PORTABLE CD/MP3 PLAYER
WITH AM/FM STEREO RECEIVER
MODEL CD-208
OPERATING INSTRUCTIONS
PLAYS REGULAR MUSIC CD DISCS & MP3 ENCODED DISCS
FULLY PROGRAMMABLE PLAYBACK
45 SECOND (CD) & 120 SECOND (MP3) ANTI-SKIP PROTECTION
RECEIVES AM/FM STEREO BROADCASTS
REPEAT ONE AND REPEAT ALL PLAY
FM STEREO AND POWER LED INDICATORS
2 WAY POWER - AC/DC
USES 6 SIZE D BATTERIES (not included)
PLEASE READ CAREFULLY BEFORE USE
IB-CD208(LC)-WM-E-060403
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to
the presence of uninsulated
dangerous voltage within
the products enclosure that
may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER
SERVICEABLE PARTS
INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
SEE BOTTOM OF THE SET.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings, install in accordance with the manufacturers
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10 .Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12 .Unplug this apparatus during lightning storms or when unused for long periods
of time.
13.Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally or has been dropped.
14 .This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquid such as vases shall be placed on the apparatus.
1
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompanying
the appliance.
IB-CD208(LC)-WM-E-060403
ADDITIONAL SAFETY INSTRUCTIONS
1.Power Sources - The appliance should be connected to a power supply
only of the type described in the operating instructions or as marked on the
appliance.
2.Wall or Ceiling Mounting - The appliance should not be mounted to a wall
or ceiling.
3.Object and Liquid Entry - Care should be taken so that objects do not fall
and liquids are not spilled into the enclosure through openings.
4.Servicing - The user should not attempt to service the appliance beyond
that described in the operating instructions. All other servicing should be
referred to qualified service personnel.
Do not apply oil or petroleum products or solvents to any part of this set.
Use of controls or adjustments or performance of procedures other than
CAUTION
those specified herein may result in hazardous radiation exposure.
This compact disc player is classified as CLASS 1 LASER PRODUCT as
stated on the bottom of the set.
2
IB-CD208(LC)-WM-E-060403
BATTERY SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY OR
DAMAGE TO YOUR SET, READ AND FOLLOW THESE INSTRUCTIONS.
1. Use only the type and size of batteries mentioned in the operating instructions
booklet (batteries are not included with this set, please buy the proper batteries).
2. Do not dispose the batteries into a fire. The cells may explode. Check with
local codes for possible special disposal instructions.
3. Do not open or mutilate the batteries. Released electrolyte is corrosive and
may cause damage to the eyes or skin. It may be toxic if swallowed.
4. Be careful when handling batteries in order not to short the battery with conducting
materials such as rings, bracelets and keys. The battery or conductor may
over heat and cause burns.
5. Do not attempt to recharge non-rechargeable batteries. The batteries may
leak corrosive electrolyte or explode.
6. Do not attempt to rejuvenate the batteries identified for use with this product by
heating them. Sudden release of the battery electrolyte may cause burns or
irritation to eyes or skin.
7. All batteries should be replaced at the same time. Mixing fresh and dis-
charged batteries could increase internal cell pressure and rupture the batteries.
8. When inserting batteries into this product, the proper polarity (
direction must be observed. Reverse insertion of some or all of the batteries
may result in battery electrolyte leakage or explosion.
9. Remove the batteries from this product if the product will not be used for a long
period of time (several months or more) since during the period the batteries
could leak, damaging the product.
10. Discard weak or dead batteries as soon as possible since they are more likely
to leak in the product. Batteries should be replaced (depending on the product)
when the display gets dim or if the Low Battery Indicator shows or if the sound
gets distorted.
11. Do not store this product in high temperature areas. Batteries that are stored
in a freezer or refrigerator for the purpose of extending shelf life should
be protected from condensation during storage and defrosting. Batteries should
be stabilized at room temperature prior to use after cold storage.
12. If this product does not operate normally, see TROUBLE SHOOTING in this
instruction manual. If you cant resolve the problem, or if the product is damaged,
refer to the LENOXX WARRANTY INFORMATION. Opening or removing
covers may expose you to dangerous voltages or other risks. Incorrect
reassembly can cause electric shock when the appliance is subsequently used.
13. If liquid leaks from the batteries, carefully wipe this liquid. Do not allow it to
touch your skin, and discard the leaking batteries.
14. Do not mix batteries (OLD and NEW or CARBON and ALKALINE, etc.).
15. The use of rechargeable batteries is not recommended for this set because
their voltage and life is lower than standard batteries.
16. Installation of batteries should be done by an adult only.
and ) or
SAVE THESE INSTRUCTIONS
3
IB-CD208(LC)-WM-E-060403
CHOOSING THE POWER SOURCES
You can use the AC power or batteries as a power source.
To a wall outlet
NOTE: The polarized
BATTERY DOOR
(on the bottom of the set)
plug has two blades with
one wider than the other.
TIP:
Replace all the batteries
with new ones when the
POWER lamp dims or
the player stops
operating. Before you
replace all the batteries,
be sure to take out the
disc from the player and
remember to check the
Battery Safety Instructions
on Page 3.
If the discs do not play
on batteries, this means
the batteries are almost
used up. But the radio
may continue to play on
these weak batteries
because it uses less
power than the disc
player.
1. Connecting the AC power
Insert one end of the supplied AC power cord into
the socket located at the rear of the set, and the
other end into the 120V standard household outlet.
2. Using the player on batteries
Remove the AC plug from the back of the set and
wall outlet, then insert 6 size D batteries (not
supplied) into the battery compartment as shown.
Observe (+) and (-) polarities.
Install Batteries
as illustrated
4
IB-CD208(LC)-WM-E-060403
PLAYING A CD
CD DOOR
FUNCTION
switch
Connect the supplied AC power cord or batteries (refer to page 4).
1
2
3
TIP:
1. will show in the display if there is no CD disc in the CD compartment
or if the CD disc is upside down.
2. will show in the display when the CD DOOR is opened.
Slide the FUNCTION
switch to the MP3/CD
position (power on), the
POWER lamp will be on,
and the symbol
starts a new cycle in the
display.
Lift the CD DOOR to open
it and push a CD down
onto the center spindle.
The label side of the CD
disc should face upward.
Close the CD DOOR. The
display will show the
symbol , total tracks
and total playing time of
that CD, then the player
will begin to play
automatically.
5
POWER lamp
Track number
currently playing
IB-CD208(LC)-WM-E-060403
Track number
USE THESE BUTTONS FOR
ADDITIONAL OPERATIONS
Open the CD DOOR
PHONES jack
FUNCTION
switch
VOLUME
control
STOP
SKIP/SEARCH
BACKWARD
by lifting here
10+/ALBUM
PLAY/
PAUSE
SKIP/SEARCH
FORWARD
TIP
When the CD
play is paused,
the track number
currently playing
will flash and no
music will play.
To resume play,
press the PLAY/
PAUSE button
again, the track
number will stop
flashing and
music will play.
If you just started
to play a disk, the
music may stop
or skip for a few
seconds. If the
music is playing
for a few minutes
and had time to
load, the music
will not skip.
To
Adjust the volume
Stop playback
Pause playback
Go to the next track
Go back to the previous
track
Go to the next 10th
track
Locate a point in a song
Remove the CD
Turn off the power
To enjoy the music without
disturbing others
6
Press or Adjust
VOLUME control
STOP button
Press PLAY/PAUSE, the track
number currently playing will
flash during pause. Press
again to resume play after
pause.
SKIP/SEARCH
FORWARD
SKIP/SEARCH
BACKWARD
Press the 10+/ALBUM
button.
or
Press and hold down while
playing till you find the point.
Press the STOP button first,
then lift the CD DOOR.
Slide the FUNCTION switch
to the OFF position, the
POWER lamp turns off.
Insert your headphones (not
included) plug them into the
PHONES jack.
IB-CD208(LC)-WM-E-060403
CD REPEAT, INTRO AND RANDOM PLAY
You may have repeat, intro and random play functions by pressing the REPEAT
button. Press the REPEAT button several times, the display will show the
followings in turn:
REPEAT ONE REPEAT ALL INTRO RANDOM NORMAL PLAY
Single Track Repeat
Plays one song over and over till you press STOP .
Press the REPEAT button once,
in the display. Select the song you want to repeat with
either of the SKIP/SEARCH buttons ( or ), or
10+/ALBUM button.
The song currently playing will repeat over and over
until you press the STOP button.
All Tracks Repeat (Disc Repeat)
Repeats all songs in order till you press STOP.
Press the REPEAT button twice,
in the display.
All the songs will keep playing in sequence 1, 2, 3, etc.
and when finished, the player will start all over again
until you press the STOP button.
Intro Play
This plays the first 10 seconds of each song in
sequential order.
Press the REPEAT button three times,
in the display. Press the PLAY button once, the first 10
seconds of each song on the CD will play in sequential
order.
When you find a song you like, press the PLAY button
again,
INTRO
will be resumed, that song (and the following songs)
will play normally.
will not show in the display, normal play
Random Play
This plays the songs on the disc in random order.
Press the REPEAT button four times,
in the display. Press the PLAY button once, the player
begins random play.
Press the SKIP/SEARCH buttons ( or ) to skip
to the next random song.
To quit random play, press the REPEAT button once
again, the player will play normally.
REPEAT ONE
REPEAT ALL
INTRO
RANDOM
7
will show
will show
will flash
will flash
IB-CD208(LC)-WM-E-060403
CD PROGRAMMED PLAY
You can make a program up to 20 tracks in the specified order you want them
to be played.
Programming Example
Program Number
Track Number (song number)
1
2
3
2
5
415
8
264
718
etc.
etc.
1
1. Slide the FUNCTION switch to the MP3/CD
position. Make sure the set is in the
2. Press the PROGRAM button once. The letters
will flash in the display .
3. Press the SKIP/SEARCH buttons ( or ) or
10+/ALBUM button to select the tracks to be
programmed in the order that you want.
4. Press the PROGRAM button to confirm. The
programmed number 2 (example) will now show in
the display, then ready for your next selecting of
track.
5. Repeat above steps 3 and 4. You can program up
to 20 tracks.
6. After programming is finished, press the PLAY
button to start programmed play.
NOTE:
1. Programming can only be done in
2. The programmed memory will be lost if the STOP button is pressed twice, or
the alkaline batteries are exhausted or removed, or AC power is shut off, or the
CD DOOR is opened.
3. The player will stop automatically after all the programmed tracks have been
played.
STOP
STOP
mode.
mode.
track number
programmed
number
To change the current program
Just create a new program following the above programming procedure.
To cancel Programmed Play
Press the STOP button twice, the word PROGRAM will disappear from the
display.
8
IB-CD208(LC)-WM-E-060403
MP3 PLAYBACK
CD DOOR
FUNCTION switch
Connect the supplied AC power cord or batteries (refer to page 4).
1
2
3
Slide the FUNCTION switch to the MP3/
CD position. The symbol starts a
different cycle in the display, and the
POWER lamp lights up.
Lift the CD DOOR to open it and push an
MP3 disc down onto the center spindle.
The label side of the MP3 disc should
face upward.
Close the CD DOOR, the display will
show all the symbols as illustrated. The
player will automatically play all the
songs of the MP3 disc.
POWER lamp
Album
Track
number
number
playing
time
General Information
1. Usually, you must write your own MP3 disc on your computers CD writer.
Or, you may buy pre-recorded MP3 discs from some on line sources.
2. When saving songs (audio files) onto your CD-R (or CD-RW), you must
save them as .MP3 (DOT MP3) files. Do not save them as .DOC or
.TEXT, .PDF etc. when downloading, converting or saving files as MP3 files.
3. Do not save TEXT files as .MP3 files because they will not play and they
may interfere with the set.
4. Do not attempt to combine normal CD audio tracks and MP3 tracks onto
one CD because the set will only recognize the audio tracks and play those.
9
IB-CD208(LC)-WM-E-060403
OTHER MP3 OPERATIONS
Operation
Press
Display window shows
To pause play
To release pause and
resume play
To stop
To turn off the power
To skip to the next track(s)
To skip to the next 10th
track(s) quickly
To skip to the previous
track(s)
To go ahead at high speed
(search)
To go back at high speed
(search)
PLAY/PAUSE
button
Track number currently playing
PLAY/PAUSE
button
STOP button
Total track
Total
number
album
STOP button once and slide the FUNCTION
to OFF position.
SKIP/SEARCH FORWARD button
once
(or repeatedly)
Press the 10+/ALBUM button once, every time
you press it, the player will skip to the next 10th
track or the end track of the disc.
SKIP/SEARCH BACKWARD button
once (or repeatedly)
Keep SKIP/SEARCH FORWARD button
depressed and release it when the desired
music section of the disc is found.
Keep SKIP/SEARCH BACKWARD button
depressed and release it when the
desired music section of the disc is found.
Press and hold down the 10+/ALBUM button
during play or in STOP mode, until the album
To change the ALBUM
number flashes. Press the SKIP/SEARCH
buttons (
or ) to choose the album.
Press the PLAY button to start the selected
album play.
TIP:
1. will show in the display if there is no MP3 disc in the CD compartment
or the MP3 disc is upside down.
2. will show in the display if the CD DOOR is opened.
3. It may take about 10 to 30 seconds to read the disc depending on how many
albums and songs are recorded on your MP3 disc.
10
IB-CD208(LC)-WM-E-060403
MP3 REPEAT, INTRO AND RANDOM PLAY
You may have repeat, intro or random play functions by pressing the REPEAT button.
Press the REPEAT button several times, the display will show the followings in turn:
REPEAT ONE REPEAT DIR REPEAT ALL INTRO RANDOM NORMAL PLAY
Single Track Repeat
Plays one song over and over till you press the STOP button.
Press the REPEAT button once, the words
appear in the display. Select the song you want to repeat
with either of the SKIP/SEARCH buttons (
10+/ALBUM button.
The song currently playing will repeat over and over till you
press the STOP button.
All Tracks Repeat (Directory Repeat)
Repeats all songs in order till you press the STOP button.
Press the REPEAT button twice, the words
show in the display. Select the directory that you want to
repeat with either of the SKIP/SEARCH buttons ( or
) or 10+/ALBUM button.
All the songs of that directory will keep playing in sequence
1, 2, 3, etc. and when finished, the player will start all over
again until you press the STOP button.
All Tracks Repeat (Disc Repeat)
Repeats all songs in order till you press the STOP button.
Press the REPEAT button three times, the words
will show in the display.
ALL
All the songs of the MP3 disc will keep playing in sequence
1, 2, 3, etc. and when finished, the player will start all over
again until you press the STOP button.
Intro Play
This plays the first 10 seconds of songs in sequential order.
Press the REPEAT button four times, the word
flashes in the display.
Press the PLAY button, the first 10 seconds of each
song on the MP3 disc will play in sequential order.
When you find a song you like, press the PLAY button
again, normal play will be resumed, that song (and the
following songs) will play
NORMALLY.
Random Play
This plays the songs on the disc in random order.
Press the REPEAT button five times, the word
will
flash in the display.
Press the PLAY button, this will play all of the songs in
random order selected by the player.
Press the SKIP/SEARCH buttons
to the next random song.
To quit random play, press the REPEAT button again,
the player will resume play normally.
( or )
REPEAT ONE
or ) or
REPEAT DIR
RANDOM
, to skip
11
will
REPEAT
will
REPEAT
REPEAT
REPEAT
INTRO
REPEAT
IB-CD208(LC)-WM-E-060403
X 2
X 3
X 4
X 5
MP3 PROGRAMMED PLAY
The tracks (songs) on the disc can be programmed (arranged in advance) to
play in any order you prefer (up to 20 tracks can be programmed).
Programming Example
Program Number
Album Number
Track Number (song number)
(title number)
23 4
1
3610417
35
81
6
5
2
4
7
2
11
etc.
8
etc.
5
etc.
During programming, the word
your preferred order, follow steps below:
1. Slide the FUNCTION switch to the MP3/CD position.
Make sure the set is in
2. Press the PROGRAM button once, the album number
will flash in the display.
3. Press the SKIP/SEARCH buttons ( or ) to
select album number, then press the PROGRAM button,
the letters will flash. Press the SKIP/SEARCH
buttons to select the track number to be programmed.
4. Press the PROGRAM button to confirm, the programmed
number will show in the display, and ready for the next
selection of track.
5. Repeat above steps 3 and 4 to program other
tracks till you finish.
6. After programming is finished, press the PLAY button
to begin programmed play.
NOTE:
1. Programming can only be done in
2. The programmed memory will be lost if the STOP button is pressed twice,
or the alkaline batteries are exhausted or removed, or AC power is shut off,
or the CD DOOR is opened.
3. The player will stop automatically after all programmed tracks have been
played.
PROGRAM
STOP
mode.
shows in the display. To program play in
album number
track number
programmed
number
STOP
mode.
To change the current program
Just create a new program following the programming procedure.
To cancel programmed play
Press the STOP button twice, the word PROGRAM will vanish from the display.
12
IB-CD208(LC)-WM-E-060403
BASIC INTRODUCTION TO MP3
MP3 files are music files which have been compressed into the MP3 format.
The player plays MP3 files which have been written onto a CD disc.
The first thing you will need is an
IBM compatible PC computer (at
least Pentium class) or an apple
computer (at least G3 class) with
lots of RAM and a CD-R or CD-RW
writer. Then you will need some
software. (Either it is in your new
computer already or you may have to
buy this from MusicMatch or a similar
company. You may go to the
Website www.musicmatch.com or
www.nero.com.)
To play MP3 files on this player, you
will need to make (record) a disc with
these MP3 files on them.
We recommend you get some books
or information from the internet to help
you learn this exciting new way to
store & play hundreds of songs in
MP3 format. Also you may search
the web for MP3 and you will
immediately find a world of information
and songs.
NOTE: Most audio CD players cannot
play MP3 files. This player can
play both MP3 and normal
music files. (It
CDs that have
normal audio files on the same
CD.)
To download an MP3 file (song) from
a website (like www.mp3.com), go to
http://www.mp3.com and you can find
a search link at the top of the
homepage that allows you to search
for MP3 files. Input a key word and
click on that link and you will find many
songs by many new artists. To
download an MP3 file, click on
software, then get MP3 link or newer
software, register and click on
download. We recommend you make
a new folder for MP3 files.
WILL NOT
BOTH MP3
play
and
You will also need blank CDs that
are recordable, these are called
CD-R or CD-RW (CD-R discs can
be recorded on only once, CD-RW
can be erased and rewritten but are
much more expensive).
Successful recording of a CD needs
an uninterrupted stream of high
speed data. For best results, limit or
close your other programs on the
computer while recording to prevent
buffer underruns or empty spots on
the disc.
(NOTE: You can also learn all about
MP3 at the mp3.com site)
You can play MP3 songs on most
computers of today or you can
highlight them for downloading &
burning (recording) them onto a
CD later. Note this player will play
MP3 songs which end in the extension
.MP3 (dot MP3). You can select how
to save a file, select .MP3 as the
correct extension on your computer.
If you want to convert your existing
records or tapes to MP3 discs, you
will need to record them using a sound
card with appropriate jacks. You will
also need software such as
MusicMatch or RealJukebox and a
set of audio cables to connect your
tape player to your sound card.
If you want to record your favorite
music CDs as an MP3, you need to
convert them into MP3 format.
Ripping is the term used for
converting audio files into MP3
format.
MP3 opens a whole new world of
music to you. Learn about this
exciting new format and enjoy.
13
IB-CD208(LC)-WM-E-060403
ABOUT MP3
WHAT IS THE MP3?
MP3 (MPEG 1 Audio Layer-3) is a
standard technology and format for
compressing a sound sequence. The
file is compressed to about 1/10 of its
original size. Sounds outside the range
of human hearing are compressed while
the sounds we can hear are not
compressed.
PLAYABLE MP3 FILES ON
THIS PLAYER
You can only play MP3 files recorded
by following requirements.
NOTE: While this player can play most
Usable media
CD-Rs and CD-RWs
Usable disc format
You can use ISO 9660 Level 1/2 and
Joliet extension format discs. This unit
can display only 1-byte characters. (2byte characters like those of Japanese
are displayed as -.)
The major specification of the usable
disc format is:
NOTES
THE USABLE NUMBER OF
FOLDERS/FILES
MP3 files it cannot play all files
and may not play all MP3
formats.
Maximum directory steps: 8
Usable characters for a file/folder
name: A - Z, 0 - 9, _ (underscore)
Maximum number of characters for
a file name: 64 and a 3-character
extension code
When naming. be sure to add the file
extension mp3 to the file name.
If you put the extension mp3 to a file
other than an MP3 file, the player
cannot recognize the file properly.
The file name does not correspond
to the ID tag.
Maximum number of folders: 511
Maximum number of files: 511
SETTINGS FOR COMPRESSION
SOFTWARE AND WRITING
SOFTWARE
To compress a source for an MP3
file, we recommend setting the
transfer bit rate of the compression
software to 44.1 kHz, 128kbps,
and Constant Bit Rate.
Please check the maximum
capacity of your CD-R / CD-RW as
they come in a different capacity
ranges.
To record at one time up to the
maximum capacity on media that
has nothing recorded it, set to Disc
at Once.
NOTES FOR SAVING FILES
ON THE MEDIA
When the disc is inserted, the player
reads all the files on that disc. If there
are many folders or non-MP3 files on
the disc, it may take a long time for play
to begin or for the next MP3 file to start
play.
Do not save unnecessary folders or
files other than MP3 ones in the disc to
be used for MP3 listening.
DO NOT
record any other files other than
MP3 files on the CD. If you record nonmp3 files onto the CD, the player may
not operate properly. Please record
ONLY MP3
NOTE: CD-Rs or CD-RWs playback
NOTE: For best results and for the best
14
files onto the CD.
capability at this CD/MP3 player
may vary depending on quality
of media, CD-Burner, speed of
burning and application
software.
reading ability, try to make your
MP3 recordings at lower
speeds. The most accurate
speed that we tested for
playability is 4X.
IB-CD208(LC)-WM-E-060403
LISTENING TO THE RADIO
FUNCTION
switch
POWER lamp
TUNING knob
Connect the supplied AC power cord or batteries (refer to page 4).
1
Slide the FUNCTION switch to the
RADIO position, the POWER
lamp will turn on.
2
Slide the BAND switch to the
proper band position (AM, FM, or
FM STEREO) that you want.
FM antenna
FM stereo lamp
BAND switch
3
4
TUNING
F
M
Tune into the station you prefer
using the TUNING knob. Adjust
for the clearest sound.
S
T
E
R
EO
This indicator will light up when
receiving an FM Stereo
broadcast.
15
IB-CD208(LC)-WM-E-060403
USE THESE BUTTONS FOR
ADDITIONAL OPERATIONS
PHONES
jack
TIP
If the FM broadcast is
•
noisy, slide the BAND
switch from FM Stereo
to FM.
Next time you want to
•
listen to the radio, just
slide the FUNCTION
switch to the RADIO
position. The player
will automatically start
playing the previously
tuned station.
FUNCTION
switch
To
Adjust the volume
Turn off the Radio
To enjoy the music
without disturbing
others
VOLUME
control
Slide or Adjust
VOLUME control
Slide the FUNCTION
switch to OFF position
Insert your headphones
plug into the PHONES
jack (HEADPHONES
ARE NOT INCLUDED)
To improve broadcast reception
Change the position of the antenna for FM or FM
Stereo. Move the set itself for AM.
NOTE: Extend the FM antenna fully before bending
or rotating.
First extend the
FM antenna fully.
Then you may
bend it or rotate it.
Rotate the set
itself for better AM
reception.
16
IB-CD208(LC)-WM-E-060403
PRECAUTIONS
On Safety
Do not open the cabinet. As the laser
beam used in the DISC player section
may be harmful to the eyes, do not
attempt to disassemble the cabinet.
Refer servicing to qualified personnel
only.
Should any solid object or liquid fall
into the player, unplug the player, and
have it checked by qualified personnel
before operating it any further.
On Placement
Do not leave the player in a location
near a heat source, or in a place
subject to direct sunlight, excessive
dust or mechanical shock.
Do not place the player on an
inclined or unstable place.
Do not place anything within 1 inch of
the back of the cabinet. The ventilation
holes must not be covered for the
player to operate properly and prolong
the life of its components.
If the player is left in a car parked in
the sun, be sure to choose a location
in the car where the player will not be
subjected to the direct rays of the
sun.
Since a strong magnet is used for
the speakers, keep personal credit
cards using magnetic coding or
springwound watches away from the
player to prevent possible damage
from the magnets.
On Power Sources
For battery operation, use 6 size
D batteries. We recommend alkaline
batteries for longer life.
When the batteries will not be used
for a few weeks or more, remove
them to avoid damage that can be
caused by battery leakage or
corrosion.
On Operation
If the player is brought directly from
a cold to a warm location, or is placed
in a very damp room, moisture may
condense on the lens inside the DISC
player section. Should this occur, the
player will not operate properly. In
this case, remove the DISC and wait
about an hour for the moisture to
evaporate.
This player has an anti-skip feature,
small bumps will not stop the music.
However this set must play a few
minutes for the anti-skip feature to
become active.
17
IB-CD208(LC)-WM-E-060403
MAINTENANCE
Cleaning the lens
A dirty lens will cause sound skipping.
If the lens is very dirty, the player may
not work. We suggest using a special
cleaning disk (not included) available in
most music and Hi-Fi stores. However,
if you do not have one, you may use a
cotton swab very slightly dampened
with alcohol to clean the lens.
Cleaning the cabinet
Wipe with a soft cloth. If the cabinet is
very dirty, dampen (not dripping wet)
the cloth with a weak solution of soapy
water, and then wipe clean.
Cleaning the Discs
Fingerprints should be carefully
wiped from the surface of disc with
a soft cloth. Unlike conventional
records, compact discs have no
grooves to collect dust and
microscopic dirt, so gently wiping
them with a soft cloth should
remove most particles. Wipe in a
straight motion from the center to
the edge.
Handling Discs
Dirty, scratched or warped discs
may cause skipping or noise.
Handle the disc only by the edges.
To keep clean, do not touch its
surface.
Discs should be stored in their cases
after use to avoid scratches.
Do not expose discs to direct sunlight,
high humidity, high temperatures, or
dust, etc. Prolonged exposure to
extreme temperatures can warp the
disc (such as leaving the discs in
your car during summer time).
Do not stick or write anything on the
music side of disc. Sharp writing
instruments, or the inks used in some
felt-tip pens, may damage its surface.
To remove the Disc
Open the CD DOOR by lifting the CD
DOOR, hold the disc by the edge while
slightly pressing on the center spindle
as illustrated, then lift it from the edge
to release and remove.
Never use thinner, benzine, record
cleaner or antistatic spray on a
compact disc. Such chemicals can
damage its plastic surface.
NOTE
Always press the STOP button and
wait for the disc to stop rotating before
opening the CD DOOR to remove the
disc.
18
IB-CD208(LC)-WM-E-060403
TROUBLE SHOOTING
Problem Remedy
Insert the AC plug into a wall outlet securely.
The power is not on.
General
There is no sound.
Make sure the batteries are installed
correctly and they are fresh.
Make sure the FUNCTION switch is at
the right position as you want.
Adjust the volume.
Unplug the headphones when listening
through speakers.
appears in the display
even when a disc is in place.
Discs do not play.
CD/MP3 player
The sound drops out.
CD/MP3 does not play while
the radio may continue to
play.
MP3 playback does not work
or stops.
The sound is weak or has
poor quality.
Radio
Insert a CD or an MP3 disc with the label
side up.
Make sure that the CD compartment is
closed.
Clean the disc.
Take out the disc and leave the CD DOOR
open for about an hour to dry moisture
condensation.
Make sure the FUNCTION switch is at the
MP3/CD position.
Clean the discs, or replace them if the discs
are badly damaged.
Place the player in a location with less
vibration.
Check if the batteries are fresh.
Your MP3 disc may not be supported on
this player. This player will play most
standard MP3 discs.
It is normal since the radio uses less power
than the CD/MP3 player.
Re-burn a new MP3 disc.
Replace all the batteries with new ones if
they are weak.
Bring the set near a window, or rotate the
set for better AM reception; or draw out
the FM antenna for better FM reception.
19
IB-CD208(LC)-WM-E-060403
SPECIFICATION
General Description
Power source:
AC 120V, 60Hz 12 Watts
DC 9V (6 size D batteries, not included)
(Alkaline batteries are recommended)
Speakers:
Output power:
Dimensions:
2 - 3 1/2 8 ohm
1.8W/channel
Width: 12 7/8
Depth: 9 5/8
Height: 5 7/8
Weight: 2 KGs (without batteries)
CD/MP3 Section
Frequency response:
Laser wavelength:
Error correction method:
Pickup: Optical 3-beam semiconductor laser
NOTE: CD-Rs or CD-RWs playback capability at this CD/MP3 player may
vary depending on quality of media, CD-Burner, speed of burning and
application software.
50Hz - 15kHz +1/-2dB
760 - 800 NM
CIRC
(780 nm wavelength)
Radio Section
Frequency range: FM: 88 - 108 MHz
AM:
530 - 1700 kHz
LENOXX reserves the right to make design and specification changes for
product improvement.
PROTECT YOUR FINE FURNITURE!
WE RECOMMEND A CLOTH OR OTHER PROTECTIVE MATERIAL BE
PLACED UNDER THE SET WHEN PLACING IT ON SURFACE WITH A
NATURAL OR LACQUER FINISH.
For Customer Service
Dial 1-800-315-5885 (MONDAY - THURSDAY 9:00 AM - 5:00 PM, FRIDAY
9:00 AM - 1:00 PM EST)
or Visit Our Website: http://www.lenoxx.com
© 2003 LENOXX ELECTRONICS CORP.
2 GERMAK DRIVE
CARTERET, N.J. 07008
MADE & PRINTED IN CHINA
20
IB-CD208(LC)-WM-E-060403
Loading...
