The radio may work normally for about 5 hours when   shows or

NOTE 3: You may use rechargeable batteries on this set. However, because

does not show anything, please check if the CD/OFF/RADIO FUNCTION

switch is moved to the CD position.

flashes in the display indicating batteries are weak for CD play, but still

OK for the radio.

rechargeable batteries generally have lower voltage (1.2 volts instead of

1.5 volts). Your playing time will be much less than normal fresh alkaline

batteries.

IB-CD625(CDR92C-0L8)-WM-E-121803

DISC PLAYING

1 Slide the CD/OFF/RADIO

FUNCTION switch to CD

position.

2 Load the disc.

Push

here

Disc

LABEL SIDE UP

3 Connect the headphones.

STEREO

HEADPHONES

CD/OFF/RADIO

FUNCTION

SWITCH

SLIDE TO OPEN

TO PHONES JACK

4 Press the PLAY/PAUSE button ( ), the POWER ON

indicator will light up.

PLAY/PAUSE

BUTTON

TRACK NUMBER

CURRENTLY

PLAYING

ELAPSED PLAYING

TIME OF THE

CURRENT TRACK

POWER ON

INDICATOR

5 Adjust the volume.

VOLUME

MAXIMUM

MINIMUM

VOLUME CONTROL

IB-CD625(CDR92C-0L8)-WM-E-121803

OTHER OPERATIONS

Operation

Press

Display window shows

To pause play

To release pause and

resume play

To stop play

To turn off the power

To skip to the next

track(s)

To skip to the previous

track(s)

To go ahead at high

speed (search forward)

To go back at high

speed (search back-

ward)

PLAY/PAUSE button

STOP button

TRACK NUMBER

CURRENTLY

PLAYING

TRACK NUMBER

CURRENTLY

PLAYING

TOTAL TRACKS

Slide the CD/OFF/RADIO FUNCTION switch to

OFF position, or press the STOP button quickly

twice.

once (or repeatedly)

Keep depressed and release it when the

desired music section of the disc is found.

If you press and hold the SKIP button ( )



while the last track is playing, and the end of the

track is reached, the music stops and the display

will show the total tracks and total playing time of

the CD, then power will shut itself off after 30

seconds.

Keep

depressed and release it when the

desired music section of the disc is found.

ELAPSED TIME

FLASHES

PLAYING TIME

ADVANCES

TOTAL PLAYING

TIME

Get into Stop Mode

Press the PLAY/PAUSE button , the set

begins to play, then press the STOP button ,

the display will show six digits similar to the

example on the right.

TOTAL TRACKS

TOTAL PLAYING

TIME

Auto power off function

The power turns off automatically 30 seconds after all tracks on the disc have been

played or after the STOP button is pressed to stop play.

To shut off the power immediately, press the STOP button twice or slide the CD/OFF/

RADIO FUNCTION switch to OFF position.

IB-CD625(CDR92C-0L8)-WM-E-121803
