Lenoxx Electronics CD-50 User Manual

PROGRAMMABLE

COMPACT DISC PLAYER

MODEL CD-50

OPERATING INSTRUCTIONS

PLAYS ALL MUSIC COMPACT DISCS



6 DIGIT LCD VISUAL DISPLAY



TRACK REPEAT & DISC REPEAT



DELUXE STEREO HEADPHONES INCLUDED



USES 4 SIZE AA BATTERIES (NOT INCLUDED)



PLEASE READ CAREFULLY BEFORE USE

CD-50(70A-0A9)121000 NL v.1 E

LOCATION OF CONTROLS

1. PHONES JACK (headphone jack)

2. CD DOOR CLOSE AREA

3. VOLUME CONTROL

4. CD DOOR OPEN BUTTON

5. REPEAT BUTTON

6. BACKWARD SKIP/SEARCH BUTTON (

)

7. FORWARD SKIP/SEARCH BUTTON ( )

8. LCD VISUAL DISPLAY

9. PLAY/PAUSE AND POWER ON BUTTON

10. STOP AND POWER OFF BUTTON

(POWER OFF IS AUTOMATIC AFTER 30 SECONDS)

11. PROGRAM BUTTON

12. CD DOOR

13. BATTERY DOOR

14. AC ADAPTOR JACK (AC ADAPTOR not included)

POWER SOURCES

Power your CD player by connecting an optional AC ADAPTOR or by inserting 4 size

AA fresh alkaline batteries.

NOTE: The only AC ADAPTOR suitable for this player is DC 4.5V 600mA, with polarity

before buying an AC ADAPTOR.

, others may damage your player. Please check voltage + current (mA)

Using with batteries

Insert 4 size AA alkaline batteries

according to the + and - markings on

the back cabinet near the BATTERY

COMPARTMENT DOOR.

Tips on battery use

Reversing polarities will damage the batteries and possibly your set. Be sure to



follow polarity ( + and - ) as indicated.

Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),



or old batteries with new ones.

When not in use for an extended period of time, or while internal batteries will not



be used, remove them to prevent possible acid leakage or corrosion resulting in

damage to your player.

When the batteries have become discharged, they must be disposed of in a safe



manner that complies with all applicable laws.

Installation of batteries should only be done by an adult (for safety).



Alkaline battery life

Bear in mind that battery life expectancy is based upon volume listening levels.

Maximum battery power consumption happens at maximum settings. Typical life

for 4 size AA alkaline batteries is about 16 hours of continuous use.

When shows or flashes in the display

If the alkaline batteries are weak and discharged, this symbol   shows or

flashes in the display, then the power automatically turns off. If this occurs, replace

the alkaline batteries (also if display does not show anything, the batteries are

dead).

DISC PLAYING

1 Load the disc.

Push

here

Disc

Label side up

2 Connect the headphones.

Stereo headphones

To PHONES

3 Press the PLAY/PAUSE button ( ).

Press to open

TRACK NUMBER

CURRENTLY

PLAYING

ELAPSED PLAYING

TIME OF THE

CURRENT TRACK

4 Adjust the volume.

MAXIMUM MINIMUM

PLAY/PAUSE

Button

VOLUME CONTROL

Other operations

Operation

To pause play

To release pause

and resume play

To stop

To turn off the power

To skip to the next track(s)

To skip to the previous track(s)

To go ahead at high speed

(search)

To go back at high speed

(search)

Press

Display window shows

TRACK NUMBER

CURRENTLY

TRACK NUMBER

CURRENTLY

TOTAL TRACKS

PLAYING

PLAYING TIME

FLASHES

PLAYING TIME

ADVANCES

TOTAL PLAYING

TIME

once (or repeatedly)

Keep depressed and release when the

desired music section of the disc is found.

If you press and hold the SKIP button ( )



while the last track is playing, and the end of the

track is reached, the music stops and the display

will show the next track number, then power will

shut off after 30 seconds.

Keep depressed and release when the

desired music section of the disc is found.

Get into Stop Mode (for programming)

Press the PLAY/PAUSE button , the set

begins to play, then press the STOP (POWER

OFF) button , the display will show six digits

similar to the example show here.

TOTAL TRACKS

TOTAL PLAYING

TIME

Auto power off function

The power turns off automatically 30 seconds after all tracks on the disc have been

played or after the STOP button is pressed to stop play.
